TRIKE/3 MOTORCYCLE GARAGE SHELTER
2100 X 3800 X 1900MM
MODEL NO: STSXL
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS &
CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO
SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE
FOR FUTURE USE.
1. SAFETY
NOTE: this is a temporary structure and is not recommended as a permanent
structure.
9 This shelter is intended to oer protection from damages caused by the sun, light
rain, light snow, tree sap, bird and animal excrement.
8 DO NOT use the shelter to shield goods from high winds, heavy snow or ice
storms. Only use it for its intended purpose.
9 Choose the shelter’s location carefully.
9 Check for overhead utility lines, branches, etc.
8 DO NOT install near roofs or structures that may shed snow, ice or excessive run-o.
8 DO NOT install near electrical wires.
9 Have an overview of all parts before attempting installation. Make sure all
components are available.
8 DO NOT use this product in environments for which it is not intended (i.e. extreme
cold, high winds, extreme heat, heavy rainfall, etc).
9 Always wear safety glasses when assembling this product.
9 Wear gloves when working with tubing to prevent cuts or abrasions.
WARNING! Anchors must be used with alI shelters. DO NOT install the cover untiI
the shelter is properly anchored to the ground.
NOTE: proper anchoring and keeping the cover tight and free of snow and debris
is the responsibility of the consumer. Damages caused by improper anchoring are
not covered under warranty.
WARNING! Keep all ame and heat sources away from the shelter. The fabric will
burn if left in continuous contact with a ame.
8 DO NOT use open ames or cooking or heating devices inside or in close
proximity to the product, including all types of stoves, gas heaters, gas lanterns,
citronella torches, mosquito coils, etc.
WARNING! In order to reduce risk of burning and avoid damage:
8 DO NOT cook, smoke, refuel or use any open ame devices in or around the shelter.
8 DO NOT store ammable liquids (gasoline, kerosene, propane, etc.) in the shelter.
8 DO NOT operate gas powered equipment in or around the shelter.
8 DO NOT use hard-edged tools or instruments, such as rakes or shovels, to
remove snow. These can cause punctures to the cover.
▲ DANGER! DO NOT start the engine of any vehicle or machine inside a closed
shelter. Ensure that there is adequate ventilation for starting engines and for any
work with paints, cleaners, etc.
8 DO NOT use bleach, alkaline or harsh detergents for cleaning. Doing so will
damage the material. Soap and warm water are recommended.
2. INTRODUCTION
Made from durable 600D Oxford PU coated anti-scratch material to protect vehicle’s paintwork. Rigid powder coated tubular frame with
hinged opening for easy-access. Side vents allows increased ventilation while still keeping vehicle protected from the elements. Includes
anchor points for fixing shelter to driveway/ground (fixings included). Padlock hasp for increased security when canopy is closed (two
combination locks included).
3. SPECIFICATION
Model No: ............................................................STSXL
Dimensions (L x W x H):.............3800 x 2100 x 1900mm
Nett Weight: ............................................................ 28kg
Size: ............................................................................ XL
Refer to
instructions
STSXL Issue 2 17/01/2025
Original Language Version
© Jack Sealey Limited
Wear protective
gloves during
assembly
Wear eye
protection during
assembly
CONTENTS
4. ASSEMBLY
Check all parts and xings before assembling the shelter.
IMPORTANT: appropriate xings must be used to secure the shelter. A heavy weight may be required on the support bar (D), in
combination with suitable expansion screws.
Connect angled bars (C) onto the side frames (A) & (B), leaving one
angled bar (C) detached. Fix support bar (D) onto the side frames (A)
& (B). Attach locking bar (J) onto the side frames (A) & (B) using the
xings provided. Slide rings (K) onto the frame. Leave in the unlocked
position shown when assembling the shelter.
STEP 3
Position side frames (A) & (B) on the ground with the shortest tubes
facing the front.
STEP 1
Attach supports (E) onto the side frames (A) & (B), using the xings
provided.
STEP 2
STEP 6
STEP 4
Fold the frame backwards, making sure the fabric covers the frame.
Let the bottom unconnected tubes pass through the fabric sleeves.
STEP 5
Pass the last angled bar (C) through the fabric sleeve and connect it
to the side frames (A & B).
Wrap the frame with the velcro sewed on the fabric cover at the
locations shown.
Original Language Version
© Jack Sealey Limited
STSXL Issue 2 17/01/2025
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations.
REGISTER YOUR
PURCHASE HERE
STSXL Issue 1 08/01/2025
Original Language Version
© Jack Sealey Limited
5. MAINTENANCE
5.1. CLEANING
9 Clean with soap and warm water.
8 DO NOT use bleach, alkaline or harsh detergents for cleaning. Doing so will damage the material.
8 DO NOT use hard-edged tools or instruments, such as rakes or shovels, to remove snow. These can cause punctures to the cover.
5.2. STORAGE
5.2.1. Remove the supports (E) to enable the cover to lay at on the ground.
5.2.2. Tie all tubes together so the shelter can be moved for storage.
