AIR FRYER
CAF201B0BPK
User Manual
IMPORTANT NOTE: For your safety and continued enjoyment of this
product, always read the user manual carefully before using.
CONTENT
IMPORTANT SAFEGUARDS
PARTS AND FEATURES
1
5
SPECIFICATIONS
6
12
13
7
OPERATION INSTRUCTIONS
CLEANING AND MAINTENANCE
SERVICE AND SUPPORT
1
When using electrical appliances, basic safety precautions
should always be followed including the following:
• Read all instructions.
• Do not operate any appliance with a damaged cord or
plug or after the appliance malfunctions or has been
damaged in any manner. Return appliance to the
nearest authorized service facility for examination,
repair, or adjustment.
• To protect against electrical shock do not immerse cord,
plugs, or other live parts in water or other liquid.
• WARNING: To prevent electric shock, unplug before
cleaning
• Do not touch hot surfaces. Use handles or knobs.
• Extreme caution must be used when moving an
appliance containing hot oil or other hot liquids.
• Close supervision is necessary when any appliance is
used by or near children.
• Do not use outdoors.Household use only.
• Unplug from outlet when not in use and before
cleaning. Allow to cool before putting on or taking off
parts.
• The use of accessory attachments not recommended by
the appliance manufacturer may cause injuries.
• Do not let cord hang over edge of table or counter, or
touch hot surfaces.
• Do not place on or near a hot gas or electric burner, or
in a heated oven.
• Always attach plug to appliance first, then plug cord
into the wall outlet. To disconnect, turn any control to
"off", then remove plug from wall outlet.
IMPORTANT SAFEGUARDS
2
IMPORTANT SAFEGUARDS
• Do not use appliance for other than intended use.
• Caution ：To reduce the risk of electric shock, cook only
in removable container provided with the product.
• Use extreme caution when removing tray or disposing
of hot grease.
• Oversize foods or metal utensils must not be inserted in
a toaster-oven as they may create a fire or risk of
electric shock.
• A fire may occur if the toaster-oven is covered or
touching flammable material, including curtains,
draperies, walls, and the like, when in operation. Do not
store any item on top of the appliance when in
operation.
• Do not clean with metal scouring pads. Pieces can break
off the pad and touch electrical parts involving a risk of
electric shock.
• Extreme caution should be exercised when using
containers constructed of other than metal or glass.
• Do not store any materials, other than manufacturers
recommended accessories, in this oven when not in
use.
• Do not place any of the following materials in the oven:
(List all materials – such as paper, cardboard, plastic,
and the like).
• Do not cover crumb tray or any part of the oven with
metal foil. This will cause overheating of the oven.
• A short power-supply cord is provided to reduce the risk
resulting from becoming entangled in or tripping over
a longer cord.
3
IMPORTANT SAFEGUARDS
• Make sure the frying basket is locked into the front of
the drawer – both frying basket handle tabs must be
fully inserted into the notches on the top of the basket
drawer.
• Always make sure frying basket drawer is fully closed,
with frying basket handle locked securely in the drawer,
while Air Fryer is in operation.
• WARNING: Air Fryer will not operate unless frying
basket drawer is fully closed.
• CAUTION: After hot air frying, the frying basket and
frying basket drawer and the cooked foods are hot.
Extreme caution must be used when handling the hot
Air Fryer basket/drawer.
• WARNING: After air frying, make sure to place the
frying basket drawer on a flat, heat-resistant surface
before pressing the basket release button.
• Do not cover the air inlet and the air outlet openings
while the appliance is operating.
• Longer detachable power-supply cords or extension
cords are available and may be used if care is exercised
in their use.
If a longer detachable power-supply cord or extension
cord is used:
- The marked electrical rating of the cord set or
extension cord should be at least as great as the
electrical rating of the appliance;
- The cord should be arranged so that it will not drape
over the countertop or tabletop where it can be
pulled on by children or tripped over unintentionally;
4
SAVE THESE INSTRUCTIONS
IMPORTANT SAFEGUARDS
- If the appliance is of the grounded type, the cord set
or extension cord should be a grounding-type 3-wire
cord.
• CAUTION: The surface is hot when in use.
• This appliance has a polarized plug (one blade is wider
than the other). To reduce the risk of electric shock, this
plug is intended to fit into a polarized outlet only one
way. If the plug does not fit fully into the outlet, reverse
the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any
way.
5
PARTS AND FEATURES
COMPONENT NAME
NOTE
All the pictures in this manual are for explanation purpose only. Any discrepancy between
the real object and the illustration in the drawing shall be subject to the real subject.
Remove parts from the component before performing installation.
The product is subject to the actual product and configuration.
Timer knob
Thermostat knob
Main unit
Base assembly
Bakeware
(optional)
Fried barrel
6
TECHNICAL DATA OF THE PRODUCT
Model Voltage
CAF201B0BPK 120V~
Frequency
60Hz
Power
1150W
SPECIFICATIONS
7
OPERATION INSTRUCTIONS
INSTRUCTIONS FOR USE
Preparation
1. The product should be stably placed on a flat table (Figure 1), so that the power cord has
a sufficient length to be plugged into the socket, and the air around the product should
be kept in circulation, and should not be close to flammable items.
2. According to different configurations install the barrel assembly (Figure 2), then push it
into the Main unit (Figure 3).
Figure 1
Figure 2
8
OPERATION INSTRUCTIONS
3. Before placing ingredients, preheat the machine for 3-5 minutes, the cooking effect will
be better.
Tips For Fried barrel
When assembling fried barrel, the sound of metal duckles proves that the
assembly is in place.
INSTRUCTIONS
1. After the machine is powered on, adjust the temperature knob to the 400 °F position
and the time knob to 3-5 minutes to complete the warm-up operation of the machine.
2. After the preheating is completed, hold the top of the machine with one hand, and pull
the barrel out by holding the handle of the barrel with the other hand. The barrel must
be placed on a stable table.
3. Put the ingredients on the bakware in the fried barrel.
4. Push the fryer into the machine, select the corresponding cooking temperature and
time by the knob, and cook and heat the ingredients.
Figure 3
9
OPERATION INSTRUCTIONS
5. After the timer "ding" sounds the heating is completed. When the food is ready, unplug
the machine. Carefully take out the fried barrel, lay it flat on the table, and then use
auxiliary tools (such as chopsticks) to remove the cooked food.
NOTE
When the fried barrel is not fully advanced, the micro-switch is not triggered, and the
machine is in a state where the barrel is powered off and will not work. At this time, you
only need to push the drum in fully
Tips For Timer
If you set the scale within 30 degrees(about 10 mins）） from the OFF position, roll to
more than 30 degrees and then adjust to the required scale.
10
OPERATION INSTRUCTIONS
Handle with care and remember to lay it flat on the table to avoid being
burned by steam or dumping the fryer, or burned by oil or hot food. In the
process of removing food, it is recommended to use auxiliary tools (such as
chopsticks) to assist.
WARM REMINDER
• The first use requires 10 minutes of dry burning. A small amount of white smoke or
odor may appear during the dry burning process, which is normal. Do not panic.
• Before the product works, please check whether the bakeware is in place to avoid
malfunction.
• If you find that the product is malfunctioning, please stop using it and contact our
service department immediately.
• Please use the bakeware and fried barrel together in the whole machine, and avoid
using them separately.
• After using, unplug the power plug and allow the air fryer to cool completely before
moving.
11
OPERATION INSTRUCTIONS
180
400
400
400
370
340
400
370
12-14
17-19
16-18
20-22
12-14
10-12
38-40
10-12
DEFROST
FRENCH FRIES
CHICKEN WING
DRUMSTICKS
FISH
SHRIMP
VEGETABLES
SWEET POTATO
MEAT
PIZZA
CAKE
EGG TART
400
340
340
340
10-12
8-10
10-12
12-14
Menus
Temperature (℉ )
Time(min.)
This table below helps you to select the basic settings for the ingredients you want to
prepare.
Tips: The best effect is to turn the food halfway, and the best food effect the weight of
French fries is 200g.
SETTINGS
12
CLEANING AND MAINTENANCE
• Please clean the air fryer to prevent it from being burned.
• After using, please clean the bakeware and fried barrel in time to avoid the damage of
the coating due to the erosion of food residue oil.
• Do not use strong abrasive cleaners to prevent damage to the machine and your
health.
• Use a soft, clean cloth to wipe the air fryer. Please do not use an over-wet cloth to clean
the air fryer, to prevent water from entering the air fryer, which may cause short circuit
and fire.
• Please do not use other cleaning equipment such as a dishwasher to clean the air fryer,
otherwise it may cause damage and affect the use.
• Use neutral detergent or clean water to clean the frying pans and drums.
• Please do not use hard and sharp items (such as wire balls, blades, etc.) to clean the
bakeware and fried barrel to prevent scratching.
• Any other servicing should be performed by an authorized service representative.
13
1 YEAR LIMITED WARRANTY
This is the only express warranty for this product and is in lieu of
any other warranty or condition. This product is warranted to be
(1) year from the date of original purchase. During this period, your
exclusive remedy is repair or replacement of this product or any
component found to be defective, at our option; however, you are
responsible for all costs associated with returning the product to
us and our returning the product or component under this war-
ranty to you. If the product or component is no longer available,
we will replace with a similar one of equal or greater value.
This warranty does not cover wear from normal use, and
damages to the product resulting from accident, alteration,
abuse, or misuse. This warranty extends only to the original
consumer purchaser or gift recipient. Keep the original sales
This warranty is void if products is used for other than single-
family household use or subjected to any voltage and waveform
We exclude all claims for special, incidental, and consequential
damages by breach of express or implied warranty. All liability is
limited to amount of the purchase price. Every implied warranty,
including any statutory warranty or condition of merchant-ability
prohibited by law, in which case such warranty or condition is
limited to the duration of this written warranty.
legal rights that vary depending on where you live. Some states or
provinces do not allow limitations on implied warranties or special,
incidental consequential damages, so the foregoing limitations
may not apply to you. Please note that failure to complete and
submit this form does not diminish your warranty
SERVICE AND SUPPORT
14
In the Event of a warranty period claim,
question, comments or if service is required
for this product, please contact us at the
following:
Customer Service Management Office:
Parsippany, NJ 07054
Toll Free: 1-866-646-4332
Amazon Store:
https://www.amazon.com/comfee
Tel: 866-646-4332
E-mail: offi[email protected]
Made in China
SERVICE AND SUPPORT
