Mounting Instructions
Use appropriate tools when performing work and always use eye
protection floor mounting.
Mounting Screws:
Floor Mounting
- Mark the exact position onto
the floor.
- Use proper drill tools
depending on the type of floor
you are mounting the drop box
(wood, tile, or concrete).
- Drill the appropriate size holes
for the anchors you are using.
- Carefully press the anchor into the holes at this time.
- Mount the safe by running screws from inside of the safe and
securing to anchors; ensure the parcel drop box mounted
securely.
Plates
Optional
Hole Plate
Propose is fixed hole. It can be
place under the drop box.
Partition Plate
This plate is installed inside the
drop box at the bottom of the
box at 20-30 cm.
The plate inside is removable.
Adding on screw is to prevent
the plate moves inside but it is
removable. If do not want to use
the inside plate, take off the
screw and remove the plate and
use the black plastic screw to
seal the hole or put the
screw back.
WARNING
Barska does not guarantee that its products will
absolutely stop theft, vandalism, burglary. Our products
are only a deterrent to such acts.
The parcel drop box must be mounted to the floor. Be
aware of the load bearing. Failure to do so can result in
personal injury and/or damage to property.
For Wood x 4 For Concrete x 4 x4
225
Screw
Partition
Plate
Hole Plate
Removable
Screw
Drop Box
Anchor
Floor
User Manual for Parcel Drop Box
Read all instructions before using drop box.
© 2021 BARSKA® | 855 Towne Center Drive | Pomona, CA 91767
(t) 888.666.6769 | (f) 909.445.8169 | www.barska.com
4/21 BC673
Side View
