Service Bulletin
Subject: UP0240 Technical Specifications
AIR-COOLED & WATER-COOLED MODELS
1 of 3
Document Number: MII_SB_0082 3/25
MANITOWOC ICE
2110 SOUTH 26TH STREET, MANITOWOC, WI 54220
800-545-5720
WWW.MANITOWOCICE.COM
GENERAL SPECIFICATIONS
Operating Temperatures
Minimum 50°F (10°C)
Maximum 100°F (38°C)
Refrigerant Charge (R-290)
Air-cooled Water-cooled
5.3 oz (150 g) 5.3 oz (150 g)
Ice Making Water Inlet
Water Inlet Connection -
3/8” FPT (Female Pipe Thread)
Water Temperature -
Minimum 40°F (4.4°C)
Maximum 90°F (32°C)
Water Pressure -
Minimum 40 psig (1.3 bar)
Maximum 80 psig (5.5 bar)
Condenser Water Inlet
Connection Size -
3/8” FPT (Female Pipe Thread)
Water Temperature -
Minimum 40°F (4.4°C)
Maximum 90°F (32°C)
Water Pressure -
Minimum 20 psig (1.3 bar)
Maximum 150 psig (10.3 bar)
Ice Making Water Drain
Drain Connection -
1/2” FPT (Female Pipe Thread)
Potable Water
17 gallons per 100 lbs of ice
64 liters per 45.5 kg of ice
Electrical
115V/60Hz/1 Ph 208-230V/60 Hz/1 Ph 230V/50 Hz/1 Ph
Air: Min Circuit Amps - 7.0
Max Fuse Size - 15 amp
Water: Min Circuit Amps - 6.0
Max Fuse Size - 15 amp
Air: Min Circuit Amps - 3.5
Max Fuse Size - 15 amp
Water: Min Circuit Amps - 3.5
Max Fuse Size - 15 amp
Air: Min Circuit Amps - 3.5
Max Fuse Size - 15 amp
Water: Min Circuit Amps - 3.0
Max Fuse Size - 15 amp
Energy Usage
Kwh / 100 lbs
Air-cooled
Half Dice: 6.23 Kwh
Dice: 6.23 Kwh
Water-cooled
Half Dice: 4.65 Kwh
Dice: 4.65 Kwh
Compressor Nominal Rating 1/2 HP
Heat of Rejection
Air Conditioning
3,700 BTU/hr
(932 kcal/hr)
Peak
4,400 BTU/hr
(1,109 kcal/hr)
Fan Cycle Control Cut-in - 200 psig (14 bar) Cut-out - 150 psig (10 bar)
High Pressure Settings Cut-in - 250 psig (17 bar) Cut-out - 350 psig (24 bar)
Dimensions
Height Width Depth
38.5 in (977 mm) 26 in (660 mm) 28.5 in (723 mm)
Clearances
Top Side Back
5.0 in (130 mm) 5.0 in (130 mm) 5.0 in (127 mm)
2 of 3
Document Number: MII_SB_0082 3/25
Subject: UP0240 Technical Specifications
Self Contained Air-cooled Ice Machines
Cycle TimesFreeze Time + Harvest Time = Total Cycle Time
Air
Temperature
Around the
Unit
Freeze Time (Minutes)
Harvest
Time
Water Temperature
50oF
10oC
70oF
21oC
90oF
32oC
70oF
21oC
13.9-16.0 16.9-18.9 18.0-20.3
1.0-2.5
80oF
27oC
15.0-17.2 17.0-20.1 19.4-22.4
90oF
32oC
16.2-18.5 19.5-22.5 21.6-25.0
100oF
38oC
19.0-21.5 20.4-24.0 23.4-26.5
110oF
43oC
21.6-24.6 23.6-26.6 24.5-27.7
Cycle times and pressures vary with operating condition.
Production and cycle times are for dice cube - Half dice cube cycle times
can be 2 - 3 minutes faster, depending on water and ambient temperature
24 Hour Ice Production
Air Temperature
Around the Unit
Water Temperature
50oF
10oC
70oF
21oC
90oF
32oC
70oF
21oC
225 lbs
102 kgs
190 lbs
86 kgs
175 lbs
79 kgs
80oF
27oC
210 lbs
95 kgs
180 lbs
82 kgs
160 lbs
73 kgs
90oF
32oC
195 lbs
88 kgs
160 lbs
73 kgs
145 lbs
66 kgs
100oF
38oC
170 lbs
77 kgs
150 lbs
68 kgs
140 lbs
64 kgs
110oF
43oC
155 lbs
70 kgs
140 lbs
64 kgs
135 lbs
61 kgs
Ice slab weight of one harvest cycle = 2.3 lbs to 2.9 lbs (1.0 kgs to 1.3 kgs).
Operating Pressures - Freeze Cycle
Air Temperature
Around the Unit
Discharge Pressure Suction Pressure
50oF
10oC
145-205 psig
10.0-14.1 bar
40-14 psig
2.8-1.0 bar
70oF
21oC
150-210 psig
10.3-14.5 bar
42-15psig
2.9-1.0 bar
80oF
27oC
160-230 psig
11.0-15.9 bar
46-18 psig
3.2-1.2 bar
90oF
32oC
180-240 psig
12.4-16.5 bar
51-20 psig
3.5-1.4 bar
100oF
38oC
230-280 psig
15.9-19.3 bar
54-24 psig
3.7-1.7 bar
110oF
43oC
245-295 psig
16.9-20.3 bar
58-25 psig
4.0-1.7 bar
Operating Pressures - Harvest Cycle
Air Temperature
Around the Unit
Discharge Pressure Suction Pressure
50oF
10oC
90-105 psig
6.2-7.2 bar
55-65 psig
3.8-4.5 bar
70oF
21oC
90-105 psig
6.2-7.2 bar
60-70 psig
4.1-4.8 bar
80oF
27oC
95-110 psig
6.6-7.6 bar
65-85 psig
4.5-5.9 bar
90oF
32oC
105-125 psig
7.2-8.6 bar
65-95 psig
4.5-6.6 bar
100oF
38oC
115-150 psig
7.9-10.3 bar
70-105 psig
4.8-7.2 bar
110oF
43oC
160-180 psig
11.0-12.4 bar
75-110 psig
5.2-7.6 bar
Storage Capacity
Storage Bin Capacity*
90 lbs
(40 kg)
*Storage Capacity is AHRI certified.
NOTE: Ice Production Derate %
• 60Hz Dice and Half Dice production derate as shown
• 60Hz Regular cube production derate is 7%.
• 50Hz Dice and Half Dice production derate is 12%.
• 50Hz Regular cube production derate is 14%.
3 of 3
Document Number: MII_SB_0082 3/25
Subject: UP0240 Technical Specifications
Self Contained Water-cooled Ice Machines
Cycle Times
Freeze Time + Harvest Time = Total Cycle Time
Air
Temperature
Around the
Unit
Freeze Time (Minutes)
Harvest
Time
Water Temperature
50oF
10oC
70oF
21oC
90oF
32oC
70oF
21oC
15.9-17.9 16.9-18.9 18.0-20.3
1.0-2.5
80oF
27oC
16.3-18.4 17.3-19.5 18.4-20.5
90oF
32oC
17.0-19.9 19.0-20.4 19.1-21.8
100oF
38oC
18.0-21.0 19.5-21.8 20.8-24.0
110oF
43oC
19.2-21.6 19.9-22.2 21.7-24.9
Cycle times and pressures vary with operating condition.
Production and cycle times are for dice cube - Half dice cube cycle times
can be 2 - 3 minutes faster, depending on water and ambient temperature
24 Hour Ice Production
Air Temperature
Around the Unit
Water Temperature
50oF
10oC
70oF
21oC
90oF
32oC
70oF
21oC
210 lbs
95.3 kgs
190 lbs
86.2 kgs
180 lbs
81.6 kgs
80oF
27oC
200 lbs
90.7 kgs
185 lbs
83.9 kgs
175 lbs
79.4 kgs
90oF
32oC
190 lbs
86.2 kgs
170 lbs
77.1 kgs
160 lbs
72.6 kgs
100oF
38oC
180 lbs
81.6 kgs
165 lbs
74.8 kgs
155 lbs
70.3 kgs
110oF
43oC
170 lbs
77.1 kgs
160 lbs
72.6 kgs
150 lbs
68.0 kgs
Ice slab weight of one harvest cycle = 2.3 lbs to 2.9 lbs (1.0 kgs to 1.3 kgs).
Operating Pressures - Freeze Cycle
Air Temperature
Around the Unit
Discharge Pressure Suction Pressure
50oF
10oC
160-180 psig
11.0-12.4 bar
48-17 psig
3.3-1.2 bar
70oF
21oC
160-180 psig
11.0-12.4 bar
52-20 psig
3.6-1.4 bar
80oF
27oC
160-180 psig
11.0-12.4 bar
52-20 psig
3.6-1.4 bar
90oF
32oC
160-180 psig
11.0-12.4 bar
53-23 psig
3.7-1.6 bar
100oF
38oC
160-180 psig
11.0-12.4 bar
54-24 psig
3.7-1.7 bar
110oF
43oC
160-180 psig
11.0-12.4 bar
58-25 psig
4.0-1.7 bar
Operating Pressures - Harvest Cycle
Air Temperature
Around the Unit
Discharge Pressure Suction Pressure
50oF
10oC
90-105 psig
6.2-7.2 bar
60-70 psig
4.1-4.8 bar
70oF
21oC
90-110 psig
6.2-7.6 bar
60-70 psig
4.1-4.8 bar
80oF
27oC
95-110 psig
6.6-7.6 bar
65-85 psig
4.5-5.9 bar
90oF
32oC
105-125 psig
7.2-8.6 bar
65-95 psig
4.5-6.6 bar
100oF
38oC
105-145 psig
7.2-10.0 bar
65-100 psig
4.5-6.9 bar
110oF
43oC
105-145 psig
7.2-10.0 bar
65-105 psig
4.5-7.2 bar
Condenser Water Consumption
Ice Production Water Usage
100 lbs
45.4 kgs
166 Gallons
628 Liters
Water Regulating Valve set point: 235 psig (16.2 bar)
Storage Capacity
Storage Bin Capacity*
90 lbs
(40 kg)
*Storage Capacity is AHRI certified.
NOTE: Ice Production Derate %
• 60Hz Dice and Half Dice production derate as shown
• 60Hz Regular cube production derate is 7%.
• 50Hz Dice and Half Dice production derate is 12%.
• 50Hz Regular cube production derate is 14%.
