Even Automatic Feeder
USER MANUAL
Model: FT80D
Have a Question For the Seller
Warranty Information
Reset to Factory Default
Cancel feeding schedule
Set the current time
Product Specifications
Feeder Assembly
Install the food tank
Install the bowls
Load in desiccant
Install the lid
Plug in the power
Set feeding meals
Recording
Manual feeding
Feeder panel introduction
Buttons Overview
FAQs
FCC WarningsFCC
[CONTENTS]
1
3
3
4
6
7
8
9
10
Setting Guideline
11
11
13
16
16
17
17
20
21
Feeder cleaning
Important notes
18
19
23
26
Product Specification
1
Model FT80D
Capacity 8L
Meals 4 meals per day
Screen LCD screen
One portion 12grams(8 portions max per meal)
Food size 2- 12mm(dry food only)
Battery-powered supply 3× alkaline D batteries (not included)
DC-powered supply 5V/1A
Operating temperature -10℃- 55℃/14°F-131°F
Dementions 23.5*23.5*33.5cm/9.3×9.3×13.2 inches
Product weight 2.4kg/5.29lbs
2
Lid
Feeder base
Meal Splitter
Control panel
Base
Food bowls
desiccant
Food tank
Turnplate
Feeder Assembly
3
Install the food tank
Align the feeder base with the tank and install the feeder as
indicated by the arrow shown.
1
4
2
Install the bowls
Insert (1) one bowl into the main base, as hown in (2) and (3).
(1)
(2) (3)
2.1 Single food bowl
5
2.2 Dual food bowls
(4)
(5) (6)
Step 1: Install the bowls
Put the two food bowls together in the direction of the arrow
shown in figure (4), and then insert the food bowl into the main
base as shown in (5) and (6).
6
3
(7) (8)
Step 2: Insert the meal splitter
Install the meal splitter as indicated by the arrow as shown in (7),
from top to bottom in place as shown in (8).
Load in desiccant
Open the desiccant cap, put in the desiccant, and then close
the desiccant cap.
7
4
Install the lid
First, align the lid to the tank and install from top to bottom, as
shown in (9). Next, fit into place, then rotate the lid clockwise
as shown in (10).
(9)
(10)
8
Step 2: Install 3 new D cell, alkaline batteries.(NOT Included)
Push the button switch to “I”. When the power is on, the
green light lights up, which indicates that the power is
normal.
Note:
(11)
5
Plug in the power
Step 1: Open the batteries cover, as shown in (11). Insert the
power cable oriented, put the cable into the slot.
9
Feeder panel introduction
Work
Status Indicator
Microphone
Hole
Number
Increase/Decrease
Recording
Manual feeding
Abnormal
Indicator
10
Buttons Overview
Note:
The screen will lock automatically after 2 minutes of non-use.
Hold for 3s to unlock.
Button Description
Set /Save
Unlock button
Number
Increase button
Number
Decrease button
Manual button
Recording
button
Press to save and move to the
next step
Operable Mode Function
Press and hold for 3s to lock/
unlock other buttons and screen
Press to increase the value
Hold for digit increasing
automatically
Press to decrease the value
Hold for digit decreasing
Press to feed 1 portion
Hold for 3s and start recording
after a beep is heard {max 10s}
Recording saved after a double
beep is heard
11
Setting Guideline
In the setting state, the LCD light will turn off and exit the
setting when there is no operation for more than 2min.
(MUST BE UNLOCKED)
Press and hold the button for 3s until the LCD display lights
up and enter the hour setting mode. The two hour digits will
start to flash, press to set the "hour". Hold digits
will automatically begin to increase/decrease until the desired
time is displayed.
Step 1
— Set the Current Time
Note:
1.1-Hour setting
12
After setting the hour, press the button to save and enter the
minute setting. Press to set the "minute". Press the
button to save.
1.2-Minute Setting
13
(MUST BE UNLOCKED)
1. Press the button to enter the copies setting of the first meal.
At this time, the meal number labeled as the first meal "①" will
lights up.
2. Press the button to set the "copies". Then press the
button to save.
Step 2
— Set feeding meals
2.1-Set the copy of the first meal
14
The maximum number of copies is 8.
Note:
After setting the copies, press the button to save. The feeder
then enters the time setting mode. The setting method is the
same method as setting the current time.
2.2-Set the time of the first meal
15
After finishing setting the first meal, press the button to save
and the feeder then enters the setting mode of the second
meal"②". Follow the same steps as setting the first meal.
Repeat to set feeding schedules for the other meals. The
maximum meal is 4.
2.3-Set the 2-4 meals
16
STEP 3— Cancel feeding schedule
If you want to cancel the feeding of a meal, you just need to set
the "copies" number to 0.
Step 3.1
If you need to change the recording message, press the
button again to record.
Note:
STEP 4— Recording
When not in the setting state( LCD lights off)
Press and hold the button, it will make one "beep" sound.
At this time, speak loudly into the device's microphone, and it
will record your voice. (max 10s) A double beep indicates
recording is saved.
A recording will be played automatically when the recording is
completed.
A recording will be played once when feeding.
17
STEP 5— Manual feeding
When not in the setting state (LCD light is off), press the
button to dispense 1 portion.
STEP 6— Reset to Factory Default
When not in the setting state (LCD light is off)
Press and hold at the same time for 3s, all settings will be
cleared, and the feeder will be restored to factory settings and
restart automatically.
18
Feeder cleaning
Turn off the feeder, unplug the power adapter, and take out the
batteries before cleaning.
The lid ,feeder tank, and turnplate can be disassembled to clean.
Lift the material cylinder up, and then remove it to clean. Please
use clean water or a soft detergent to clean. After cleaning, you
must wait for the device to dry before using.
The base and the exterior parts of the feeder body can be wiped
with a dry cloth.
DO NOT PUT THEM INTO THE WATER FOR CLEANING.
19
Important notes
Low power reminder: The red alarm light will flash when the
battery power is low. Please replace the battery regularly for
normal use.
Only for indoor use.It is best to keep the feeder against a wall
to prevent the pet from knocking it down.
Please check whether there is enough food in the feeder and
add more when required.
If not using the feeder for a long time, remove the batteries to
avoid any electrolyte leakage.
When the red alarm light is on persistently, the equipment has
malfunctioned. Please check the status of the feeder.
20
FAQs
Q1: How many meals can be set per day?
A: 4 meals per day at most with 8 portions per meal. One copy
is about 12 grams.
Q2: Why is the feeder is not dispensing food smoothly?
A: Check if there is food residual accumulation of food in the outlet.
Please clean the feeder regularly to prevent food blockages.
Q3: Why can I not wake up/Lockdown/Reset the feeder?
A: Try unplugging and plugging in the feeder, and try again.
Q5: How can I change the recording?
A: Press and hold the "REC" button to re-recording and it will
automatically replace the previous recording.
Q4: How long will the batteries last?
A: Put in the three-D cell batteries. They will last for about 30 days.
Any more questions, please email our support team:
The feeder is suitable for dry food only, and food under
12mm is ideal.
Note:
Batteries are designed as back-up power, and are not
recommended to be used in the long run.
Note:
21
Notes:
FCC WarningsFCC
Changes or modifications to this unit not expressly approved.
Non-compliance could void the user's authority to operate
the equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
22
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communi-
cations. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment causes
harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following Measures:
Reorient or relocate the receiving antenna.
Increase the distance between the equipment and receiver.
Connect the equipment into an outlet on a different circuit
than the one the receiver is currently connected.
Consult the dealer or an experienced radio/TV technician
for help.Shielded interface cables must be used with the
equipment in order to comply with the limits for a digital
device pursuant to Sub part B of Part 15 of FCC Rules.
Specifications and designs are subject to change without
any notice or obligation on the part of the manufacturer.
23
1
Warranty Information
NON-TRANSFERRABLE LIMITED WARRANTY
① To provide customers with a quality shopping and user
experience, we guarantee to replace, issue a refund, provide
acceptable solutions to any defective products (as the
customers prefers) from the date of purchase up to 2 years.
② Proof of purchase must be provided (order number or
receipt) when making a claim to our customer support center.
③ Warranty registration may be requested within a month
since the date of purchase, by sending your order number to
the mailbox: [email protected]
④ The warranty is not transferable. We only provide warranty
services to buyers who purchased from our Amazon store and
WOpet official website store and possess proof of purchase -
not to any other purchaser or subsequent owner.
24
2
3
⑥ The sellers are the responsible party. Amazon allows different
sellers to sell the same product, so please confirm the seller by
checking the order details before contacting us.
⑤ Price matching policy is not applicable. No price difference
will be refunded.
WHAT IS COVERED
Receiving defective or used (proof needed) products;
Receiving with missing parts;
Item is defective under proper use.
WHAT IS NOT COVERED
Purchase from non-amazon channels /non-WOpet official
website store/other physical stores;
Gift without proof of purchase;
Tampering/abnormal use/accidental damage;
Replacements and parts;
Installation fee/labor fee;
25
4 MAKING A CLAIM
If you have any problems when using our products, please
send an email to the mailbox: [email protected]
30 days free Return & Replacement
Standard Warranty: 1-Year product Warranty
2-Year Warranty Application: Please scan the QR code below to
finish the registration form on our official website to get 2-Year
in total warranty.
Please finish the form within 30 days after you received the
items.
Note:
26
Have a Question For the Seller
Home
Your Order
Buy Again
Your Wish List
Your Account
Shop by Department
Order#
Order Total
Shipped
Product link
Qty: 1
Sold By: Seller
Your Orders
Product link
Buy it again
Write a product review
View order details
View order details BRAND
Have a question
for the seller?
Ask a question
1.Find your order 2.Click “View order details”
3.Click the Seller name 4.Click “Ask a question”
27
Gifted parts, replacements, consumable products are not
covered by the 2-year warranty.
Manufactures’ warranties may not apply in all cases,
depending on factors such as use of the product, where the
product was purchased, or who you purchase the product
from.
Please review the warranty cafefully, and contact the
manufacture if you have any questions.
28
29
