PNPR45W
GE Profile
™
Professional Smart Valve Water Softener 45,000 Grain Capacity
DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)
PLUMBING CODES: All plumbing must be completed in accordance with national, state and local
plumbing codes. In the state of Massachusetts, The Commonwealth of Massachusetts plumbing
code 248-CMR shall be adhered to. A licensed plumber shall be used for this installation.
INSTALLATION INFORMATION: For complete information, see installation instruction packaged
with the water softener.
POWER REQUIREMENTS: The water softener uses a direct plug-in external supply (included).
Be sure to use the included power supply and plug it into a nominal 120V, 60-cycle household
outlet that is in a dry location only, grounded and properly protected by an over current device
such as a circuit breaker or fuse.
LOCATION: Install the water softener close to the water supply inlet, and upstream of all other
plumbing connections, except outside water pipes. A nearby drain is needed to carry away
regeneration discharge (drain) water. Use a oor drain, laundry tub, sump, standpipe or other
options (check your local codes). Do not locate the water softener where freezing temperatures
occur. Do not attempt to treat water over 120°F. Freezing temperatures or hot water damage
voids the warranty.
17.5” (444.5mm)
27.56” (700mm)
37” (940mm)
17.5” (444.5mm)
11.69”
(296.96mm)
5.79”
(141.17mm)
17.49” (444.13mm)
10.81”
(274.56mm)
Above illustration intended for dimensional reference only.
Refer to photograph for actual product appearance.
Well Pump
Well W
ater Supply
City Water Supply
OR
Pressure
Tank
Optional
Sediment Filter
Water
Heater
Water
Softener
Brine
Tank
Hot Water to House
Cold
Water to House
Untreated Water to
Outside Faucets
Shuto
valve
Specification Revised 4/25
For answers to your Monogram, Café™, GE Profile™ or GE Appliances product questions,
visit our website at geappliances.com or call GE Answer Center® Service, 800.626.2000.
49.25” (1250.95mm)
46.6” (1183.7mm)
4.33”
(110.1mm)
10.4” (262.2mm)
PNPR45W
GE Profile
™
Professional Smart Valve Water Softener 45,000 Grain Capacity
FEATURES AND BENEFITS
Large Grain Capacity – This high capacity Professional water softener can easily remove 45,000 grains. Professional
Smart Valve water softeners can accommodate a household family size of up to 6 persons or more
WiFi-Enabled Leak Detection Powered by SmartHQ™ – This WiFi-enabled Professional Smart Valve water softener allows
y
ou to address potential leaks by remotely shutting off water to your entire house, from anywhere, using your smartphone
Remote Water Shutoff Valve – Enjoy complete peace of mind with an included water shutoff valve to remotely shut
water off to your entire house
Water Flow Monitoring Powered by SmartHQ™ – View daily or weekly water softener usage and receive alerts on your
smartphone when there is a continuous water flow or a potential leak is detected
Heavy Duty Design – This heavy duty Professional Smart Valve water softener is designed with 1" NPT metal plumbing
connections for robust installation and extra protection with dual 0-ring seals. Included 1" water softener connectors
can conveniently accommodate both 3/4" and 1 1/4" plumbing
Bypass Blending Valve Control – A custom water bypass blending valve allows you to conveniently control your
preferred water softness level or set as complete bypass
WiFi-Enabled Low Salt Reminder Powered by SmartHQ™ – Receive an instant notification on your smartphone when
your water softener salt level is low
WiFi-Enabled Vacation Mode Powered by SmartHQ™ – Receive an instant notification on your smartphone when water
flow is detected at any flow rate when set on vacation mode
LED Digital Control Panel – This Professional Smart Valve water softener allows you to choose what is displayed on
your LED Digital Control Panel. Settings include Clock Adjustment options, Salt Level, Hardness Level and Salt Saver mode
Salt Days to Empty Indicator – Manage your Professional Smart Valve water softener salt usage with a visual
countdown of days until empty clearly displayed on the control panel
Outdoor Rated with Optional Protective Cover – Enjoy the flexibility to install your Professional Smart Valve water
softener outside or inside thanks to a durable design and optional protective cover accessory*
(*ODCOVSFT protective cover sold separately)
Salt Tank Cleanability – Easily clean out your Professional Smart Valve water softener with a separate salt tank
that is simple to rinse clean
Salt Capacity – 325 lbs.
