530iB
EN Operator's manual 2-19
Contents
Introduction..................................................................... 2
Safety..............................................................................3
Assembly...................................................................... 10
Operation...................................................................... 10
Maintenance................................................................. 14
Troubleshooting............................................................ 15
Transportation, storage and disposal........................... 16
Technical data.............................................................. 17
Declaration of Conformity............................................. 19
Introduction
Product overview
7
10
98
11 12
19
13
1
2
3
6
4
5
14
15
17
18
16
20
21
1. Blower nozzle
2. Keypad
3. Power trigger
4. Handle
5. Support eyelet for harness (included accessory)
6. Supports
7. Bluetooth indicator
8. Cruise control indicator
9. Boost indicator
10. Warning indicator
11. On/Off button
12. Cruise control
13. Operator's manual
14. Battery indicator button
15. Battery status
16. Warning indicator
17. Battery (accessory)
18. Battery release button
2 2337 - 006 - 30.04.2025
19. Harness
1
20. Battery charger (accessory)
21. Charging and error indicator on charger
Product description
Husqvarna 530iB is a blower model with an electrical
motor.
We have a policy of continuous product development
and therefore reserve the right to modify the design and
appearance of products without prior notice.
Intended use
This product is designed for blowing leaves and other
debris from lawns, pathways, asphalt roads and the like.
Symbols on the product
Warning! The blower can be dangerous!
Careless or incorrect use can result in
serious or fatal injury to the operator
or others. It is extremely important that
you read and understand the contents
of the operator's manual. Please read
the operator's manual carefully and make
sure you understand the instructions
before using the machine.
Use eye protection.
Protected against splashing water.
The blower operator must ensure that
no people or animals come closer
than 15 metres. When several opera-
tors are working at the same site a
safety distance of at least 15 metres
must be in effect. The blower can for-
cibly throw objects that can bounce
back. This can result in serious eye
injuries if the recommended safety
equipment is not used.
yyyy wwxxxxx The rating plate shows the serial
number. yyyy is the production year,
ww is the production week and xxxxx
is the sequential number.
Direct current.
If the product features Bluetooth
®
wireless
technology. The Bluetooth
®
symbol will be
marked on the product name label. Refer
to
Product overview on page 2
.
Noise emission to the environment label
as per European Directive 2000/14/EC,
UK directives and regulations and New
South Wales legislation "Protection of the
Environment Operations (Noise Control)
Regulation 2017". The guaranteed sound
power level of the product is specified in
Technical data on page 17
and on the
label.
Symbols on the product or its packaging
indicate that this product cannot be
handled as domestic waste. This product
must be deposited at an appropriate
recycling facility.
The product agrees with the applicable
EC directives.
Note: Other symbols/decals on the product refer to
certification requirements for some markets.
Manufacturer
Husqvarna AB
Drottninggatan 2, SE-561 82 Huskvarna
Product damage
We are not responsible for damages to our product if:
• the product is incorrectly repaired.
• the product is repaired with parts that are not
from the manufacturer or not approved by the
manufacturer.
• the product has an accessory that is not from the
manufacturer or not approved by the manufacturer.
• the product is not repaired at an approved service
center or by an approved authority.
Safety
Safety definitions
Warnings, cautions and notes are used to point out
specially important parts of the manual.
WARNING: Used if there is a risk of
injury or death for the operator or bystanders
1
Sold separately in some markets.
2337 - 006 - 30.04.2025 3
if the instructions in the manual are not
obeyed.
CAUTION: Used if there is a risk of
damage to the product, other materials or
the adjacent area if the instructions in the
manual are not obeyed.
Note: Used to give more information that is necessary
in a given situation.
Work area safety
• Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
• Do not operate machines in explosive atmospheres,
such as in the presence of flammable liquids, gases
or dust.Machines create sparks which may ignite the
dust or fumes.
• Keep children and bystanders away while operating
a machine. Distractions can cause you to lose
control.
Electrical safety
• Machine plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs
with earthed (grounded) machines. Unmodified plugs
and matching outlets will reduce risk of electric
shock.
• Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
• Do not expose machines to rain or wet conditions.
Water entering a machine will increase the risk of
electric shock.
• Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the machine. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk
of electric shock.
• When operating a machine outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of
electric shock.
• If operating a machine in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of a RCD reduces the risk of
electric shock.
Personal safety
• Stay alert, watch what you are doing and use
common sense when operating a machine. Do not
use a machine while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating machines may result in
serious personal injury.
•
Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat or hearing
protection used for appropriate conditions will reduce
personal injuries.
• Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the machine. Carrying machines with your finger
on the switch or energising machines that have the
switch on invites accidents.
• Remove any adjusting key or wrench before turning
the machine on. A wrench or a key left attached to
a rotating part of the machine may result in personal
injury.
• Do not overreach. Keep proper footing and balance
at all times. This enables better control of the
machine in unexpected situations.
• Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
• If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
• Do not let familiarity gained from frequent use of
machines allow you to become complacent and
ignore machine safety principles. A careless action
can cause severe injury within a fraction of a second.
Machine use and care
• Do not force the machine. Use the correct machine
for your application. The correct machine will do the
job better and safer at the rate for which it was
designed.
• Do not use the machine if the switch does not turn
it on and off. Any machine that cannot be controlled
with the switch is dangerous and must be repaired.
• Disconnect the plug from the power source and/or
remove the battery pack, if detachable, from the
machine before making any adjustments, changing
accessories, or storing machines. Such preventive
safety measures reduce the risk of starting the
machine accidentally.
• Store idle machines out of the reach of children and
do not allow persons unfamiliar with the machines
or these instructions to operate the machines.
Machines are dangerous in the hands of untrained
users.
• Maintain machines and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect
the machines´s operation. If damaged, have the
machine repaired before use. Many accidents are
caused by poorly maintained machines.
• Keep cutting tools sharp and clean. Properly
maintained cutting machines with sharp cutting
edges are less likely to bind and are easier to
control.
4
2337 - 006 - 30.04.2025
• Use the machine, accessories and bits etc. in
accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the machine for operations
different from those intended could result in a
hazardous situation.
• Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the machine in unexpected situations.
Battery machine use and care
• Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used
with another battery pack.
• Use machines only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
• When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
• Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from
the battery may cause irritations or burns.
• Do not use a battery pack or machine that
is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour
resulting in fire, explosion or risk of injury.
• Do not expose a battery pack or machine to
fire or excessive temperature. Exposure to fire or
temperature above 130 °C / 265 °F may cause
explosion.
• Follow all charging instructions and do not charge
the battery pack or machine outside the temperature
range specified in the instructions. Charging
improperly or at temperatures outside the specified
range may damage the battery and increase the risk
of fire.
Service
• Have your machine serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the machine is
maintained.
• Never service damaged battery packs. Service of
battery packs should only be performed by the
manufacturer or authorized service providers.
Garden blower, garden vacuum and garden
blower/vacuum safety warnings
• Before use, check the supply cord and any extension
cord for signs of damage or aging. Do not touch the
cord before disconnecting the supply. Do not use the
machine if the cord is damaged or worn. A damaged
supply cord may result in electric shock, fire and/or
serious injury.
• Do not use the machine in bad weather conditions,
especially when there is a risk of lightning. This
decreases the risk of being struck by lightning.
• Wear eye protection and ear protection. Adequate
protective equipment will reduce the risk of personal
injury.
• While operating the machine, always wear non-
slip and protective footwear. Do not operate the
machine when barefoot or wearing open sandals.
This reduces the risk of injury to the feet.
• Do not wear loose fitting clothing or articles such
as scarves, strings, chains, ties, etc., that could get
drawn into the air inlets. Tie back or cover long hair
to make sure it does not get drawn into the air inlets.
If any of these items are drawn into the air inlets, it
can increase the risk of personal injury.
• Keep bystanders away while operating the machine.
Thrown debris can increase the risk of personal
injury.
• Never point the blower nozzle in the direction of
people or pets or in the direction of windows. Use
extra caution when blowing debris near solid objects,
such as trees, automobiles and walls that can cause
debris to ricochet. Thrown objects can damage
property and increase the risk of personal injury.
• Do not use the machine to blow anything that is
burning or smoking, such as cigarettes, matches or
hot ashes. These ignition sources may increase the
risk of fire.
• Do not touch the fan while still in motion. Turn off
the machine and wait until the fan stops before
removing any part that may give access to the fan.
This reduces the risk of injury from moving parts.
• When clearing jammed material or servicing the
machine, make sure the power switch is off.
Unexpected starting of the machine while clearing
jammed material or servicing may result in serious
personal injury.
General machine safety warnings
WARNING:
Read all safety warnings,
instructions, illustrations and specifications
provided with this machine. Failure to follow
all instructions listed below may result in
electric shock, fire and/or serious injury.
• Save all warnings and instructions for future
reference. The term "machine" in the warnings refers
to your mains-operated (corded) machine or battery-
operated (cordless) machine.
2337 - 006 - 30.04.2025
5
General safety instructions
WARNING: Read the warning
instructions that follow before you use the
product.
• This product is a dangerous tool if you are not
careful or if you use the product incorrectly. This
product can cause serious injury or death to the
operator or others. It is very important that you
read and understand the contents of this operator’s
manual.
• Do not change the product without an approval from
the manufacturer. Do not use a product that has
been changed by others and always use original
accessories. Changes that are not approved from
the manufacturer can result in serious injury or death
to the operator or others.
• Long term inhalation of chain oil fumes and sawdust
can cause health problems.
• This product produces an electromagnetic field
during operation. This field may under some
circumstances interfere with active or passive
medical implants. To decrease the risk of serious
injury or death, we recommend persons with medical
implants to turn to their physician and the medical
implant manufacturer before operating this product.
Safety instructions for operation
WARNING: Read the warning
instructions that follow before you use the
product.
• If you encounter a situation where you are uncertain
how to proceed you should ask an expert. Contact
your dealer or your service workshop. Avoid all
usage which you consider to be beyond your
capability.
• Make sure that you can move and stand safely.
Check the area around you for possible obstacles
(roots, rocks, branches, ditches, etcetera) in case
you have to move suddenly. Take great care when
you work on sloping ground.
• Keep a good balance and a firm foothold at all times.
Do not overreach.
• Listen out for warning signals or shouts when
you wear hearing protection. Always remove your
hearing protection as soon as the product stops.
• Do not operate the product near open windows.
• Show consideration to persons in your surroundings
by avoiding using the product at unsuitable times,
such as late in the evening or early in the morning.
Follow local regulations and ordinances.
• Use the product with the lowest possible airflow. It
is seldom necessary to use full airflow, and many
work procedures can be done at half airflow. A lower
airflow means less noise and less dust, and it is
also easier to keep control over the rubbish collected
together/moved.
• In dusty conditions slightly dampen the surface when
using the product.
• Use a rake or a brush to release rubbish stuck to the
ground.
• Hold the opening of the blower as close to the
ground as possible.
• Observe your surroundings. Direct the product away
from persons, animals, play areas, cars etc..
• Minimize the blowing time by lightly wetting dusty
areas or using spray equipment.
• Be aware of the wind direction. Work with the wind to
make your work easier.
• Stop the product and remove the battery if the
product starts to vibrate abnormally.
• Using the blower to move large piles is time
consuming and creates unnecessary noise.
• Clean up afterwards. Make sure that you have not
blown rubbish into someone's garden.
• Do not run with the product.
• The powerful currents of air can move objects at
such a speed that they can bounce back and cause
serious eye injuries.
• Do not direct the airflow towards people or animals.
• Stop the motor before you assemble or dismantle
accessories or other parts.
• Keep all parts of your body away from hot surfaces.
• Never put the product down when it is activated
unless you have it in clear sight.
• Stop the machine, and remove the battery. Make
sure that all moving parts have come to a complete
stop:
• whenever you leave the machine
• before clearing blockages or unclogging chute
• before checking, cleaning or working on the
machine
• Immediately shut off the power source and allow
the machine to stop if the cutting mechanism hits
any foreign objects or if the machine should start
making any unusual noise or vibration. Disconnect
the battery from the machine and take the following
steps before restarting and operating the machine:
• examine for damage
• replace or repair any damaged parts
6
2337 - 006 - 30.04.2025
• check for and tighten any loose parts
• Shut off the power source and disconnect the
machine from battery before cleaning unwanted
material if the machine becomes clogged.
• Do not transport this machine while the power
source is running.
• Do not tilt the machine while the power source is
running.
• The blower must not be used while on a ladder or
scaffolding.
• Do not use the product unless you are able to call for
help in case of an accident.
• Watch out for thrown objects. Stones, rubbish, etc.,
can be thrown up into the eyes causing blindness or
serious injury.
• Use a residual-current device (RCI) for increased
security when you charge the product. A residual-
current device is fitted to protect operators in case
an electrical fault should occur.
• This product is renowned for its low vibration load.
Overexposure to vibration can lead to circulatory
damage or nerve damage in people who have
impaired circulation. Contact your doctor if you
experience symptoms of overexposure to vibration.
Such symptoms include numbness, loss of feeling,
tingling, pricking, pain, loss of strength, changes in
skin colour or condition. These symptoms normally
appear in the fingers, hands or wrists.
• Only use the product for the purpose it was intended
for.
• It is not possible to cover every conceivable situation
you can face. Always exercise care and use your
common sense. Avoid all situations which you
consider to be beyond your capability. If you still feel
uncertain about operating procedures after reading
these instructions, you should consult an expert
before continuing.
• Operate the product only in daylight or in good
artificial light.
• Keep firm footing on slopes.
• Walk, do not run.
• Keep all air intakes clean.
• All covers, guards and handles must be fitted before
starting.
• A damaged or incorrect guard can cause injury. Do
not use the product that does not have an approved
guard attached.
Personal protective equipment
WARNING: Read the warning
instructions that follow before you use the
product.
• Always use approved personal protective equipment
when you use the product. Personal protective
equipment cannot fully prevent injury but it
decreases the degree of injury if an accident does
occur. Let your dealer help you select the right
equipment.
• Long term exposure to noise can result in damaged
hearing. In general, battery powered products
are relatively quiet but damage can result from
a combination of noise level and long usage.
Husqvarna recommends that operators use hearing
protectors when using products for a longer coherent
time of a day. Continual and regular users should
have their hearing checked regularly.
WARNING: Hearing protectors limit
the ability to hear sounds and warning
signals.
• Use approved eye protection. If you use a visor,
you must also use approved protective goggles.
Approved protective goggles must comply with the
ANSI Z87.1 standard in the USAs or EN 166 in EU
countries.
• Use clothing made of a strong fabric. Always use
heavy, long pants and long sleeves. Do not use
loose clothing that can catch on twigs and branches.
Do not wear jewelry, short pants, sandals or go with
bare feet. Put your hair up safely above shoulder
level.
2337 - 006 - 30.04.2025
7
• Keep first aid equipment close at hand.
• A breathing mask should be used when there is a
risk of dust.
Safety devices on the product
WARNING: Read the warning
instructions that follow before you use the
product.
• In this section the product’s safety features, its
purpose and how checks and maintenance should
be carried out to ensure that it operates correctly.
See instructions under the heading
Safety devices
on the product on page 8
to find where these parts
are located on your product.
• The life span of the product can be reduced
and the risk of accidents can increase if product
maintenance is not carried out correctly and
if service and/or repairs are not carried out
professionally. If you need further information please
contact your nearest servicing dealer.
• Never use a product with damaged safety
components. The product's safety equipment must
be inspected and maintained as described in this
section. If your product fails any of these checks,
contact your service agent to get it repaired.
• All servicing and repair work on the product requires
special training. This is especially true of the
product′s safety equipment. If your product fails any
of the checks described below you must contact your
service agent. When you buy any of our products we
guarantee the availability of professional repairs and
service. If the retailer who sells your product is not
a servicing dealer, ask him for the address of your
nearest service agent.
To do a check of the keypad
1. Press and hold the On/Off button (C).
C
B
A
a) The product is switched on when the green LEDs
of the battery indicator (B) is lit.
b) The product is switched off when the green LEDs
of the battery indicator (B) is out.
2. Refer to
Troubleshooting on page 15
if the warning
indicator (A) is lit or flashes.
To do a check of the power trigger
1. Push and release the power trigger to make sure
that it moves freely.
Battery safety
WARNING:
Read the warning
instructions that follow before you use the
product.
• Only use Husqvarna approved batteries. Refer to
Approved batteries on page 18
. The batteries are
software encrypted.
• Use Husqvarna approved batteries as a power
supply for the related Husqvarna products only.
Refer to
Approved batteries on page 18
. To prevent
injury, do not use the battery as a power supply for
other devices.
8
2337 - 006 - 30.04.2025
• Risk of electrical shock. Do not connect the battery
terminals to keys, screws or other metal. This can
cause a short circuit of the battery.
• Do not use batteries that are non-rechargeable.
• Do not put objects into the air slots of the battery.
• Keep the battery away from sunlight, heat or open
flame. The battery can cause burns and/or chemical
burns.
• Keep the battery away from rain and wet conditions.
• Keep the battery away from microwaves and high
pressure.
• Do not try to disassemble or break the battery.
• Use the battery in temperatures between -10 °C (14
°F) and 40 °C (104 °F).
• Do not clean the battery or the battery charger with
water. Refer to
Battery machine use and care on
page 5
.
• Do not use a battery that is damaged or does not
operate correctly.
• Keep batteries in storage away from metal objects
such as nails, screws or jewelry.
• Keep the battery away from children.
Battery charger safety
WARNING: Read the warning
instructions that follow before you use the
product.
• Risk of electrical shock or short circuit if the safety
instructions are not obeyed.
• Use an approved grounded mains socket that is not
damaged.
• Do not use other battery chargers than the one
supplied for your product. Only use Husqvarna
approved battery chargers to charge Husqvarna
approved batteries. Refer to
Approved batteries on
page 18
.
• Do not try to disassemble the battery charger.
• Do not use a battery charger that is damaged or do
not work correctly.
• Do not lift the battery charger by the power cord. To
disconnect the battery charger from a mains socket,
pull out the plug. Do not pull the power cord.
• Keep all cables and extension leads away from
water, oil and sharp edges. Make sure that the cable
is not caught between doors, fences or similar.
• Do not use the battery charger near flammable
materials or materials that can cause corrosion.
Make sure that the battery charger is not covered.
Pull out the plug to the battery charger if there is
smoke or fire.
• Only charge the battery indoors in a location with
good airflow and away from sunlight. Do not charge
the battery outdoors. Do not charge the battery in
wet conditions.
• Only use the battery charger where the temperature
is between 5 °C (41 °F) and 40 °C (104 °F). Use the
charger in an environment which has a good airflow,
dry and free from dust.
• Do not put objects into the cooling slots of the
battery charger.
• Do not connect the battery charger terminals to
metal objects as this can short circuit the battery
charger.
• Use approved wall sockets that are not damaged.
Safety instructions for maintenance
WARNING: Read the warning
instructions that follow before you do
maintenance on the product.
• Remove the battery before you do maintenance,
other checks or assemble the product.
• The operator must only do the maintenance and
servicing shown in this operator's manual. Turn to
your servicing dealer for maintenance and servicing
of a larger extension.
• Do not clean the battery or the battery charger with
water. Strong detergent can cause damage to the
plastic.
• If you do not do maintenance, it decreases the
life cycle of the product and increases the risk of
accidents.
• Special training is necessary for all servicing and
repair work, especially for the safety devices on the
product. If not all checks in this operator's manual
are approved after you have done maintenance, turn
to your servicing dealer. We guarantee that there are
professional repairs and servicing available for your
product.
2337 - 006 - 30.04.2025
9
Assembly
To assemble the tube on the product
1. Put the blower nozzle over the tubular end of the
product.
2. Push the blower nozzle in fully and turn the blower
nozzle to lock it to the product.
To install the eyelet for the harness
1. Install the eyelet onto the side of the chassis.
Note: Install eyelet onto the side that points away
from your body during operation.
2. Attach the eyelet with the screw.
To adjust the harness
1. Put on the harness.
2. Connect the product to the harness.
3. Adjust the harness for the best work position.
4. Adjust the side straps to make the product weigh
equally on your shoulders.
5. Adjust the harness to optimize the work position.
Operation
Introduction
WARNING: Read and understand the
safety chapter before you use the product.
Husqvarna Connect
Husqvarna Connect is a free app for your mobile device.
The Husqvarna Connect app gives extended functions
for your Husqvarna product:
• Extended product information.
• Information about, and help with, product parts and
servicing.
10 2337 - 006 - 30.04.2025
To start to use Husqvarna Connect
1. Download the Husqvarna Connect app on your
mobile device.
2. Register in the Husqvarna Connect app.
3. Follow the instruction steps in the Husqvarna
Connect app to connect and register the product.
Note: Husqvarna Connect app is not available for
download in all markets. Speak to your servicing
dealer for more information.
Husqvarna Fleet Services
™
Husqvarna Fleet Services
™
is a cloud solution that
gives the commercial fleet manager an overview of all
products. For more information about Husqvarna Fleet
Services
™
, refer to www.husqvarna.com.
To connect to the product with
Husqvarna Fleet Services
™
1. Download the Husqvarna Fleet Services
™
app to
your mobile device.
2. Log on to the Husqvarna Fleet Services
™
app.
3. Follow the instructions about how to pair the product
with Husqvarna Fleet Services
™
.
Bluetooth
®
wireless technology
Products with built-in Bluetooth
®
wireless technology
can connect to mobile devices and enables additional
functions.
The symbol for
Bluetooth
®
wireless technology comes
on when your mobile device is connected to the product.
To do a function check before you use
the product
1. Do a check of the air inlet for dirt and cracks. Use
a brush and clean off grass and leaves from the
product.
2. Make sure that the product works correctly.
3. Do a check of all nuts and screws and make sure
that they are tight.
To connect the battery charger
1. Connect the battery charger to the voltage and
frequency that is specified on the rating plate.
2. Put the plug in a grounded socket outlet. The LED
on the battery charger flashes green one time.
Note:
The battery does not charge if the battery
temperature is less than 0 °C (32 °F) or more than
50°C (122 °F). If the temperature is more than 50 °C/122
°F, the battery charger makes the battery become cool
before the battery charges.
To charge the battery
Note: Charge the battery if it is the first time that you
use it. A new battery is only 30% charged.
1. Make sure that the battery is dry.
2. Put the battery in the battery charger.
Note: The battery and battery charger can look
different between different models, but the procedure
is the same.
3. Make sure that the green charging light on the
battery charger comes on. That means that the
battery is connected correctly to the battery charger.
4. When all LEDs on the battery come on, the battery is
fully charged.
5. To disconnect the battery charger from the mains
socket, pull the plug. Do not pull the cable.
6. Remove the battery from the battery charger.
Note:
Refer to the battery and battery charger
manuals for more information.
2337 - 006 - 30.04.2025 11
To connect the battery to the product
WARNING: Only use Husqvarna
approved batteries in the product.
1. Make sure that the battery is fully charged.
2. Slide the battery into the battery holder of the
product. The battery must slide easily, if not, it is not
installed correctly.
3. Press the lower part of the battery and push it in as
far as it will go into the battery compartment. The
battery will lock into position when you hear a click.
4. Make sure that the latches snap in place correctly.
To start the product
1. Press and hold the On/Off button (A) until the green
LEDs of the battery indicator (B) comes on.
A
B
2. Use the power trigger to control the speed.
To stop the product
1. Release the power trigger.
2. Push and hold the On/Off button until the green
LEDs of the battery indicator comes off.
3. Remove the battery from the product. Push the two
release buttons and pull out the battery.
12 2337 - 006 - 30.04.2025
To the cruise control function
1. Press the power trigger to choose the optimal airflow
for your work.
2. Press the cruise control button to set the chosen
airflow, the LED of the cruise control indicator comes
on.
3. Continue to work without pressing the power trigger.
4. Press the cruise control button again to deactivate
the cruise control function.
To increase the airflow with boost
mode
The airflow of the product can be increased with boost
mode.
1. Start the product. Refer to
To start the product on
page 12
.
2. Push and hold the power trigger in position (B) to
start boost mode and increase the airflow.
A
B
Note: There is a resistance in the power trigger
that divides standard mode (A) from boost mode (B).
3. Release the power trigger to move from boost mode
to standard mode.
2337 - 006 - 30.04.2025
13
Maintenance
Introduction
WARNING: Before you do any
maintenance work you must read and
understand the safety chapter.
Maintenance schedule
WARNING: Remove the battery before
you do maintenance.
The following is a list of the maintenance steps that you
must do on the product. In addition to the maintenance
specified in the maintenance schedule, let a Husqvarna
servicing dealer do servicing on the product regularly.
For information about the service intervals, speak to
your Husqvarna servicing dealer.
Maintenance Daily Weekly Monthly
Clean the product. X
Clean the air intake. X
Do a check of the On/Off button. X
Do a check of the screws. X
Do a check of the battery. X
Clean the battery holder and do a check of the connector. X
Clean the battery and do a check of the connector. X
Clean the battery charger and do a check of the connector. X
To do a check of the air intake
1. Make sure that the air intake is not blocked.
2. Release the power trigger and remove leaves or
unwanted material if necessary.
CAUTION: A blocked air intake
decreases the blowing capacity of the
product and increases the motor's
working temperature. This can result in
motor failure due to overheating.
To examine the battery and the battery
charger
1. Examine the battery for damages, for example
cracks.
2. Examine the battery charger for damages, for
example cracks.
3. Make sure that the connection cord of the battery
charger is not damaged and that there are no cracks
in it.
To clean the product, the battery and
the battery charger
1. Clean the product with a dry cloth after use.
2. Clean the battery and battery charger with a dry
cloth. Keep the battery guide tracks clean.
3. Make sure that the terminals on the battery and the
battery charger are clean before the battery is put in
the battery charger or the product.
14 2337 - 006 - 30.04.2025
Troubleshooting
User interface
User interface Possible faults Possible action
Green indicator flashes Low battery voltage. Charge the battery.
Red error indicator flashes Temperature deviation. Let the product cool down.
The product does not start Dirt in battery connectors.
Clean with compressed air or a soft
brush.
Red error indicator is lit The product needs servicing. Contact your servicing agent.
Battery
40-B330X
2
Symptoms Cause Action
The battery error indicator flashes. The battery is empty. Charge the battery.
Heavy workload in combination with
very low battery temperature.
Make the battery warm. For example,
move it indoors or operate at low
speed until the battery is warm.
The battery does not operate. The
operating range of the battery is at
its limit.
Remove the battery from the product.
Let the battery rest, and then push
the battery indicator button.
The battery temperature indicator is
ON.
The battery is too cold or too hot to
use.
Keep the battery in an ambient tem-
perature between -10°C (14°F) and
40°C (104°F). When the battery has
the correct temperature, it can be
used again.
The battery temperature indicator
flashes.
The battery is near its temperature
limits.
Decrease the speed and/or workload.
Keep the battery in the preferred
temperature between +10°C (50°F)
and +30°C (86°F) for optimal per-
formance.
The battery temperature indicator is
ON while the battery is in the charg-
er.
Temperature deviation, the battery is
too cold or too hot to charge.
Let the battery cool down or move
it indoors to warm it up. When the
battery has the correct temperature,
it can be charged again. Make sure
to use the charger where the ambient
temperature is between 5°C (41°F)
and 40°C (104°F). Keep the charger
away from sunlight. If the problem
continues, speak to your dealer.
2
The troubleshooting may differ for other battery models. Refer to the operator's manual of the battery for
information about how to use the battery. Only use Husqvarna approved batteries.
2337 - 006 - 30.04.2025 15
The battery error indicator comes on. The battery has a critical error. Speak to your dealer.
Battery charger
40-C750X
3
Symptoms Possible faults Possible procedure
The charging indicator on the
charger is yellow.
The battery error indicator flash-
es, or the battery temperature in-
dicator is on.
Temperature devia-
tion, the battery is too
cold or too hot to use
or charge.
If the battery is too hot, keep it connected to the charger.
The built-in fan of the charger decreases the temperature
of the battery. When the battery has the recommended
temperature, the charging starts automatically.
If the battery is too cold, move it indoors. When the
battery has the recommended temperature, continue the
charging.
Obey the temperature range for operation, refer to the
operator's manual of the battery charger. Keep the
charger away from sunlight. If the problem continues,
speak to your dealer.
The charging indicator on the
charger is yellow. The battery er-
ror indicator on the battery is on.
The battery has a
critical error.
Speak to your dealer.
The charging indicator on the
charger is red.
The charger has a
critical error.
Speak to your dealer.
Transportation, storage and disposal
Transportation and storage
• The supplied Li-ion batteries obey the Dangerous
Goods Legislation requirements.
• Obey the special requirement on package and labels
for commercial transportation, including by third
parties and forwarding agents.
• Speak to a person with special training in dangerous
material before you send the product. Obey all
applicable national regulations.
• Use tape on open contacts when you put the battery
in a package. Put the battery in the package tightly
to prevent movement.
• Remove the battery for storage or transportation.
• Put the battery and the battery charger in a space
that is dry and free from moisture and frost.
• Do not keep the battery in an area where static
electricity can occur. Do not keep the battery in a
metal box.
• Put the battery in storage where the temperature is
between 5°C/41°F and 25°C/77°F and away from
open sunlight.
• Put the battery charger in storage where the
temperature is between 5 °C/41 °F and 45°C/113°F
and away from open sunlight.
• Use the battery charger only when the surrounding
temperature is between 5°C/41°F and 40°C/104°F.
• Charge the battery 30% to 50% before you put it in
storage for long periods.
• Put the battery charger in storage in a space that is
closed and dry.
• Keep the battery away from the battery charger
during storage. Do not let children and other not
approved persons to touch the equipment. Keep the
equipment in a space that you can lock.
• Clean the product and do a full servicing before you
put the product in storage for a long time.
• Attach the product safely during transportation.
3
The troubleshooting may differ for other battery charger models. Refer to the operator's manual of the battery
charger for information about how to use the battery charger. Only use Husqvarna approved battery chargers.
16 2337 - 006 - 30.04.2025
Disposal
The symbol means that the product is not domestic
waste. Recycle it through your local collection system
for electrical and electronic equipment. This contributes
to proper end of life waste management. Contact
local authorities, domestic waste services, your dealer
or retailer for information. Incorrect disposal may
have potential negative effects on the environment
and human health, due to the potential presence of
hazardous substances.
Note: The symbol shows on the product or package of
the product.
Technical data
Technical data
530iB
Motor
Motor type BLDC
Weight
Weight without battery and nozzle, kg 2.7
Noise emissions
4
Sound power level, measured dB (A) 91
Sound power level, guaranteed L
WA
dB (A) 92
Water protection level
IPX4
5
YES
Sound levels
6
Sound pressure level at the operator's ear, measured according to IEC
62841-4-6, dB (A):
77
Vibration levels
7
Vibrations levels at handles, measured according to IEC 62841-4-6, m/s
2
1.5
Fan performance
Airflow in normal mode with round standard nozzle, m
3
/min (cfm) 15.2 (537)
Airflow in Boost mode with round standard nozzle, m
3
/min (cfm) 16.7 (590)
Maximum air velocity in normal mode with round standard nozzle, m/s (mph) 62 (139)
4
Noise emissions in the environment measured as sound power (L
WA
) in conformity with EC directive
2000/14/EC. Reported sound power level for the machine has been measured with the original cutting
attachment that gives the highest level. The difference between guaranteed and measured sound power
is that the guaranteed sound power also includes dispersion in the measurement result and the variations
between different machines of the same model according to Directive 2000/14/EC.
5
The Husqvarna Handheld Battery products marked with IPX4 fulfils these requirements on product approval
level
6
Reported data for sound pressure level for the machine has a typical statistical dispersion (standard deviation)
of 3 dB (A).
7
Reported data for vibration level has a typical statistical dispersion (standard deviation) of 2 m/s
2
.
2337 - 006 - 30.04.2025 17
530iB
Maximum air velocity in Boost mode with round standard nozzle, m/s (mph) 68 (152)
Maximum blow force in normal mode with round standard nozzle, N 15
Maximum blow force in Boost mode with round standard nozzle, N 18
Noise and vibration data are determined on the basis of
the rated maximum speed.
Approved batteries
Battery 40-B330X BLi300
Type Lithium-ion Lithium-ion
Battery capacity, Ah 9.0 9.4
Nominal voltage, V 36 36
Weight, kg 1.9 1.9
Approved battery chargers
Battery charger QC500 40-C750X
Input voltage, V 100-240 100-240
Frequency, Hz 50-60 50-60
Power, W 500 750
Accessories
Approved accessories
Approved accessories Type Art. no.
Nozzle (length) Nozzle standard (400mm) 537 49 76-01
Harness Single Harness 537 21 62-01
18 2337 - 006 - 30.04.2025
Declaration of Conformity
Declaration of conformity
We, Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel:
+46-36-146500, declare on our sole responsibility that
the product:
Description Handheld Battery-operated Blower
Brand Husqvarna
Type / Model 530iB
Identification Serial numbers dating from 2025 and onwards
complies fully with the following EU directives and
regulations:
Regulation Description
2006/42/EC "relating to machinery"
2014/30/EU ”relating to electromagnetic compatibility”
2011/65/EU “relating to restriction of hazardous substances”
2000/14/EC "relating to outdoor noise"
2014/53/EU* "relating to Radio Equipment"
and that the following standards and/or technical
specifications are applied: EN 62841-1:2015+A11:2022,
EN IEC 62841-4-6:2024+A11:2024, EN 61000-6-3:2007/
A1:2011/AC:2012, EN IEC 61000-6-3:2021, EN
61000-6-1:2007, EN IEC 61000-6-1:2019, EN IEC
63000:2018, EN ISO 12100:2010.
*For products with Bluetooth
®
functionality: ETSI EN
301 489-1 v.1.9.2, ETSI EN 301 489-1 v.2.2.3, ETSI EN
301 489-17 v.3.2.4, ETSI EN 300 328 v.2.2.2
SMP Svensk Maskinprovning AB, Box 4053, SE-904 03
Umeå, Sweden, has also verified agreement with annex
V of the council's directive 2000/14/EC.
For information relating to noise emissions, refer to
Technical data on page 17
.
Huskvarna, 2025-02-10
Stefan Holmberg, R&D Director, Technology
Management, Husqvarna AB
Responsible for technical documentation
2337 - 006 - 30.04.2025 19
www.husqvarna.com
Original instructions
1143907-26
2025-05-13
