www.dibea.com
BX-400
Read this user manual carefully before first
use. Keep this manual for further guidance in
case.
Instruction
Manual
Cordless Vacuum Cleaner
1
Contents
Disclaimer ....................................................................................................................................... 2
Warnings and Precautions ............................................................................................................3
Product Description .......................................................................................................................4
What’s in the box .......................................................................................................................... 4
Installation Guide .......................................................................................................................... 5
Use of brush .................................................................................................................................. 5
Removal and installation of dust cup ............................................................................................5
Use Guide ........................................................................................................................................6
Start of vacuum cleaner ................................................................................................................ 6
Adjustment of suction ...................................................................................................................6
Charging and indicator lights ........................................................................................................6
Cleaning and Maintenance ........................................................................................................... 7
Daily storage ................................................................................................................................. 7
Cleaning of the machine ............................................................................................................... 7
Trouble shooting ............................................................................................................................ 9
Product Specification ...................................................................................................................10
Limited Warranty ........................................................................................................................ 11
1
Disclaimer
Thank you for choosing our BX-400 cordless hand vacuum cleaner. The
information in this document affects your safety and your legal rights and
responsibilities. Read this entire document carefully to ensure proper
configuration before use. Failure to read and follow instructions and warning in
this document may result in serious injuries or death to yourself or others,
damage to the product, or damage to other objects in the vicinity. This document
and all other collateral documents are subject to change at the sole discretion of
Suzhou DIBEA Electrical Technology Co., Ltd. For up-to-date product information,
visit www.dibea.com.
By using this product, you hereby signify that you have read this disclaimer and
warnings carefully and that you understand and agree to abide by the terms and
conditions herein. You agree that you are solely responsible for your own
conduct while using this product, and any consequences thereof. You agree to use
this product only for purposes that are proper and in accordance with all
applicable laws, rules, and regulations, and all terms, precautions, practices,
policies, and guidelines Suzhou DIBEA Electrical Technology Co., Ltd. has made
and may make available.
Suzhou DIBEA Electrical Technology Co., Ltd. accepts no liability for damage,
injury or any legal responsibility incurred directly or indirectly from the use of
this product. The user shall observe usage and lawful practices including, but not
limited to, those set forth in this documents. If your vacuum cleaner is damaged
due to abuse, negligence, incorrect use or failure to configure original accessories,
you will lose the right of after-sales service, and all warranty applications
submitted to the DIBEA Brand Suzhou Service Center will be rejected.
Without the permission and authorization of the Company, this publication shall
be stored in the retrieval system and no one can copy or disseminate it in any
form.
IMPORTANT: Please read and understand this entire manual before
attempting to assemble, operate or install the product.
2
Warnings and Precautions
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,OR INJURY:
Power supply
1. This product is powered by a 14.8V DC lithium battery, use only DIBEA or DIBEA
recommended battery.
2. Do not use or store the product or the battery near any heat sources.
3. Use only the charger supplied by the manufacturer to recharge.
4. Unplug when not in use for extended periods and before maintenance or servicing.
5. Do not incinerate the appliance even if it severely damaged. The batteries can explode in a fire.
6. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
7. Do not use appliance that is damaged or modified. Damaged or modified batteries may exhibit
unpredictable behavior resulting in fire, explosion or risk of injury.
8. Follow all charging instructions and do not charge the appliance outside of the temperature
range specified in the instructions. Charging improperly or at temperatures outside of the specified
range may damage the battery and increase the risk of fire.
Warnings:
The battery is not fully charged out of the carton. Before using the charger to
charge the battery, read the safety instructions above and then follow charging
procedures outlined.
Precautions and warnings
1. Please do not use this product outdoors or in wet places, and do not grasp or grip it with wet
hands.
2. If the machine has been dropped, damaged, placed outdoors or fallen into water, please do not
use and send it to an authorized service center for inspection.
3. Do not put any large objects into the suction port of the vacuum cleaner. Please keep suction
port unblocked; keep the suction port away from ginned cotton, large amount of hair and anything
that may block the suction port.
4. When operating, keep your hair, loose clothes, fingers and all parts of your body away from
suction port and movable parts to avoid being sucked or entangled.
5. Do not deal with burning substances or smoking garbage such as cigarettes, matches or soot.
6. Do not handle flammables or liquids such as gasoline or places where gasoline may be available,
kerosene, paint, alcohol, detergent, etc.
7. Do not operate the vacuum cleaner when the filter device is not installed.
8. Please shut down the machine before connecting or replacing accessories.
9. Do not use it for any other purposes excluded in the instructions.
10. It is not allowed to be used as a toy. When operating, please pay special attention if there are
3
children on the side.
11. Please lay special stress on safety when cleaning the stairs.
12. If the vacuum cleaner is damaged, it must be repaired by the manufacturer, its agents or
personnel with equivalent qualifications in order to prevent injury accidents.
13. Please operate the vacuum cleaner correctly according to the operating instruction. It is only
applicable to accessories recommended by the manufacturer.
14. Do not use without dust bag and/or filters in place.
15. Unplug the charger from outlet before any routine cleaning or maintenance.
Warnings:
The vacuum cleaner herein is for residential usage and shall not be used in
commercial or industrial situations.
Warnings:
Suitable for dry locations ONLY. Do not use outdoors or on wet surfaces. Do NOT
pick up any water or liquids.
Warnings:
THIS IS NOT A TOY. Cleaning, using and maintenance should NOT performed by
children and persons with reduced physical, sensory or reasoning capabilities, or
lack of experience and knowledge without close supervision.
Warnings:
If the appliance is not working as it should, has received a sharp blow,has been
dropped, damaged, left outdoors, or dropped into water, do NOT start and contact
DIBEA customer service for help.
Warnings:
Use only as described in this manual. Use only manufacturer’s
recommended attachments.
4
Product description
What’s in the box
5
Installation Guide
Built-in flip-up brush
Gently flip up the brush when using. Do not pull it off.
Lock/unlock the dust cup
Hold the handle with one hand, then rotate the dust cup counterclockwise with the other hand
to unlock the dust cup; rotate the dust cup clockwise to lock it.
(Lock)
(Unlock)
6
Use Guide
Start / stop the vacuum cleaner
Turn on the OF/OFF button to start / stop working.
Adjust the suction power
Turn on the vacuum cleaner, and press the ON/OFF button on the motor to adjust the suction
power according to your cleaning needs.
Power modes: Eco (Green indicator light) and Max (Red indicator light).
Charging the vacuum cleaner
Step 1: Turn OFF the vacuum cleaner.
Step 2: Put the vacuum cleaner in the charging dock, with the ON/OFF button in front.
Step 3: If the indicator lights flash, then the vacuum cleaner is charging.
Step 4: The indicator lights are all ON, and the vacuum cleaner is fully charged.
ON/OFF button
7
Cleaning and Maintenance
Cleaning
Step 1: Click the dust cup release button to dump the dust inside.
Step 2: Hold the handle with one hand, then rotate the dust cup counterclockwise with the
other hand to unlock the dust cup.
Step 3: Rotate the metal mesh filter clockwise and gently remove it.
Step 4: Remove the HEPA filter inside the metal mesh filter.
Step 5: Wash the HEPA filter, metal mesh filter and dust cup with cool clean water.
Step 6: Ensure the filters are completely dry for 12 hours before refitting.
NOTE:
Washable parts: the HEPA filter, metal mesh filter and dust cup.
Do NOT wash the motor.
Repalace the HEPA filter
The filters should be replaced every 6 to 9 months and whenever worn or damaged.
Note: Before using the vacuum cleaner, make sure that all filters are installed in the
correct position.
Note: Recommended accessories for use with your product are available at extra cost
from your local dealer or authorized service center. If you need assistance in
locating any accessory, please contact DIBEA customer service e-mail:
eu-support@dibea.com
Click to dump the dust inside.
8
Precautions and Product Maintenance
Storage
1. The best storage place is one that is cool and dry, away from direct sunlight and excess heat or
cold. Store the fully charged tool disconnected from the charger.
2. Please fully charge the handheld vacuum cleaner at least once a month to ensure its long
service life.
9
Trouble shooting
※ Common faults of the machine and solutions
S/N
Condition
Fault cause
Solutions
1
Doesn’t work
1. Clog in tool
2. The motor is broken
1. Remove tool and remove
any debris or hair in either
opening of the tool.
2. Contact DIBEA for help
2
Low suction power
1. The dust cup is full
2. The battery is out of power
3. The HEPA filter is wasted
1. Clean the dust cup
2. Recharge the battery
3. Change HEPA filter
3
Dust leakage
1. The dust cup is full
2. The dust cup may not be
assembled properly
1. Clean the dust cup
2. Reinstall the dust cup
4
Won’t turn on
1. Battery is fully discharged
1. Recharge the battery
Product Specification
Rated Power
140W
Battery Capacity
Li-ion 2600mAh 14.8V
Charging time
4-5 hours
Suction power
16KPa (+10% / -5%)
Noise
70dB
Net Weight
0.55KG
Motor
BLDC
Dust cup capacity
200 ml
Working time
40 min (+10% / -5%)
Filter
Metal mesh + HEPA filter
10
2 Years Limited Warranty
If a claim is received within two years of purchase and the product is found to have
failed under the warranty we shall, at our option:
repair the product,
exchange the product with a product that is new or which has been manufactured
from new or serviceable used parts and is at least functionally equivalent to the
original product.
Please note:
1. Easily damaged accessories including filters, brush heads, non-slip strips, etc. are
not covered by our warranty, but if the product accessories are damaged within one
year, you can contact us via amazon message for related accessories, we will offer you
with discounts.
2. You must provide proof of of (both the original and any subsequent)
delivery/purchase before any work can be carried out on your DIBEA appliance.
Without this proof, any work carried out will be chargeable, Keep your receipt or
delivery note.
3. Any parts which are replaced by DIBEA will become the property of DIBEA.
4. The repair or replacement of your DIBEA appliance under guarantee will not
extend the period of guarantee.
The warranty gives you specific rights and you may also have other rights, which vary
in different states and countries. Some jurisdictions may not allow limitations on how
long an implied warranty lasts or the exclusion or limitation of incidental or
consequential damages, so the absolute exclusions or limitations may not apply to
you.
This warranty does not cover (a) normal wear and tear (including, without limitation,
wear and tear of batteries, if applicable), (b) defects caused by rough or inappropriate
handling or use or damage caused by accident, misuse, neglect, fire, water, lightning
or other acts of nature, (c) if the product contains a battery and the fact that the battery
has been short-circuited, if the seals of the battery enclosure or the cells are broken or
show evidence of tampering or if the battery has been used in equipment other than
those for which it has been specified, (d) non-compliance with the product
instructions, (e) willful or deliberate damage, neglect or negligence, (f) use of spare
parts, an unauthorized cleaning solution if applicable, or other replacement items
(including consumables) which are not provided or recommended by us, (g) any
alteration or modification to the product which has been carried out by you or a third
party not authorized by us, (h) any failure to adequately package the product for
transportation, (i) extreme or external causes beyond our reasonable control including,
but not limited to, breakdowns, fluctuations, or interruptions in electric power, ISP
11
(internet service provider) service, or wireless networks, (j) weak and/or inconsistent
wireless signal strength in your home, (k) any product(s) purchased from
unauthorized sellers/dealers/resellers. Some jurisdictions may not allow limitations on
how long an implied warranty lasts or the exclusion or limitation of incidental or
consequential damages, so the above exclusions or limitations may not apply to you.
Suzhou Dibea Electrical Technology Co.,Ltd.
Providing one-stop household
Official website: www.dibea.com Email
address: [email protected]
cleaning solution
