20V 12’’ Cordless Snow Shovel
270-3278
TOLL-FREE HELPLINE: 1-888-930-8528
Read this operator manual before using this product. Failure to do so can result in serious injury. SAVE THIS
MANUAL
OPERATOR’S MANUAL
TABLE OF CONTENTS
Some of the following symbols may be used on this product. Please study them and learn their meaning.
Proper interpretation of these symbols will allow you to operate the product better and safer.
READ ALL INSTRUCTIONS!
WARNING:
Some dust created by power sanding, sawing, grinding, drilling and other construction activities
may contain chemicals known to the state of California to cause cancer, birth defects or other
reproductive harm. Some examples of these chemicals are:
Lead from lead-based paints,
Crystalline silica from bricks and cement and other masonry products, and
Arsenic and chromium from chemically - treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your
exposure to these chemicals: work in a well-ventilated area, and work with approved safety equipment,
such as those dust masks that are specially designed to lter out microscopic particles.
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible danger. The safety symbols and the
explanations with them deserve your careful attention and understanding. The symbol warnings do not,
by themselves, eliminate any danger. The instruction and warnings they give are no substitutes for proper
accident prevention measures.
The following signal words and meanings are intended to explain the levels of risk associated with this
product.
NOTICE
CAUTION
WARNING
DANGER
SYMBOL SYMBOL
Indicates a hazardous situation, which, if not avoided, could result in injury.
Indicates a hazardous situation, which, if not avoided, could result in injury.
Indicates a hazardous situation, which, if not avoided, could result in injury.
(Without Safety Alert Symbol) Indicates information considered important.
MEANING
.....................................................................................................................3
................................................................................................................5
........................................................................................................9
..........................................................................................................11
.....................................................................................................12
.................................................................................................................13
............................................................................................................................14
.......................................................................................................................15
...............................................................................................................................16
.................................................................................................................17
..............................................................................................................................17
Safety symbols
Safety instructions
Know your snow shovel
Charging your battery
Assembly and operation
Before operation
Operation
Maintenance
Storage
Trouble shooting
Warranty
Read the operator’s manual
WARNING
Do not expose the unit to rain or wet
conditions. Keep dry.
SYMBOL SYMBOLDESCRIPTION DESCRIPTION
SAFETY ALERT
– indicate a precau-
tion, a warning or a danger.
Wear respiratory protection
Wear safety footwear
DANGER
Cutting hazard - Keep feet
away from the rotating auger.
DANGER
Cutting/dismemberment hazard Keep
hands away from the rotating auger.
Stop motor before removing debris
Do not use hands to unclog chute.
Do not burn the battery pack.
Batteries may enter water cycle if
disposed of improperly, which can be
hazardous to the ecosystem. Do not
dispose of old batteries as unsorted
municipal waste.
Wear hearing protection.
Wear eye protection.
Wear protective gloves
CAUTION
Beware of stone or other
foreign objects that could be thrown
from the appliance.
Indoor use only. Only use battery
charger indoors.
The rotating part will continuously run
for several seconds after you turn o
the machine.
DANGER
Cutting/dismemberment
hazard Keep feet away from the
rotating part.
Li-ion battery. This product has been
marked
with a symbol relating to ‘separate
collection’
for all battery packs and battery pack.
It will
then be recycled or dismantled in
order to
reduce the impact on the environment.
Battery packs can be hazardous for
the
environment and for human health
since they
contain hazardous substances.
SAFETY INSTRUCTIONS
WARNING:
Only use the accessories that are provided with this product. Use other accessories might increase
the risk of injury. Follow the instructions in this manual.
WARNING:
When using electric gardening appliances, basic safety precautions should always be followed to
reduce the risk of re, electric shock, or injury to persons, includes the following:
READ ALL INSTRUCTIONS
1) Do not use on graveled surface unless the snow blower is adjusted for such a surface in accordance with
the operator’s manual.
2) Keep Children Away – All persons (besides operator) should be kept a safe distance from work area.
3) Dress Properly – Do not wear loose clothing or jewelry. They can be caught in moving parts.
4) Wear proper footwear when operating the snow blower.
5) Keep hands away from moving parts.
6) Keep guards in place and in working order.
7) Don’t Force Snow Shovel – It will perform better and safer at the rate for which it was designed.
8) Don’t Overreach – Keep proper footing and balance at all times.
9) If the snow Shovel strikes a foreign object follow these steps:
i.Stop snow Shovel. Release the switch.
ii.Remove the battery pack.
iii.Inspect for damage.
iv.Repair any damage before restarting and operating the snow shovel.
10) Disconnect Snow Shovel– Remove the battery pack from the snow shovel when not in use, before ser-
vicing, when changing accessories, and the like.
11) Store Idle Snow Shovel Indoors – When not in use, the snow shovel should be stored indoors in dry,
locked-up place – out of reach of children.
12) Maintain Snow Shovel with Care – Follow instructions for lubricating and changing accessories.
SAVE THESE INSTRUCTIONS
Safe Operation Practices for Snow Shovel
This snow shovel is capable of amputating hands and feet and throwing objects. Failure to observe the fol-
lowing safety instructions could result in serious injury.
Training
1. Read, understand and follow all instructions on the machine and in the manual(s) before operating this
unit. Be thoroughly familiar with the controls and the proper use of the equipment. Know how to stop the
unit and disengage the controls quickly.
2. Never allow children to operate the equipment. Never allow adults to operate the equipment without prop-
er instruction.
3. Keep the area of operation clear of all persons, particularly small children.
4. Exercise caution to avoid slipping or falling, especially when operating the snow shovel in reverse.
Preparation
1. Thoroughly inspect the area where the equipment is to be used and remove all doormats, sleds, boards,
wires, and other foreign objects.
2. Do not operate the equipment without wearing adequate winter garments. Avoid loose tting clothing that
can get caught in moving parts. Wear footwear that will improve footing on slippery surfaces.
3. Never attempt to make any adjustments while the motor is running (except when specically recommend-
ed by manufacturer).
4. Always wear safety glasses or eye shields during operation or while performing an adjustment or repair
to protect eyes from foreign objects that may be thrown from the machine.
Operation
1. Do not put hands or feet near or under rotating parts. Keep clear of the discharge opening at all times.
2.Exercise extreme caution when operating on or crossing gravel drives, walks, or roads. Stay alert for
hidden hazards or trac.
3. After striking a foreign object, stop the motor, remove the battery pack from the machine, thoroughly in-
spect the snow shovel for any damage, and repair the damage before restarting and operating the snow
shovel.
4. If the unit should start to vibrate abnormally, stop the motor and check immediately for the cause. Vibra-
tion is generally a warning of trouble.
5. Stop the motor whenever you leave the operating position, before unclogging the rotor housing, and
when making any repairs, adjustments or inspections.
6. When cleaning, repairing or inspecting the snow shovel, stop the motor and make certain the collector/
impeller and all moving parts have stopped. Remove the battery pack from the machine to prevent acci-
dentally starting the motor.
7. Exercise extreme caution when operating on slopes.
8. Never operate the snow shovel without proper guards, and other safety protective devices in place and in
proper working order.
9. Never direct the discharge toward people or areas where property damage can occur. Keep children and,
pets and other bystanders away from the work area.
10. Do not overload the machine capacity by attempting to clear snow at too fast a rate.
11. Never operate the machine at high transport speeds on slippery surfaces.
12. Remove the battery pack when snow shovel is transported or not in use.
13. Use only attachments and accessories approved by the manufacturer of the snow shovel.
14. Never operate the snow shovel without good visibility or light. Always be sure of your footing, and keep a
rm hold on the handles. Walk; never run.
Clearing a Clogged Rotor Housing
Hand contact with the rotating auger inside the rotor housing is the most common cause of injury associated
with snow shovel. Never use your hand to clean out the rotor housing.
To clear the chute:
1.SHUT THE MOTOR OFF. Remove the battery.
2.Wait 10 seconds to be sure the rotating auger has rotating.
3.Always use a clean-out tool, not your hands, to free the rotating auger.
Maintenance and Storage
1. Check all the bolts at frequent intervals for proper tightness to be sure the equipment is in safe working
condition.
2. Always refer to operator’s manual for important details if the snow shovel is to be stored for an extended
period.
3. Maintain or replace safety and instruction labels, as necessary.
4. Run the machine a few minutes after throwing snow to prevent freeze-up of the auger.
ADDITIONAL SAFE OPERATION PRACTICES FOR SNOW
SHOVEL
Safety instructions
1. Training
The following should be carried out for training:
a) Read the operating and service instruction manual carefully. Be thoroughly familiar with the controls and
the proper use of the equipment.
b) Never allow children to operate a power snow shovel.
c) Keep the area of operation clear of all persons, particularly small children, and pets.
d) Do not use a shovel for any job except that for which it is intended.
2. Preparation
The following preparations should be carried out:
a) Thoroughly inspect the area where the equipment is to be used and remove all stones, sticks, wires,
boards, and other foreign objects.
b) Do not operate the equipment when barefoot or wearing open sandals. Always wear substantial footwear.
c) Work only in daylight or in good articial light.
d) Always be sure of your footing; keep a rm hold on the handle and walk, never run.
3. Operation
During operation, the following should be observed:
a) Do not put hands or feet near or under rotating parts. Keep clear of the discharge opening at all times.
Stop the auger when crossing gravel drives, walks, or roads.
b) After striking a foreign object, stop the motor, remove the battery pack, thoroughly inspect the machine
for any damage, and repair the damage before restarting and operating.
c) If the equipment should start to vibrate abnormally, stop the motor and check immediately for the cause.
Vibration is generally a warning of trouble.
d) Stop the motor and remove the battery pack whenever leaving the equipment, before cleaning the rotor
housing, and before making any repairs or inspections.
e) Do not clean snow across the face of slopes, or in an up-and down fashion. Exercise extreme caution
when changing direction on slopes. Do not work on excessively steep slopes.
f) Never operate the snow shovel without proper guards, plates, or other safety protective devices in place.
g) Do not wash with a hose; avoid getting water in motor and electrical connections.
4. Maintenance
The following maintenance items should be carried out:
a) Check the scraper/auger and the mounting bolts at frequent intervals for proper tightness.
b) Keep all nuts, bolts, and screws tight to be sure the equipment is in safe working condition.
c) Replace the auger if it is bent or cracked. An unbalanced auger causes vibration that could damage the
motor drive unit or cause personal injury.
d) Clean the auger thoroughly and check its balance by supporting it horizontally on a thin nail through its
center hole. The nail should also be in a horizontal position. If either end of the auger rotates downward,
remove some plastic from the heavy or lower end until the auger is balanced. It is balanced when neither
end drops.
SAFETY WARNINGS FOR BATTERY PACK
1. Do not dismantle, open or shred battery pack.
2. Do not expose battery pack to heat or re. Avoid storage in direct sunlight. The cells may explode. Check
with local codes for possible special disposal instructions.
3. Do not short-circuit a battery pack Do not store battery packs haphazardly in a box or drawer where they
may short-circuit each other or be short-circuited by other metal objects. When battery pack is not in use,
keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal
objects, that can make a connection from one terminal to another. Shorting the battery terminals together
may cause burns or re.
4. Do not subject battery pack to mechanical shock
5. Observe the plus (+) and minus (-) marks on the battery back and equipment and ensure correct use.
6. Keep battery pack out of the reach of children.
7. Always purchase the battery pack recommended by the device manufacturer of the equipment.
8. Keep battery pack clean and dry.
9. Wipe the battery pack terminals with a clean dry cloth if they become dirty.
10. Battery pack needs to be charged before use. Always use the correct charger and refer to the manufac-
turer’s instructions or equipment manual for proper charging instructions.
11. Do not leave battery pack on prolonged charge when not in use.
12. After extended periods of storage, it may be necessary to charge and discharge the battery pack several
times to obtain maximum performance.
13. Battery pack gives its best performance when it is operated at normal room temperature (68°F ±41°F).
14. Use the battery pack only in the application for which it was intended.
15. Remove the battery pack from the equipment when not in use.
16. Dispose of properly.
17. Do not handle the charger; including charger plug, or charger terminals with wet hands.
18. Do not charge the battery pack outdoors, in rain, or in wet locations.
19. Recharge only with the charger specied by the manufacturer. A charger that is suitable for one type of
battery pack may create a risk of re when used with another battery pack.
20. Use power tools only with specically designated battery packs. Use of any other battery packs may cre-
ate a risk of injury and re.
21. Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally
occurs, ush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
Save these instructions.Refer to them frequently and use them to instruct others who may use
this tool. If you lend this tool to someone else, also lend these instructions to them to prevent
misuse of the product and possible injury.
SAFETY WARNINGS FOR BATTERY CHARGER
WARNING:
Any changes or modications to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
These limits are designed to provide reasonable protection against harmful interference in a residential in-
stallation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
● Consult the dealer or an experienced radio/TV technician for help.
KNOW YOUR CORDLESS SNOW SHOVEL
Read the owner’s manual and safety rules carefully before operating your cordless snow shovel. Compare
the illustration below to the actual unit in order to familiarize yourself with the location of the various controls
and adjustments. Save this manual for future reference.
1. Rear handle
2. Lock-o switch
3. Battery compartment
4. Upper pole
5. Locking knob
6. Adjustable front handle
7. Middle pole
8. Lower pole
9. Impeller/auger
10. Battery pack
11. Battery charger
1
2
3
4
5
6
7
8
9
11
10
Item No.
Voltage
No-load speed
Clearing width
Snow depth
Operation type
Throw distance
Machine weight (Without battery)
Battery pack
Charger
Charger Rating
Charging Time (Approx.)
Item No.
Battery pack
Charger
Locking knob+locking bolt for auxiliary handle
Locking knob+locking bolt for main shaft
270-3278
20V D.C.
2400/min
12” (30cm)
6” (15cm)
Single-Stage
16.4ft (5m)
10.58 lbs (4.8 kg)
4.0Ah Li-ion (D01204200)
1.5 A Rapid Charger (D02203000)
Input: 120V~60Hz, 50W
Output: Max. 21.2V D.C., 1.5A
180 Mins
270-3278
1 pc
1 pc
1 set
2 sets
TECHNICAL DATA
ACCESSORIES
LED Indicator
3 lights on
2 lights on
1 light on
1 light ashing
Battery Charge Level/Working Conditions
70%<Charge Level≤100%
40%<Charge Level≤70%
10%<Charge Level≤40%
Charge Level ≤10%
CHARGING YOUR BATTERY
BATTERY INDICATOR
The battery pack is equipped with a push button for checking the charge level. Simply press the push button
to read o the battery charge level from the LEDs of the battery indicator.
WARNING:
Do not use the charger outdoors or expose it to wet or damp conditions. Water entering the charger
will increase the risk of electric shock.
NOTICE:
Lithium-Ion battery packs are shipped partially charged. Before using it the rst time, fully charge
the battery pack.
NOTICE:
You can only charge one battery at a time with the charger provided.
a. Connect the charger to the power supply (120V~60Hz). The red charging indication LED will shine, indi-
cating that the charger is working correctly.
b. Align the raised ribs of the battery pack with the battery-mounting slots in the charger; slide the battery
pack down onto the charger.
c. When the battery is inserted properly, the green light will slowly ash to indicate that the battery is
charging. The red light will turn o.
d. When the green light stays on, the battery is fully charged.
NOTICE:
●
The battery pack will fully charge if left on the charger, but it will not overcharge. If the battery
pack remains on the charger for one month or more, it will drop to lower charge capacity. If this
occurs, re-install the battery pack on the charger to recharge it fully.
● A signicantly reduced run time after fully charging the battery pack indicates that the batteries
are near the end of their usable life and must be replaced.
● The charger may warm during charging. This is part of the normal operation of the charger.
Charge in a well-ventilated area.
CHARGER LED INDICATOR TABLE
Use the table below to determine charger light patterns and possible causes.
Possible Reason
•No load charging –There’s no battery inserted in the charger.
•Fully charged – The battery is fully charged and the charging process is nished.
•Normal charging – The battery is being charged.
Indication
•Red Light – O
•Green Light – On
•Red Light – On
•Green Light – O
Assembly And Operation
WARNING:
To prevent accidental starting that may could cause serious personal injury, always remove the
battery pack from the tool when assembling parts.
WARNING:
Do not attempt to modify this tool or create accessories not recommended for use with this tool. Any
such alteration or modication is misuse and could result in a hazardous condition leading to seri-
ous injury.
WARNING:
Do not attempt to start the tool before it has been completely assembled.
UNPACKING
● This product requires assembly.
● Remove all the items from the carton. Make sure that all items listed in the parts list are included.
● Inspect the product carefully to make sure that no breakage or damage occurred during shipping.
● Do not discard the packing material until you have carefully inspected and satisfactorily operated the tool.
If any parts are damaged or missing, please return the tool to the place of purchase
ASSEMBLING THE MAIN
SHAFT
a. The tool arrives with the shaft locking knobs and
bolts detached and shafts loosened. You need to
connect and lock the three shafts together. Slide
the middle shaft onto the lower shaft. Line up the
two square mounting holes on each tube.
Make
sure the cable (a) is clear of the square holes.
(Fig, 1)
ASSEMBLY AND
OPERATION
b. Align and insert the shaft locking bolt through the
aligned holes and into the end. Then insert the
shaft locking knob into the end of the bolt from
the other side.
(Fig. 2)
NOTICE: You may have to carefully move the
cable inside the tube to one side if it blocks
the path of the bolt.
c. Turn the locking knob clockwise to tighten. Now
the middle shaft is locked with the lower shaft.
(Fig. 3)
d. Slide the upper shaft onto the middle shaft. Line
up the two square mounting holes on each tube.
Align and insert the shaft locking bolt through the
aligned holes and into the end. Then insert the
shaft locking knob into the end of the bolt from
the other side. Tighten the knob by turning it
clockwise.
(Fig. 4)
NOTICE: Pay attention to the main handle direc-
tion when installing the upper shaft to the middle
shaft. The main handle should be the opposite
direction with the snow outlet.
BEFORE OPERATION
WARNING:
ALWAYS stop the machine and
remove the battery pack before making any ad-
justment.
ADJUSTING THE AUXILIARY
HANDLE
a. Stop the machine and remove the battery pack.
Wait until the auger comes to a complete stop.
Turn the auxiliary handle locking knob count-
er-clockwise to loosen the handle.
(Fig, 5)
b. Rotate the auxiliary handle or adjust the height
as needed to a comfortable position.
(Fig. 6)
c. Re-tighten the handle locking knob by turning it
clockwise. Be sure to tighten securely in order to
prevent the auxiliary handle from moving around
or sliding.
INSTALLING OR REMOVING
THE BATTERY PACK
To install:
a. Open the battery pack compartment cover; slide
the battery pack into the port inside of the compart-
ment. Push to the end with a sucient force until it
clicks to lock in place.
(Fig, 7)
b. Close the battery pack compartment cover.
(Fig. 8)
NOTICE: The battery can only be installed in one
way
To remove:
a. Open the battery pack compartment cover.
b.
(Fig. 9)
Depress the battery pack release button at both
sides and hold them, then pull the battery pack
out from the battery compartment.
(Fig. 10)
OPERATION
INTENDED USE
This snow shovel is intended to be used to sweep
snow from sidewalks, steps, patios, decks and other
hard at surfaces such as paved driveways. Use it
only on hard, at surfaces free of sand, stone and
debris, wires or any other objects.
WARNING: Do not allow familiarity with this
product to make you careless. Remember that
a careless fraction of a second is sucient to
inict serious injury.
WARNING: Do not use any attachments or
accessories not recommended by the manufac-
turer of this product. The use of attachments
or accessories not recommended can result in
serious personal injury.
WARNING: Keep the area to be cleared free
of stones, toys or other foreign objects that the
auger might pick up and throw. Such items could
be covered by snow and are easy to overlook, so
be sure to conduct a thorough inspection of the
area before beginning work.
STARTING/STOPPING THE SNOW SHOVEL NO-
TICE: Before each use, check and make sure
all fasteners on the snow shovel (screws, bolts,
etc.) are fully tightened. Check the scraper blade
and the auger for wear and tear at regular inter-
vals.
To start the snow shovel:
WARNING: To avoid injury; do not squeeze
the trigger while the snow shovel is inverted.
When starting, make sure the operator and the
To stop the snow shovel:
To stop the snow shovel, just release the on/o
switch.
OPERATING TIPS
● Start the cordless snow shovel. Push the shovel
forward at a comfortable rate, yet slow enough to
clear the path completely. The clearing width of
the snow shovel and the depth of snowfall should
dictate your forward speed.
● Direct the snow discharge to the right or to the
left by holding the cordless snow shovel at a
slight angle.
● To remove snow most eciently, throw the snow
downwind and slightly overlap each swath.
● When clearing deeper drifts, hold the cordless
snow shovel by the upper and auxiliary handles
and use a swinging or sweeping motion. Remove
up to 6 in. (15 cm) of snow with each pass and
repeat as many times as needed.
● Remove the battery after using the cordless
snow shovel. Hang the shovel so it will not be
misplaced or damaged.
MAINTENANCE
WARNING: When servicing, use only iden-
tical replacement parts. Use of any other parts
may create a hazard or cause product damage,
lb ensure safety and reliability all repairs should
be performed by a qualied service technician.
WARNING: To prevent serious personal inju-
ry, remove the battery pack from the tool before
servicing, cleaning, changing add-on attach-
ments or removing material from the unit.
WARNING: For the user's safety; worn or
damaged parts must be replaced. Replace with
original replacement parts only.
CLEANING
Regular cleaning and maintenance of your snow
shovel will ensure eciency and prolong the life of
the product. After each use, clean out the ice and
debris from the auger and the scraper blade.
Snow shovel requires no additional lubrication. Wipe
clean with a soft cloth soaked with water and a soft
brush. Never wet or spray water on the machine. Do
not use detergents or solvents as these could cause
irreparable damage to the snow shovel. Chemicals
can destroy the plastic parts.
Clearing a Clogged Auger
Hand contact with the rotating auger inside the
motor housing is the most common cause of injury
associated with cordless snow shovels. Never use
your hands to clear a clogged auger.
To clear the auger:
● Shut the motor o and remove the battery.
● Wait 10 seconds to be sure the auger have come
to a complete stop.
● Always use a clean-out tool, not your hands, to
free the auger.
REPLACING THE SCRAPER
BLADE
WARNING: Make sure to turn o the machine
and remove the battery before performing any
maintenance task on your cordless snow shovel.
The scraper blade is a wear item and should be
replaced when necessary. A worn scraper blade can
cause extreme vibration and damage the auger.
NOTICE: To replace the scraper blade, you need
to prepare a Torx key set.
snow shovel must be in a stable position.
Hold the snow shovel rmly with two hands, make
sure the auger is not touching any surface. Depress
and hold the safety lock-o button on the handle
grip, and then squeeze the on/o switch and hold it.
Once the machine is switched on, you can release
the safety lock-o button.
(Fig. 11)
a. Place the snow shovel on the ground or on a work
bench. Turn the snow shovel over. Using a suitable
torx key (not supplied) to remove the 3 screws that
secure the scraper blade to the base of the unit.
(Fig.
12)
b. Remove the old scraper blade.
(Fig. 13)
c.Install the new scraper blade and fasten it securely
to the housing with the 3 screws.
(Fig. 14)
STORAGE
CORDLESS SNOW SHOVEL:
a. Examine the cordless snow shovel thoroughly
for worn, loose or damaged parts. Should you
need to repair or replace a part, contact Litheli
Customer Service for assistance.
b. Remove the battery from the cordless snow
shovel before storing.
c. Allow to dry thoroughly.
d. To protect the snow shovel from corrosion when
storing for long periods, lightly oil the metal parts.
e. Store the cordless snow shovel indoors in a
locked, dry, well-ventilated place out of the
reach of children to prevent unauthorized use or
damage.
BATTERY AND CHARGER:
a. Do not expose your battery pack or charger to
water, rain or allow them to get wet. This could
permanently damage the charger and the battery
pack. Do not use oil or solvents to clean or
lubricate your battery pack as the plastic casing
can become brittle and crack, causing a serious
risk of injury.
b. Store the battery pack and charger at room
temperature away from moisture. Do not store
in damp locations where corrosion of terminals
may occur; As with other battery pack types,
permanent capacity loss can result if the
pack is stored for long periods of time at high
temperatures (over 120°F/49°C).
TROUBLE SHOOTING
WARNING:
Switch o the machine and remove the battery packs prior to any troubleshooting.
SolutionPossible CauseProblem
Make sure the battery is fully inserted.Battery not installed well.
Charge the battery.Battery depleted.
Depress the lock-o button fully and then squeeze the
on/b switch.
Lock-o button not depressed.
Remove battery from snow shovel. Place battery on
charger and allow to charge for 10 minutes. Remove
from charger and install in snow shovel for use.
Battery too cold.
Contact the service center for replacing.Drive belt worn or damaged.
Contact the service center for replacing.Auger worn or damaged.
Switch o the snow shovel, remove the battery pack,
and clean the discharge.
Discharge blocked.
Contact the service center for replacing.Drive belt worn or damaged.
Contact the service center for replacing.Auger worn or damaged.
Replace the scraper blade.Scraper blade worn.
Contact the service center for replacing.Driver belt damaged.
Replace the scraper blade.Scraper blade worn.
Motor does not
start
Poor
performance
Abnormal
vibrations
The motor is on
but the auger
does not turn.
The snow shovel
leaves a thin
layer.
WARRANTY
LIMITED WARRANTY SERVICE
2-Year Tool, Battery and Charger Warranty
Against Defects in Materials, Parts or Workmanship.
All Units Must Be Used and Maintained in Accordance with The Directions and Reg-
ulations in The Operator’s Manual.
