www.warmlite.co
WALL-MOUNTED
FROST WATCHER
MODEL WL41003Y
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
2 CUSTOMER SERVICE TEAM: +44 (0) 333 220 6056
TECHNICAL DATA
Description: Frost Watcher
Model: WL41003
Rated Voltage: 220 - 240V
Frequency: ~ 50Hz
Power consumption: 500W
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
RKW Quality Assurance, United Kingdom
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RKW has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.
3www.warmlite.co
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the
mains lead of this
appliance may not
correspond with the
coloured markings
identifying the terminals
in your plug, please
proceed as follows:
The wires in the mains lead are coloured in
accordance with the following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable).
The wire coloured blue is the neutral and must
be connected to the terminal marked [N] or
coloured black.
The wire coloured brown is the live wire and
must be connected to the terminal marked [L] or
coloured red.
The wire coloured green/yellow must be
connected to the terminal marked with the letter
[E] or marked
.
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal
.
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - and then cut it o the mains
lead and immediately dispose of its safely. Never
attempt to reuse the plug or insert it into a
socket outlet as there is a danger of an electric
shock.
WARNING:
This Appliance MUST be Earthed
FUSE
4 CUSTOMER SERVICE TEAM: +44 (0) 333 220 6056
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• IMPORTANT: Only use appliance
when mounted to a wall.
• IMPORTANT: The wall mounting
bracket supplied with the
appliance must be used.
• DO NOT immerse cords, plugs
or any part of the appliance in
water or any other liquid.
• DO NOT leave the appliance
unattended while it is operating.
• Close supervision is necessary
when any appliance is used by
or near children or pets.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory or
mental capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved.
• Children shall not play with the
appliance.
• Cleaning and user maintenance
shall not be made by children
without supervision.
• Switch o at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• If the supply cord or appliance
is damaged, stop using the
appliance immediately and seek
advice from the manufacturer
or its service agent or a similarly
qualied person.
• DO NOT let the cord hang over
the edge of a table or counter or
let it come into contact with any
hot surfaces.
• The use of accessory
attachments is not
recommended by the appliance
manufacturer, apart from those
supplied with this product.
• DO NOT pull the plug out by the
cord as this may damage the
plug and/or the cable.
• Do not use this product for
anything other than its intended
use.
• This appliance is for household
use only.
• DO NOT carry the appliance by
the power cord.
• DO NOT use the appliance
outdoors.
5www.warmlite.co
• Always ensure that the heater
is only used when mounted on
a wall. Ensure that the heater is
not positioned close to curtains,
furniture or any combustible
materials as this could create a
re hazard.
• Allow a 50cm safe area around
the heater on the top and sides
and a 120cm safe area at the
front of the appliance.
• The heater must not be located
immediately below a mains
socket outlet.
• DO NOT cover the heater as this
may lead to a re risk.
• Do NOT obstruct any of the
openings of the heater.
• DO NOT insert any object
through any openings on the
heater.
• Check from time to time for
accumulated dust.
• DO NOT use the heater in
areas where ammable liquids
are stored or where ammable
fumes may be present.
• DO NOT operate the heater on a
timer, or leave on overnight.
• DO NOT operating the heater on
any oor or surface.
• When not being used, please
unplug the heater from the
mains socket.
• Keep the mains lead away from
the hot body of the heater and
ensure that it is not pulled tight
between the socket and the
heater.
• DO NOT use the heater in the
immediate surroundings of a
bath, a shower, a swimming
pool or similar indoor locations
and do not touch hot surfaces.
• Always unplug the heater and
allow it to cool before moving it
from one location to another.
• DO NOT attempt to dismantle
or repair any part of the heater.
This should only be done by a
qualied service agent.
• In the unlikely event the
appliance develops a fault,
stop using it immediately and
seek advice from the service
department.
HIGH VOLTAGE HOT SURFACE DO NOT COVER
6 CUSTOMER SERVICE TEAM: +44 (0) 333 220 6056
2
3
1
WHAT’S IN THE BOX
Instruction Manual
Frost Watcher
2 Screws
2 Rawlplugs
Wall Bracket
1. Convection Grills
2. Thermostat
3. Power Indicator
BEFORE YOUR FIRST USE:
1. Remove your appliance from the packaging.
2. Plug the appliance into the mains supply.
3. Safely mount the appliance on a wall, away from curtains, furniture or any combustible
materials.
4. Your appliance is now ready for normal use.
Dispose of the packaging in a responsible manner.
7www.warmlite.co
INSTALLING YOUR APPLIANCE
Please maintain the stated minimum distances.
WALL MOUNTING:
1. Unscrew the screws on the side from the
top cover.
2. Install the mounting bracket to the wall,
as shown in the drawing below. Two wall
anchors (6 mm) and mounting screws are
included.
3. Make sure that the device is mounted
level.
4. Hang the heater into the mounting bracket
and screw in the lateral screws back in
again.
5. The device may only be used when
installed on a wall and in an upright
(vertical position)!
6. After connecting the plug with the power
outlet the heater is ready to be used.
It must be guaranteed that a heater
permanently connected to the power
supply can be switched o through a
disconnection mechanism (e.g. a circuit
breaker, installation switch, etc.) with a
minimum separation distance of 3 mm to
the contact.
7. Should you have diculty tting this
product please contact your local
electrician.
8. If this product is being hard wire into you
electrical supply, it is recommend that any
installation of this nature is carried out by
a fully qualied electrician.
USING YOUR APPLIANCE
The heater WL41003 is only suitable to be
used in dry rooms (in accordance with the
norm IP 20).
The frost protection convector is intended to be
used in unheated rooms in order to prevent the
freezing of water pipes, frost damages on walls,
as well as for the hibernation of plants in the
house or winter garden.
The use of bathrooms as a frost protection
device is only permitted if it is guaranteed that
the device does not come into any contact with
humidity and moisture.
The heater may only be used when installed on
a wall and only for the purposes described.
The product automatically switches on when
the temp drops below 0°C, when the product
is set to the lowest setting
The thermostat will then control the
temperature upto a maximum of 30°C
depending on the room size. (The product will
not warm up a large room to 30°C !!)
8 CUSTOMER SERVICE TEAM: +44 (0) 333 220 6056
CLEANING AND CARE
• Before attempting to clean the appliance
please ensure that the appliance is
disconnected from the power supply to
ensure that there is no risk of electrical
shock.
• To clean the appliance use a damp cloth
with a small amount of mild detergent and
wipe the case of the appliance.
• Do not attempt to clean the internal
spaces.
• If the appliance shows any signs of wear
or damage disconnect immediately from
the mains supply, do NOT use it – have it
checked by a suitably qualied person.
WARNING:
DO NOT IMMERSE ANY PART OF THE
APPLIANCE IN WATER
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish.
You are required to dispose of old electrical
and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk
for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to
information about the recycling of electrical
items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it
has reached the end of its life.
9www.warmlite.co
NOTES
10 CUSTOMER SERVICE TEAM: +44 (0) 333 220 6056
NOTES
11www.warmlite.co
NOTES
We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are giving you an extra year peace of mind.
To receive your extra year guarantee, register your appliance online by visiting
www.warmlite.co
Should you have a problem
with your appliance or need any spare parts please call our
Customer Service Team on:
+44 (0) 333 220 6056
Distributed throughout the UK by RKW LTD
0617.V2
