Service Bulletin
Subject: UP0140 Technical Specifications
AIR-COOLED MODELS
1 of 2
Document Number: MII_SB_0080 3/25
MANITOWOC ICE
2110 SOUTH 26TH STREET, MANITOWOC, WI 54220
800-545-5720
WWW.MANITOWOCICE.COM
GENERAL SPECIFICATIONS
Operating Temperatures
Minimum 50°F (10°C)
Maximum 100°F (38°C)
Refrigerant Charge (R-290) 4.9 oz (140 g)
Ice Making Water Inlet
Connection Size -
3/8” FPT (Female Pipe Thread)
Water Temperature -
Minimum 40°F (4.4°C)
Maximum 90°F (32°C)
Water Pressure -
Minimum 20 psig (1.3 bar)
Maximum 80 psig (5.5 bar)
Ice Making Water Drain
Connection Size -
1/2” FPT (Female Pipe Thread)
Potable Water
17 gallons per 100 lbs of ice
64.35 liters per 45.5 kg of ice
Electrical
115V/60 Hz/1 Ph 230V/50 Hz/1 Ph
Energy Usage
Kwh / 100 lbs
7.25 Kwh
Min Circuit Amps - 5.0
Max Fuse Size - 15 amp
Min Circuit Amps - 2.5
Max Fuse Size - 15 amp
Compressor Nominal Rating 0.33 HP
Heat of Rejection
Air Conditioning
2,500 BTU/hr
(630 kcal/hr)
Peak
2,900 BTU/hr
(731 kcal/hr)
Fan Cycle Control Cut-in - 200 psig (14 bar) Cut-out - 150 psig (10 bar)
High Pressure Settings Cut-in - 250 psig (17 bar) Cut-out - 350 psig (24 bar)
Dimensions
Height Width Depth
38.5 in (980 mm) 26.0 in (660 mm) 28.5 in (725 mm)
Clearances
Top Side Back
5.0 in (130 mm) 5.0 in (130 mm) 5.0 in (130 mm)
2 of 2
Document Number: MII_SB_0080 3/25
Subject: UP0140 Technical Specifications
Self Contained Air-cooled Ice Machines
Cycle Times
Freeze Time + Harvest Time = Total Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time (Minutes)
Harvest
Time
Water Temperature
50oF
10oC
70oF
21oC
90oF
32oC
70oF
21oC
10.2-11.7 12.3-13.7 13.0-14.8
1.0-2.5
80oF
27oC
11.2-12.9 13.0-14.9 14.5-16.5
90oF
32oC
11.8-13.7 14.5-16.5 17.5-20.0
100oF
38oC
14.6-16.5 17.6-20.0 17.5-21.5
110oF
43oC
16.2-18.5 19.9-22.4 20.3-23.0
Cycle times and pressures vary with operating condition.
Production and cycle times are for dice cube - Half dice cube cycle times
can be 2 - 3 minutes faster, depending on water and ambient temperature
24 Hour Ice Production
Air Temp.
Entering
Condenser °F/°C
Water Temperature
50oF
10oC
70oF
21oC
90oF
32oC
70oF
21oC
130 lbs
59 kgs
110 lbs
50 kgs
105 lbs
48 kgs
80oF
27oC
120 lbs
54 kgs
105 lbs
48 kgs
95 lbs
43 kgs
90oF
32oC
115 lbs
52 kgs
95 lbs
43 kgs
85 lbs
39 kgs
100oF
38oC
95 lbs
43 kgs
85 lbs
39 kgs
80 lbs
36 kgs
110oF
43oC
85 lbs
39 kgs
80 lbs
36 kgs
70 lbs
32 kgs
Ice slab weight of one harvest cycle = 1.1 lbs to 1.4 lbs (0.49 kgs to 0.63
kgs).
Operating Pressures - Freeze Cycle
Air Temp. Entering
Condenser °F/°C
Discharge Pressure Suction Pressure
50oF
10oC
140-210 psig
9.7-14.5 bar
45-17 psig
3.1-1.2 bar
70oF
21oC
140-215 psig
9.7-14.8 bar
54-17 psig
3.7-1.2 bar
80oF
27oC
150-220 psig
10.3-15.2 bar
55-17 psig
3.8-1.2 bar
90oF
32oC
160-225 psig
11.0-15.5 bar
58-17 psig
4.0-1.2 bar
100oF
38oC
205-230 psig
14.1-15.9 bar
60-20 psig
4.1-1.4 bar
110oF
43oC
235-260 psig
16.2-18.0 bar
65-22 psig
4.5-1.5 bar
Operating Pressures - Harvest Cycle
Air Temp. Entering
Condenser °F/°C
Discharge Pressure Suction Pressure
50oF
10oC
95-120 psig
6.6-8.3 bar
65-95 psig
4.5-6.6 bar
70oF
21oC
100-120 psig
6.9-8.3 bar
70-95 psig
4.8-6.6 bar
80oF
27oC
105-120 psig
7.2-8.3 bar
75-95 psig
5.2-6.6 bar
90oF
32oC
120-140 psig
8.3-9.7 bar
90-114 psig
6.2-7.9 bar
100oF
38oC
140-160 psig
9.7-11.0 bar
110-135 psig
7.6-9.3 bar
110oF
43oC
160-185 psig
11.0-12.8 bar
100-155 psig
6.9-10.7 bar
Storage Capacity
Storage Bin Capacity*
90 lbs
(40 kg)
*Storage Capacity is AHRI certified.
NOTE: Ice Production Derate %
• 60Hz Dice and Half Dice production derate as shown
• 60Hz Regular cube production derate is 7%.
• 50Hz Dice and Half Dice production derate is 12%.
• 50Hz Regular cube production derate is 14%.
