Rev: 1.0
Staple Loading Instructions
Staple
Brad Nail
Wire staple
1
2
4
3
Press the slider and move it to bottom.
Insert the staple &
nail strip into the magazine.
Insert the slider and push it until it lock.
Pull out the slider.
NHT0050
3 in 1
Hand Stapler & Nailer
Pull out the slider.
Clean the jammed fasteners with pliers.
Press the magazine back into place.
Hold both side of magazine at opening
tip and pull it backward, then open
the magazine outward.
Stapler Jammed Clear Instruction
1
2
4
3
Turn the bolt to a lower position,
the impact force will be greater
Wire staple
10--12mm
3/8"-- 1/2"
ARROW® T18®
6--14mm
1/4"-- 9/16"
BRAD NAIL
18 GAUGE
TRA700 serials
ARROW® T50®
6--14mm
1/4"-- 9/16"
Stanley®
Adjustable impact force knob:
