POI-3000, Gigabit PoE
Injector,802.3at/af PoE, 30W
Product Images
2
7/20/24
Short Description
IEEE 802.3af/at PoE PSE with 30W power budget
Auto-detection and protection of non-standard PoE devices
Unique interlocking feature for easy installation
10/100/1000Mbps wire speed transmission and reception
6KV surge protection level on each port
Description
Advanced PoE SolutionThe LevelOne POI-3000 is a single port, high power PoE PSE
solution for remote PoE PD devices. Generating up to 30W , POI-3000 supplies remote
power for new applications such as wireless access points, pan-tilt-zoom (PTZ) IP cameras
and videophones. It complies with IEEE 802.3at PoE standard and is backward to
IEEE802.3af. It can work with 10/100Base-T networking devices and emerging 1000Base-T
devices such as Wi-MAX and wireless IEEE 802.11n access points. For all the function
featured in POI-3000, people can get the benefit of flexible network installation at lower
cost, less downtime. It also provides a high-bandwidth pipe to the network.
3
7/20/24
Additional Information
Gigabit RJ45 2
802.3af/at PoE 1
Color Black
EAN 4015867158111
Model Number POI-3000
Features
Output Power Voltage: 52 VDC Maximal Per Port
Power: 30 Watts Maximal Input Power AC Input
Voltage: 100~240 VAC Requirements AC Input
Current: 0.8A@ 100-240 VAC
Injector Port Type Single Port
Data rate Gigabit Ethernet
Grade Commercial
Operating humidity 5% RH ~ 95% RH
Operating temperature -20°C ~ 60°C
Package Contents POI-3000 Quick Installation Guide
Dimensions (W x D x H) 55 x 35.5 x 173.5 mm
Product weight (kg) 0,28
Data rate 10/100/1000Mbps
Indicators Power, PoE
Mount Wall mount
Pin assignment and polarity 1/2 (+), 3/6 (-)
Power consumption 30W
Power supply included Yes
Standards
IEEE 802.3 10Base-T, Ethernet IEEE 802.3u
100Base-TX, Fast Ethernet IEEE802.3ab
1000Base-T, Gigabit Ethernet IEEE 802.3af/at
Power over Ethernet (PoE) compliant
