Quick Setup Guide
MFC-J1360DW / MFC-J1365DW / MFC-J1410DW
MFC-J4355DW / MFC-J4555DW
D038TL001-00
USA/CAN
Version 0
The latest manuals are available at the Brother
support website: support.brother.com/manuals
Continue to the next column
Read the Product Safety Guide first, then read this Quick Setup Guide for the correct installation procedure.
a
Unpack the machine and
check the components
Remove the protective tape or film covering the
machine and the supplies.
b
Load plain Letter paper in the
paper tray
Manuals in Spanish for this model are available at support.brother.com/manuals.
Manuales en Español para este modelo están disponibles en
support.brother.com/manuals.
If you have followed the instructions in the printed Quick Setup Guide included with your
machine and selected step 5-B "Set up from the machine's control panel", go directly to step
5-B in this guide.
NOTE
• The illustrations in this guide may not match your model
exactly, but the steps are the same for each model.
• The components may differ depending on your country.
• Save all packing materials and the box in case you need to
ship your machine.
• If you use a wired connection, you must purchase the correct
interface cable for the interface you want to use. (Supported
models only)
USB cable: Use a USB 2.0 cable (Type A/B) that is no more
than 6 feet (2 meters) long (included in some countries).
Ethernet (Network) cable: Use a straight-through Category
5 (or greater) twisted-pair cable for 10BASE-T or
100BASE-TX Fast Ethernet Network (not included).
2
Continue to the next column
c
Connect the telephone line
cord (models with the fax
function only)
Insert the telephone line cord into the socket
marked LINE.
For more information on using the fax feature, see
the Online User's Guide.
d
Connect the power cord
The machine powers on automatically.
(For certain models only) If you are prompted to
select your country or language, follow the LCD
instructions.
e
Choose your setup method
Follow this step only if you are using this
machine as a fax machine.
MFC-J1360DW / MFC-J1365DW
MFC-J1410DW
MFC-J4355DW / MFC-J4555DW
2
1
Choose the setup method according to your
environment.
Set up using mobile app or computer software
(Recommended)
«
Set up from the machine's control panel
(Mac users who cannot use a mobile device for
setup should select this method.)
«
Set up using mobile app or
computer software
Go to the website applicable to your setup method:
NOTE
You can use your machine with multiple devices. Use one
of the setup methods in this step to download the
machine's software onto other devices that you want to
use.
5-A
5-B
Recommended
5-A
setup.brother.com
Set up with your mobile device
* The mobile device must be connected to Wi-Fi
®
.
Set up with your computer
(Windows only)
https://
setup.brother.com
3
Continue to the next column
Follow the steps below according to your model.
1. Press when the QR Code screen appears.
2. Press when the [Set up from machine]
screen appears.
1. Press [Setup without app/software]
when the QR Code screen appears.
2. Press [Yes] when the [Setup without app/
software] screen appears.
f
Install the starter ink
cartridges
Open the ink cartridge cover.
(The illustrations in this guide may not match your
model exactly, but the steps are the same for
each model.)
Quickly shake just the black ink cartridge
horizontally 15 times as shown, before inserting it
into the machine.
Follow the LCD instructions to install the ink
cartridges.
After installing all of the four ink cartridges, close
the ink cartridge cover.
Check the LCD messages to continue the setup.
When the ink preparation message appears,
follow the LCD instructions to perform the initial
ink system cleaning.
Cleaning can take a few minutes, and you can
perform the next step during this time.
g
Set the date and time
Follow the LCD instructions to set the date and
time.
Set up from the machine's
control panel
MFC-J1360DW / MFC-J1365DW
MFC-J4355DW
MFC-J1410DW / MFC-J4555DW
MFC-J4355DW / MFC-J4555DW
5-B
NOTE
The first time you install the ink cartridges, the machine will use
extra ink to fill the ink delivery tubes. This is a one-time process
that enables high-quality printing.
4
Continue to the next column
h
Set firmware update
notifications
When the firmware update information screen
appears, configure your firmware settings.
i
Check the print quality
When the initial ink system cleaning has finished,
print the Print Quality Check Sheet:
Press .
Press [OK].
The machine prints the Print Quality Check Sheet.
On the machine's LCD, select the images that
closely match the image for each color on the
Print Quality Check Sheet, and then restart the
cleaning procedure, if required.
j
Adjust the print alignment
(recommended)
To adjust the print alignment before using your
machine, print the Adjustment Sheet:
When the paper adjustment message appears,
press and follow the LCD instructions.
When the paper adjustment message appears,
press [Start] and follow the LCD instructions.
There is a black circle located in the top left corner
of the sheet.
MFC-J1360DW / MFC-J1365DW
MFC-J4355DW
MFC-J1410DW / MFC-J4555DW
12 34
MFC-J1360DW / MFC-J1365DW
MFC-J4355DW
MFC-J1410DW / MFC-J4555DW
5
Continue to the next column
Place the Adjustment Sheet face down on the
scanner glass, making sure the black circle is in
the top left corner of the scanner glass, as shown.
Follow the LCD instructions to adjust the
alignment.
When finished, remove the Adjustment Sheet
from the scanner glass.
k
Confirm the machine setup
completion
Follow the LCD instructions if displayed, and then
confirm the machine setup completion.
l
Connect your computer or
mobile device to your
machine (if needed)
Visit the following website from your computer or
mobile device or scan the code below to install the
software:
Make sure your machine and mobile device are
connected to the same network.
https://
setup.brother.com
setup.brother.com
NOTE
MFC-J1360DW / MFC-J1365DW
MFC-J1410DW
For USB connection, locate the correct port on the
side of the machine, as shown.
6
© 2024 Brother Industries, Ltd. All rights reserved.
For detailed machine information and product specifications, see the Online User's Guide at support.brother.com/manuals.
D038TL001-00
Now you are ready to print or scan from this machine.
Complete the steps in the "Manual wireless setup"
section, if necessary.
Manual wireless setup
Find the SSID (Network Name) and Network Key
(Password) on your wireless access point/router.
1. Go to your machine, and press or Wi-Fi on
the panel.
2. Press OK to select [Find Wi-Fi Network].
The [Enable WLAN?] message appears on
the LCD.
3. Press to select Yes.
4. Select the SSID (Network Name) for your
access point/router and enter the Network Key
(Password).
1. Go to your machine and press > [Find
Wi-Fi Network] > [Yes].
2. Select the SSID (Network Name) for your
access point/router and enter the Network Key
(Password).
For more information, see Enter Text on Your Brother
Machine in the Online User's Guide.
When the wireless setup is successful, the LCD displays
[Connected].
Setup Finished
Important Notice for Network Security:
The default password to manage this machine's settings is
located on the back of the machine and marked “Pwd”. We
recommend immediately changing the default password to
protect your machine from unauthorized access.
MFC-J4355DW / MFC-J4555DW
For USB connection or wired network connection
(certain models only), locate the correct port (based
on the cable you are using) inside the machine, as
shown.
MFC-J1360DW / MFC-J1365DW
MFC-J4355DW
If you cannot find this information, ask your network
administrator or wireless access point/router
manufacturer.
MFC-J1410DW / MFC-J4555DW
If you cannot find this information, ask your network
administrator or wireless access point/router
manufacturer.
SSID: ●●●●●
Network Key: ●●●●●
