EN
Quick Guide
1
SETTING MENU
1. Switch on the appliance by pressing the ON-OFF button.
2. Hold the Settings (Extra Dry ) button for 3 seconds, until you hear
abeep and the display shows „SEt”.
3. After one second the rst available setting (letter „ ”) will be displayed.
4. Press Auto programs /Extra options buttons to scroll through the list
of available settings (see table below), then press START/Pause to view
or change the value of currently selected setting.
5. Press Auto programs /Extra options buttons to change the value,
then press START/Pause to save the new value.
6. To change another setting, repeat points 2 and 5.
7. Press ON-OFF or wait 30 seconds to exit the menu.
LETTER
SETTING
VALUES
(Default - in bold)*
Cycle Counter - number of washing cycles
carried out by the dishwasher.
Eg. 25 cycles: 25;
Eg. 13.947 cycles:
13_947
(scrolling
for 3 times)
Water Hardness Level (see “SETTING THE WA-
TER HARDNESS” and “WATER HARDNESS TABLE”)
1 | 2 | 3 | 4 | 5
Rinse Aid Level
(see “ADJUSTING THE DOSAGE OF RINSE AID”)
0 | 1 | 2 | 3 | 4 | 5
ActiveDry (see “OPTIONS AND FUNCTIONS”)
“1” = On, “0” = O
1 | 0
Time on the oor (see “OPTIONS AND FUNCTIONS”)
“1” = On, “0” = O
1 | 0
Sound
“1” = On, “0” = O
1 | 0
Internal Lights (see “OPTIONS AND
FUNCTIONS”)
“1” = On, “0” = O
1 | 0
Factory Settings - press START/Pause to re-
store to the factory default all the values of the
settings included in the settings menu.
-
*) The default value does not apply to the Cycle Counter.
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on
the dishes and on the machine’s functional components.
The salt reservoir is located in the lower part of the dish-
washer (under the lower rack on the left side).
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
• Salt must be lled when the SALT REFILL indicator light on the control
panel is lit.
1. Remove the lower rack and unscrew the reservoir cap (anticlockwise).
2. Position the funnel (see gure) and ll the salt reservoir right up to its
edge (approximately 0,5 kg); it is not unusual for alittle water to leak out.
3. Only the rst time you do this: ll the salt reservoir with water.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly so that no detergent can get into
the container during the wash program (this could damage the water sof-
tener beyond repair).
Run aprogram every time as soon as you completed relling the salt
reservoir to avoid corrosion.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently pre-
venting scale buildup on the heater, contributing also to better cleaning ef-
ciency. This system regenerates itself with salt, therefore it is required
to rell the salt container when empty.
The frequency of regeneration depends on the water hardness level setting
- regeneration takes place once per 4-6 Eco cycles with the water hard-
ness level set to 3. During runs with regeneration, additional water man-
agement system ll will happen. The regeneration and water management
process occurs at the beginning of the cycle with additional fresh water.
• Single regeneration consumes ~7.5 L of water;
• Takes up to 15 additional minutes for the cycle;
• Consumes below 0.065kWh of energy.
A
B
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid dis-
penser Ashould be lled when the RINSE AID REFILL
indicator light in the control panel is lit.
1. Open the dispenser B by pressing and pulling up
the tab on the lid.
2. Pour in the rinse aid (max. 110 ml), making sure it
does not overow from the dispenser. If this hap-
pens, clean the spill immediately with adry cloth.
3. Press the lid down until you hear aclick to close it.
NEVER pour the rinse aid directly into the appli-
ance tub.
D
C
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening
device C. Introduce the detergent into the dry dis-
penser D only. Place the amount of detergent for
pre-washing directly inside the tub.
1. When measuring out the detergent refer to the men-
tioned earlier information to add the proper quantity.
Inside the dispenser D, there are indications to help the detergent dosing.
2. Remove detergent residues from the edges of the dispenser and close
the cover until it clicks.
3. Close the lid of the detergent dispenser by pulling it up until the closing
device is secured in place.
The detergent dispenser automatically opens up at the right time accord-
ing to the program.
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
CONTROL PANEL
FIRST TIME USE
More information in the Daily Reference Guide on website.
THANK YOU FOR BUYING AHOTPOINT PRODUCT.
In order to receive amore complete assistance, please
register your appliance on: www.hotpoint.eu/register
PLEASE SCAN THE
QR CODE ON YOUR
APPLIANCE IN
ORDER TO HAVE
MORE DETAILED
INFORMATION
Before using the appliance carefully read Safety and Installation Instructions.
After installation, please remember to remove all transport protection parts from
the dishwasher.
1
3
2
1. Delay Time on the oor - indicator of the time left
to the start of the cycle, when the Delay option is set
2. Salt reservoir empty - indicator light on the oor
3. Remaining Time on the oor - indicator of the time
left to the end of the cycle
DISPLAY ON THE FLOOR
1. ON-OFF/Reset button with indicator light
2. Eco program button with indicator light
3. Rapid program button with indicator light/ Soak program - 3 sec. press
4. Delicates program button with indicator light/ Self-Clean program
- 3 sec. press
5. Auto programs buttons with indicator lights - Auto Intensive 65°/
Auto Mixed 55°/ Auto Fast 50°
6. Salt reservoir empty indicator light
7. Rinse Aid reservoir empty indicator light
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
8. Display
9. Program number and remaining time indicator
10. Closed water tap indicator light
11. DESCALE indicator light
12. Extra options buttons with indicator lights - Half Load / Silent / Sani Rinse
13. 3D Zone Wash option button with indicator light
14. Extra Dry option button with indicator light / Settings - 3 sec. press
15. Delay option button with indicator light
16. START/Pause button with indicator light
EN
Quick Guide
2
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.
Note for Test Laboratories:
For information on comparative EN testing conditions, please send an email to the following address: dw_test_suppor[email protected]om
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration by up to 20 min.
EXTRA DRY - The higher temperature during the final rinse and the
extended drying phase allow improved drying. The EXTRA DRY option
results in the lengthening of the wash cycle.
DELAY - The start of the program may be delayed for a period of time
between 0:30 and 24 hours.
The DELAY function cannot be set once a program has been started.
WATER TAP CLOSED – Alarm - Flashes when there is no inlet water or
water tap is closed.
ActiveDry - It is aconvection drying system which automatically opens the
door during/after drying phase to ensure exceptional drying performance
every day. Door opens at the temperature that is safe to your kitchen fur-
niture, thus door will not be opened when the option of SANI RINSE is on.
As additional steam protection, special designed protection foil is added
together with the dishwasher.
INTERNAL LIGHTS - When the feature is active the LEDs in the tub are
automatically switched on/o as soon as the user open/close the door
respectively.
If the door remains opened for more than 10 min, the LEDs in the
tub switch o (to turn them on again, the door has to be closed and opened
again).
This feature is active by default, but it is possible to deactivate it in
the “SETTINGS MENU”.
SILENT - Suitable for night-time operation of the appliance. This option
can be used to limit noise emission during wash phases. It will increase
cycle time depending on base cycle selection.
SANI RINSE - This option can be used to sanitize washed dishes. It will
increase the nal rinse temperature and add antibacterial wash to the
selected program. Ideal to clean crockery and feeding bottles. The dishwasher
door must be kept shut for the entire duration of the program in order to
guarantee reduction of germs. WARNING: the crockery and plates could
be extremely hot at the end of the cycle.
SENSING - When the sensor is detecting the soil level an
animation appears in the display (around 20 min.) and the cycle
duration is updated. SENSING is for the level of soiling on the
dishes and is present for all cycles (excepting Eco) adjusting the program
accordingly. .
HALF LOAD - If there are not many dishes to be washed, HALF LOAD
is used to save water, electricity or time, depending on the selected
program. Remember to halve the amount of detergent.
OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator
lights up) (see CONTROL PANEL). If an option is not compatible with the selected program (see PROGRAMS TABLE), the corresponding LED ashes rap-
idly 3 times and beeps will sound. The option will not be enabled. An option can change time or water or energy consumption for the program.
PROGRAMS TABLE
OPTIONS AND FUNCTIONS
Please scan the QR code on your product in order to have more detailed information.
TIME ON THE FLOOR - A LED light projected on the oor indicates the
time left to the end of the cycle. The light goes o every time the door
is opened. The light goes o at the end of a cycle.This feature is active
by default, but it is possible to deactivate it in the “SETTINGS MENU”.
3D ZONE WASH - Thanks to the additional power jets this option
provides up to 80% more water power, a more intensive and powerful
wash in the lower rack, in the specic bottom area. This option is
recommended for washing pots and casseroles (please refer to the 3D loading
section).
Program
Programs description
Drying
phase
ActiveDry
Available
options
*)
Duration
of wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
Eco 50°- Program is suitable to clean normally soiled tableware,
that for this use, it is the most ecient program in terms of its
combined energy and water consumption, and that it is used to
assess compliance with the EU Ecodesign legislation.
5:45 9.5 0.50
Rapid 45° - Program is recommended for limited amount of
lightly-soiled dishes with no dried food residues. Does not
include the drying phase.
-
0:30 - 0:40 10.5 - 15.0 0.55 - 0.65
Delicates 45° - Program for delicate items, which are more
sensitive to high temperatures, for example glasses and cups.
1:40 - 1:50 12.5 - 17.0 0.95 - 1.20
Auto Intensive - 65°- Automatic pro-
gram for heavily soiled dishes and pans.
Senses the level
of soiling on the
dishes and adjusts
the program accor-
dingly. When the
sensor is detecting
the soil level an ani-
mation appears in
the display and the
cycle duration is up-
dated.
2:25 - 3:10 17.0 - 25.0 1.30 - 1.70
Auto Mixed - 55° Automatic program
for normally soiled dishes with dried
food residues.
1:20 - 3:20 7.5 - 20.5 0.75 - 1.20
Auto Fast - 50°- Automatic program
for normally and lightly soiled dishes.
The everyday cycle that ensures opti-
mal cleaning and drying performan-
ce in shorter time.
1:00 - 1:50 8.0 - 16.0 0.70 - 1.10
Soak - Use to refresh crockery planned to be washed later.
No detergent to be used with this program.
-
0:12 4.5 0.10
Self-Clean 65° - Program to be used to perform mainte-
nance of the dishwasher and water management system,
to be carried out only when the dishwasher is EMPTY using
specic detergents designed for dishwasher maintenance.
-
-
1:40 11.0 1.10
EN
Quick Guide
3
DESCALE – Alarm - Limescale accumulation was detected on the
internal components of the appliance. Check if the Water Hardness
Setting is at the correct value and salt is present in the salt container (see
FIRST TIME USE), then use a descaling product (WPro brand is recommended)
with Self-Clean program. After a successful descaling, the icon will stop
being displayed.
If the actions above are not performed, product performance will deteriorate.
DESCALE warning will start blinking and «dES» alarm will appear on the
display. If still no action is taken, the appliance will only allow a certain
number of cycles to be started (indicated during «dES» alarm display)
and then will be BLOCKED to prevent component damage, with only
the Self-Clean program available. Performing a full descaling will unblock
the product. In the case of extremely high amounts of limescale, descaling
may have to be performed twice to be ecient.
CARE AND MAINTENANCE
More information in the Daily Reference Guide on website.
LOADING THE RACKS
CAPACITY: 15 standard place-settings
CYCLE COUNTER - This feature shows the number of cycles the
dishwasher has performed.
For the number of cycles from 0-999, a xed number will be displayed.
Example for 25 cycles.
When the cycle number is higher than 1000, the number will scroll in
the display. The “_” represents the “
.
”, as for instance: 1.000 = 1_000,
13.947= 13_947 (the number will scroll for 3 times).
Example for
13.947 cycles:
After the cycle visualization, the display will return to visualize
„ ”
.
NOTE: The dishwasher may have already performed about 30 cycles.
This is due to the extended quality process carried out during
production. It guarantees higher product quality.
TOP RACK
The top rack pro-
vides a targeted
cleaning Wash Zone
for bowls, mugs,
even big plates and
cutlery that you’d
normally load in the
lower racks, making
extra space for the rest of the day’s dishes.
A separate arrangement of the cutlery makes
collection easier after washing and improves
washing and drying performance.
Knives and other utensils with sharp edges
must be positioned with the blades facing
downwards.
UPPER RACK
Load delicate and light dishes: glasses, cups,
saucers, low salad bowls.
The upper rack has tip-up supports which can
be used in a vertical position when arranging
tea/ dessert saucers or in a lower position to
load bowls and food containers.
(loading example for the upper rack)
ADJUSTING THE HEIGHT OF THE UPPER RACK
The height of the upper rack can be adjusted: ahigh po-
sition to place bulky crockery in the lower basket and
alow position to make the most of the tip-up supports
by creating more space upwards and avoiding collision
with the items loaded into the lower rack.
We strongly recommend that you do not adjust the
height of the rack when it is loaded. NEVER raise or
lower the basket on one side only.
FOLDABLE FLAPS WITH ADJUSTABLE POSITION
The side foldable aps can be folded or unfolded to opti-
mize the arrangement of crockery inside the rack. Wine
glasses can be placed safely in the foldable aps by insert-
ing the stem of each glass into the corresponding slots.
LOWER RACK
For pots, lids, plates, salad bowls, cutlery etc. Large
plates and lids should ideally be placed at the
sides to avoid interferences with the spray arm.
The lower rack has tip-up supports which can
be used in a vertical position when arranging
plates or in ahorizontal position (lower) to load
pans and salad bowls easily.
(loading example for the lower rack)
3D ZONE WASH
3D Zone Wash uses additional water jets located both:
in the lower and upper part of the dishwasher (marked
with orange color) to wash more intensively heavily soiled
items by increasing water coverage on dishes.
CUTLERY BASKET
It is tted with top grids for improved cutlery arrangement.
It must only be positioned at the front of the lower rack.
Knives and other utensils with sharp edges must be
placed in the cutlery basket with the points facing
downwards or they must be positioned horizontally
in the tip-up compartments on the upper rack.
CLEANING THE FILTER ASSEMBLY
A
A
B
C
1 2 3 4
The dishwasher must not be used without l-
ters or if the lter is loose.
It is important when reinstalling the lter that
the two triangles shown on the zoom meet (Fig 1).
In case you nd foreign objects (such as broken
glass, porcelain, bones, fruit seeds etc.) please re-
move them carefully.
Inspect the trap and remove any food residues.
NEVER REMOVE the wash-cycle pump protec-
tion (shown by an arrow) (Fig 4).
EN
Quick Guide
4
In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or is-
sues please contact authorized After-sales Service whose contact details can be found in the warranty booklet. Spare parts will be available
for aperiod of either up to 7 or up to 10 years, according to the specic Regulation requirements.
PROBLEMS POSSIBLE CAUSES SOLUTIONS
Descale
indicator is lit
or blinking;"dES"
alarm is displayed.
Limescale is accumulating on internal components
of the appliance.
Descale the appliance immediately using the Self Clean program and acommercially available
descaling product (see OPTIONS AND FUNCTIONS). Rell the reservoir with salt. Check the water
hardness setting. If the appliance is not descaled, it will stop functioning.
The dishwasher
won’t drain.
Display shows:
F7 E3 or F9 E1
The lter is clogged with food residues or
limescale
Clean the lter and descale the appliance (see CLEANING THE FILTER ASSEMBLY and DESCALE
INSTRUCTION).
The drain hose is kinked. Check the drain hose (see INSTALLATION INSTRUCTION).
The sink drain pipe is blocked. Clean the sink drain pipe.
The dishwasher
does not ll the
water. The display
shows: H
2
O and
is lit; acoustic alarm
sounds.
No water in the water supply or the tap is closed. Make sure there is water in the water supply and the water tap is open.
The water inlet hose is kinked.
Check the inlet hose (see INSTALLATION). Open dishwasher door, press START/Pause button and
close the door within 4 seconds.
The screen in the water inlet hose is clogged; it is
necessary to clean it.
Check and clean the screen in the water inlet hose. Open dishwasher door, press START/Pause
button and close the door within 4 seconds.
The dishwasher
nishes the cycle
prematurely.
The display shows:
F8 E3
The lter is clogged with food residues or
limescale.
Clean the lter and descale the appliance (see CLEANING THE FILTER ASSEMBLY and DESCALE
INSTRUCTION).
Drain hose positioned too low or siphoning into
the home sewage system.
Check if the end of the drain hose is placed at the correct height (see INSTALLATION). Check for
siphoning into the home sewage system, and install asiphon breaker/air admittance valve if
necessary.
An excessive amount of foam is present.
The detergent has not been measured out correctly or it is not suitable for use in dishwashers
(see FILLING THE DETERGENT DISPENSER).
Air in the water supply. Check water supply for leaks or other issues letting air inside.
The dishes are not
dried well.
Rinse aid is not present or the dosage is too low.
Make sure the rinse aid dispenser is lled (see FILLING THE RINSE AID DISPENSER). Multifunctional
tablets only will not provide as good drying eects as the actual use of liquid rinse aid.
The dishes have been unloaded after the door
was opened automatically but before the actual
cycle end.
Make sure the cycle has ended before starting to unload the dishes (see DAILY USE). For even
better drying results, it is recommended to let the dishes sit inside the dishwasher with the door
open for additional 15 minutes after the cycle ends.
The dishes are sitting too at.
If you notice puddles of water inside cavities of cups, mugs or bowls, try loading the dishes (es-
pecially in the upper rack) providing more inclination to let larger amounts of water drip down
before drying starts.
The selected cycle does not have the drying
phase.
Please check in the PROGRAMS TABLE if the selected program is equipped in the drying phase.
Acycle without the drying phase may not deliver desired drying eciency, so it is recommend-
ed to change cycle selection for the one that has the drying phase.
The dishes are made of non-stick or plastic. Some water drops remaining on this type of material are normal.
Dishes and glasses
are covered with
limescale or awhit-
ish lm.
The salt reservoir is empty.
Rell the reservoir with salt as soon as possible. Using the appliance without salt may cause
damage to its internal components.
The water hardness setting is too low.
Increase the setting (see WATER HARDNESS TABLE).
The cap of the salt reservoir is not properly closed.
Check and close the salt reservoir cap.
The rinse aid reservoir is empty or the rinse aid
dosage is insucient.
Rell the dispenser with rinse aid and check the dosage setting (for more information - see
FILLING THE RINSE AID DISPENSER).
The dishwasher
shows F8 E5
Valve is blocked or faulty. Close the water tap, if possible. Do not switch o the power supply. Call the service.
Detergent leaks.
Depends on the liquid detergent used and can be
emphasized in case of delay option is activated.
Small leaks will not cause machine malfunction and can be avoided by changing liquid deter-
gent type or using tablets.
TROUBLESHOOTING
Please scan the QR code on your product in order to have more detailed information.
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code on your product.
• Visiting our website docs.hotpoint.eu and parts-selfservice.europeanappliances.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet).
When contacting our After-sales Service, please state the codes provided on your product’s identication plate.
The model information can be retrieved using the QR-Code reported in the energy label.
The label also includes the model identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.
IEC 436
:
CLEANING THE SPRAY ARMS
On occasions, food residue
may become encrusted onto
the spray arms and block the
holes used to spray the water. It
is therefore recommended that
you check the arms from time
to time and clean them with
asmall non-metallic brush.
To remove the upper spray you
must remove it together with
the manifold.
The Top Rack has a xed wash tube with all the wash nozzles facing up-
ward. To clean it you can slide the rack out and with a tweezer remove items
that may be lodged in the nozzles.
The lower spray arm may be removed by
pulling it upwards and rotating it an-
ti-clockwise. Mounting back the spray
arm is by pulling it down and rotating it
clockwise.
The ceiling spray arm may be removed
by pressing it up and then rotating it
anti-clockwise. Mounting back the spray
arm is by pulling it upwards and rotating
it clockwise.
400020021494
02/2024 as - Xerox Fabriano
400020021494
02/2024 as - Xerox Fabriano
