Mounting Instructions
Use appropriate tools when performing work and always use eye
protection floor mounting.
Mounting Screws:
Floor Mounting
- Mark the exact position onto
the floor.
- Use proper drill tools
depending on the type of floor
you are mounting the drop box
(wood, tile, or concrete).
- Drill the appropriate size holes for the anchors you are using.
- Carefully press the anchor into the holes at this time.
- Mount the safe by running
screws from inside of the safe
and securing to anchors;
ensure the parcel drop box
mounted securely.
Plates
Optional
Hole Plate
Propose is fixed hole. It can be
place under the drop box.
For Wood x 4 For Concrete x 4 x4
Screw
Drop Box
Anchor
Floor
User Manual for Parcel Mail Box,
with One Drop Door
Read all instructions before using drop box.
© 2022 BARSKA® | 855 Towne Center Drive | Pomona, CA 91767
(t) 888.666.6769 | (f) 909.445.8169 | www.barska.com
12/21
WARNING
Barska does not guarantee that its products will
absolutely stop theft, vandalism, burglary. Our products
are only a deterrent to such acts.
The parcel drop box must be mounted to the floor. Be
aware of the load bearing. Failure to do so can result in
personal injury and/or damage to property.
BC686
