48-59-1801
Li-Ion Battery Charger
Aug. 2007
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 10-20-2995 Service Serial Label (1)
2 12-20-1801 Service Nameplate (1)
FIG. NOTES
1, 2 A clean, dry surface is essential for proper performance
for anyadhesive system. The area intended for application
of any adhesive label or nameplate must be prepared by
cleaning with isopropyl alcohol. The solvent is to be applied
with a clean, lint free applicator and the surface allowed to
dry before applying the label or nameplate.
54-04-1810
REVISED BULLETIN
SERVICE PARTS LIST
BULLETIN NO.
WIRING INSTRUCTION
DATE
CATALOG NO.
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
SERIAL
NUMBER
MILWAUKEE ELECTRIC TOOL CORPORATION
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
EXAMPLE:
Component Parts (Small #)
Are Included When Ordering
The Assembly (Large #).
0
00
B29A
1
2
