Installation Guide
Some models featured in this guide may be unavailable in your country or region. For local sales information, visit https://www.omadanetworks.com.
© 2026 TP-Link 7100002997 REV6.30.2
PoE Injector and PoE Splitter
PoE Injector PoE SplitterPower Socket
Ethernet Device
(switch, gateway, etc.)
12V 9V 5V
LAN OUT
PWR
DC OUT
Non-PoE Device
(suggested power: <12 W)
PoE Injector & Splitter
The PoE injector and PoE splitter can be used as a kit to supply power and transmit data to a Non-PoE
device.
LAN IN
PWR
DC 48V
Set the required voltage for
the non-PoE device before
connecting the cable.
PoE InjectorPower Socket Ethernet Device
(switch, gateway, etc.)
LAN IN
PWR
DC 48V
PoE Injector Only
The PoE injector supplies steady power and data connectivity to a powered device such as a PoE IP camera, PoE
AP, and PoE IP phone through an Ethernet cable.
IP Camera AP IP Phone
Powered Device (PD)
The maximum output power of POE150S
is 15.4W. PoE devices that require more
than 15.4W are not supported.
12V 9V 5V
PoE Splitter
LAN OUT
PWR
DC OUT
Non-PoE Device
(suggested power: <12 W)
PoE Switch
PoE Splitter Only
The PoE splitter can be used with a PoE switch to deliver direct current (DC) power and data to a Non-PoE device.
Set the required voltage for the
non-PoE device before connecting
the cable.
Please read and follow the above safety information when operating the device.
We cannot guarantee that no accidents or damage will occur due to improper
use of the device. Please use this product with care and operate at your own
risk.
A:
Yes. All RJ45 ports of the PoE injector support 10/100/1000 Mbps
auto-negotiation.
Q1. Can the PoE injector supply power to a PoE device which
doesn’t have a gigabit PoE port?
A1: Ensure the PD is PoE-compliant and its connecting port supports the PoE
function.
A2: Ensure the power consumption of the PD doesn’t exceed 15.4 W,
otherwise the overload protection of the PoE injector will be activated. The
quality and length of the Ethernet cable may inuence the reception of the
power supply.
Q2. What can I do if my PoE injector doesn’t supply power to
the powered device or the supplied power is unstable?
FAQ
Q3. Must I use the PoE injector together with the PoE splitter?
A: No. The PoE injector can supply power to all PDs supporting the PoE
function. The PoE splitter is used with a PoE switch or the PoE injector to
supply power to a non-PoE device.
A1: Ensure the power cord is connected to the PoE injector with a power
source properly.
A2: Ensure the power consumption of the PD doesn’t exceed 15.4 W;
otherwise, the PoE injector will activate the overload protection and the
power will be cut o.
Q4. The Power LED of the PoE injector is not lit.
Operating Temperature (POE150S)
Operating Temperature (POE10R)
-10˚C to 50˚C (14˚F to 122˚F)
-5˚C to 45˚C (23˚F to 104˚F)
Storage Temperature -40˚C to 70˚C (-40˚F to 158˚F)
Storage Humidity 5% to 90% non-condensing
Operating Humidity 10% to 90% non-condensing
Environmental and Physical Specifications
Ports
Specications
IEEE 802.3i, IEEE802.3u, IEEE 802.3ab, IEEE 802.3af
Standards
PWR
UTP/STP of Cat. 5 or above (based on the standards that the
connected devices comply with)
LED
Cable Type
General Specifications
POE10R:
10/100/1000 Mbps Auto-Negotiation RJ45 POWER+DATA
IN Port
10/100/1000 Mbps Auto-Negotiation RJ45 LAN OUT Port
5V / 9V / 12V DC OUT Power Output Port
POE150S:
10/100/1000 Mbps Auto-Negotiation RJ45 LAN IN Port
10/100/1000 Mbps Auto-Negotiation RJ45 POWER+DATA
OUT Port
DC 48 V Power Input Port
EU Declaration of Conformity
TP-Link hereby declares that the PoE injector and splitter are in compliance with
the essential requirements and other relevant provisions of directives
2014/30/EU, 2014/35/EU, 2009/125/EC, 2011/65/EU and (EU)2015/863.
The original EU declaration of conformity may be found at
https://www.tp-link.com/en/ce.
UK Declaration of Conformity
TP-Link hereby declares that the PoE injector and splitter are in compliance with
the essential requirements and other relevant provisions of the Electromagnetic
Compatibility Regulations 2016 and Electrical Equipment (Safety) Regulations
2016.
The original UK Declaration of Conformity may be found at
https://www.tp-link.com/support/ukca
Продукт сертифіковано згідно с правилами системи УкрСЕПРО на
відповідність вимогам нормативних документів та вимогам, що передбачені
чинними законодавчими актами України.
Responsible party:
TP-Link Systems Inc.
Address: 10 Mauchly, Irvine, CA 92618
Website: https://www.tp-link.com/us/
Tel: +1 626 333 0234
Fax: +1 909 527 6804
E-mail: [email protected]
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that may cause undesired operation.
Any changes or modications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
We, TP-Link Systems Inc., has determined that the equipment shown as above has been shown to comply with the
applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the
equipment is properly maintained and operated.
Issue Date: 2025-2-25
Component Name Model
I.T.E. POWER SUPPLY
T480038-2B1
Product Name: PoE Splitter
Model Number: POE10R
Product Name: PoE Injector
Model Number: POE150S
Product Name: I.T.E. POWER SUPPLY
Model Number: T480038-2B1
Responsible party:
TP-Link Systems Inc.
Address: 10 Mauchly, Irvine, CA 92618
Website: https://www.tp-link.com/us/
Tel: +1 626 333 0234
Fax: +1 909 527 6804
E-mail: [email protected]
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communication. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that may cause undesired operation.
Any changes or modications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
We, TP-Link Systems Inc., has determined that the equipment shown as above has been shown to comply with the
applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the
equipment is properly maintained and operated.
Issue Date: 2025-2-25
FCC compliance information statement
FCC compliance information statement
CE Mark Warning
Продукт сертифіковано згідно с правилами системи УкрСЕПРО на відповідність вимогам нормативних
документів та вимогам, що передбачені чинними законодавчими актами України.
CAN ICES-3 (B)/NMB-3(B)
Industry Canada Statement
BSMI Notice (For POE150S)
安全諮詢及注意事項
請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。
清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。
注意防潮，請勿將水或其他液體潑灑到本產品上。
插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆蓋開口。
請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位置中。
請不要私自拆開機殼或自行維修，如產品有故障請與原廠或代理商聯繫。
For POE10R:
限用物質含有情況標示聲明書
產品元件名稱
PCB
外殼
塑膠組件
其他及其配件
限用物質及其化學符號
備考1： "○"系指該項限用物質之百分比含量未超出百分比含量基準值。
備考2： " - " 系指該項限用物質為排除項目。
○ ○ ○ ○ ○
鉛
Pb
○
○
○
-
鎘
Cd
○
○
汞
Hg
○
○
六價鉻
Cr
+6
○
○
多溴聯苯
PBB
○
○
多
溴二苯醚
PBDE
○
○
○ ○ ○ ○ ○
Points de collecte sur www.quefairedemesdechets.fr
Privilégiez la répara�on ou le don de votre appareil !
À DÉPOSER
EN MAGASIN
À DÉPOSER
EN DÉCHÈTERIE
OU
FR
Cet appareil
et ses accessoires
se recyclent
Explanation of the symbols on the product label
產品標籤上符號的解釋
Note: The product label can be found at the bottom of the product.
Symbols may vary from products.
注意：產品標籤可在產品底部找到。符號可能因產品而異。
Symbol
符號
Explanation
說明
Class II equipment
二級設備
Class II equipment with functional earthing
具有接地功能的二級設備
Alternating current
交流電
Direct current
DC 電壓
Polarity of d.c. power connector
輸出端點的極性
For indoor use only
僅供室內使用
Dangerous voltage
危險電壓
Caution, risk of electric shock
請注意，有觸電的危險
Energy eciency Marking
能源效率標誌
Protective earth
保護接地
Earth
接地
Frame or chassis
框架或外殼
Functional earthing
功能接地
Caution, hot surface
請注意，表面過熱
Caution
警告
Operator's manual
操作手冊
Stand-by
待機
"ON"/"OFF" (push-push)
“開啟”/”關閉”（按壓式）
Fuse
保險絲
Fuse is used in neutral N
保險絲用於中性線 N
RECYCLING
回收
This product bears the selective sorting symbol for Waste electrical
and electronic equipment (WEEE). This means that this product must
be handled pursuant to European directive 2012/19/EU in order to be
recycled or dismantled to minimize its impact on the environment.
User has the choice to give his product to a competent recycling
organization or to the retailer when he buys a new electrical or electronic
equipment.
這個產品帶有歐盟指令 2012/19/EU 中關於廢棄電氣電子設備（WEEE）的
選擇性分類標誌。這意味著，該產品必須按照該指令處理，以便進行回收
或拆解，從而最大限度地減少對環境的影響。
用戶可以選擇將產品交給有資格的回收機構，或在購買新的電器或電子設
備時將其交給零售商進行回收。
Caution, avoid listening at high volume levels for long periods
請小心，避免長時間以高音量收聽。
Disconnection, all power plugs
斷線，所有電源插頭
m
Switch of mini-gap construction
迷你間隙結構開關
µ
Switch of micro-gap construction (for US version)
Switch of micro-gap / micro-disconnection construction (for other
versions except US)
小間隙結構開關（US 版本）
小間隙/小斷開結構的開關（非 US 版）
ε
Switch without contact gap (Semiconductor switching device)
無接觸間隙的開關（半導體開關設備）
Safety Information
Keep the device away from water, re, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device. If you need
service, please contact us.
Do not use any other chargers than those recommended.
Do not use damaged charger or USB cable to charge the device.
For POE150S:
限用物質含有情況標示聲明書
產品元件名稱
PCB
外殼
電源供應器
其他及其配件
限用物質及其化學符號
備考1： "○"系指該項限用物質之百分比含量未超出百分比含量基準值。
備考2： " - " 系指該項限用物質為排除項目。
○ ○ ○ ○ ○
鉛
Pb
○
○
-
-
鎘
Cd
○
○
汞
Hg
○
○
六價鉻
Cr
+6
○
○
多溴聯苯
PBB
○
○
多
溴二苯醚
PBDE
○
○
○ ○ ○ ○ ○
運作溫度（POE150S）
運作溫度（POE10R）
存放溫度
運作濕度
存放濕度
環境和物理規格
-10˚C - 50˚C (14˚F - 122˚F)
-5˚C - 45˚C (23˚F - 104˚F)
-40˚C - 70˚C (-40˚F - 158˚F)
10% - 90% RH 無凝結
5% - 90% RH 無凝結
PoE Injector:
Power LED Explanation
On: Supplying power normally
O: No power supply
PoE Splitter:
On: Connected to PSE correctly
O: No PSE is connected
LAN OUT
PWR
DC OUT
LAN IN
PWR
DC 48V
Model
POE150S
Power Adapter Manufacturer
TP-Link
For the EU countries, use only the power adapters listed below:
