T10 Jump Starter
User Manual
Cautions
T10 At A Glance
Thank you for choosing Suaoki.
Suaoki T10 is a 3-in-1 device, functioning as a jump starter to boost flat car battery,
as a portable power bank to charge your electronic devices and as a LED flashlight.
Please read the user manual carefully before use and keep it for future reference.
Failure to follow the instructions may result in injury.
1. ONLY use it to start a 12V vehicle (gas engine up to 5L,diesel engine up to 2L).
2. DO NOT use the jump starter to start a car when the remaining capacity is less than
50% or when it is still hot.
3. Disconnect the battery clamp from the jump starter and the vehicle immediately after
every starting attempt.
4. DO NOT use the jump starter to start the car in high frequency. Allow at least 30s of
resting time before jump starting a car again.
5. DO NOT charge the product immediately after use or while it is still hot.
6. Please charge the jump starter at least once a month to extend battery life.
7. DO NOT allow the metal teeth of the red clamp to touch the metal teeth of the black
clamp.
8. Please keep this product away from children.
9. Please DO NOT disassemble this product.
10. Please store and charge the jump starter at a dry and well-ventilated place. Keep it
away from corrosive, flammable and explosive materials.
11. DO NOT expose this product to extreme environment where the temperature and
humidity is high.
12. Never burn or incinerate this product because it may explode and generate toxic
fumes and other potentially harmful chemicals.
13. Never insert foreign objects into any input or output ports, because it may cause short
circuit which will damage the battery and even cause fire and personal injury.
14. If you find the jump starter inflates, please stop using it at once.
· 1 ·
① Jumping Port
②③ USB Output Port
④ Input Port
⑤ LED Flashlight
⑥ Power Button
⑦ Power Indicator lights
EN
Instructions
● Reading the power indicator
· 2 ·
ENGINE
START
15V/1A
①
②
③ ④ ⑤
⑥⑦
1. Check the remaining power level
Press the power button to activate the lights.
Suaoki T10 has 4 indicator lights in total to display the amount of battery power left. See
the chart below to understand how the No. of lights and battery level corresponds:
2. Check the current charging status
The indicator light will flash one by one when the jump starter is being charged. A solid
light means a fully charged battery level. For example, when 2 lights are illuminated and
a third is blinking, that means the unit is between 50%-75% charged. Once the third light
stops blinking the unit is 75% charged.
※ Note:
It takes around 4 hours to fully charge the jump starter. Over-charging is best to
be avoided as it may raise safety concerns and shorten battery life.
No. of lights
Battery level
1 light
25%
2 lights 4 lights3 lights
50% 75% 100%
EN
· 3 ·
● Charging the jump starter
Both the power adapter and the car charger can charge the jump starter.
Charging with adapter
First step: Insert the adapter into a socket.
Second step: Insert the other end of the adapter into the input port of the jump starter.
Charging with car charger
1. Plug the car charger into the socket of cigarette lighter on your 12V vehicle.
2. Insert the other end into the input port of the jump starter.
※ Note:
1. You'd better charge it at least once a month in order to extend battery life.
2. Don’t charge it immediately after using it to start a car or while it is still hot.
3. It takes around 4 hours to be fully charged (with original adapter). Prolonged charging
time is a practice best to be avoided as it may raise safety concerns and shorten
battery life.
● Jump starting a car
Remember to check the remaining power capacity of the jump starter. When less than
two indicator lights are on, do not use it to jump start a car.
1. Connect the red clamp to the positive
terminal(+) of the vehicle’s battery and
the black clamp to negative one(-).
2. Connect the battery clamp with the jump
starter.
3. Start the car. If the auto cannot be started,
you need to disconnect the battery clamp
from the jump starter and the vehicle. Wait
for at least 30 seconds, then repeat the
steps above.
4. Remove the battery clamp from the jump
starter and then remove the red and black
clamps from car battery immediately.
OUTPUT2
OUTPUT2
EN
Product Parameter Package Content
· 4 ·
● Charging electronic devices
Choose a suitable charging cable and insert the cable into the USB port of the jump
starter. Then insert the other end of the cable into the input port of the cell phone/tablet,
click the power button then your device is being charged.
● Using the LED flashlight
Press the power button for 3 secs to turn on the flashlight.
There are 3 LED light modes that appear in the following order:
1st click: Strong lighting mode
2nd click: SOS mode
3rd click: Strobe mode
4th click: Off
Our company provides customers with warranty of 12 months from the date of purchase.
Battery Capacity: 12000mAh/44.4Wh
Starting Outlet Voltage: 12V
Two USB Output: 5V-2.4A/2.4A（Max)
Charging Mode: 15V/1A
Start Current: 200A
Peak Current: 400A
Operating Temperature Range: -20℃ to
60℃ / -4℉ to 140℉
Warranty
For any inquiries or comments concerning our products, please send an email to
[email protected], and we will respond to you as soon as possible.
Contact us
●
1 x Suaoki T10 Jump Starter
●
1 x Adapter
●
1 x Car Charger
●
1 x Pair of Battery Clamps
●
1 x Micro USB Cable
●
1 x User Manual
※ Note:
1. Step 1 comes before step 2. For safety concern, please do not reverse the order.
2. DO NOT use the jump starter to start the car in high frequency, the time interval
between two starting attempts must be longer than 30s.
3. The jump starter cannot be used as a charger for the car battery.
EN
MADE IN CHINA
Web: www.suaoki.com
E-mail: support@suaoki.com
