Poly Sync 60 Series
Bluetooth and USB Conference
Room Speakerphone
User Guide
Contents
Controls 3
LEDs 4
Be safe 4
Set up, power and pair 5
Power 5
Corded setup 5
Mobile setup 5
Video camera setup 7
Load software 8
Update rmware 8
Daily Use 9
Answer or end a call 9
Mute/Unmute 9
Volume 9
Voice assistant (smartphone feature) 9
Launch Microsoft Teams (Teams model only) 9
Customize your speakerphone 9
Charge your mobile phone 9
Link speakerphones (daisy chain audio) 10
Linked speakerphone audio settings 10
Troubleshoot 11
What's in the box 13
Support 14
2
A conference room speakerphone with mobile and corded connectivity.
Volume
Mic / Mic Mute
NFC
Siri
Google Assistant
:02
/
Blutooth
Lock
Indicator Light
Music
ANC
Timer
Devices
Headphones
Phone
Mobile
Computer
Camera
Charging/Battery
Blutooth
Lock
Indicator Light
Music
ANC
Timer
Custom Button
Device Controls
Headphones
Phone
Mobile
Computer
Camera
Headset
Support
Settings
Daisy Chain / Link
Lock
ANC
Timer
Custom Button
Volume
Mic / Mic Mute
Play / Pause
Power
Device Controls
Headphones
Computer
Camera
Headset
Lock
Indicator Light
ANC
Timer
Custom Button
Device Controls
Headphones
Mobile
Computer
Camera
Headset
Support
Settings
Plus / Minus
Daisy Chain / Link
Power
Device Controls
Settings
Plus / Minus
Check / Delete
Daisy Chain / Link
General
Indicator Light
Scaled to 45% of full size
NFC Near Field Communication
Bluetooth pairing
Press to interact with Microsoft Teams (Teams model only, desktop
application required)
Volume down
Mute/unmute
Volume up
Call answer/end
Siri, Google
Assistant
Default voice assistant (smartphone feature)
USB phone charge ports
Link 2 speakerphones (smartphone feature)
Pause/play media (default). Customize feature in Poly Lens App
Controls
3
LED bar What lights mean
Crossing
blue pattern
Pairing mode
Solid blue Pairing successful (connected)
Flashing
green
Incoming call
Solid green In a call
Solid red Mute active
Crossing
white
pattern
Linking mode (daisy chain audio)
2 white
blinks
Linking successful
NOTE LEDs do not illuminate in standby mode.
Please read the safety guide for important safety, charging, battery and regulatory
information before using your new speakerphone.
LEDs
Be safe
4
Reverse view
ANC
Timer
Custom Button
Device Controls
Headphones
Camera
Headset
Lock
ANC
Timer
Custom Button
Device Controls
Headphones
Computer
Camera
Headset
Volume
Mic / Mic Mute
Play / Pause
Power
Device Controls
Ports on speakerphone's reverse side
Computer USB-C port
Video camera USB-A port
Power port
The speakerphone is powered on when the power cable is connected to an outlet. The
power port is on the reverse side of the speakerphone.
Connect the USB cable from the speakerphone to your computer's USB-A or USB-C port.
USB-A / USB-CUSB-C
NOTE The USB cable connects to the computer port on the reverse side of the speakerphone.
NOTE Ensure that the USB-C-only connector is plugged into the speakerphone. Corded mode
may not function if the USB-A to USB-C adapter is connected to the speakerphone.
1 With your speakerphone powered on, press the Bluetooth button for 2 seconds. You
hear "pairing" and the LED flashes a crossing blue pattern.
Set up, power and pair
Power
Corded setup
Mobile setup
5
Poly Sync 60
:02
“Pairing”
Headphones
Camera
Headset
Blutooth
2 Activate Bluetooth on your mobile device and set it to search new devices. Select “Poly
Sync 60.”
3 Pairing is successful when you hear "pairing successful" and the LED flashes blue.
NFC pairing
Your speakerphone supports NFC pairing to your mobile device. NFC pairing may not
function if two devices are already paired to your speakerphone.
1 Ensure NFC is enabled on your mobile device and the display is unlocked. (Mobile device
NFC capability may vary.)
2 With the speakerphone powered on, bring mobile device's NFC tag within range of the
speakerphone's NFC tag until pairing completes. If necessary, accept the connection.
Secure Connection (mobile)
The Secure Connection feature provides extra security for Bluetooth calls in a conference
room.
When enabled, your paired device disconnects after each mobile call, ensuring that device
audio does not play through the speakerphone when not intended. Manage in Poly Lens
App.
NOTE Enabling Secure Connection disconnects previously paired devices.
1 With your speakerphone powered on and Secure Connection enabled in Poly Lens App,
press the Bluetooth button for 2 seconds. You hear "pairing" and the LED flashes a
crossing blue pattern.
2 Activate Bluetooth on your device and set it to search new devices. Select “Poly Sync 60.”
Poly Sync 60
:02
“Pairing”
Headphones
Camera
Headset
Blutooth
3
Pairing is successful when you hear "pairing successful" and the LED flashes blue.
Headphones
Camera
Headset
“Pairing
successful”
4 Make or take a mobile call or play music via Bluetooth.
5 After the end of a call, continue the mobile connection by pressing any button within 30
seconds. When no action is taken, the mobile connection ends and the Bluetooth button is
no longer illuminated.
6
1 Your speakerphone ships with the video camera port covered. It is on the reverse side of
the speakerphone. Access the port by removing the cover with the provided torx tool.
Headphones
Camera
Headset
Blutooth
2 Connect your compatible video camera's cable to the USB-A camera port on the
speakerphone.
NOTE Video camera cable not provided.
Video camera setup
7
Customize your device behavior through advanced settings and options with Poly Lens
Desktop App. Some softphones require the installation of Poly software to enable device
call control (answer/end and mute) functionality. Download: poly.com/lens.
NOTE Device settings are also available in Plantronics Hub Desktop App.
Keep your firmware up-to-date to improve performance and add new features to your
Poly device.
Update your rmware using your computer with Poly Lens App. Download at poly.com/
lens.
While updating rmware:
• Do not use your Poly device until the update is complete.
• Disconnect your Poly device from paired devices such as phones, tablets and computers.
• Do not start a second update from a second device.
• Do not stream media.
• Do not answer or place a call.
Load software
Update firmware
8
Press the Call button to answer or end a call.
During an active call, press the Mute
button to mute or unmute the microphones.
Manage mute settings in Poly Lens App.
Press the Volume up (+) or down (-) buttons to increase or decrease volume.
Adjust speakerphone microphone volume
Place a test softphone call and adjust softphone volume and PC sound volume accordingly.
Siri, Google Assistant, Cortana Press and hold the Call button for 2 seconds to activate
your phone's default voice assistant. Wait for the phone prompt to activate voice dialing,
search, and other smartphone voice controls.
Your device has a Teams
button to quickly view and use the Microsoft Teams desktop
app. The Teams button pulses when you have a meeting or notification.
• When not on a call, tap the Teams button to view Microsoft Teams app on your
computer.
• When the Teams button LED pulses purple, tap to view your Teams notifications or
meeting.
NOTE Teams model and open Teams desktop application required. Teams mobile application is
not supported.
Customize your Rocket
button feature in Poly Lens App. Play/pause media is the default
feature when you tap the Rocket
button.
Choose from:
• Play/pause audio (default)
• Device status check
• Clear trusted device list
• Mobile calls only: Default voice assistant (Siri, Google Assistant)
• Redial
• Hold/resume call (varies by softphone)
With the speakerphone powered on, charge up to 2 phones. Connect phone charge cable
to one of 2 USB-A charging ports (cables not provided).
Phone
Mobile
Charging/Battery
NOTE Connection provides power only.
Daily Use
Answer or end a call
Mute/Unmute
Volume
Voice assistant
(smartphone feature)
Launch Microsoft
Teams (Teams model
only)
Customize your
speakerphone
Charge your mobile
phone
9
Use two Poly Sync speakerphones with your computer or mobile device.
NOTE You may link Sync 40 and Sync 60 speakerphones. Ensure that each speakerphone is
updated to the latest device software release in Poly Lens Desktop App.
NOTE The primary device settings are used when speakerphones are daisy-chained. The
speakerphone paired or connected to your computer or mobile phone is your primary device.
1 Pair or connect one speakerphone to your PC or mobile device. See Corded setup, Mobile
setup or USB adapter setup.
2 Wirelessly link speakerphones by pressing both Link buttons for 2 seconds. You hear
"connecting" and the LEDs pulse white.
Linking is successful when you hear "connection successful" and the LED flashes white on
both speakerphones.
NOTE Enter linking mode only when both speakerphones are inactive (not in a call or streaming
media).
“Connection successful”
:02:02
Support
Settings
Daisy Chain / Link
Support
Settings
Daisy Chain / Link
Lock
ANC
Timer
Custom Button
“Connecting”“Connecting”
3 Control the system from either speakerphone to play audio or make calls.
4 End linking mode by pressing both Link buttons for 2 seconds.
You hear "device disconnected."
NOTE The primary device settings are used when speakerphones are daisy-chained. The
speakerphone paired or connected to your computer or mobile phone is your primary device.
Manage daisy chain audio settings in Poly Lens Desktop App. Select an audio output:
Party (default) or Stereo.
NOTE In Stereo mode, the primary device has the right channel audio and the secondary
device has the left channel audio.
Link speakerphones (daisy chain audio)
Linked speakerphone
audio settings
10
The speakerphone doesn't play audio
when connected to my computer in
corded mode.
• Ensure that the speakerphone is powered on by
connecting the power cable to an outlet.
• The computer USB cable may be inserted backwards.
Ensure that the USB-C-only end of the cable is
inserted into the speakerphone. The end of the cable
with USB-A connector (and attached USB-C adapter)
inserts into your computer.
• Do not connect the USB cable to a phone charging
port on the speakerphone's side. Connect to the USB-
C port on reverse side of the speakerphone.
(Teams model only) How do I interact
with Microsoft Teams?
• Tap the Teams button to quickly open and use
Microsoft Teams.
• Teams model is compatible with Microsoft Teams
desktop app. Teams mobile app is not supported.
Is stereo sound available when two
speakerphones are wirelessly linked?
Yes, in Poly Lens App, go to Settings > General > Daisy
chain audio and select Stereo. For more information,
see Linked speakerphone audio settings.
Download app: poly.com/lens.
• How do I manage my speakerphone using
Poly software?
• My speakerphone isn't recognized by
Poly Lens Mobile App or Plantronics Hub
Mobile App.
• Your speakerphone is supported by Poly desktop
applications: Poly Lens Desktop App and Plantronics
Hub Desktop App. Download: poly.com/lens.
• Your speakerphone is not supported by Poly mobile
apps.
How do I use the Secure Connection
feature with my mobile calls?
The Secure Connection feature provides extra
security for Bluetooth calls in a conference room.
• Activate Secure Connection in Poly Lens Desktop
App.
• Automatically disconnects your paired mobile device
from the speakerphone after a call.
• Continue the mobile connection by pressing any
button on the speakerphone within 30 seconds after
the end of a call.
How do I customize the Rocket button
feature?
• Ensure Poly Lens Desktop App is loaded on your
computer.
• Customize your Rocket button feature in Poly Lens
Desktop App.
• Play/pause media is the default feature when you tap
the Rocket button. Play/pause feature is not
compatible with some web-based apps.
I want to connect a video camera to my
speakerphone.
• Your speakerphone ships with the USB-A video
camera port covered. Access the port by removing
the cover with the provided tool.
Troubleshoot
11
• Connect your compatible video camera's cable to the
USB-A camera port on the speakerphone.
12
Contents may vary by product.
Speakerphone
Combined USB-A/USB-C
cable
Power supply and plug
adapters
Torx tool (for video camera
port) Quick start guide
What's in the box
13
Support
NEED MORE HELP?
poly.com/support
Manufacturer:
Plantronics, Inc. Plantronics B.V.
345 Encinal Street
Santa Cruz, CA 95060
United States
Scorpius 171
2132 LR Hoofddorp
Netherlands
©
2022 Plantronics, Inc. All rights reserved. Poly, the propeller design, and the Poly logo
are trademarks of Plantronics, Inc. Bluetooth is a registered trademark of Bluetooth SIG,
Inc. and any use by Plantronics, Inc. is under license. All other trademarks are the
property of their respective owners. Manufactured by Plantronics, Inc.
Model ID: SY60/SY60-M.
218941-06 01.22
14
