WALL MOUNTED FOLDING MOTORCYCLE
SHELTER
MODEL NO: MCTS
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
8 This is a temporary structure and is not recommended as a permanent structure.
9 Choose your shelter’s location carefully. Check for overhead utility lines, branches, etc. DO NOT install near roofs or other structures that
may shed snow, ice or excessive run-off onto your shelter. Keep away from electrical wires!
9 Have an overview of all parts before attempting installation. Make sure all components are available.
8 DO NOT use this product in environments for which it is not intended (i.e. extreme cold, high winds, extreme heat, heavy rainfall, etc).
9 Always wear safety glasses when assembling this product. Wear gloves when working with tubing to prevent cuts or abrasions.
WARNING! Anchors must be used with all shelters. Covers should NOT be installed until it has been properly anchored to the ground.
9 Proper anchoring and keeping cover tight and free of snow and debris, is the responsibility of the consumer. Damages caused by
improper anchoring are not covered under warranty.
WARNING! Keep all ame and heat sources away from the shelter fabric. The fabric will burn if left in continuous contact with a ame
source.
8 DO NOT use open ames or cooking or heating devices inside or in close proximity to the product, including all types of stoves, gas
heaters, gas lanterns, citronella torches, mosquito coils, etc.
WARNING! In order to reduce risk of burning and avoid damage, DO NOT:- cook, smoke, refuel or use any open flame devices in or
around the shelter, store flammable liquids (gasoline, kerosene, propane, etc.) in the shelter,operate gas powered equipment in or around
the shelter.
9 Keep open ames a safe distance away from the shelter.
8 DO NOT use hard-edged tools or instruments, such as rakes or shovels, to remove snow. These can cause punctures to the cover.
8 NEVER start the engine of any vehicle or machine inside a closed shelter. Ensure that there is adequate ventilation for starting
engines and for any work with paints, cleaners, etc.
8 DO NOT use bleach, alkaline or harsh detergents for cleaning. Doing so will damage the polycarbonate material. Soap and warm
water are recommended.
9 This temporary shelter is intended to offer protection from damages caused by the sun, light rain, light snow, tree sap, bird and animal
excrement. DO NOT use it to shield goods from high winds, heavy snow or ice storms. Only use it for its intended use.
8 DO NOT assemble in strong winds.
2. INTRODUCTION
Fixed to a wall or fence this shelter offers an extra layer of protection to your motorcycle. It can be assembled in a matter of minutes,
and for a fraction of the cost of a permanent xture such as a shed or brick outbuilding. Constructed using a breglass frame and PVC
coated 300D polyester canopy. This design ensures your motorcycle, moped, bicycle or mobility scooter; remains protected from the
wind and rain. Designed in a way that the rain water doesn’t collect or gather on the hood. Simple assembly with ve breglass poles
through the sleeves, and use the eyelets to x the shelter to a fence, wall or outbuilding. Seven pegging loops and metal pegs are
provided to x the bottom edge of the shelter, if sited on soft ground.
3. SPECIFICATION
4. ASSEMBLY
Quick and easy to assemble. Just slide the ve breglass poles through the sleeves and insert the steel D-Ring “hinge pins”
into the ends of the rods at either end. The eyelets/grommets around the back secure your Sealey MCTS 90 degrees to the
fence, wall, or shed. The clever rear wind block panel has a horizontal row of ve brass xing eyelets along the lower edge.
This allows you to use a Sealey MCTS on fences or walls as low as 115 cm (3 feet, 5½”). Wall plugs and screws are included.
The Sealey MCTS cover has big smooth curves, which encourage rain and snow to run off. The front of the Sealey MCTS
simply lifts up to provide full, instant access. Toggle and loop straps let you fold it up and x it, out of
the way when not in use. There are seven pegging loops, so if you site your Sealey MCTS on soft ground, you can use the
pegs (metal stakes) provided to x it down.
Refer to
instruction
manual
MCTS Issue:1 13/11/24
Original Language Version
© Jack Sealey Limited
Wear eye
protection
Wear
protective
gloves
MODEL NO MCTS
Dimensions (L x W x H) H: 1700 x W: 2500 x D: 1700mm
Nett Weight 3.48kg
In practice, however, the weight of the hood holds it down sufciently and it doesn’t generally tend to lift, even in the wind.
This clever motorcycle cover can be packed away in minutes when not required and you can take it with you when you move.
MCTS Issue:1 13/11/24
Original Language Version
© Jack Sealey Limited
fig.
1
fig.
2
Securing screw holes to
attach to wall
Rods
D-Rings
Stowage bag
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts
without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
