Support and E-Warranty Certificate www.vevor.com/support
ELECTRIC CITRUS JUICER
INSTRUCTION MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and dose not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL: YC-301S
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
ELECTRIC CITRUS JUICER
- 2 -
IMPORTANT ASSURANCE
When using electrical appliances, basic safety precautions should always be
followed including the following:
1. Read all instructions.
2. THIS PRODUCT IS INTENDED FOR HOUSEHOLD USE ONLY. Do not use this
appliance for anything other than its intended use. Do not use outdoors.
3. This appliance can be used by children aged 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning the use of
the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
4. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning the
use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
5. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
6. Switch off the appliance and disconnect from the supply before changing
accessories or approaching parts that move in use.
7. Always disconnect the appliance from the supply if it is left unattended and
before assembling, disassembling or cleaning.
8. This appliance shall not be used by children. Keep the appliance and its cord
out of reach of children.
9. To protect against electrical shock, do not submerge the appliance or allow the
power cord to come into contact with water or any other liquid.
10. DO NOT operate this appliance on or near any hot surfaces (such as a gas or
electric burner or in a heated oven).
11. DO NOT remove the container from the motor base while the appliance is in
operation.
12. DO NOT expose containers to extreme temperature changes.
13. DO NOT overfill.
14. DO NOT operate the appliance empty.
- 3 -
15. DO NOT press too hard on the cone or run for longer than 3 minutes - you may
damage your juicer.
SAVE THESE INSTRUCTIONS
PARTS
1 dust cover
2 cone
3 strainer
4 juice leakage
5 power unit
SPECIFICATIONS
Rated voltage
120V～
Rated frequency
60Hz
- 4 -
OPERATION INSTRUCTIONS
Before plugging in
Make sure your electricity supply is the same as the one shown on the underside
of the machine.
Before using it for the first time
1 Wash the parts: see ‘cleaning’.
2 Wrap any excess cord around the bracket on the underside of the power unit .
To use your citrus juicer
1 Place the juice collector onto the power unit, hold the handle and turn until it
matches well .
2 Put the strainer inside the juice Collector until it matches well , then add the
cone .
3 Cut the fruit in half. Then press each half down onto the cone and the
juicer will operate automatically. Press operating time not exceeding 10 seconds.
4 To stop the juicer lift the fruit from the cone.
5 To pour the juice, remove the cone and strainer from the juice collector
and pour using the pouring lip.
6 . When juicing large quantities, empty the strainer regularly to prevent the
build up of pulp and seeds. Empty the juice collector as required.
CLEAN AND MAINTENANCE
. Always switch off, unplug and dismantle before cleaning.
. Replace the dust cover after use.
power unit
Rated power
100W
- 5 -
. Wipe with a damp cloth, then dry.
other parts
. Wash in hot soapy water, then dry.
. Alternatively, they can be washed on the top rack of your dishwasher.
TROUBLESHOOTING
If any irregularities are found during the operation of the appliance, read the table
below to identify the cause and to find a solution to the problem.
Fault
phenomenon
Analysis of causes
Fault resolution
After connecting
the power supply,
turn on the switch,
but this product
cannot work.
1. The power plug is not
plugged in properly
2. The outlet is in poor
contact
3. The internal cable of
the main unit is off or the
circuit board is damaged.
1. Plug the power plug
back in again
2. Replace the power
socket and try again
When this product
is used initially, the
motor smells
terrible.
This is not an abnormal
occurrence
If the product still emits
this odor after repeated
use, please send it to the
nearest maintenance shop
for inspection.
This machine
stops during the
application.
1. The voltage is too low
2. Excessive or hard
ingredients
3. The continuous
working hour is too long
1. Check if the voltage is
too low
2. Disconnect the power
and remove the excess
ingredients .
3. It is a normal
phenomenon, and the
motor will resume
operation after a break
- 6 -
Noise at work
1. The strainer are not
fully installed, resulting in
unsteady operation;
2. The start motor in the
machine body breaks
down.
1. Fully install the strainer.
2. Please send it to the
nearest maintenance shop
for inspection.
