4
5
OPEN
Biometric Fingerprint Safe
User Manual V3.0
Pull out the metal piece to secure the shelf board;
push the metal piece back to the vertical position
to remove the shelf board.
Slide the keyhole cover to the left as shown. Insert the backup key into the
keyhole and turn it 90°counterclockwise. Then, rotate the knob clockwise to
open the door.
Note: This method is intended for setting up the user fingerprint and passcode
when opening the safe for the first time or if the fingerprint and passcode fail
to unlock the safe. In such cases, you can use the backup key to open the
safe. Please ensure that the backup key is stored in a safe place and never
keep it inside the safe.
Place your programmed finger on the fingerprint sensor. The fingerprint sensor
will light up green, and the indicator will light up blue and emit a short beep.
Then, rotate the knob clockwise to open the door.
Touch the numeric keypad and it will light up blue. Then, enter your programmed
passcode and end with the "#" key. The indicator will light up blue with a short
beep. After that, rotate the knob clockwise to open the door.
IMPORTANT
1. Please do not lock the backup keys and backup battery box inside the safe.
2. Test your fingerprint and passcode several times before storing valuables inside.
3. If you experience any problems or challenges with your safe, please contact us at
[email protected]. Many issues can be resolved quickly without the product being returned.
If the batteries are depleted, plug the backup power supply into the USB-C port
on the side of the lock panel. Then, repeat step 2 or 3 to open the safe.
NOTE: Supports both backup battery box and USB-C phone charging cable for
eemergency power supply.
Have any issues? Please contact us: dayi_service@outlook.com
Model: DF-60Pro
4 Ways to Unlock Your Safe
1. Backup Key
2. Fingerprint
3. Passcode
4. Backup Power Supply
1. Unauthorized Entry Alarm
After 3 invalid passcode or fingerprint attempts, a loud alarm will be triggered for 20 seconds.
2. Vibration Alarm
Press the “*”key to activate the vibration alarm mode, all indicators will light up with a short beep
indicate activation. If the safe is shaken or hit violently, a loud alarm will be triggered.
NOTE: To stop the alarm, enter your programmed passcode or scan your programmed fingerprint.
NOTE: The vibration alarm mode is off by default. Press the "*" key each time to activate it.
Dual Alarm System
Mute Mode
1. Mute Mode : Press the "1" key on the numeric keypad for 3 seconds. The green indicator willON
light up, indicating that mute mode is activated.
2. Mute Mode : Press the "1" key on the numeric keypad for 3 seconds. The green indicator willOFF
light up, indicating that mute mode is deactivated.
Low Battery Notification
If the buzzer sounds while opening the door, it indicates low battery power.
Please replace the batteries as soon as possible.
How To Install Foot Pads?
1. Remove the stickers
from the foot pads.
2. Attach the foot pads to
the bottom of the safe.
How To Bolt Your Safe To The Wall?
1. Place the safe in the desired location and open the door.
2. Use a screw or pencil to mark spots through the 4 holes of the safe.
3. Move the safe aside and drill into the wall at the marked spots.
4. Replace the safe in the desired position, then insert the expansion bolts
into each hole.
5. Secure the safe to the wall.
Rotate Knob
Emergency Power Supply
(Type-C)
Confirm button(#)
Emergency keyhole cover
(Slide to the left)
The delete key
(*)
1
2
Fingerprint Scanner
Have any issues? Please contact us: dayi_service@outlook.com
OPEN
Instruction Manual
Please do not lock the emergency key and emergency battery box into the cabinet.
PRODUCT DETAILS
PACKING
User Manual x 1
Backup Keys x 2
Backup Battery Box x 1
Foot Pads x 4
Expansion Screws x 4
Preparing Your Safe for First-Time Use
1. Slide the keyhole cover to the left as shown.
Insert the backupkey into the keyhole and turn it
90°counterclockwise. Then, rotate the knob clockwise
to open the door.
1
2
3
4
5
2. Open the battery case cover and insert 4 AA alkaline batteries as shown.
* DO NOT use rechargeable batteries or any other type of non-alkaline battery.
* DO NOT mix old and new batteries.
* DO NOT mix alkaline and standard batteries.
Setting The User Fingerprint
1. Open the door and press The fingerprint sensor will light up with the red setting button.
a breathing light, and emit a short beep, indicating that the safe is now in fingerprint
setup mode.
2. Place your programmed finger on the fingerprint sensor. A short beep indicates a
valid scan. Repeat this process 5 times until the indicator lights up blue and emits
a long beep, indicating that fingerprint enrollment is complete.
3. Repeat steps 1-2 to add additional user fingerprints.
NOTE:
- The safe can store up to 25 fingerprints.
- Any fingerprint can access the safe for the first time.
- Place your finger flat and fully cover the scanner.
- Adjust your finger's position and angle to ensure all parts of the fingerprint are captured.
- Do not use a finger that has a cut or scar.
- Ensure your hands are clean and dry before programming or operating the fingerprint
scanner.
- For optimal performance, clean the fingerprint sensor periodically with a dry, lint-free cloth.
- The fingerprint sensor may not work well in cold conditions.
Red setting button
1. Open the door and press The numeric keypad will light up the green setting button.
blue and emit a short beep, indicating that the safe is now in passcode setup mode.
2. Enter your programmed 3 to 8 digit codes and end with the “#”key.
The indicator will light up blue and emit a long
beep, indicating that the new
passcode has been successfully set.
NOTE:
- The default passcode is "123456".
- Only one passcode can be programmed for the safe.
- The passcode can consist of 3 to 8 digit codes.
- Important: Open the door and test your programmed passcode several times before
storing valuables inside.
Setting the User Passcode
Green setting button
Deleting All User Fingerprints and Passcodes
1. Open the door and press for 6 seconds. The fingerprint the green setting button
sensor will light up green, then the indicator lights up blue and emits a long beep,
indicating that all user fingerprints and passcode have been cleared.
NOTE: The default passcode will revert to “123456” and the fingerprint database will be
cleared. Please reset your fingerprint and passcode before storing valuables
inside.
3
Setting button
Removable Shelf
Locking Bolts
Internal battery case
Door Organizer
Locking Box
