APMS80BP Modular Back Panel 665mm User Manual

instructions for

MODULAR BACK PANEL 665MM

model no: APMs80BP

Thank you for purchasing a sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. sAFETY

1.1. GENERAL sAFETY

9 locate the back panel in a suitable working area.

9 Keep the back panel clean and tidy in accordance with good workshop practice.

9 Keep children and unauthorised persons away from the working area.

9 take care when assembling in case of sharp edges, wear protective gloves.

8 DO NOT use the back panel for any purpose other than that for which it is designed.

8 DO NOT get the back panel wet or use in damp or wet locations or areas where there is condensation.

8 DO NOT clean the back panel with any solvents which may damage the surface.

Note: the mounting of this product to the wall, will require assistance from another person.

2. iNTRODUCTiON

 Modularstoragesystemidealforanygarageorworkshop.Canbeeasilyadjustedandupgradedtosuitspecicneeds.Purchasea

simple base cabinet or create a custom storage system.

standard features include:

 •Ballbearingdrawerslidesthroughout.

 •Basecabinetsaresuppliedwithaworktopasstandard.

 •Floorcabinetsfeatureadjustableshelves.

 •Eachunitissuppliedwithalockandtwokeys.

 •Suppliedatpackedandwillrequiresomesimpleassembly.

 •Twodooroorandwallcabinetsfeatureperforatedpegboardpanelsontheinsideofthedoors.

3. sPECiFiCATiON

model no: ............................................................ APMS80BP

W x d x H: ................................................. 665x10x685mm

4. CONTENTs

refer to

instruction

manual

Wear protective

gloves

APMS80BP|Issue:112/02/18

Original Language Version

sealey Group, Kempson Way, suffolk Business Park, Bury st Edmunds, suffolk. iP32 7AR

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

ENviRONMENT PROTECTiON

recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to

a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely

unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids

according to local regulations.

Note: it is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior

notice.

important: no liability is accepted for incorrect use of this product.

Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.

5. AssEMBLY

5.1. seek assistance from another person to mount back panel on the wall.

5.2.  Usingthebackpanelasaguide,drilla12mmholeintothewall.

Note: Thexingholesshouldbehorizontalandthereturnededgetouchesthewall.

5.3.  Insertthewallxing,tthewashersandnutanddoup.Repeatfortheotherthreexings.Ensurethebackpanelissecurelyxedto

the wall.

APMS80BP|Issue:112/02/18

Original Language Version
