What's in the box
AC Charging Cable
Anker SOLIX F3800 Plus
Portable Power Station
User Manual &
Warranty Card
Solar Charging Cable
(x2)
Overview
3
1
11
15
19
17
18
12
2
5
4
10
8
14
9
16
20
7
6
13
21
Retractable Handle (To extend, press the
handle button, then pull)
Display Button
On/O Button USB Ports
IoT Button Car Socket
Car Socket Button NEMA TT-30R AC Output Port
NEMA L14-30R AC Output Port AC Outlet Button
NEMA 5-20R AC Output Port (Le 3 Ports
Have UPS)
Overcharge Protection (AC
Output)
AC Input Port Home Power Panel Port
Overcharge Protection (AC Input) Dual Solar Input
Expansion Battery Port Anker SOLIX Smart Generator Port
Wheel Brake Bottom Handle
Wheels
What's in the box
Overview
LCD Screen Guide
Recharging Your Power
Station
Powering On / O
Powering Your Devices
Uninterruptible Power
Supply (UPS)
Connect With an
Expansion Battery
Connect with Anker SOLIX
Home Power Panel
Connect Two Anker SOLIX
F3800 Plus Power Stations
Anker App for Smart
Control
Light
Carry Your Power Station
FAQ
Specifications
LCD Screen Guide
4
5
1
16
15
2 3
6789
10
11
12
13
14
Remaining Battery for Power Station and Expansion Battery
Overload Warning
This icon appears when a port is overloaded. The port will turn o to avoid any
damage. Please remove the device causing overload.
Current Output Power
Current Input Power
Whole-Home Power Mode
USB-A Output Port
USB-C Output Port
Car Socket Charging
IoT
Press the IoT button once to turn on Bluetooth and Wi-Fi, and connect your devices
through the app when this icon appears on the screen.
Press the IoT button for 2 seconds to turn o Bluetooth and Wi-Fi.
Press the IoT button for 7 seconds to reset Bluetooth and Wi-Fi.
AC Charge and Voltage Frequency
Electrical Vehicle Charging
Number of Expansion Battery Connected
When the expansion battery is connected successfully, this icon appears on the
screen.
Estimated Time to Fully Recharge
Estimated Time for Battery to Deplete
Low-Temperature Alert
When this icon shows, stop using the power station until the icon disappears.
High-Temperature Alert
When this icon shows, stop using the power station and let it cool down until the
icon disappears.
Recharging Your Power Station
When your portable power station only has 1% battery remaining, the "Remaining
Battery" indicator will flicker to remind you to recharge.
The maximum charging power of the power station under dierent temperatures:
Cell Temperature
AC Input Maximum Power AC and Solar Input Maximum Power
0~10°C
760W 760W
10~15°C
1800W 2000W
15~50°C
1800W 3300W
AC Recharging (1800W Max)
Recharge your power station by connecting to a wall outlet with the AC charging
cable.
240V Generator Recharging
You can purchase Anker SOLIX Generator Input Adapter to connect Anker SOLIX F3800
Plus via the Home Power Panel port. Aer connecting the 240V Generator, one Anker
SOLIX F3800 Plus recharges at a maximum power of 3300W; if Anker SOLIX F3800 Plus is
connected to Expansion Batteries, recharging power can be up to 6000W.
When Anker SOLIX Generator Input Adapter is connected to Anker SOLIX F3800 Plus
Portable Power Station, the NEMA 5-20R AC output ports on the power station will
be disabled. You can still use the L14-30R or TT-30R ports.
Solar Panel Recharging (3200W Max)
1. Recharge your power station with a maximum solar input of 3200W.
2. Wiring Instructions:
Series Wiring
The solar input voltage range for Anker SOLIX F3800 Plus is 11-165V. Ensure the total
solar voltage is within this range. Voltage exceeding 165V will damage the product.
Parallel Wiring
• The solar input current for Anker SOLIX F3800 Plus is 17A. Please ensure the total
solar current is near 17A. If it exceeds 17A, the output power of the solar panel
cannot be fully utilized.
• To connect solar panels in parallel, purchase the Solar Parallel Connection
Connector from the Anker oicial website. Follow the diagram and connect the
panels as indicated by the dotted line.
• Solar panel extension cables (10 / 3m) are included in packages for Anker
SOLIX portable solar panels.
Powering On / O
3s
Press the On/O button for 3 seconds to turn your power station on or o.
When the "Remaining Battery" indicator shows on the LCD screen, your power station
is ready to charge devices.
• When powered on, press the DISPLAY button to turn the screen on or o.
• The auto-o time can be set in the Anker app.
• The power station will power o automatically if the output buttons are turned
o and no power loads are detected for 12 hours. The standby duration can be
set in the Anker app.
Powering Your Devices
AC Charging
• 120V AC Port
Press the AC outlet button and connect your devices to the 5-20R output ports.
• If no AC plug insertion is detected, the AC outlet button will automatically turn
o aer 15 minutes by default (the auto-o time can be set in Anker app) to save
power.
• AC charging power can be set in Anker app.
On / O
x1
Press the AC outlet button and connect your devices to the TT-30R AC output ports.
The max output power via this port is 3000W.
• 240V AC Port
• To ensure safe power supply with the 240V AC ports, the neutral (N) and ground
(PE) wires of the inlet box or transfer switch must be properly connected. Missing
neutral (N) and ground (PE) wires may cause appliances damaged on the circuit.
• The LRA (Locked Rotor Amps) of Anker SOLIX F3800 Plus is 80A. You will need a so
starter if your air conditioner requires higher LRA to start.
1. Press the AC outlet button and connect the power station to your inlet box or transfer
switch via the L14-30R AC output port. The max output power via this port is 6000W.
To ensure safe power supply to your inlet box or transfer switch via the 240V AC
ports, check and confirm that the neutral and ground wires of the inlet box or
transfer switch are properly connected.
x1
2. Double-press the AC outlet button to turn on EV mode, wait until the car icon
appears on screen, then connect your device to the L14-30R AC output port. When the
power station is in EV Charging mode, it cannot be charged via AC simultaneously.
x2
USB Charging
Connect your devices to the USB ports.
If the output current of the USB port remains below 60mA continuously for two
hours, the USB charging will automatically stop to save power.
Car Socket Charging
Turn on the car socket and connect your devices to start charging.
On / O
Uninterruptible Power Supply (UPS)
To use the UPS feature, connect your power station to a wall outlet with the AC
charging cable, then press the AC outlet button and connect your devices via the UPS
AC output ports.
On
Connect With an Expansion Battery
You can purchase Anker SOLIX BP3800 Expansion Batteries and connect them with your
power station to increase the capacity up to 26880Wh. Please refer to the user manual
of Anker SOLIX BP3800 Expansion Battery for detailed instructions.
Connect with Anker SOLIX Home Power Panel
You can purchase Anker SOLIX Home Power Panel to enhance your home backup and
power utility. Please refer to the user manual of Anker SOLIX Home Power Panel for
detailed instructions.
Connect Two Anker SOLIX F3800 Plus Power Stations
You can purchase Anker SOLIX Double Power Hub to connect two Anker SOLIX F3800
Plus Stations via the Home Power Panel ports to double power output. Anker SOLIX
Double Power Hub can output a maxtimum power of 12000W. Please refer to the user
manual of Anker SOLIX Double Power Hub for detailed instructions.
Anker App for Smart Control
You can remotely control your power station using the Anker app.
1. Download the Anker app from the App Store (iOS devices) or Google Play (Android
devices), or by scanning the QR code.
2. Connect the device to a network before using the app for the first time. Aer
connecting successfully, you can connect your device o-grid.
3. Firmware update: You will be informed once a new firmware version is detected
when you connect the power station to the app. During the update, ensure the power
station is being charged and connected to Wi-Fi.
Light
Turn on/o the light on Anker App.
Carry Your Power Station
1. Lay the power station flat.
2. Open the bottom folding handle.
3. Grab the bottom and top handles to li the power station.
FAQ
Q1: What is the maximum power output of the AC output ports?
The AC output ports can deliver a maximum of 6000W to connected devices. Each
group of NEMA 5-20R AC output ports can deliver 2400W (120V/20A) of power.
Q2: What should I do when using a solar charger to charge my power station?
Anker SOLIX F3800 Plus Portable Power Station has 2 solar input ports. Each solar input
port supports an 11-165V solar charger with a solar charging connector, the current
supports 17A max.
Q3: Can the USB-C ports charge the power station (input only), or are they output only?
The USB-C ports support output only.
Q4: What should I do when AC recharging fails?
If AC recharging does not work, check if the overload protection switch is turned on. If
it is on, press down to reset and then continue recharging.
Q5: How do I reset my power station?
If your power station is not working correctly, insert a paper clip or pin into the reset
hole for 1 second for a factory reset. If the power station still doesn't work, please
contact support@anker.com.
Q6: Why is the power station not working aer it hasn't been used for a long time?
If the power station is stored at a low capacity for a long time, LiFePO4 batteries will
self-consume power which may lead to a quick discharge. This oen leads to poor
conductivity and a reduced battery lifespan that causes the battery not to work.
Q7: How should I store and maintain the power station?
When storing your power station, please make sure that you:
1) Turn o the main power button.
2) Store the power station in a dry and cool environment.
3) Check the remaining battery capacity each week. If the battery level is below 30%,
fully charge the power station. In addition, charge the battery to 100% every 3 months.
Q8: How do I charge my electric vehicle via the power station?
Double-press the AC outlet button to activate EV mode charging. Make sure to set the
charging rate of the EV charger to less than 25A to avoid overloading the output to
your electric vehicle, such as a Tesla.
Q9: When recharging Anker SOLIX F3800 Plus Portable Power Station with a 120V AC
input, can I use its 240V outlet to charge other devices?
No, when Anker SOLIX F3800 Plus is recharging via the 120V AC input, you can only use
its three 120V UPS outlets to charge other devices.
Q10: When recharging Anker SOLIX F3800 Plus Portable Power Station with a 240V
generator, can I use its 120V outlet to charge other devices?
Yes. When Anker SOLIX F3800 Plus is recharging via a 240V generator, you can use NEMA
L14-30R and TT-30R ports to charge other devices.
Specifications
Battery Type LiFePO4 Cell
Cell Part Number 32140FS-15000mAh
Cell Number 80
Cell Capacity 51.2Vdc 75Ah/3840Wh
AC Input
120V~ 15A Max (< 3hrs) / 12A Max (continuous), 60Hz,
L+N+PE
AC Input Power (Charging) 1800W Max
AC Input Power (Bypass Mode) 1440W Max
Solar Panel Input 1 11-165V
17A Max (1600W Max Each)
Solar Panel Input 2 11-165V
17A Max (1600W Max Each)
DC Input Port 60V Max, 120A Max
Car Charger Output 12V 10A
Home Power Panel Port
6000W Max (AC Input), 6000W Max (AC Output),
120V/240V, L1+L2+N+PE
AC Output Power (Total) 6000W Max
AC Output 1 (the 3 le ports of
NEMA 5-20R)
120V~ 20A Max, 60Hz, 2400W Max
AC Output 2 (the 3 right ports
of NEMA 5-20R)
120V~ 20A Max, 60Hz, 2400W Max
AC Output (NEMA TT-30) 120V~ 25A Max, 60Hz, 3000W Max
AC Output (NEMA L14-30R) 120V/240V~ 25A Max, 60Hz, 6000W Max
USB-A Output 5V
2.4A (12W Max Per Port)
USB-C Output
5V
3A / 9V 3A / 15V 3A / 20V 3A / 20V 5A (100W
Max Per Port)
UPS 20ms
Discharging Temperature
-4°F-104°F / -20°C-40°C
Charging Temperature
32°F-104°F / 0°C-40°C
Size
27.6×15.3×15.6 in / 70.2×38.8×39.5 cm
Net Weight
61.5 kg / 135.6 lb
