MINI FRIDGE
SKU: ZX-PF-4D/ZX-PF-4F/ZX-PF-4B
mini fridgr
CONTENTS
01
02
02
SAVE THESE INSTRUCTIONS HOUSEHOLD USE ONLY
NOTES ON THE CORD PLUG
IMPORTANT SAFEGUARDS
02
PRODUCT DESCRIPTION
03
ILLUSTRATION FOR POWER SUPPLY
03-05
OPERATION INSTRUCTION
05-06
TIPS FOR OPERATION
06
SCOPE OF APPLICATION
06
TROUBLESHOOTING
06
CLEANING AND MAINTENANCE
07
SERVICE
07
GUARANTEE
02
PRODUCT PARAMETERS
IMPORTANT SAFEGARDS
1.When using the product, please note that the voltage used is absolutely correct (the applicable
voltage of this product is clearly marked on the product nameplate).
2.To ensure optimal performance, keep the Mini cooler’s fans clear of dirt and debris. Stuck fans will
overheat the unit and can pose a potential fire hazard.
3.Do not place any cloth or paper products on the unit.
4.When plugging in the unit, ensure that the power cord is inserted tightly into the socket. A loose
socket can cause damage or fire.
5.When using the unit in a car/vehicle with the DC power cord, the vehicle’s engine must be turned on
first. When the engine is running, the unit can then be plugged into the vehicle's adapter. This prevents
a power surge and potential property damage, injury, and/or fire.
6.The vehicle-used function can be only activated when the vehicle is running. Be sure to turn off its
power and unplug the vehicle-used power cord after the vehicle stops running.
7.Keep the unit away from flammable items and running water to prevent damage, injury, and/or fire.
8.DO NOT attempt to open, break, or refit the appliance.
9.DO NOT submerge or rinse under running water.
10.When packing the unit, do not place upside-down.
11.Avoid dropping or banging the unit.
12.DO NOT leave the appliance in the rain.
13.Adult use and supervision only. This is not a toy. Children should not play with this Mini cooler. For
people with reduced physical, sensory, and/or mental capabilities, use precaution and follow all
instructions when operating this unit to ensure safety.
14.Always keep ventilation openings clear of obstruction.
15.DO NOT use other electrical appliances inside the food storage compartments of the appliance.
16.If the power cords supplied with the Mini cooler are damaged in any way—DO NOT attempt to repair
them; damaged power cords must be replaced by the manufacturer.
17.When the power cord is damaged, do not touch the AC power cord with your hands to avoid danger.
18.The product should not be used for transporting or loading the acid-corrosive items, and the product
should not be wiped with corrosive solvents.
19.Use this product in strict accordance with the instructions, please do not disassemble the internal
parts without permission.
20.The product should be stored in a place which is tidy and of good draft, and a ventilation channel
with a width of 10cm should be kept around it. And do not put the product at the rainy places or the
places with heat sources, such as electric stoves, LPG stoves, heat pipes or flames.
21.The Mini Cooler should be cleaned regularly if there is residual water inside it.
22.The Mini Cooler is not allowed to be used for freezing fresh meat. It is better to put frozen foods and
drinks into it for storage.
23.Please do not open the door frequently and the door cannot be opened for too long in order to keep
contents inside it be fresh.
24.Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
25.DANGER: Risk of child entrapment. Before you throw away your old refrigerator or freezer:
* Take off the doors.
* Leave the shelves in place so that children may not easily climb inside.
01
02
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
NOTES ON THE CORD PLUG
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric
shock, this plug will fit in a polarized outlet only one way. If the plug does not fit fully into the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician. Do not modify the plug in any way.
PRODUCT DESCRIPTION
1.This Mini cooler is a great way to keep food and drinks cool. It is of simple and cute appearance,
compact, easy to carry, as well as of long service life and low power consumption. It is a good helper
for home and travel use.
2.This product is fully embodied a concept of "Green and Environmentally-friendly”. And this product
uses semiconductor refrigeration technology, it has no bulky compressor and no refrigerant to avoid
noise and fluorine pollution. It is an environmentally-friendly refrigeration product without pollution.
3.This product is particularly suitable for drivers, tourists, migrant workers, singles, mother, office
workers and students due to its functions, light weight, small size and easy-to-carry.
4.This product has simple structure and long service life, and it is convenient to maintain, and it is of
low power consumption and strong shock-resistant capability.
1. Front view
2. Side view 3. Back view
PRODUCT PARAMETERS
Product name: Mini Cooler SKU: ZX-PF-4D/ZX-PF-4F/ZX-PF-4B
Rated power: 36W
Rated voltage: 120V~/12V
Working principle: Semiconductor
refrigeration technology
Cooling temperature: ≥59℉lower than the current ambient
temperature
Heating temperature: Heat up to 140℉±50℉
ILLUSTRATION FOR POWER SUPPLY
OPERATION INSTRUCTION
Before plugging in the Mini cooler, make sure the Power switch of the unit is set to the of “ ” setting.
1.Vehicle use (DC 12V)
CAUTION: Car/vehicle engine must be turned on first before plugging in the cooler. This precaution
prevents a power surge that can lead to the unit overheating and/or becoming a potential fire risk.
（1）Insert the DC connector of DC power cord into the unit’s DC port.
（2）Insert the DC plug into the appropriate cigarette-lighter outlet.
03
(3) Turn the Power switch to the “Cool” setting, the green indicator turns on.
2. Home use (AC 120V )
(1)Insert the AC connector of AC power cord into the unit’s AC port.
(2)Insert the AC plug into wall outlet.
(3) Turn the Power switch to the “Cool” setting, the green indicator turns on.
04
Cool: Green indicator lights up Heat: Red indicator lights up
3. Operation for “Cool” and “Heat”
(1) When cooling, turn the “Cool and Heat Switch”to "Cool" setting, the green indicator lights up and
the Mini Refrigerator starts to cool.
(2) When heating, turn the “Cool and Heat Switch” to "Heat" setting, the red indicator lights up and
the Mini Refrigerator starts to heat.
(3) When need to turn off the Mini Refrigerator, turn the “Cool and Heat Switch” to the middle “OFF”
position, and the Mini Refrigerator stops working.
(4) When make switch between "Cool" and "Heat" settings, be sure to turn the switch to “OFF”setting
firstly and then switch to another setting after 15 minutes. Do not directly make switch between “Cool”
and “Heat” setting as the cooling system of the Mini Refrigerator may be damaged due to the drastic
change of temperature.
1.The closer to the cooling position, the better the cooling effect.
2.Metal cans can be selected for cooling drinks for better results.
3.The fruits such as watermelon can be cut into two halves and be sealed by the plastic wrap, and
then make its flat surface be attached to the inner wall of the Mini Cooler.
4.For make the meal be fresh, firstly put the meal into a flat stainless steel plate, and then seal the
plate with the plastic wrap, finally, make the bottom surface of plate be attached to the inner wall of
the Mini Cooler .
5.Cosmetics and medicines should be spread on the inner wall of the Mini Cooler flatly. The closer to
the cooling module, the better the cooling result.
6.Pre-chilled food and drinks are recommended to put into this unit. If drinks are at room temperature
it will take 2-3 hours to chill them.
NOTE: When need to turn off the Mini Cooler, turn the “Power switch” to the position of “ ” , and the
Mini Cooler stops working.
TIPS FOR OPERATION
05
1.Application places: Car, home, yacht, office, dormitory and cosmetics store etc.
2.The objects which are suitable for cooling: Fruits, bottled/canned beverages, tea, medicines,
breast milk and cosmetics etc.
3.The objects which are not suitable for cooling: Frozen foods such as ice cream and others ,
chemical reagents, and meat etc.
1. If the Mini Cooler is not energized, please follow the steps below to operate:
(1) Check and make sure the power cord is properly connected to the power outlet.
(2) Check and make sure the Mini Cooler is turned on.
(3) Check and make sure the cigarette lighter is properly connected and turned on, and please clean
the base of the cigarette lighter with a non-metallic brush if it is contaminated.
2. If the cooling effect is not good, please contact customer support.
1.Before perform cleaning and maintenance, the “Power switch” must be firstly turned off and then
unplug to disconnect the power source.
2.Wipe the dirt and dust on the surface of the body with a piece of soft cloth dipped with detergent.
And you can use a piece of soft cloth dipped with warm water to clean the inside of the appliance.
3.The body must not be rinsed with water, especially the parts of the body such as the ventilation
openings of the switch socket, otherwise it will cause damage to the product and a risk of electric
shock.
4.When the unit is off and at room temperature, take a soft cloth and gently wipe down the inside of
your unit to remove any moisture that may accumulate. This is recommended once or twice a week.
SCOPE OF APPLICATION
TROUBLESHOOTING
CLEANING AND MAINTENANCE
06
SERVICE
Please call our customer service hotline if you encounter problems during use.
1.Welcome to use the vehicle-used series products. Please read this manual carefully before using it,
pay special attention to "IMPORTANT SAFEGARDS", and save this manual for future reference.
2.If this product is given to others, please give it together with this instruction manual.
3.The upgrade and specification of this product are subject to change without notice. The form and
color of the actual product may be slightly different from those shown on the manual, please
understand!
GUARANTEE
The customers can contact the after-sales, explain the reason for the return and reach an
“Agreementon Returning Goods”. Customers who purchase the product will enjoy the
comprehensive service in accordance with the relevant national regulation
"Provisions on the Liability for the Repair, Replacement and Return of Some Commodities".
07
