Pet Blow Dryer
User Manual
ON-D139
Packaging List
Hair dryer main unit x 1 Blowing pipe x 1
03 04 05
07
08 09 10 11
Product Installation
Operation Guidelines
Operating Instructions
Cleaning and Maintenance
1. Power Connection
Palm-shaped
air nozzle x 1
Wide flat air
nozzle x 1
Flat air
nozzle x 1
Round air
nozzle x 1
2. Power-On Switch
3. Adjust the Wind Speed
4. Adjust the Temperature
5. Drying a Pet's Fur 6. Rotate counterclockwise
to turn off the power
Attention:
*For the health of your pet, it is recommended to regularly clean the filter
components and blowing components. Please disconnect the power before
cleaning. The main unit is not waterproof, so please use a cloth to wipe it
clean.
*Please allow the filter components and filter cartridges to dry in a shady
and ventilated area before reinstalling them to prevent water ingress that
may cause electric shock or damage to the machine.
Fault Diagnosis
Fault Descriptions
Handling Measures
Customer Support
WE ARE READY TO HELP
Product Specifications
Rated Power
Rated Voltage
Rated Frequency
Wind Speed Adjustment
Main Unit Size
Power Cord Length
Net Weight of Product
For Pets
US: 1700W / UK: 2000W
US: AC120V / UK&EU: AC 220V-240V
US: 60Hz / UK&EU: 50Hz
Stepless Speed Regulation
321* 170*224mm
2M
3.8KG
Cats / Dogs
Oneisall offers a standard 2-year warranty. If you have any issues with your Oneisall
product, please do not hesitate to contact us. Be sure to include your proof of
purchase, model number, and any relevant photos or videos in your message to
expedite the process. Our Oneisall support team is available 7 days a week and will
respond to your inquiry within 24 hours. Thank you for choosing Oneisall.
Please note that the Oneisall warranty does not apply to used products or
purchases made from unauthorized sellers. It's important to be aware that the
warranty also does not cover consumable parts such as blades, guards, filters,
brushes, and similar items. These parts may require regular replacement or
maintenance.
suppor[email protected]
+1 877-522-8578（US) Mon-Fri 8am-5pm(PST)
www.oneisall.com
@Oneisall Official
06
GPSR Product Information
Catalogue
Safety Warning
Product Precautions
Packaging List
Product Installation
Operating Instructions
Operation Guidelines
Cleaning and Maintenance
Fault Diagnosis
Product Specifications
Customer Support
GPSR Product Information
01
02
03
03
04
05
07
08
09
10
11
oneisall support Tutorial Video
Instruction
manual x1
Installation of
air duct assembly
Install the air nozzle
Temperature & Speed Settings
Align the telescopic air duct with the
unlock position of the main unit and
twist clockwise to lock it in place.
Select the appropriate nozzle for your
application; insert the nozzle into the
hose handle and install by twisting
clockwise to align the pads.
Heating
Setting Indicator
Mode Switch Button
Heating Key
Turn on the power
by rotating clockwise
Standard Edition
Hold the Handle Steadily
Turn on the power by rotating clockwise
1. Open the Filter Cover 2. Remove the Two Filter
Cartridges (Inner and Outer)
Rotate clockwise to increase speed, rotate counterclockwise to decrease speed.
7. Storage and Organization
Unplug the power source and organize the blowing components for storage
Press to turn on heating,
with two modes Available
Press repeatedly to cycle
through Warm Air, Hot Air, and
Heating Off
Press to automatically
cycle through Warm Air, Hot
Air, and Natural Air
Min Max
Wind speed decreases with
counterclockwise rotation
Use with an appropriate air nozzle
Indicator Light
Orange: Warm Air Mode
Red: Hot Air Mode
White: Heating Off
3. Clean the Filter Cartridges and Screen Accessories
Clean the filter cartridges and screen accessories with water or detergent, then place
them in a shady and ventilated area to dry
1. Unplug the power plug for 10 seconds, then plug it back in and
turn it on again.
2. Check if there is power in the power socket.
3. Check if the power socket and power cord are damaged.
4. If the machine malfunctions, please contact customer service
for after-sales support.
1. Unplug the power plug for 10 seconds, then plug it back in and
turn it on again.
2. Check if the power switch has been pressed to turn on the
machine.
3. Check if the wind speed setting is adjusted in the wrong
direction (counterclockwise).
4. If the machine malfunctions, please contact after-sales
customer service.
1. Unplug the power plug for 10 seconds, then plug it back in and
turn it on again.
2. Increase the wind speed setting.
3. Check if the air outlet/nozzle/air intake filter is blocked.
4. Check if there is obvious air leakage between the air duct/air
duct joint/nozzle joint.
5. Check if the working voltage of the machine is too low.
6. If the machine malfunctions, please contact after-sales
customer service.
1. After unplugging the power plug for 10 seconds, power it on
again.
2. Check if the heating setting is turned on
3. If the machine malfunctions, please contact after-sales
customer service.
1. Unplug the power plug for 10 seconds, then plug it back in and
power it on again.
2. Increase the heating setting.
3. Check if the ambient temperature for the machine is too low.
4. Check if the voltage of the working environment is too low for
the machine.
5. If the machine malfunctions, please contact after-sales
customer service.
Machine has no
response
The wind speed
cannot be adjusted
Low air
output speed
The machine does not
emit hot air
Low air output
temperature
1. Check if the filter cartridges and air intake components are
properly assembled or missing.
2. Check if there are any foreign objects that have been sucked
into the machine.
3. Check if the air inlet and outlet are blocked.
4. If the machine malfunctions, please contact after-sales
customer service.
1. Check if the connectors at both ends of the telescopic air duct
are tightened.
2. Inspect the air duct, connectors, and nozzles for any damage.
3. Verify that the nozzle connector and the machine's outlet
connector are installed according to the markings.
Significant noise or
abnormal sound
Obvious air
leakage
Tutorial Video
Promotional
Video
The wind speed increases
with the rotation angle.
Name: APEX CE SPECIALISTS LIMITED
Add: 6f East Union Street, Manchester, England, M16 9AE
Contact: Wells
Tel: +441616371080
E-Mail: Info@apex-ce.com
Name: Apex CE Specialists GmbH
Add: Grafenberger Allee 277-287,40237 Düsseldorf,DE
Contact Person: Wells Yan
Tel: +353212066339
E-Mail: Info@apex-ce.de
GPSR-Manufacturer info:
Business Name: chuzhouguanyidianzishangwuyouxiangongsi
Manufacturer Address: CN, 239200, anhui, chuzhoushi, laianxian, xinanzhenqingliuxilu,
taixinxiangzhangyuan1dong1danyuan2403shi
Tel: +86 130 4980 3796
E-Mail: oneisallofficial@hotmail.com
Product Name: Pet Blow Dryer
Brand: Oneisall
Product Model: MAS-520
Input: US:AC 120V~60HZ / UK&EU:AC 220V-240V~50HZ
Power: US:1700W / UK&EU:2000W
Made in China
Safety Warning
Read Before Use: Before using the pet blow dryer, read all safety and operating
instructions.
Supervision: This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
Cord Management:If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to avoid a
hazard.
This product must be used with the required rated voltage and frequency;
Please do not use this product near fabrics or flammable objects, flammable gases,
heat sources, fire sources, or other high-temperature environments to avoid
accidents;
During operation, avoid blocking the air intake and outlet with fingers or other
objects. Make sure to clean it after use to prevent buildup of grease or other
residues;
Please clean the air inlet regularly to ensure smooth air intake without any obstruc-
tion;
Absolutely do not leave while the hair dryer is running. When the use is completed or
there is a power outage during use, please turn off the power first and then unplug
the power cord from the outlet;
Do not connect any accessories of other brands to this hair dryer to avoid
accidents;
Please inspect the power cord regularly. If the plug, power cord, or the hair dryer
itself is damaged, please do not use it anymore;
Please do not use thinners, benzene, or other solvents to clean the hair dryer;
If there are any abnormalities or malfunctions during use, please refer to the
troubleshooting table in this manual and do not disassemble the device yourself;
Keep it away from water and avoid getting the machine wet. Do not use this device
outdoors or on damp surfaces;
For added protection, it is recommended to install a Residual Current Device (RCD)
with a rated residual operating current not exceeding 30mA in the electrical circuit
supplying the bathroom. Consult with the RCD installer;
When using in the bathroom, please unplug the power cord after use, as there is still
a risk of coming into contact with water even when the product is powered off;
The label on the hair dryer indicates "Do not use while bathing or showering," do not
use it near water-filled containers such as bathtubs or washbasins, and do not use it
with wet hands.
The product body is not washable or suitable for direct sunlight. After disconnecting
the power, it can be wiped with a dry towel;
During the drying process, if the pet feels uncomfortable, you can adjust the
temperature and wind speed down. If the pet still feels uncomfortable, please stop
using it immediately.
01 02
Product Precautions
Do not use this product in excessively damp environments or in water to prevent
electric shock;
Please do not touch or plug/unplug the power plug with wet hands to prevent
electric shock;
Before each use, ensure that the air outlet hose and each connector are tightened
properly to avoid significant air leakage that affects the performance;
Before use, please hold the handle of the air outlet hose firmly and then adjust the
air speed for use to prevent the air outlet nozzle from swaying around;
Due to the high air speed of this hair dryer, avoid directly blowing the air nozzle
towards people or objects during use to prevent discomfort or danger;
Before use is completed, please turn off the wind speed first and wait for the
machine to stop blowing before putting down the air nozzle and air hose;
When the product is working, please do not block the air outlet and air inlet to
prevent the motor from overheating and burning;
Please clean the product filter only when the power is disconnected;
The product body is not washable or suitable for direct sunlight. After disconnecting
the power, it can be wiped with a dry towel;
During the drying process, if the pet feels uncomfortable, you can adjust the
temperature and wind speed down. If the pet still feels uncomfortable, please stop
using it immediately.
Pet Blow Dryer
User Manual
ON-D139
Model: MAS-520
Any problems you have, please contact us :
support@oneisall.com
ON-D139
oneisall support Tutorial Video
MAS-520说明书
尺寸:135X195mm
材质:125g铜版
印刷:一专一黑印刷
折 叠 方 式 ：骑 马 钉
PANTONE 2018C
135 mm
195 mm
Model: MAS-520
