INSTRUCTION MANUAL
Water Tank Capacity 68 oz Dehumidifier
Thank you for choosing to purchase a product from US.
Please read the entire manual carefully prior to first use and
keep it in a safe place for future reference.
Use this product in accordance with the instructions in this manual. Any other use not recommended
by the manufacturer that could result in fire, electric shock, or personal injury.
To avoid the risk of electric shock, fire, or personal injury, always turn off the product before handling,
cleaning, or servicing it. Unplug the power cord and empty the water tank.
Persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge,
including children, should not use this device unless under supervision or instruction.
Do not cover or block the air inlet and outlet of this product during use, and there must be at least
50 cm of clearance around it.
Dispose of the water collected from the dehumidifier, this water cannot be drunk.
Always place the product upright on a flat, stable table. Operating this product in any other location
may create hazards and water leakage.
Do not allow water or other liquids to enter the product as this may create a fire or electrical hazard.
Do not use any abrasive cleaners or solvents as this will damage the device.
This product is suitable for indoor households and similar use. Do not use outdoors.
Avoid placing the power cord where it could cause a trip. Do not place the power cord under a rug
or cover it with a similar rug.
Do not twist or wrap power cords and plugs around the product as this will weaken or destroy the
insulation, especially where it is attached to the product.
Do not pull on the power cord, and do not move, carry, or hang the product by the power cord.
When using this device, do not remove the water tank, otherwise it may cause water leakage.
This product can only be used with the supplied adapter.
If the power cord is damaged, it must be replaced by the manufacturer, or service agent, or a similarly
qualified person to avoid a hazard.
Do not attempt to repair or adjust any electrical or mechanical component equipment in the machine
as doing so may be unsafe and will void your warranty.
SAFETY WARNING
Product dimension
Power
Voltage
Power specifications
Electric current
Water tank capacity
Net weight
Model No
Applicable room size
: 108-323 sq.ft
: 5.84 Ib
: 8.66*6.18*11.26in
: SY-801
: 68 oz
Dehumidification capacity
: 20 oz/24H
ON/OFF button
Indicator light
Tank cover
Floater
Air inlet
Air outlet
DC socket
DC plug
Water tank
AC plug
: 80 W
: 100-240V~
: DC, AC; 18V
: 4A
PRODUCT SPECIFICATIONS
PRODUCT COMPONENTS
This dehumidifier uses Peltier technology and condensation technology (no compressor) to dehumidify,
is lightweight and quiet. Ideal for small rooms and poorly ventilated areas such as wardrobes, cupboards,
kitchens, bathrooms and pantries that are prone to damp odors and fungal infections.
Using this dehumidifier will help remove unwanted moisture from the air.
1. Place the dehumidifier on a stable, table and connect the power adapter to an electrical outlet.
Standing horizontally Connection to the power supply Turning on the power
2. Press the ON/OFF button for the first time, the dehumidifier starts to work, the indicator light turns
blue, and the multi-colorful lights cycle automatically.
3. Press the ON/OFF button again, the dehumidifier will stop working, and the indicator light and
multi-colorful lights will turn off.
4. In the power-on state, long-press the ON/OFF button for 2 seconds, the multi-colorful light can
be turned on or off separately.
5. In the power-on state, quick double-click the ON/OFF button to turn on the 8H timing function, and
the indicator light turns purple; Double-click the ON/OFF button again to turn off the timing function,
and the indicator light turns blue.
6. After the water tank is filled with water, the device stops working, and the LED light is always on red,
indicating that the water tank is full and needs to be poured.
FEATURES
OPERATION INSTRUCTION
1. When the water tank is full, turn off the power and take out the water tank.
Pull out the tank Open the lid Drain the tank Close the lid and
put the tank back
CLEANING THE WATER TANK
Warning: When not using this product, do not leave water in the water tank. The accumulated water may
breed microorganisms.
The water tank should be emptied and cleaned regularly; tank should be cleaned at least weekly, or before
storage, to prevent mold and bacteria growth.
1. Clean the tank with mild detergent and tap water.
Cleaning the water tank
with detergent.
Wiping off water droplets on
the surface of the tank
Reinstalling the tank
2. Remove any scale or deposits that have formed in the tank.
3. Wipe and clean the surface of the water tank before putting it back into the device.
2. Place the tank on a stable table and remove the tank cover.
3. Gently tilt the tank, pour the water into the sink or basin, and empty it.
4. After pouring out the water, close the lid of the tank and put it back into the device.
EMPTYING THE WATER TANK
WARNING:
Always turn off the device and unplug the power cord before handling or cleaning the product.
NOTE:
Do not use any abrasive cleaners or solvents as this will damage the device;
Do not allow water or other liquids to flow inside the device as this may create a fire or electrical hazard.
EXTERIOR CLEANING
STORAGE
PRODUCTS AND ACCESSORIE
Dehumidifier Power adapter Instruction manual
To clean the exterior of the product,
wipe with a soft, dry cloth to remove
dust or light residue.
1. Before storage, ensure that the equipment and water tank are clean and dry.
2. If you store your products by season, we recommend using the original
packaging or a box of similar size.
3. Do not wrap the power cord and plug around the product,
as this may damage or tear the insulation, especially where it is
connected to the product.
4. Store the device in a safe, clean, dry place when not in use.
CLEANING AND STORAGE
INSTRUCTION MANUAL
2000ML Dehumidifier
Thank you for choosing to purchase a product from XXX. Please read the
entire manual carefully prior to first use and keep in a safe place for future reference.
1. This manual has been carefully proofread.
2. There will be technical improvements to this product in the future without prior notice.
3. If there is any change in the appearance and color of the product, please refer to the actual product.
4. The internal pictures of the product are for reference only.
FREQUENTLY ASKED QUESTIONS & SOLUTIONS
FREQUENTLY
ASKED QUESTIONS
Device not
running
CAUSE ANALYSIS
Power outage or disconnection
The power plug is not inserted correctly
Air inlet or outlet blockage
Low moisture
removal capacity
Indoor humidity is too low
Running more than two dehumidifiers
in the room at the same time
SOLUTIONS
Check the power
Insert the power plug
Timer function has run out of time
Double-click the power button to cancel the
timer function or restart the device
Remove obstructions from the air inlet or outlet
It is recommended to use a dehumidifier
when the indoor humidity is above 60%
Please reduce the number of dehumidifiers
Are the doors and windows closed?
Whether there is a heat /
moisture source in the room.
Interior space/area too large
The device is tilted
Device water
leakage
Long time
operation still
can not achieve
the purpose of
moisture removal
Please close the doors and windows
Please adjust / close
Use in a suitable room (10-30㎡)
Place the device smoothly
tank is full of water Empty the water tank
Water tank not in place / or in
incorrect location
Water tank breakage
Water tank floater fallen / off-position
Note: If the analysis of the above phenomenons still cannot eliminate the fault, please contact
our after-sales service or dealer.
Contact supplier to replace water tank
Re-installation of the floater
Place the water tank correctly in the device
SPECIAL STATEMENT
