FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 42-70-0135 Belt Clip/Screw Service Kit (1)
54-49-1010
SERVICE PARTS LIST
BULLETIN NO.
MILWAUKEE TOOL
www.milwaukeetool.com
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 2
EXAMPLE:
Component Parts (Small #) Are Included
When Ordering The Assembly (Large #).
0
00
1
48-22-1010
STAPLE & NAIL GUN
Jan. 2015
REVISED BULLETIN
WIRING INSTRUCTION
DATE
CATALOG NO.
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
SERIAL
NUMBER
NOTE: Belt Clip can be
mounted to either side of tool.
