DUAL NOZZLE BBQ LIGHTER & BLOWER
BT-3500
INSTRUCTION MANUAL
Battery Compartment
1. Unlatch and remove the battery door and insert 3 AA standard or
rechargeable batteries (not included). New batteries will provide
up to 30 minutes of continuous run time.
2. Match battery placement with diagram inside the battery
housing.
3. Replace battery door and latch shut. When fan power is
diminished, replace the batteries.
BATTERY
COMPARTMENT
Gas Filling
1. Adapter are not normally required when filling.
2. To refill, hold butane fuel (not included) above the tool since fuel
transfer is dependent on gravity.
3. Press while holding vertically downward into center of the refill
valve and apply firm pressure.
4. Stop refilling when gas reaches about 80% full.
5. Wait five minutes for the fuel to stabilize and for residual fuel to
vent.
REFILL
VALVE
Fan Blower Operation
1. To turn on the fan blower, push the safety switch down in the
middle of the button
2. With the switch depressed, slide the button forward to turn the
power on to the blower.
3. The fan blower will continue operation when the button is in the
forward position.
4. To turn the fan blower off, slide the switch back into the off
position.
FLAME
LIGHTER
NOZZLE
FAN
BLOWER
NOZZLE
FAN BLOWER SWITCH
CONTINUOUS
USE BUTTON
IGNITION SAFETY
SWITCH
GAS ADJUSTMENT
IGNITION SWITCH
BATTERY
COMPARTMENT
REFILL
VALVE
PUSH SWITCH
FORWARD TO
POWER ON
Ignition Sequence
1. Set the gas adjustment wheel to middle setting for the initial lighting of the torch function.
2. Slide the child safety switch forward and press the ignition button simultaneously. It may take two or three tries before the torch ignites.
Each try will require sliding the child safety switch forward and pressing the ignition button
3. For continuous flame, press the continuous use button before releasing the ignition button.
4. To adjust the intensity of the flame, use the gas adjustment wheel.
5. To shut the torch off, press the ignition button again and this will cut off the gas supply and extinguish the flame.
LIGHTING
INSTRUCTIONS
Model BT-3500
Made in Taiwan
www.wlenk.com
DUAL NOZZLE BBQ LIGHTER & BLOWER
GAS ADJUSTMENT SAFETY SWITCH
IGNITION BUTTON
CONTINUOUS USE
BUTTON
