1
4 Inch Rechargeable Fan
Model No. COL1540GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
4 Inch Rechargeable Fan
Model No. COL1540GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
• Read and familiarise yourself with all operating
instructions before using this Rechargeable Fan.
• Before using your Rechargeable Fan, visually check that
the unit is intact and has not suffered any transit damage.
• Always use this appliance on a solid, level, non-flammable
surface.
• Ensure that there is clearance of at least 100mm (4
Inches) minimum around the fan for sufficient ventilation.
• Ensure that any ventilation openings are not covered with
items, such as newspapers, table-cloths, curtains, etc.
• No naked flame sources, such as lighted candles, should
be placed on the fan.
• DO NOT position the fan close to sources of heat such as
radiators, heaters, other electronic equipment, etc.
• The fan shall not be exposed to dripping or splashing and
that no objects filled with liquids, such as vases, shall be
placed on the apparatus.
• DO NOT immerse the fan or its charging cable in water or
any other liquids.
3
4 Inch Rechargeable Fan
Model No. COL1540GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• DO NOT leave the fan unattended during use.
• DO NOT leave the fan unattended whilst connected to a
USB supply.
• Close supervision is required when using this fan near
children.
• Never leave this fan within reach of children.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Children of less than 3 years should be kept away unless
continuously supervised.
• It is imperative to unplug the USB supply after the fan has
been used, before it is cleaned and whilst being repaired.
• Unplug after each use.
• Repairs to electrical appliances should only be performed
by qualified personnel. Improper repairs may place the
user at serious risk.
• DO NOT operate this appliance after a malfunction or
after being dropped or damaged in any way.
• DO NOT allow the charging cable to hang over sharp
edges or come in contact with hot surfaces.
• DO NOT run the charging cable under carpets, rugs, etc.
• This product is intended for household use only and
should not be used for industrial purposes.
• DO NOT use any accessories or attachments with this
product other than those supplied or recommended by
supplier.
4
4 Inch Rechargeable Fan
Model No. COL1540GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• DO NOT use this product for anything other than its
intended use.
• DO NOT push objects into any openings as damage to the
product and/or electric shock may occur.
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
This symbol provides useful additional information on the
use of this product.
This symbol identifies voltage and the current rating for direct
current.
This symbol means batteries and rechargeable batteries may
not be disposed of with household waste!
As the end user you are required by law to bring all batteries
and rechargeable batteries to a collection point run by the Local
Authority or to a retailer, so that they can be disposed of in an
environmentally friendly manner.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste. Please ensure it is
taken to a suitable facility for disposal. Check with your Local
Authority or retailer for recycling advice or visit www.recycle-
more.co.uk or www.weeeireland.ie enter your postcode to find
out your nearest recycling site.
5
4 Inch Rechargeable Fan
Model No. COL1540GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Before First Use of Your Rechargeable Fan
Remove all packing materials and discard responsibly.
Ensure all parts are present (if applicable) see Description of Parts below.
Description of Parts
1. Fan Guard
2. Air Outlet
3. LED Indicator
4. Power / Speed Button
5. Air Inlet
6. USB C-Type Charging Port
7. USB Charging Cable
8. USB C-Type Plug
9. Large USB Plug
7
9
6
4
3
1
5
2
Description of Parts - Accessories
8
6
4 Inch Rechargeable Fan
Model No. COL1540GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Charging the Internal Battery
Before use, please ensure that the internal rechargeable battery is fully charged as
follows:
1. Insert the USB C-Type Plug (8) of the USB
Charging Cable (7) into the USB C-Type Charging
Port (6) on the rear panel of the Rechargeable
Fan to charge the internal battery.
2. Insert the Large USB Plug (9) of the USB
Charging Cable (7) into a suitable USB charger
rated at 800mA Maximum such as a dedicated
USB mains charger or USB outlet on a computer.
3. The LED Indicator (3) will flash Red whilst charging.
Once the battery is fully charged, the LED Indicator
(3) will change to White to indicate fully charge and
the USB Charging Cable (7) can be removed.
4. The internal battery can operate for 2 - 8hours after it is fully charged. Battery
will take 2 - 3hours to fully charge from flat.
The Rechargeable Fan can be used whilst connected to the USB supply.
Using Your Rechargeable Fan
1. Switch on the Rechargeable Fan by pressing the
Power/Speed Button (4).
2. Press the Power/Speed Button (4) for fan speed I.
3. Repeatedly press the Power/Speed Button (4) for
speeds 2 and 3.
4. The LED Indicator (3) will illuminate white when the
Rechargeable Fan is on.
5. Further pressing the Power/Speed Button (4) after Speed III will switch the unit
off.
The airflow direction can be adjusted by swinging the
Fan Guard (1) up and down.
If the LED Indicator (3) flashes red during use, this
indicates the battery power is less than 20% and will
require recharging.
7
4 Inch Rechargeable Fan
Model No. COL1540GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Care and Use of Your Rechargeable Fan
• Always disconnect the fan from the USB supply before cleaning.
• Clean outside of the fan with a clean damp cloth. Never clean with harsh or
abrasive cleaners.
• Do not submerge the fan or its charging cable in water or any other liquids.
• Store the fan in a cool, dry place out of direct sunlight.
Technical Specification
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of plastics in the appropriate plastics collection service.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for recycling
advice or visit www.recycle-more.co.uk or www.weeeireland.ie
enter your postcode to find out your nearest recycling site
This symbol means batteries and rechargeable batteries may not
be disposed of with household waste!
As the end user you are required by law to bring all batteries and
rechargeable batteries to a collection point run by the Local
Authority or to a retailer, so that they can be disposed of in an
environmentally friendly manner.
Model Number
COL1540GE
Rated Power
4W
Rated Input
DC 5V @800mA (max.)
Battery Type/Capacity*
Li-ion 3.7V 1800mAh
Unpacked Weight
Approx. 235g
Dimensions (Approx.)
167mm (H) x 85mm (W) x 118mm (D) Approx.
8
4 Inch Rechargeable Fan
Model No. COL1540GE
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in addition to your 1 year
guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to
the conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
