99944200601
PAS 80-Tooth
Blade Brushcutter
Attachment
FOR MODELS: SRM-2100SB, 2400SB, 210SB, 211SB, 225SB, 260SB,
261SB, PAS-2100, 2400, 2601, 210, 211, 225, 225VP, 225VPB, 230, 231,
260, 261, 265, 266, 280, 2620
Users of this equipment risk injury to themselves and
others if the unit is used improperly and/or safety
precautions are not followed. ECHO provides an
operator’s manual. It must be read and understood for
proper and safe operation. Failure to do so could result in
serious injury.
TABLE OF CONTENTS 99944200601
2 X77 12092600
© 04/2017 ECHO Inc.
TABLE OF CONTENTS
Introduction ................................................................................................. 3
Servicing Information .................................................................................. 3
Parts/Serial Number ............................................................................ 3
Service................................................................................................. 3
Echo Consumer Product Support........................................................ 4
Product Registration ............................................................................ 4
Additional or Replacement Manuals .................................................... 4
Safety.......................................................................................................... 4
Manual Safety Symbols and Important Information............................. 4
International Symbols .......................................................................... 5
Personal Condition and Safety Equipment .......................................... 6
Equipment.......................................................................................... 11
Description ................................................................................................ 12
Contents.................................................................................................... 13
Assembly................................................................................................... 14
Power Head Shaft/Lower Shaft Assembly ......................................... 14
Install Handle/Barrier Bar................................................................... 15
Shield and Blade Installation ............................................................. 15
Balance Unit ...................................................................................... 17
Operation .................................................................................................. 17
Maintenance ............................................................................................ 18
Skill Levels......................................................................................... 18
Maintenance Intervals........................................................................ 18
Lubrication ......................................................................................... 19
Drive Shaft (Lower) ........................................................................... 19
Storage...................................................................................................... 20
Storage Hook Installation................................................................... 20
Specifications............................................................................................ 20
Product Registration.................................................................................. 20
Notes......................................................................................................... 22
99944200601 INTRODUCTION
X7712092600 3
© 04/2017 ECHO Inc.
ENGLISH
INTRODUCTION
Welcome to the ECHO family. This ECHO product was designed and manu-
factured to provide long life and on-the-job dependability. Read and under-
stand this manual and the safety manual. Keep the manuals in a safe place
for future reference.
The operators manual contains specifications and information for safety,
operation, maintenance, storage and assembly specific to this product.
Scan the QR codes throughout the operator’s manual for more information.
The safety manual explains possible hazards and the measures you should
take to insure safe operation.
SERVICING INFORMATION
Parts/Serial Number
Genuine ECHO Parts and Assem-
blies for your ECHO products are
available only from an Authorized
ECHO Dealer. When you do need to
buy parts always have the Model
Number and Serial Number of the
unit with you. For future reference
write them in the space provided
below.
Model No. _________________
Serial No. _________________
Service
Service of this product during the warranty period must be performed by an
Authorized ECHO Service Dealer. For the name and address of the
Authorized ECHO Service Dealer nearest you, ask your retailer or call:
1-800-432-ECHO (3246). Dealer information is also available on our Web
Site. www.echo-usa.com. When presenting your unit for Warranty service/
repairs, proof of purchase is required.
SAFETY 99944200601
4 X77 12092600
© 04/2017 ECHO Inc.
Echo Consumer Product Support
If you require assistance or have questions concerning the application,
operation, or maintenance of this product, call the ECHO Consumer Prod-
uct Support Department at 1-800-673-1558 from 8:00 am to 5:00 pm (Cen-
tral Standard Time) Monday through Friday. Before calling, please know the
model and serial number of your unit.
Product Registration
Register your ECHO equipment on-line at www.echo-usa.com or by filling
out the product registration sheet included in this manual. Registering your
product confirms warranty coverage and provides a direct link to ECHO if
we find it necessary to contact you.
Additional or Replacement Manuals
Replacement Operator or Safety Manuals, and Parts
Catalogs, are available from your Authorized ECHO Ser-
vice Dealer, or at www.echo-usa.com, or by contacting
ECHO Inc., 400 Oakwood Road, Lake Zurich, IL 60047
(800-673-1558). Always check www.echo-usa.com for
updated information.
Safety Videos are available from your Authorized ECHO Service Dealer. A
$5.00 shipping charge is required for each video.
SAFETY
Manual Safety Symbols and Important Information
Throughout this manual and on the product itself, you will find safety alerts
and helpful, informational messages preceded by symbols or key words.
The following is an explanation of those symbols and key words and what
they mean to you.
The safety alert symbol accompanied by the word “DANGER”
calls attention to an act or condition which WILL lead to serious
personal injury or death if not avoided.
99944200601 SAFETY
X7712092600 5
© 04/2017 ECHO Inc.
ENGLISH
The safety alert symbol accompanied by the wrod “WARNING”
calls attention to an act or condition which CAN lead to serious
personal injury or death if not avoided.
The safety alert symbol accompanied by the word “CAUTION”
calls attention to an act or condition which may lead to minor or
moderate personal injury if not avoided.
The enclosed message provides information necessary for the pro-
tection of the unit.
Note: This enclosed message provides tips for use, care and main-
tenance of the unit.
CIRCLE AND SLASH SYMBOL
This symbol means the specific action shown is prohibited.
Ignoring these prohibitions can result in serious or fatal injury.
International Symbols
Symbol Description Symbol Description
Warning, See
Operator’s Manual
Safety / Alert
Wear Eye, Ear and
Head Protection
Finger Severing
Wear Hand and Foot
Protection
Rotating Cutting
Attachment
Wear Face Shield
Wear Slip Resistant
Footwear
SAFETY 99944200601
6 X77 12092600
© 04/2017 ECHO Inc.
Personal Condition and Safety Equipment
Users of this product risk injury to themselves and others if the
unit is used improperly and/or safety precautions are not fol-
lowed. Proper clothing and safety gear must be worn when op-
erating unit.
Physical Condition
Your judgment and physical dexterity may not be good:
• If you are tired or sick
• If you are taking medication
• If you have taken alcohol or drugs
Operate unit only if you are physically and mentally well.
Keep Feet Away From
Blade
Do not operate closer
than 15 m (50 ft.) from
electrical hazards.
Keep bystanders at
least 15 m (50 ft.)
away.
DO NOT USE
BLADES - Line Head
Only
Thrown Objects
Plan retreat path from
falling objects.
Hot Surface
AVOID KICKOUT
Keep Bystanders At Least
15 m (50 ft.) Away
Beware Thrown Objects
Wear Eye Protection
Keep Bystanders and Helpers
Away 15 m (50 ft.)
Symbol Description Symbol Description
99944200601 SAFETY
X7712092600 7
© 04/2017 ECHO Inc.
ENGLISH
Eye Protection
◆ Eye protection that meets ANSI Z87.1 or CE requirements
must be worn whenever you operate the unit.
◆ For additional safety, a full-face shield may be worn over
safety glasses or goggles to provide protection from sharp
branches or flying debris.
Hand Protection
Wear sturdy, no-slip, rubber work gloves to improve your grip on the han-
dles. Gloves also provide protection against cuts and scratches, cold envi-
ronments, and reduce the transmission of machine vibration to your hands.
Hearing/Ear Protection
ECHO recommends wearing hearing protection whenever unit is used.
Breathing Protection
Operators who are sensitive to dust or other common airborne allergens
may need to wear a dust mask to prevent inhaling these materials while
operating unit. Dust masks can provide protection against dust, plant debris,
and other plant matter such as pollen. Make sure the mask does not impair
your vision, and replace the mask as needed to prevent air restrictions.
Proper Clothing
Wear snug-fitting, durable clothing:
• Pants should have long legs, shirts should have long sleeves.
• DO NOT WEAR SHORTS.
• DO NOT WEAR TIES, SCARVES, JEWELRY, or clothing with loose or
hanging items that could become entangled in moving parts or surround-
ing growth.
• Keep clothing buttoned or zipped, and keep shirt tails tucked in.
Wear sturdy work shoes with nonskid rubber soles:
• DO NOT WEAR OPEN TOED SHOES.
• DO NOT OPERATE UNIT BAREFOOTED.
Keep long hair away from engine and air intake. Retain hair with cap or net.
SAFETY 99944200601
8 X77 12092600
© 04/2017 ECHO Inc.
Heavy protective clothing can increase operator fatigue, which may lead to
heat stroke. Schedule heavy work for early morning or late afternoon hours
when temperatures are cooler.
The components of this machine generate an electromagnetic
field during operation, which may interfere with some pacemak-
ers. To reduce the risk of serious or fatal injury, persons with
pacemakers should consult with their physician and the pace-
maker manufacturer before operating this machine. In the ab-
sence of such information, ECHO does not recommend
the use
of this machine by anyone who has a pacemaker.
Extended Operation / Extreme Conditions
Prolonged exposure to cold and/or vibration may result in inju-
ry. Read and follow all safety and operation instructions to min-
imize risk of injury. Failure to follow instructions may result in
painful wrist/hand/arm injuries.
It is believed that a condition called Raynaud’s Phenomenon, which affects
the fingers of certain individuals, may be brought about by exposure to
vibration and cold. Exposure to vibration and cold may cause tingling and
burning sensations, followed by loss of color and numbness in the fingers.
The following precautions are strongly recommended, because the mini-
mum exposure, which might trigger the ailment, is unknown.
• Keep your body warm, especially
the head, neck, feet, ankles,
hands, and wrists.
• Maintain good blood circulation by
performing vigorous arm exer-
cises during frequent work
breaks, and also by not smoking.
• Limit the hours of operation. Try to
fill each day with jobs where oper-
ating the unit or other hand-held
power equipment is not required.
• If you experience discomfort, red-
ness, and swelling of the fingers followed by whitening and loss of feeling,
consult your physician before further exposing yourself to cold and vibra-
tion.
99944200601 SAFETY
X7712092600 9
© 04/2017 ECHO Inc.
ENGLISH
Repetitive Stress Injuries
(RSI)
It is believed that overusing the
muscles and tendons of the fingers,
hands, arms, and shoulders may
cause soreness, swelling, numb-
ness, weakness, and extreme pain
in those areas. Certain repetitive
hand activities may put you at a high
risk for developing a Repetitive
Stress Injury (RSI). An extreme RSI
condition is Carpal Tunnel Syn-
drome (CTS), which could occur
when your wrist swells and
squeezes a vital nerve that runs
through the area. Some believe that
prolonged exposure to vibration may contribute to CTS. CTS can cause
severe pain for months or even years.
To reduce the risk of RSI/CTS, do the following:
• Avoid using your wrist in a bent, extended, or twisted position. Instead try
to maintain a straight wrist position. Also, when grasping, use your whole
hand, not just the thumb and index finger.
• Take periodic breaks to minimize repetition and rest your hands.
• Reduce the speed and force with which you do the repetitive movement.
• Do exercises to strengthen the hand and arm muscles.
• Immediately stop using all power equipment and consult a doctor if you
feel tingling, numbness, or pain in the fingers, hands, wrists, or arms. The
sooner RSI/CTS is diagnosed, the more likely permanent nerve and mus-
cle damage can be prevented.
All over head electrical conductors and communications wires
can have electricity flow with high voltages. This unit is not in-
sulated against electrical current. Never touch wires directly or
indirectly, otherwise serious injury or death may result.
Do not operate this product indoors or in inadequately
ventilated areas. Engine exhaust contains poisonous emissions
and can cause serious injury or death.
SAFETY 99944200601
10 X7712092600
© 04/2017 ECHO Inc.
Read the Manuals
• Provide all users of this equipment with the Operator’s Manual and Safety
Manual for instructions on Safe Operation.
Clear the Work Area
• Spectators and fellow workers must be warned, and children and animals
prevented from coming nearer than 15 m (50 ft.) while the unit is in use.
Keep a Firm Grip
• Always hold throttle handle and support handle with thumbs and fingers
tightly encircling the handles.
Keep a Solid Stance
• Maintain footing and balance at all times. Do not stand on slippery,
uneven or unstable surfaces. Do not work in odd positions or on ladders.
Do not over reach.
Avoid Hot Surfaces
• During operation, the drive shaft
housing and attachment bearing
housing may become very hot,
too hot to touch. Avoid contact
during and immediately after operation.
Equipment
Use this attachment with ECHO approved models only. Serious
injury may result from the use of this attachment combined with
a non approved ECHO product.
• Check unit for loose/missing nuts, bolts, and screws. Tighten and/or
replace as needed.
• Inspect shield for damage and make sure it is securely in place. Replace
if shield is damaged or missing.
• Check that the cutting attachment is firmly attached and in safe operating
condition.
80-Tooth blade requires professional sharpening.
99944200601 SAFETY
X7712092600 11
© 04/2017 ECHO Inc.
ENGLISH
Note: ECHO, INC. will not be responsible for the failure of cutting
devices, attachments or accessories which have not been
tested and approved by ECHO.
Moving parts can amputate fingers or cause severe injuries.
Keep hands, clothing and loose objects away from all openings.
◆ ALWAYS stop engine, disconnect spark plug, and make
sure all moving parts have come to a complete stop before
removing obstructions, clearing debris, or servicing unit.
◆ DO NOT start or operate unit unless all guards and
protective covers are properly assembled to unit.
◆ NEVER reach into any opening while the engine is running.
Moving parts may not be visible through openings.
DESCRIPTION 99944200601
12 X7712092600
© 04/2017 ECHO Inc.
DESCRIPTION
Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and
that you understand and follow the instructions on it. If a decal cannot be
read, a new one can be ordered from your ECHO dealer.
1. LOWER DRIVE SHAFT ASSEMBLY
2. FLEXIBLE DRIVE CABLE
3. PLASTIC BLADE SHIELD
4. BLADE
5. SHOULDER HARNESS
15 m
50 ft
1
5
3
4
2
99944200601 CONTENTS
X7712092600 13
© 04/2017 ECHO Inc.
ENGLISH
CONTENTS
The ECHO product you purchased has been factory pre-assembled for your
convenience. Due to packaging restrictions, some assembly may be
necessary.
After opening the carton, check for damage. Immediately notify your retailer
or ECHO Dealer of damaged or missing parts. Use the contents list to check
for missing parts.
1 80 Tooth Brushcutter Attachment
1 Operator's Manual
1 Warranty Sheet
1 80 Tooth Metal Blade
1 Plastic Shield
1 4-Hole Barrier Bar
1 2-Hole Barrier Bar
3 M5 x 0.8 x 25 mm Torx Bolt (shield mounting)
3 M5 x 0.8 Lock Nut (shield mounting)
4 M5 x 0.8 x 35 mm Torx Bolt (barrier bar)
4 M5 x 0.8 Lock Nut (barrier bar)
11 2 mm x 22 mm Cotter Pins
1 Storage Hook Assembly
1 Shoulder Harness with Quick-Release Hook
1 Spanner Tool - 8 mm x 10 mm
1 T-Wrench - 17 mm x 19 mm
1 Locking Rod - 5 mm x 120 mm
1 Shield Plate
ASSEMBLY 99944200601
14 X7712092600
© 04/2017 ECHO Inc.
ASSEMBLY
Power Head Shaft To Lower Shaft Assembly
Do not perform maintenance or assembly procedures with
engine running.
1. Set Power Head/Shaft Assembly on a level surface.
2. Pull locater pin (A) out, and turn counter-clockwise ¼
turn to lock-out position.
3. Remove vinyl cap from attachment drive shaft.
4. Remove cardboard spacer, if necessary.
Note: Your coupler may appear different than
coupler shown.
5. Carefully fit attachment drive
shaft assembly into coupler (B)
to decal assembly line (C),
making sure that the inner
lower drive shaft engages the
square upper drive shaft
socket.
Note: Earlier model power
heads may have shorter
couplings.
Note: Lower bearing housing
and head assembly must be in line with the engine.
6. Rotate locater pin (A) ¼ turn
clockwise to engage lower shaft
hole. Insure locater pin is fully
engaged by twisting lower drive
shaft. Locater pin should snap
flush in coupler. Full
engagement will prevent further
shaft rotation.
7. Secure lower shaft assembly to
coupler by tightening clamping
knob (D).
Install Handle/Barrier Bar
Note: The Barrier Bar is required when using grass or weed blades.
Units equipped with U-Handles do not require installation of
the Barrier Bar.
Parts Required: PAS or SRM-SB Power Head Shaft and Coupling
B
A
C
D
A
99944200601 ASSEMBLY
X7712092600 15
© 04/2017 ECHO Inc.
ENGLISH
4-screw front handle
1. Remove screws and nuts and
back plate from handle.
2. Position front handle on shaft
and install Barrier Bar using
5x35 mm screws and new nuts
included with kit. Handle must
be at least 250 mm (10 in.) from
center of rear handle grip.
3. Adjust handle position for
comfortable operation, and
tighten screws securely.
2-screw front handle
1. Remove screws and nuts and
back plate from handle.
2. Position front handle on shaft
and install Barrier Bar using
5x35 mm screws provided in
kit. Handle must be at least
250 mm (10 in.) from center of
rear handle grip.
3. Adjust handle position for
comfortable operation, and
tighten screws securely.
Note: The Barrier Bar is not a
handle.
Shield and Blade Installation
Install the shield first, then install the blade. Note the orientation of the
components, install as shown.
ASSEMBLY 99944200601
16 X7712092600
© 04/2017 ECHO Inc.
Shield
Shield mounting lock nuts (A).
Shield (B).
Shield Plate (C).
Shield mounting bolts (D).
Blade
Upper blade plate (E).
Blade (F).
Lower blade plate (G).
Hex nut (H).
Cotter pin (I).
A
B
C
D
E
F
G
H
I
99944200601 OPERATION
X7712092600 17
© 04/2017 ECHO Inc.
ENGLISH
Balance Unit
1. Put on harness and attach unit
to harness.
2. Slide harness clamp up and
down until unit balances with
head approximately 51 mm to
76 mm (2 in. to 3 in.) from the
ground.
3. Tighten clamp screw.
Note: In case of Emergency, the
trimmer/brushcutter can
be released from the
harness by pulling up on
the quick-release collar.
OPERATION
Moving parts can amputate fingers or cause severe injuries.
Keep hands, clothing and loose objects away from all
openings. Always stop engine, disconnect spark plug, and
make sure all moving parts have come to a complete stop
before removing obstructions, clearing debris, or servicing
unit. Allow unit to cool before performing service.
51 mm to 76 mm
(2 in. to 3 in.)
MAINTENANCE 99944200601
18 X7712092600
© 04/2017 ECHO Inc.
Note: Refer to the Grass Trimmer / Brush Cutter Safety Manual for
proper and safe trimming techniques.
MAINTENANCE
Moving parts can amputate fingers or cause severe injuries.
Keep hands, clothing and loose objects away from all openings.
Always stop engine, disconnect spark plug, and make sure all
moving parts have come to a complete stop before removing
obstructions, clearing debris, or servicing unit. Allow unit to
cool before performing service. Wear gloves to protect hands
from sharp edges and hot surfaces.
Your ECHO unit is designed to provide many hours of trouble free service.
Regular scheduled maintenance will help your unit achieve that goal. If you
are unsure or are not equipped with the necessary tools, we recommend
that you take your unit to an ECHO Servicing Dealer for maintenance. To
help you decide whether you want to DO-IT-YOURSELF or have the ECHO
Dealer do it, each maintenance task has been graded. If the task is not
listed, see your ECHO Dealer for repairs.
Skill Levels
Level 1 = Easy to do. Common tools may be required.
Level 2 = Moderate difficulty. Some specialized tools may be required.
Click HERE or go to http://www.echo-usa.com/products/maintenance-kit for
information on Maintenance Kits.
Maintenance Intervals
IMPORTANT - Time intervals shown are maximum. Actual use and your
experience will determine the frequency of required maintenance.
1
Apply lithium based grease.
Component/
System
Maintenance
Procedure
Skill
Level
Interval
Drive Shaft
Grease 1 Every 25 hours of use
1
Gear Housing
Grease 1 Every 50 hours of use
1
Screws/Nuts/
Bolts
Inspect/Tighten/
Replace
1 Before Each Use
99944200601 MAINTENANCE
X7712092600 19
© 04/2017 ECHO Inc.
ENGLISH
Lubrication
Level 1.
Gear Housing
1. Clean all loose debris from gear case.
2. Remove plug (A) and check
level of grease. Grease should
fill gear case to bottom of
grease plug hole.
3. Add grease if necessary using
manual grease gun or squeeze-
type tube. Do not use high
pressure grease gun. DO NOT
over-fill.
4. Install plug (A).
Drive Shaft (Lower)
1. Loosen screw (B) and remove
locating screw (C). Pull gear
case and shield from drive shaft
housing.
2. Pull flexible cable from the drive
shaft housing, wipe clean and
re-coat with 15 ml (0.5 oz.) of
grease.
3. Slide the flexible cable back in
the drive housing. DO NOT get dirt on the flex cable.
4. Install the gear housing and shield assembly.
Parts Required: Lithium Base Grease
A
B
C
STORAGE 99944200601
20 X7712092600
© 04/2017 ECHO Inc.
STORAGE
Storage Hook Installation
1. Insert small end of hook into
locating hole on attachment
shaft.
2. Slide plastic cap onto end of
attachment shaft.
SPECIFICATIONS
PRODUCT REGISTRATION
Thank you for choosing ECHO Power Equipment
Please go to http://www.echo-usa.com/Warranty/Register-Your-ECHO to
register your new product on-line. It's FAST and EASY! NOTE: your
information will never be sold or misused by ECHO, Inc. Registering your
purchase enables us to contact you in the unlikely event of a service update
or product recall, and verifies your ownership for warranty consideration.
If you do not have access to the Internet, you can complete the form below
and mail to:
ECHO Inc., Product Registration, PO Box 1139, Lake Zurich IL 60047.
MODEL 99944200601
Shaft Length 830 mm (32.7 in.)
Attachment Width 265 mm (10.4 in.)
Attachment Height 153 (6.0 in.)
Weight (without blade) 1.5 kg (3.32 lb.)
Drive shaft 6.35 mm (0.25 in.) flexible shaft
Rotating Direction Counter-clockwise (viewed from the top)
Cutter 203 mm (8 in.) 80 tooth metal blade – 25 mm (0.98 in.) arbor
Shield Plastic
99944200601 PRODUCT REGISTRATION
X7712092600 21
© 04/2017 ECHO Inc.
ENGLISH
NOTES 99944200601
22 X7712092600
© 04/2017 ECHO Inc.
NOTES
99944200601 NOTES
X7712092600 23
© 04/2017 ECHO Inc.
ENGLISH
ECHO, INCORPORATED
400 Oakwood Road
Lake Zurich, IL 60047
www.echo-usa.com
U02600001001 - U02600999999
