WA0221
P06
P10
P12
EN
F
ES
Brush Cutter Attachment
Accessoire pour débroussailleuse
Fijación de la desbrozadora
2
4
1
3
5
9
10
6
8
7
1
2
A
B
C
D
E1
E2
F
1
2
A
B
C
D
E1
E2
F
6
Brush Cutter Attachment EN
PRODUCT SAFETY
WARNING: This product can expose you
to chemicals including lead and Di(2-
ethylhexyl)phthalate (DEHP) which are known
to the State of California to cause cancer and
birth defects or other reproductive harm. For
more information go to www.P65Warnings.
ca.gov.
Important Safety Instructions
WARNING: Read all safety warnings
and instructions. Failure to follow the
warnings and instructions may result in
electric shock, fire and/or serious injury.
FOR ALL APPLIANCES:
1) Avoid Dangerous Environment - Don’t use
appliances in damp or wet locations.
2) Don’t Use In Rain.
3) Keep Children Away - All visitors should be kept
at a distance from work area.
4) Dress Properly - Do not wear loose clothing or
jewelry. They can be caught in moving parts.
Use of rubber gloves and substantial footwear
is recommended when working outdoors. Wear
protective hair covering to contain long hair.
5) Use Safety Glasses - Always use face or dust
mask if operation is dusty.
6) Use Right Appliance - Do not use appliance for
any job except that for which it is intended.
7) Don’t grasp the exposed cutting blades or
cutting edges when picking up or holding the
appliance.
8) Don’t Force Appliance - It will do the job better
and with less likelihood of a risk of injury at the
rate for which it was designed.
9) Don’t Overreach - Keep proper footing and
balance at all times.
10) Stay Alert - Watch what you are doing. Use
common sense. Do not operate appliance when
you are tired.
11) Store Idle Appliances Indoors - When not in use,
appliances should be stored indoors in dry, and
high or locked-up place - out of reach of children.
12) Maintain Appliance With Care - Keep cutting
edge sharp and clean for best performance and
to reduce the risk of injury. Follow instructions
for lubricating and changing accessories. Keep
handles dry, clean, and free from oil and grease.
13) Check Damaged Parts - Before further use of the
appliance, a guard or other part that is damaged
should be carefully checked to determine that it
will operate properly and perform its intended
function. Check for alignment of moving parts,
binding of moving parts, breakage of parts,
mounting, and any other condition that may
affect its operation. A guard or other part that
is damaged should be properly repaired or
replaced by an authorized service center unless
indicated elsewhere in this manual.
FOR ALL BATTERY – OPERATED GARDENING
APPLIANCES：
1. Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to battery
pack, picking up or carrying the appliance.
Carrying the appliance with your finger on the
switch or energizing appliance that have the
switch on invites accidents.
2. Disconnect the battery pack from the appliance
before making any adjustments, changing
accessories, or storing appliance. Such
preventive safety measures reduce the risk of
starting the appliance accidentally.
3. Recharge only with the charger specified by the
manufacturer .A charger that is suitable for one
type of battery pack may create a risk of fire when
used with another battery pack.
4. Use appliances only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
5. When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another. Shorting the battery terminals together
may cause burns or a fire.
6. Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause
irritation or burns.
7. Do not use a battery pack or appliance that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior
resulting in fire, explosion or risk of injury.
8. Do not expose a battery pack or appliance to fire
or excessive temperature. Exposure to fire or
temperature above 130°C may cause explosion.
9. Follow all charging instructions and do not charge
the battery pack or appliance outside of the
temperature range specified in the instructions.
Charging improperly or at temperatures outside
of the specified range may damage the battery
and increase the risk of fire.
10. Have servicing performed by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the product is
maintained.
11. Do not modify or attempt to repair the appliance
or the battery pack (as applicable) except as
indicated in the instructions for use and care.
BRUSH CUTTER SAFETY
WARNINGS
1. Physical Condition of Operator
Do not operate this unit when tired, ill, or under the
influence of alcohol, drugs, or medication.
2. Clothing Recommendation
Always wear heavy, long pants, boots, gloves, and
7
Brush Cutter Attachment EN
a long-sleeve shirt. Do not wear loose clothing,
jewelry, short pants, sandals, or go barefoot. Secure
hair so it is above shoulder level.
3. Condition of Unit Before Use
Inspect unit before each use. Replace damaged parts.
Make sure all fasteners are in place and secure.
Replace cutting attachment parts that are cracked,
chipped, or damaged in any way. Make sure the
cutting attachment is properly installed and securely
fastened. Be sure the cutting attachment shield is
properly attached and in the position recommended
by the manufacturer.
The handles shall be mounted in accordance with the
manufacturer’s instructions. Do not attach any blade
to a unit without proper installation of all required
parts. Failure to use the proper parts can cause the
blade to fly off and seriously injure the operator and/
or bystanders. Discard blades that are bent, warped,
cracked, broken, or damaged in any way. Use a sharp
blade. A dull blade is more likely to snag and thrust.
4. Proper Stance
Keep firm footing and balance. Do not over-reach.
Keep cutting attachment below waist level. Keep all
parts of your body away from the rotating cutting
attachment.
5. Work Area
Clear the area to be cut before each use. Remove all
objects such as rocks, broken glass, nails, wire, or
string, which can be thrown or become entangled in
the cutting attachment.
6. Stopping the Unit
A coasting blade can cause injury while it continues
to spin after the appliance is stopped. Maintain
proper control until the blade has completely
stopped rotating. When the unit is turned off, make
sure the cutting attachment has stopped before
servicing, cleaning or removing material from the
gardening appliance and before the unit is set down.
7. Blade Thrust Danger
Blade thrust may occur when the spinning blade
contacts an object that it does not immediately cut.
Blade thrust can be violent enough to cause the unit
and/or operator to be propelled in any direction, and
possibly lose control of the unit.
Blade thrust can occur without warning if the blade
snags, stalls or binds.
Blade thrust is more likely to occur in areas where it
is difficult to see the material being cut.
SAFETY WARNINGS FOR
BATTERY PACK
a) Do not dismantle, open or shred battery
pack.
b) Do not expose battery pack to heat or fire.
Avoid storage in direct sunlight.
c) Do not short-circuit a battery pack. Do not
store battery packs haphazardly in a box
or drawer where they may short-circuit
each other or be short-circuited by other
metal objects. When battery pack is not in use,
keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small
metal objects, that can make a connection from
one terminal to another. Shorting the battery
terminals together may cause burns or fire.
d) Do not remove battery pack from its
original packaging until required for use.
e) Do not subject battery pack to mechanical
shock.
f) In the event of battery leaking, do not allow
the liquid to come in contact with the skin
or eyes. If contact has been made, wash
the affected area with copious amounts of
water and seek medical advice.
g) Observe the plus (+) and minus (–) marks on
the battery back and equipment and ensure
correct use.
h) Do not use any battery pack which is not
designed for use with the equipment.
i) Keep battery pack out of the reach of
children.
j) Seek medical advice immediately if a cell or
battery has been swallowed.
k) Always purchase the battery pack
recommended by the device manufacturer
for the equipment.
l) Keep battery pack clean and dry.
m) Wipe the battery pack terminals with a
clean dry cloth if they become dirty.
n) Battery pack needs to be charged before
use. Always use the correct charger and
refer to the manufacturer’s instructions
or equipment manual for proper charging
instructions.
o) Do not leave battery pack on prolonged
charge when not in use.
p) After extended periods of storage, it may
be necessary to charge and discharge
the battery pack several times to obtain
maximum performance.
q) Battery pack gives its best performance
when it is operated at normal room
temperature (20 °C ± 5 °C).
r) When disposing of battery packs, keep
battery packs of different electrochemical
systems separate from each other.
s) Recharge only with the charger specified
by Worx. Do not use any charger other than
that specifically provided for use with the
equipment. A charger that is suitable for one
type of battery pack may create a risk of fire when
used with another battery pack.
t) Retain the original product literature for
future reference.
u) Use only the battery pack in the application
for which it was intended.
v) Remove the battery pack from the
equipment when not in use.
w) Dispose of properly.
SAVE THESE INSTRUCTIONS
8
Brush Cutter Attachment EN
SYMBOLS
To reduce the risk of injury, user must
read instruction manual
Wear ear protection
Wear head protection
Wear protective gloves
Wear protective footwear
The distance between the machine
and bystanders shall be at least 15 m
Beware of thrown objects
Beware of blade thrust
Li-Ion battery, battery must be recycled
Do not burn
Batteries may enter water cycle if
disposed improperly, which can be
hazardous for ecosystem. Do not
dispose of waste batteries as unsorted
municipal waste.
Remove battery from the socket before
carrying out any adjustment, servicing
or maintenance.
POSITEC Inc. has established a partnership with the
RBRC Corporation to recycle any Positec batteries
with the RBRC-call2recycle seal. For environmental
protection, please do not discard batteries in the
trash. After the batteries’ life cycle is ended, then
please call 1-800-822-8837 for a free service that will
properly dispose of the battery.
COMPONENT LIST
1. BLADE GUARD
2. BLADE
3. COVER/BLADE HOUSING
4. LOCK-NUT
5. WASHER *
6. SHOULDER STRAP
7. SAFETY-STOP GUARD
8. FLANGE
9. WRENCH
10. HEX KEY
*Spare part for after-market blades.
Not all the accessories illustrated or described
are included in standard delivery.
TECHNICAL DATA
WA0221
No load speed
6700r/min
Cutting diameter 9'' (25cm)
Machine weight 3.97lbs (1.8kg)
ACCESSORIES
WA0221
Wrench
1
Hex key
1
Shoulder strap
1
9
Brush Cutter Attachment EN
Safety-stop handle
1
Only use the appropriate accessories intended for
this tool. Accessory information can be found on
the product packaging, at a Worx dealer or on our
website at www.worx.com.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTEND USE
This attachment is intended for cutting thick brush.
ASSEMBLY & OPERATION
Action Figure
ASSEMBLY
Connecting
Remove the existing attachment, and
connect the pole hedge trimmer. Slip
the attachment into the shaft of the
main unit and secure in place with the
locking knob.
See Fig. A
Assembling the safety-stop handle
Loosen the screw on the auxiliary
handle, insert the safety-stop handle,
then tighten the screw to make sure it
is well fixed.
See Fig. B
Assembling the shoulder strap
See Fig. C
Assembling the safety guard
Remove (8) Flange. Remove three
screws and install (1) Safety Guard by
aligning three holes over screw holes.
Reinstall screws to secure safety guard.
Reinsert (8) Flange.
See Fig. D
Assembling the brush cutter blade
Insert (10) Hex Key into hole. Place (2)
blade over (8) Flange. Place (3) Cover
over blade. Then, use (9) wrench to
tighten (4) Lock-Nut.
See Fig.
E1, E2
OPERATION
Starting
Press the lock-off button first, then press
the switch trigger to start the machine.
See Fig. F
MAINTENANCE
Remove the battery from brush cutter
attachment before carrying out any
adjustment, servicing or maintenance.
There are no user serviceable parts in your power
tool. Never use water or chemical cleaners to
clean your power tool. Wipe clean with a dry cloth.
Always store your power tool in a dry place. Keep
the motor ventilation slots clean. Keep all working
controls free of dust.
FOR BATTERY TOOLS
The ambient temperature range for the use and
storage of tool and battery is 0℃-45℃ (32°F-113°F).
The recommended ambient temperature range for
the charging system during charging is 0℃-40℃
(32°F-104°F).
