Instruction Manual
Notice d'Utilisation
Manual de instrucciones
!"#$"%&'(&)#*+,$--).#(*
(#
)+
/#*+,$-+).#&!"#$"%
!"#$"%(&')&)*+,$0).#)
1,
(*
Notice d'Utilisation
CB300U
Serial Number
Model
Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked under the most
meticulous quality control procedures, will provide you an effective service.
Therefore, read this entire user manual carefully before using the product and keep it as a reference.
If you handover the product to someone else, give the user manual as well.
The user manual will help you use the product in a fast and safe way.
• Read the manual before installing and operating the product.
• Make sure you read the safety instructions.
• Keep the manual in an easily accessible place as you may need it later.
• Read the other documents given with the product.
Remember that this user manual is also applicable for several other models. Differences between
models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
Important information or useful tips.
Warning against dangerous conditions for life and property.
Warning against electric voltage.
Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked under the most
meticulous quality control procedures, will provide you an effective service.
Therefore, read this entire user manual carefully before using the product and keep it as a reference.
If you handover the product to someone else, give the user manual as well.
The user manual will help you use the product in a fast and safe way.
• Read the manual before installing and operating the product.
• Make sure you read the safety instructions.
• Keep the manual in an easily accessible place as you may need it later.
• Read the other documents given with the product.
Remember that this user manual is also applicable for several other models. Differences between
models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
Important information or useful tips.
Warning against dangerous conditions for life and property.
Warning against electric voltage.
Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and checked under the most
meticulous quality control procedures, will provide you an effective service.
Therefore, read this entire user manual carefully before using the product and keep it as a reference.
If you handover the product to someone else, give the user manual as well.
The user manual will help you use the product in a fast and safe way.
• Read the manual before installing and operating the product.
• Make sure you read the safety instructions.
• Keep the manual in an easily accessible place as you may need it later.
• Read the other documents given with the product.
Remember that this user manual is also applicable for several other models. Differences between
models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
Important information or useful tips.
Warning against dangerous conditions for life and property.
Warning against electric voltage.
Remove the right crisper
drawer to see the serial tag.
XX-XXXXXX-XX
1.Your refrigerator
Refrigerator shelf weight limitations
2. Important Instructions Safety
and Environment
2.1 Intended use
2.2 General Safety
2.3 Hydrocarbon (HC) Warning
2.4 For Products with a Water
Dispenser/Ice Machine
2.5 Intended Use
2.6 Children’s Safety
3. Environmental instructions
3.1 Compliance with the WEEE
Directive and Disposing the Waste
Product
3.2 Compliance with the RoHS
Directive
3.3 Packaging Information
4.Installation
4.1 Before Installation
4.2 Appropriate installation location
4.3 Inset installations
4.4 Electrical connection
4.5 Adjusting the feet
4.6 Illumination lamp
4.7 Door/Drawer Open Warning
4.8 Transportation of the product
4.9 Water connection
4.10 Connecting the water hose
to the refrigerator
4.11 Connecting the water line
to the water supply
- Installing the Handles
5. Preparation
6. Using the control
6.1 Indicator panel
Operating Temperatures
Operating the product
- Freezing fresh food
- Recommendations for preserving frozen
food
1
2
3
3
3
4
4
4
4
5
5
5
5
6
8
8
8
9
9
9
9
9
9
9
9
10
11
12
12
13
13
13
13
13
13
14
14
14
14
14
14
15
15
15
16
17
17
17
17
- Placing the food
- Deep-freeze information
- Moving the FlexiLift Door Shelf *optional
- Glass shelves
- Crisper bins
- Deli Drawer
- Humidity controlled crisper (EverFresh+)
- Harvest Fresh
- Odor filter
- Ice container
- Door flappers
- Drawer Removal
- Door Removal
7. Maintenance and cleaning
7.1 Avoiding bad odors
7.2 Protecting the plastic surfaces
8. Troubleshooting
CONTENT
1.Your refrigerator
1 / EN
Figures in this user manual are schematic and may not match the product exactly. if
the subject parts are not included in the product you have purchased, then those
parts are only valid for other models.
1. Fridge Compartment
2. Freezer Compartment
*3. Ice making (in Freezer Compartment)
4. Celing Display
5. Adjustable Glass Shelf
*6. Wine rack
7. Crisper
8. Chiller
9. Half Door Shelf
10. Gallon Door Shelf
11. Top Drawer
12. Bottom Drawer
*Option
1
2
4
5
*6
7
9
8
10
11
12
*3
*Option
2 / EN
Refrigerator shelf weight limitations
Fridge compartment shelves, are tested for max 71 pounds (32 kg) per each part.
Chiller will hold up to 61 pounds (27.6 kg) per each one. Crisper will hold up to 32 pounds (14.6 kg).
Half door shelf holds up to 3.3 pounds (1.5 kg) and gallon door shelf will hold up to 7.5 pounds (3.4 kg). Top
drawer holds up to 111 pounds(50.2 kg) and bottom drawer hold up to 93 pounds(42. kg)
71 lbs
(32 Kg)
3.3 lbs
(1.5 Kg)
7.5 lbs
(3.4 Kg)
93 lbs
(42.1 Kg)
32 lbs
(14.6 Kg)
61 lbs
(27.6 Kg)
111 lbs
(50.2 Kg)
3 / EN
2. Important Instructions Safety and Environment
This chapter contains safety information that will help you
avoid the risk personal injury or preperty damage. Failure
to follow these instructions shall render any product
warranty void.
2.1 Intended use
This appliance is intended to be used in household and
similar applications such as
staff kitchen areas in shops, offices and other working
environments;
farm houses and by clients in hotels, motels and other
residential type environments;
bed and breakfast type environments;
catering and similar non-retail applications.
2.2 General Safety
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety. Children should be supervised to ensure
that they do not play with the appliance.
Failure to follow the instructions and uncontrolled use
of the product lead to dangerous results!
Unplug the product if you encounter a failure during
use.
If the product malfunctions, it must not be operated
until repaired by the authorised service provider. Risk of
electric shock!
Plug the product into a grounded socket protected by a
fuse that corresponds to the value on its nameplate.
Have a qualified electrician ground the product. Our
company cannot be held responsible for damages
resulting from the failure to use the product with a
grounded socket pursuant to local regulations.
Unplug the product when not in use.
Never wash the product by spreading or pouring water
onto it! Risk of electric shock!
Never touch the plug with wet hands!
Never unplug the product by pulling the cable. Always
pull by holding the socket.
Do not plug the refrigerator if the wall socket is loose.
Never connect your refrigerator to energy saving
devices. Such systems are harmful to your product.
Unplug the product during installation, care, cleaning
and repairing procedures.
Always have the Authorised Service Provider install
the product and establish its electrical connections. The
manufacturer cannot be held responsible for damages
caused by procedures performed by unauthorised
persons.
Do not eat cone ice cream or ice cubes immediately
after you take them out of the freezer compartment! This
may cause frostbite in your mouth!
Do not touch frozen food with wet hands! They may
stick to your hand!
Do not put bottled or canned liquid beverages in the
freezer compartment. They may burst!
Never use steam or steam cleaners to clean or defrost
the refrigerator. Steam gets into contact with the live parts
in your refrigerator, causing short circuit or electric shock!
WARNING : When positioning the appliance,
ensure the supply cord is not trapped or damaged.If the
supply cord is damaged, it must be replaced by an
authorized service technician or licensed electrician in
order to avoid a hazard.
WARNING : Do not locate multiple portable
socket-outlets or portable power supplies at the rear of
the appliance.
Do not use mechanical devices or other means to
accelerate the defrosting process other than those
recommended by the manufacturer.
Never use the parts in your refrigerator such as the
door and drawer as a means of support or step. This may
cause the product to tip over or damage the parts of it.
WARNING : Keep ventilation
openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
WARNING : Do not use mechanical
devices or other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
WARNING : Do not damage the
refrigerant circuit.
WARNING : Do not use electrical
appliances inside the food storage
compartments of the appliance, unless they
are of the type recommended by the
manufacturer.
4 / EN
2. Important Instructions Safety and Environment
Do not damage the parts where the refrigerant is
circulating with drilling or cutting tools. The refrigerant
that might blow out when the gas channels of the
evaporator, pipe extensions or surface coatings are
punctured causes skin irritations and eye injuries.
Do not cover or block the ventilation holes in your
refrigerator with any object.
Place the beverage with higher proofs tightly closed
and vertically.
Do not use gaseous sprays near the product since
there is the risk or fire or explosion!
Flammable items or products that contain flammable
gases (e.g. spray) as well as explosive materials should
never be kept in the appliance.
Do not place vessels filled with liquid onto the product.
Splashing water on an electrical part may cause electric
chock or the risk of fire.
Do not store items that need precise temperature
adjustment (such as vaccines, heat-sensitive medication,
science materials etc.) in the refrigerator.
If you are not going to use the product for a long time,
unplug it and remove the food in it.
If there is a blue light on the refrigerator, do not look at
this light with optical tools.
Exposing the product to rain, snow, sun or wind is
dangerous in terms of electrical safety.
In products with mechanical control (thermostat), wait
for 5 minutes to plug in the product again after
unplugging.
Do not overload the refrigerator. Object in the
refrigerator may fall down when the door is opened,
causing injury or damage. Similar problems may arise if
any object is placed onto the product.
If the product has a door handle, do not
pull the handle when re-locating the
product. The handle might be loose.
Be careful not to jam your hand or any other body part
in the moving parts of the refrigerator.
Do not put your hand or any other foreign materials
into the ice machine while it is operating.
2.3 Hydrocarbon (HC) Warning
If your product’s cooling system contains R600a:
This gas is flammable. Therefore, pay attention not to
damage the cooling system or the piping during use and
transportation. If damaged, keep the product away from
potential fire sources that may cause it to catch fire and
ventilate the room where the product is placed.
2.4 For Products with a Water
Dispenser/Ice Machine
Pressure for cold water inlet shall be maximum 90 psi
(620 kPa). If your water pressure exceeds 80 psi (550
kPa), use a pressure limiting valve in your mains system.
If you do not know how to check your water pressure, ask
for the help of a professional plumber.
If there is a risk of water impact in your installation,
always use a water impact protection equipment in that
installation. Please consult professional plumbers if you
are not sure if there is water impact in your installation.
Do not make installation on the hot water inlet.
Use drinking water only.
Take the necessary measures against the freezing risk
of the hoses. The water temperature operating range
must be 0.6°C (33°F) minimum and 38°C (100°F)
maximum.
2.5 Intended Use
This product has been designed for domestic use. It is
not suitable for commercial use and it must not be used
out of its intended use.
It must be used only for storing food.
The manufacturer will not take any responsibility for
damages resulting from improper use or transport.
Original spare parts will be available for 10 years after
the purchase date of the product.
2.6 Children’s Safety
If there is a lock on the door of the product, the key
should be kept out of the reach of children.
Do not let children play with the product.
If the product is damaged and if you see gas
leak, please keep away from the gas. It may
cause frostbite when it gets into contact with
the skin. (including R134)
Ignore this warning if the cooling system of
your product contains R134a.
Type of gas used in the product is stated on
the type plate which is on the left wall inside
the refrigerator.
WARNING: Never throw the product
into fire for disposal.
WARNING: Never connect the
product to a cold water mains with a pressure
of 550 kPa (80 psi) or above.
CAUTION: To Prevent A child From
Being Entrapped, Keep Out Of Reach Of
Children And Not In The Vicinity Or
Refrigerator
5 / EN
2. Important Instructions Safety and Environment
3. Environmental instructions
3.1 Compliance with the WEEE
Directive and Disposing the Waste
Product:
This product conforms to the EU WEE
Directive (2012/19 EU). This product
bears a classification symbol for waste
electrical and electronic equipment
(WEEE). This product has been
manufactured from high quality parts
and materials which can be reused and
are suitable for recycling. Therefore, do not dispose the
product with normal domestic waste or other waste at the
end of its service life. Take it to a collection centre for
recycling electrical and electronic equipment. Please
consult local authorities to learn about the locations of
such collection centres.
3.3 Packaging Information
Packaging materials of the product have
been manufactured from recyclable materials
in accordance with our National Environment
Regulations. Do not dispose the packaging
materials with normal domestic waste or other types of
waste. Take these materials to a recycling point
designated by local authorities.
WARNING: Before disposing your old
refrigerator or freezer:
Children may get locked inside.
Remove the doors.
Leave the shelves to prevent children from
getting inside the product easily..
DANGER:
Risk of Fire or Explosion:
This product uses flammable refrigerant.
Do not use mechanical devices to defrost
the refrigerator.
Do not use chemicals for cleaning.
Do not pierce the refrigerant pipe.
If the refrigerant pipe is pierced, it must be
repaired only by licensed service personnel.
Please consult the repair/user manual
before cleaning the product. All safety
instructions must be followed.
Dispose the product according to
federal or local regulations.
3.2 Compliance with the RoHS Directive:
The unit you have purchased conforms to the EU
RoHS Directive (2011/65/EU). It does not contain
harmful or prohibited materials specified in the
Directive.
6 / EN
4.Installation
(
513mm
)
/
16
7
/
30
(784mm)
8
3
20
“
“
25
71-11/16”(1820mm)
(786mm)
15
16
5
8
(650mm)
/
“
30
/
“
24 ”(620mm)
Cabinet
25 / ”(650mm)
Countertop
Top View
Recessed
electrical outlet
Allow 1 ” (30 mm) min, clearance at rear
for proper air circulation and
water/electrical connections
1/2’’ on EACH side.
Minimum Clearances - 2” on the top, 1/2”
on each side, and 1 3/16 in the back.
13
/
32
3
16
/
19
32
”
130
Allow 2” (50 mm) min. clearance
between the top of refrigerator
and bottom of cabinetry.
7 / EN
4.Installation
A
B
C
D
E
F
A B C
(69
11
/
16
”)1770mm.
(27
9
/
16
”)700mm. (29
13
/
16
”)758mm.
(3
3
/
16
”)81mm. (43
1
/
4
”)1111mm.
(29
3
/
4
”)756mm.
(68
1
/
2
”)1740mm. (24
7
/
16
”)620mm.
D E F
G H I
J K L
M N
(40
4
/
16
”)1022mm.
(39”)991mm. (37
5
/
8
”)956mm.
(10
11
/
16
”)271mm.
(39
1
/
8
”)993.5mm. (50
15
/
16
”)1293mm.
G
H
I
J
K
L
M
N
130
o
90
o
8 / EN
4.Installation
4.1 Before Installation
Before installing, be sure the opening measurements
are sufficient to receive the product and that the
appropriate electrical and plumbing connections are
present.
4.2 Appropriate installation location
Install the product at least 12” (30cm) away from heat
sources such as cooktops, ovens, space heaters,
radiators and stoves at least2” (5 cm) away from
electrical ovens. Product must not be subjected to direct
sun light and kept in humid places after installation.
Refer to the nearest Authorized Service Agent for
installation of the product. To make the product ready for
use, make sure that the electricity installation is
appropriate before calling the Authorized Service Agent.
If not, call a qualified electrician to have any necessary
arrangements carried out.
Your product comes with an internal water filter. Part
number of the filter is 4918450200 and you can use this
part number when ordering replacement filters.
Water line pressure values
psi
90
80
620
550
120 V AC
60 Hz
15 A
6.2
5.5
kPa bar
Max Operating pressure :
Max Pressure for limiting
device requirement :
Do not place the product on the materials such as rugs
or carpets.
Place the product on an even floor surface to prevent
wobbling.
Do not install the product in places where the
temperature falls below 50F°/10ºC.
Make sure that sufficient room is provided around the
appliance to ensure free air circulation.
For proper functionality, there should be a gap of at least
1 3/16” (30 mm) between the refrigerator and the rear wall.
To ensure this, attach the gray, circular buffers, to be
installed on the rear back metal cover of the refrigerator.
These are shipped inside the crisper drawer in the Fresh
Food compartment.
4.3 Inset installations
If the product will be installed within surrounding
cabinetry or in an alcove, be sure there is adequate
airflow around the product for proper functionality. This
refrigerator requires at least 2” from the top of the unit to
the ceiling or enclosure, 1/2” on each side and 1 3/16” in
the back. (the spacer is shipped with the product)
Electrical requirements
Voltage
Frequency
Current
Preparation of the location and electrical
installation at the place of installation is under
customer's responsibility.
Plumbing: The refrigerator should only be
connected to the cold water line.
Product must not be plugged in during
installation. Otherwise, there is the risk of
death or serious injury!
If two refrigerators are to be installed side
by side, there should be at least 1 1/2”
(4 cm) distance between them.
WARNING: Installation and electrical
connections of the product must be carried
out by the Authorized Service Agent.
Manufacturer shall not be held liable for
damages that may arise from procedures
carried out by unauthorized persons.
WARNING: Prior to installation,
visually check if the product has any defects
on it. If so, do not have it installed. Damaged
products cause risks to your safety.
1
2
3
9 / EN
4.Installation
4.9 Water connection
First you must connect the water hose to the refrigerator.
4.10 Connecting the water hose
to the refrigerator
1. Remove the valve channel cover (A) from the water
inlet valve.
2. Connect the water line (C) to the inlet valve (B) and
tighten by hand to secure it. It is not necessary to use
pliers, but if there is a leak, you may tighten slightly
with a pair of pliers.
4.11 Connecting the water line
to the water supply
Connect the water line to a water supply valve. If a valve is
not present or you are not sure, consult a qualified plumber.
4.4 Electrical connection
120VAC, 60Hz, Dedicated 15Amp Circuit.
GFCI outlets will provide added protection, but any
failure of the GFCI could cause food spoilage, which is
not covered by the manufacturer’s warranty.
Electrical connection must comply with national
regulations.
Power cable plug must be within easy reach after
installation.
Do not make connections via extension cables or
multi-plu gs.
4.5 Adjusting the feet
After moving the refrigerator into place, we recommend
lowering the feet to secure the product in place. You can
also adjust the feet if the product is not balanced. Twist
the feet in the desired direction according to the
illustration below. Adjusting the feet can also be used to
align the doors.
4.6 Illumination lamp
Do not attempt to repair yourself but call the Authorized
Service Agent if the LED illumination lamps do not go on.
The lamp(s) used in this appliance is not suitable for
household room illumination. The intendedpurpose of this
lamp is to assist the user to place foodstuffs in the
refrigerator/freezer in a safe and comfortable way.
4.7 Door/Drawer Open Warning
An audio warning signal will be given when the door of
your product is left open for 1 minute. This warning will be
muted when the door is closed or if any of the display
buttons are pressed.
4.8 Transportation of the product
1. Unplug the product before transporting it.
2. Remove water connections.
3. Secure the shelves, accessories, crisper and etc. in
the refrigerator by adhesive tape before repackaging it.
WARNING: Damaged power cable
must be replaced by the Authorized Service
Agents.
WARNING: First unplug the product.
Product must not be plugged in when
adjusting the feet. There is the risk of electric
shock!
WARNING: If the product has a
failure, it should not be operated unless it is
repaired by the Authorized Service Agent!
There is the risk of electric shock!
WARNING: Refrigerator and the
pump, if any, must be unplugged during
connection.
WARNING: Packaging materials are
dangerous for the children. Keep packaging
materials in a safe place away from reach of
the children.
Packaging must be tied with thick tapes or
strong strips and the rules of transportation
printed on the package must be followed.
10 / EN
4.Installation
Installing the Handles
1. Handle Assemblies x 3
2. Allen Key Ball End x 1
2. Position the drawer handles over the handle mounts and tighten the set screw on the left and right of the handle.
1. Position the top handles over the handle mounts and tighten the set screw on the top and bottom of each handle.
11 / EN
5. Preparation
Before starting to use the product, check that all
preparations are made in accordance with the
instructions in sections "Important instructions for safety
and environment" and "Installation".
Clean the interior of the refrigerator as recommended
in the “Maintenance and cleaning” section. Ensure that
interior is dry before operating.
Plug the refrigerator into the grounded wall outlet.
When the door is opened the interior illumination will turn
on.
“Note: temperature will take approximately 6 hours to
stabalize. Food requiring refrigeration should not be
placed in the refrigerator until after this time.”
Do not allow the food to touch the temperature sensor
in fresh food compartment.
To allow the fresh food compartment keep its ideal
storage temperature, sensor must not be covered by food.
You will hear a noise when the compressor
starts up. The liquids and gases sealed
within the refrigeration system may also
give rise to noise, even if the compressor is
not running and this is quite normal.
Front edges of the refrigerator may feel warm.
This is normal. These areas are designed to
be warm to avoid condensation.
12 / EN
6. Using the control
6.1 Indicator panel
Touch-control indicator panel allows you to set the temperature and control the other functions of the refrigerator. Just
press the relevant buttons for function settings.
7. Ice Maker Off icon (*optional):
The ice cubes with a slash through them will be
illuminated when the ice maker is turned on.
8. Freezing Compartment Temperature
Setting Key:
Temperature setting is made for cooler compartment.
Pressing this key will enable the freezer compartment
temperature to be set at -7,-6,-5,-4,-3,-2,-1,0,1,2,3,4 and
5 Fahrenheit.
9.QuickFreezing Key:
When the quick reeze key is pressed, the quickfreeze
symbol ( ) shall be illuminated and the
quickfreeze function shall be activated. Freezingcom-
partment temperature is set to -16 Fahrenheit. Function
is cancelled when the key is pressed again. The quick
freezing function shall be automatically cancelled after
24 hours. To freeze a large amount of fresh food, press
the quick freeze key before placing the food in the
freezer compartment.
10. Sabbath Mode:
Press the Fresh Food Temp Set Function key for 3
seconds to activate or deactivate the Sabbath Mode.
When Sabbath Mode is activated, the display, alarm,
door opening or light buttons will not function. "SA"
will appear in the display. The cooling algorithm is set
according to the sabbath fashion. If the user does
not deactivate the Sabbath mode, the refrigerator will
automatically cancel it in 72 hours.
11. Ice Maker on/off key (*optional):
Press and hold the Freezer Temp Set key for 3 seconds
to turn the Ice Maker on and on.
7. Ice Maker Off icon (*optional):
The ice cubes with a slash through them will be
illuminated when the ice maker is turned on.
8. Freezing Compartment Temperature
Setting Key:
Temperature setting is made for cooler compartment.
Pressing this key will enable the freezer compartment
temperature to be set at -7,-6,-5,-4,-3,-2,-1,0,1,2,3,4 and
5 Fahrenheit.
9.QuickFreezing Key:
When the quick reeze key is pressed, the quickfreeze
symbol ( ) shall be illuminated and the
quickfreeze function shall be activated. Freezingcom-
partment temperature is set to -16 Fahrenheit. Function
is cancelled when the key is pressed again. The quick
freezing function shall be automatically cancelled after
24 hours. To freeze a large amount of fresh food, press
the quick freeze key before placing the food in the
freezer compartment.
10. Sabbath Mode:
Press the Fresh Food Temp Set Function key for 3
seconds to activate or deactivate the Sabbath Mode.
When Sabbath Mode is activated, the display, alarm,
door opening or light buttons will not function. "SA"
will appear in the display. The cooling algorithm is set
according to the sabbath fashion. If the user does
not deactivate the Sabbath mode, the refrigerator will
automatically cancel it in 72 hours.
11. Ice Maker on/off key (*optional):
Press and hold the Freezer Temp Set key for 3 seconds
to turn the Ice Maker on and on.
5. Fault Condition Indicator:
This indicator ( ) shall be active when your
refrigerator cannot perform adequate cooling or
in case of any sensor error. “E” shall be displayed on.
6. Freezing Compartment Symbol:
The temperature values of the freezing compartment is
displayed on the screen when this symbol is active.
5. Fault Condition Indicator:
This indicator ( ) shall be active when your
refrigerator cannot perform adequate cooling or
in case of any sensor error. “E” shall be displayed on.
6. Freezing Compartment Symbol:
The temperature values of the freezing compartment is
displayed on the screen when this symbol is active.
1.On/Off Function:
This function ( ) allows you to make the Fridge turn
off when pressed for 3 seconds. The fridge could be
turned on by pressing On/Off button for 3 seconds again.
When the function is active, all indicators turn off.
1.On/Off Function:
This function ( ) allows you to make the Fridge turn
off when pressed for 3 seconds. The fridge could be
turned on by pressing On/Off button for 3 seconds again.
When the function is active, all indicators turn off.
2. Vacation Function Key:
Press the key for 3 seconds to activate the vacation function.
Vacation mode is activated and the vacation symbol ( ) is
illuminated. “- -” shall be displayed on the Fresh Food
Compartment temperature indicator and the Fresh Food
Compartment does not actively perform cooling. You shall not
keep your food in the Fresh Food Compartment when this
function is activated. The Freezer Comparment will continue to
operate at its set temperature. Press the key for 3 seconds
again to cancel this function.
3. Fresh Food Compartment Temperature
Setting Key:
Allows setting of temperature for Fresh Food Compartment
Pressing this key will enable the Fresh Food Compartment
temperature to be set at
46,45,44,43,42,41,40,39,38,37,36,35,34 and 33 Fahrenheit.
4. Fresh Food Compartment Symbol:
The temperature values of the cooling compartment
is displayed on the screen when this symbol is active.
2. Vacation Function Key:
Press the key for 3 seconds to activate the vacation function.
Vacation mode is activated and the vacation symbol ( ) is
illuminated. “- -” shall be displayed on the Fresh Food
Compartment temperature indicator and the Fresh Food
Compartment does not actively perform cooling. You shall not
keep your food in the Fresh Food Compartment when this
function is activated. The Freezer Comparment will continue to
operate at its set temperature. Press the key for 3 seconds
again to cancel this function.
3. Fresh Food Compartment Temperature
Setting Key:
Allows setting of temperature for Fresh Food Compartment
Pressing this key will enable the Fresh Food Compartment
temperature to be set at
46,45,44,43,42,41,40,39,38,37,36,35,34 and 33 Fahrenheit.
4. Fresh Food Compartment Symbol:
The temperature values of the cooling compartment
is displayed on the screen when this symbol is active.
1
2
3
4 6
8 9 10 11*
7*
5
13 / EN
Operating Temperatures
Operating the product
Freezing fresh food
Wrap the food or place them in a covered container
before putting them in the refrigerator.
Hot food and beverages must cool down to room
temperature before putting them in the refrigerator.
The food that you want to freeze must be fresh and in
good quality.
Pack the food in an airtight manner to prevent them
from drying even if they are going to be stored for a short
time.
Materials to be used for packaging must be tear-proof
and resistant to cold, humidity, oils and acids and they
must also be airtight, All packaging must be completely
sealed.
Frozen food must be used immediately after they are
thawed and they should never be refrozen.
Do not freeze excessively large quantities of food at
one time.The quality of the food is best preserved when it
is frozen right through to the core as quickly as possible.
Placing warm food into the freezer compartment
causes the cooling system to operate continuously until
the food is frozen solid.
Recommendations for preserving
frozen food
To ensure the quality achieved by the frozen food
manufacturer and food retailler is maintained, follow the
steps listed below:
1. Put packets in the freezer as quickly as possible
after purchase.
2. Make sure that contents of the package are labelled
and dated.
3. Check whether the "Use By" and "Best Before"
dates on the packaging are exceeded or not.
Placing the food
Deep-freeze information
You can keep the freshness of food for many months (at 5
F° / -15°C or lower temperatures in the deep freeze).
Material necessary for packaging
Cold resistant adhesive tape
self adhesive label
rubber rings
Pen
Explanations
Freezer
Compartment
Setting
Fridge
Compartment
Setting
-4°F/-20°C 37 °F / 3°C These settings are recommended when the ambient temperature exceeds 86F°/30°C
5°F/-15°C 39 °F /4°C This is the normally recommended setting.
Quick Freeze 39 °F / 4°C Use when you wish to freeze your food in a short time. Your refrigerator will return to
its previous mode when the process is over.
Freezer
compartment
shelves
Various frozen food such as meat, fish,
ice cream,vegetables and etc.
Fridge
compartment
shelves
Food in pans, covered plates and closed
containers
Crisper Vegettables and fruits
Fridge
compartment
door shelves
Small and packaged food or beverage
(such as milk, fruit juice, beer and etc.
Deli drawer Delicatessen products (cheese, butter,
salami and etc.)
Divided the food into portions according
to your family’s daily or meal based
consumption needs.
Pack the food in an airtight manner to
prevent them from drying even if they are
going to be stored for a short time.
14 / EN
Operating the product
Moving the FlexiLift Door Shelf
*optional
Moving the FlexiLift door shelf can be fixed in 2 different
positions. In order to move the shelf, push the buttons on
the side evenly. Shelf will be movable. Move the shelf up
or down. When the shelf is in the position that you want,
release the buttons. Rack will be fixed again in the
position where you have released the buttons.
Glass shelves
You can remove the glass shelves to clean them.Be
careful when removing the shelves since they are heavy.
Crisper bins
(in some models)
Crisper bins allow you to prepare the food for freezing.
You can also use these compartment to store your food
at a temperature a few degrees below the fridge
compartment.
You can increase the inner volume of ypur refrigerator by
removing any of the chiller compartments:
1. Pull the compartment towards yourself until it stops.
2. Lift the compartment about 7/16’’ (1cm) up and pull
towards yourself to remove it from its seating.
Deli Drawer
The Deli Drawer is designed with cool air circulation
intensified around it. This allows for items stored in the
drawer to be generally fresh food compartment than
average Fresh Food temperatures.
If required, remove door shelves prior to Deli Drawer
removal
Humidity controlled crisper
(EverFresh+)
Humidity levels of the vegetables and fruit are kept under
control with the feature of humiditycontrolled crisper and
the food is ensured to stay fresh longer.
We recommend you to place the leafy vegetables such as
lettuce, spinach and the vegetables which are sensitive to
humidity loss, in a horizontal manner as much as possible
inside the crisper, not on their roots in a vertical position.
While the vegetables are being placed, individual weights
of the vegetables should be taken into consideration.
Heavy and hard vegetables should be put at the bottom of
the crisper and the lightweight and soft vegetables should
be placed on top.
Never leave vegetables inside the crisper in their bags.
This will cause them to decompose prematuraly. If you
wish to keep vegetables separate, use perforated paper
bags or similar materials to do so. Certain fruits such as
pears, apricots, peaches or apples generate high levels of
ethylene gas. Do not place them with other fruits and
vegetables which do not, as this will cause them to
decompose faster.
Harvest Fresh
Crispers of the refrigerator are illuminated with blue light.
Food stored in the crispers continue their photosynthesis
by means of the wavelength effect of blue light and thus,
preserve their freshness and preserves their vitamin
content.
Odor filter
Odor filter in the air duct of the fridge compartment
prevents build-up of unpleasant odors in the refrigerator.
15 / EN
Operating the product
Ice container
The ice container is used to collect ice produced by the
ice maker. Do not put water in it to make ice as it may
break. The ice container is not used for storing foods.
Door flappers
Movable door flapper is intended to prevent the cold air
inside the refrigerator from escaping outside. Sealing is
provided when the gaskets on the door presses on the
surface of the door flapper while the fridge compartment
doors are closed.
Drawer Removal
1. Open drawer door to
maximum position.
2. Remove ice container
from top drawer
3. Open upper door then tilt-up top drawer and remove
WARNING: Be careful when assembly
Drawer back. It’s must be place in the correct
position.
Operating the product
Door Removal
1.With the upper door closed, remove the single screw in
the hinge cover.
2.Open the door, take off the hinge cover remove
ambient sensor from cover.
3.Close the upper door and remove the 3 screws
securing the hinge plate and disconnect reed switch
cable.
4.Open the door and tilt it 10-15 degrees and lift it off the
bottom hinge.
16 / EN
7. Maintenance and cleaning
8. Troubleshooting
The life of the product is extended and common problems
are reduced, if it is cleaned regularly.
Never use gasoline, benzene or similar substances for
cleaning purposes.
Never use any sharp and abrasive tools, soap,
household cleaners, detergent and wax polish for
cleaning.
Dissolve one teaspoon of baking soda in 1 pint of water.
Soak a cloth with the solution and wring it thoroughly.
Wipe the interior of the refrigerator with this cloth and dry
thoroughly.
Make sure that no water enters the lamp housing and
other electrical items.
If you will not use the refrigerator for a long period of
time, unplug it, remove all food inside, clean it and leave
the door ajar.
Check regularly that the door gaskets are clean. If not,
clean them.
To remove door and body shelves, remove all of its
contents.
Remove the door shelves by pulling them up. After
cleaning, slide them from top to bottom to install.
Never use cleaning agents or water that contain
chlorine to clean the outer surfaces and chromium coated
parts of the product. Chlorine causes corrosion on such
metal surfaces
Check this list before contacting a servicer. Doing so will
save you time and money. This list includes frequent
complaints that are not related to faulty workmanship or
materials. Certain features mentioned herein may not
apply to your product.
The refrigerator is not working.
The power plug is not fully seated. >>> Plug it in outlet
completely into the socket.
The fuse connected to the socket powering the product
or the main fuse is blown. >>> Be sure the unit is turned
on. A single red light in the display means the product is
plugged in but not turned on. Press and hold the Power
button for three seconds to turn the unit on.
Condensation on the side wall of the fresh food
compartment (MULTI ZONE, COOL, CONTROL and
FLEXI ZONE).
The door is opened too frequently >>> Take care not to
open the product’s door too frequently.
The environment is too humid. >>> Do not install the
product in humid environments.
7.1 Avoiding bad odors
Materials that may cause odor are not used in the
production of our refrigerators. However, due to
inappropriate food preserving conditions and not cleaning
the inner surface of the refrigerator as required can bring
forth the problem of odor . Pay attention to following to
avoid this problem:
Keeping the refrigerator clean is important. Food
residuals, stains, etc. can cause odor. Therefore, clean
the refrigerator with baking soda dissolved in water every
15 days. Never use detergents or soap.
Keep the food in closed containers. Microorganisms
spreading out from uncovered containers can cause
unpleasant odors.
Never keep the food that is past its expiration date or
has spoiled in the refrigerator.
7.2 Protecting the plastic surfaces
Do not put liquid oils or oil-cooked meals in your
refrigerator in unsealed containers as they damage the
plastic surfaces of the refrigerator. If oil is spilled or
smeared onto the plastic surfaces, clean and rinse the
relevant part of the surface at once with warm water.
Foods containing liquids are kept in unsealed holders.
>>> Keep the foods containing liquids in sealed holders.
The product’s door is left open. >>> Do not keep the
product’s door open for long periods.
The thermostat is set to too low temperature. >>> Set
the thermostat to appropriate temperature.
Compressor is not working.
In case of sudden power failure or pulling the power
plug off and putting back on, the gas pressure in the
product’s cooling system is not balanced, which triggers
the compressor thermic safeguard. The product will
restart after approximately 6 minutes. If the product does
not restart after this period, contact a servicer.
Defrosting is active. >>> This is normal for a fully-auto-
matic defrosting product. The defrosting is carried out
periodically.
The product is not plugged in. >>> Make sure the
power cord is plugged in.
The temperature setting is incorrect. >>> Select the
appropriate temperature setting.
WARNING: Unplug the product
before cleaning it.
17 / EN
8. Troubleshooting
The power is out. >>> The product will continue to
operate normally once the power is restored.
The refrigerator’s operating noise is increasing while
in use.
The product’s operating performance may vary
depending on the ambient temperature variations. This
is normal and not a malfunction.
The refrigerator runs too often or for too long.
The new product may be larger than the previous one.
Larger products will run for longer periods.
The room temperature may be high. >>> The product
will normally run for long periods in higher room
temperature.
The product may have been recently plugged in or a
new food item is placed inside. >>> The product will take
longer to reach the set temperature when recently
plugged in or a new food item is placed inside. This is
normal.
Large quantities of hot food may have been recently
placed into the product. >>> Do not place hot food into
the product.
The doors were opened frequently or kept open for
long periods. >>> The warm air moving inside will cause
the product to run longer. Do not open the doors too
frequently.
The freezer of fresh food compartment door may be
ajar. >>> Check that the doors are fully closed.
The product may be set to temperature too low. >>>
Set the temperature to a higher degree and wait for the
product to reach the adjusted temperature.
The fresh food compartment or freezer door washer
may be dirty, worn out, broken or not properly settled.
>>> Clean or replace the gasket. Damaged / torn door
washer will cause the product to run for longer periods to
preserve the current temperature.
The freezer temperature is very low, but the fresh
food compartment temperature is adequate.
The freezer compartment temperature is set to a very
low degree. >>> Set the freezer compartment
temperature to a higher degree and check again.
The fresh food compartment temperature is very low,
but the freezer temperature is adequate.
The fresh food compartment temperature is set to a
very low degree. >>> Set the freezer compartment
temperature to a higher degree and check again.
The food items kept in fresh food compartment
drawers are frozen.
The fresh food compartment temperature is set to a
very low degree. >>> Set the freezer compartment
temperature to a higher degree and check again.
The temperature in the fresh food compartment or the
freezer is too high.
The fresh food compartment temperature is set to a very
high degree. >>> Temperature setting of the fresh food
compartment has an effect on the temperature in the freezer
compartment. Wait until the temperature of relevant parts
reach the sufficient level by changing the temperature of
fresh food compartment or freezer compartments.
The doors were opened frequently or kept open for long
periods. >>> Do not open the doors too frequently.
The door may be ajar. >>> fully close the door.
The product may have been recently plugged in or a new
food item is placed inside. >>> This is normal. The product
will take longer to reach the set temperature when recently
plugged in or a new food item is placed inside.
Large quantities of hot food may have been recently
placed into the product. >>> Do not place hot food into the
product.
Shaking or noise.
The ground is not level or firm. >>> if the product is
shaking when moved slowly, adjust the feet to balance the
product. Also make sure the ground is sufficiently frim to
bear the product.
Any items placed on the product may cause noise. >>>
Remove any items placed on the product.
The product is making noise of liquid flowing, spraying
etc.
The product’s operating principles involve liquid and gas
flows. >>> This is normal and not a malfunction.
There is sound of wind blowing coming from the
product.
The product uses a fan for the cooling process. This is
normal and not a malfunction.
There is condensation on the product’s internal walls.
Hot or humid weather will increase icing and
condensation. This is normal and not a malfunction.
The doors were opened frequently or kept open for long
periods. >>> Do not open the doors too frequently; if open,
close the door.
The door may be ajar. >>> fully close the door.
There is condensation on the product’s exterior or
between the doors.
The ambient weather may be humid, this is quite normal
in humid weather. >>> The condensation will dissipate when
the humidity is reduced.
The interior smells bad.
The product is not cleaned regularly. >>> Clean the
interior regularly using sponge, warm water and carbonated
water.
Certain containers and packaging meterials may cause
odor. >>> Use containers and packaging material free of
odor.
18 / EN
8. Troubleshooting
The foods were placed in unsealed containers. >>> Keep
the food in sealed containers. Microorganisms may spread
out of unsealed food items and cause bad odor. Remove
any expired or spoiled foods from the product.
The door is not closing.
Food packages may be blocking the door. >>> Relocate
any items blocking the doors.
The product is not standing in full upright position on the
ground. >>> Adjust the stands to balance the product.
The ground is not level or firm. >>> Make sure the ground
is level and sufficiently firm to bear the product.
The vegetable bin is jammed.
The food items may be obstructing with the upper section
of the drawer. >>> Reorganize the food items in the drawer.
If The Surface Of The Product Is Hot.
High temperatures may be observed between the two
doors, on the side panels and at the rear grill while the
product is operating. This is normal and does not require
service maintenance! Be careful when touching these areas.
WARNING:
If the problem persists after following the
instructions in this section, contact your vendor or
an Authorized Service. Do not try to repair the
product.
WARNING:
This product can expose you to chemicals you
to chemicals including Nickel(Metallic) which is
know to the
State of California to cause cancer.
For more information go to www.P65Warn-
ing.cs.gov
Note : Nickel is a component in all stainless
steel and more and some other metal components.
WARNING:
This product can expose you to chemicals you
to chemicals including Nickel(Metallic) which is
know to the
State of California to cause cancer.
For more information go to www.P65Warn-
ing.cs.gov
Note : Nickel is a component in all stainless
steel and more and some other metal components.
WARNING:
This product can expose you to chemicals you
to chemicals including Nickel(Metallic) which is
know to the
State of California to cause cancer.
For more information go to www.P65Warn-
ing.cs.gov
Note : Nickel is a component in all stainless
steel and more and some other metal components.
19 / EN
