900MM/1100MM WALL MOUNTED FOLDABLE
WORKBENCHES
MODEL NO: APWMW01, APWMW02
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure Health & Safety, and local authority regulations are adhered to when assembling and using this product.
9 Locate in a suitable area where it will not be an obstruction.
9 Keep the general area clean, uncluttered and ensure there is adequate lighting.
WARNING! Mount on a at and solid wall such as breeze block that is strong enough to hold the weight of the workbench and
anything placed upon/within it.
9 A generic xing kit has been supplied but please ensure only ttings suitable for the type of wall this unit is mounted to are used.
8 DO NOT attempt to wall mount the workbench on your own. Obtain assistance or use manual handling equipment.
9 Wall mount the workbench at such a height that minimises the risk of injury when used.
9 Keep children and unauthorised persons away from the work area.
8 DO NOT use the workbench for any purpose other than that for which it is designed.
8 DO NOT site the workbench out of doors.
8 DO NOT get the workbench wet or use in damp or wet locations or areas where there is condensation.
8 DO NOT clean the workbench with any solvents or abrasives which may damage the coated surface.
8 DO NOT overload the workbench.
9 Ensure that the workbench is properly and rmly assembled and installed before loading it.
2. INTRODUCTION
Wall mounted foldable workbench ideal for garages and workshops where space is at a premium. Heavy-duty hammered metal workbench with
100kg capacity. Supplied with 600mm wall mount bracket and hardware pack. Back panel pegboard design compatible with Sealey TTS Hooks
with a 10cm deep gap for tool storage. Lockable design for added security of contents within. Also features two cable and plug grommet holes
either side for corded tools or powerbar. Overall size: 914 x 620 x 560mm.
3. SPECIFICATION
Model No.: ...........................................................APWMW01
Overall Size (W x D x H):
Overall Size Open: .................................. 914 x 620 x 560mm
Overall Size Closed: .................................914 x 80 x 560mm
Workbench Size: ....................................... 914 x 470 x 30mm
4. CONTENTS
Refer to
instructions
Wear protective
gloves
Model No.: ...........................................................APWMW02
Overall Size (W x D x H):
Overall Size Open: ................................1100 x 670 x 610mm
Overall Size Closed: ...............................1100 x 80 x 610mm
Workbench Size: .....................................1100 x 520 x 30mm
APWMW01, APWMW02 Issue 2 (F) 24/08/23
Original Language Version
© Jack Sealey Limited
5. ASSEMBLY
Mark wall as below
Drill into the wall
Pay attention to the distance
between the holes
Mark
Distance from the
centre of the holes
Step 1
Step 2
Step 3
Wall
APWMW01, APWMW02 Issue 2 (F) 24/08/23
Original Language Version
© Jack Sealey Limited
Step 4
Step 5
Step 6
B x 1
P1 x 4
P2 x 4
Table
top
A
2 Press the
box down
B
Wall
Open body
APWMW01, APWMW02 Issue 2 (F) 24/08/23
Original Language Version
© Jack Sealey Limited
Step 7
Always lock the worktop after it
has been folded up, in order to
prevent it falling open.
APWMW01, APWMW02 Issue 2 (F) 24/08/23
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic
Equipment (WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact
your local solid waste authority for recycling information.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts
without prior notice.
IMPORTANT: No Liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 60 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
