436LiB, 536LiB, 530iBX
EN Operator's manual 2-16
Contents
Introduction..................................................................... 2
Safety..............................................................................3
Assembly........................................................................ 8
Operation........................................................................ 8
Maintenance................................................................. 11
Troubleshooting............................................................ 12
Transportation, storage and disposal........................... 13
Technical data.............................................................. 14
Accessories.................................................................. 15
EC Declaration of Conformity....................................... 16
Introduction
Product overview
20
21
19
7 8
10 9
1
2
3
6
4
5
1
2
3
4
5
12
11
13
17
18
15
14
16
1. Blower nozzle
2. Keypad
3. Power trigger
4. Handle
5. Support eyelet for harness (536LiB, 530iBX)
6. Supports
7. Start/stop button
8. Warning indicator (ERROR LED)
9. Boost: Temporary increase of airflow
10. Cruise control: Set the optimal air flow for your work
11. Cord
12. Battery charger
13. Power and warning indicator
14. Battery release button
2 519 - 002 - 30.05.2018
15. Battery
16. Warning indicator (ERROR LED)
17. Battery indicator button
18. Battery status
19. Operator's manual
20. Harness (536LiB)
21. Harness, hip pad (530iBX)
Product description
Husqvarna 436LiB, 536LiB, 530iBX are blower models
with an electrical motor.
We have a policy of continuous product development
and therefore reserve the right to modify the design and
appearance of products without prior notice.
Intended use
This product is designed for blowing leaves and other
debris from lawns, pathways, asphalt roads and the like.
The product is designed for household use.
Symbols on the product
Warning! The blower can be dangerous!
Careless or incorrect use can result in
serious or fatal injury to the operator or
others. It is extremely important that you
read and understand the contents of the
operator's manual. Please read the
operator's manual carefully and make sure
you understand the instructions before using
the machine.
Use approved eye protection.
Direct current.
Noise emission to the environment refer to
the European Community's Directive. The
emission of the product is specified in the
Technical data chapter and on the label.
Symbols on the product or its packaging
indicate that this product cannot be handled
as domestic waste. This product must be
deposited at an appropriate recycling facility.
The product agrees with the applicable EC
directives.
Protected against splashing water.
The blower operator must ensure that
no people or animals come closer
than 15 metres. When several opera-
tors are working at the same site a
safety distance of at least 15 metres
must be in effect. The blower can for-
cibly throw objects that can bounce
back. This can result in serious eye
injuries if the recommended safety
equipment is not used.
yyyywwxxxx The rating plate shows the serial
number. yyyy is the production year,
ww is the production week and xxxx
is the sequential number.
Manufacturer
Husqvarna AB
Drottninggatan 2, SE-561 82 Huskvarna
Product liability
As referred to in the product liability laws, we are not
liable for damages that our product causes if:
• the product is incorrectly repaired.
• the product is repaired with parts that are not from
the manufacturer or not approved by the
manufacturer.
• the product has an accessory that is not from the
manufacturer or not approved by the manufacturer.
• the product is not repaired at an approved service
center or by an approved authority.
Safety
Safety definitions
Warnings, cautions and notes are used to point out
specially important parts of the manual.
WARNING: Used if there is a risk of injury or
death for the operator or bystanders if the
instructions in the manual are not obeyed.
CAUTION: Used if there is a risk of damage
to the product, other materials or the
adjacent area if the instructions in the
manual are not obeyed.
Note: Used to give more information that is necessary in
a given situation.
519 - 002 - 30.05.2018 3
Introduction
WARNING: Read all safety warnings and all
instructions. Failure to follow the warnings
and instructions may result in electric shock,
fire and/or serious injury.
General power tool safety warnings
Check before starting
• Inspect the working area. Remove all loose objects,
such as stones, broken glass, nails, steel wire, string
etc. that could be thrown out.
• Always remove the battery to prevent the machine
being started by accident. Always disconnect the
battery before any maintenance on the machine.
• Before using the machine and after any impact,
check for signs of wear or damage and repair as
necessary.
• Only use original spare parts.
• The machine operator must ensure that no people or
animals come closer than 15 metres while working.
When several operators are working in the same
area the safety distance should be at least 15
metres.
• Do an overall inspection of the machine before use,
see maintenance schedule.
• National or local regulations may regulate the use.
Comply to given regulations
Personal safety
• Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result
in serious personal injury.
• Keep bystanders away.
• This appliance is not intended for use by person
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety. Children should
be supervised to ensure that they do not play with
the appliance.
• Never allow children or other persons not trained in
the use of the machine and/or the battery to use or
service it. Local laws may regulate the age of the
user.
• Keep unauthorised persons at a distance. Children,
animals, onlookers and helpers should be kept
outside the safety zone of 15 m (50 ft.). Stop the
machine immediately if anyone approaches.
• Store the equipment in a lockable area so that it is
out of reach of children and unauthorized persons.
•
Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
• Never use the machine if you are tired, if you have
drunk alcohol, or if you are taking medication that
could affect your vision, your judgement or your
coordination.
• Wear personal protective equipment. See
instructions under the heading "Personal protective
equipment".
• Always remove the battery when passing the
machine to another person.
• Keep in mind that it is you, the operator that is
responsible for not exposing people or their property
to accidents or hazards.
Power tool use and care
• Never use a machine that has been modified in any
way from its original specification. Never use the
machine near explosive or flammable materials.
• Never use a machine that is faulty. Carry out the
safety checks, maintenance and service instructions
described in this manual. Some maintenance and
service measures must be carried out by trained and
qualified specialists. See instructions under the
heading Maintenance.
• Only use original spare parts.
• Always ensure that ventilation openings are kept
clear of debris.
• All covers, guards and handles must be fitted before
starting.
• Only use the machine in daylight or in other well-lit
conditions.
• Never use the machine in bad weather, for instance
in fog, in rain, damp or in wet locations, strong
winds, intense cold, risk of lightning, etc. Extremely
hot weather may cause overheating of the machine.
Operation in bad weather is tiring and can lead to
dangerous conditions, for instance slippery surfaces.
• If the machine starts vibrating abnormally, stop the
machine and remove the battery.
• Walk, never run.
General safety instructions
WARNING: Read the warning instructions
that follow before you use the product.
• Incorrect or careless use of the product can turn it
into a dangerous tool that can cause serious or even
fatal injury to the operator or others. You must read
and understand the contents of this operator's
manual.
• Under no circumstances may the design of the
product be modified without the permission of the
manufacturer. Never use a product that has been
modified in any way from its original specification
4
519 - 002 - 30.05.2018
and always use original accessories. Non-authorized
modifications and/or accessories can result in
serious personal injury or the death of the operator
or others. Your warranty may not cover damage or
liability caused by the use of non-authorized
accessories or replacement parts.
• This product produces an electromagnetic field
during operation. This field may under some
circumstances interfere with active or passive
medical implants. To reduce the risk of serious or
fatal injury, we recommend persons with medical
implants to consult their physician and the medical
implant manufacturer before operating this product.
Safety instructions for operation
WARNING: Read the warning instructions
that follow before you use the product.
• If you encounter a situation where you are uncertain
how to proceed you should ask an expert. Contact
your dealer or your service workshop. Avoid all
usage which you consider to be beyond your
capability.
• Never use the product in bad weather, for instance in
fog, in rain, strong winds, intense cold, etc.
• Do not allow children to use or be in the vicinity of
the product. Since the product is easy to start,
children may be able to start it if they are not kept
under full surveillance. This can mean a risk of
serious personal injury. Disconnect the battery when
the product is not under close supervision.
• Ensure that no people or animals come closer than
15 metres (50 ft.) while you work. When several
operators are working in the same area the safety
distance should be at least 15 metres. Otherwise
there is a risk of serious personal injury. Stop the
product immediately if anyone approaches. Never
swing the product around without first checking
behind you to make sure that no one is within the
safety zone.
• Make sure that you can move and stand safely.
Check the area around you for possible obstacles
(roots, rocks, branches, ditches, etcetera) in case
you have to move suddenly. Take great care when
you work on sloping ground.
• Keep a good balance and a firm foothold at all times.
Do not overreach.
• Listen out for warning signals or shouts when you
wear hearing protection. Always remove your
hearing protection as soon as the product stops.
• Show consideration to persons in your surroundings
by avoiding using the product at unsuitable times,
such as late in the evening or early in the morning.
Follow local regulations and ordinances.
• Use the product with the lowest possible airflow. It is
seldom necessary to use full airflow, and many work
procedures can be done at half airflow. A lower
airflow means less noise and less dust, and it is also
easier to keep control over the rubbish collected
together/moved.
• Use a rake or a brush to release rubbish stuck to the
ground.
• Hold the opening of the blower as close to the
ground as possible.
• Observe your surroundings. Direct the product away
from persons, animals, play areas, cars etc..
• Minimize the blowing time by lightly wetting dusty
areas or using spray equipment.
• Be aware of the wind direction. Work with the wind to
make your work easier.
• Stop the product and remove the battery if the
product starts to vibrate abnormally.
• Using the blower to move large piles is time
consuming and creates unnecessary noise.
• Clean up afterwards. Make sure that you have not
blown rubbish into someone's garden.
• Do not run with the product.
• The powerful currents of air can move objects at
such a speed that they can bounce back and cause
serious eye injuries.
• Do not direct the airflow towards people or animals.
• Stop the motor before you assemble or dismantle
accessories or other parts.
• Keep all parts of your body away from hot surfaces.
• Never put the product down when it is activated
unless you have it in clear sight.
• The blower must not be used while on a ladder or
scaffolding.
• Do not use the product unless you are able to call for
help in case of an accident.
519 - 002 - 30.05.2018
5
• Watch out for thrown objects. Stones, rubbish, etc.,
can be thrown up into the eyes causing blindness or
serious injury.
• Use a residual-current device (RCI) for increased
security. A residual-current device is fitted to protect
operators in case an electrical fault should occur.
• This product is renowned for its low vibration load.
Overexposure to vibration can lead to circulatory
damage or nerve damage in people who have
impaired circulation. Contact your doctor if you
experience symptoms of overexposure to vibration.
Such symptoms include numbness, loss of feeling,
tingling, pricking, pain, loss of strength, changes in
skin colour or condition. These symptoms normally
appear in the fingers, hands or wrists.
• Only use the product for the purpose it was intended
for.
• It is not possible to cover every conceivable situation
you can face. Always exercise care and use your
common sense. Avoid all situations which you
consider to be beyond your capability. If you still feel
uncertain about operating procedures after reading
these instructions, you should consult an expert
before continuing.
Personal protective equipment
WARNING: Read the warning instructions
that follow before you use the product.
• Always use approved personal protective equipment
when you use the product. Personal protective
equipment cannot fully prevent injury but it
decreases the degree of injury if an accident does
occur. Let your dealer help you select the right
equipment.
• Long term exposure to noice can result in damaged
hearing. In general, battery powered products are
relatively quiet but damage can result from a
combination of noise level and long usage.
recommends that operators use hearing protectors
when using products for a longer coherent time of a
day. Continual and regular users should have their
hearing checked regularly.
WARNING:
Hearing protectors limit the
ability to hear sounds and warning
signals.
• Use approved eye protection. If you use a visor, you
must also use approved protective goggles.
Approved protective goggles must comply with the
ANSI Z87.1 standard in the USAs or EN 166 in EU
countries.
• Use clothing made of a strong fabric. Always use
heavy, long pants and long sleeves. Do not use
loose clothing that can catch on twigs and branches.
Do not wear jewelry, short pants, sandals or go with
bare feet. Put your hair up safely above shoulder
level.
• Keep first aid equipment close at hand.
• A breathing mask should be used when there is a
risk of dust.
Safety devices on the product
WARNING: Read the warning instructions
that follow before you use the product.
In this section the product’s safety features, its purpose
and how checks and maintenance should be carried out
to ensure that it operates correctly. See instructions
under the heading
Product overview on page 2
to find
where these parts are located on your product.
The life span of the product can be reduced and the risk
of accidents can increase if product maintenance is not
carried out correctly and if service and/or repairs are not
carried out professionally. If you need further information
please contact your nearest servicing dealer.
WARNING:
Never use a product with
defective safety components. The product's
safety equipment must be inspected and
maintained as described in this section. If
your product fails any of these checks,
contact your service agent to get it repaired.
CAUTION: All servicing and repair work on
the machine requires special training. This is
especially true of the machine′s safety
equipment. If your machine fails any of the
checks described below you must contact
your service agent. When you buy any of
our products we guarantee the availability of
professional repairs and service. If the
6 519 - 002 - 30.05.2018
retailer who sells your machine is not a
servicing dealer, ask him for the address of
your nearest service agent.
To do a check of the keypad
1. Press and hold the start/stop button (B).
A
B
C
a) The product is switched on when the LED (A) is
lit.
b) The product is switched off when the LED (A) is
out.
2. See
Troubleshooting on page 12
if the warning
indicator (C) is lit or flashes.
To do a check of the power trigger
1. Push and release the power trigger to make sure
that it moves freely.
Battery safety
WARNING: Read the warning instructions
that follow before you use the product.
• Only use the Husqvarna BLi batteries that we
recommend for your product. The batteries are
software encrypted.
• Use the Husqvarna BLi batteries that are
rechargable as a power supply for the related
Husqvarna products only. To prevent injury, do not
use the battery as a power supply for other devices.
• Risk of electrical shock. Do not connect the battery
terminals to keys, screws or other metal. This can
cause a short circuit of the battery.
• Do not use batteries that are non-rechargable.
• Do not put objects into the air slots of the battery.
• Keep the battery away from sunlight, heat or open
flame. The battery can blow up and cause burns
and/or chemical burns.
• Keep the battery away from rain and wet conditions.
• Keep the battery away from microwaves and high
pressure.
• Do not try to disassemble or break the battery.
• Do not let battery acid touch your skin. Battery acid
causes injuries to the skin, corrosion and burns. If
you get battery acid in your eyes, do not rub but
flush with water for minimum 15 minutes. If battery
acid has touched your skin, you must clean the skin
with a large quantity of water and soap. Get medical
aid.
• Use the battery in temperatures between -10 °C (14
°F) and 40 °C (104 °F).
• Do not clean the battery or the battery charger with
water. See
To clean the product, the battery and the
battery charger on page 12
.
• Do not use a defective or damaged battery.
• Keep batteries in storage away from metal objects
such as nails, screws or jewelry.
• Keep the battery away from children.
Battery charger safety
WARNING: Read the warning instructions
that follow before you use the product.
• Risk of electrical shock or short circuit if the safety
instructions are not obeyed.
• Use an approved grounded mains socket that is not
damaged.
• Do not use other battery chargers than the one
supplied for your product. Only use Husqvarna QC
chargers when you charge Husqvarna BLi
replacement batteries.
• Do not try to disassemble the battery charger.
• Do not use a defective or damaged battery charger.
• Do not lift the battery charger by the power cord. To
disconnect the battery charger from a mains socket,
pull out the plug. Do not pull the power cord.
• Keep all cables and extension leads away from
water, oil and sharp edges. Make sure that the cable
is not caught between doors, fences or similar.
• Do not use the battery charger near flammable
materials or materials that can cause corrosion.
Make sure that the battery charger is not covered.
Pull out the plug to the battery charger if there is
smoke or fire.
• Only charge the battery indoors in a location with
good airflow and away from sunlight. Do not charge
the battery outdoors. Do not charge the battery in
wet conditions.
• Only use the battery charger where the temperature
is between 5 °C (41 °F) and 40 °C (104 °F). Use the
charger in an environment which has a good airflow,
dry and free from dust.
• Do not put objects into the cooling slots of the
battery charger.
519 - 002 - 30.05.2018
7
• Do not connect the battery charger terminals to
metal objects as this can short circuit the battery
charger.
• Use approved wall sockets that are not damaged.
Safety instructions for maintenance
WARNING: Read the warning instructions
that follow before you do maintenance on
the product.
• Remove the battery before you do maintenance,
other checks or assemble the product.
• The operator must only do the maintenance and
servicing shown in this operator's manual. Turn to
your servicing dealer for maintenance and servicing
of a larger extension.
• Do not clean the battery or the battery charger with
water. Strong detergent can cause damage to the
plastic.
• If you do not do maintenance, it decreases the life
cycle of the product and increases the risk of
accidents.
• Special training is necessary for all servicing and
repair work, especially for the safety devices on the
product. If not all checks in this operator's manual
are approved after you have done maintenance, turn
to your servicing dealer. We guarantee that there are
professional repairs and servicing available for your
product.
• Only use original spare parts.
Assembly
To assemble the tube on the product
1. Put the blower nozzle over the tubular end of the
product.
2. Push the blower nozzle in fully and turn the blower
nozzle to lock it to the product.
To adjust the harness
1. Put the hip pad straps through the fastenings in the
harness for the backpack battery.
2. Adjust the harness to optimize the work position.
Operation
Introduction
WARNING: Read and understand the safety
chapter before you use the product.
To do a function check before you use
the product
1. Do a check of the air inlet for dirt and cracks. Use a
brush and clean off grass and leaves from the
product.
2. Make sure that the product works correctly.
3. Do a check of all nuts and screws and make sure
that they are tight.
8 519 - 002 - 30.05.2018
To connect the battery charger
1. Connect the battery charger to the voltage and
frequency specified on the rating plate.
2. Put the plug in a grounded socket outlet. The LED
on the battery charger flashes green one time.
Note: The battery will not charge if the battery
temperature is more than 50 °C/122 °F. If the
temperature is more than 50 °C/122 °F, the battery
charger will cool down the battery.
Backpack battery (530iBX)
The backpack battery capacity is shown with digits on
the product and the LED lamps on the backpack battery.
See the backpack battery operator's manual for
information about how to charge and do maintenance on
the backpack battery.
To charge the battery
Note: Charge the battery if it is the first time that you use
it. A new battery is only 30% charged.
1. Make sure that the battery is dry.
2. Put the battery in the battery charger.
3. Make sure that the green charging light on the
battery charger comes on. That means that the
battery is connected correctly to the battery charger.
4. When all LEDs on the battery come on, the battery is
fully charged.
5. To disconnect the battery charger from the mains
socket, pull the plug. Do not pull the cable.
6. Remove the battery from the battery charger.
Note: Refer to the battery and battery charger manuals
for more information.
To connect the battery to the product
WARNING: Only use Husqvarna original
batteries in the product.
1. Make sure that the battery is fully charged.
519 - 002 - 30.05.2018
9
2. Slide the battery into the battery holder of the
product. The battery must slide easily, if not, it is not
installed correctly.
3. Press the lower part of the battery and push it in as
far as it will go into the battery compartment. The
battery will lock into position when you hear a click.
4. Make sure that the latches snap in place correctly.
To connect the backpack battery to the
product
1. Connect the adapter cable from the product to the
backpack battery.
2. Fasten the battery cable in the attachments on the
harness.
3. When the back pack battery is used, carry the
backpack battery on the back.
To start the product
1. Press and hold the start button until the green LED
light comes on.
2. Use the power trigger to control the speed.
To start the product
When the backpack battery starts there is a startup time
of about 4 seconds (software booting). During that time,
you can hear the fans inside the backpack battery
blowing and a green LED on the battery blinks. When
the green LED is lit on the battery, the product is ready
to start.
1. Start the backpack battery. Do not proceed the steps
that follow before the green LED is lit.
2. Press and hold the start button until the green LED
light comes on.
3. Use the power trigger to control the speed.
To stop the product
1. Release the power trigger.
2. Press and hold the stop button until the green LED
light comes off.
3. Remove the battery from the product. Press the two
release buttons and pull out the battery.
To stop product and the backpack
battery
1. Release the power trigger.
2. Press and hold the stop button until the green LED
light comes off.
10
519 - 002 - 30.05.2018
3. Unplug the backpack battery cable from the product
.
Note: If the backpack battery is not used for more than
30 minutes, the backpack battery turns off automatically.
To start the backpack battery again, press the start
button on the backpack battery.
To set the optimal airflow for your work
1. Press the power trigger to choose the optimal airflow
for your work.
2. Press the cruise control button to set the chosen
airflow, the LED comes on.
3. Continue to work without needing to press the power
trigger.
4. Press the cruise control button again to deactivate
the cruise control function.
To temporarily increase the airflow
1. Start the product. See
To start the product on page
10
.
2. Press and hold the boost button to get the maximum
airflow, the LED comes on.
a) 536LiB, 530iBX has unlimited boost time.
b) 436LiB has a limited boost time of 30 seconds.
Release and press the boost button again.
3. Release the boost button to use the product with
normal air flow.
Maintenance
Introduction
WARNING: Before you do any maintenance
work you must read and understand the
safety chapter.
Maintenance schedule
WARNING: Remove the battery before you
do maintenance.
The following is a list of the maintenance steps that you
must do on the product.
Maintenance Daily Weekly Monthly
Clean the outside of the machine with a clean and dry cloth. Never use water. X
Keep handles dry, clean and free from oil and grease. X
519 - 002 - 30.05.2018 11
Maintenance Daily Weekly Monthly
Make sure that the start/stop button works correctly and is not damaged. X
Make sure the power trigger is functioning properly with regard to safety. X
Check that nuts and screws are tight. X
Check that the battery is intact. X
Check the battery's charge. X
Check that the release buttons on the battery works and locks the battery into
the machine.
X
Check that the battery charger is intact and functional. X
Check that all couplings, connections and cables are intact and free from dirt. X
Check the connections between the battery and the machine and also check the
connection between battery and the battery charger.
X
To do a check of the air intake
1. Make sure that the air intake is not blocked on any
side on the product.
2. Stop the product and remove leaves or unwanted
material if necessary.
CAUTION: A blocked air intake
decreases the blowing capacity of the
product and increases the motor's
working temperature. This can result in
motor failure due to overheating.
To examine the battery and the battery
charger
1. Examine the battery for damages, for example
cracks.
2. Examine the battery charger for damages, for
example cracks.
3. Make sure that the battery charger connection wire
is intact and that there are no cracks in it.
To clean the product, the battery and
the battery charger
1. Clean the product with a dry cloth after use.
2. Clean the battery and battery charger with a dry
cloth. Keep the battery guide tracks clean.
3. Make sure that the terminals on the battery and the
battery charger are clean before the battery is put in
the battery charger or the product.
Troubleshooting
Keypad
Keypad Possible faults Possible action
Green LED flashing Low battery voltage. Charge the battery.
Red error LED flashing The power trigger and the start but-
ton are pressed at the same time.
Release the power trigger and the
product becomes active.
Temperature deviation. Let the product cool down.
The product does not start Dirt in battery connectors. Clean with compressed air or a soft
brush.
12 519 - 002 - 30.05.2018
Keypad Possible faults Possible action
Red error LED is lit The product needs servicing. Contact your servicing agent.
Battery
LED display Possible faults Possible action
Green LED flashing Low battery voltage. Charge the battery.
Red error LED flashing The battery is discharged. Charge the battery.
Temperature deviation. Use the battery in tempereatures be-
tween -10°C (14°F) and 40°C
(104°F).
Over voltage. Check that the mains voltage corre-
sponds with that stated on the rating
plate on the product.
Remove the battery from the battery
charger.
Red error LED is lit Cell difference is to much (1V). Contact your servicing agent.
Backpack battery
See the backpack battery manual for troubleshooting of
the backpack battery.
Battery charger
LED display Possible faults Possible action
Red error LED flashing Temperature deviation. Use the battery charger in surround-
ings where tempereatures are be-
tween 5 °C (41 °F) and 40 °C (104
°F).
Red error LED is lit Contact your service agent.
Transportation, storage and disposal
Transportation and storage
• The supplied Li-ion batteries obey the Dangerous
Goods Legislation requirements.
• Obey the special requirement on package and labels
for commercial transportations, including by third
parties and forwarding agents.
• Speak to a person with special training in dangerous
material before you send the product. Obey all
applicable national regulations.
• Use tape on open contacts when you put the battery
in a package. Put the battery in the package tightly
to prevent movement.
• Remove the battery for storage or transportation.
• Put the battery and the battery charger in a space
that is dry and free from moisture and frost.
• Do not keep the battery in an area where static
electricity can occur. Do not keep the battery in a
metal box.
• Put the battery in storage where the temperature is
between 5 °C (41 °F) and 25 °C (77 °F) and away
from open sunlight.
519 - 002 - 30.05.2018 13
• Put the battery charger in storage where the
temperature is between 5 °C (41 °F) and 45 °C (113
°F) and away from open sunlight.
• Charge the battery 30% to 50% before you put it in
storage for long periods.
• Put the battery charger in storage in a space that is
closed and dry.
• Keep the battery away from the battery charger
during storage. Do not let children and other not
approved persons to touch the equipment. Keep the
equipment in a space that you can lock.
• Clean the product and do a full servicing before you
put the product in storage for a long time.
• Use the transportation guard on the product to
prevent injuries or damage on the product during
transportation and storage.
• Attach the product safely during transportation.
Disposal of the battery, battery charger
and product
The symbol below means that the product is not
domestic waste. Recycle it at a recycling station for
electrical and electronic equipment. This helps to
prevent damage to the environment and to persons.
Speak to local authorities, domestic waste service or
your dealer for more information.
Note: The symbol shows on the product or package of
the product.
Technical data
Technical data
436LiB 536LiB 530iBX
Motor
Motor type BLDC (brushless)
36V
BLDC (brushless)
36V
BLDC (brushless)
36V
Weight
Weight without battery, kg/ lb 2.5/5.5 2.4/5.3 2.9/6.4
1
Noise emissions
2
Sound power level, measured dB (A) 95 97 90
Sound power level, guaranteed L
WA
dB (A) 96 98 91
Water protection level
All weather use Yes Yes Yes
IPX4
3
No Yes Yes
Sound levels
4
Equivalent sound pressure level at the oper-
ator's ear, measured according to EN ISO
11203 and ISO 22868, dB (A):
81 82 77.6
1
weight with cable included
2
Noise emissions in the environment measured as sound power (L
WA
) in conformity with EC directive
2000/14/EC. Reported sound power level for the machine has been measured with the original cutting attach-
ment that gives the highest level. The difference between guaranteed and measured sound power is that the
guaranteed sound power also includes dispersion in the measurement result and the variations between dif-
ferent machines of the same model according to Directive 2000/14/EC.
3
The Husqvarna Handheld Battery products marked with IPX4 fulfils these requirements on product approval
level
4
Reported data for equivalent sound pressure level for the machine has a typical statistical dispersion (stand-
ard deviation) of 3 dB (A).
14 519 - 002 - 30.05.2018
436LiB 536LiB 530iBX
Vibration levels
5
Vibrations levels at handles, measured ac-
cording to ISO 22867, m/s
2
0.7 0.5 0.4
Fan performance
Air flow in normal mode with standard noz-
zle, m
3
/min
11.0 11.6 12.1
Maximum air velocity in normal mode with
standard nozzle, m/s / mph
47 / 105.1 48 / 107.4 49 / 109.6
Noise and vibration data are determined on the basis of
the rated maximum speed.
Approved batteries
Only use original Husqvarna BLi batteries for this
product.
Approved battery chargers
Battery charger QC330 QC500
Input voltage, V 100-240 100-240
Frequency, Hz 50-60 50-60
Power, W 330 500
Accessories
Approved accessories
Approved accessories
Type Art. no.
Nozzle (lenght)
Flat Nozzle 600 mm) 579 79 75-01
Round Nozzle with metal ring
(300 mm)
586 10 63-01
Round Nozzle with metal ring
(400 mm)
586 10 63-02
Nozzle Silencer (400 mm) 589 81 17-01
Handlebar Handlebar for 530iBX 501 71 51-01
Battery belt FLEXI
Carrying Kit for BLi batteries 590 77 67-01
Adapter Kit for 436LiB and
536LiB
590 77 67-02
Connector Kit for 530iBX
6
590 77 67-03
5
Reported data for vibration level has a typical statistical dispersion (standard deviation) of 2 m/s
2
.
6
436LiB and 536LiB requires the backpack BLiX-adapter
519 - 002 - 30.05.2018 15
EC Declaration of Conformity
EC Declaration of conformity
Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: tel:
+46-36-146500, declares under sole responsibility that
the battery leaf blowers Husqvarna 436LiB and 536LiB
from 2018’s serial numbers and onwards (the year is
clearly stated in plain text on the type plate with
subsequent serial number), are in conformity with the
requirements of the COUNCIL’S DIRECTIVES:
• of May 17, 2006 ”relating to machinery” 2006/42/EC.
• of February 26, 2014 ”relating to electromagnetic
compatibility” 2014/30/EU.
• of September 6, 2006 "on batteries and
accumulators and waste batteries and accumulators"
2006/66/EC
• of May 8, 2000 ”relating to the noise emissions in the
environment” 2000/14/EC.
• of June 8, 2011 on the "restriction of use of certain
hazardous substances" 2011/65/EU
The following standards have been applied: EN
60335-1:2012+A11:2014, (IEC 60335-2-100:2002), EN
ISO 14982:2009, CISPR 12:2007+A1:2009
In addition, RISE SMP Svensk Maskinprovning AB, ,
Sweden, has certified conformity with annex V of the
Council's Directive of May 8, 2000 "relating to the noise
emissions in the environment" 2000/14/EC. The
certificates have the numbers: 01/012/006-436LiB,
01/012/007-536LiB.
For information relating to noise emissions, see
Technical data on page 14
.
Huskvarna, 2018-01-02
Lars Roos, Development manager (Authorized
representative for Husqvarna AB and responsible for
technical documentation.)
EC Declaration of conformity
Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: tel:
+46-36-146500, declares under sole responsibility that
the battery leaf blower Husqvarna 530iBX from 2018’s
serial numbers and onwards (the year is clearly stated in
plain text on the type plate with subsequent serial
number), are in conformity with the requirements of the
COUNCIL’S DIRECTIVES:
• of May 17, 2006 ”relating to machinery” 2006/42/EC.
• of February 26, 2014 ”relating to electromagnetic
compatibility” 2014/30/EU.
• of September 6, 2006 "on batteries and
accumulators and waste batteries and accumulators"
2006/66/EC
• of May 8, 2000 ”relating to the noise emissions in the
environment” 2000/14/EC.
• of June 8, 2011 on the "restriction of use of certain
hazardous substances" 2011/65/EU
The following standards have been applied: EN
60335-1:2012+A11:2014, (IEC 60335-2-100:2002), EN
55014-1:2006+A1:2009, EN 61000-6-2:2005
In addition, RISE SMP Svensk Maskinprovning AB, ,
Sweden, has certified conformity with annex V of the
Council's Directive of May 8, 2000 "relating to the noise
emissions in the environment" 2000/14/EC. The
certificates has the number: 01/012/009.
For information relating to noise emissions, see
Technical data on page 14
.
Huskvarna, 2018-06-15
Lars Roos, Development manager (Authorized
representative for Husqvarna AB and responsible for
technical documentation.)
16 519 - 002 - 30.05.2018
519 - 002 - 30.05.2018 17
18 519 - 002 - 30.05.2018
519 - 002 - 30.05.2018 19
www.husqvarna.com
Original instructions
1159794-26
2018-06-12
