120iB
EN Operator's manual 2-22
Contents
Introduction..................................................................... 2
Safety..............................................................................3
Assembly...................................................................... 14
Operation...................................................................... 14
Maintenance................................................................. 16
Troubleshooting............................................................ 17
Transportation, storage and disposal........................... 18
Technical data.............................................................. 18
EC Declaration of Conformity....................................... 21
Introduction
Product overview
BLi
1
6
9
7
8
2
3
4
5
15
15
14
10
131211
16
1. Blower nozzle
2. Keypad
3. Power trigger
4. Handle
5. Supports
6. Airflow indicator
7. Warning indicator (error LED)
8. Mode control
9. Start/stop button
10. Battery release button
11. Battery status
12. Warning indicator (error LED)
13. Power and warning indicator
14. Battery, included in the Husqvarna 120iB blower kit
only
15. Battery charger, included in the Husqvarna 120iB
blower kit only
16. Operator's manual
Product description
The Husqvarna 120iB is a blower model with an electric
motor.
We have a policy of continuous product development
and therefore reserve the right to modify the design and
the appearance of the products without prior notice.
2 1310 - 005 - 21.04.2022
Intended use
This product is designed for blowing leaves and other
debris from lawns, pathways, asphalt roads and the like.
The product is designed for household use.
Symbols on the product
WARNING! This product is dangerous.
Injury or death can occur to the operator
or bystanders if the product is not used
carefully and correctly. To prevent injury
to the operator or bystanders, read
and obey all safety instructions in the
operator's manual.
Use approved eye protection.
Rated voltage, V
Direct current.
Noise emission to the environment
label as per EU and UK directives
and regulations, and New South Wales
legislation "Protection of the Environment
Operations (Noise Control) Regulation
2017". The guaranteed sound power level
of the product is specified in
Technical
data on page 18
.
The product or package of the product
is not domestic waste. Recycle it at
a recycling station for electrical and
electronic equipment.
The product agrees with the applicable
EC directives.
This product conforms to the applicable
UK regulations.
Do not use in rain.
The blower operator must ensure that
no people or animals come closer
than 15 metres. When several opera-
tors are working at the same site a
safety distance of at least 15 metres
must be in effect. The blower can for-
cibly throw objects that can bounce
back. This can result in serious eye
injuries if the recommended safety
equipment is not used.
yyyy wwxxxxx The rating plate shows serial number.
yyyy is the production year, ww is the
production week.
Manufacturer
Husqvarna AB
Drottninggatan 2, SE-561 82 Huskvarna
Product liability
As referred to in the product liability laws, we are not
liable for damages that our product causes if:
• the product is incorrectly repaired.
• the product is repaired with parts that are not
from the manufacturer or not approved by the
manufacturer.
• the product has an accessory that is not from the
manufacturer or not approved by the manufacturer.
• the product is not repaired at an approved service
center or by an approved authority.
Safety
Safety definitions
Warnings, cautions and notes
are used to point out specially
important parts of the manual.
WARNING: Used if
there is a risk of
injury or death for the
operator or bystanders
1310 - 005 - 21.04.2022 3
if the instructions in the
manual are not obeyed.
CAUTION: Used if there
is a risk of damage to the
product, other materials
or the adjacent area if
the instructions in the
manual are not obeyed.
Note: Used to give more
information that is necessary in
a given situation.
Introduction
WARNING: Read all
safety warnings and all
instructions. Failure to
follow the warnings and
instructions may result in
electric shock, fire and/or
serious injury.
General power tool safety
warnings
Check before starting
•
Inspect the working area.
Remove all loose objects,
such as stones, broken glass,
nails, steel wire, string etc. that
could be thrown out.
•
Always remove the battery to
prevent the machine being
started by accident. Always
disconnect the battery before
any maintenance on the
machine.
•
Before using the machine and
after any impact, check for
signs of wear or damage and
repair as necessary.
•
Only use original spare parts.
•
The machine operator must
ensure that no people or
animals come closer than 15
metres while working. When
several operators are working
in the same area the safety
distance should be at least 15
metres.
•
Do an overall inspection of
the machine before use, see
maintenance schedule.
•
National or local regulations
may regulate the use. Comply
to given regulations.
Personal safety
•
Stay alert, watch what you
are doing and use common
sense when operating a power
tool. Do not use a power tool
while you are tired or under
the influence of drugs, alcohol
or medication. A moment
of inattention while operating
power tools may result in
serious personal injury.
•
Keep bystanders away.
4
1310 - 005 - 21.04.2022
•
This appliance is not
intended for use by person
(including children) with
reduced physical, sensory
or mental capabilities, or
lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use of
the appliance by a person
responsible for their safety.
Children should be supervised
to ensure that they do not play
with the appliance.
•
Never allow children or other
persons not trained in the use
of the machine and/or the
battery to use or service it.
Local laws may regulate the
age of the user.
•
Keep unauthorised persons at
a distance. Children, animals,
onlookers and helpers should
be kept outside the safety
zone of 15 m (50 ft.). Stop
the machine immediately if
anyone approaches.
•
Store the equipment in a
lockable area so that it is
out of reach of children and
unauthorized persons.
•
Dress properly. Do not wear
loose clothing or jewellery.
Keep your hair, clothing and
gloves away from moving
parts. Loose clothes, jewellery
or long hair can be caught in
moving parts.
•
Never use the machine if you
are tired, if you have drunk
alcohol, or if you are taking
medication that could affect
your vision, your judgement or
your coordination.
•
Wear personal protective
equipment. See instructions
under the heading "Personal
protective equipment".
•
Always remove the battery
when passing the machine to
another person.
•
Keep in mind that it is you, the
operator that is responsible
for not exposing people or
their property to accidents or
hazards.
Power tool use and care
•
Never use a machine that
has been modified in any way
from its original specification.
Never use the machine
near explosive or flammable
materials.
•
Never use a machine that
is faulty. Carry out the
safety checks, maintenance
and service instructions
described in this manual.
Some maintenance and
service measures must be
carried out by trained and
1310 - 005 - 21.04.2022
5
qualified specialists. See
instructions under the heading
Maintenance.
•
Only use original spare parts.
•
Always ensure that ventilation
openings are kept clear of
debris.
•
All covers, guards and handles
must be fitted before starting.
•
Only use the machine in
daylight or in other well-lit
conditions.
•
Never use the machine in
bad weather, for instance
in fog, in rain, damp or in
wet locations, strong winds,
intense cold, risk of lightning,
etc. Extremely hot weather
may cause overheating of the
machine. Operation in bad
weather is tiring and can lead
to dangerous conditions, for
instance slippery surfaces.
•
If the machine starts vibrating
abnormally, stop the machine
and remove the battery.
•
Walk, never run.
General safety instructions
WARNING: Read the
warning instructions that
follow before you use the
product.
•
Incorrect or careless use of
the product can turn it into a
dangerous tool that can cause
serious or even fatal injury to
the operator or others. You
must read and understand
the contents of this operator's
manual.
•
Under no circumstances
may the design of
the product be modified
without the permission of
the manufacturer. Never
use a product that has
been modified in any
way from its original
specification and always
use original accessories.
Non-authorized modifications
and/or accessories can result
in serious personal injury or
the death of the operator
or others. Your warranty
may not cover damage or
liability caused by the use of
non-authorized accessories or
replacement parts.
•
This product produces an
electromagnetic field during
operation. This field may
under some circumstances
interfere with active or passive
medical implants. To reduce
the risk of serious or fatal
injury, we recommend persons
with medical implants to
consult their physician and the
6
1310 - 005 - 21.04.2022
medical implant manufacturer
before operating this product.
•
Remove the battery from the
product during charging.
Safety instructions for operation
WARNING: Read the
warning instructions that
follow before you use the
product.
• If you encounter a situation
where you are uncertain how
to proceed you should ask an
expert. Contact your dealer or
your service workshop. Avoid
all usage which you consider
to be beyond your capability.
• Make sure that you can move
and stand safely. Check
the area around you for
possible obstacles (roots,
rocks, branches, ditches,
etcetera) in case you have to
move suddenly. Take great
care when you work on
sloping ground.
• Keep a good balance and a
firm foothold at all times. Do
not overreach.
• Listen out for warning
signals or shouts when
you wear hearing protection.
Always remove your hearing
protection as soon as the
product stops.
• Do not operate the product
near open windows.
• Show consideration to
persons in your surroundings
by avoiding using the product
at unsuitable times, such as
late in the evening or early
in the morning. Follow local
regulations and ordinances.
• Use the product with the
lowest possible airflow. It is
seldom necessary to use
full airflow, and many work
procedures can be done at
half airflow. A lower airflow
means less noise and less
dust, and it is also easier to
keep control over the rubbish
collected together/moved.
• In dusty conditions slightly
dampen the surface when
using the product.
• Use a rake or a brush to
release rubbish stuck to the
ground.
• Hold the opening of the
blower as close to the ground
as possible.
• Observe your surroundings.
Direct the product away from
persons, animals, play areas,
cars etc..
1310 - 005 - 21.04.2022
7
• Minimize the blowing time by
lightly wetting dusty areas or
using spray equipment.
• Be aware of the wind
direction. Work with the wind
to make your work easier.
• Stop the product and remove
the battery if the product
starts to vibrate abnormally.
• Using the blower to move
large piles is time consuming
and creates unnecessary
noise.
• Clean up afterwards. Make
sure that you have not
blown rubbish into someone's
garden.
• Do not run with the product.
• The powerful currents of air
can move objects at such a
speed that they can bounce
back and cause serious eye
injuries.
• Do not direct the airflow
towards people or animals.
• Stop the motor before
you assemble or dismantle
accessories or other parts.
• Keep all parts of your body
away from hot surfaces.
• Never put the product down
when it is activated unless
you have it in clear sight.
• The blower must not be
used while on a ladder or
scaffolding.
• Do not use the product unless
you are able to call for help in
case of an accident.
• Watch out for thrown objects.
Stones, rubbish, etc., can
be thrown up into the eyes
causing blindness or serious
injury.
• Use a residual-current device
(RCI) for increased security
when you charge the product.
A residual-current device is
fitted to protect operators in
case an electrical fault should
occur.
8
1310 - 005 - 21.04.2022
• This product is renowned
for its low vibration load.
Overexposure to vibration can
lead to circulatory damage or
nerve damage in people who
have impaired circulation.
Contact your doctor if you
experience symptoms of
overexposure to vibration.
Such symptoms include
numbness, loss of feeling,
tingling, pricking, pain, loss
of strength, changes in skin
colour or condition. These
symptoms normally appear in
the fingers, hands or wrists.
• Only use the product for the
purpose it was intended for.
• It is not possible to cover
every conceivable situation
you can face. Always
exercise care and use your
common sense. Avoid all
situations which you consider
to be beyond your capability.
If you still feel uncertain about
operating procedures after
reading these instructions,
you should consult an expert
before continuing.
Personal protective equipment
WARNING: Read the
warning instructions that
follow before you use the
product.
•
Always use approved personal
protective equipment when
you use the product. Personal
protective equipment cannot
fully prevent injury but it
decreases the degree of injury
if an accident does occur. Let
your dealer help you select the
right equipment.
•
Long term exposure to
noise can result in damaged
hearing. In general, battery
powered products are
relatively quiet but damage
can result from a combination
of noise level and long usage.
recommends that operators
use hearing protectors when
using products for a longer
coherent time of a day.
Continual and regular users
should have their hearing
checked regularly. Note that
hearing protectors limit the
ability to hear sounds and
warning signals.
•
Use approved eye protection.
If you use a visor, you must
1310 - 005 - 21.04.2022
9
also use approved protective
goggles. Approved protective
goggles must comply with
the ANSI Z87.1 standard in
the USAs or EN 166 in EU
countries.
•
Use clothing made of a strong
fabric. Always use heavy, long
pants and long sleeves. Do
not use loose clothing that can
catch on twigs and branches.
Do not wear jewelry, short
pants, sandals or go with bare
feet. Put your hair up safely
above shoulder level.
•
Keep first aid equipment close
at hand.
•
A breathing mask should be
used when there is a risk of
dust.
Safety devices on the product
WARNING: Read the
warning instructions that
follow before you use the
product.
•
In this section the product’s
safety features, its purpose
and how checks and
maintenance should be
carried out to ensure
that it operates correctly.
See instructions under the
heading
Product overview on
page 2
to find where these
parts are located on your
product.
•
The life span of the product
can be reduced and the risk
of accidents can increase if
product maintenance is not
carried out correctly and if
service and/or repairs are not
carried out professionally. If
you need further information
please contact your nearest
servicing dealer.
•
Never use a product with
defective safety components.
The product's safety
equipment must be inspected
and maintained as described
in this section. If your product
fails any of these checks,
contact your service agent to
get it repaired.
•
All servicing and repair work
on the product requires
special training. This is
especially true of the
product′s safety equipment.
10
1310 - 005 - 21.04.2022
If your product fails any of
the checks described below
you must contact your service
agent. When you buy any of
our products we guarantee
the availability of professional
repairs and service. If the
retailer who sells your product
is not a servicing dealer, ask
him for the address of your
nearest service agent.
To do a check of the keypad
1. Push and hold the start/stop
button (B).
B
A
C
a)The product is on when
the LED (A) comes on.
b)The product is off when
the LED (A) is out.
2. Refer to
User interface on
page 17
if the warning
indicator (C) comes on or
flashes.
To do a check of the power
trigger
• Push and release the power
trigger to make sure that it
moves freely.
Battery safety
WARNING: Read the
warning instructions that
follow before you use the
product.
•
Only use the BLi batteries
that we recommend for your
product. The batteries are
software encrypted.
•
Use the BLi batteries that
are rechargable as a power
supply for the related
Husqvarna products only. To
prevent injury, do not use the
battery as a power supply for
other devices.
•
Risk of electrical shock.
Do not connect the battery
terminals to keys, screws or
other metal. This can cause a
short circuit of the battery.
1310 - 005 - 21.04.2022
11
•
Do not use batteries that are
non-rechargable.
•
Do not put objects into the air
slots of the battery.
•
Keep the battery away from
sunlight, heat or open flame.
The battery can cause burns
and/or chemical burns.
•
Keep the battery away from
rain and wet conditions.
•
Keep the battery away
from microwaves and high
pressure.
•
Do not try to disassemble or
break the battery.
•
Use the battery in
temperatures between -10 °C
(14 °F) and 40 °C (104 °F).
•
Do not clean the battery
or the battery charger with
water. Refer to
To clean the
product, the battery and the
battery charger on page 16
.
•
Do not use a defective or
damaged battery.
•
Keep batteries in storage
away from metal objects such
as nails, screws or jewelry.
•
Keep the battery away from
children.
Battery charger safety
WARNING: Read the
warning instructions that
follow before you use the
product.
•
Risk of electrical shock or
short circuit if the safety
instructions are not obeyed.
•
Do not use other battery
chargers than the one
supplied for your product.
Only use Husqvarna QC
chargers when you charge
BLi replacement batteries.
•
Do not try to disassemble the
battery charger.
•
Do not use a defective or
damaged battery charger.
•
Do not lift the battery
charger by the power cord.
To disconnect the battery
charger from a mains socket,
pull out the plug. Do not pull
the power cord.
•
Keep all cables and extension
leads away from water, oil
and sharp edges. Make sure
that the cable is not caught
between objects, for example,
doors, fences or equivalent.
•
Do not use the battery
charger near flammable
materials or materials that
can cause corrosion. Make
sure that the battery charger
is not covered. Pull out the
plug to the battery charger if
there is smoke or fire.
•
Only charge the battery
indoors in a location with
good airflow and away from
sunlight. Do not charge the
12
1310 - 005 - 21.04.2022
battery outdoors. Do not
charge the battery in wet
conditions.
•
Only use the battery charger
where the temperature is
between 5 °C (41 °F) and 40
°C (104 °F). Use the charger
in an environment which has
a good airflow, dry and free
from dust.
•
Do not put objects into the
cooling slots of the battery
charger.
•
Do not connect the battery
charger terminals to metal
objects as this can short
circuit the battery charger.
•
Use approved mains sockets
that are not damaged. Make
sure that the cord of
the battery charger is not
damaged. If extension cables
are used, make sure that
the extension cables are not
damaged.
Safety instructions for
maintenance
WARNING: Read the
warning instructions that
follow before you do
maintenance on the
product.
•
Remove the battery before
you do maintenance, other
checks or assemble the
product.
•
The operator must only
do the maintenance and
servicing shown in this
operator's manual. Speak to
your servicing dealer for
maintenance and servicing of
a larger extension.
•
Keep all nuts, bolts and
screws tight to be sure the
product is in safe working
condition.
•
Replace worn or damaged
parts.
•
If you do not do maintenance,
it decreases the life cycle of
the product and increases the
risk of accidents.
•
Special training is necessary
for all servicing and repair
work, especially for the
safety devices on the
product. If not all checks in
this operator's manual are
approved after maintenance,
speak to your servicing dealer.
We guarantee that there
are professional repairs and
servicing available for your
product.
•
Only use original spare parts.
1310 - 005 - 21.04.2022
13
Assembly
Introduction
WARNING: Read and understand the
safety chapter before you assemble the
product.
To assemble the tube on the product
1. Put the blower nozzle over the tubular end of the
product.
2. Push the blower nozzle in fully and turn the blower
nozzle to lock it to the product.
Operation
Introduction
WARNING: Read and understand the
safety chapter before you use the product.
To do a function check before you use
the product
1. Do a check of the air inlet for dirt and cracks. Use
a brush and clean off grass and leaves from the
product.
2. Make sure that the product works correctly.
3. Do a check of all nuts and screws and make sure
that they are tight.
To connect the battery charger
1. Connect the battery charger to the voltage and
frequency that is specified on the rating plate.
2. Put the plug in a grounded socket outlet. The LED
on the battery charger flashes green one time.
Note: The battery does not charge if the battery
temperature is more than 50 °C/122 °F. If the
temperature is more than 50 °C/122 °F, the battery
charger makes the battery become cool before the
battery charges.
To charge the battery
CAUTION: Make sure that the battery,
the battery charger and the terminals on the
battery are clean and dry. Do not put the
battery in the battery charger if it is dirty or
wet.
1. Connect the battery charger to a power outlet. The
charging LED flashes red 1 time and green 1 time.
CAUTION: Only connect the battery
charger to a power outlet with the
voltage and frequency specified on the
rating plate.
2. Connect the battery to the battery charger.
14 1310 - 005 - 21.04.2022
3. Make sure that the charging LED comes on.
4. Remove the battery from the battery charger when it
is fully charged. Push the battery indicator button for
battery status. When all the LED indicators come on,
the battery is fully charged.
5. Pull the power plug to disconnect the battery charger
from the power outlet. Do not pull the power cord.
To connect the battery to the product
WARNING: Only use Husqvarna
original batteries in the product.
1. Make sure that the battery is fully charged.
2. Slide the battery into the battery holder of the
product. The battery must slide easily, if not, it is not
installed correctly.
3. Press the lower part of the battery and push it in as
far as it will go into the battery compartment. The
battery will lock into position when you hear a click.
4. Make sure that the latches snap in place correctly.
To start the product
1. Push and hold the start button until the green LED
light comes on.
2. Use the power trigger to operate the product.
To set the optimal airflow for your work
• Push the mode control button to set the airflow.
There are 3 airflow steps. The LED shows the set
airflow.
To stop the product
1. Release the power trigger.
2. Push and hold the power button until the green LED
light comes off.
3. Remove the battery from the product. Push the two
release buttons and pull out the battery.
Automatic shutdown function
The product has an automatic shutdown function that
stops the product if it is not used. The product shuts
down after 30 minutes.
1310 - 005 - 21.04.2022
15
Maintenance
Introduction
WARNING: Before you do any
maintenance work you must read and
understand the safety chapter.
Maintenance schedule
WARNING: Remove the battery before
you do maintenance.
The following is a list of the maintenance steps that you
must do on the product.
Maintenance Daily Weekly Monthly
Clean the outside of the machine with a clean and dry cloth. Never use water. X
Keep handles dry, clean and free from oil and grease. X
Make sure that the start/stop button works correctly and is not damaged. X
Make sure the power trigger is functioning properly with regard to safety. X
Check that nuts and screws are tight. X
Check that the battery is intact. X
Check the battery's charge. X
Check that the release buttons on the battery works and locks the battery into
the machine.
X
Check that the battery charger is intact and functional. X
Check that all couplings, connections and cables are intact and free from dirt. X
Check the connections between the battery and the machine and also check the
connection between battery and the battery charger.
X
To do a check of the air intake
1. Make sure that the air intake is not blocked on the
sides on the product.
2. Stop the product and remove leaves or unwanted
material if it is necessary.
CAUTION: A blocked air intake
decreases the blow capacity of the
product and increases the work
temperature of the motor. This can
result in motor failure because the motor
becomes too hot.
To examine the battery and the battery
charger
1. Examine the battery for damages, for example
cracks.
2. Examine the battery charger for damages, for
example cracks.
3. Make sure that the connection cord of the battery
charger is not damaged and that there are no cracks
in it.
To clean the product, the battery and
the battery charger
1. Clean the product with a dry cloth after use.
2. Clean the battery and battery charger with a dry
cloth. Keep the battery guide tracks clean.
3. Make sure that the terminals on the battery and the
battery charger are clean before the battery is put in
the battery charger or the product.
16 1310 - 005 - 21.04.2022
Troubleshooting
User interface
User interface Possible faults Possible solution
Green LED
Flashes
Low battery
voltage.
Charge the battery.
Red error LED
flashes
Temperature
deviation.
Let the product cool down.
The product
does not start
Dirt in battery
connectors.
Clean with compressed air or a soft brush.
The battery is
empty.
Charge the battery.
Red error LED
flashes
Servicing is
necessary.
Speak to your servicing agent.
Battery
LED display
Possible faults Possible action
Green LED flashing Low battery voltage. Charge the battery.
Red error LED flashing The battery is discharged. Charge the battery.
Temperature deviation. Use the battery in tempereatures
between -10°C (14°F) and 40°C
(104°F).
Over voltage. Check that the mains voltage corre-
sponds with that stated on the rating
plate on the product.
Remove the battery from the battery
charger.
Red error LED is lit Cell difference is to much (1V). Contact your servicing agent.
Battery charger
Problem
Possible faults Possible solution
Red error LED flashes. Temperature deviation. Use the battery charger in tempera-
tures between 5 °C (41 °F) and 40 °C
(104 °F).
Red error LED comes on. Speak to your servicing dealer.
1310 - 005 - 21.04.2022 17
Transportation, storage and disposal
Transportation and storage
• The supplied Li-ion batteries obey the Dangerous
Goods Legislation requirements.
• Obey the special requirement on package and labels
for commercial transportation, including by third
parties and forwarding agents.
• Speak to a person with special training in dangerous
material before you send the product. Obey all
applicable national regulations.
• Use tape on open contacts when you put the battery
in a package. Put the battery in the package tightly
to prevent movement.
• Remove the battery for storage or transportation.
• Put the battery and the battery charger in a space
that is dry and free from moisture and frost.
• Do not keep the battery in an area where static
electricity can occur. Do not keep the battery in a
metal box.
• Put the battery in storage where the temperature is
between 5°C/41°F and 25°C/77°F and away from
open sunlight.
• Put the battery charger in storage where the
temperature is between 5 °C/41 °F and 45°C/113°F
and away from open sunlight.
• Use the battery charger only when the surrounding
temperature is between 5°C/41°F and 40°C/104°F.
• Charge the battery 30% to 50% before you put it in
storage for long periods.
• Put the battery charger in storage in a space that is
closed and dry.
• Keep the battery away from the battery charger
during storage. Do not let children and other not
approved persons to touch the equipment. Keep the
equipment in a space that you can lock.
• Clean the product and do a full servicing before you
put the product in storage for a long time.
• Use the transportation guard on the product to
prevent injuries or damage on the product during
transportation and storage.
• Attach the product safely during transportation.
Disposal of the battery, battery charger
and product
The symbol below means that the product is not
domestic waste. Recycle it at a recycling station
for electrical and electronic equipment. This helps to
prevent damage to the environment and to persons.
Speak to local authorities, domestic waste service or
your dealer for more information.
Note: The symbol shows on the product or package of
the product.
Technical data
Technical data
120iB
Motor
Motor type BLDC (brushless) 36V
Weight
Weight without battery, kg 2.0
18 1310 - 005 - 21.04.2022
120iB
Noise emissions
1
Sound power level, measured dB (A) 96
Sound power level, guaranteed L
WA
dB (A) 97
Water protection level
All weather use Yes
IPX4
2
No
Sound levels
3
Equivalent sound pressure level at the operator's ear, measured according
to EN ISO 11203 and ISO 22868, dB (A):
83
Vibration levels
4
Vibrations levels at handles, measured according to ISO 22867, m/s
2
1.0
Fan performance
Air flow in normal mode with standard nozzle, m
3
/min 10.3
Maximum air velocity in normal mode with standard nozzle, m/s / mph 46 / 102.9
Noise and vibration data are determined on the basis of
the rated maximum speed.
Approved batteries
Only use Husqvarna original BLi batteries for this
product.
Approved batteries
Battery BLi10 BLi20
Type Lithium-ion Lithium-ion
Battery capacity, Ah 2.1 (VTC4) 2 (HD2) 4.2 (VTC4) 4.0 (HD2)
Nominal voltage, V 36 36.5 36 36.5
Weight, kg/lbs 0.7/1.5 0.7/1.5 1.2/2.6 1.2/2.6
Battery B70 B140
Type Lithium-ion Lithium-ion
Battery capacity, Ah 2 4.0
1
Noise emissions in the environment measured as sound power (L
WA
) in conformity with EC directive
2000/14/EC. Reported sound power level for the machine has been measured with the original cutting
attachment that gives the highest level. The difference between guaranteed and measured sound power
is that the guaranteed sound power also includes dispersion in the measurement result and the variations
between different machines of the same model according to Directive 2000/14/EC.
2
The Husqvarna Handheld Battery products marked with IPX4 fulfils these requirements on product approval
level
3
Reported data for equivalent sound pressure level for the machine has a typical statistical dispersion (stand-
ard deviation) of 3 dB (A).
4
Reported data for vibration level has a typical statistical dispersion (standard deviation) of 2 m/s
2
.
1310 - 005 - 21.04.2022 19
Battery B70 B140
Nominal voltage, V 36 36
Weight, kg/lbs 0.7/1.5 1.2/2.6
Approved battery chargers
Battery charger QC 80
Input voltage, V 100-240
Frequency, Hz 50-60
Power, W 80
Battery charger C80
Input voltage, V 100-240
Frequency, Hz 50-60
Power, W 80
20 1310 - 005 - 21.04.2022
EC Declaration of Conformity
EU Declaration of conformity
We, Husqvarna AB, SE-561 82 Huskvarna, SWEDEN,
tel: +46-36-146500, declare on our sole responsibility
that the product:
Description Handheld Battery-operated Blower
Brand
Husqvarna
Type / Model 120iB
Identification Serial numbers dating from 2022 and onwards
complies fully with the following EU directives and
regulations:
Regulation Description
2006/42/EC "relating to machinery"
2014/30/EMC "relating to electromagnetic compatibility"
2011/65/EU “relating to restriction of hazardous substances”
2000/14/EC "relating to outdoor noise"
and that the following standards and/or technical
specifications are applied: EN 60335-1:2012, EN
50636-2-100:2014, EN 61000-6-3:2007+A1:2011, EN
61000-6-1:2007, EN IEC 63000:2018
Charger QC80 (also placed on market as a
standalone product 2014): EN 60335-1:2012+A11:2014,
EN 60335-2-29:2004+A2:2010, EN
62233:2008 EN 55014-1:2017+A11:2020, EN
55014-2:1997+A1:2001+A2:2008, EN 61000-3-2:2014,
EN 61000-3-3:2013, EN IEC 63000:2018
RISE SMP Svensk Maskinprovning AB, Box 7035,
SE-750 07 Uppsala, Sweden has certified conformity
with the council's directive 2000/14/EC, conformity
assessment procedure: Annex VI
For information relating to noise emissions, refer to
Technical data on page 18
.
Huskvarna, 2022-04-11
Stefan Holmberg
R&D Director, Technology Management, Husqvarna AB
Responsible for technical documentation
1310 - 005 - 21.04.2022 21
UK Declaration of conformity
We, Husqvarna AB, SE-561 82 Huskvarna, SWEDEN,
tel: +46-36-146500, declare on our sole responsibility
that the product:
Description Handheld Battery-operated Blower
Brand
Husqvarna
Type / Model 120iB
Identification Serial numbers dating from 2022 and onwards
complies fully with the following UK regulations:
Description
The Supply of Machinery (Safety) Regulations 2008
Electromagnetic Compatibility Regulations 2016
The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations
2012
The Noise Emission in the Environment by Equipment for use Outdoors Regulations 2001
and that the following standards and/or technical
specifications are applied: EN 60335-1:2012, EN
50636-2-100:2014, EN 61000-6-3:2007+A1:2011, EN
61000-6-1:2007, EN IEC 63000:2018
Charger QC80 (also placed on market as a
standalone product 2014): EN 60335-1:2012+A11:2014,
EN 60335-2-29:2004+A2:2010, EN
62233:2008 EN 55014-1:2017+A11:2020, EN
55014-2:1997+A1:2001+A2:2008, EN 61000-3-2:2014,
EN 61000-3-3:2013, EN IEC 63000:2018
For information relating to noise emissions, refer to
Technical data on page 18
.
Huskvarna, 2022-04-11
Stefan Holmberg
R&D Director, Technology Management, Husqvarna AB
Responsible for technical documentation
UK Importer:
Husqvarna UK Ltd
Preston Road, Co. Durham
DL5 6UP
22 1310 - 005 - 21.04.2022
1310 - 005 - 21.04.2022 23
www.husqvarna.com
Original instructions
1143128-26
2022-04-27
