Model No: DL168
Thank you for purchasing a product from the Dellonda range. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
DL168 Issue 2 10/01/24
PORTABLE POWER BANK
140W 27000mAh
2
• Features
Important Information
Please read these instructions carefully and note any safe operational requirements, warnings & cautions. Use the product correctly and with care for
the purpose for which it is intended. Failure to do so may cause damage and/or personal injury and will invalidate the warranty. Keep these instructions
safe for future use.
Refer to
instructions
Indoor use
only
1 ON / OFF switch
2 Type-C1 Input / Output
3 USB-A Output
4 C2 Output
5 LED Display
1
2
3
4
5
3
Electrical Safety
• WARNING! It is the user’s responsibility to read, understand and comply with the following electrical instructions:You must ensure the risk of
electric shock is minimised by the installation of appropriate safety devices.
• You must also read and understand the following instructions concerning electrical safety. The Electricity At Work Act 1989 requires all portable
electrical appliances, if used on business premises, to be tested by a qualied electrician, using a Portable Appliance Tester (PAT).
• The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of the appliance and the safety of
the appliance operator. If in any doubt about electrical safety, contact a qualied electrician. You must ensure that you:
• Inspect the Power Pack, charge cables and connectors for wear and damage to ensure items are safe before use. If worn or damaged DO NOT
use.
• Uncoil used cables between Power Pack and devices when in use.
• DO NOT pull the Power Pack from any sockets by the lead used.
• DO NOT try to take the Power Pack apart.
• DO NOT get the Power Pack wet, or use in wet, damp conditions (for indoor use only.
• Battery Safety
• Recycle or dispose of used battery as stipulated by local regulation.
• Ensure the internal battery is fully charged before initial use.
• WARNING! To reduce the risk of burns or re.
• DO NOT attempt to open, disassemble, modify or service the battery pack.
• DO NOT crush, puncture, short external contacts or dispose of in re or water.
• DO NOT expose to temperatures above 60°C (140°F).
• DO NOT move/handle/use the Power Pack when it is being charged.
• DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently recharge the
battery at least once every six months of non-use.
General Safety Instructions
• Familiarise yourself with the application and limitations of the Power Pack as well as the potential hazards.
• Keep children and unauthorised persons away from the working area.
• When not in use, store carefully in a safe, dry, childproof location.
• Use the cables provided with this unit only.
• DO NOT short circuit this unit and keep it way from metal objects such as coins, keys, jewellery etc.
• DO NOT pull the cables from any connections
• DO NOT use the unit outdoors, or in damp, or wet locations and DO NOT operate within the vicinity of flammable liquids or gases.
• DO NOT use for a task for which it is not designed.
• DO NOT modify or disassemble the Power Pack.
• DO NOT drop unit. If unit receives a sharp blow or is otherwise damaged in any way have it checked by a qualied technician.
• NOTE: This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.
Operation
Charging the power pack
• Insert the USB TYPE-C cable into the unit’s relevant input C1 port.
• Insert other end into either a USB wall charger (not supplied), a car accessory charger (not supplied) or the USB port on a computer (not supplied).
• While charging, the LED indicator will display battery level.
Using the power pack
• To charge USB digital devices, select appropriate cable for your device. Plug the charging cable into the USB ouputs
• Disconnect after use.
Maintenance
• Disconnect after use.
• After usage recharge the unit.
• After charging / usage remove all cables / connections.
• Use a clean, dry cloth to wipe down the unit after use.
• Store in clean, dry environment with ambient temperature between 4
o
C and 30
o
C.
4
Dellonda Limited, Sole UK Distributor of Baridi
Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757575 suppor[email protected] www.dellonda.co.uk
Model No DL168
Capacity 27000mAh/99.9Wh
Dimensions (W x D x H) 165 x 55 x 50mm
USB- C1 Input: 5V , 9V 3A, 12V 3A, 15V 3A, 20V 5A, 28V 5A,
140W(max)
USB-C1 Output 5V 3A, 9V 3A, 12V 3A, 15V 3A, 20V 5A, 28V 5A,
140W(max
USB-C2 Output 5V 2.4A, 9V 2.22A, 20W(max)
USB A Output 5V 3A, 9V 2A, 12V 1.5A, 18W(max)
Nett Weight 0.64kg
Specication
Note: It is Dellonda’s policy to continually improve products and we reserve the right to alter data, specifications and component parts without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which will be required.
BATTERY REMOVAL : ONLY TO BE PERFORMED BY SUITABLY QUALIFIED PERSON
Under the Waste Batteries and Accumulators Regulations 2009, Dellonda Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack Sealey
Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid waste
authority for recycling information.
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
