Dewalt 61110S DXPW3425E-S 3400 PSI Pressure Washer User Manual

If you have questions or

comments, contact us.

1-877-362-4271

Instruction Manual

Gas Pressure Washer

final page size: 8.5 x 5.5 in

Fig. A

Components

Panel assembly

Nozzle holder

Professional spray gun

Wheel

Quick‑connect spray wand

Frame

Engine dipstick/oil plug

Engine switch

Starter grip

Engine

Choke control

Fuel valve lever

Gas cap

Handle assembly

High pressure hose

High pressure pump

Battery box

Engine start connector

Water sensing device

nOTE: Photographs and line drawings used in this manual are for reference only and do not represent a specific

model.

Fig.B

Fig.C

Fig.E

Fig.F

Fig.K

Fig.M

Fig.G

Fig.L

Fig.H

Fig.I

Fig.J

Fig.D

Fig.N

Fig.O

Fig.Q

Fig.R

Fig.W

Fig.Y

Fig.S

Fig.X

Fig.T

Fig.U

Fig.V

Fig.P

Fig.Z Fig.AA

Fig.BB

English (original instructions)

QUICK SETUP GUIDE



WARNING: To reduce the risk of injury, read the pressure washer instruction manual and the engine instruction manual

before operating pressurewasher.

install the handle

Place handle onto frame, depress the snap buttons, and

slide the handle assembly onto the frame until snap

buttons snap intoplace.

Attach Battery Box Mounting Bracket

Align the holes in the battery box mounting bracket with

the holes in the frame. Push the saddle bolt through

the bracket and frame, secure with knob. Tighten

knobsecurely.

Add/Check Oil

The engine is shipped without oil. Before starting engine,

add the oil provided. Check oil level prior to each use. Refer

to Engine Owner’s Manual for completeprocedure.

Add gasoline

In a well ventilated outdoor area add fresh, high quality,

unleaded gasoline with a pump octane rating of 86or

higher. Do not overfill. Wipe up spilled fuel before

starting the engine. Refer to Engine Owners Manual for

completeprocedure.

IMPORTANT: Ethanol Shield

™

(sold separately) is a fuel stabilizer that helps eliminate and prevent ethanol related

problems in power equipment. Follow the instructions on the container and add to thegasoline.



DANGER:

• Never run engine indoors or in enclosed, poorly ventilated areas. Engine exhaust contains carbon monoxide, an

odorless and deadlygas.

• Risk of fluid injection and laceration. When using the high‑pressure setting, DO NOT allow the high‑pressure spray to

come in contact with unprotected skin, eyes or with any pets or animals. Serious injury willoccur.



WARNING: Do not allow the unit to run for more than two minutes without the gun trigger being pulled. This

could cause overheating and damage to the pump. When the temperature inside the pump rises too high, the

thermal relief valve will open and release a spray of water from the pump to lower the internal temperature.

The valve will thenclose.



WARNING: To reduce the risk of electric shock or explosion, do not short circuit the battery terminals or charge in a

sealed container. Keep sparks and flame away. Do not use metal tools for connections and keep metal objects away from

the battery terminals. Metal objects can make a connection from one terminal to another. Shorting the battery terminals

together can cause sparks, burns, or afire.

BATTERY SET UP GUIDE

Open batterybox.

Connect the red wire to the

"+" (positive) terminal and

the black wire to the "-"

(negative) terminal.

Close battery box

Connect the engine start

connector to the battery box

Connect the bullet connector

to the engine startconnector.

Complete battery

boxassembly

QUICK START GUIDE

Connect garden hose to Pump

Thread the garden hose to the

pumpinlet.

Connect high Pressure hose

to Pump

Connect the high pressure hose to the

pumpoutlet.

Connect high Pressure hose

to spray gun

Thread the other end of the high

pressure hose to the spray gun.

Connect spray Wand to

spraygun

Thread the spray wand into the end of

the spraygun.

Connect QC nozzles to

sprayWand

Pull quick connect coupler back and

insert nozzle. Release quick connect

coupler and twist nozzle to make sure

it is secure incoupler.

Turn Water Faucet

CompletelyOn

Do not run the unit without water

supply connected and turned on. Use

Cold WaterOnly.

nOTE: Unit equipped with water

sensing device, shuts down

machine if the presence of water is

notdetected.

Release Air from system

Release all air from pump and high

pressure hose by depressing trigger

until a steady stream of water is

present. Approximately 30seconds.

Place the fuel valve lever in the

Onposition.

Verify the Engine switch is

turned to the On Position

30 S

Move the choke to the

ClOsEDposition

Press the starter button OR pull

the Recoil starter grip

Press the starter button for 3seconds

to start engine OR Pull the recoil

starter grip to start theengine.Repeat

asneeded.

Move the choke to the

OPEnposition



WARNING: This Guide is not a substitute for reading the operator’s manual. User must read and understand operator’s

manual before using thisproduct.

Engine

Refer to the engine instruction manual for location and operation of other enginecontrols.



WARNING: Read all safety warnings and all

instructions. Failure to follow the warnings and

instructions may result in electric shock, fire and/or

seriousinjury.



WARNING: Never modify the product or any part of

it. Damage or personal injury couldresult.

WARNING: To reduce the risk of injury, read the

instructionmanual.

IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT THIS

Definitions: Safety Alert Symbols andWords

This instruction manual uses the following safety alert

symbols and words to alert you to hazardous situations and

your risk of personal injury or propertydamage.



DANGER: Indicates an imminently hazardous

situation which, if not avoided, will result in death or

seriousinjury.



WARNING: Indicates a potentially hazardous

situation which, if not avoided, could result in death

or seriousinjury.



CAUTION: Indicates a potentially hazardous situation

which, if not avoided, may result in minor or

moderateinjury.



(Used without word) Indicates a safety

relatedmessage.

NOTICE: Indicates a practice not related to

personal injury which, if not avoided, may result in

propertydamage.

Important Safety Instructions



DANGER: Carbon Monoxide. Using an engine

indoors can kill you in minutes. Engine exhaust

contains high levels of carbon monoxide (CO),

a poisonous gas you cannot see or smell. You

may be breathing CO even if you do not smell

engineexhaust.



WARNING: This product and its exhaust contain

chemicals known to the State of California

to cause cancer, and birth defects and other

reproductiveharm.

• NEVER use an engine inside homes, garages,

crawlspaces or other partly enclosed areas. Deadly

levels of carbon monoxide can build up in these

areas. Using a fan or opening windows and doors

does NOT supply enough freshair.

• ONLY use outdoors and far away from open

windows, doors and vents. These openings can

pull in engineexhaust.

• Even when the engine is used correctly, CO

may leak into your home. ALWAYS use a

battery‑powered or battery backup CO alarm

in your house. Read and follow all directions

for CO alarm before using. If you feel sick,

dizzy or weak at anytime, move to fresh air

immediately. See a doctor. You could have carbon

monoxidepoisoning.



WARNING: Do not operate this unit until you

read this instruction manual and the engine

instruction manual for safety, operation and

maintenanceinstructions.



WARNING: When using this product basic

precautions should always be followed, including

thefollowing:

1 . Read all instructions before using theproduct.

2 . To reduce the risk of injury, close supervision is

necessary when a product is used nearchildren.

3 . Know how to stop the product and bleed

pressures quickly. Be thoroughly familiar with

thecontrols.

4 . tay alert–watch what you aredoing.

5 . Do not operate the product when fatigued or

under the influence of alcohol ordrugs.

6 . Keep operating area clear of allpersons.

7 . Do not overreach or stand on unstable

support. Keep good footing and balance at

alltimes.

8 . Follow the maintenance instructions speciﬁed in

themanual.



DANGER: RISK OF INJECTION OR SEVERE

INJURY. KEEP CLEAR OF NOZZLE. DO NOT

DIRECT DISCHARGE STREAM AT PERSONS.

THIS PRODUCT IS TO BE USED ONLY BY

TRAINEDOPERATORS.



WARNING: This product may not be equipped with a

spark‑arresting muffler. If the product is not equipped

and will be used around flammable materials or

on land covered with materials such as agricultural

crops, forest, brush, grass or other similar items, then

an approved spark arrester must be installed and

is legally required in the state of California. It is a

violation of California statutes section 130050and/

or sections 4442and 4443of the California Public

Resources Code, unless the engine is equipped with

a spark arrester, as defined in section 4442, and

maintained in effective working order. Spark arresters

are also required on some U.S. Forest Service land

and may also be legally required under other statutes

andordinances.



WARNING: This product and its exhaust can expose

you to chemicals including lead and lead compounds,

and carbon monoxide, which are known to the State

of California to cause cancer and birth defects or

other reproductive harm. For more information go to

www.P65Warnings.ca.gov.

SAVE THESE INSTRUCTIONS



DANGER: RISK OF EXPLOSION OR FIRE

WhAT CAn hAPPEn hOW TO PREVEnT iT

• Spilled gasoline

and it’s vapors can

become ignited from

cigarette sparks,

electrical arcing,

exhaust gases and hot

engine components

such as themuffler.

• Shut off engine and allow it

to cool before adding fuel

to thetank.

• Use care in filling tank to

avoid spilling fuel. Move

pressure washer away

from fueling area before

startingengine.

• Heat will expand

fuel in the tank

which could result in

spillage and possible

fireexplosion.

• Keep maximum fuel level

1/2" (12.7 mm) below

bottom of filler neck to

allow forexpansion.

• Operating the

pressure washer

in an explosive

environment could

result in afire.

• Operate and fuel

equipment in

well‑ventilated areas free

from obstructions. Equip

areas with fire extinguisher

suitable for gasolinefires.

• Materials placed

against or near the

pressure washer can

interfere with its

proper ventilation

features causing

overheating and

possible ignition of

thematerials.

• Never operate pressure

washer in an area

containing dry brush

orweeds.

• Muffler exhaust heat

can damage painted

surfaces, melt any

material sensitive to

heat (such as siding,

plastic, rubber, vinyl

or the pressure hose,

itself), and damage

liveplants.

• Always keep pressure

washer a minimum of

4' (1.2m) away from

surfaces (such as houses,

automobiles or live plants)

that could be damaged

from muffler exhaustheat.

• Improperly stored

fuel could lead to

accidental ignition.

Fuel improperly

secured could get

into the hands of

children or other

unqualifiedpersons.

• Store fuel in an OSHA

approved container, in a

secure location away from

workarea.

• Use of acids, toxic or

corrosive chemicals,

poisons, insecticides,

or any kind of

flammable solvent

with this product

could result in serious

injury ordeath.

• Do not spray

flammableliquids.

• Shorting the battery

terminals together

may cause burns or

afire.

• Keep battery away from

other metal objects like

paper clips, coins, keys,

nails, screws, or other small

metal objects that can

make a connection from

one terminal to another.



DANGER: RISK TO BREATHING (ASPHYXIATION

WhAT CAn hAPPEn hOW TO PREVEnT iT

• Breathing exhaust

fumes will cause

serious injury or

death! Engine

exhaust contains

carbon monoxide,

an odorless and

deadlygas.

• Operate pressure washer

in a well‑ventilated area.

Avoid enclosed areas such

as garages, basements,etc.

• Never operate unit in or

near a location occupied by

humans oranimals.

• Some cleaning fluids

contain substances

which could cause

injury to skin, eyes

orlungs.

• Use only cleaning fluids

specifically recommended

for high pressure washers.

Follow manufacturers

recommendations. Do not

use chlorine bleach or any

other corrosivecompound.



DANGER: RISK OF FLUID INJECTION AND

LACERATION

WhAT CAn hAPPEn hOW TO PREVEnT iT

• Your pressure

washer operates

at fluid pressures

and velocities high

enough to penetrate

human and animal

flesh which could

result in amputation

or other serious

injury. Leaks caused

by loose fittings or

worn or damaged

hoses can result in

injection injuries.

DO NOT TREAT

FLUID INJECTION

AS A SIMPLE CUT!

See a physician

immediately!

• Inspect the high pressure

hose regularly. Replace the

hose immediately if it is

damaged, worn, has melted

from contacting the engine,

or shows any signs of

cracks, bubbles, pinholes, or

other leakage. Never grasp

a high pressure hose that is

leaking ordamaged.

• Never touch, grasp or

attempt to cover a pinhole

or similar water leak on the

high pressure hose. The

stream of water IS under

high pressure and WILL

penetrateskin.

• Never place hands in front

ofnozzle.

• Your pressure

washer operates

at fluid pressures

and velocities high

enough to penetrate

human and animal

flesh which could

result in amputation

or other serious

injury. Leaks caused

by loose fittings or

worn or damaged

hoses can result in

injection injuries.

DO NOT TREAT

FLUID INJECTION

AS A SIMPLE CUT!

See a physician

immediately!

(CONTINUED)

• Direct spray away from self

andothers.

• Make sure hose and fittings

are tightened and in good

condition. Never hold

onto the hose or fittings

duringoperation.

• Do not allow hose to

contactmuffler.

• Never attach or remove

wand or hose fittings while

system ispressurized.

• When using replacement

lances or guns with this

pressure washer, do not use

a lance and/or lance/gun

combination that is shorter

in length than what was

provided with this pressure

washer as measured from

the nozzle end of the lance

to the guntrigger.

• Injuries can result

if system pressure

is not reduced

before attempting

maintenance

ordisassembly.

• To relieve system pressure,

shut off engine, turn off

water supply and pull

gun trigger until water

stopsflowing.

• Use only accessories

rated equal to or higher

than the rating of the

pressurewasher.



DANGER: RISK OF INJURY FROM SPRAY

WhAT CAn hAPPEn hOW TO PREVEnT iT

• High‑velocity fluid

spray can cause

objects to break,

projecting particles at

highspeed.

• Always wear

ANSI‑approved Z87.1 safety

glasses. Wear protective

clothing to protect against

accidentalspraying.

• Never point wand at or

spray people oranimals.

• Light or unsecured

objects can become

hazardousprojectiles.

• Always secure trigger

lock when wand is not

in service to prevent

accidentaloperation.

• Never permanently

secure trigger in pull‑back

(open)position.



DANGER: RISK OF UNSAFE OPERATION

WhAT CAn hAPPEn hOW TO PREVEnT iT

• Unsafe operation of

your pressure washer

could lead to serious

injury or death to you

orothers.

• Do not use chlorine

bleach or any other

corrosivecompound.

• Become familiar with the

operation and controls of

the pressurewasher.

• Keep operating area

clear of all persons, pets

andobstacles.

• Do not operate the product

when fatigued or under

the influence of alcohol or

drugs. Stay alert at alltimes.

• Never compromise

the safety features of

thisproduct.

• Do not operate machine

with missing, broken or

unauthorizedparts.

• Never leave wand

unattended while unit

isrunning.

• If proper starting

procedure is not

followed, engine can

kickback causing

serious hand and

arminjury.

• If engine does not start

after two pulls, squeeze

trigger of gun to relieve

pump pressure. Pull starter

cord slowly until resistance

is felt. Then pull cord rapidly

to avoid kickback and

prevent hand or arminjury.

• The spray gun/wand

is a powerful cleaning

tool that could look

like a toy to achild.

• Keep children away from

the pressure washer at

alltimes.

• Reactive force of spray

will cause gun/wand

to kickback, and could

cause the operator to

slip or fall or misdirect

the spray. Improper

control of gun/wand

can result in injuries

to self andothers.

• Do not overreach or stand

on an unstablesupport.

• Do not use pressure washer

while standing on aladder.

• Grip gun/wand firmly with

both hands. Expect the gun

to kickback whentriggered.



DANGER: RISK OF INJURY OR PROPERTY

DAMAGE WHEN TRANSPORTING OR STORING

WhAT CAn hAPPEn hOW TO PREVEnT iT

• Fuel or oil can leak or

spill and could result

in fire or breathing

hazard. Serious injury

or death can result.

Fuel or oil leaks will

damage carpet, paint

or other surfaces in

vehicles ortrailers.

• Oil could fill the

cylinder and damage

the engine if the

unit is not stored or

transported in an

uprightposition.

• If pressure washer is

equipped with a fuel

shut‑off valve, turn the

valve to the off position

before transporting to

avoid fuel leaks. If pressure

washer is not equipped

with a fuel shut‑off valve,

drain the fuel from tank

before transporting.

Only transport fuel in an

OSHA‑approved container.

Always place pressure

washer on a protective

mat when transporting to

protect against damage to

vehicle from leaks. Always

transport and store unit in

an upright position.Remove

pressure washer from

vehicle immediately upon

arrival at yourdestination.



DANGER: RISK OF ELECTRICAL SHOCK

WhAT CAn hAPPEn hOW TO PREVEnT iT

• Spray directed at

electrical outlets or

switches, or objects

connected to an

electrical circuit,

could result in a fatal

electricalshock.

• Unplug any electrically

operated product before

attempting to clean

it. Direct spray away

from electric outlets

andswitches.



DANGER: RISK OF CHEMICAL BURN

WhAT CAn hAPPEn hOW TO PREVEnT iT

• Use of acids, toxic or

corrosive chemicals,

poisons, insecticides,

or any kind of

flammable solvent

with this product

could result in serious

injury ordeath.

• Do not spray acids,

gasoline, kerosene, or any

other flammable materials

with this product. Use only

household detergents,

cleaners and degreasers

recommended for use with

pressurewashers.

• Wear protective clothing

to protect eyes and

skin from contact with

sprayedmaterials.



WARNING: RISK OF BURSTING

WhAT CAn hAPPEn hOW TO PREVEnT iT

• Over inflation of

tires could result in

serious injury and

propertydamage.

• Use a tire pressure gauge

to check the tires pressure

before each use and while

inflating tires; see the tire

sidewall for the correct tire

pressure.

nOTE: Air tanks, compressors

and similar equipment used to

inflate tires can fill small tires

similar to these very rapidly.

Adjust pressure regulator on

air supply to no more than the

rating of the tire pressure. Add

air in small increments and

frequently use the tire gauge to

prevent overinflation.

• High‑velocity fluid

spray directed

at pneumatic

tire sidewalls

(such as found

on automobiles,

trailers and the like)

could damage the

sidewall resulting in

seriousinjury.

• On pressure washers rated

above 1600psi (11032kPa)

use the widest fan spray

(40º nozzle) and keep

the spray a minimum of

8" (200 mm) from the

pneumatic tire sidewall. Do

not aim spray directly at

the joint between the tire

andrim.



WARNING: RISK OF HOT SURFACES

WhAT CAn hAPPEn hOW TO PREVEnT iT

• Contact with hot

surfaces, such as

engines exhaust

components, could

result in seriousburn.

• During operation, touch

only the control surfaces of

the pressure washer. Keep

children away from the

pressure washer at all times.

They may not be able to

recognize the hazards of

thisproduct.



WARNING: RISK OF INJURY FROM LIFTING

WhAT CAn hAPPEn hOW TO PREVEnT iT

• Serious injury

can result from

attempting to lift too

heavy anobject.

• The pressure washer is too

heavy to be lifted by one

person. Obtain assistance

from others beforelifting.



CAUTION: Risk of Injury. Disconnect battery ground

[Negative (–)] Terminal beforeservicing.

SAVE THESE INSTRUCTIONS FOR

FUTURE USE

INSTALLATION

Pressure Washer Assembly (Fig.A, C, G–J)

1. Place handle assembly

14

onto frame

6

, depress the

snap buttons, and slide the handle assembly onto the

frame until snap buttons snap intoplace.



CAUTION: Risk of personal injury. Avoid placing

hands between handle and frame when assembling

to preventpinching.

2. Align the holes in the battery box mounting bracket

20

with the holes in the frame

6

. Push the saddle bolt

21

through the bracket

20

and frame, secure with

knob

22

. Tighten knobsecurely.

3. Attach high pressure hose

15

to spray gun. Make sure

it issecure.

4. Connect wand

5

to spray gun. Make sure connection

issecure.

5. Place the nozzle holder

2

onto the panel assembly

1

and push each nozzle holder intoplace.

6. Remove the five colored quick‑connect nozzles from the

plastic bag and insert them into correct grommet on the

nozzle holder. Nozzles are color coded to match colored

nozzles on panelassembly.

nOTE: The pump on this unit is maintenance free and

requires no oil. If there is a problem with the pump, contact

our Customer Service Group as soon aspossible.



WARNING: Risk of bursting. Use a tire pressure gauge

to check the tires pressure before each use and while

inflating tires; see the tire sidewall for the correct

tirepressure.

nOTE: Air tanks, compressors and similar equipment used

to inflate tires can fill small tires similar to these very rapidly.

Adjust pressure regulator on air supply to no more than the

rating of the tire pressure. Add air in small increments and

frequently use the tire gauge to prevent overinflation.

Connecting the Battery (Fig.C–F)



WARNING: To reduce the risk of electric shock or

explosion, do not short circuit the battery terminals or

charge in a sealed container. Keep sparks and flame

away. Do not use metal tools for connections and keep

metal objects away from the battery terminals. Metal

objects can make a connection from one terminal to

another. Shorting the battery terminals together can

cause sparks, burns, or afire.

Use only a 12V 6.5Ah/21 WPC battery.

Before using the electric start feature, the battery must be

fully charged and the starter cable on the pressure washer

connected to the connection port on the battery. See

Charging the Battery in the Maintenancesection.

To Connect the Battery (Fig.C–F)

1. Open the battery box

17

2. Connect the red wire to the "+" (positive)

23

terminal

and the black wire to the "‑" (negative)

24

terminal.

3. Close battery box

4. Connect the engine start connector

18

to the

batterybox.

5. Connect the bullet connector

25

to the engine start

connector

18

6. FigureF shows the complete battery boxassembly.

OPERATION

Pressure Adjustments (Fig.K)

The pressure setting is preset at the factory to achieve

optimum pressure and cleaning. To lower the pressure, follow

theseinstructions.

1. Back away from the surface to be cleaned. The further

away you are, the less the pressure will be on the surface

to becleaned.

2. Change to the 40˚ nozzle (white). This nozzle delivers a

less powerful stream of water and a wider spray pattern.

Refer to spray Wandnozzles.

3. This pressure washer's high pressure pump is equipped

with an adjustable unloader feature that allows the

pressure setting to be adjusted. To lower the pressure, turn

the pressure control knob on the pump counterclockwise

to the desired pressure. To return the pump pressure to

the factory setting, turn the pressure control knob on the

pump clockwise until itstops.

NOTICE: DO NOT try to tum pressure regulator knob

past the built‑in stop or damage to the pump willresult.

NOTICE: DO NOT overtighten the pressure control knob.

If overtightened the knob COULD break and result in

immediate loss of water pressure and costly repairs to

theunit.

NOTICE: DO NOT attempt to increase pump pressure. A

higher pressure setting than the factory set pressure may

damage thepump.

Spray Wand Nozzles (Fig.A, L)

The nozzles for the spray wand are stored in the nozzle

holder

2

on the panel assembly

1

. Colors on the panel identify

nozzle location and spray pattern. Refer to the following chart

to choose the correct nozzle for the job to beperformed.

nozzle

Color

spray Pattern Uses surfaces***

Red

0˚

powerful

pinpoint for

very intense

cleaning

metal or

concrete;

DO NOT use on

wood

Yellow

15˚

intense

cleaning of

small areas

metal, concrete

or wood

green

intense

cleaning of

larger areas

metal, concrete

or wood

White

covers wide

areas of

cleaning

metal, concrete,

wood or vinyl

Black

low pressure

applies

cleaning

solutions

metal, concrete,

wood or vinyl

*** NOTICE: The high pressure spray from your pressure

washer is capable of causing damage to surfaces such

as wood, glass, automobile paint, auto striping and

trim, delicate objects such as flowers and shrubs. Before

spraying, check the item to be cleaned to assure yourself

that it is strong enough to resist damage from the force

ofspray.

Changing Nozzles on Spray Wand

(Fig.L)



DANGER: Risk of fluid injection. Do not direct

discharge stream toward persons, unprotected skin,

eyes or any pets or animals. Serious injury willoccur.



WARNING: Flying objects could cause risk of serious

injury. Do Not attempt to change nozzles while

pressure washer is running. Turn engine off before

changingnozzles.

1. Pull quick‑connect coupler back and insertnozzle.

2. Release quick‑connect coupler and twist nozzle to make

sure it is secure incoupler.



WARNING: Flying object could cause risk of serious

injury. Ensure nozzle is completely inserted in

quick‑connect socket and quick‑ connect collar is fully

engaged (forward) before squeezing guntrigger.

Chemicals and Cleaning Solvents

Applying chemicals or cleaning solvents is a

low‑pressureoperation.

nOTE: Use only soaps and chemicals designed for pressure

washer use. Do not usebleach.

To Apply Chemicals and Solvents

(Fig.M)

1. Press chemical hose

26

onto barbed fitting located

near high pressure hose connection of pump asshown.

2. Place the other end of chemical hose with filter into

the container holding chemical/cleaning solution.

nOTE:For every 10gallons (38 liters) of water pumped

1gallon (3.8 liters) of chemical/cleaning solution will

beused.

3. Install low‑pressure (black) nozzle into quick connect

fitting of spray wand, refer to spray Wand nozzles.

nOTE: Chemicals and soaps will not siphon if the black

soap nozzle is not installed on the spraywand.

4. After use of chemicals, place chemical hose into

container of clean water and draw clean water through

chemical injection system to rinse system thoroughly

NOTICE: Risk of property damage. Failure to do so

could cause damage to the pump. Pumps damaged

due to chemicals will not be covered underwarranty.

Starting



WARNING: To reduce the risk of injury, read the

pressure washer instruction manual and the engine

instruction manual before starting pressurewasher.



DANGER: Risk of fluid injection and laceration.

When using the high pressure setting, DO NOT allow

the high pressure spray to come in contact with

unprotected skin, eyes, or with any pets or animals.

Serious injury willoccur.

• Your washer operates at fluid pressures and

velocities high enough to penetrate human and

animal flesh, which could result in amputation or

other serious injury. Leaks caused by loose fittings

or worn or damaged hoses can result in injection

injuries. DO NOT TREAT FLUID INJECTION AS A

SIMPLE CUT! See a physician immediately!



DANGER: Carbon Monoxide. Using an engine

indoors can kill you in minutes. Engine exhaust

contains high levels of carbon monoxide (CO),

a poisonous gas you cannot see or smell. You

may be breathing CO even if you do not smell

engineexhaust.

• Breathing exhaust fumes will cause serious

injury or death! Engine exhaust contains carbon

monoxide, an odorless and deadlygas.

• Operate pressure washer in a well‑ventilated

area. Avoid enclosed areas such as garages,

basements,etc.

• Never operate unit in or near a location occupied

by humans oranimals.



WARNING: Risk of fire, asphyxiation and burning.

Never fill fuel tank when engine is running or hot. Do

not smoke when filling fueltank.

• Never fill fuel tank completely. Fill tank to

1/2" (12.7 mm) below bottom of filler neck to

provide space for fuel expansion. Wipe any fuel

spillage from engine and equipment before

startingengine.

• DO NOT let hoses come in contact with very hot

engine muffler during or immediately after use

of your pressure washer. Damage to hoses from

contact with hot engine surfaces will NOT be

covered bywarranty.

NOTICE: NEVER pull water supply hose to move

pressure washer. This could damage hose and/or

pumpinlet.

• DO NOT use hot water, use cold wateronly.

• Never turn water supply off while pressure washer

engine is running or damage to pump willresult.

• DO NOT stop spraying water for more than two

minutes at a time. Pump operates in bypass mode

when spray gun trigger is not pressed. When the

temperature inside the pump rises too high the

thermal relief valve (

27

, Fig.N) will open and

release a gush of water in an effort to lower the

temperature inside the pump. The thermal relief

valve will then close. If pump is left in bypass mode

for more than two minutes internal components

of the pump can bedamaged.

Start‑up Procedure (Fig.A, O–V)

nOTE: The pressure washer has both electric start and

recoil start capabilities available. A nominal 12volt sealed

rechargeable lead‑acid battery is supplied that complies

with non‑spillable battery regulations. The unit can be can

be operated in any position withoutleakage.

nOTE: The pressure washer is shipped with the battery

cable disconnected. The battery cable must be connected

before the electric start feature will operate. For initial

battery connection, see Connecting the Battery in the

Assemblysection.

nOTE: For best results, make sure your battery is

fullycharged before starting, see Charging the Battery in

the Maintenancesection.

1. In a well‑ventilated outdoor area, add fresh, high‑quality,

unleaded gasoline with a pump octane rating of 86or

higher. Do not overfill. Wipe up spilled fuel before

starting the engine. Refer to engine instruction manual

for correctprocedure.

IMPORTANT: Ethanol Shield™ (sold separately) is a fuel

stabilizer that helps eliminate and prevent ethanol

related problems in power equipment. Follow the

instructions on the container and add to thegasoline.

NOTICE: Use of fuels with greater than 10% ethanol

are not approved for use in this product per EPA

regulations and will damage the unit and void

thewarranty.

2. Check engine oil level. Refer to the engine instruction

manual for correctprocedure.

3. Connect the water hose to the water source. Turn the

water source on to remove all air from the hose. When

a steady stream of water is present, turn the water

sourceoff.

4. Verify the filter screen

28

is in water inlet of pump. The

convex side facesout.

NOTICE: Failure to use an inlet screen filter may cause

damage to pump components and voidwarranty.

5. Connect the cold water source

31

to pump inlet.

nOTE: Water source must provide a minimum of

5gallons per minute at 20psi (138kPa).



WARNING: To reduce the possibility of contamination

always protect against backflow when connected to a

potable watersystem.

6. Connect high pressure hose

15

to pumpoutlet.

7. If applying a chemical or cleaning solution, refer to

Chemicals and CleaningSolvents.

8. Turn the water sourceon.

NOTICE: Risk of property damage. Failure to do so

could cause damage to thepump.

9. Remove all air from the pump and high pressure hose

by depressing trigger until a steady stream of water

ispresent.

10. Turn the engine ON/OFF switch

8

to the ONposition.

11. Place the fuel valve lever

12

in the ONposition.

12. If the engine is cold, move the choke

11

to the CLOSED

position asshown.

13. Electric start- Press the starter button 

32

for

3seconds to startengine.

nOTE: For best results, make sure your battery is

fullycharged before starting, see Charging the Battery in

the Maintenancesection.

Recoil start- Pull the starter gripslowly.



WARNING: Risk of unsafe operation. Pull starter

grip slowly until resistance is felt. Then pull starter

grip

9

rapidly to avoid kickback and prevent hand or

arminjury.

nOTE: Do not allow the starter grip to snap back. Return it

gently byhand.



WARNING: Risk of unsafe operation. If engine does

not start after two pulls, squeeze trigger of gun to

relieve pump pressure. Pull starter cord slowly until

resistance is felt. Then pull cord rapidly to avoid

kickback and prevent hand or arminjury.

nOTE: If the oil level in the engine is low, the engine will

not start. If the engine does not start, check the oil level and

add oil asneeded.

14. As the engine warms up, move the choke to the

openposition.

15. Depress trigger on gun to start waterflow.



WARNING: Do not allow the unit to run for

more than two minutes without the gun trigger

being pulled. This could cause overheating and

damage to the pump. When the temperature

inside the pump rises too high, the thermal relief

valve will open and release a spray of water from

the pump to lower the internal temperature. The

valve will thenclose.



WARNING: Risk of unsafe operation. Stand on a

stable surface and grip gun/wand firmly with both

hands. Expect the gun to kickback whentriggered.

16. Release trigger to stop waterflow.



DANGER: Risk of injury from spray. Engage the

trigger lock

29

when gun is not in use to prevent

accidentalspraying.

17. Adjust spray for the task being performed by changing

quick connect nozzle. Refer to spray Wandnozzles.

Shutting Down (Fig.W, X)

1. If chemicals were applied, place the chemical hose

into a container of clean water and draw clean

water through chemical injection system to rinse

systemthoroughly.

NOTICE: Risk of property damage Failure to do so

could cause damage to thepump.

2. Place the engine ON/OFF switch

8

to the OFFPosition.

3. Place the fuel valve lever

12

in the OFFposition.

NOTICE: Risk of property damage. Never turn water

supply off while pressure washer engine is running or

damage to pump willresult.

4. Turn water sourceoff.

5. Pull trigger on spray gun to relieve any water pressure in

hose or spraygun.

6. Refer to Storage for proper storageprocedures.

MAINTENANCE



WARNING: Risk of burning. When performing

maintenance, you may be exposed to hot surfaces,

water pressure or moving parts that can cause serious

injury ordeath.



WARNING: Risk of fire. Always disconnect, spark

plug wire, let the engine cool and release all water

pressure before performing any maintenance

or repair. The engine contains flammable fuel.

Do not smoke or work near open flames while

performingmaintenance.



CAUTION: Risk of Injury. Disconnect battery ground

[Negative (–)] Terminal beforeservicing.

To ensure efficient operation and longer life of your pressure

washer, a routine maintenance schedule should be prepared

and followed. If the pressure washer is used in unusual

conditions, such as high temperatures or dusty conditions,

more frequent maintenance checks will berequired.

Engine

Consult the engine instruction manual for the manufacturer's

recommendations for any and allmaintenance.

nOTE: The pressure washer frame is equipped with an oil

drain hole to help make changing the engine oileasier.

Pump

The pump on this unit is maintenance free and requires

no oil. If there is a problem with the pump, contact our

Customer Service Group as soon aspossible.

Battery

Charging the Battery (Fig.E, AA, BB)

To keep the battery fully charged and ready for use, connect

the battery charger to keep the battery while storing the

pressurewasher.

nOTE: The battery charger provided should only be used

with the a 12V 6.5Ah/21 WPC sealed lead acid battery

supplied with this pressurewasher.

1. Plug the battery charger

33

into a standard household

120V receptacle. Make sure the household power

supply is 120V, 60Hz, AConly.

2. Disconnect the engine start connector

18

on the

pressure washer from the battery box

17

3. Connect the battery charger

33

to the connection port

on the battery box

17

. The light on the battery charger

will illuminate red while the battery ischarging.

nOTE: The battery will become slightly warm to the touch

while charging. This is normal and does not indicate a

problem. When battery is fully charged, the red light will

turngreen.

nOTE: If the light does not illuminate, the battery main‑

tainer fuse may need to be replaced. Check the fuse and

replace ifneeded.

4. When the battery is fully charged and ready to use,

connect to the pressure washer:

a. Disconnect the batterycharger.

b. Reconnect the engine start connector

18

on the

pressure washer to the connection port on the

battery box

17

, ensure the plug is fullyseated.

Replacing the Battery (Fig.C–F)



WARNING: To reduce the risk of electric shock or

explosion, do not short circuit the battery terminals or

charge in a sealed container. Keep sparks and flame

away. Do not use metal tools for connections and keep

metal objects away from the battery terminals. Metal

objects can make a connection from one terminal to

another. Shorting the battery terminals together can

cause sparks, burns, or afire.

1. Disconnect the engine start connector

18

on the

pressure washer from the battery box

17

2. Open the battery box

17

3. Disconnect the battery:

‑ Disconnect the black wire from the battery’s nega‑

tive (–)terminal.

‑ Disconnect the red wire from the battery’s positive

(+)terminal.

4. Remove the old battery and dispose of according to

local and state regulations. Always abide by the safety

warnings provided with thebattery.

5. Open the battery box and place the new battery into

the battery box and follow the Connecting the Battery

instructions underAssembly.

Nozzle Cleaning (Fig.Y, Z)

If the nozzle becomes clogged with foreign materials,

such as dirt, excessive pressure may develop. If the nozzle

becomes partially clogged or restricted, the pump pressure

will pulsate. Clean the nozzle immediately using the nozzle

kit supplied and the following instructions:

1. Shut off the pressure washer and turn off the

watersupply.

2. Pull trigger on gun handle to relieve any waterpressure.

3. Disconnect the spray wand from thegun.

4. Remove the high pressure nozzle from the spray wand.

Remove any obstructions with the nozzle cleaning

tool

30

provided and back flush with cleanwater.

5. Direct water supply into spray nozzle to back flush

loosened particles for 30seconds.

6. Reassemble the nozzle to thewand.

7. Reconnect spray wand to gun then turn on

watersupply.

8. Start pressure washer and place spray wand into high

pressure setting totest.

To Clean the Water Inlet Filter (Fig.O)

This filter screen

28

should be checked periodically and

cleaned ifnecessary.

1. Remove the filter screen

28

by grasping the end and

removing it from water inlet ofpump.

2. Clean filter by flushing it with water on bothsides.

3. Reinsert filter into water inlet of pump. Convex side

facesout.

nOTE: Do not operate pressure washer without filter

properlyinstalled.

STORAGE

Engine

Consult the engine instruction manual for the

manufacturer's recommendations forstorage.

To Prevent Fuel‑Related Problems

1. Add Ethanol Shield™ fuel stabilizer following the

manufacturer’s instructions. When adding a gasoline

stabilizer, fill the fuel tank with fresh gasoline. If

only partially filled, air in the tank will promote fuel

deterioration during storage. If you keep a container

of gasoline for refueling, be sure that it contains only

freshgasoline.

2. After adding a gasoline stabilizer, run the engine

outdoors for 10minutes to be sure that treated gasoline

has replaced the untreated gasoline in thecarburetor.

3. Turn the fuel valve to the OFFposition.

4. Continue to run the engine until it stops from the lack of

fuel in the carburetor fuel bowl. Running time should be

less than 3minutes.

Pump

The manufacturer recommends using DeWALT

Pump Guard

or equivalent when storing the unit for more than 30 days

and/or when freezing temperatures are expected.

DeWALT

Pump Guard is environmentallyfriendly.

nOTE: Using pump guard helps provide proper lubrication

to the internal seals of the pump regardless of temperature

or environment.

NOTICE: Risk of property damage. Use only

DeWALT

Pump Guard or equivalent. Other products could be

corrosive and/or contain alcohol which may cause

pumpdamage.

1. Turn off pressure washer and disconnect hoses

frompump.

2. Unscrew bottle valve from Pump Guard bottle and

remove seal.

3. Screw bottle valve back ontobottle.

4. Attach bottle to water inlet ofpump.

5. Squeeze bottle to inject contents intopump.

6. With ignition switch off, simultaneously pull starter rope

and squeeze bottle. Repeat until protector fluid exits

pump outlet. nOTE: This step may require twopeople.

Pressure Washer

1. Drain all water from high pressure hose, coil it and store

it in cradle of the pressure washerhandle.

2. With nozzle pointed down and the spray gun and wand

in a vertical position, squeeze trigger to drain all water

from spray gun and wand. Store in gunholder.

3. Store chemical hose so it is protected fromdamage.



CAUTION: Risk of personal injury. Avoid placing

hands between handle and frame when assembling

to preventpinching.

NOTICE: Risk of property damage. Always store and

transport unit in an uprightposition.

Battery Removal and Preparation

forRecycling



WARNING: To reduce the risk of electric shock or

explosion, do not short circuit the battery terminals.

Keep sparks and flame away. Do not use metal tools

for connections and keep metal objects away from

the battery terminals. Metal objects can make a

connection from one terminal to an‑ other. Shorting

the battery terminals together can cause sparks,

burns, or afire.



WARNING: Upon removal, cover the battery’s

terminals with heavy‑ duty adhesive tape. Do not

attempt to destroy or disas‑ semble battery or remove

any of its components. Lead acid batteries must be

recycled or disposed of properly. Also, never touch

both terminals with metal objects and/ or body parts

as short circuit may result. Keep away from children.

Failure to comply with these warnings could result in

fire and/or seriousinjury.

To preserve natural resources, please recycle or dispose of

batteries properly. This product uses lead

acid batteries. Local, state or federal laws

may prohibit disposal of batteries in

ordinarytrash.

Consult your local waste authority

for information regarding available recycling and/or

disposaloptions.

Accessories



DANGER: Risk of fluid injection. When using

replacement spray wands or guns with this pressure

washer, DO NOT use a spray wand and/or spray gun/

wand combination that is shorter in length than what

was provided with this pressure washer as measured

from the nozzle end of the wand to the guntrigger.



WARNING: Since accessories, other than those

offered by

DeWALT, have not been tested with this

product, use of such accessories with this tool could be

hazardous. To reduce the risk of injury, only DeWALT

recommended accessories should be used with

thisproduct.

Recommended accessories for use with your tool are

available at extra cost from your local dealer or authorized

service center. If you need assistance in locating any

accessory, please contact

DeWALT, call 1‑877‑362‑4271.

Service Information

Please have the following information available for all

service calls: Model Number ___________________

Serial Number _____________________________

Date and Place of Purchase ____________________

Repairs



WARNING:To assure product SAFETY and

RELIABILITY, repairs, maintenance and adjustment

(including brush inspection and replacement, when

applicable) should be performed by a

DeWALT factory

service center or a DeWALT authorized service center.

Always use identical replacementparts.

To find the nearest service center, please contact

DeWALT, call

1‑877‑362‑4271.

Limited Warranty

The manufacturer of this product agrees to repair or replace

designated parts that prove defective within the warranty

period listed below at the manufacturer’s sole discretion.

Specific limitations/extensions and exclusions apply.

This warranty covers defects in material and workmanship

and not parts failure due to normal wear, depreciation,

abuse, accidental damage, negligence, improper use,

maintenance, water quality or storage. To make a claim

under the terms of the warranty, all parts said to be

defective must be retained and available for return upon

request to a designated Warranty Service Center for

warranty inspection.

The judgments and decisions of the

manufacturer concerning the validity of warranty claims

are final.

These warranties pass through to the end user and are

non‑transferable. As a factory authorized and trained

Warranty Service Center, the factory will honor the terms

of all component warranties and satisfy claims of the

appropriate warrantyprovisions.

Normal wear items include, but are not limited to, valves

and seals, which are not covered by thiswarranty.

This warranty replaces all other warranties, express or

implied, including without limitation any warranties of

merchantability or fitness for a particular purpose and all

such warranties are hereby disclaimed and excluded by the

manufacturer. The manufacturer’s warranty obligation is

limited to repair and replacement of defective products as

provided herein and the manufacturer shall not be liable for

any further loss, damages, or expenses – including damages

from shipping, accident, abuse, acts of God, misuse, or

neglect. Neither is damage from repairs using parts not

purchased from the manufacturer or alterations performed

by non‑factory authorized personnel. Failure to install and

operate equipment according to the guidelines put forth in

the instruction manual shall void warranty.

This warranty does not cover the following:

machines used for rental purposes, damage resulting from

shipping (claims must be filed with freighter), accident,

abuse, act of God, misuse, or neglect. Neither is damage

from repairs or alterations performed by non‑factory

authorized personnel or failure to install and operate

equipment according to the guidelines put forth in the

instruction manual.

The manufacturer will not be liable to any persons

for consequential damage, for personal injury, or for

commercial loss.

Responsibility of Original Purchaser (initialUser):

• To process a warranty claim on your

DeWALT pressure

washer, report the concern to 1-877-362-4271 or

[email protected] for authorization and

direction to the nearest authorized service centre in

yourarea.

• Retain original cash register sales receipt as proof of

purchase for warrantywork.

• Use reasonable care in the operation and maintenance

of the product as described in the Owners Manual(s).

Warranty Does not Apply to Failures Due to:

• Merchandise sold as reconditioned, used as rental

equipment, used for commercial purposes or

commercial applications, or floor or displaymodels.

Freight damage

• Damage due to chemical deterioration, scale build up,

rust, corrosion or thermal expansion

• Freeze damage

• Damage caused by parts or accessories not obtained

from an authorized dealer or not approved by

themanufacturer.

• Normal wear of moving parts or components affected

by movingparts.

Engine and Emissions Control system

Covered by engine manufacturer warranty. See

enginemanual.

high Pressure Pump (defectsin material and

workmanship)

Three (3) years from date of purchase

Frame (defectsin material and workmanship)

Five (5) years from date ofpurchase.

Accessories (Defectsin Material and Workmanship)

Includes nozzles, hoses, spray guns, wands, tires, feet

Ninety (90) days from date ofpurchase.

Glossary

Bypass mode: Allows water to re‑circulate within pump

when the gun trigger is notpulled.

Chemical hose: Feeds cleaning agents into the

pump to mix with the water. Refer to Chemicals and

Cleaningsolvents.

Chemical injection system: Mixes cleaners or cleaning

solvents with water to improve cleaningeffectiveness.

Choke control: Opens and closes carburetor chokevalve.

CU: Cleaning Units. GPM multiplied by psi. (GPM x PSI = CU)

Fuel valve lever: Opens/closes connection between fuel

tank andcarburetor.

gPM*: Gallons Per Minute. The unit of measure for the flow

rate ofwater.

Psi*: Pounds per Square Inch. The unit of measure for water

pressure. Also used for air pressure, hydraulic pressure,etc.

* Complies with CETA Performance Standard CPC‑100.

kPa (kilopascal): Metric pressure measurement.

1kilopascal equal 1000pascals.

Quick-connect spray wand: Allows the user to quickly

change out high pressure nozzles. Refer to spray

Wandnozzles.

Thermal relief valve: When the temperature inside the

pump rises too high the valve will open and release a gush

of water in an effort to lower the temperature inside the

pump. The valve will thenclose.

Water supply: All pressure washers must have a source of

water. The minimum requirements for a water supply are

20psi (138kPa) and 5gallons perminute.

Troubleshooting Guide

This section provides a list of the more frequently encountered malfunctions, their causes and corrective actions. The

operator or maintenance personnel can perform some corrective actions, and others may require the assistance of a qualified

FNA technician or yourdealer.

Problem Code

Engine will not start/Engine starts and dies 1, 2, 3, 4, 5, 6, 7, 8, 32 (refer to the engine's instruction manual for further engine troubleshooting)

No or low pressure (initial use) 9, 10, 11, 12, 13, 14, 15, 16

Will not draw chemicals 16, 17, 18, 19, 20, 21

No or low pressure (after period of normal use) 22, 23, 24

Water leaking at gun/spray wand connection 25, 26

Water leaking at pump 25, 26, 27, 28

Pump Pulsates 12

Electric start feature not working 29, 30, 31

Troubleshooting Codes

CODE POssiBlE CAUsE POSSIBLE SOLUTION

1 No fuel. Add fuel.

2 Low oil. Add required amount of oil.

3 Pressure builds up after two pulls on the recoil starter or

after initial use.

Squeeze gun trigger to relieve pres sure.

4 Choke lever in the NO CHOKE position. Move choke to the CHOKE po si tion.

5 Spark plug wire not attached. Attach spark plug wire.

6 Engine ON/OFF switch in OFF po si tion. Place engine ON/OFF switch in ON position.

CODE POssiBlE CAUsE POSSIBLE SOLUTION

7 Choke lever in the CHOKE position on a hot engine or an

engine that has been exposed to thermal heat for a long

period of time.

Move choke to the NO CHOKE po si tion.

8 Fuel valve CLOSED. Move the fuel valve lever to the OPEN position.

9 Spray wand not in high pressure. See Spray Wand Nozzles under Operation.

10 Low water supply. Water supply must be at least 5 GPM @ 20 psi (138 kPa).

11 Leak at high pressure hose fitting. Repair leak. Apply sealant tape if necessary.

12 Nozzle obstructed. See Nozzle Cleaning under Maintenance.

13 Water filter screen clogged. Remove and clean filter. See To Clean the Water Inlet Filter

under Maintenance.

14 Air in hose. Turn off the engine, then the water source. Disconnect the

water source from the pump inlet and turn the water source

on to remove all air from the hose. When there is a steady

stream of water present, turn water source off. Recon nect

water source to pump inlet and turn on wa ter source. Squeeze trigger to

re move re main ing air.

15 Choke lever in the CHOKE position. Move choke to the NO CHOKE po si tion.

16 High pressure hose is too long. Use high pressure hose under 100 feet (30.48 m). Lengthen water supply

hose instead of high pressure hose.

17 Spray wand not in low pressure. See Spray Wand Nozzles under Operation.

18 Chemical filter clogged. Clean filter.

19 Chemical screen not in cleaning solution. Make sure end of chemical hose is fully submerged into cleaning solution.

20 Chemical too thick. Dilute chemical. Chemical should be the same consistency as water.

21 Worn seal or packing. Have parts cleaned or replaced by authorized service center.

22 Chemical build up in chemical injector. Have replaced by an authorized service center.

23 Worn or obstructed valves. Have replaced by authorized service center.

24 Worn unloader piston. Have replaced by authorized service center.

25 Worn or broken o‑ring. Check and replace.

26 Loose hose connection. Tighten.

27 Piston packings worn. Have replaced by authorized service center.

28 Pump head or tubes damaged from freezing. Have replaced by authorized service center.

29 Engine start connector is not connected. Connect engine start connector.

30 Battery is not charged. Charge the battery. See Charging the Battery under Maintenance.

31 Battery positive and negative battery wires disconnected. Connect the positive and negative battery wires.

32 Unit equipped with water sensing device. Presence of

water is not detected in the pump.

Turn water faucet completely on.

The FNA Group, Inc.,7152 99th Street Pleasant Prairie, WI 53158

The following are trademarks for one or more D

eWALT power tools: the yellow and black color scheme, the “D” shaped air

intake grill, the array of pyramids on the handgrip, the kit box configuration, and the array of lozenge‑shaped humps on the

surface of thetool.

eWALT

, GUARANTEED TOUGH

and the yellow and black color scheme are trademarks the DeWALT Industrial Tool Co., used

underlicense.

The FNA Group, Inc.,7152 99th Street Pleasant Prairie, WI 53158, a licensee of D

eWALT Industrial Tools

Dewalt 61110S DXPW3425E-S 3400 PSI Pressure Washer

Product's Documents

User Manual

Specifications

Dewalt 61110S Questions and Answers
