30" CONTEMPORARY OVENS
PLANNING GUIDE
SERIES 7
SELF-CLEANING OVEN | OB30SCPTDX3, OB30SCPTDB3
COMPACT CONVECTION-SPEED | OM30NCTDX3, OM30NCTDB3
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 290004843A PLANNING GUIDE 30" ovENS vERSIoN A - JULY 2025
CONCEPT DESIGN PAGE
DEVELOPED AND DETAILED DESIGN PAGE DEVELOPED AND DETAILED DESIGN PAGE
SPECIFICATIoN GUIDE
Self-Cleaning Oven 4
Compact Convection-Speed Oven 6
SUPPORT
For additional design planning and installation support please
contact the Fisher & Paykel design support team.
designsupport@fisherpaykel.com
CONTENTS | 30" OVENS
INTRODUCTION
This comprehensive planning guide provides you with the
framework and tools to achieve your desired design outcome
with Fisher & Paykel appliances. In this guide, you will find a
range of conceptual, detailed, and dimensional product
information to bring your ideas to life and create spaces that
truly reflect your vision.
NOTES
The models shown in this Planning Guide may not be available
in all markets and are subject to change at any time. Refer to to
our website fisherpaykel.com for the latest document version.
Product specifications may vary from those shown.
This Planning Guide should not be used as installation guidance
for any product. Specific installation guidance will be available
with the product on delivery and on our website.
<< CONTENTS
CONTENTS
PAGE 3© FISHER & PAYKEL APPLIANCES LIMITED 2025PLANNING GUIDE 30" ovENS vERSIoN A - JULY 202590004843A
SPECIFICATION GUIDE
SERIES 7
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 490004843A PLANNING GUIDE 30" ovENS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
OB30SCPTDX3, OB30SCPTDB3SPECIFICATION GUIDE | SELF-CLEANING OVEN, 30"
OVERVIEW
Designed to be distinctive and timeless, this Contemporary
oven matches with our Contemporary style family of appliances.
Pyrolytic self-cleaning simplifies maintenance, while intuitive
temperature and heat type recommendations accessed via the
large touch screen and SmartHQ™ support optimal cooking
results across a wide range of functions and food types.
PRODUCTS
oB30SCPTDX3 - Brushed Silver Glass
30" Series 7 Contemporary Self-Cleaning Oven
oB30SCPTDB3 - Black Glass
30" Series 7 Contemporary Self-Cleaning Oven
SERIES & STYLE
Series 7
Contemporary
FEATURES
1 Contemporary style is distinctive and timeless. Designed to
match with our Contemporary style family of appliances
2 Self-cleaning pyrolytic function breaks down food residue
for an easy clean
3 Premium soft-close door with advanced thermal
performance
4 Generous 4.6 cu ft useable capacity
5 5" touchscreen with illuminated dial
6 Achieve optimal results with temperature and heat type
recommendations
7 Twin vertical fans, perfect for multi-shelf cooking
8 Connected capability via the SmartHQ™ app gives control &
visibility from anywhere at anytime
ACCESSORIES
1 Self-cleaning-proof Side Ladders
2 Flat Shelf (x2)
OB30SCPTDB3
OB30SCPTDX3
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 590004843A PLANNING GUIDE 30" ovENS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
OB30SCPTDX3, OB30SCPTDB3SPECIFICATION GUIDE | SELF-CLEANING OVEN, 30"
CAVITY DIMENSIONS
Cavity Dimensions
inch mm
A Minimum inside height of cavity
28 1/32 712
B Minimum inside width of cavity
28 1/2 724
C Minimum inside depth of cavity*
23 1/2** 597**
Recommened cabinet height
28 3/4 731
Recommened cabinet width
30 762
*Measured from front of chassis.
**Requires ventilation at the rear of the cavity.
ISOMETRIC VIEW
PRODUCT DIMENSIONS
Product Dimensions inch mm
A Overall height
28 11/16 729
B Overall width
29 7/8 758
C Chassis height
27 7/8 708
D Chassis width
28 3/8 720
E Chassis depth
22 5/8 575
F Front panel thickness
13/16 20
Depth with door fully open*
23 3/8 594
*Measured from front of control panel.
ISOMETRIC VIEW
b
a
c
d
a
b
c
SPECIFICATIONS
Model Number
OB30SCPTDX3
30" Series 7 Contemporary Self-Cleaning Oven
- Brushed Silver Glass
OB30SCPTDB3
30" Series 7 Contemporary Self-Cleaning Oven
- Black Glass
Electrical
Supply 208 or 240 V, 60 Hz
Service 20 A
Connection Hard wired 78 3/4" (2000mm)
Capacity
Total Oven
capacity
4.9cu ft (137L)
e
f
Ventilation
required
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 690004843A PLANNING GUIDE 30" ovENS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | COMPACT CONVECTION-SPEED OVEN, 30" OM30NCTDX3, OM30NCTDB3
OVERVIEW
Designed to be distinctive and timeless, this Contemporary
Convection-Speed oven matches with our Contemporary style
family of appliances. With versatile cooking options including
microwave or convection for ecient heating across a variety of
dishes. Intuitive temperature and heat type recommendations
can be accessed via the touch screen and SmartHQ™, to
support optimal cooking results across a wide range of
functions and food types.
PRODUCTS
oM30NCTDX3 - Brushed Silver Glass
30" Series 7 Contemporary Compact Convection-Speed Oven
oM30NCTDB3 - Black Glass
30" Series 7 Contemporary Compact Convection-Speed Oven
SERIES & STYLE
Series 7
Contemporary
OM30NCTDB3
OM30NCTDX3
FEATURES
1 Contemporary style is distinctive and timeless. Designed to
match with our Contemporary style family of appliances
2 Combines fast microwave cooking with even convection
heat for versatile, efficient heating across a variety of dishes
3 With soft open and close, the CoolTouch door is safe to
touch from the outside - protecting hands and surrounding
cabinetry
4 Generous 38L useable capacity with four shelf positions
5 5" touchscreen with illuminated dial is intuitive and easy to
use
6 Achieve optimal results with temperature and heat type
recommendations
7 30 functions, including four microwave-only, 14 traditional
oven and four combination settings
8 Includes a wired temperature sensor for real-time
monitoring of cooking temperatures
9 Connected capability via the SmartHQ™ app gives control &
visibility from anywhere at anytime
ACCESSORIES
1 Chrome Side Ladders
2 Wire Shelf
3 Step Down Wire Shelf
4 Broil Rack
5 Glass Tray
<< CONTENTS
© FISHER & PAYKEL APPLIANCES LIMITED 2025 PAGE 790004843A PLANNING GUIDE 30" ovENS vERSIoN A - JULY 2025
The models shown in this Planning Guide may not be available in all markets and are subject to change at any time. Product specifications may vary from those shown. This Planning Guide should not be used as installation guidance for any product. Further information is required to safely and correctly
install the products featured here. Specific installation guidance will be available with the product on delivery and on our website fisherpaykel.com
SPECIFICATION GUIDE | COMPACT CONVECTION-SPEED OVEN, 30" OM30NCTDX3, OM30NCTDB3
CAVITY DIMENSIONS
Cavity Dimensions
inch mm
A Minimum inside height of cavity
17 5/16 440
B Minimum inside width of cavity
28 1/2 724
C Minimum inside depth of cavity*
21 5/8** 550**
Recommened cabinet height
18 1/8 460
Recommened cabinet width
30 762
*Measured from front of chassis.
**Requires ventilation at the rear of the cavity.
ISOMETRIC VIEW
PRODUCT DIMENSIONS
Product Dimensions inch mm
A Overall height
18 458
B Overall width
29 7/8 758
C Chassis height
17 1/8 435
D Chassis width
28 3/8 720
E Chassis depth
21 7/16 545
F Front panel thickness
13/16 20
Depth with door fully open*
12 5/8 320
*Measured from front of control panel.
ISOMETRIC VIEW
b
a
c
d
a
b
c
SPECIFICATIONS
Model Number
OM30NCTDX3
30" Series 7 Contemporary Compact
Convection-Speed Oven - Brushed Silver Glass
OM30NCTDB3
30" Series 7 Contemporary Compact
Convection-Speed Oven- Black Glass
Electrical
Supply 208 or 240 V, 60 Hz
Service 20 A
Connection Hard wired 78 3/4" (2000mm)
Capacity
Total Oven
capacity
1.7cu ft (49L)
e
f
Ventilation
required
<< CONTENTS
