Philips TAR4600/10 Clock Radio

User manual - Transcript

• Page 1: Register your product and get support at wwwphilipscomsupport User manual TAR4600 4000 Series Clock Radio
• Page 2 - English - : 6 Listen to FM radio 10 Tune to FM radio stations 10 Store FM radio stations automatically 10 Store FM radio stations manually 10 Select a preset radio station 10 Show menu in FM mode 11 Show RDS information 11 7 Other features 12 USBtype C port for charging out 12 8 Product specications 12 9 Troubleshooting 13 10 Notice 13 Compliance 13 1 Important 2 Safety 2 2 Your clock radio 3 Introduction 3 Whats in the box 3 Overview of the clock radio 4 3 Get started 5 Install batteries 5 Connect power 5 Turn onSwitch to standby 5 Adjust volume 5 Adjust display brightness 5 4 ClockAlarm setting 6 Automatically setting the clock 6 Manually setting the clock 6 Show menu 6 Set alarm time 7 Activatedeactivate alarm timer 7 Snooze the alarm 7 Stop alarm sounds 7 Set sleep timer 7 5 Listen to DAB radio 8 Tune to DAB radio stations 8 Store DAB radio stations 8 Select a preset radio station 8 Show DAB information Show menu in DAB mode 9 1EN Contents
• Page 3 - English - : 2 EN 1 Important Safety Read these instructions Heed all warnings Follow all instructions Do not block any ventilation openings Install in accordance with the manufacturers instructions Do not install near any heat sources such as radiators heat registers stoves or other apparatus including ampliers that produce heat Protect the power cord from being walked on or pinched particularly at plugs convenience receptacles and the point where they exit from the clock radio Only use attachmentsaccessories specied by the manufacturer Unplug this apparatus during lightning storms or when unused for long periods of time Refer all servicing to qualied service personnel Servicing is required when the apparatus has been damaged in any way such as powersupply cord or plug is damaged liquid has been spilled or objects have fallen into the apparatus the apparatus has been exposed to rain or moisture does not operate normally or has been dropped Battery usage CAUTION To prevent battery leakage which may result in bodily injury property damage or damage to the clock radio Do not mix old and new batteries Do not mix alkaline standard carbonzinc or recharge able nicad nimh etc batteries CAUTION Danger of explosion if batteries are incorrectly replaced Replace only with the same or equivalent type Battery in extreme high or low temperatures during use storage or transportation and low air pressure at high altitude can pose safety hazards Do not replace a battery with an incorrect type that can defeat a safeguard for example some lithium battery types Leaving a battery in an extremely high temperature surrounding or an extremely low air pressure environment may result in an explosion or leakage of ammable liquid or gas Install all batteries correctly and as marked on the unit Remove batteries if they are exhausted or if the remote control if included is not to be used for a long time Batteries contain chemical substances They should be disposed of properly If you suspect that a battery has been swallowed or placed inside any part of the body seek immediate medical attention When you change the batteries always keep all new and used batteries out of reach of children Ensure that the battery compartment is completely secure after you replace the battery If the battery compartment cannot be completely secured discontinue use of the product Keep out of reach of children and contact the manufacturer This clock radio shall not be exposed to dripping or splashing Do not place any sources of danger on the clock radio eg liquid lled objects lighted candles Where the plug of the Direct Plugin Adapter is used as the disconnect device the disconnect device shall remain readily operable Please use the product safely in an environment with temperature between 0C and 45 C
• Page 4 - English - : Your clock radio Congratulations on your purchase and welcome to Philips To fully benet from the support that Philips offers register your product at wwwphilipscomsupport Introduction With this clock radio you can listen to FM and Digital Audio Broadcasting DAB radio Whats in the box Check and identify the contents of your package Main unit Power adaptor Quick start guide Safey sheet Warranty set two alarms to ring at different times charge your mobile devices 3 EN Wireless speaker TAR460010 Note Power adaptor quantity and plug type vary by regions Images illustrations and drawings shown on this user manual are for reference only actual product may vary in appearance
• Page 5 - English - : 4EN Overview of the clock radio PRESET BACK Store radio stations in memory Select a preset radio station Back to previous menu Exit menu setting HOUR TUN Tune to a radio stations Select previous preset station Select a menu option Set hour SNOOZE BRIGHTNESS Snooze alarm Adjust display brightness SCAN ENTER Scan and store radio stations automatically Enter selected menu item list Display panel Display current status ALR 1 Set alarm VOL Adjust volume Set alarm ALR 2 MENU INFO Info display Enter menu setting Tune to a radio stations Select next preset station Select a menu option Set minute MIN TUN SLEEP Set the sleep timer VOL Adjust volume USBtype C charging out port Charge your mobile devices DC IN Connect to the supplied power adaptor DABFM Antenna DAB FM Turn on or switch to standby Switch to DABFM source
• Page 6 - English - : Get started Always follow the instructions in this chapter in The batteries can only back up clock and alarm settings sequence Install batteries Caution Risk of product damage Make sure that the power voltage corresponds to the voltage printed on the back or underside of the clock radio Risk of electrical shock When you unplug the power cord always pull the plug from the socket Never pull the cord Connect power Caution Risk of explosion Keep the batteries away from heat sunshine or re Never discard batteries in re Batteries contain chemical substances so they should be disposed of properly Do not mix battery types eg alkaline with carbon zinc Only use batteries of the same type for the set Note The type plate is located at the bottom of the clock radio Open the battery compartment at the bottom of the unit Insert 2 pcs AAA batteries not supplied with correct polarity as indicated then close the battery compartment 5 EN Turn onSwitch to standby Adjust volume While listening press VOL VOL to adjust volume Connect the power adapter to the wall outlet Note Power adaptor quantity and plug type vary by regions Images illustrations and drawings shown on this user manual are for reference only actual product may vary in appearance Adjust display brightness Press BRIGHTNESS to select different brightness levels or turn off the display screen High Medium Low Off Press to turn the unit on The radio switches to the last selected source Press for 3 seconds to switch the unit to Standby The time and date if set are displayed
• Page 7 - English - : 6EN ClockAlarm setting In DABFM RDS station the unit can synchronize with time transmitted by DABFM RDS station with CT information automatically Automatically setting the clock Press MENU to access the Clock setting Press ENTER to enter ltSet DateampTimegt Press TUN TUN to select ltAutogt then press ENTER to conrm Press BACK to exit the setup mode Manually setting the clock Press MENU to access the Clock setting Press ENTER to enter ltSet DateampTimegt Press TUN TUN to select ltManualgt then press ENTER to conrm the month will blink Press TUN TUN to set month then press ENTER to conrm the day will blink Press TUN TUN to set day then press ENTER to conrm the year will blink Press TUN TUN to set year then press ENTER to conrm the time will blink Press HOUR to set hour and press MIN to set minute then press ENTER to conrm The time is set Press BACK to exit the setup mode Press MENU to access the Clock setting Press TUN TUN to select ltTime Formatgt then press ENTER to conrm Press TUN TUN to set lt12Hgtlt24Hgt hour format then press ENTER to conrm Press BACK to exit the setup mode Set time format Press MENU to access the Clock setting Press TUN TUN to select ltDate Formatgt then press ENTER to conrm Press TUN TUN to set ltMMDDYYYYgt ltDDMMYYYYgt or ltYYYYMMDDgt date format then press ENTER to conrm Press BACK to exit the setup mode Set date format Press MENU to access Clock setting Press TUN TUN to select a menu option and then press ENTER to conrm the option or enter the lowerlevel menu Set DateampTime to set date time Time Format to select time format Date Format to select date format Repeat steps 2 if any suboption is available under one option Press BACK to return to the previous menu or exit the menu Note If no button is pressed within 30 seconds the menu exits Press and hold BACK for 3 seconds to exit the menu Show menu When the unit in standby mode you can access the menu for control options Set DateampTime Time Format Date Format Auto Manual 12H 24H MMDDYYYY DDMMYYYY YYYYMMDD Clock setting Note lf no button is pressed in approx 30 seconds the unit exits clock setting mode automatically Press and hold BACK for 3 seconds to exit timer setting mode without storing
• Page 8 - English - : Set sleep timer This clock radio can switch to standby mode automatically after a preset period Press SLEEP to select a period in minutes The clock radio switches to standby mode automatically after the preset period To deactivate the sleep timer Press SLEEP until OFF off appears 7 EN Press and hold ALR 1 or ALR 2 for 3 seconds to activated the alarm setup mode the icon or and alarm time will blink Press HOUR to set hour and press MIN to set minute then press ALR 1 or ALR 2 to conrm the icon or and alarm period will blink Press TUN TUN to select alarm period ONCE DAILY WEEKDAY WEEKEND then press ALR 1 or ALR 2 to conrm the icon or and alarm source will blink Press TUN TUN to select alarm source Buzzer DAB or FM station then press ALR 1 or ALR 2 to conrm If DAB or FM is selected as the alarm source the icon or and station preset number will blink press TUN TUN to select DAB or FM preset radio station then press ALR 1 or ALR 2 to conrm Set alarm time Stop alarm sounds When the alarm sounds press or corresponding ALR 1ALR 2 the alarm stops but the alarm settings remain Note Make sure that you have set the clock correctly Tip The unit exits alarm setting mode when being idle for 30 seconds If DABFM source is selected and not preset the station Buzzer is activated automatically Alarm timeout is 60 minutes if no user action Activatedeactivate alarm timer Snooze the alarm When the alarm sounds press SNOOZE The alarm snoozes and repeats ringing 10 minutes later Press ALR 1 or ALR 2 to activate or deactivate the alarm timer If the alarm timer is activated the icon or and alarm information will appear If the alarm timer is deactivated the icon or and alarm information will disappear During alarm snooze time press SNOOZE to select another period in minutes to ringing gain 10 20 50 6030 40
• Page 9 - English - : 8EN Note After 3 seconds preset radio station will be conrm automatically Listen to DAB radio Note Keep the clock radio away from other electronic devices to avoid radio interference For better reception fully extend and adjust the position of the DABFM antenna Tune to DAB radio stations To tune to a station from the available station list Tip To remove a prestored station store another station in its place Tip The stations may change from time to time To update the station list press and hold SCAN for 3 seconds to perform full scan Store DAB radio stations Note You can store a maximum of 20 DAB radio stations 1 In DAB mode tune to a DAB radio station Press and hold PRESET for 3 seconds to activate programming mode The Preset Store is displayed The preset number begins to blink The Stored is displayed The station is stored in the selected position 3 Press TUN TUN to select a number Press PRESET again to conrm 2 Press ENTER to conrm 5 Repeat steps 1 to 4 to store more DAB radio stations Press TUN TUN to navigate through the available DAB stations Scanning is displayed The station list is memorized in the radio Next time when you turn on the radio the station scan does not take place The radio scans and stores all the DAB radio stations automatically and then broadcasts the rst available station Press DABFM to select DAB mode The rst time you select DAB radio mode or if the station list is empty the radio performs a full scan automatically Select a preset radio station In DAB mode press PRESET to select a preset number Option A 1 In DAB mode press PRESET 2 Press TUN TUN to select a preset radio station Option B
• Page 10 - English - : 9 EN Show menu in DAB mode Press MENU to access DAB menu Press TUN TUN to select a menu option and then press ENTER to conrm the option or enter the lowerlevel menu Full scan to perform full scan Manual tune tune to a specic channel frequency manually and add it to the station list Prune remove all the invalid stations from the station list DRC level compress the dynamic range of a radio signal so that the volume of quiet sounds is increased and the volume of loud sounds is reduced Clock setting to set date time and select time date format System for display the current version of the rmware and for reset all radio settings to the factory default status Repeat steps 2 if any suboption is available under one option Press BACK to return to the previous menu or exit the menu When you listen to DAB you can access the menu for control options Yes No 5A 174928MHz 5B 176640MHz 5C 178352MHz Yes No Off High Low Set DateampTime Time Format Date Format Reset Version Auto Manual 12H 24H MMDDYYYY DDMMYYYY YYYYMMDD DAB Menu Full scan Manual tune Prune DRC level Clock setting System Note If no button is pressed within 30 seconds the menu exits Press and hold BACK for 3 seconds to exit the menu While listening to DAB radio press and hold INFO for 3 seconds to display the following information if available DAB or DAB Station Name Scrolling text Programme type Multiplex name Channel Frequency Mode Transfer speed Mode Channel type Signal quality Show DAB information
• Page 11 - English - : 10EN Listen to FM radio Note Keep the clock radio away from other electronic devices to avoid radio interference For better reception fully extend and adjust the position of the DABFM antenna Tune to FM radio stations 1 Press DABFM to select FM mode 2 Press and hold TUN TUN for 3 seconds The clock radio tunes to a station with strong reception automatically 3 Repeat Step 2 to tune to more radio stations To tune to a station manually Press TUN TUN to select a frequency Note The tuning grid of the clock radio is 50KHz the radio frequency on the display panel will increase 005MHz by pressing TUN TUN Tip To remove a prestored station store another station in its place Store FM radio stations automatically Store FM radio stations manually In FM tuner mode press and hold SCAN for 3 seconds The unit stores all the available FM radio stations automatically and broadcasts the rst station Note You can store a maximum of 20 FM radio stations 1 In FM tuner mode tune to an FM radio station 2 Press and hold PRESET for 3 seconds to activate programming mode The preset number begins to blink 3 Press TUN TUN to select a number Press PRESET again to conrm 5 Repeat steps 1 to 4 to store more FM radio stations Note After 3 seconds preset radio station will be conrm automatically Select a preset radio station In FM tuner mode press PRESET to select a preset number Option A 1 In FM tuner mode press PRESET 2 Press TUN TUN to select a preset radio station Option B
• Page 12 - English - : 11 EN Press MENU to access FM menu Press TUN TUN to select a menu option and then press ENTER to conrm the option or enter the lowerlevel menu Clock setting to set date time and select time date format System for display the current version of the rmware and for reset all radio settings to the factory default status Repeat steps 2 if any suboption is available under one option Press BACK to return to the previous menu or exit the menu Note If no button is pressed within 30 seconds the menu exits Press and hold BACK for 3 seconds to exit the menu Show RDS information Station name Program type such as NEWSnews FrequencySPOR Tsport POP M pop music Time Text RDS Radio Data System is a service that allows FM stations to show additional information Tune to an RDS station Press and hold INFO for 3 seconds to displayed the followinginformationif available Show menu in FM mode When you listen to FM you can access the menu for control options Set DateampTime Time Format Date Format Reset Version Auto Manual 12H 24H MMDDYYYY DDMMYYYY YYYYMMDD FM Menu Clock setting System
• Page 13 - English - : 12EN Product specications Note Product information is subject to change without prior notice Output Power Tuner Amplier Tuning RangeFM Tuning RangeDAB 875108 MHz 174240 MHz Band III Charging out Tuning Grid 50 KHz Sensitivity Mono 26 dB SN Ratio lt22 dBf Total Harmonic Distortion lt10 Signal to Noise Ratio gt50 dBA General information USBtype C charging port Power Supply 50V 30A 50V 20A Operation Power Consumption lt15 W Standby Power Consumption lt1 W Dimensions W x H x D 103x1035x103 mm Weight Main unit 375 g Connect the standard size end of a USB cable not included to the USBtype C Port on back of the unit and connect the other end to the charging port on your device USB type C port for charging out Other features RMS 700mW 10 THD Max14W
• Page 14 - English - : Troubleshooting Warning Never remove the casing of the product To keep the warranty valid never try to repair the device yourself If you encounter problems when using this device check the following points before requesting service If the problem remains unsolved go to the Philips webpage wwwphilipscomsupport When you contact Philips make sure that the device is nearby and the model number and serial number are available No power Make sure that the AC power plug of the unit is connected properly Make sure that there is power at the AC outlet No sound Adjust the volume No response from the unit Disconnect and reconnect the AC power plug then turn on the unit again Poor radio reception Keep the clock radio away from other electronic devices to avoid radio interference Fully extend and adjust the position of the antenna Alarm does not work Set the clockalarm correctly Clockalarm setting erased Power has been interrupted or the power plug has been disconnected Reset the clockalarm Replace the backup batteries 13 EN This symbol means the product must not be discarded as household waste and should be delivered to an appropriate collection facility for recycling Follow local rules and never dispose of the product and rechargeable batteries with normal household waste Correct disposal of old products and rechargeable batteries helps prevent negative consequences for the environment and human health This symbol means that the product contains batteries covered by European Regulation EU 20231542 which cannot be disposed of with normal household waste Inform yourself about the the local separate collection system for electrical and electronic collection system for electrical and electronic products and batteries Follow local rules and never dispose of the product and batteries with normal household waste Correct disposal of old products and batteries helps prevent negative consequences for the environment and human health Any changes or modications made to this device that are not expressly approved by MMD Hong Kong Holding Limited may void the users authority to operate the product Hereby TP Vision Europe BV declares that the product is in compliance with the essential requirements and other relevant provisions of RED Directive 201453EU and UK Radio Equipment Regulations SI 2017 No 1206 You can nd the Declaration of Conformity on wwwphilipscomsupport This product complies with the radio interference requirements of the European Community This product is designed and manufactured with highquality materials and components which can be recycled and reused Notice Compliance
• Page 15 - English - : TAR460010UMV10 MMD Hong Kong Holding Limited All rights reserved Specications are subject to change without notice Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips NV and are used under license This product has been manufactured by and is sold under the responsibility of MMD Hong Kong Holding Limited or one of its affiliates and MMD Hong Kong Holding Limited is the warrantor in relation to this product
