Customer Support:
1-800-474-2147
E-mail us at: [email protected]
ENERGY STAR
®
qualified units remove moisture with less energy than conventional dehumidifiers.
Dehumidifier
Owner’s Manual
Read and save these instructions before use
Model: DH45W
For product inquiries or support:
www.jmatek.com
THANK YOU!
Thank you for purchasing a Honeywell dehumidifier. This User Manual is intended to provide you with
important information needed to set up, operate, maintain and troubleshoot this product.
The user of electrical products may create hazards that include, but are not limited to injury, fire,
electrical shock. Failure to follow these instructions may damage and/ or impair its operation and void
the warranty.
When using electrical appliances, basic safety precautions should always be followed:
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
DO NOT touch the dehumidifier or the electrical plug with wet hands.
Check the household voltage to ensure it matches the appliance's specification.
Before operating, remove all packaging material and check for any damage that may have occurred
during shipping.
DO NOT operate any product with a damaged cord or plug.
DO NOT use an extension cord with this appliance.
DO NOT run power cord under carpeting, or cover it with rugs or runners. Keep the cord away from
areas where it may be tripped over.
Always unplug the dehumidifier before emptying the water tank.
The water collected in the tank must be discarded. The water should never be used for drinking.
Always unplug the dehumidifier and remove the water from the water tank before cleaning, servicing
or relocating the unit.
Remove the power cord from the electrical receptacle by grasping and pulling on the power cord
plug-end only, never pull the cord.
This appliance has been manufactured for use in domestic environments and must not be used for
other purposes.
DO NOT use the product in areas where gasoline, paint or other flammable goods and objects are
used or stored.
This dehumidifier is designed for indoor residential applications only. It should not be used for
commercial or industrial applications.
DO NOT attempt to repair or adjust any electrical or mechanical functions of the dehumidifier, as this
may cause danger and void the warranty.
DO NOT cover the air inlet or outlet on the appliance as this may cause the unit to fail.
DO NOT insert or allow objects to enter any ventilation or exhaust opening as this may damage the
product and could cause electrical shock or fire.
DO NOT let children play with this appliance, packaging or included plastic bag.
If the unit is damaged or it malfunctions, do not continue to operate it. Unplug the product from the
electrical outlet. Refer to the troubleshooting section and contact the customer support center.
Always place the dehumidifier on a leveled floor.
Never install the product near a bathtub or any water container.
Store in a dry area, away from direct sunlight, when not in use.
This appliance and its packaging materials are not intended for use by persons (including children or
elderly) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instructions concerning the use of the appliance by a
person responsible for their safety.
Always grip the side handles and keep the unit upright when transporting from room to room – DO
NOT tilt the product on its side or upside-down.
If the dehumidifier was transported tilted on its side, you must position it upright again and wait at
least 4 hours before using it.
WARNING: To reduce the risk of fire or electric shock, do not use this appliance with any solid state
speed control device.
SAFETY RULES
1
EN
WARNING -- READ AND SAVE THESE INSTRUCTIONS BEFORE USING THIS PRODUCT.
HOW A DEHUMIDIFIER WORKS
2
EN
•
•
•
•
Before using the dehumidifier, place the unit UPRIGHT for at least
1 hour before use to allow the refrigerant to stabilize. If the unit
was tilted on its side or upside-down during transportation, set
the unit upright for 4 hours before use.
For optimal efficiency, the dehumidifier must be operated in an
enclosed area. Keep all doors, windows and other outside
entrances to the room closed.
Place the dehumidifier at least 12 inches (31cm) away from other
objects (e.g. curtains or furniture) that may restrict airflow from the
front or through the air vents of the unit.
The dehumidifier must be positioned on a level floor.
IMPORTANT: The effectiveness of the dehumidifier can be
influenced by different factors. One factor is the rate at which
new, moisture-laden air enters the room and the amount of air
circulating in and out of the area to be dehumidified. For example,
if a door to a basement is constantly opened, letting new,
moisture-laden air into the room, dehumidification will take longer
than if the door was kept closed. If the dehumidifier is in a room
with a storage closet or cabinets, it will have little or no effect in
drying the inside of the storage closet or cabinets unless there is
adequate circulation of air in and out of these places. To
dehumidify these places, open the storage door or cabinet doors
to allow air circulation. You may find that installing a second
dehumidifier may be required for larger enclosed areas.
When the dehumidifier is switched ON, a fan pulls moisture-laden air into the dehumidifier where it
passes through dehumidifying coils inside the unit. These coils condense moisture from the air and
collect it in the water tank. The dry air is then exhausted from the dehumidifier. The air flows through the
air vents of the dehumidifier into the room as dry, warm air.
IMPORTANT: The dehumidifier is designed to operate between 41°F (5°C) and 89°F (32°C). The
dehumidifier’s performance may be greatly reduced if room temperatures exceed this temperature
range.
SELECTING A LOCATION (IMPORTANT)
12 inches (31cm)
PARTS DESCRIPTION
3
EN
(3)
(4)
(5)
(6)
(7)
(8)
(1) (2)
(9)
(10)
(11)
(3)
5) Washable Air Filter
6) Moist Air Intake
7) Water Tank
8) Water Level Indicator
9) Direct Drain Outlet
10) Drain Cap
11) Rubber Stopper
1) Control Panel
2) Dehumidified Air Exhaust Vent
3) Handle
4) Casters
USE & OPERATION
CONTROL PANEL
Timer Control
Humidity / Timer
Set Controls
°C/ °F Set
Controls
Fan Speed Control
Temperature / Timer Display Humidity Display (%)
Power Control
Press to set the desired fan speed.
There are 2 fan speeds to select from: High || / Low |
A higher fan speed results in faster moisture removal.
Fan Speed Control
Press to switch the dehumidifier ON or OFF.
This illuminates when the Water Tank is full of
water or if the Water Tank is not positioned
properly on the unit. To switch off , empty
the Water Tank and check that the tank is
secured properly into place.
This indicates that the room temperature is too low.
Increase the room temperature or wait until the
temperature increases to switch off and to turn
the dehumidifier on again.
Power Control
Water Tank Full Indicator Light Defrost Light
USE & OPERATION (CONTINUED)
CONTROL PANEL (CONTINUED)
Timer Control
The dehumidifier can be set to automatically switch ON or OFF after a selected period of time (between
1-24 hour intervals). The Timer hours selection is displayed on the Timer/Temperature Display Screen.
NOTE: Before setting the Timer control, make sure there is power to the unit.
Auto-Off Timer:
While the unit is running, first press and then tap or hold the ▲ or ▼ to select the number of hours
you want the unit to run before it switches off. The unit automatically switches off after the set time
period has elapsed. You must repeat the Timer set up procedures to reset the Timer for next use, if
needed.
Auto-On Timer:
When unit is in standby mode, press and ▲ or ▼ to select the number of hours until you want the
unit to automatically start running. The previous fan speed and humidity setting will be maintained. The
unit will continue running until the water tank is full (unless the unit is set up for continuous draining)or
until you switch it off manually.
NOTE: To cancel any Timer settings, simply press and then tap or hold the ▲ or ▼ until the Timer
display shows '0'.
Temperature / Timer Display
When the unit is switched ON, the Temperature / Timer Display shows the current room temperature.
Pressing the Timer temporarily switches the display to show the Timer setting (in hours) for 10
seconds, before reverting back to the temperature display
Humidity Control Setting
When the unit is switched ON, the Humidity Display shows the current humidity percentage. Press ▲ or
▼ to select your preferred humidity level. The humidity is adjusted in increments of 5% by pressing ▲ or
▼ . The adjustable Relative Humidity (RH) range is between 30% RH to 90% RH. Ten seconds after
setting the preferred humidity setting, the display will revert back to displaying the current humidity.
Recommended Settings: It is recommended to leave the unit running at 30% humidity at High Fan
Speed during the first 2 to 3 days until damp odors are removed. After a few days when the Relative
Humidity has been reduced to a more comfortable level, press ▲ or ▼ to choose a higher RH% that
maintains a comfortable humidity level thereafter. A recommended healthy humidity level is between
40% and 50%
°C/ °F Display Options
Press °C/ °F to change the Temperature Display from degrees Celcius °C to degrees Fahrenheit °F.
EN
4
USE & OPERATION (CONTINUED)
5
EN
DRAINING THE WATER
The condensed water can be collected directly into the water tank. When the water tank is full, the
dehumidifier will automatically shut OFF and will illuminate on the control panel followed by a
beeping sound.
IMPORTANT: Do not move the dehumidifier when the water tank is full as it will be heavy and can
cause water spillage.
IMPORTANT: Improper alignment or positioning of the water tank will
cause the unit to pause operation, the warning light on top of the dehumidifier
will illuminate followed by a beeping sound, until the water tank is fitted
properly.
NOTE: There is a Float inside the water tank that senses the water level to automatically stop
dehumidification when the water tank is full. Make sure the float is positioned correctly inside the
water tank by ensuring it lies level with the top edge of the water tank.
1.1
1.2
1.3
Locate the water tank at the front of the dehumidifier.
Gently pull the water tank out and place it on the floor.
Grip the handle inside the water tank and carry the
water tank to a sink to empty.
Replace the empty water tank back into the front
of the dehumidifier. Please make sure that the tank is
properly positioned.
WARNING: Always drain and discard water collected from dehumidification. The water is not clean and
cannot be used for drinking.
1. Draining water collected in the Water Tank
Handle
Float
For continuous water drainage, you will need a garden hose* and a suitable water drain (e.g. a sink
or drain hole at floor level) near the dehumidifier.
2.1
2.2
2.3
2.4
IMPORTANT: Make sure water can flow down the garden hose by keeping the hose angled down and
free of bends or kinks.
IMPORTANT: If you stop using the continuous drain function, the drain cap and rubber stopper must be
replaced before use to prevent leakage.
*The garden hose is NOT supplied.
2. Continuous Water Drainage
Locate the drain outlet on the back of the unit.
Unscrew and remove both drain cap and rubber
stopper.
Locate the female connector at one end of the
garden hose. Insert the garden hose onto the drain
outlet of the dehumidifier. Screw and tighten the
garden hose connector onto the threaded part of
the drain outlet, making sure the hose connector is
secured to ensure there will be no leaks. If there
are leaks, the hose and the drain outlet may not be
connected properly. Disconnect, replace and
tighten the garden hose connector again.
Position the other end of the garden hose in the sink or drain. Make sure the hose is not bent
or kinked which might stop the water flow. Make sure the hose is secured over the drain and
will not fall out of place causing unwanted water spillage.
2.1
2.2
Drain outlet
Drain cap
Rubber stopper
garden hose
2.3
2.4
USE & OPERATION (CONTINUED)
CLEANING & MAINTENANCE
EN
WARNING: Always switch OFF the dehumidifier and unplug it from the electrical outlet before
attempting any cleaning or maintenance of this product.
Appliance Maintenance:
• Switch OFF the appliance before disconnecting the power supply.
• Only use a soft cloth to clean the appliance.
Air Filter Maintenance:
The Air Filter located at the top of the unit helps to remove dust particles from the air. A dirty filter
blocked by dust particles can reduce the efficiency of the dehumidifier. For optimum dehumidification, it
is recommended to clean the air filter every 2 weeks :
1. Switch OFF the dehumidifier. Press down on the
air filter with 2 hands to release the air filter
from the top of the unit.
2. Rinse the air filter under running water, or vacuum
away the dust with a vacuum cleaner.
3. After cleaning the air filter, dry in a cool, shaded place, then carefully reinstall into the unit.
End of Season Storage & Maintenance:
If the appliance will not be used for an extended period of time:
• Switch OFF the unit and unplug from the electrical power outlet.
• Empty the water tank and let it dry. If your dehumidifier is connected to the continuous drain hose, you
must disconnect the hose, dry and then replace the drain cap and rubber stopper back into the drain
outlet.
• Remove the air filter and clean with water. Let the air filter dry and reinstall back into the unit.
• Make sure all parts of the dehumidifier and accessories are dry before storage.
• Cover the dehumidifier with a cloth/ plastic bag before storage, to protect the surface from dust and
scratches.
• It is recommended to coil the power cord and store it off the floor to ensure it is protected from bends
and kinks.
• Store the unit upright in a dry location, away from direct sunlight.
6
TROUBLESHOOTING GUIDE
The following troubleshooting guide addresses the most common problems. If problems persist, call
customer service.
Dehumidifier does
not start
No electricity. Check for power.
The power cord is not
properly plugged in.
Remove and reconnect the power cord.
The safety switch activated
on the electrical plug.
Reset the safety switch and wait for 3
minutes to pass. Contact customer service if
problem persists.
PROBLEM POSSIBLE CAUSE SOLUTION
TROUBLESHOOTING GUIDE (CONTINUED)
7
EN
Unit runs but the
humidity level does
not decrease
Dehumidifier runs
constantly/ does not
stop
The humidity level setting is
too high.
Decrease the humidity level setting.
A door or window is open,
letting in new moisture.
The temperature in the
room is too low.
Area to be dehumidified is
too large.
Make sure all windows or doors to the
outside are closed and tightly sealed.
There are other sources of
humidity in the room
(e.g. boiling water in pot).
Switch on the dehumidifier when these
sources are not present.
The capacity of your dehumidifier may not be
adequate for the room it is used in. It is
recommended to add an extra dehumidifier
for large areas.
Frost appears on the
coils
Water on the floor
Noise
Dehumidifier has been
recently turned on in low
room temperatures (usually
below 41°F (5°C)).
The garden hose/ drain
hose may be loose.
This is normal. Frost will disappear in an hour
or so after the dehumidifier is switched OFF.
Check the connections between the hose
and the drain outlet on the unit. See
Continuous Water Drainage section.
You intended to use the
water tank to collect water
but the continuous drain
hose is still connected.
Fan is working.
Disconnect the hose and replace the rubber
stopper and drain cap if using the water tank
to collect water. See Continuous Water
Drainage section.
Wind from the fan can create sounds during
operation. This is a normal sound.
A door or window is open,
letting in new moisture.
The water tank is full.
The water tank is not in the
correct position.
The temperature of the
room is too low.
Make sure all windows or doors to the
outside are closed and tightly sealed.
Empty the water tank.
Position the water tank correctly into the unit.
Unit will not operate until the water tank is
secure in place.
The dehumidifier may not work effectively in
low temperature environments. Increase the
temperature of the room or wait until the
temperature increases to use the dehumidifier.
The air filter is dirty/ blocked. Clean the air filter.
Air outlet or intake is blocked. Remove blockage.
The dehumidifier is designed to operate
between 41°F (5°C) and 89°F (32°C).
Moisture removal is greatly reduced if room
temperatures exceed this temperature range.
PROBLEM POSSIBLE CAUSE SOLUTION
Water Tank Full
is illuminated and
the unit is beeping
Defrost
is illuminated
TECHNICAL SPECIFICATIONS
EN
8
Electrical products should be properly disposed of.
Please recycle where facilities exist. Check with your local authority
or retailer for recycling.
Dehumidifiers
DH45W
115 V~ 60 Hz
Description of Product
Model
Voltage/Frequency
Power Consumption
515W
Dehumidifying capacity
45 pints / 24 hours
R-410ARefrigerant Type
24 hour (ON / OFF)Timer
Dimensions (W) x (D) x (H)
Weight
13.3 x 9.9 x 21.4 inches / 338 x 252 x 544 mm
28.7 lbs / 13 kgs
JMATEK North America LLC
Mahwah, New Jersey 07495 USA
Phone: 1-800-474-2147
Email: [email protected]
Web: www.jmatek.com
© 2016 JMATEK Limited. All rights reserved.
The Honeywell Trademark is used under license from
Honeywell International Inc.
Honeywell International Inc. makes no representations
or warranties with respect to these products.
This product is manufactured by Airtek Int'l Corp. Ltd.
(subsidiary of JMATEK Ltd.)
