EN
1
APPLIANCE
THANK YOU FOR BUYING A HOTPOINT PRODUCT.
In order to receive a more complete assistance, please
register your appliance on: www.hotpoint.eu/register
1. Upper rack
2. Cutlery tray
3. Foldable aps
4. Upper rack height adjuster
5. Upper spray arm
6. Lower rack
7. Lower spray arm
8. Filter Assembly
9. Salt reservoir
10. Detergent and Rinse Aid dispensers
11. Rating plate
12. Control panel
1. ON-OFF / Reset button with indicator light
2. Program selection button
3. Program indicator lights
4. START/Pause button with indicator light
DAILY REFERENCE
GUIDE
CONTROL PANEL
PRODUCT DESCRIPTION
1
3
4
5
6
7
9
8
2
0000 000 00000
Service:
1011
12
PLEASE SCAN THE
QR CODE ON YOUR
APPLIANCE IN
ORDER TO HAVE
MORE DETAILED
INFORMATION
Before using the appliance carefully read Safety and Installa-
tion Instructions.
After installation, please remember to remove all transport pro-
tection parts from the dishwasher.
3 4
1 2
2
FIRST TIME USE
SALT, RINSE AID AND DETERGENT
ADVICE REGARDING THE FIRST TIME USE
After installation, remove the stoppers from the racks and the retaining
elastic elements from the upper rack.
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes
and on the machine’s functional components.
• It is mandatory that THE SALT RESERVOIR NEVER BE EMPTY.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher (see
Product Description) and must be lled when the green oat on the cap
of the salt reservoir is no longer visible..
1. Remove the lower rack and unscrew the reser-
voir cap (anticlockwise).
2. Only the rst time you do this: ll the salt
reservoir with water.
3. Position the funnel (see gure) and ll the salt
reservoir right up to its edge (approximately
1 kg); it is not unusual for a little water to leak
out.
4. Remove the funnel and wipe any salt residue
away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get
into the container during the wash program (this could damage the wa-
ter softener beyond repair).
Whenever you need to add salt, it is mandatory to complete
the procedure before the beginning of the washing cycle to avoid
corrosion.
SETTING THE WATER HARDNESS
To allow the water softener to work in a perfect way, it is essential that
the water hardness setting is based on the actual water hardness in your
house. This information can be obtained from your local water supplier.
The factory sets the default value for the water hardness
• Switch on the appliance by pressing the ON/OFF button.
• Switch o the appliance by pressing the ON/OFF button.
• Hold down button P for 5 seconds, until you hear a beep.
• Switch on the appliance by pressing the ON/OFF button.
• The program indicator light of the current set level ashes.
• Press button P to select the desired hardness level (see WATER HARD-
NESS TABLE).
Water Hardness Table
Level
°dH
German
degrees
°fH
French degrees
°Clark
English degrees
1 Soft 0 - 6 0 - 10 0 - 7
2 Medium 7 - 11 11 - 20 8 - 14
3 Average 12 - 16 21 - 29 15 - 20
4 Hard 17 - 34 30 - 60 21 - 42
5
Very
hard
35 - 50 61 - 90 43 - 62
• Switch o the appliance by pressing the ON/OFF button.
Setting is complete!
As soon as this procedure is complete, run a program without loading.
Only use salt that has been specically designed for dishwashers.
After the salt has been poured into the machine, the SALT REFILL indi-
cator light switches o.
If the salt container is not lled, the water softener and the heating
element may be damaged as a result of limescale accumulation.
Using of Salt is recommended with any type of dishwasher detergent.
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid dispenser A should
be lled when when the dark optical indicator on the dispenser door C
becomes transparent.
A
B
C
1. Open the dispenser B by pressing and pulling up the tab on the lid.
2. Pour in the rinse aid (max.110 ml), making sure it does not overow
from the dispenser. If this happens, clean the spill immediately with
a dry cloth.
3. Press the lid down until you hear a click to close it.
NEVER pour the rinse aid directly into the appliance tub.
ADJUSTING THE DOSAGE OF RINSE AID
If you are not completely satised with the drying results, you can ad-
just the quantity of rinse aid used.
• Switch the dishwasher on using the ON/OFF button.
• Switch it o using the ON/OFF button.
• Press button P three times - a beep will be heard.
• Switch it on using the ON/OFF button.
• The program indicator light of the current set level ashes.
• Press button P to select the level of rinse aid quantity to be supplied.
• Switch it o using the ON/OFF button
Setting is complete!
If the rinse aid level is set to 1 (ECO), no rinse aid will be supplied.
A maximum of 5 levels can be set according to the dishwasher model.
The factory setting is specic to the model, please follow instruction
above to check this for your machine.
• If you see bluish streaks on the dishes, set a low number (2-3).
• If there are drops of water or limescale marks on the dishes, set a mid-
range number (4-5 ).
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening device D.
Introduce the detergent into the dry dispenser E only. Place
the amount of detergent for pre-washing directly inside the tub.
1. When measuring out the detergent
refer to the mentioned earlier in-
formation to add the proper quan-
tity. Inside the dispenser E there
are indications to help the deter-
gent dosing.
2. Remove detergent residues
from the edges of the dispenser
and close the cover until it clicks.
3. Close the lid of the detergent
dispenser by pulling it up un-
til the closing device is secured
in place.
The detergent dispenser automatically opens up at the right time ac-
cording to the program.
Usage of detergent not designed for dishwashers may cause mal-
function or damage to the appliance.
D
E
EN
3
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.
Note for Test Laboratories:
For information on comparative EN testing conditions, please send an email to the following address: [email protected]
Pre-treatment of the dishes is not needed before any of the programs.
*) Door is opened before the programm has been ended. This is to improve the drying eciency. Wait until the time has reached 00:00 to unload thedish-
washer
**) Values given for programmes other than the eco programme are indicative only. The actual time may vary depending on many factors such as tem-
perature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected
options and sensor calibration. The sensor calibration can increase program duration up to 20 min.
Program
Drying
phase
ActiveDry
*)
Duration
of wash
program
(h:min)
**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
1. Eco 50°
3:35 8.7 0.72
2. Intensive 65°
2:45 17.5 1.60
3. Mixed 55°
2:30 15.0 1.30
4. Rapid 40’
50°
-
0:40 9.0 0.70
5. Half Load 55°
1:20 11.0 1.00
PROGRAMS TABLE
PROGRAMS DESCRIPTION
Instructions on wash cycle selection.
1 ECO
Eco program is suitable to clean normally soiled tableware, that for this
use, it is the most ecient program in terms of its combined energy
and water consumption, and that it is used to assess compliance with
the EU Ecodesign legislation.
2 INTENSIVE
Program recommended for heavily soiled crockery, especially suitable
for pans and saucepans (not to be used for delicate items).
3 MIXED
Mixed soil. For normally soiled dishes with dried food residues.
4 RAPID 40’
Program to be used for half load of lightly-soiled dishes with no dried
food residues. Does not have drying phase.
5 HALF LOAD
Ideal for washing a half load of lightly or normally soiled crockery.
Notes:
Please note that cycle Rapid 40’ is dedicated for lightly soiled dishes.
OPTIONS AND FUNCTIONS
ActiveDry
ActiveDry is a convection drying system which automatically opens the door during/after drying phase to ensure exceptional drying performance
every day. Door opens at the temperature that is safe to your kitchen furniture.
As additional steam protection, special designed protection foil is added together with the dishwasher.
To see how to mount protection foil please refer to (INSTALLATION GUIDE).
4
LOADING THE RACKS
FOLDABLE FLAPS WITH ADJUSTABLE POSITION
The side foldable aps can be fold or unfold
to optimize the arrangement of crockery
inside the rack.
Wine glasses can be placed safely in the fold-
able aps by inserting the stem of each glass
into the corresponding slots.
In the case of the high position of the upper
rack, aps cannot remain in the vertical posi-
tion.
Depending on the model:
– to unfold the aps there is needed to slide
it up and rotate or release it from the snaps
and pull it down.
– to fold the aps there is needed to rotate it and slide aps down
or pull it up and attach aps to the snaps.
LOWER RACK
For pots, lids, plates, salad bowls, cutlery
etc. Large plates and lids should ideally be
placed at the sides to avoid interferences
with the spray arm.
(loading example for the lower rack)
CUTLERY RACK
The third rack was designed to house
the cutlery. Arrange the cutlery as
shown in the gure.
Aseparate arrangement of the cutlery
makes collection easier after washing
and improves washing and drying per-
formance.
Knives and other utensils with sharp
edges must be positioned with the
blades facing downwards.
UPPER RACK
Load delicate and light dishes: glasses, cups,
saucers, low salad bowls.
(loading example for the upper rack)
ADJUSTING THE HEIGHT OF THE UPPER RACK
The height of the upper basket can be
adjusted: high position to place bulky crock-
ery in the lower basket and low position
to make the most of the tip-up compart-
ments by creating more space upwards.
The upper rack is equipped with a Upper
Rack height adjuster (see gure), without
pressing the levers, lift it up by simply hold-
ing the rack sides, as soon as the rack is stable
in its upper position. To restore to the lower
position, press the levers (A) at the sides
of the rack and move the basket downwards.
We strongly recommend that you do not adjust the height of the rack
when it is loaded.
NEVER raise or lower the basket on one side only.
EN
5
DAILY USE
1. CHECK WATER CONNECTION
Check that the dishwasher is connected to the water supply and that
the tap is open.
2. SWITCH ON THE DISHWASHER
Open the door and press the ON/OFF button.
3. LOAD THE RACKS (see LOADING THE RACKS)
4. FILLING THE DETERGENT DISPENSER
5. CHOOSE THE PROGRAM AND CUSTOMISE THE CYCLE
Select the most appropriate program in accordance with the type
of crockery and its soiling level (see PROGRAMS DESCRIPTION) by
pressing the P button.
6. START
Start the wash cycle by pressing START/Pause button (led is lit)
and closing the door within 4 sec. When the program starts you
hear a single beep. If the door was not closed within 4sec., the alarm
sound will be played. In this case, open the door, press START/Pause
button and close the door again within 4 sec.
7. END OF WASH CYCLE
Skalbimo ciklo pabaiga rodoma pyptelėjimu ir mirksi pasirinktos
programos indikatoriaus lemputė.
Open the door and switch o
the appliance by pressing the ON/OFF button.
Wait for a few minutes before removing the crockery - to avoid
burns. Unload the racks, beginning with the lower one.
The machine will switch o automatically during certain extended
periods of inactivity, in order to minimise electricity consumption.
If the crockery is only lightly soiled or if it has been rinsed with
water before being placed in the dishwasher, reduce the amount
of detergent used accordingly.
MODIFYING A RUNNING PROGRAM
If a wrong program was selected, it is possible to change it, provided
that it has only just begun: open the door, press and hold the ON/OFF
button, the machine will switch o.
Switch the machine back on using the ON/OFF button and select
the new wash cycle and any desired options; Start the wash cycle by
pressing START/Pause button and closing the door within 4 sec.
ADDING EXTRA CROCKERY
Without switching o the machine, open the door (START/Pause led
starts blinking) (be ware of HOT steam!) and place the crockery inside
the dishwasher. Press the START/Pause button and close the door with-
in 4 sec., the cycle will resume from the point at which it was interrupted.
ACCIDENTAL INTERRUPTIONS
If the door is opened during the wash cycle, or if there is a power cut,
the cycle stops. Press the START/Pause button and close the door with-
in 4 sec., the cycle will resume from the point at which it was interrupted.
ADVICE AND TIPS
TIPS
Before loading the baskets, remove all food residues from the crockery
and empty the glasses. You do not need to rinse beforehand under run-
ning water.
Arrange the crockery so that it is held in place rmly and does not tip
over; and arrange the containers with the openings facing downwards
and the concave/convex parts placed obliquely, thus allowing the wa-
ter to reach every surface and ow freely.
Warning: lids, handles, trays and frying pans do not prevent the spray-
er arms from rotating.
Place any small items in the cutlery basket.
Very soiled dishes and pans should be placed in the lower basket be-
cause in this sector the water sprays are stronger and allow ahigher
washing performance.
After loading the appliance, make sure that the sprayer arms can
rotate freely.
UNSUITABLE CROCKERY
• Wooden crockery and cutlery.
• Delicate decorated glasses, artistic handicraft and antique crockery.
Their decorations are not resistant.
• Parts in synthetic material which do not withstand high tempera-
tures.
• Copper and tin crockery.
• Crockery soiled with ash, wax, lubricating grease or ink.
The colours of glass decorations and aluminium/silver pieces can
change and fade during the washing process. Some types of glass (e.g.
crystal objects) can become opaque after anumber of wash cycles too.
DAMAGE TO GLASS AND CROCKERY
• Only use glasses and porcelain guaranteed by the manufacturer as
dishwasher safe.
• Use adelicate detergent suitable for crockery
• Collect glasses and cutlery from the dishwasher as soon as the wash
cycle is over.
TIPS ON ENERGY SAVING
• When the household dishwasher is used according to the manufac-
turer’s instructions, washing tableware in adishwasher usually con-
sumes less energy and water than hand dishwashing.
• In order to maximize dishwasher eciency it is recommended to initiate
the wash cycle once dishwasher is fully loaded. Loading the house-
hold dishwasher up to the capacity indicated by the manufacturer will
contribute to energy and water savings. Information on correct load-
ing of tableware can be found in LOADING THE RACKS chapter.
• In case of partial loading it is recommended to use dedicated wash
options if available (Half load/ Zone Wash, Multizone), illing up only
selected racks. Incorrect loading or overloading the dishwasher may
increase resources usage (such as water, energy and time, as well as
increase noise level), reducing cleaning and drying performance.
• Manual pre-rinsing of tableware items leads to increased water and
energy consumption and is not recommended.
HYGIENE
To avoid odour and sediment which can be accumulated in the
dishwasher please run a high temperature program at least one
amonth. Use atea spoon of detergent and run it without the loading
to clean your appliance.
6
CARE AND MAINTENANCE
CLEANING THE FILTER ASSEMBLY
Regularly clean the lter assembly so that the lters do not clog and
that the waste water ows away correctly.
Using dishwasher with clogged lters or foreign objects inside ltration
system or sprayarms may cause unit malfunction resulting in lose of
performance, noisy work or higher resources usage.
The lter assembly consists of three lters which remove food residues
from the washing water and then recirculate the water.
The dishwasher must not be used without lters or if the lter is
loose.
At least once per month or after each 30 cycles, check the lter assem-
bly and if necessary clean it thoroughly under running water, using
anon-metallic brush and following the instructions below:
1. Turn the cylindrical lter Ain an anti-clockwise direction and pull it
out (Fig 1).
2. Remove the cup lter B by exerting a slight pressure on the side
aps (Fig 2).
3. Slide out the stainless-steel plate lter C (Fig 3).
4. In case you nd foreign objects (such as broken glass, porcelain,
bones, fruit seeds etc.) please remove them carefully.
5. Inspect the trap and remove any food residues. NEVER REMOVE the
wash-cycle pump protection (black detail) (Fig 4).
A
A
B
C
1
3
2
4
After cleaning the lters, re-place the lter assembly and x it in posi-
tion correctly; this is essential for maintaining the ecient operation
ofthe dishwasher.
CLEANING THE WATER INLET HOSE
If the water hoses are new or have not been used for an extended period
of time, let the water run to make sure it is clear and free of impurities be-
fore performing the necessary connections. If this precaution is not tak-
en, the water inlet could become blocked and damage thedishwasher.
CLEANING THE SPRAY ARMS
On occasions, food residue may become encrusted onto the spray arms
and block the holes used to spray the water. It is therefore recommend-
ed that you check the arms from time to time and clean them with
asmall non-metallic brush.
To remove the upper spray arm, turn the plastic locking ring in aclock-
wise direction. The upper spray arm should be replaced so that the side
with the greater number of holes is facing upwards.
The lower spray arm may be removed by pulling it upwards.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently
preventing scale buildup on heater, contributing also to better cleaning
eciency.
This system regenerates itself with salt, therefore it is required to
rell salt container when empty.
Frequency of regeneration depends on water hardness level setting
- regeneration takes place once per 6 Eco cycles with water hardness
level set to 3.
Regeneration process starts in nal rinse and nishes in drying phase,
before cycle ends.
• Single regeneration consumes: ~3.5L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
EN
7
TROUBLESHOOTING
PROBLEMS POSSIBLE CAUSES SOLUTIONS
The dishwasher
won’t start
or does not
respond
to commands.
The appliance has not been plugged
in properly.
Insert the plug into the socket.
Power outage.
For safety reasons, dishwasher will not re-start automatically when power returns.
Open dishwasher door, press START/Pause button and close the door within
4 seconds.
The dishwasher door is not closed.
ActiveDry pin is not pulled in.
Vigorously push the door until you hear the “click”.
Cycle is interupted by door opening
for more than 4 seconds.
Press START/Pause and close the door within 4 seconds.
It does not respond to commands.
Switch o the appliance by pressing the ON/OFF button, switch it back on after
approximately one minute and restart the program. If problem persists,
unplug the appliance for 1 minute, then plug it back in.
The dishwasher
won’t drain.
The wash cycle has not nished yet. Wait until the wash cycle nishes.
The drain hose is bent. Check that the drain hose is not bent (see INSTALATION INSTRUCTION).
The sink drain pipe is blocked. Clean the sink drain pipe.
The lter is clogged up with food residues. Clean the lter (see CLEANING THE FILTER ASSEMBLY).
The dishwasher
makes
excessive noise.
The dishes are rattling against each other. Position the crockery correctly (see LOADING THE RACKS).
An excessive amount of foam has been
produced.
The detergent has not been measured out correctly or it is not suitable for use
in dishwashers (see FILLING THE DETERGENT DISPENSER). Restart the current
cycle by switching OFF the dishwasher, then switch it on again, select a new
program, press START/Pause and close the door within 4 seconds. Please do
not add any detergent.
The dishes are
not clean.
The crockery has not been arranged
properly.
Arrange the crockery correctly (see LOADING THE RACKS).
The spray arms cannot rotate freely, being
hindered by the dishes.
Arrange the crockery correctly (see LOADING THE RACKS).
The wash cycle is too gentle. Select an appropriate wash cycle (see PROGRAMS TABLE).
An excessive amount of foam has been
produced.
The detergent has not been measured out correctly or it is not suitable for use
in dishwashers (see FILLING THE DETERGENT DISPENSER).
The cap on the rinse aid compartment has
not been shut correctly.
Make sure the cap of the rinse aid dispenser is closed.
The lter is soiled or clogged. Clean the lter assembly (see CARE AND MAINTENANCE).
There is no salt. Fill the salt reservoir (see FILLING THE SALT RESERVOIR).
The dishwasher
does not ll
the water.
All LEDs are
blinking rapidly
No water in the water supply or the tap is
closed.
Make sure there is water in the water supply or the tap running.
The inlet hose is bent.
Make sure the inlet hose is not bent (see INSTALLATION) reprogram
the dishwasher and reboot.
The sieve in the water inlet hose is clogged;
it is necessary to clean it
After having carried out the verication and cleaning, turn o and turn on
the dishwasher and restart a new program.
Dishwasher
nishes the cycle
prematurely.
Drain hose positioned too low or siphoning
into home sewage system.
Check if end of drain hose is placed at correct height (see INSTALLATION).
Check for siphoning into home sewage system, install air admittance valve
if necessary.
Air in water supply. Check water supply for leaks or other issues letting air inside.
Detergent leaks.
Depends on the liquid detergent used and
can be emphasized in case of delay option
is activated.
Small leaks will not cause machine malfunction and can be avoided by
changing liquid detergent type or using tablets.
In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other er-
rors or issues please contact authorized After-sales Service whose contact details can be found in the warranty booklet. Spare parts
will be available for aperiod of either up to 7 or up to 10 years, according to the specic Regulation requirements.
Policies, standard documentation, ordering of spare parts and additional product information can be
found by:
• Using QR code on your product.
• Visiting our website docs.hotpoint.eu and parts-selfservice.europeanappliances.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contact-
ing our After-sales Service, please state the codes provided on your product’s identication plate.
The model information can be retrieved using the QR-Code reported in the energy label.
The label also includes the model identier that can be used to consult the portal of the registry
at https://eprel.ec.europa.eu.
IEC 436
:
8
400020012617B
06/2025 dp - Xerox Fabriano
