10W SMD LED 3-IN-1 FOLDING FLOODLIGHT
MODEL NO: LED15WFL
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
USE ONLY THE SUPPLIED USB CABLE FOR CONNECTING FLOODLIGHT TO THE POWER SUPPLY.
WARNING! It is the user’s responsibility to read, understand and comply with the following electrical instructions:
You must ensure the risk of electric shock is minimised by the installation of appropriate safety devices. An RCCB (Residual Current
Circuit Breaker) should be incorporated in the main distribution board. We also recommend that an RCD (Residual Current Device) is
used with all electrical products, particularly portable equipment which is plugged into an electrical supply not protected by an RCCB.
You must also read and understand the following instructions concerning electrical safety.
1.1.1. The Electricity At Work Act 1989 requires all portable electrical appliances, if used on business premises, to be tested by a qualified
electrician, using a Portable Appliance Tester (PAT).
The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of the appliance and
thesafetyoftheapplianceoperator.Ifinanydoubtaboutelectricalsafety,contactaqualiedelectrician.
Inspect the USB cable and connector for wear and damage to ensure items are safe before connecting to a power
supply. If worn or damaged DO NOT use.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or fire: ,
8 DO NOT attempt to open, disassemble, modify or service the battery.
8 DO NOT expose to temperatures above 60°C (140°F).
8 DO NOT crush, puncture, short external contacts or dispose of in fire or water.
1.3. GENERAL SAFETY
9 Ensure the floodlight is correctly charged before initial use.
8 DO NOT cover or block the lens during use.
8 DO NOT turn the floodlight on when it is being re-charged.
8 DO NOT shine directly into your, other person’s or animal’s eyes.
8 DO NOT allow children to use the floodlight.
8 DO NOT handle or move the floodlight whilst it is being charged.
8 DO NOT use the floodlight if you suspect that the battery or the spotlight casing is damaged.
8 DO NOT immerse the floodlight in water.
9 Ensure the floodlight is unplugged and allowed to cool before attempting any cleaning or storage.
9 When not in use, store the floodlight in a safe, dry, childproof location.
2. INTRODUCTION
3-in-1Designmakesthislightperfectforalmostanysituationandworkplace.Foldingoodlightcaneitherbeplacedintothestand
foldedtoilluminatebothsidesofaroomorfoldeduptocreateonelongoodlight.Floodlightsuppliedwithastrongbasetokeepthe
light upright and in position. Fold out magnets are situated at either end to be used as an under-bonnet light. The light also features
hooksateitherendandonecentrallysoyoucanhangitalmostanywhere.Verybright1000lumenlightwiththreedierentlight
settings. Rechargeable 3.7V Li-ion 4000mAh battery supplied with USB charging cable.
3. SPECIFICATION
Model No .......................................................LED15WFL
Battery ...........................................3.7V LI-ion 4000mAh
Charging time ........................................................5-6hrs
Colour Temperature ..............................................6000K
IP rating....................................................................IP20
Lumen Output ..................................................... 1000lm
LED type ................................................................. SMD
Operating Time ..............2 hrs both sides, 4 hrs one side
Power .......................................................................10W
Original Language Version
© Jack Sealey Limited
Refer to
instructions
LED15WFL Issue:1 19/01/23
4. OPERATION
Thebatteryttedtothislampisconsideredtobeaconsumableitemanditsabilitytoacceptachargewillreduceovertime.
We will provide warranty against mechanical and electrical defect for a period of one year - this does not cover fair wear and tear.
Ifthebatteryisnotproperlychargedbeforerstuse,orregularlyconditioned,itscapacitywilldiminish.Underthesecircumstances
we will not replace the battery regardless of whether it is less than one year old.
WARNING! Ensure that you read, and fully understand the safety instructions before use.
NOTE: Before initial use, fully charge the unit.
4.1. BATTERY CHARGING
4.1.1. Ensure the floodlight is turned off before charging (Fig.1).
4.1.2. Battery charge level is indicated by the LED display (Fig.2).Red charging light will indicate charging and goes to green when fully charged.
4.1.3. When full charge has been reached, unplug the charger cable from the power supply.
4.2. USING THE FLOODLIGHT
4.2.1. Turnoodlightonandousingthemodeswitch(Fig.1)onthemainbody.
4.2.2. TheoodlighthasthreeworkingmodesselectedbyuseoftheModeSelectorswitch(Fig.1).
4.2.3. Operating modes are: lights illuminated,followed by either front or back light lit independently.
4.2.4. Adjustthepositionofthelightusingtheratcheteectbuiltintothejointsoftheframe.
4.2.5. The light assembly has magnetic feet and a sprung hook see Fig’s 3 to Fig.6 for usage.
5. MAINTENANCE
WARNING! Ensure that you read, understand and apply the safety instructions relating to the battery before charging it.
5.1. Ensuretheoodlightisturned‘O’beforeattemptingtochargethebattery.
5.2. Wipe down dirty surfaces with damp cloth. DO NOT use abrasive or caustic cleaning materials.
5.3. Dispose of broken unit in accordance with local authority battery regulations. DO NOT dispose of with regular refuse.
5.4. STORAGE
5.4.1. Store the charger in a safe, dry location.
NOTES:
DO NOT fully discharge the batteries before recharging.
DO NOT leave batteries in a discharged state, recharge batteries immediately. If the floodlight is not in use, recharge the batteries every
three months.
USB Charging
Point and Light
On/O Indicator
Mode selector
Switch
Hook for under car bonnet use or hanging
from a draw etc.
Full Upright position. Top or bottom or both
can be illuminated.
Charging Indication
Light Red / Green
© Jack Sealey Limited
Original Language Version
LED15WFL Issue:1 19/01/23
g.1
g.2
g.3
g.4
Original Language Version
© Jack Sealey Limited
LED15WFL Issue:1 19/01/23
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Corner light for inside tool box or overhead cupboard
Magnetic feet which pull out from the internal sides of body. So can be mounted on any magnetic
surface.
REGISTER YOUR
PURCHASE HERE
g.4
g.5
