www.warmlite.co
2000W
CONVECTION HEATER
MODEL WL41007
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
This product is only suitable for well insulated spaces or occasional use.
2
CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
TECHNICAL DATA
Description: Convection Heater
Model: WL41007
Rated Voltage: 220-240V
Frequency: 50-60Hz
Power Consumption: 1800 – 2000W
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
RK Wholesale LTD Quality Assurance, United Kingdom
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RK Wholesale LTD has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.
3
www.warmlite.co
WARNING:
This Appliance MUST be Earthed
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the mains lead of this appliance
may not correspond with the coloured markings
identifying the terminals in your plug, please
proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable). The
wire labelled blue is the neutral and must be
connected to the terminal marked [N].
The wire labelled brown is the live wire and must
be connected to the terminal marked [L].
The wire labelled green/yellow must be
connected to the terminal marked with the letter
[E].
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - then cut it o of the mains lead
and immediately dispose of it in a safe manner.
Never attempt to reuse the plug or insert it into a
socket outlet as there is a danger of an electric
shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neautral
(Blue)
Live
(Brown)
4
CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• Please ensure that the
appliance is used on a stable,
level, and heat resistant
surface.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT leave the appliance
unattended while it is
operating.
• Close supervision is
necessary when any
appliance is used by or near
children or pets.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards
involved.
• Children shall not play with
the appliance.
• Cleaning and user
maintenance shall not be
made by children without
supervision.
• Switch o at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• If the supply cord or appliance
is damaged, stop using
the appliance immediately
and seek advice from the
manufacturer or its service
agent or a similarly qualied
person.
• DO NOT let the cord hang
over the edge of a table or
counter or let it come into
contact with any hot surfaces.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer
apart from those supplied
with this product. DO NOT
use extension cords with the
appliance.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.
• DO NOT use this product
for anything other than its
intended use.
• This product is only suitable
for well insulated spaces or
occasional use.
5
www.warmlite.co
• This appliance is for
household use only.
• DO NOT carry the appliance
by the power cord.
• DO NOT use the appliance
outdoors.
• DO NOT use the heater
unless the feet are correctly
attached.
• Always ensure that the
heater is placed on a rm
level surface. Ensure that the
heater is not positioned close
to curtains, furniture or any
combustible materials as this
could create a re hazard.
• Allow a 50cm safe area
around the heater on the
top and sides and a 120cm
safe area at the front of the
appliance.
• The heater must not be
located immediately below a
mains socket outlet.
• WARNING! DO NOT cover
the heater as this may lead to
a re risk.
• WARNING! DO NOT obstruct
any of the openings of the
heater.
• WARNING! DO NOT insert
any object through any
openings on the heater.
• Check from time to time for
accumulated dust.
• WARNING! DO NOT use
the heater in areas where
ammable liquids are stored
or where ammable fumes
may be present.
• WARNING! DO NOT operate
the heater on a timer, or leave
on overnight.
• When not being used, please
unplug the heater from the
mains socket.
• Keep the mains lead away
from the hot body of the
heater and ensure that it is
not pulled tight between the
socket and the heater.
• WARNING! DO NOT use
the heater in the immediate
surroundings of a bath, a
shower, a swimming pool or
similar indoor locations and
DO NOT touch hot surfaces.
• Always unplug the heater
and allow it to cool before
moving it from one location to
another.
• WARNING! DO NOT attempt
to dismantle or repair any part
of the heater. This should only
be done by a qualied service
agent.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team.
HIGH VOLTAGE HOT SURFACE DO NOT COVER
6
CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
WHAT’S IN THE BOX
Instruction Manual
Convection Heater
2 Feet
4 Self Tapping Screws
1. Output Vents
2. Handles
3. Heat Control Switches
4. Thermostat Control knob
5. Feet
3
4
5
2 1
BEFORE YOUR FIRST USE:
1. Remove your appliance from the packaging.
2. Assemble your appliance.
3. Locate your appliance in accordance with the safety instructions.
4. Plug the appliance into the mains supply.
5. Your appliance is now ready for normal use.
Dispose of the packaging in a responsible manner.
7
www.warmlite.co
ASSEMBLY
Before using the heater, the feet (supplied
separately in the carton),
must be tted to the unit.
These are to be attached to
the base of the heater using
the 4 self-tapping screws
provided, taking care to
ensure that they are located correctly in the
bottom ends of the heater side mouldings.
USING YOUR APPLIANCE
NOTE: It is normal when the heaters are
turned on for the rst time or when they are
turned on after having not been used for a long
period of time the heaters may emit some smell
and fumes. This will disappear when the heater
has been on a short while.
1. Choose a suitable location for the heater,
taking into account the safety instructions.
2. Insert the plug of the heater into a suitable
socket.
3. Turn the thermostat knob fully in a
clockwise direction to the maximum
setting.
4. There are 3 heat settings, 750W, 1250W
& 2000W. To use your rst heat setting,
select the switch under the 750W mark.
To use the second heat setting only switch
on the switch under the 1250W mark.
To use your third setting of 2000W switch
on both switches at the same time.
The power indicator light will light up once
the switch is in the on position.
5. When the desired room temperature
has been reached, the thermostat knob
should be turned slowly anti-clockwise
until the thermostat is heard to click o
and the lights on the element switches are
seen to go out.
6. After this the heater will keep the air
temperature in the room at the set
temperature by switching on and o
automatically.
CLEANING AND CARE
• Before cleaning always switch o the
heater and remove the plug from the
electrical socket.
• Ensure that the unit is cool enough to
work on.
• To remove the dust, wipe the appliance
with a dry cloth.
• Never use abrasive powders or solvents.
• If the heater shows any signs of wear or
damage disconnect immediately from the
mains supply, DO NOT use it – have it
checked by a suitably qualied person.
WARNING:
DO NOT IMMERSE ANY ELECTRICAL PART
OF THE APPLIANCE IN WATER SUCH AS
MOTOR UNITS OR PLUGS.
PLEASE SEE CLEANING SECTION FOR
FURTHER INSTRUCTIONS.
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish.
You are required to dispose of old electrical
and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk
for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to
information about the recycling of electrical
items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it
has reached the end of its life.
8
CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
Model Identier(s): WL41007
Item Symbol Valve Unit Item Unit
Heat Output
Type of heat input for electric storage, local space
heaters only (select one)
Nominal heat
output
Pnom 1,8-2,0 kW
Manual heat charge with integrated
thermostat
N/A
Minimum heat
output (indicative)
Pmin 0,75 kW
Manual heat charge control with room
and/or outdoor temperature feedback
N/A
Maximum
continuous heat
output
Pmax, c 2,0 kW
Electronic heat charge control with room
and/or outdoor temperature feedback
N/A
Auxiliary electricity
consumption
Fan assisted heat output N/A
At nominal heat
output
elmax N/A kW
Type of heat output/room temperature control
(select one)
At minimum heat
output
elmin N/A kW
Single stage heat output and no room
temperature control
No
In standby mode eISB 0 kW
Two or more manual stages, no room
temperature control
No
With mechanic thermostat room temperature
control
Yes
With electronic room temperature control No
Electronic room temperature control plus day
timer
No
Electronic room temperature control plus
week timer
No
Other control options (multiple selections possible)
Room temperature control with presence
detection
No
Room temperature control with open
window detection
No
With distance control option No
With adaptive start control No
With working time limitation No
With black bulb sensor No
Contact Details: Imported by RK Wholesale LTD., Berryhill Road, Stoke-on-Trent ST4 2NL
9
www.warmlite.co
NOTES
10
CUSTOMER SUPPORT TEAM: +44 (0) 333 220 6056
NOTES
11
www.warmlite.co
NOTES
We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are oering you an extra 1 year peace of mind.
*To receive your extra guarantee period, register your appliance online
within 28 days of purchase by visiting:
www.warmlite.co
Make sure to retain your original receipt.
Should you have a problem
with your appliance or need any spare parts please call our
Customer Support Team on:
+44 (0) 333 220 6056
Distributed throughout the UK by RK Wholesale LTD
0319.V4
