AXISQ3505–VEFixedDomeNetworkCamera

UserManual

AboutthisDocument

ThismanualisintendedforadministratorsandusersoftheAXIS

Q3505–VEFixedDomeNetworkCamera,andisapplicabletormware

5.55andlater.Itincludesinstructionsforusingandmanagingthe

productonyournetwork.Previousexperienceofnetworkingwillbeof

usewhenusingthisproduct.SomeknowledgeofUNIXorLinux-based

systemsmayalsobebenecial,fordevelopingshellscriptsand

applications.LaterversionsofthisdocumentwillbepostedtotheAxis

website,asrequired.Seealsotheproduct’sonlinehelp,availablevia

theweb-basedinterface.

LegalConsiderations

Videoandaudiosurveillancecanberegulatedbylawsthatvaryfrom

countrytocountry.Checkthelawsinyourlocalregionbeforeusing

thisproductforsurveillancepurposes.

Thisproductincludesone(1)H.264decoderlicenseandone(1)AAC

decoderlicense.Topurchasefurtherlicenses,contactyourreseller.

Liability

Everycarehasbeentakeninthepreparationofthisdocument.Please

informyourlocalAxisofceofanyinaccuraciesoromissions.Axis

CommunicationsABcannotbeheldresponsibleforanytechnicalor

typographicalerrorsandreservestherighttomakechangestothe

productandmanualswithoutpriornotice.AxisCommunicationsAB

makesnowarrantyofanykindwithregardtothematerialcontained

withinthisdocument,including,butnotlimitedto,theimplied

warrantiesofmerchantabilityandtnessforaparticularpurpose.Axis

CommunicationsABshallnotbeliablenorresponsibleforincidentalor

consequentialdamagesinconnectionwiththefurnishing,performance

oruseofthismaterial.Thisproductisonlytobeusedforitsintended

purpose.

IntellectualPropertyRights

AxisABhasintellectualpropertyrightsrelatingtotechnologyembodied

intheproductdescribedinthisdocument.Inparticular,andwithout

limitation,theseintellectualpropertyrightsmayincludeoneormore

ofthepatentslistedatwww.axis.com/patent.htmandoneormore

additionalpatentsorpendingpatentapplicationsintheUSandother

countries.

Thisproductcontainslicensedthird-partysoftware.Seethemenuitem

“About”intheproduct’suserinterfaceformoreinformation.

ThisproductcontainssourcecodecopyrightAppleComputer,

Inc.,underthetermsofApplePublicSourceLicense2.0(see

www.opensource.apple.com/apsl).Thesourcecodeisavailablefrom

https://developer.apple.com/bonjour/

EquipmentModications

Thisequipmentmustbeinstalledandusedinstrictaccordancewiththe

instructionsgivenintheuserdocumentation.Thisequipmentcontains

nouser-serviceablecomponents.Unauthorizedequipmentchangesor

modicationswillinvalidateallapplicableregulatorycertications

andapprovals.

TrademarkAcknowledgments

AXISCOMMUNICATIONS,AXIS,ETRAX,ARTPECandVAPIXare

registeredtrademarksortrademarkapplicationsofAxisABinvarious

jurisdictions.Allothercompanynamesandproductsaretrademarksor

registeredtrademarksoftheirrespectivecompanies.

Apple,Boa,Apache,Bonjour,Ethernet,InternetExplorer,Linux,

Microsoft,Mozilla,Real,SMPTE,QuickTime,UNIX,Windows,Windows

VistaandWWWareregisteredtrademarksoftherespectiveholders.

JavaandallJava-basedtrademarksandlogosaretrademarksor

registeredtrademarksofOracleand/oritsafliates.UPnP

isa

certicationmarkoftheUPnP

ImplementersCorporation.

SD,SDHCandSDXCaretrademarksorregisteredtrademarksofSD-3C,

LLCintheUnitedStates,othercountriesorboth.Also,miniSD,microSD,

miniSDHC,microSDHC,microSDXCarealltrademarksorregistered

trademarksofSD-3C,LLCintheUnitedStates,othercountriesorboth.

RegulatoryInformation

Europe

ThisproductcomplieswiththeapplicableCEmarkingdirectives

andharmonizedstandards:

•ElectromagneticCompatibility(EMC)Directive2004/108/EC.See

ElectromagneticCompatibility(EMC)onpage2.

•LowVoltage(LVD)Directive2006/95/EC.SeeSafetyonpage3.

•RestrictionsofHazardousSubstances(RoHS)Directive2011/65/EU.

SeeDisposalandRecyclingonpage3.

Acopyoftheoriginaldeclarationofconformitymaybeobtainedfrom

AxisCommunicationsAB.SeeContactInformationonpage3.

ElectromagneticCompatibility(EMC)

Thisequipmenthasbeendesignedandtestedtofulllapplicable

standardsfor:

•Radiofrequencyemissionwheninstalledaccordingtothe

instructionsandusedinitsintendedenvironment.

•Immunitytoelectricalandelectromagneticphenomenawhen

installedaccordingtotheinstructionsandusedinitsintended

environment.

USA

Thisequipmenthasbeentestedusingashieldednetworkcable(STP)

andfoundtocomplywiththelimitsforaClassBdigitaldevice,

pursuanttopart15oftheFCCRules.Theselimitsaredesigned

toprovidereasonableprotectionagainstharmfulinterferenceina

residentialinstallation.Thisequipmentgenerates,usesandcanradiate

radiofrequencyenergyand,ifnotinstalledandusedinaccordance

withtheinstructions,maycauseharmfulinterferencetoradio

communications.However,thereisnoguaranteethatinterference

willnotoccurinaparticularinstallation.Ifthisequipmentdoes

causeharmfulinterferencetoradioortelevisionreception,which

canbedeterminedbyturningtheequipmentoffandon,theuseris

encouragedtotrytocorrecttheinterferencebyoneormoreofthe

followingmeasures:

•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connecttheequipmentintoanoutletonacircuitdifferentfrom

thattowhichthereceiverisconnected.

•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

Theproductshallbeconnectedusingashieldednetworkcable(STP)

thatisproperlygrounded.

Canada

ThisClassBdigitalapparatuscomplieswithCanadianICES-003.The

productshallbeconnectedusingashieldednetworkcable(STP)thatis

properlygrounded.

CetappareilnumériquedelaclasseBestconfomeàlanorme

NMB-003duCanada.Leproduitdoitêtreconnectéàl'aided'uncâble

réseaublindé(STP)quiestcorrectementmisàlaterre.

Europe

ThisdigitalequipmentfulllstherequirementsforRFemission

accordingtotheClassBlimitofEN55022.Theproductshallbe

connectedusingashieldednetworkcable(STP)thatisproperly

grounded.

Thisproductfulllstherequirementsforemissionandimmunity

accordingtoEN50121-4andIEC62236-4railwayapplications.

Thisproductfulllstherequirementsforimmunityaccording

toEN61000-6-1residential,commercialandlight-industrial

environments.

Thisproductfulllstherequirementsforimmunityaccordingto

EN61000-6-2industrialenvironments.

Thisproductfulllstherequirementsforimmunityaccordingto

EN55024ofceandcommercialenvironments

Australia/NewZealand

ThisdigitalequipmentfulllstherequirementsforRFemission

accordingtotheClassBlimitofAS/NZSCISPR22.Theproductshall

beconnectedusingashieldednetworkcable(STP)thatisproperly

grounded.

Japan

この装置は、クラスB情報技術装置です。この装置は、家

庭環境で使用することを目的としていますが、この装置が

ラジオやテレビジョン受信機に近接して使用されると、受

信障害を引き起こすことがあります。取扱説明書に従って

正しい取り扱いをして下さい。本製品は、シールドネット

ワークケーブル(STP)を使用して接続してください。また

適切に接地してください。

Korea

이기기는가정용(B급)전자파적합기기로서주로가정에

서사용하는것을목적으로하며,모든지역에서사용할수

있습니다.적절히접지된STP(shieldedtwistedpair)케이

블을사용하여제품을연결하십시오.

Safety

ThisproductcomplieswithIEC/EN/UL60950-1and

IEC/EN/UL60950-22,SafetyofInformationTechnology

Equipment.Theproductshallbegroundedeitherthroughashielded

networkcable(STP)orotherappropriatemethod.

Battery

TheAxisproductusesa3.0VBR/CR2032lithiumbatteryasthepower

supplyforitsinternalreal-timeclock(RTC).Undernormalconditions

thisbatterywilllastforaminimumofveyears.

LowbatterypoweraffectstheoperationoftheRTC,causingittoreset

ateverypower-up.Whenthebatteryneedsreplacing,alogmessage

willappearintheproduct’sserverreport.Formoreinformationabout

theserverreport,seetheproduct´ssetuppagesorcontactAxissupport.

Thebatteryshouldnotbereplacedunlessrequired,butifthebattery

doesneedreplacing,contactAxissupportatwww.axis.com/techsupfor

assistance.

WARNING

•Riskofexplosionifthebatteryisincorrectlyreplaced.

•Replaceonlywithanidenticalbatteryorabatterywhichis

recommendedbyAxis.

•Disposeofusedbatteriesaccordingtolocalregulationsor

thebatterymanufacturer'sinstructions.

DisposalandRecycling

Whenthisproducthasreachedtheendofitsusefullife,disposeof

itaccordingtolocallawsandregulations.Forinformationabout

yournearestdesignatedcollectionpoint,contactyourlocalauthority

responsibleforwastedisposal.Inaccordancewithlocallegislation,

penaltiesmaybeapplicableforincorrectdisposalofthiswaste.

Europe

Thissymbolmeansthattheproductshallnotbedisposedof

togetherwithhouseholdorcommercialwaste.Directive2012/19/EU

onwasteelectricalandelectronicequipment(WEEE)isapplicablein

theEuropeanUnionmemberstates.Topreventpotentialharmto

humanhealthandtheenvironment,theproductmustbedisposed

ofinanapprovedandenvironmentallysaferecyclingprocess.For

informationaboutyournearestdesignatedcollectionpoint,contact

yourlocalauthorityresponsibleforwastedisposal.Businessesshould

contacttheproductsupplierforinformationabouthowtodispose

ofthisproductcorrectly.

ThisproductcomplieswiththerequirementsofDirective2011/65/EUon

therestrictionoftheuseofcertainhazardoussubstancesinelectrical

andelectronicequipment(RoHS).

China

Thisproductcomplieswiththerequirementsofthelegislative

actAdministrationontheControlofPollutionCausedbyElectronic

InformationProducts(ACPEIP).

ContactInformation

AxisCommunicationsAB

Emdalavägen14

22369Lund

Sweden

Tel:+46462721800

Fax:+4646136130

www.axis.com

Support

Shouldyourequireanytechnicalassistance,pleasecontactyourAxis

reseller.Ifyourquestionscannotbeansweredimmediately,your

resellerwillforwardyourqueriesthroughtheappropriatechannelsto

ensurearapidresponse.IfyouareconnectedtotheInternet,youcan:

•downloaduserdocumentationandsoftwareupdates

•ndanswerstoresolvedproblemsintheFAQdatabase.Search

byproduct,category,orphrase

•reportproblemstoAxissupportstaffbyloggingintoyourprivate

supportarea

•chatwithAxissupportstaff(selectedcountriesonly)

•visitAxisSupportatwww.axis.com/techsup/

LearnMore!

VisitAxislearningcenterwww.axis.com/academy/forusefultrainings,

webinars,tutorialsandguides.

AXISQ3505–VEFixedDomeNetworkCamera

TableofContents

HardwareOverview..........................................6

ConnectorsandButtons..........................................6

LEDIndicators..................................................8

StatusLEDBehaviorandBuzzerSignalforLevellingAssistant...........8

AccesstheProduct..........................................9

AccessfromaBrowser...........................................9

AccessfromtheInternet..........................................9

SettheRootPassword...........................................9

TheLiveViewPage..............................................10

MediaStreams.............................................14

HowtoStreamH.264............................................14

MJPEG........................................................14

AXISMediaControl(AMC)........................................14

AlternativeMethodsofAccessingtheVideoStream....................15

AccessAudioStreams............................................16

SetUptheProduct..........................................17

BasicSetup....................................................17

VideoandAudio............................................18

VideoStream...................................................18

StreamProles.................................................20

CameraSettings................................................20

ViewArea.....................................................23

Overlay........................................................24

PrivacyMask...................................................26

Focus&Zoom..................................................26

SetZoomandFocus-OpticalZoomforMonitoring....................26

AudioSettings..................................................27

AudioClips....................................................28

ConguretheLiveViewPage.................................29

PTZ(PanTiltZoom).........................................31

PresetPositions.................................................31

Gatekeeper....................................................31

GuardTour.....................................................32

Advanced......................................................32

Detectors..................................................33

CameraTampering..............................................33

ShockDetection................................................33

MotionDetection...............................................33

AudioDetection................................................35

Applications...............................................36

ApplicationLicenses.............................................36

InstallApplication...............................................36

ApplicationConsiderations........................................36

Events....................................................38

SetUpActionRules.............................................38

AddRecipients..................................................40

CreateSchedules................................................41

SetUpRecurrences..............................................41

Recordings.................................................42

RecordingList..................................................42

ContinuousRecording............................................42

Languages.................................................44

SystemOptions.............................................45

Security.......................................................45

Date&Time....................................................47

Network.......................................................48

Storage.......................................................53

Ports&Devices.................................................54

Maintenance...................................................55

Support.......................................................55

Advanced......................................................56

AXISQ3505–VEFixedDomeNetworkCamera

TableofContents

ResettoFactoryDefaultSettings...................................57

Troubleshooting............................................58

ChecktheFirmware.............................................58

UpgradetheFirmware...........................................58

Symptoms,PossibleCausesandRemedialActions.....................59

TechnicalSpecications......................................63

Connectors....................................................66

Multicable(soldseparately).......................................67

PerformanceConsiderations.......................................68

AXISQ3505–VEFixedDomeNetworkCamera

HardwareOverview

Note

3–9mmlens:Pressingthelenstoohardwhilecleaningmaycausethelenstomovedown.Ifthishappenswhilethe

cameraisinoperation,re-calibratetheopticsbyclickingCalibratefromtheServerMaintenancewebpage(System

Options>Maintenance).

8 9 11

1 2 3 4 5

6 16

Networkconnector

Controlbutton

I/Oconnector

Audioout

Audioin

SDcardslot

AC/DCconnectorforpoweraccessory

Mountingbracket

Sidelidcoveringsideholeinmountingbracket

10.

Conduitadaptor

11.

Lockingclip

12.

Unitcasing

13.

Cameraunit

14.

Domecover

15.

Weathershield

16.

StatusLed

17.

Functionbutton

18.

Springinunitcasing

19.

HeaterCaution! Caution!

Caution!

Theheatermaybehot

ConnectorsandButtons

Fortechnicalspecications,seepage63.

AXISQ3505–VEFixedDomeNetworkCamera

HardwareOverview

NetworkConnector

RJ45EthernetconnectorwithPoweroverEthernet(PoE).

NO NO

TICE TICE

TICE

Theproductshallbeconnectedusingashieldednetworkcable(STP).Allcablesconnectingtheproducttothenetworkshall

beintendedfortheirspecicuse.Makesurethatthenetworkdevicesareinstalledinaccordancewiththemanufacturer’s

instructions.Forinformationaboutregulatoryrequirements,seeElectromagneticCompatibility(EMC)onpage2.

I/OConnector

Usewithexternaldevicesincombinationwith,forexample,tamperingalarms,motiondetection,eventtriggering,timelapserecording

andalarmnotications.Inadditiontothe0VDCreferencepointandpower(DCoutput),theI/Oconnectorprovidestheinterfaceto:

•Digitaloutput–ForconnectingexternaldevicessuchasrelaysandLEDs.Connecteddevicescanbeactivatedbythe

VAPIX®ApplicationProgrammingInterface,outputbuttonsontheLiveViewpageorbyanActionRule.Theoutputwill

showasactive(shownunderSystemOptions>Ports&Devices)ifthealarmdeviceisactivated.

•Digitalinput–Analarminputforconnectingdevicesthatcantogglebetweenanopenandclosedcircuit,forexample:

PIRs,door/windowcontacts,glassbreakdetectors,etc.Whenasignalisreceivedthestatechangesandtheinputbecomes

active(shownunderSystemOptions>Ports&Devices).

AudioConnector

TheAxisproducthasthefollowingaudioconnectors:

•Audioin(pink)–3.5mminputforamonomicrophone,oraline-inmonosignal.

•Audioout(green)–3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress(PA)systemoran

activespeakerwithabuilt-inamplier.Astereoconnectormustbeusedforaudioout.

SDCardSlot

AmicroSDcard(notincluded)canbeusedforlocalrecordingwithremovablestorage.Formoreinformation,seeTechnical

Specicationsonpage63.

NO NO

TICE TICE

TICE

Topreventcorruptionofrecordings,theSDcardshouldbeunmountedbeforeremoval.Tounmount,gotoSetup>System

Options>Storage>SDCardandclickUnmount.

Note

ForSDcardrecommendationsseewww.axis.com

ControlButton

Thecontrolbuttonisusedfor:

•Resettingtheproducttofactorydefaultsettings.Seepage57.

•ConnectingtoanAXISVideoHostingSystemservice.Seepage49.Toconnect,pressandholdthebuttonforabout3

secondsuntiltheStatusLEDashesgreen.

•ConnectingtoAXISInternetDynamicDNSService.Seepage49.Toconnect,pressandholdthebuttonforabout3seconds.

FunctionButton

Thefunctionbuttonhasmultiplefunctions:

•AsLevellingAssistant–Thisfunctionhelpstoensuretheimageislevel.Pressthebuttonforabout2secondstostartthe

levellingassistantandpressagaintostop.ThestatusLED(seepage8)andbuzzersignalassistlevellingoftheimage.

Theimageislevelwhenthebuzzerbeepscontinuously.

AXISQ3505–VEFixedDomeNetworkCamera

HardwareOverview

•ToviewtheStatusLED–PressthebuttononcetolightuptheStatusLEDs.Pressagaintoturnthemoff.TheLEDs

willturnoffautomaticallyafter10seconds.

LEDIndicators

LED

Color

Indication

Unlit

Connectionandnormaloperation

Amber

Steadyduringstartup.Flashesduringrmwareupgrade.

Amber/redFlashesamber/redifnetworkconnectionisunavailableorlost.

RedFlashesredforrmwareupgradefailure.

Status

GreenShowssteadygreenfor10secondsfornormaloperationafterrestart.

Note

•TheStatusLEDcanbeconguredtoashwhileaneventisactive.

•TheStatusLEDcanbeconguredtoashforidentifyingtheunit.GotoSetup>SystemOptions>Maintenance.

StatusLEDBehaviorandBuzzerSignalforLevellingAssistant

ForinformationontheFunctionbuttonusedforlevellingtheimage,seeConnectorsandButtons.

Color

Buzzer

Cameraposition

Fixedgreen

Continuousbeep

Level

FlashinggreenFastintervalAlmostlevel

FlashingorangeMediumintervalNotlevel

Flashingred

Slowinterval

Farfromlevel

AXISQ3505–VEFixedDomeNetworkCamera

AccesstheProduct

ToinstalltheAxisproduct,refertotheInstallationGuidesuppliedwiththeproduct.

Theproductcanbeusedwithmostoperatingsystemsandbrowsers.TherecommendedbrowsersareInternetExplorerwithWindows,

SafariwithMacintoshandFirefoxwithotheroperatingsystems.SeeTechnicalSpecicationsonpage63.

ToviewstreamingvideoinInternetExplorer,allowinstallationofAXISMediaControl(AMC)whenprompted.

TheAxisproductincludesone(1)H.264decoderlicenseforviewingvideostreamsandone(1)AACaudiolicense.Thelicensesare

automaticallyinstalledwithAMC.Theadministratorcandisabletheinstallationofthedecoders,topreventinstallationofunlicensed

copies.

Note

•QuickTime

isalsosupportedforviewingH.264streamsandforaudio.

•Ifyourcomputerrestrictstheuseofadditionalsoftwarecomponents,theproductcanbeconguredtouseaJavaapplet

forviewingMotionJPEG.

AccessfromaBrowser

1.Startabrowser(InternetExplorer,Firefox,Safari).

2.EntertheIPaddressorhostnameoftheAxisproductinthebrowser’sLocation/Addresseld.Toaccesstheproductfroma

Macintoshcomputer(MacOSX),clickontheBonjourtabandselecttheproductfromthedrop-downlist.

IfyoudonotknowtheIPaddress,useAXISIPUtilitytolocatetheproductonthenetwork.Forinformationabouthowto

discoverandassignanIPaddress,seetheInstallationandManagementSoftwareCDorthedocumentAssignanIPAddress

andAccesstheVideoStreamonAxisSupportwebatwww.axis.com/techsup

3.Enteryourusernameandpassword.Ifthisisthersttimetheproductisaccessed,therootpasswordmustrstbe

congured.Forinstructions,seeSettheRootPasswordonpage9.

4.Theproduct’sLiveViewpageopensinyourbrowser.

Note

ThecontrolsandlayoutoftheLiveViewpagemayhavebeencustomizedtomeetspecicinstallationrequirementsand

userpreferences.Consequently,someoftheexamplesandfunctionsfeaturedheremaydifferfromthosedisplayedin

yourownLiveViewpage.

AccessfromtheInternet

Onceconnected,theAxisproductisaccessibleonyourlocalnetwork(LAN).ToaccesstheproductfromtheInternetyoumust

congureyournetworkroutertoallowincomingdatatrafctotheproduct.Todothis,enabletheNAT-traversalfeature,which

willattempttoautomaticallyconguretheroutertoallowaccesstotheproduct.ThisisenabledfromSetup>SystemOptions>

Network>TCP/IPAdvanced.

Formoreinformation,seeNATtraversal(portmapping)forIPv4onpage50.SeealsoAXISInternetDynamicDNSServiceat

www.axiscam.net

ForTechnicalnotesonthisandothertopics,visittheAxisSupportwebatwww.axis.com/techsup

SettheRootPassword

ToaccesstheAxisproduct,youmustsetthepasswordforthedefaultadministratoruserroot.ThisisdoneintheCongureRoot

Passworddialog,whichopenswhentheproductisaccessedforthersttime.

AXISQ3505–VEFixedDomeNetworkCamera

AccesstheProduct

Topreventnetworkeavesdropping,therootpasswordcanbesetviaanencryptedHTTPSconnection,whichrequiresanHTTPS

certicate.HTTPS(HypertextTransferProtocoloverSSL)isaprotocolusedtoencrypttrafcbetweenwebbrowsersandservers.The

HTTPScerticateensuresencryptedexchangeofinformation.SeeHTTPSonpage45.

Thedefaultadministratorusernamerootispermanentandcannotbedeleted.Ifthepasswordforrootislost,theproductmustbe

resettothefactorydefaultsettings.SeeResettoFactoryDefaultSettingsonpage57.

TosetthepasswordviaastandardHTTPconnection,enteritdirectlyinthedialog.

TosetthepasswordviaanencryptedHTTPSconnection,followthesesteps:

1.ClickUseHTTPS.

Atemporarycerticate(validforoneyear)iscreated,enablingencryptionofalltrafctoandfromtheproduct,andthe

passwordcannowbesetsecurely.

2.Enterapasswordandthenre-enterittoconrmthespelling.

3.ClickOK.Thepasswordhasnowbeencongured.

PTZMode

PTZmodeissetthersttimetheAxisproductisaccessedandcanonlybechangedbyresettingtheproducttofactorydefault

settings.TheproductcanuseeitherOpticalzoomforinstallationorOpticalZoomformonitoring.ThedefaultmodeisOptical

zoomforinstallation.Inthismodeopticalzoomisdisabledformonitoring,butitispossibletoenableviewareasanddigital

PTZ.TheGatekeeperfunctionisnotavailableinthismode.

SelectOpticalzoomformonitoringtouseopticalzoomonlyformonitoring(suchasforGatekeeper).InthismodedigitalPTZ

andviewareasaredisabled.

CongureCaptureMode

CapturemodedenesthemaximumresolutionandmaximumframerateavailableintheAxisproduct.Thecapturemodesettingalso

affectsthecamera’sangleofview.

Selectthedesiredcapturemodefromthedrop-downlistandclickOK.

SeealsoCaptureModeonpage20.

SetPowerLineFrequency

PowerlinefrequencyissetthersttimetheAxisproductisaccessedandcanonlybechangedfromPlainCong(seepage56)

orbyresettingtheproducttofactorydefault.

Selectthepowerlinefrequency(50Hzor60Hz)usedatthelocationoftheAxisproduct.Selectingthewrongfrequencymaycause

imageickeriftheproductisusedinuorescentlightenvironments.

Note

Powerlinefrequencyvariesdependingongeographicregion.TheAmericasusuallyuse60Hz,whereasmostotherpartsof

theworlduse50Hz.Localvariationscouldapply.Alwayscheckwiththelocalauthorities.

TheLiveViewPage

ThecontrolsandlayoutoftheLiveViewpagemayhavebeencustomizedtomeetspecicinstallationrequirementsanduser

preferences.Consequently,someoftheexamplesandfunctionsfeaturedheremaydifferfromthosedisplayedinyourownLiveView

page.Thefollowingprovidesanoverviewofeachavailablecontrol.

AXISQ3505–VEFixedDomeNetworkCamera

AccesstheProduct

ControlsontheLiveViewPage

ClickViewsizetoscaletheimagedownto800pixelswideortofullscale.OnlyavailableinMJPEG.

ClickWDRontoenableWDRinintensebacklightconditions.ClickWDRofftodisableWDRinlowlight

conditionsforoptimalexposure.

SelectastreamprolefortheLiveViewpagefromtheStreamProledrop-downlist.Forinformationabouthow

tocongurestreamproles,seepage20.

ClickPulsetoactivatetheproduct’soutputportforadenedperiodoftime.Forinformationabouthowto

enableandcongureoutputbuttons,seepage30.

ClicktheActive/Inactivebuttonstomanuallyactivateandinactivetheproduct’soutputport.Forinformation

abouthowtoenableandcongureoutputbuttons,seepage30.

TheManualTriggerbuttonisusedtotriggeranactionrulefromtheLiveViewpage.Forinformationabouthowto

congureandenablethebutton,seeManualTriggeronpage11.

ClickSnapshottosaveasnapshotofthevideoimage.Thisbuttonisprimarilyintendedforusewhenthe

AXISMediaControlviewertoolbarisnotavailable.EnablethisbuttonfromLiveViewCong>ActionButtons.

TheAudioclipdrop-downlistallowsyoutoplayanaudioclipfromtheLiveViewpage.Selectthe

audioclipandclickthePlaybutton.

Activatetheproduct’sheaterwiththisbutton.EnablethisbuttonfromLiveViewCong>ActionButtons.

EnableordisabletheGatekeeperbyselectingOnorOfffromthedrop-downlist.ReadmoreabouttheGatekeeper

onpage31.

ManualTrigger

TheManualTriggerisusedtotriggeranactionrulefromtheLiveViewpage.Themanualtriggercanforexamplebeusedto

validateactionsduringproductinstallationandconguration.

Tocongurethemanualtrigger:

1.GotoSetup>Events.

2.ClickAddtoaddanewactionrule.

3.FromtheTriggerdrop-downlist,selectInputSignal.

4.Fromtheseconddrop-downlist,selectManualTrigger.

5.Selectthedesiredactionandconguretheothersettingsasrequired.

Formoreinformationaboutactionrules,seeEventsonpage38.

AXISQ3505–VEFixedDomeNetworkCamera

AccesstheProduct

ToshowthemanualtriggerbuttonsintheLiveViewpage:

1.GotoSetup>LiveViewCong.

2.UnderActionButtons,selectShowmanualtriggerbutton.

AXISMediaControlviewertoolbar

TheAXISMediaControlviewertoolbarisavailableinInternetExploreronly.SeeAXISMediaControl(AMC)onpage14formore

information.Thetoolbardisplaysthefollowingbuttons:

ThePlaybuttonconnectstotheAxisproductandstartsplayingamediastream.

TheStopbuttonstopsthemediastream.

TheSnapshotbuttontakesasnapshotofthevideoimage.Thelocationwheretheimageissavedcanbespecied

intheAMCControlPanel.

ClicktheViewFullScreenbuttonandthevideoimagewilllltheentirescreen.PressESC(Escape)onthecomputer

keyboardtocancelfullscreenview.

TheRecordbuttonisusedtorecordthecurrentvideostream.Thelocationwheretherecordingissavedcanbespeciedin

theAMCControlPanel.EnablethisbuttonfromLiveViewCong>ViewerSettings.

AMCAudioControls

AMCaudiobuttonscontrolthespeakersandmicrophoneconnectedtotheclientcomputer.Thebuttonsareonlyvisiblewhen

audioisenabled.

Speakerbutton—Clicktoturnthespeakersonoroff.

Microphonebutton–Clicktomuteorunmutethemicrophone.InSimplex-speakeronlymode,theMicrophoneandTalk

buttonsmustbothbeactivetosendaudiototheAxisproduct.Clickeitherbuttontostopaudiotransmission.

Usetheslidertocontrolthevolumeofthespeakersandthemicrophone.

Half-duplexmode

TheTalk/Listenbuttonisusedtoswitchbetweensendingandreceivingaudio.Thebuttoncanbecongured

fromtheAudiotabintheAMCControlpanel:

•Push-To-Talkmode:Clickandholdthebuttontotalk/send.Releasethebuttontolisten.

•Togglemode:Clickoncetoswitchbetweentalkingandlistening.

Simplex–speakeronlymode

Tosendaudio,theTalkandMicrophonebuttonsmustbothbeactive.Clickeitherbuttontostopaudio

transmission.

PTZControls

TheLiveViewpagealsodisplaysPan/Tilt/Zoom(PTZ)controls.Theadministratorcanenable/disablecontrolsforspeciedusersunder

SystemOptions>Security>Users.

Note

ThesecontrolsareavailableifdigitalPTZisenabledintheselectedviewarea,seeViewAreaonpage23.

AXISQ3505–VEFixedDomeNetworkCamera

AccesstheProduct

ClicktheEmulatejoystickmodebuttonandclickintheimagetomovethecameraviewinthedirectionofthe

mousepointer.

ClicktheCentermodebuttonandclickintheimagetocenterthecameraviewonthatposition.Thecentermode

buttoncouldalsobeusedtozoominonaspecicarea.Clickintheimageanddragtodrawarectanglesurrounding

theareatobemagnied.Tozoomout,rotatethemousewheel.

ClicktheCtrlpanelbuttontoopenthePTZcontrolpanelwhichprovidesadditionalPTZcontrols.

User-denedbuttonscanalsoappearintheControlpanel.SeeControlsonpage32.

Toviewaspecicviewareaorpresetposition,selectitfromtheSourcelist.

PanandTiltbars–Usethearrowstopanandtiltthecameraview,orclickona

positiononthebartosteerthecameraviewtothatposition.

Focusbar–Usethearrowstofocusthecamera,orclickonapositiononthebar

tosetthefocusposition.Usingthefocusbarwilldisabletheproduct’sautofocus.

Tore-enable,usethePTZcontrolpanelwhichisopenedbyclickingtheCtrlpanel

button(seeabove).

ThePTZcontrolscanbedisabledunderPTZ>Advanced>Controls,seeControlsonpage32.

AXISQ3505–VEFixedDomeNetworkCamera

MediaStreams

TheAxisproductprovidesseveralaudioandvideostreamformats.Yourrequirementsandthepropertiesofyournetworkwill

determinethetypeyouuse.

TheLiveViewpageintheproductprovidesaccesstoH.264andMotionJPEGvideostreams,audiostreamsandtothelistofavailable

streamproles.Otherapplicationsandclientscanaccessvideoandaudiostreamsdirectly,withoutgoingviatheLiveViewpage.

HowtoStreamH.264

H.264can,withoutcompromisingimagequality,reducethesizeofadigitalvideolebymorethan80%comparedwiththeMotion

JPEGformatandasmuchas50%morethantheMPEG-4standard.Thismeansthatmuchlessnetworkbandwidthandstoragespace

arerequiredforavideole.Orseenanotherway,muchhighervideoqualitycanbeachievedforagivenbitrate.

Decidingwhichcombinationofprotocolsandmethodstousedependsonyourviewingrequirements,andonthepropertiesof

yournetwork.TheavailableoptionsinAXISMediaControlare:

UnicastRTP

Thisunicastmethod(RTPoverUDP)isused

forliveunicastvideo,especiallywhenitis

importanttoalwayshaveanup-to-datevideo

stream,evenifsomeframesaredropped.

RTPoverRTSP

Thisunicastmethod(RTPtunneledoverRTSP)

isusefulasitisrelativelysimpletocongure

rewallstoallowRTSPtrafc.

RTPoverRTSPoverHTTP

Thisunicastmethodcanbeusedtotraverse

rewalls.Firewallsarecommonlyconguredto

allowtheHTTPprotocol,thusallowingRTPto

betunneled.

Unicastingisusedforvideo-on-demand

transmissionsothatthereisnovideotrafc

onthenetworkuntilaclientconnectsand

requeststhestream.

Notethatthereareamaximumof10

simultaneousunicastconnections.

MulticastRTP

Thismethod(RTPoverUDP)shouldbeusedforlivemulticastvideo.Thevideostreamisalways

up-to-date,evenifsomeframesaredropped.

Multicastingprovidesthemostefcientusageofbandwidthwhentherearelargenumbersof

clientsviewingsimultaneously.Amulticastcannothowever,passanetworkrouterunlessthe

routerisconguredtoallowthis.ItisnotpossibletomulticastovertheInternet,forexample.

Notealsothatallmulticastviewerscountasoneunicastviewerinthemaximumtotalof10

simultaneousconnections.

AXISMediaControlnegotiateswiththeAxisproducttodeterminethetransportprotocoltouse.Theorderofpriority,listedinthe

AMCControlPanel,canbechangedandtheoptionsdisabled,tosuitspecicrequirements.

Note

H.264islicensedtechnology.TheAxisproductincludesoneH.264viewingclientlicense.Installingadditionalunlicensed

copiesoftheclientisprohibited.Topurchaseadditionallicenses,contactyourAxisreseller.

MJPEG

ThisformatusesstandardJPEGstillimagesforthevideostream.Theseimagesarethendisplayedandupdatedataratesufcient

tocreateastreamthatshowsconstantlyupdatedmotion.

TheMotionJPEGstreamusesconsiderableamountsofbandwidth,butprovidesexcellentimagequalityandaccesstoeveryimage

containedinthestream.TherecommendedmethodofaccessingMotionJPEGlivevideofromtheAxisproductistousetheAXIS

MediaControlinInternetExplorerinWindows.

AXISMediaControl(AMC)

AXISMediaControl(AMC)inInternetExplorerinWindowsistherecommendedmethodofaccessinglivevideofromtheAxisproduct.

AXISQ3505–VEFixedDomeNetworkCamera

MediaStreams

TheAMCControlPanelcanbeusedtocongurevariousvideoandaudiosettings.PleaseseetheAXISMediaControlUser’s

Manualformoreinformation.

TheAMCControlPanelisautomaticallyinstalledonrstuse,afterwhichitcanbecongured.OpentheAMCControlPanelfrom:

•WindowsControlPanel(fromtheStartscreenorStartmenu)

•Alternatively,right-clickthevideoimageinInternetExplorerandclickSettings.

AlternativeMethodsofAccessingtheVideoStream

YoucanalsoaccessvideoandimagesfromtheAxisproductinthefollowingways:

•MotionJPEGserverpush(ifsupportedbytheclient,Firefox,forexample).ThisoptionmaintainsanopenHTTPconnection

tothebrowserandsendsdataasandwhenrequired,foraslongasrequired.

•StillJPEGimagesinabrowser.Enterthepathhttp://<ip>/axis-cgi/jpg/image.cgi

•WindowsMediaPlayer.ThisrequiresAXISMediaControlandtheH.264decodertobeinstalled.Thefollowingpaths

canbeused:

-UnicastviaRTP:axrtpu://<ip>/axis-media/media.amp

-UnicastviaRTSP:axrtsp://<ip>/axis-media/media.amp

-UnicastviaRTSP,tunneledviaHTTP:axrtsphttp://<ip>/axis-media/media.amp

-Multicast:axrtpm://<ip>/axis-media/media.amp

•QuickTime

.Thefollowingpathscanbeused:

-rtsp://<ip>/axis-media/media.amp

-rtsp://<ip>/axis-media/media.3gp

AXISQ3505–VEFixedDomeNetworkCamera

MediaStreams

Note

•<ip>=IPaddess

•TheAxisproductsupportsQuickTime6.5.1andlater.

•QuickTimemayaddlatencytothevideostream.

•ItmaybepossibletouseotherplayerstoviewtheH.264streamusingthepathsabove,althoughAxisdoesnotguarantee

this.

AccessAudioStreams

TheLiveViewpageprovidesaccesstoaudiothroughAXISMediaControl;inadditionaudiocanbeaccessedinthefollowingways:

•VAPIX®ApplicationProgrammingInterface(API)Formoreinformation,visitwww.axis.com/developer

•WindowsMediaPlayersupportssimplexaudio.Thefollowingpathscanbeused:

-UnicastviaRTP:axrtpu://<ip>/axis-media/media.amp

-UnicastviaRTSP:axrtsp://<ip>/axis-media/media.amp

-UnicastviaRTSP,tunneledviaHTTP:axrtsphttp://<ip>/axis-media/media.amp

-Multicast:axrtpm://<ip>/axis-media/media.amp

•QuickTime

supportsG.71 1andAACaudioencoding.Thefollowingpathscanbeused:

-rtsp://<ip>/axis-media/media.amp

-rtsp://<ip>/axis-media/media.3gp

•TheJavaappletsupportssimplexaudiowithG.711encoding.

AXISQ3505–VEFixedDomeNetworkCamera

SetUptheProduct

TheAxisproductcanbeconguredbyuserswithadministratororoperatorrights.Toopentheproduct’sSetuppages,clickSetupin

thetopright-handcorneroftheLiveViewpage.

•Administratorshaveunrestrictedaccesstoallsettings.

•OperatorshaveaccesstoallsettingsexceptSystemOptions

Seealsotheonlinehelp

BasicSetup

BasicSetupprovidesshortcutstothesettingsthatshouldbemadebeforeusingtheAxisproduct:

1.Users.Seepage45.

2.TCP/IP.Seepage48.

3.Date&Time.Seepage47.

4.VideoStream.Seepage18.

5.Focus&Zoom.Seepage26.

6.AudioSettings.Seepage27.

TheBasicSetupmenucanbedisabledfromSystemOptions>Security>Users.

AXISQ3505–VEFixedDomeNetworkCamera

VideoandAudio

Thevideoandaudiosettingscanbeusedtooptimizevideoandaudioquality.Youcancongurethefollowing:

•Videostreamsettings.Seepage18.

•Streamproles.Seepage20.

•Camerasettings.Seepage20.

•Viewareas.Seepage23.

•Overlayimage.Seepage24.

•Privacymask.Seepage26.

•Focusandzoom.Seepage26.

•Audiosettings.Seepage27.

•Audioclips.Seepage28.

VideoStream

YoucandenethefollowingvideostreamsettingsfromVideo&Audio>VideoStream:

•Image.Seepage18.

•Audio.Seepage27.

•H.264.Seepage19.

•MJPEG.Seepage19.

PixelCounter

Thepixelcountershowsthenumberofpixelsinanareaoftheimage.Thepixelcounterisusefulinsituationswherethereisa

requirementthattheimageisacertainsize,forexampleinfacerecognition.

Thepixelcountercanbeaccessedfrom:

•Video&Audio>VideoStream.UnderPreview,clickOpenandselecttheShowpixelcounteroptiontoenablethe

rectangleintheimage.Usethemousetomoveandresizetherectangle,orenterthenumberofpixelsintheWidth

andHeighteldsandclickApply.

•Video&Audio>Focus&Zoom.SelecttheShowpixelcounteroptiontoenabletherectangleintheimage.Usethe

mousetomoveandresizetherectangle,orenterthenumberofpixelsintheWidthandHeighteldsandclickApply.

•TheLiveViewpageinInternetExplorerwithAXISMediaControl(AMC)inWindows.Right-clickintheimageandselect

Pixelcounter.Usethemousetomoveandresizetherectangle.


ThedefaultimagesettingscanbeconguredunderVideo&Audio>VideoStream.SelecttheImagetab.

Thefollowingsettingsareavailable:

•Resolution.Selectthedefaultresolution.

•Compression.Thecompressionlevelaffectstheimagequality,bandwidthandlesizeofsavedimages;thelowerthe

compression,thehighertheimagequalitywithhigherbandwidthrequirementsandlargerlesizes.

AXISQ3505–VEFixedDomeNetworkCamera

VideoandAudio

•Mirrorimage.Ifrequired,theimagecanbemirrored.

•Rotateimage.Ifrequired,theimagecanberotated.

•Maximumframerate.Toavoidbandwidthproblems,theframerateallowedtoeachviewercanbeLimitedtoaxed

amount.Alternatively,theframeratecanbesetasUnlimited,whichmeanstheAxisproductalwaysdeliversthehighest

frameratepossibleunderthecurrentconditions.

•Overlaysettings.SeeOverlayonpage24.

ClickSavetoapplythenewsettings.

H.264

H.264,alsoknownasMPEG-4Part10/AVC,isavideocompressionstandardthatprovideshighqualityvideostreamsatlowbitrates.

AnH.264videostreamconsistsofdifferenttypesofframessuchasI-framesandP-frames.AnI-frameisacompleteimagewhereas

P-framesonlycontainthedifferencesfrompreviousframes.

TheH.264streamsettingscanbeconguredfromtheVideo&Audio>VideoStreampage.SelecttheH.264tab.Thesettings

denedinthispagewillapplytoallH.264streamsthatdonotuseastreamprole.

TheGOVlengthisthenumberofframesbetweentwoconsecutiveI-frames.IncreasingtheGOVlengthmaysaveconsiderablyon

bandwidthrequirementsinsomecases,butmayalsohaveanadverseaffectonimagequality.

TheAxisproductsupportsthefollowingH.264proles:

•Baseline.TheBaselineproleisrecommendedforclientsthatdon’tsupportCABACentropycoding.

•Main.TheMainproleprovideshighercompressionwithmaintainedvideoqualitycomparedtotheBaselineprolebut

requiresmoreprocessingpowertodecode.

•High.TheHighproleprovidesreducedbitrateandhighercompressionwithmaintainedvideoqualitycomparedtothe

Mainprolebutrequiresmoreprocessingpowertodecode.

ThebitratecanbesetasVariablebitrate(VBR)orMaximumbitrate(MBR).VBRadjuststhebitrateaccordingtotheimage

complexity,usingupmorebandwidthforincreasedactivityintheimage,andlessforlowerimageactivity.Whentheactivityin

thesceneincreases,thebitratewouldusuallyincreaseaswell.Ifthereisasurplusinbandwidth,thismaynotbeanissueand

selectingVariablebitrate(VBR)willbesufcient.Butifbandwidthislimited,itisrecommendedtocontrolthebitratebyselecting

Maximumbitrate(MBR).Whentheactivityinthesceneincreases,VBRadjuststhebitrateaccordingtothecomplexity,usingup

morebandwidthforincreasedactivityinthescene,andlessforlowersceneactivity.MBRallowsyoutosetatargetbitratethat

limitsthebandwidthconsumption.

TheMBRtargetbitrateworksliketheceilingofatent.Itlimitsthebitrate,whilemaintainingsomeexibility.Thebitrate

maybounceupanddownwithinthesettargetbutwhenitnearsthesettargetvalue,thelimitationkicksin.However,because

MBRwillalwaysprioritizeacontinuousvideostream,itallowstemporaryovershootsfromthetargetbitrate.Becausesettinga

targetvaluepreventsthebitratefromincreasing,framerateandimagequalityareaffectednegatively.Topartlycompensatefor

this,selectwhichvariableshallbeprioritized,framerateorimagequality.Notsettingaprioritymeansthatframerateand

imagequalityareequallyaffected.

Thecurrentbitratecanbesettoappearastextoverlay.UnderOverlaySettings,selectIncludetextandenterthemodier

#bintheeld.

Toapplythesettings,clickSave.

MJPEG

Sometimestheimagesizeislargeduetolowlightorcomplexscenery.Adjustingthemaximumframesizehelpstocontrolthe

bandwidthandstorageusedbytheMotionJPEGvideostreaminthesesituations.SettingtheframesizetotheDefaultsetting

providesconsistentlygoodimagequalityattheexpenseofincreasedbandwidthandstorageusageinlowlight.Limitingtheframe

sizeoptimizesbandwidthandstorageusage,butmaygivepoorimagequality.Topreventincreasedbandwidthandstorageusage,

themaximumframesizeshouldbesettoanoptimalvalue.

AXISQ3505–VEFixedDomeNetworkCamera

VideoandAudio

StreamProles

Astreamproleisasetofpredenedstreamsettingsincludingresolution,compression,framerateandoverlaysettings.Stream

prolescanbeused:

•Whensettinguprecordingusingactionrules.SeeEventsonpage38.

•Whensettingupcontinuousrecording.SeeContinuousRecordingonpage42.

•IntheLiveViewpage–selectthestreamprolefromtheStreamproledrop-downlist.

Forquicksetup,useoneofthepredenedstreamproles.Eachpredenedprolehasadescriptivename,indicatingitspurpose.If

required,thepredenedstreamprolescanbemodiedandnewcustomizedstreamprolescanbecreated.

Tocreateanewproleormodifyanexistingprole,gotoSetup>Video&Audio>StreamProles.

ToselectadefaultstreamprolefortheLiveViewpage,gotoSetup>LiveViewCong.

CameraSettings

TheVideo&Audio>CameraSettingspageprovidesaccesstoadvancedimagesettingsfortheAxisproduct.

CaptureMode

CapturemodedenesthemaximumresolutionandmaximumframerateavailableintheAxisproduct.Acapturemodewithalarge

maximumresolutionhasareducedmaximumframerateandviceversa.

Thecapturemodesettingalsoaffectsthecamera’sangleofviewastheeffectivesizeoftheimagesensordiffersbetweencapture

modes.

Capturemodeissetthersttimetheproductisaccessed.SelectthedesiredcapturemodeandclickOK.

Important

Changingcapturemodewhentheproducthasbeenconguredisnotrecommendedasmostothersettingswillbeeither

removedorreset.

Tochangecapturemode,followthesesteps:

1.GotoSetup>Video&Audio>CameraSettings.

2.Selectthenewcapturemode.

3.ClickSave.

4.Reviewandrecongureallsettings,forexample:

-Viewareas

-Streamproles

-PTZsettingsincludingpresetpositionsandguardtours

-Gatekeeper

-Focuswindows

-Motiondetectionwindows

-Privacymasks

-Imageoverlays

-Exposurezones

AXISQ3505–VEFixedDomeNetworkCamera

VideoandAudio

-Whitebalancewindows

-Actionrules

-Settingsinuploadedapplications

ImageAppearance

IncreasingtheColorlevelincreasesthecolorsaturation.Thevalue100givesmaximumcolorsaturation.Thevalue0givesa

blackandwhiteimage.

TheimageBrightnesscanbeadjustedintherange0–100,whereahighervalueproducesabrighterimage.

IncreasingtheSharpnesscanincreasebandwidthusage.Asharperimagemightincreaseimagenoiseespeciallyinlowlight

conditions.Alowersettingreducesimagenoise,butthewholeimagewillappearlesssharp.

TheContrastchangestherelativedifferencebetweenlightanddark.Itcanbeadjustedusingtheslidebar.

LocalContrastappliescontrasttoaspecicareaoftheimage.Usetheslidertoadjustthecontrast,whereahighervalueproduces

animagewithhighcontrastbetweenthedarkandlightareas.

ImageCorrection

Imagecorrectionsettingscancompensatefordifferenttypesofimageissues.SelectElectronicimagestabilization(EIS)to

compensateforvibrationsorselectBarreldistortioncorrectiontocompensateforlenseffects.

Note

•ItisnotrecommendedtouseElectronicimagestabilization(EIS)togetherwithWideDynamicRange(WDR).

•Electronicimagestabilization(EIS)cannotbeusedtogetherwithBarreldistortioncorrection.

ElectronicImageStabilization(EIS)

Whenmonitoringanenvironmentthatissubjecttovibrationssuchasatrainstation,orwhenthecameraismountedonapole,

imagesmayappearunsteady.Toautomaticallyimproveimagestability,selectElectronicimagestabilization(EIS)fromVideo&

Audio>CameraSettings.

BarrelDistortionCorrection

Barreldistortionisalenseffectthatcausesanimagetolookcurved.Theextentofdistortiondependsonthezoomlevel.

Toeditbarreldistortionsettings,clickEditfromVideo&Audio>CameraSettings>ImageCorrection.IntheBarrelDistortion

Correctionwindow,adjusttheslidertocorrectthedistortion,usingthegridforassistance.

WhiteBalance

Whitebalanceisusedtomakecolorsintheimageappearthesameregardlessofthecolortemperatureofthelightsource.TheAxis

productcanbesettoautomaticallyidentifythelightsourceandcompensateforitscolor.Alternatively,selectthetypeoflight

sourcefromthedrop-downlist.Foradescriptionofeachavailablesetting,seetheonlinehelp

ThewhitebalancewindowisenabledfortheAutomaticandAutomaticoutdooroptionsthatappearintheWhitebalancedrop-down

list.Selectoneoftheoptionsfromthedrop-downlisttosetthewhitebalancewindowproperties.SelectAutomatictousethe

defaultsettingsfortheAutomaticandAutomaticoutdooroptions(intheWhitebalancedrop-downlist).SelectCustomtomanually

setareferencewindowforwhitebalanceintheviewarea.

WideDynamicRange

Widedynamicrange(WDR-DynamicCapture)providesbalancedimagesinsceneswhenthereisaconsiderablecontrastbetween

lightanddarkareasintheimage.Thecameraautomaticallyhandlesthetransitionbetweensuchscenesandlow-lightconditions.In

rarelightconditionsdisablingWDRmightgiveabetterimage.

AXISQ3505–VEFixedDomeNetworkCamera

VideoandAudio

Important

UseWDRincombinationwithautomaticexposurecontrol.Otherexposuresettingscouldgiveundesirableresults.

Note

WDRisonlyavailableifyouhaveselectedacapturemodethatsupportsWDR.SeeCongureCaptureModeonpage10.

ExposureSettings

Conguretheexposuresettingstosuittheimagequalityrequirementsinrelationtolighting,framerateandbandwidth

considerations.

Exposurevalue-Clickinthebartone-tunetheexposure.

Exposurecontrol-Thissettingisusedtoadapttotheamountoflightused.Automaticisthedefaultsettingandcanbeusedin

mostsituations.Theshutterspeedisautomaticallysettoproduceoptimumimagequality.Flicker-free50or60Hzisusedtoremove

ickerwhichcanbecausedbyuorescentandotherlightsources.TheHoldcurrentoptionlocksthecurrentexposuresettings.

EnableBacklightcompensation-Enablethisoptionifabrightspotoflight,forexamplealightbulb,causesotherareasin

theimagetoappeartoodark.

Exposurezones-Thissettingdetermineswhichpartoftheimageisusedtocalculatetheexposure.Formostsituations,theAuto

settingcanbeused.Forparticularrequirements,selectapredenedarea.

Exposurepriority-WhenMotionisprioritizedandmaximumShuttertimeissettoasmallvalue,motionblurintheimageis

minimized.Thiscanbeusefulforrecognitionofmovingobjectssuchaspeopleandvehicles.However,prioritizingmotionmaycause

anincreaseinimagenoise,especiallyinlowlightsituations.WhenLownoiseisprioritizedandGainissettoasmallvalue,image

noiseisminimized.Thelesizeisreduced,whichcanbeusefulifstoragespaceorbandwidthislimited.However,prioritizinglow

noisemayresultinaverydarkimage,especiallyinlowlightsituations.

Shutter&Gain

Theshutterandgainsettingsaffecttheamountofmotionblurandnoiseintheimage.Toadapttodifferentlighting,available

storagespaceandbandwidth,itisoftennecessarytoprioritizeeitherlowmotionblurorlownoise.TheAxisproductallows

usingdifferentprioritizationinnormallightandinlowlight.

Shutterspeedisrelatedtotheamountoftimetheshutterisopenedandismeasuredinseconds(s).Aslowshutterspeedallows

morelighttoreachthesensorandcanhelpproduceabrighterimageinlowlightsituations.Ontheotherhand,aslowshutter

speedcancausemovingobjectstoappearblurry.

SetShutterto

•Autotosettheshutterspeedautomatically.Ifrequired,useMaxshuttertolimittheshutterspeedtopreventtheframe

ratefrombeingreduced.Forexample,toget30fps,setMaxshutterto1/30.

•Fixedtouseaxedshutterspeed.

Gain,measuredindecibel(dB),istheamountofamplicationappliedtotheimage.Ahighgainmayprovideabetterimageinlow

lightsituationsbutwillincreasetheamountofimagenoise.

SetGainto

•Autotosetthegainautomatically.Ifrequired,useMaxgaintolimittheappliedgain.

•Fixedtouseaxedgain.

WhenShutterandGainarebothsettoAuto,itispossibletosetthePrioritybetweenlowmotionblurandlownoisemanuallyandto

useadifferentPriorityinNormalLightandinLowLight.

Example

Consideranareawherepeopleorvehiclesmoveduringtheday,butwherethereshouldbenomovementsduringnight.Tobeableto,

forexample,recognizefacesorlicenseplates,movethenormallightpriorityslidertowardlowmotionblur.Atnighttime,motion

AXISQ3505–VEFixedDomeNetworkCamera

VideoandAudio

detectionismoreimportantthanidentication.Motionblurisacceptableandsincelowlightcancausealotofnoise,move

thelowlightpriorityslidertowardlownoise.

Example

Ifstoragespaceorbandwidthislimited,tryusingalowergain.Thiswillreduceimagenoiseandproducesmallerimageles.

Irisadjustment

SelectEnableautomaticirisadjustmenttoautomaticallycompensateforchanginglightconditions.Thisoptionisnotavailable

ifaxedirisisused.

UsetheIrisadjustmentslidertosetthepreferredF-value.Thescalerepresentstheamounttheirisisopen.Ifsetto0,theirisis

openedasmuchaspossible.Ifsetto100,theirisisclosedasmuchaspossible.TheactualF-valueisshownbelowtheslider.If

automaticirisadjustmentisenabled,theiriswillstayatthispositionaslongaslightconditionsarefavorable.Iflightconditions

change,theiriswilladjustitselftothebestirissettings.Ifautomaticirisadjustmentisdisabled,theiriswilllockontheset

positionregardlessoflightconditions

Day/Night

TheIRcutlterpreventsinfrared(IR)lightfromreachingtheimagesensor.Inpoorlightingconditions,forexampleatnight,orwhen

usinganexternalIRlamp,settheIRcutltertoOff.Thisincreaseslightsensitivityandallowstheproductto“see”infraredlight.The

imageisshowninblackandwhitewhentheIRcutlterisoff.

IfusingautomaticExposurecontrol,settheIRcutltertoAutotoautomaticallyswitchbetweenOnandOffaccordingtothe

lightingconditions.

TheDay/Nightshiftlevelbarhelpsdeterminewhenthecamerawillshiftfromdaymodetonightmode.Normally,thecamera

automaticallychangesmodefromdaytonightwhenverydark(level100intheslider).BysettingDay/Nightshiftleveltoa

lowervalue,thecamerawillchangetonightmodeearlier.

ViewArea

Aviewareaisacroppedpartofthefullview.EachviewareaistreatedasavideosourceinLiveViewandhasitsownvideo

streamandPTZsettings.

Whensettingupaviewareaitisrecommendedthatthevideostreamresolutionisthesamesizeasorsmallerthantheviewarea

size.Settingthevideostreamresolutionlargerthantheviewareasizeimpliesdigitallyscaledupvideoaftersensorcapture,

requiringmorebandwidthwithoutaddingimageinformation.

Toenable,gotoVideo&Audio>CameraSettingsandselectEnableViewAreas.

Toaddanewviewarea:

1.GotoVideo&Audio>ViewArea.

2.ClickAdd.

3.ThenewviewareaappearsunderSelectedviewarea.EnteradescriptivenameintheNameeld.

4.SelectanAspectratioandaVideostreamresolution.

5.Anewviewareacoversthewholeimage.Usethemousetomoveandresizetheviewarea.

6.SelectEnablePTZtoenabledigitalPTZfortheviewarea.

7.ClickSavetosavethesettings.

Tomodifyaviewarea,selecttheviewareainthelistandmodifythesettingsasrequired.ClickSave.

Toremoveaviewarea,selecttheviewareaandclickRemove.

AXISQ3505–VEFixedDomeNetworkCamera

VideoandAudio

Note

ThePTZfunctionalityisusefulduringinstallationoftheAxisproduct.Useaviewareatocropoutaspecicpartofthe

fullview.

Note

ViewareaswillbedisabledifOpticalzoomformonitoringisselected.SeePTZModeonpage10.

Overlay

Overlaysareusedtoprovideextrainformation,forexampleforforensicvideoanalysisorduringproductinstallationand

conguration.Overlaysaresuperimposedoverthevideostream.

Anoverlaytextcandisplaythecurrentdateandtime,oratextstring.Whenusingatextstring,modierscanbeusedtodisplay

informationsuchasthecurrentbitrateorthecurrentframerate.Forinformationaboutavailablemodiers,seeFileNaming&

Date/TimeFormatsintheonlinehelp

Itisalsopossibletodisplaytextwhenanactionruleistriggered,seeUseOverlayTextinanActionRule.

Toenableoverlays:

1.GotoVideo&Audio>VideoStreamandselecttheImagetab.

2.Toincludeanoverlayimage,selectIncludeoverlayimageatthecoordinates.Theoverlayimagemustrstbeuploadedto

theAxisproduct,seeOverlayImage.

3.Toincludedateandtime,selectIncludedateandIncludetime.

4.Toincludeatextstring,selectIncludetextandenterthetextintheeld.Modierscanbeused,seeFileNaming&

Date/TimeFormatsintheonlinehelp

5.Denetextoverlaycharacteristicsintherelevantelds.

6.ClickSave.

Tomodifythedateandtimeformat,gotoSystemOptions>Date&Time.SeeDate&Timeonpage47.

OverlayImage

Anoverlayimageisastaticimagesuperimposedoverthevideostream.Theimage,forexampleacompanylogo,isusedtoprovide

extrainformationortomaskapartoftheimage.

Formoreinformationaboutprivacymasks,seePrivacyMaskonpage26.

Touseanoverlayimage,theimagemustrstbeuploadedtotheAxisproduct.TheuploadedimageshouldbeaWindows24-bitBMP

imagewithmaximum250colors.Theimagewidthandheight,inpixels,mustbeexactlydivisibleby4andcannotbelargerthanthe

maximumimageresolution.Ifcombiningtextandimageoverlays,takeintoconsiderationthatthetextoverlayoccupies16or32

pixelsinheight(dependingontheresolution)andhasthesamewidthasthevideoimage.

ToautomaticallyscaletheimagetotheresolutionusedbytheAxisproduct,selecttheoptionScalewithresolutionfromthe

TransparencySettingspagewhichisdisplayedwhenuploadingintheimage.

Touploadanoverlayimage:

1.GotoVideo&Audio>OverlayImage.

2.ClickBrowseandbrowsetothele.

3.ClickUpload.

4.TheTransparencySettingspageisnowdisplayed:

AXISQ3505–VEFixedDomeNetworkCamera

VideoandAudio

-Tomakeacolorintheoverlayimagetransparent,selectUsetransparencyandentertheRGBhexadecimalvalue

forthecolor.Example:Tomakewhitetransparent,enter#FFFFFF.

-Toscaletheimageautomatically,selectScalewithresolution.Theimagewillbescaleddowntotthe

resolutionusedbytheAxisproduct.

5.ClickSave.

Toselecttheimagetouseasoverlay:

1.GotoVideo&Audio>OverlayImage.

2.SelecttheimagetousefromtheUseoverlayimagelistandclickSave.

Todisplaytheoverlayimage:

1.GotoVideo&Audio>VideoStreamandselecttheImagetab.

2.UnderOverlaySettings,selectIncludeoverlayimageatthecoordinates.

3.Tocontroltheimage’sposition,entertheXandYcoordinates.TheX=0andY=0positionisthetopleftcorner.Ifapartof

theimageispositionedoutsidethevideoimage,theoverlayimagewillbemovedsothatthewholeimageisvisible.

4.ClickSave.

UseOverlayTextinanActionRule

Actionrules,seepage38,candisplayanoverlaytextwhentheruleistriggered.Thetextcanbeusedtoprovideinformationfor

forensicvideoanalysis,notifysurveillanceoperatorsorvalidatetriggersandactionsduringproductinstallationandconguration.

Todisplayoverlaytextwhenanactionruleistriggered,themodier#Dshouldbeusedasdescribedbelow.Whentheruleis

triggered,#Dwillbereplacedbythetextspeciedintheactionrule.

Startbyenablingoverlaytextinthevideostream:

1.GotoVideo&Audio>VideoStreamandselecttheImagetab.

2.UnderOverlaySettings,selectIncludetext.

3.Enterthemodier#Dand,optionally,additionaltextwhichwillbedisplayedalsowhentheactionruleisnotactive.

Createtheactionrule:

1.GotoEvents>ActionRules

2.ClickAddtocreateanewrule.

3.SelectaTriggerand,optionally,aScheduleandAdditionalconditions.Seetheonlinehelpfordetails.

4.FromtheActionslist,selectOverlayText

5.EnterthetexttodisplayintheTexteld.Thisisthetextthat#Dwillbereplacedby.

6.SpecifytheDuration.Thetextcanbedisplayedwhiletheruleisactiveorforaxednumberofseconds.

Example

Todisplaythetext“Motiondetected”whenmotionisdetected,enter#DintheIncludetexteldandenter“Motiondetected”in

theTexteldwhensettinguptheactionrule.

Note

Todisplaytextinmultipleviewareas,overlaytextmustbeenabledineachviewarea.

AXISQ3505–VEFixedDomeNetworkCamera

VideoandAudio

PrivacyMask

Aprivacymaskisauser-denedareathatpreventusersfromviewingpartsofthemonitoredarea.Privacymasksappearas

blocksofsolidcolororblurredimageelementsandareappliedonthevideostream.Privacymaskscannotbebypassedusingthe

VAPIX®applicationprogramminginterface(API).

ThePrivacyMaskList(Video&Audio>PrivacyMask)showsallthemasksthatarecurrentlyconguredintheAxisproductand

indicatesiftheyareenabled.

Youcanaddanewmask,re-sizethemaskwiththemouse,chooseacolorforthemask,andgivethemaskaname.

Formoreinformation,seetheonlinehelp

Important

Addingmanyprivacymasksmayaffecttheproduct’sperformance.

Focus&Zoom

Forinstallationinstructions,refertotheproduct’sInstallationGuide.

IfyouhaveselectedOpticalzoomforinstallation,followtheinstructionsbelowtosetfocusandzoom.SeePTZModeonpage10

formoreinformation.

Tosetfocusandzoom:

1.InstallthecameraasdescribedintheInstallationGuide.

2.GotoVideo&Audio>Focus&Zoom.

3.OntheBasictab,setthezoomlevelusingtheslider.Thebuttons<and>movethezoompositiononestepineither

direction.Thebuttons<<and>>movethezoompositioninmultiplestepsineitherdirection.

4.ClickPerformautofocustofocusthecameraautomatically.

5.Ifmoreadjustmentsareneeded,gototheAdvancedtab.

Note

•Movementsinfrontofthecamerashouldbeavoidedduringautomaticfocusing.

OntheAdvancedtab,focuscanbeadjustedmanually:

1.ClickOpeniristoopentheiristoitsmaximumposition.Thisgivesthesmallestdepthofeldandprovidesthebest

conditionsforfocusing.

2.FocusissetintheFocuswindow.Usethemousetomoveandresizethefocuswindow.

3.ClickintheFocuspositionbartofocusonadesiredlocation.Thebuttons<and>movethefocuspositiononestepin

eitherdirection.Thebuttons<<and>>movethefocuspositioninmultiplestepsineitherdirection.

4.Whensatised,clickEnableiristoenabletheiris.

SetZoomandFocus-OpticalZoomforMonitoring

TosetFocus&ZoomwhenyouhaveselectedOpticalzoomformonitoring:

GotoPTZ>PresetPositionsandfollowtheonlineinstructionstosetthefocus.Inordertobeabletoretainthisfocusposition

afterrestartingthecamera,enteranameforthispresetintheCurrentpositioneldandselecttheUsecurrentpositionasHome

option.IfyoucalibratetheopticswhileinthisOpticalzoomformonitoringmode,selectthispresetfromtheAvailablepositions

drop-downlistinthePresetPositionswebpage.ClickGotoandSave.

Formoreinformationonpresetpositions,seePresetPositionsonpage31.

AXISQ3505–VEFixedDomeNetworkCamera

VideoandAudio

Tosetlimitsforfocusandzoom:

GotoVideo&Audio>Focus&Zoom.

SelectaZoomtelelimitvaluetolimitthecamera’smaximumzoom.ThedigitalzoomlevelisindicatedwiththeletterD.To

checkthezoomtelelimit,clickGoto.

SettheFocusnearlimittopreventthecamerafromfocusingonobjectsthataretooclose.

Itispossibletosetfocusandzoomfromthispage,butthefocuswillbelostwhenthecameraisrestarted.

AudioSettings

TheaudiofunctionalityforeachvideostreamisenabledunderVideo&Audio>VideoStream>Audio.

AudioModes

TheAxisproductsupportsthefollowingaudiomodes:

Fullduplex-Simultaneoustwo-wayaudioallowingtheAxisproducttotransmitandreceiveaudioatthesametime.Thereisno

echocancellation;iffeedbackloopsappear,trymovingthemicrophoneorthespeaker.

Half-duplex-AudiocanbetransmittedtoandfromtheAxisproductbutonlyinonedirectionatatime.Totransmitaudiousingthe

LiveViewpage,usetheTalkandListenbuttons,seeAMCAudioControlsonpage12.

Simplex—NetworkCameraspeakeronly-AudioistransmittedfromaclienttotheAxisproductandcanbeplayedbyaspeaker

connectedtotheproduct.TotransmitaudiousingtheLiveViewpage,theTalkandMicrophonebuttonsmustbothbeactive,

seeAMCAudioControlsonpage12.

Simplex—NetworkCameramicrophoneonly-AudiocapturedbytheproductmicrophoneistransmittedfromtheAxisproductto

oneormoreclients.

Tosettheaudiomode,gotoVideo&Audio>AudioSettingsandselectthedesiredmodefromtheAudiomodedrop-downlist.

AudioInput

AnexternalmicrophoneoralinesourcecanbeconnectedtotheAudio-inconnector.ConguretheaudioinputsettingsunderVideo

&Audio>AudioSettings.

Note

IfusingLineinamonocontactmustbeused.Signalontipandgroundonsleeve.

ThefollowingaudiosourcesareavailableunderAudioInput:

•InternalMicrophone:Selectthisaudiosourcetousetheinternalmicrophone.

•ExternalMicrophone:Selectthisaudiosourcetousetheexternalmicrophone.

•Line:SelectthisaudiosourcetouseaLineindevice,thatis,anaudiomixerformultiplemicrophonesoramicrophone

withabuilt-inamplier.

Selectthe+30dBmicrophoneboostoptiontoamplifythesignaloftheexternalmicrophoneconnectedtotheAxisproduct.

ThisoptionisnotavailablewhentheLinesourceisselected.

TheMicrophonepoweroptionprovidesDCpowerforanexternalmicrophone.Microphonepowershouldonlybeusedwith

microphonesthatrequirethiskindofpowering,thatis,electretmicrophones.Thissettingshouldnotbeenabledwhenusingadynamic

orbatterypoweredmicrophone.Foruseofaprofessionalmicrophonerequiring12Vphantompower,thereisabuilt-inpowersupply.

Note

Touseaprofessionalmicrophonerequiring48Vphantompower,youneedanexternalpowersupplyandabalanced

converter(audiotransformer)inbetween.Theinputmustneverexceed12VDC.

AXISQ3505–VEFixedDomeNetworkCamera

VideoandAudio

UsetheInputgaintocontrolthevolume(dBFullScale)oftheaudioinput.Ifthesoundistoolow,chooseahigherdB,toamplify

thesound.Ifthesoundistoohigh,choosealowerdB.TheLevelbargivesavisualrepresentationoftheaudiosignallevelindB

relativetothefull-scaleinputlevel.

•Green—thesignalisatagoodlevel.

•Yellow—thesignalisbecomingdistorted.

•Red—thesignalisdistorted.

UsetheEncodingoptiontoselectdigitalaudioencodingformat.

•AACrequiresalicenseforbothencodinganddecoding.AACistheleastcomplicatedandmostwidelyusedcodec.If

achievingthebestpossibleaudioqualityisapriority,AACistherecommendedcodectouse.AnAAClicenseisincluded

intheAxisproduct.

•G711isanunlicensedstandardcodecthatisusefulwhenintegratingaudiointoaVoIPsystem

•G726isanunlicensedspeechcodecthatismostcommonlyusedwithinthesecurityindustry.

Note

Ifrecordingaudiotoedgestorage,suchasanSDcardornetworkshare,useAACencoding.

TheSampleratedenesthenumberoftimespersecondthesoundissampled.Ahighersampleratewillprovidebetteraudio

quality,butalsorequiresagreaterbandwidth.

SettherequiredBitratedependingontheselectedencoding.Ahigherbitratewillgivebetteraudioquality.Alowerbitrate

mayhavelatencyordelay,butwillrequirelessbandwidth.

Formoreinformationaboutthesesettings,pleaseseetheonlinehelp

AudioOutput

AnexternalspeakercanbeconnectedtotheAudio-outconnector(abuilt-inamplierisrequiredforthis).Theoutputcanbe

connectedtoanotheramplierwithspeakers.Astereoconnectormustbeusedfortheaudioout.

ConguretheaudiooutputsettingsunderVideo&Audio>AudioSettings.

Outputgain-Controlthevolume(dBFullScale)ofthelineaudiooutput.Ifthesoundistoolow,chooseahigherdB.Ifthe

soundistoohigh,choosealowerdB.

AudioClips

AnaudioclipisasoundlethatcanbeplayedwheneventsoccurordirectlyfromtheLiveViewpage.Theaudioclipmustrstbe

uploadedtotheAxisproductorrecordedbyamicrophoneconnectedtotheproduct.

Toadd,download,modifyorremoveaudioclips,gotoVideo&Audio>AudioClips.Formoreinformationseetheonlinehelp

ToconguretheAxisproducttoplayaudioclipswhenaneventoccurs,anactionrulemustbesetup.Formoreinformation,

seeEventsonpage38.

Note

Audioclipscannotbeusediftheproduct’saudiofunctionalityisenabled.TheaudiofunctionalityisenabledontheAudio

tabunderVideo&Audio>VideoStream.

AXISQ3505–VEFixedDomeNetworkCamera

ConﬁguretheLiveViewPage

YoucancustomizetheLiveViewpageandalterittosuityourrequirements.Itispossibletodenethefollowingfeaturesof

theLiveViewpage.

•StreamProle.Seepage20.

•DefaultViewerforBrowser.Seepage29.

•ViewerSettings.Seepage29.

•ActionButtons.ThesearethebuttonsdescribedinControlsontheLiveViewPageonpage1 1.

•UserDenedLinks.Seepage30.

•OutputButtons.Seepage30.

DefaultViewerforBrowsers

FromLiveViewCong>DefaultViewerselectthedefaultmethodforviewingvideoimagesinyourbrowser.Theproductattempts

toshowthevideoimagesintheselectedvideoformatandviewer.Ifthisisnotpossible,theproductoverridesthesettingsand

selectsthebestavailablecombination.

BrowserViewerDescription

AMC

RecommendedviewerinInternetExplorer(H.264/MotionJPEG).

QuickTime

H.264.

Javaapplet

AslowerimagingalternativetoAMC(MotionJPEG).Requiresoneofthe

followinginstalledontheclient:

•JVM(J2SE)1.4.2orhigher.

•JRE(J2SE)5.0orhigher.

WindowsInternetExplorer

StillimageDisplaysstillimagesonly.ClicktheRefreshbuttoninyourbrowsertoviewa

newimage.

ServerPush

Recommendedviewerforotherbrowsers(MotionJPEG).

QuickTime

H.264.

Javaapplet

AslowerimagingalternativetoServerPush(MotionJPEGonly).

Otherbrowsers

StillimageDisplaysstillimagesonly.ClicktheRefreshbuttoninyourbrowsertoviewa

newimage.

Formoreinformation,pleaseseetheonlinehelp.

ViewerSettings

Tocongureoptionsfortheviewer,gotoLiveViewCong>ViewerSettings.

•SelectShowviewertoolbartodisplaytheAXISMediaControl(AMC)ortheQuickTimeviewertoolbarunderthevideo

imageinyourbrowser.

•H.264decoderinstallation.TheadministratorcandisableinstallationoftheH.264decoderincludedwithAXISMedia

Control.Thisisusedtopreventinstallationofunlicensedcopies.Furtherdecoderlicensescanbepurchasedfromyour

Axisreseller.

•SelectShowcrosshairinPTZjoystickmodetoenableacrossthatwillindicatethecenteroftheimageinPTZjoystick

mode.

AXISQ3505–VEFixedDomeNetworkCamera

ConﬁguretheLiveViewPage

•SelectUsePTZjoystickmodeasdefaulttoenablejoystickmode.Themodecanbechangedtemporarilyfromthe

PTZcontrolpanel.

•SelectEnablerecordingbuttontoenablerecordingfromtheLiveViewpage.Thisbuttonisavailablewhenusingthe

AMCviewer.TherecordingsaresavedtothelocationspeciedintheAMCControlPanel.SeeAXISMediaControl

(AMC)onpage14.

UserDenedLinks

Todisplayuser-denedlinksintheLiveViewpage,selecttheShowcustomlinkoption,givethelinkanameandthenentertheURL

tolinkto.Whendeningaweblinkdonotremovethe'http://'fromtheURLaddress.Customlinkscanbeusedtorunscriptsor

activateexternaldevicesconnectedtotheproduct,ortheycanlinktoawebpage.Customlinksdenedascgilinkswillrunthe

scriptinthebackground,inahiddenframe.Deningthelinkasaweblinkwillopenthelinkinanewwindow.

OutputButtons

ExternalI/OdevicesconnectedtotheAxisproduct’soutputportscanbecontrolleddirectlyfromtheLiveViewpage.

TodisplayoutputbuttonsintheLiveViewpage:

1.GotoSetup>LiveViewCong.

2.UnderOutputButtons,selectthetypeofcontroltouse:

-Pulseactivatestheoutputforadenedperiodoftime.Thepulsetimecanbesetfrom1/100secondto60

seconds.

-Active/Inactivedisplaystwobuttons,oneoreachaction.

Toconguretheactiveandinactivestates,gotoSystemOptions>Ports&Devices>I/OPortsandsettheport’sNormalstate.

FormoreinformationaboutI/Oports,seeI/OPortsonpage54.

AXISQ3505–VEFixedDomeNetworkCamera

PTZ(PanTiltZoom)

ThePTZmenuisavailableifdigitalPTZ(pan,tiltandzoom)isenabledintheselectedviewarea.Formoreinformationonviewareas,

seeViewAreaonpage23.

ThisoptionisonlyavailableifyouhaveselectedOpticalzoomforinstallation.SeePTZModeonpage10.

IfOpticalzoomformonitoringhasbeenselectedduringinstallationviewareaswillbedisabled.FormoreinformationseePTZ

Modeonpage10.

PresetPositions

Apresetpositionisasavedviewthatcanbeusedtoquicklysteerthecameratoaspecicposition.Apresetpositionconsistsof

thefollowingvalues:

•Panandtiltpositions

•Zoomposition

•Focusposition

Eachviewareahasitsownpresetpositions.

Presetpositionscanbeaccessedinseveralways:

•ByselectingthepresetfromtheSourcedrop-downlistintheLiveViewPage.

•Whensettingupactionrules.Seepage38.

•Whensettingupguardtours.Seepage32.

•WhensettinguptheGatekeeper.Seepage31

Toaddapresetposition:

1.GotoPTZ>PresetPositions.

2.Clickintheimageorusethecontrolstosteerthecameraviewtothedesiredposition.

3.EnteradescriptivenameintheCurrentpositioneld.

4.ClickAddtosavethepresetposition.

TheentireviewareaistreatedastheHomepositionwhichisreadilyaccessiblebyclickingtheHomebuttonontheLiveView

pageandinthePresetPositionssetupwindow.

TheproductcanbeconguredtoreturntotheHomepositionwhenthePTZfunctionalityhasbeeninactiveforaspeciedlengthof

time.EnterthelengthoftimeintheReturntohomeaftereldandclickSave.Setthetimetozerotopreventtheproductfrom

automaticallyreturningtotheHomeposition.

Toincludethepresetpositionnameintheoverlaytext,gotoVideo&Audio,selectIncludeoverlaytextandenterthemodier#Pin

theeld.Formoreinformationaboutmodiers,seeFileNaming&Date/TimeFormatsintheonlinehelp

Gatekeeper

TheGatekeepermonitorsanareasuchasanentrancegate.Whenmotionisdetectedinthemonitoredarea,theGatekeeperwillsteer

thecameratoaselectedpresetposition.Usingazoomed-inpresetpositioncanmakeitpossibleto,forexample,readalicenseplate

oridentifyaperson.Whenmotionisnolongerdetected,thecamerareturnstoitsHomepositionafteradenedtime.

ToenabletheGatekeeper,gotoPTZ>Gatekeeperandfollowtheonlineinstructions.

AXISQ3505–VEFixedDomeNetworkCamera

PTZ(PanTiltZoom)

Itisalsopossibleto,forexample,recordvideoorsaveimages(takeasnapshot)whiletheGatekeeperisactive.GotoEvents

andsetupanactionrulewithPTZPresetReachedastrigger.

Note

Thisisfeatureisnotavailableifyouhaveselectedopticalzoomforinstallation(seePTZModeonpage10).

GuardTour

Aguardtourdisplaysthevideostreamfromdifferentpresetpositions,one-by-one,inapredeterminedorderoratrandomandfor

congurabletimeperiods.Theenabledguardtourwillkeeprunningaftertheuserhasloggedofforclosedthebrowser.

Toaddaguardtour:

1.GotoPTZ>GuardTourandclickAdd.

2.Enteradescriptivename.

3.Specifythepauselengthbetweenruns.

4.SelectanavailablepresetpositionandclickApply.

5.SpecifytheViewTimeinsecondsorminutes.

6.SpecifytheViewOrderorselecttheRandomvieworderoption.

7.ClickSave.

Tomodifyorremoveguardtours,gotoPTZ>GuardTour,selecttheguardtourintheGuardTourListandclickModify/Remove.

Formoreinformationseetheonlinehelp

Advanced

Controls

AdvancedPTZsettingscanbeconguredunderPTZ>Advanced>Controls.

ThePanelShortcutCommandButtonslistshowstheuser-denedbuttonsthatcanbeaccessedfromtheLiveViewpage’sCtrl

panel.ThesebuttonscanbeusedtoprovidedirectaccesstocommandsissuedusingtheVAPIX®applicationprogramminginterface.

ClickAddtoaddanewshortcutcommandbutton.

ThefollowingPTZcontrolsareenabledbydefault:

•Pancontrol

•Tiltcontrol

•Zoomcontrol

•Focuscontrol

Todisablespeciccontrols,deselecttheoptionsunderEnable/Disablecontrols.

Ifusingmultipleviewareas,deselectingacontrolwillonlydisablethecontrolintheselectedviewarea.

AXISQ3505–VEFixedDomeNetworkCamera

Detectors

CameraTampering

CameraTamperingcangenerateanalarmwheneverthecameraisrepositioned,orwhenthelensiscovered,sprayedorseverely

defocused.Tosendanalarm,forexampleanemail,anactionrulemustbesetup.

Toconguretampering:

1.GotoDetectors>CameraTampering.

2.SettheMinimumduration,thatis,thetimethatmustelapsebeforeanalarmisgenerated.Increasetimetoprevent

falsealarmsforknownconditionsthataffecttheimage.

3.SelectAlarmfordarkimagesifanalarmshouldbegeneratediflightsaredimmedorturnedoff,orifthelensissprayed,

covered,orrenderedseverelyoutoffocus.

4.ClickSave.

Toconguretheproducttosendanalarmwhentamperingoccurs:

1.GotoEvents>ActionRules.

2.ClickAddtosetupanewactionrule.

3.EnteraNamefortheactionrule.

4.UnderCondition,selectDetectorsfromtheTriggerlist.

5.SelectTamperingfromthelistofdetectors.

6.Optionally,selectascheduleandsetadditionalconditions.

7.Selecttheaction.Tosendanemail,selectSendNoticationandselectaRecipientfromthelistofdenedrecipients.

Note

TheWhiletheruleisactiveoptionunderDurationcannotbeusedwithcameratampering,sincecameratamperingdoesnot

haveadurationandonceithasbeentriggereditwillnotautomaticallyreturntoitsuntriggeredstate.

Formoreinformationonactionsrules,seeEventsonpage38.

ShockDetection

EnableShockDetectionfromtheDetectorsmenu.Shockdetectionisused,forexample,togenerateanalarmiftheproductishit

byanobject.

UsetheShocksensitivityslidertoadjustthesensitivitylevelatwhichtheproductshouldsendanalarmuponbeinghit.Low

sensitivityvalueimpliesthattheproductwillgenerateanalarmonlyifthehitispowerful.

MotionDetection

Motiondetectionisusedtogenerateanalarmwhenevermovementstartsorstopsinthecameraview.

Motiondetectionisconguredbydeningupto10IncludeandExcludewindows:

•Includewindows—deneareaswheremotionshouldbedetected

•Excludewindows—deneareaswithinanIncludewindowthatshouldbeignored(areasoutsideIncludewindows

areautomaticallyignored).

AXISQ3505–VEFixedDomeNetworkCamera

Detectors

Forinstructions,seeSetUpMotionDetectionWindowsonpage34.

Tocontrolthenumberofmotiondetectionalarms,theparametersObjectSize,HistoryandSensitivitycanbeadjusted.See

MotionDetectionParametersonpage34.

Oncemotiondetectionwindowsarecongured,theAxisproductcanbeconguredtoperformactionswhenmotionisdetected.

Possibleactionsincludeuploadingimagesandstartrecording.Formoreinformation,seeSetUpActionRulesonpage38.

Note

•Usingthemotiondetectionfeaturemaydecreasetheproduct’soverallperformance.

•ThepositionoftheMotionDetectionWindowisrelativetotheorientationoftheCamera.Changingtheorientationofthe

camerawillalsochangethepositionoftheMotionDetectionWindow.

SetUpMotionDetectionWindows

TosetupamotiondetectionIncludeWindow,followtheseinstructions:

1.GotoDetectors>MotionDetection.

2.SelectadesiredresolutionforviewingwhilesettingupMotionDetectionfromtheViewinlist.

3.SelecttheCongureIncludedWindowsoptionandclickNew.Selectthenewwindowinthelistofwindowsand

enteradescriptivename.

4.Adjustthesize(dragthebottomright-handcorner)andtheposition(clickonthetextatthetopanddragtothedesired

position)ofthewindow.

5.AdjusttheObjectSize,HistoryandSensitivityprolesliders(seeMotionDetectionParametersfordetails).Anydetected

motionwithinanactivewindowisindicatedbyredpeaksintheActivitywindow.

6.ClickSave.

Toexcludepartsoftheincludewindow,selecttheCongureExcludedWindowsandpositiontheexcludewindowwithinthe

includewindow.

Todeleteanincludeorexcludewindow,selectthewindowinthelistofwindowsandclickDel.

MotionDetectionParameters

Theparameterscontrollingmotiondetectionaredescribedinthetablebelow:

Parameter

ObjectSize

History

Sensitivity

Description

Objectsizerelativetowindow

size.

Objectmemorylength.

Differenceinluminance

betweenbackgroundand

object.

Highlevel(100%)

Onlyverylargeobjectstrigger

motiondetection.

Anobjectthatappearsin

thewindowtriggersmotion

detectionforalongtime

beforeitisconsideredas

non-moving.

Ordinarycoloredobjectson

ordinarybackgroundstrigger

motiondetection.

Mediumlevel(50%)

Alargedifferenceinluminance

isrequiredtotriggermotion

detection.

Lowlevel(0%)

Evenverysmallobjectstrigger

motiondetection.

Anobjectthatappearsin

thewindowtriggersmotion

detectiononlyforaveryshort

timebeforeitisconsideredas

non-moving.

Onlyverybrightobjectson

adarkbackgroundtrigger

motiondetection.

AXISQ3505–VEFixedDomeNetworkCamera

Detectors

Recommendedvalues

5–15%60–90%75–95%

Defaultvalues

15%90%90%

Note

•Totriggeronsmallobjectsormovements,useseveralsmallmotiondetectionwindowsratherthanonelargewindow

andselectalowobjectsize.

•Toavoidtriggeringonsmallobjects,selectahighobjectsize.

•Whilemonitoringanareawheremovingobjectsarenotexpected,selectahighhistorylevel.Thiswillcausemotion

detectiontotriggeraslongastheobjectispresentinthewindow.

•Toonlydetectashinglight,selectalowsensitivity.Inothercaseshighsensitivityisrecommended.

AudioDetection

TheAxisproductcanbeconguredtogenerateanalarmwhenaudiorisesaboveorfallsbelowthethresholdvalue.Thethreshold

valuecanbesetintherange0–100where0isthemostsensitiveand100theleastsensitive.

1.GotoDetectors>AudioDetection.

2.SettheaudioalarmlevelandclickSave.

3.GotoEvents>ActionRulesandsetupanactionrule,seeSetUpActionRulesonpage38.

DetectedaudioisindicatedbycoloredpeaksintheActivityindicator.Aneventistriggeredwhendetectedaudiorisesaboveorfalls

belowthethresholdvalue,whichisrepresentedbythebar.

AXISQ3505–VEFixedDomeNetworkCamera

Applications

ThirdpartyapplicationscanbeuploadedtoandinstalledontheAxisproduct.Applicationsaddfunctionalitytotheproduct,for

examplevideoanalyticsandintelligentvideocapabilitiessuchasrecognition,tracking,detectionandcounting.Forinformation

aboutavailableapplications,downloads,trialsandlicenses,gotowww.axis.com/applications

Note

•Itisrecommendedtorunoneapplicationatatime.

•Avoidrunningapplicationswhenthebuilt-inmotiondetectionisactive.

ApplicationLicenses

Someapplicationsneedalicensetorun.Licensescanbeinstalledintwoways:

•Automaticinstallation—requiresaccesstotheInternet

•Manualinstallation—obtainthelicensekeyfromtheapplicationvendoranduploadthekeytotheAxisproduct

Torequestalicense,theAxisproductserialnumber(S/N)isrequired.Theserialnumbercanbefoundontheproductlabelandunder

SystemOptions>Support>SystemOverview.

InstallApplication

Toinstallandstartanapplication:

1.GotoSetup>Applications.

2.UnderUploadApplication,clickBrowse.LocatetheapplicationleandclickUploadPackage.

3.Installthelicense(ifapplicable).Forinstructions,seethedocumentationprovidedbytheapplicationvendor.

4.Starttheapplication.GotopageApplications,selecttheapplicationinthelistofinstalledapplicationsandclickStart.

5.Conguretheapplication.Forinstructions,seethedocumentationprovidedbytheapplicationvendor.

Note

•Applicationscanbeuploadedbyproductadministrators.

•ApplicationsandlicensescanbeinstalledonmultipleproductsatthesametimeusingAXISCameraManagement,version

3.10andlater.

Togeneratealoglefortheapplication,gotoApplications.SelecttheapplicationandclickLog.

ApplicationConsiderations

Ifanapplicationisupgraded,applicationsettings,includingthelicense,willberemoved.Thelicensemustbereinstalledand

theapplicationrecongured.

IftheAxisproduct’srmwareisupgraded,installedapplicationsandtheirsettingswillremainunchanged,althoughthisisnot

guaranteedbyAxisCommunicationsAB.Notethattheapplicationmustbesupportedbythenewrmware.Forinformationabout

rmwareupgrades,seeUpgradetheFirmware.

IftheAxisproductisrestarted,runningapplicationswillrestartautomatically.

IftheAxisproductisrestored,installedapplicationsremainunchangedbutmustberestarted.Tostarttheapplication,goto

Setup>Applications.SelecttheapplicationinthelistofinstalledapplicationsandclickStart.Forinformationaboutrestoring

theAxisproduct,seeMaintenance.

AXISQ3505–VEFixedDomeNetworkCamera

Applications

IftheAxisproductisresettofactorydefault,installedapplicationsandtheirsettingsareremoved.Forinformationaboutfactory

default,seeResettoFactoryDefaultSettings.

AXISQ3505–VEFixedDomeNetworkCamera

Events

TheEventpagesallowyoutoconguretheAxisproducttoperformactionswhendifferenteventsoccur.Forexample,theproduct

canstartarecordingorsendanemailnoticationwhenmotionisdetected.Thesetofconditionsthatdeneshowandwhen

theactionistriggerediscalledanactionrule.

SetUpActionRules

Anactionruledenestheconditionsthatmustbemetfortheproducttoperformanaction,forexamplerecordvideoorsendan

emailnotication.Ifmultipleconditionsaredened,allofthemmustbemettotriggertheaction.

Formoreinformationaboutavailabletriggersandactions,seeTriggersonpage38andActionsonpage40.

Thefollowingexampledescribeshowtosetupanactionruletorecordvideotoanetworkshareifthereismovementinthe

camera’seldofview.

Setupmotiondetectionandaddanetworkshare:

1.GotoDetectors>MotionDetectionandcongureamotiondetectionwindow.Seepage34

2.GotoSystemOptions>Storageandsetupthenetworkshare.Seepage54.

Setuptheactionrule:

1.GotoEvents>ActionRulesandclickAdd.

2.SelectEnableruleandenteradescriptivenamefortherule.

3.SelectDetectorsfromtheTriggerdrop-downlist.

4.SelectMotionDetectionfromthedrop-downlist.Selectthemotiondetectionwindowtouse.

5.Optionally,selectaScheduleandAdditionalconditions.Seebelow.

6.UnderActions,selectRecordVideofromtheTypedrop-downlist.

7.SelectaStreamproleandconguretheDurationsettingsasdescribedbelow.

8.SelectNetworkSharefromtheStoragedrop-downlist.

Tousemorethanonetriggerfortheactionrule,selectAdditionalconditionsandclickAddtoaddadditionaltriggers.Whenusing

additionalconditions,allconditionsmustbemettotriggertheaction.

Topreventanactionfrombeingtriggeredrepeatedly,aWaitatleasttimecanbeset.Enterthetimeinhours,minutesandseconds,

duringwhichthetriggershouldbeignoredbeforetheactionrulecanbeactivatedagain.

TherecordingDurationofsomeactionscanbesettoincludetimeimmediatelybeforeandaftertheevent.SelectPre-triggertime

and/orPost-triggertimeandenterthenumberofseconds.WhenWhiletheruleisactiveisenabledandtheactionistriggered

againduringthepost-triggertime,therecordingtimewillbeextendedwithanotherpost-triggertimeperiod.

Formoreinformation,seetheonlinehelp

Triggers

Availableactionruletriggersandconditionsinclude:

•Applications–Useinstalledapplicationstotriggertherule.SeeApplicationsonpage36.

•Detectors

-AudioDetection–Triggertherulewhenaudioisdetected.SeeAudioDetectiononpage35.

AXISQ3505–VEFixedDomeNetworkCamera

Events

-Day/NightMode–Triggertherulewhentheproductswitchesbetweendaymode(IRcutlteron)andnight

mode(IRcutlteroff).Thiscanforexamplebeusedtocontrolanexternalinfrared(IR)lightconnected

toanoutputport.

-LiveStreamAccessed–Triggertherulewhenanystreamisaccessedandduringedgestorageplayback.

Thiscanforexamplebeusedtosendnotications.

-MotionDetection–Triggertherulewhenmotionisdetected.SeeMotionDetectiononpage33.

-ShockDetected–TriggertherulewhentheAxisproductdetectsithasbeentiltedorhit.SeeShockDetection

onpage33.

-Tampering–Triggertherulewhentamperingisdetected.SeeCameraTamperingonpage33.

•Hardware

-Network–Triggertheruleifnetworkconnectionislostorrestored.Thiscanforexamplebeusedtostart

recordingtotheSDcard.

-Temperature–Triggertheruleifthetemperaturefallsoutsideorinsidetheoperatingrangeoftheproduct.This

canforexamplebeusedtosendmaintenancenotications.

•InputSignal

-DigitalInputPort–TriggertherulewhenanI/Oportreceivesasignalfromaconnecteddevice.SeeI/O

Portsonpage54.

-ManualTrigger–TriggertheruleusingtheManualTriggerbuttonintheLiveViewpage.SeeControlson

theLiveViewPageonpage1 1.Thiscanforexamplebeusedtovalidateactionsduringproductinstallation

andconguration.

-VirtualInputs–canbeusedbyaVMS(VideoManagementSystem)totriggeractions.Virtualinputscan,for

example,beconnectedtobuttonsintheVMSuserinterface.

•PTZ

-Moving–TriggertherulewhenthecameraviewmovesduetoaPTZoperation.Thiscanforexamplebeused

asanadditionalconditiontopreventanactionruletriggeredbymotiondetectiontorecordvideowhilethe

cameraviewmovesduetoaPTZoperation.

-PresetReached–Triggertherulewhenthecamerastopsatapresetposition.Thiscanbeforexamplebeused

withtheSendImagesactiontouploadimagesfromthepresetposition.

•Storage

-Disruption–Triggertheruleifstorageproblemsaredetected,forexampleifthestoragedeviceisunavailable,

removed,full,lockedorifotherreadorwriteproblemsoccur.Thiscanforexamplebeusedtosendmaintenance

notications.

-Recording–TriggerstherulewhentheAxisproductrecordstothestoragedevice.Therecordingstatustrigger

canbeusedtonotifytheoperator,forexamplebyashingLEDlights,iftheproducthasstartedorstoppedto

recordtothestoragedevice.Notethat,thistriggercanbeusedonlyforedgestoragerecordingstatus.

•System

-SystemReady–Triggertherulewhentheproducthasbeenstartedandallservicesarerunning.Thiscanfor

examplebeusedtosendanoticationwhentheproductrestarts.

•Time

-Recurrence–Triggertheruleperiodically.SeeSetUpRecurrencesonpage41.Thiscanforexamplebeusedto

uploadanimageevery5minutes.

-UseSchedule–Triggertheruleaccordingtotheselectedschedule.SeeCreateSchedulesonpage41.

AXISQ3505–VEFixedDomeNetworkCamera

Events

Actions

Availableactionsinclude:

•Day/NightVisionMode–Setdaymode(IRcutlteron)ornightmode(IRcutlteroff).

•OutputPort–ActivateanI/Oporttocontrolanexternaldevice.

•OverlayText–Displayanoverlaytext.SeeUseOverlayTextinanActionRuleonpage25.

•PlayAudioClip–SeeAudioClipsonpage28.

•PTZControl

-PresetPosition–Gotoapresetposition.

-GuardTour–Startaguardtour.SeeGuardTouronpage32.

•RecordVideo–Recordvideoandaudiotoaselectedstorage.Torecordaudio,useAACaudioencodingandmakesurethat

audioisenabledintheselectedstreamprole.

•SendImages–Sendimagestoarecipient.

•SendNotications–Sendanoticationmessagetoarecipient.

•SendSNMPTrap–SendanSNMPtrapmessagetotheoperator.MakesurethatSNMPisenabledandcongured

underSystemOptions>Network>SNMP.

•SendVideoClip–Sendavideocliptoarecipient.

•StatusLED–FlashtheLEDindicator.Thiscanforexamplebeusedtovalidatetriggerssuchasmotiondetectionduring

productinstallationandconguration.

•WDRMode–TheWDRModecanbeturnedonoroffwhentheactionruleistriggered.

AddRecipients

Theproductcansendmedialesandmessagestonotifyusersaboutevents.Beforetheproductcansendmedialesornotication

messages,youmustdeneoneoremorerecipients.

Toaddarecipient:

1.GotoEvents>RecipientsandclickAdd.

2.Enteradescriptivename.

3.SelectarecipientType.

4.Entertheinformationneededfortherecipienttype.

5.ClickTesttotesttheconnectiontotherecipient.

6.ClickOK.

SetUpEmailRecipients

Emailrecipientscanbeconguredbyselectingoneofthelistedemailproviders,orbyspecifyingtheSMTPserver,portand

authenticationusedby,forexample,acorporateemailserver.

Note

Someemailprovidershavesecurityltersthatpreventusersfromreceivingorviewinglargeamountofattachments,from

receivingscheduledemailsandsimilar.Checktheemailprovider’ssecuritypolicytoavoiddeliveryproblemsandlocked

emailaccounts.

AXISQ3505–VEFixedDomeNetworkCamera

Events

Tosetupanemailrecipientusingoneofthelistedproviders:

1.GotoEvents>RecipientsandclickAdd.

2.EnteraNameandselectEmailfromtheTypelist.

3.EntertheemailaddressestosendemailstointheToeld.Usecommastoseparatemultipleaddresses.

4.SelecttheemailproviderfromtheProviderlist.

5.EntertheuserIDandpasswordfortheemailaccount.

6.ClickTesttosendatestemail.

Tosetupanemailrecipientusingforexampleacorporateemailserver,followtheinstructionsabovebutselectUserdenedas

Provider.EntertheemailaddresstoappearassenderintheFromeld.SelectAdvancedsettingsandspecifytheSMTPserver

address,portandauthenticationmethod.Optionally,selectUseencryptiontosendemailsoveranencryptedconnection.Theserver

certicatecanbevalidatedusingthecerticatesavailableintheAxisproduct.Forinformationonhowtouploadcerticates,

seeCerticatesonpage46.

CreateSchedules

Schedulescanbeusedasactionruletriggersorasadditionalconditions,forexampletorecordvideoifmotionisdetectedoutside

ofcehours.Useoneofthepredenedschedulesorcreateanewscheduleasdescribedbelow.

Tocreateanewschedule:

1.GotoEvents>SchedulesandclickAdd.

2.Enteradescriptivenameandtheinformationneededforadaily,weekly,monthlyoryearlyschedule.

3.ClickOK.

Tousethescheduleinanactionrule,selecttheschedulefromtheScheduledrop-downlistintheActionRuleSetuppage.

SetUpRecurrences

Recurrencesareusedtotriggeractionrulesrepeatedly,forexampleevery5minutesoreveryhour.

Tosetuparecurrence:

1.GotoEvents>RecurrencesandclickAdd.

2.Enteradescriptivenameandrecurrencepattern.

3.ClickOK.

Tousetherecurrenceinanactionrule,rstselectTimefromtheTriggerdrop-downlistintheActionRuleSetuppageandthen

selecttherecurrencefromtheseconddrop-downlist.

Tomodifyorremoverecurrences,selecttherecurrenceintheRecurrencesListandclickModifyorRemove.

AXISQ3505–VEFixedDomeNetworkCamera

Recordings

TheAxisproductcanbeconguredtorecordvideocontinuouslyoraccordingtoanactionrule:

•Tostartacontinuousrecording,seepage42.

•Tosetupactionrules,seepage38.

•Toaccessrecordings,seeRecordingListonpage42.

•Tocongurecameracontrolledstorage,seeStorageonpage53.

RecordingList

RecordedvideosarelistedontheRecordings>Listpage.Thelistshowseachrecording’sstartdateandtime,durationandthe

eventthattriggeredtherecording.

Toplayordownloadarecording,followthesesteps:

1.GotoRecordings>List.

2.Usetheltertonarrowthelistofrecordings.EnterthedesiredltercriteriaandclickFilter.Someltersmaytake

alongtimetocomplete.

3.Selecttherecording.

4.ClickPlaytoplaytherecording,orclickDownloadtodownloadtherecording.

Multiplerecordingscanbedownloadedatthesametime.SelecttherecordingsandclickDownload.Thedownloadedleisaziple

containingaminimumofthreeles,ofwhichtheMatroska(mkv)lesaretheactualrecordings.Therecordingsaretime-stamped

withthedateandtimetheyweredownloaded(thatis,notthedatetherecordingsweremade).

Note

ToplayrecordingsinWindowsMediaPlayer,AXISMatroskaFileSplittermustbeinstalled.AXISMatroskaFileSplitter

canbedownloadedfromwww.axis.com/techsup/software

Fordetailedrecordingandvideoinformation,selectarecordingandclickProperties.

Toremovearecording,selecttherecordingandclickRemove.

ContinuousRecording

TheAxisproductcanbeconguredtocontinuouslysavevideotoastoragedevice.Forinformationaboutstoragedevices,seeStorage

onpage53.Topreventthediskfrombecomingfull,itisrecommendedtocongurethedisktoautomaticallyremoveoldrecordings.

Ifanewstreamproleisselectedwhilearecordingisongoing,therecordingwillbestoppedandsavedintherecordinglistanda

newrecordingwiththenewstreamprolewillstart.Allpreviouscontinuousrecordingswillremainintherecordinglistuntilthey

areremovedmanuallyorthroughautomaticremovalofoldrecordings.

Tostartacontinuousrecording,followthesesteps:

1.GotoRecordings>Continuous.

2.SelectEnabled.

3.SelectthetypeofstoragedevicefromtheStoragelist.

4.SelectaStreamproletouseforcontinuousrecordings.Toincludeaudiointherecording,useAACaudioencodingand

makesurethataudioisenabledintheselectedstreamprole.

AXISQ3505–VEFixedDomeNetworkCamera

Recordings

5.ClickSavetosaveandstarttherecording.

AXISQ3505–VEFixedDomeNetworkCamera

Languages

MultiplelanguagescanbeinstalledintheAxisproduct.Allwebpagesincludingtheonlinehelpwillbedisplayedintheselected

language.Toswitchlanguages,gotoSetup>Languagesandrstuploadthenewlanguagele.Browseandlocatetheleandclick

theUploadLanguagebutton.SelectthenewlanguagefromthelistandclickSave.

Note

•Resettingtheproducttofactorydefaultsettingswilleraseanyuploadedlanguagelesandresettheproductlanguageto

English.

•ClickingtheRestorebuttonontheMaintenancepagewillnotaffectthelanguage.

•Armwareupgradewillnotaffectthelanguageused.Howeverifyouhaveuploadedanewlanguagetotheproductand

laterupgradethermware,itmayhappenthatthetranslationnolongermatchestheproduct'swebpages.Inthiscase,

uploadanupdatedlanguagele.

•Alanguagealreadyinstalledintheproductwillbereplacedwhenacurrentoralaterversionofthelanguageleisuploaded.

AXISQ3505–VEFixedDomeNetworkCamera

SystemOptions

Security

Users

UseraccesscontrolisenabledbydefaultandcanbeconguredunderSystemOptions>Security>Users.Anadministratorcan

setupotherusersbygivingthemusernamesandpasswords.Itisalsopossibletoallowanonymousviewerlogin,whichmeans

thatanybodymayaccesstheLiveViewpage.

Theuserlistdisplaysauthorizedusersandusergroups(accesslevels):

Viewer-AccesstotheLiveViewpage

Operator-AccesstotheLiveViewpageandtoallsettingsexceptSystemOptions

Administrator-Unrestrictedaccesstoallsettings;canadd,modifyandremoveotherusers.

UnderHTTP/RTSPPasswordSettings,selectthetypeofpasswordtoallow.Youmayneedtoallowunencryptedpasswordsifthereare

viewingclientsthatdonotsupportencryption,orifyouupgradedthermwareandexistingclientssupportencryptionbutneed

tologinagainandbeconguredtousethisfunctionality.

UnderUserSettings,selecttheEnableanonymousviewerloginoptiontoallowanonymoususersaccesstotheLiveViewpage.

SelecttheEnableanonymousPTZcontrollogintoallowanonymoususersaccesstothePTZcontrols.

DeselecttheEnableBasicSetupoptiontohidetheBasicSetupmenu.BasicSetupprovidesquickaccesstosettingsthatshouldbe

madebeforeusingtheAxisproduct.

ONVIF

ONVIF(OpenNetworkVideoInterfaceForum)isaglobalinterfacestandardthatmakesiteasierforendusers,integrators,consultants,

andmanufacturerstotakeadvantageofthepossibilitiesofferedbynetworkvideotechnology.ONVIFenablesinteroperablitybetween

differentvendorproducts,increasedexibility,reducedcostandfuture-proofsystems.

BycreatingauseryouautomaticallyenableONVIFcommunication.UsetheusernameandpasswordwithallONVIFcommunication

withtheproduct.Formoreinformationseewww.onvif.org

IPAddressFilter

IPaddresslteringisenabledontheSystemOptions>Security>IPAddressFilterpage.Onceenabled,thelistedIPaddressare

allowedordeniedaccesstotheAxisproduct.SelectAlloworDenyfromthelistandclickApplytoenableIPaddressltering.

Theadministratorcanaddupto256IPaddressentriestothelist(asingleentrycancontainmultipleIPaddresses).

HTTPS

HTTPS(HyperTextTransferProtocoloverSecureSocketLayer,orHTTPoverSSL)isawebprotocolprovidingencryptedbrowsing.

HTTPScanalsobeusedbyusersandclientstoverifythatthecorrectdeviceisbeingaccessed.Thesecuritylevelprovidedby

HTTPSisconsideredadequateformostcommercialexchanges.

TheAxisproductcanbeconguredtorequireHTTPSwhenusersfromdifferentusergroups(administrator,operator,viewer)connect.

TouseHTTPS,anHTTPScerticatemustrstbeinstalled.GotoSystemOptions>Security>Certicatestoinstallandmanage

certicates.SeeCerticatesonpage46.

ToenableHTTPSontheAxisproduct:

1.GotoSystemOptions>Security>HTTPS

AXISQ3505–VEFixedDomeNetworkCamera

SystemOptions

2.SelectanHTTPScerticatefromthelistofinstalledcerticates.

3.Optionally,clickCiphersandselecttheencryptionalgorithmstouseforSSL.

4.SettheHTTPSConnectionPolicyforthedifferentusergroups.

5.ClickSavetoenablethesettings.

ToaccesstheAxisproductviathedesiredprotocol,enterhttps://orhttp://intheaddresseldinabrowser.

TheHTTPSportcanbechangedontheSystemOptions>Network>TCP/IP>Advancedpage.

IEEE802.1X

IEEE802.1Xisastandardforport-basedNetworkAdmissionControlprovidingsecureauthenticationofwiredandwirelessnetwork

devices.IEEE802.1XisbasedonEAP(ExtensibleAuthenticationProtocol).

ToaccessanetworkprotectedbyIEEE802.1X,devicesmustbeauthenticated.Theauthenticationisperformedbyanauthentication

server,typicallyaRADIUSserver,examplesofwhichareFreeRADIUSandMicrosoftInternetAuthenticationService.

InAxisimplementation,theAxisproductandtheauthenticationserveridentifythemselveswithdigitalcerticatesusingEAP-TLS

(ExtensibleAuthenticationProtocol-TransportLayerSecurity).ThecerticatesareprovidedbyaCerticationAuthority(CA).

Youneed:

•aCAcerticatetoauthenticatetheauthenticationserver.

•aCA-signedclientcerticatetoauthenticatetheAxisproduct.

Tocreateandinstallcerticates,gotoSystemOptions>Security>Certicates.SeeCerticatesonpage46.ManyCAcerticates

arepreinstalled.

ToallowtheproducttoaccessanetworkprotectedbyIEEE802.1X:

1.GotoSystemOptions>Security>IEEE802.1X.

2.SelectaCACerticateandaClientCerticatefromthelistsofinstalledcerticates.

3.UnderSettings,selecttheEAPOLversionandprovidetheEAPidentityassociatedwiththeclientcerticate.

4.ChecktheboxtoenableIEEE802.1XandclickSave.

Note

Forauthenticationtoworkproperly,thedateandtimesettingsintheAxisproductshouldbesynchronizedwithanNTP

server.SeeDate&Timeonpage47.

Certicates

Certicatesareusedtoauthenticatedevicesonanetwork.Typicalapplicationsincludeencryptedwebbrowsing(HTTPS),network

protectionviaIEEE802.1Xandsecureuploadofimagesandnoticationmessagesforexampleviaemail.Twotypesofcerticates

canbeusedwiththeAxisproduct:

Server/Clientcerticates-ToauthenticatetheAxisproduct.

CAcerticates-Toauthenticatepeercerticates,forexamplethecerticateofanauthenticationserverincasetheAxisproductis

connectedtoanIEEE802.1Xprotectednetwork.

Note

Installedcerticates,exceptpreinstalledCAcerticates,willbedeletediftheproductisresettofactorydefault.Preinstalled

CAcerticatesthathavebeendeletedwillbereinstalled.

AServer/Clientcerticatecanbeself-signedorissuedbyaCerticateAuthority(CA).Aself-signedcerticateofferslimited

protectionandcanbeusedbeforeaCA-issuedcerticatehasbeenobtained.

AXISQ3505–VEFixedDomeNetworkCamera

SystemOptions

Toinstallaself-signedcerticate:

1.GotoSetup>SystemOptions>Security>Certicates.

2.ClickCreateself-signedcerticateandprovidetherequestedinformation.

TocreateandinstallaCA-signedcerticate:

1.Createaself-signedcerticateasdescribedabove.

2.GotoSetup>SystemOptions>Security>Certicates.

3.ClickCreatecerticatesigningrequestandprovidetherequestedinformation.

4.CopythePEM-formattedrequestandsendtotheCAofyourchoice.

5.Whenthesignedcerticateisreturned,clickInstallcerticateanduploadthecerticate.

Server/ClientcerticatescanbeinstalledasCerticatefromsigningrequestorasCerticateandprivatekey.SelectCerticate

andprivatekeyiftheprivatekeyistobeuploadasaseparateleorifthecerticateisinPKCS#12format.

TheAxisproductisshippedwithseveralpreinstalledCAcerticates.Ifrequired,additionalCAcerticatescanbeinstalled:

1.GotoSetup>SystemOptions>Security>Certicates.

2.ClickInstallcerticateanduploadthecerticate.

AudioSupport

SelectEnableaudiosupporttoallowclientstoretrieveaudiostreamsfromtheAxisproduct.Forinformationonhowtocongure

audiosettings,seeAudioSettingsonpage27.

Note

DeselectingthisoptionwilldisableaudiogloballyintheAxisproduct,forconguredeventsandproleswithaudioaswell.

Date&Time

TheAxisproduct’sdateandtimesettingsareconguredunderSystemOptions>Date&Time.

CurrentServerTimedisplaysthecurrentdateandtime(24hclock).Thetimecanbedisplayedin12hclockinthetextoverlay(see

below).

Tochangethedateandtimesettings,selectthepreferredTimemodeunderNewServerTime:

•Synchronizewithcomputertime–Setsdateandtimeaccordingtothecomputer’sclock.Withthisoption,dateand

timearesetonceandwillnotbeupdatedautomatically.

•SynchronizewithNTPServer–ObtainsdateandtimefromanNTPserver.Withthisoption,dateandtimesettingsare

updatedcontinuously.ForinformationonNTPsettings,seeNTPCongurationonpage50.

IfusingahostnamefortheNTPserver,aDNSservermustbecongured.SeeDNSCongurationonpage49.

•Setmanually–Allowsyoutomanuallysetdateandtime.

IfusinganNTPserver,selectyourTimezonefromthedrop-downlist.Ifrequired,checkAutomaticallyadjustfordaylightsaving

timechanges.

TheDate&TimeFormatUsedinImagesisthedateandtimeformatdisplayedasatextoverlayinthevideostream.Usethe

predenedformatsorseeFileNaming&Date/TimeFormatsintheonlinehelp

forinformationonhowtocreatecustomdateand

timeformats.Toincludedateandtimeintheoverlaytext,gotoVideo&AudioandselectIncludedateandIncludetime.

AXISQ3505–VEFixedDomeNetworkCamera

SystemOptions

Network

BasicTCP/IPSettings

TheAxisproductsupportsIPversion4andIPversion6.Bothversionscanbeenabledsimultaneously,andatleastoneversion

mustalwaysbeenabled.

IPv4AddressConguration

Bydefault,theAxisproductissettouseIPv4(IPversion4)andtoobtaintheIPaddressautomaticallyviaDHCP.TheIPv4settingsare

conguredunderSystemOptions>Network>TCP/IP>Basic.

DHCP(DynamicHostCongurationProtocol)allowsnetworkadministratorstocentrallymanageandautomatetheassignmentof

IPaddresses.DHCPshouldonlybeenabledifusingdynamicIPaddressnotication,oriftheDHCPcanupdateaDNSserver.Itis

thenpossibletoaccesstheAxisproductbyname(hostname).

IfDHCPisenabledandtheproductcannotbeaccessed,runAXISIPUtilitytosearchthenetworkforconnectedAxisproducts,orreset

theproducttothefactorydefaultsettings(seepage57)andthenperformtheinstallationagain.

TouseastaticIPaddress,checkUsethefollowingIPaddressandspecifytheIPaddress,subnetmaskanddefaultrouter.

IPv6AddressConguration

IfIPv6(IPversion6)isenabled,theAxisproductwillreceiveanIPaddressaccordingtothecongurationinthenetworkrouter.

ToenableIPv6,gotoSystemOptions>Network>TCP/IP>Basic.OthersettingsforIPv6shouldbeconguredinthenetworkrouter.

ARP/Ping

Theproduct’sIPaddresscanbeassignedusingARPandPing.Forinstructions,seeAssignIPAddressUsingARP/Pingonpage48.

TheARP/Pingserviceisenabledbydefaultbutisautomaticallydisabledtwominutesaftertheproductisstarted,orassoonasanIP

addressisassigned.Tore-assignIPaddressusingARP/Ping,theproductmustberestartedtoenableARP/Pingforanadditional

twominutes.

Todisabletheservice,gotoSystemOptions>Network>TCP/IP>BasicandcleartheoptionEnableARP/PingsettingofIPaddress.

Pingingtheproductisstillpossiblewhentheserviceisdisabled.

AssignIPAddressUsingARP/Ping

Theproduct'sIPaddresscanbeassignedusingARP/Ping.Thecommandmustbeissuedwithin2minutesofconnectingpower.

1.AcquireafreestaticIPaddressonthesamenetworksegmentasthecomputer.

2.Locatetheserialnumber(S/N)ontheproductlabel.

3.Openacommandpromptandenterthefollowingcommands:

Linux/Unixsyntax

arp-s<IPaddress><serialnumber>temp

ping-s408<IPaddress>

Linux/Unixexample

arp-s192.168.0.12500:40:8c:18:10:00temp

ping-s408192.168.0.125

Windowssyntax(thismayrequirethatyourunthecommandpromptasanadministrator)

arp-s<IPaddress><serialnumber>

AXISQ3505–VEFixedDomeNetworkCamera

SystemOptions

ping-l408-t<IPaddress>

Windowsexample(thismayrequirethatyourunthecommandpromptasanadministrator)

arp-s192.168.0.12500-40-8c-18-10-00

ping-l408-t192.168.0.125

4.Checkthatthenetworkcableisconnectedandthenrestarttheproductbydisconnectingandreconnectingpower.

5.ClosethecommandpromptwhentheproductrespondswithReplyfrom192.168.0.125:...orsimilar.

6.Openabrowserandtypehttp://<IPaddress>intheLocation/Addresseld.

ForothermethodsofassigningtheIPaddress,seetheInstallationandManagementSoftwareCDorthedocumentAssignanIP

AddressandAccesstheVideoStreamonAxisSupportwebatwww.axis.com/techsup

Note

•ToopenacommandpromptinWindows,opentheStartmenuandtypecmdintheRun/Searcheld.

•TousetheARPcommandinWindows8/Windows7/WindowsVista,right-clickthecommandprompticonandselect

Runasadministrator.

•ToopenacommandpromptinMacOSX,opentheTerminalutilityfromApplication>Utilities.

AXISVideoHostingSystem(AVHS)

AVHSusedinconjunctionwithanAVHSservice,provideseasyandsecureInternetaccesstoliveandrecordedvideoaccessiblefrom

anylocation.FormoreinformationandhelptondalocalAVHSServiceProvidergotowww.axis.com/hosting

TheAVHSsettingsareconguredunderSystemOptions>Network>TCPIP>Basic.ThepossibilitytoconnecttoanAVHSservice

isenabledbydefault.Todisable,cleartheEnableAVHSbox.

One-clickenabled-Pressandholdtheproduct’scontrolbutton(seeHardwareOverviewonpage6)forabout3secondsto

connecttoanAVHSserviceovertheInternet.Onceregistered,AlwayswillbeenabledandtheAxisproductstaysconnectedto

theAVHSservice.Iftheproductisnotregisteredwithin24hoursfromwhenthebuttonispressed,theproductwilldisconnect

fromtheAVHSservice.

Always-TheAxisproductwillconstantlyattempttoconnecttotheAVHSserviceovertheInternet.Onceregisteredtheproductwill

stayconnectedtotheservice.Thisoptioncanbeusedwhentheproductisalreadyinstalledanditisnotconvenienttousethe

one-clickinstallation.

AXISInternetDynamicDNSService

AXISInternetDynamicDNSServiceassignsahostnameforeasyaccesstotheproduct.Formoreinformation,seewww.axiscam.net

ToregistertheAxisproductwithAXISInternetDynamicDNSService,gotoSystemOptions>Network>TCP/IP>Basic.Under

Services,clicktheAXISInternetDynamicDNSServiceSettingsbutton(requiresaccesstotheInternet).Thedomainnamecurrently

registeredatAXISInternetDynamicDNSservicefortheproductcanatanytimeberemoved.

Note

AXISInternetDynamicDNSServicerequiresIPv4.

AdvancedTCP/IPSettings

DNSConguration

DNS(DomainNameService)providesthetranslationofhostnamestoIPaddresses.TheDNSsettingsareconguredunderSystem

Options>Network>TCP/IP>Advanced.

SelectObtainDNSserveraddressviaDHCPtousetheDNSsettingsprovidedbytheDHCPserver.

Tomakemanualsettings,selectUsethefollowingDNSserveraddressandspecifythefollowing:

AXISQ3505–VEFixedDomeNetworkCamera

SystemOptions

Domainname-Enterthedomain(s)tosearchforthehostnameusedbytheAxisproduct.Multipledomainscanbeseparatedby

semicolons.Thehostnameisalwaystherstpartofafullyqualieddomainname,forexample,myserveristhehostnameinthe

fullyqualieddomainnamemyserver.mycompany.comwheremycompany.comisthedomainname.

Primary/SecondaryDNSserver-EntertheIPaddressesoftheprimaryandsecondaryDNSservers.ThesecondaryDNSserveris

optionalandwillbeusediftheprimaryisunavailable.

NTPConguration

NTP(NetworkTimeProtocol)isusedtosynchronizetheclocktimesofdevicesinanetwork.TheNTPsettingsareconguredunder

SystemOptions>Network>TCP/IP>Advanced.

SelectObtainNTPserveraddressviaDHCPtousetheNTPsettingsprovidedbytheDHCPserver.

Tomakemanualsettings,selectUsethefollowingNTPserveraddressandenterthehostnameorIPaddressoftheNTPserver.

HostNameConguration

TheAxisproductcanbeaccessedusingahostnameinsteadofanIPaddress.ThehostnameisusuallythesameastheassignedDNS

name.ThehostnameisconguredunderSystemOptions>Network>TCP/IP>Advanced.

SelectObtainhostnameviaIPv4DHCPtousehostnameprovidedbytheDHCPserverrunningonIPv4.

SelectUsethehostnametosetthehostnamemanually.

SelectEnabledynamicDNSupdatestodynamicallyupdatelocalDNSserverswhenevertheAxisproduct’sIPaddresschanges.

Formoreinformation,seetheonlinehelp

Link-LocalIPv4Address

Link-LocalAddressisenabledbydefaultandassignstheAxisproductanadditionalIPaddresswhichcanbeusedtoaccess

theproductfromotherhostsonthesamesegmentonthelocalnetwork.TheproductcanhaveaLink-LocalIPandastatic

orDHCP-suppliedIPaddressatthesametime.

ThisfunctioncanbedisabledunderSystemOptions>Network>TCP/IP>Advanced.

HTTP

TheHTTPportusedbytheAxisproductcanbechangedunderSystemOptions>Network>TCP/IP>Advanced.Inadditiontothe

defaultsetting,whichis80,anyportintherange1024–65535canbeused.

HTTPS

TheHTTPSportusedbytheAxisproductcanbechangedunderSystemOptions>Network>TCP/IP>Advanced.Inadditionto

thedefaultsetting,whichis443,anyportintherange1024–65535canbeused.

ToenableHTTPS,gotoSystemOptions>Security>HTTPS.Formoreinformation,seeHTTPSonpage45.

NATtraversal(portmapping)forIPv4

Anetworkrouterallowsdevicesonaprivatenetwork(LAN)toshareasingleconnectiontotheInternet.Thisisdonebyforwarding

networktrafcfromtheprivatenetworktothe“outside”,thatis,theInternet.Securityontheprivatenetwork(LAN)isincreased

sincemostroutersarepre-conguredtostopattemptstoaccesstheprivatenetwork(LAN)fromthepublicnetwork(Internet).

UseNATtraversalwhentheAxisproductislocatedonanintranet(LAN)andyouwishtomakeitavailablefromtheother(WAN)side

ofaNATrouter.WithNATtraversalproperlycongured,allHTTPtrafctoanexternalHTTPportintheNATrouterisforwardedto

theproduct.

NATtraversalisconguredunderSystemOptions>Network>TCP/IP>Advanced.

AXISQ3505–VEFixedDomeNetworkCamera

SystemOptions

Note

•ForNATtraversaltowork,thismustbesupportedbytherouter.TheroutermustalsosupportUPnP

•Therouterhasmanydifferentnames:“NATrouter”,“Networkrouter”,“InternetGateway”,”Broadbandrouter”,“Broadband

sharingdevice”or“Homerewall”buttheessentialpurposeofthedeviceisthesame.

Enable/Disable-Whenenabled,theAxisproductattemptstocongureportmappinginaNATrouteronyournetwork,usingUPnP

NotethatUPnP

mustbeenabledintheproduct(seeSystemOptions>Network>UPnP).

UsemanuallyselectedNATrouter-SelectthisoptiontomanuallyselectaNATrouterandentertheIPaddressfortherouterin

theeld.Ifnorouterisspecied,theproductautomaticallysearchesforNATroutersonyournetwork.Ifmorethanonerouteris

found,thedefaultrouterisselected.

AlternativeHTTPport-SelectthisoptiontomanuallydeneanexternalHTTPport.Entertheportnumberintheeld.Ifnoportis

enteredhere,aportnumberisautomaticallyselectedwhenNATtraversalisenabled.

Note

•AnalternativeHTTPportcanbeusedorbeactiveevenifNATtraversalisdisabled.ThisisusefulifyourNATrouterdoesnot

supportUPnPandyouneedtomanuallycongureportforwardingintheNATrouter.

•Ifyouattempttomanuallyenteraportthatisalreadyinuse,anotheravailableportisautomaticallyselected.

•Whentheportisselectedautomaticallyitisdisplayedinthiseld.Tochangethis,enteranewportnumberandclickSave.

FTP

TheFTPserverrunningintheAxisproductenablesuploadofnewrmware,userapplications,etc.TheFTPservercanbedisabled

underSystemOptions>Network>TCP/IP>Advanced.

Note

ThisFTPserverhasnothingtodowiththeproduct’sabilitytotransferimagesviaFTPtootherlocationsandservers.

RTSP

TheRTSPserverrunningintheAxisproductallowsaconnectingclienttostartanH.264stream.TheRTSPportnumbercanbe

changedunderSystemOptions>Network>TCP/IP>Advanced.Thedefaultportis554.

Note

H.264videostreamswillnotbeavailableiftheRTSPserverisdisabled.

SOCKS

SOCKSisanetworkingproxyprotocol.TheAxisproductcanbeconguredtouseaSOCKSservertoreachnetworksontheother

sideofarewallorproxyserver.ThisfunctionalityisusefuliftheAxisproductislocatedonalocalnetworkbehindarewall,and

notications,uploads,alarms,etcneedtobesenttoadestinationoutsidethelocalnetwork(forexampletheInternet).

SOCKSisconguredunderSystemOptions>Network>SOCKS.Formoreinformation,seetheonlinehelp.

QoS(QualityofService)

QoS(QualityofService)guaranteesacertainlevelofaspeciedresourcetoselectedtrafconanetwork.AQoS-awarenetwork

prioritizesnetworktrafcandprovidesagreaternetworkreliabilitybycontrollingtheamountofbandwidthanapplicationmayuse.

TheQoSsettingsareconguredunderSystemOptions>Network>QoS.UsingDSCP(DifferentiatedServicesCodepoint)values,the

Axisproductcanmarkdifferenttypesoftrafc.

Note

LiveaudioDSCPwillbeequaltolivevideoDSCPifH.264overRTSPisused.

AXISQ3505–VEFixedDomeNetworkCamera

SystemOptions

SNMP

TheSimpleNetworkManagementProtocol(SNMP)allowsremotemanagementofnetworkdevices.AnSNMPcommunityisthe

groupofdevicesandmanagementstationrunningSNMP.Communitynamesareusedtoidentifygroups.

AXISVideoMIB(ManagementInformationBase)forvideohardwarecanbeusedtomonitorAxis-specic,hardware-related

issuesthatmayneedadministrativeattention.FormoreinformationaboutAXISVideoMIBandtodownloadMIBles,goto

www.axis.com/techsup

ToenableandcongureSNMPintheAxisproduct,gototheSystemOptions>Network>SNMPpage.

Dependingonthelevelofsecurityrequired,selecttheversiononSNMPtouse.

TrapsareusedbytheAxisproducttosendmessagestoamanagementsystemonimportanteventsandstatuschanges.CheckEnable

trapsandentertheIPaddresswherethetrapmessageshouldbesentandtheTrapcommunitythatshouldreceivethemessage.

Note

IfHTTPSisenabled,SNMPv1andSNMPv2cshouldbedisabled.

TrapsforSNMPv1/v2areusedbytheAxisproducttosendmessagestoamanagementsystemonimportanteventsandstatus

changes.CheckEnabletrapsandentertheIPaddresswherethetrapmessageshouldbesentandtheTrapcommunitythat

shouldreceivethemessage.

Thefollowingtrapsareavailable:

•Coldstart

•Warmstart

•Linkup

•Authenticationfailed

Note

AllAXISVideoMIBtrapsareenabledwhenSNMPv1/v2ctrapsareenabled.Itisnotpossibletoturnonoroffspecictraps.

SNMPv3providesencryptionandsecurepasswords.TousetrapswithSNMPv3,anSNMPv3managementapplicationisrequired.

TouseSNMPv3,HTTPSmustbeenabled,seeHTTPSonpage45.ToenableSNMPv3,checktheboxandprovidetheinitialuser

password.

Note

Theinitialpasswordcanonlybesetonce.Ifthepasswordislost,theAxisproductmustberesettofactorydefault,see

ResettoFactoryDefaultSettingsonpage57.

UPnP

TheAxisproductincludessupportforUPnP

.UPnP

isenabledbydefaultandtheproductisautomaticallydetectedbyoperating

systemsandclientsthatsupportthisprotocol.

UPnP

canbedisabledunderSystemOptions>Network>UPnP

RTP/H.264

TheRTPportrangeandmulticastsettingsareconguredunderSystemOptions>Network>RTP.

TheRTPportrangedenestherangeofportsfromwhichthevideo/audioportsareautomaticallyselected.Formulticaststreams,

onlycertainIPaddressesandportnumbersshouldbeused.

SelectAlwaysMulticastVideoand/orAlwaysMulticastAudiotostartmulticaststreamingwithoutopeninganRTSPsession.

AXISQ3505–VEFixedDomeNetworkCamera

SystemOptions

Bonjour

TheAxisproductincludessupportforBonjour.Bonjourisenabledbydefaultandtheproductisautomaticallydetectedbyoperating

systemsandclientsthatsupportthisprotocol.

BonjourcanbedisabledunderSystemOptions>Network>Bonjour.

Storage

SDCard

NO NO

TICE TICE

TICE

Topreventcorruptionofrecordings,theSDcardshouldalwaysbeunmountedbeforeitisejected.

Note

ForSDcardrecommendationsseewww.axis.com

TheAxisproductsupportsmicroSDcardswithupto64GBofstorage.Forbestrecordingperformance,useultra-highspeedmicroSD

cards(microSDHCUHS-IormicroSDXCUHS-I).

ThefollowingSDcardlesystemsaresupported:

•ext4—recommendedduetoitsresilienceagainstdatalossifthecardisejectedorifthereisabruptpowerloss.Toaccess

datastoredonthecardfromtheWindowsoperatingsystem,athird-partyext4driverorapplicationisrequired.

•vFAT—supportedbymostoperatingsystemsforpersonalcomputers.

TheSDcardismanagedontheSystemOptions>Storagepage.ClickSDCardtoopenStorageManagement.

Ifthecard’sstatusshowsasfailed,clickCheckdisktoseeiftheproblemcanbefoundandthentryRepair.Thisoptionisonly

availableforSDcardswithext4.ForSDcardswithvFAT,useacardreaderorcomputertotroubleshootthecard.

Toavoidllingthecard,itisrecommendedtoremoverecordingscontinuously.UnderGeneralSettings,selectRemoverecordings

olderthanandselectthenumberofdaysorweeks.

Tostopwritingtothecardandprotectrecordingsfrombeingremoved,selectLockunderGeneralSettings.

MountandUnmountSDCard

NO NO

TICE TICE

TICE

Topreventcorruptionofrecordings,theSDcardshouldalwaysbeunmountedbeforeitisejected.

TheSDcardisautomaticallymountedwhenthecardisinsertedintotheAxisproductorwhentheproductisstarted.Amanual

mountisonlyrequiredifthecardhasbeenunmountedandnotejectedandre-inserted.

TounmounttheSDcard:

1.OpentheAxisproduct’swebpagesandgotoSetup>SystemOptions>Storage.

2.ClickSDCard.

3.ClickUnmount.

4.Thecardcannowberemoved.

FormatSDCard

NO NO

TICE TICE

TICE

FormattingtheSDcardwillremovealldataandrecordingsstoredonthecard.

AXISQ3505–VEFixedDomeNetworkCamera

SystemOptions

Important

Ifautoformatisenabled,onlyuseneworemptySDcards.Anydatastoredonthecardwillbelostwhenthecardisinserted

intotheAxisproduct.

AnSDcardinsertedintotheproductcanbemanuallyformattedtooneofthesupportedlesystems.Tomanuallyformatthe

SDcard,followthesesteps:

1.InserttheSDcardintheSDcardslot.

2.OpentheAxisproduct’swebpagesandgotoSetup>SystemOptions>Storage.

3.ClickSDCard.

4.ClickFormatandselectthedesiredlesystem.

5.ClickOKtostartformattingthecard.

NetworkShare

NetworkshareallowsyoutoaddnetworkstoragesuchasaNAS(network-attachedstorage).TheNASshallbededicatedfor

recordingsanddatafromtheAxisproductsconnectedtothenetwork.ForinformationaboutreferenceNASdevices,goto

www.axis.com/products/cam_companion_software/supported.htm

Note

ForNASrecommendationsseewww.axis.com

Toaddanetworkshare:

1.GotoSystemOptions>Storage.

2.ClickNetworkShare.

3.EntertheIPaddress,DNSorBonjournametothehostserverintheHosteld.

4.EnterthenameoftheshareintheShareeld.Subfolderscannotbeused.

5.Ifrequired,selectThesharerequiresloginandentertheusernameandpassword.

6.ClickConnect.

ToclearallrecordingsanddatafromtheAxisproduct’sfolderonthedesignatedshare,clickClearunderStorageTools.

Toavoidllingtheshare,itisrecommendedtoremoverecordingscontinuously.UnderRecordingSettings,selectRemoverecordings

olderthanandselectthenumberofdaysorweeks.

Tostopwritingtotheshareandprotectrecordingsfrombeingremoved,selectLockunderRecordingSettings.

Ports&Devices

I/OPorts

TheAxisproductprovidestwocongurableinputandoutputportsforconnectionofexternaldevices.Forinformationabout

howtoconnectexternaldevices,seeConnectorsonpage66.

TheI/OportsareconguredunderSystemOptions>Ports&Devices>I/OPorts.Selecttheportdirection(InputorOutput).The

portscanbegivendescriptivenamesandtheirNormalstatescanbeconguredasOpencircuitorGroundedcircuit.

PortStatus

ThelistontheSystemOptions>Ports&Devices>PortStatuspageshowsthestatusoftheproduct’sinputandoutputports.

AXISQ3505–VEFixedDomeNetworkCamera

SystemOptions

Accelerometer

Thelevelingassistantthathelpstolevelthecameraisenabledbydefault.Todisableit,de-selecttheEnablelevelingassistantoption

fromSystemOptions>Ports&Devices>AccelerometerandclickSave.Torefreshthepageandviewthesavedsetting,clickReset.

Maintenance

TheAxisproductprovidesseveralmaintenancefunctions.TheseareavailableunderSystemOptions>Maintenance.

ClickRestarttoperformacorrectrestartiftheAxisproductisnotbehavingasexpected.Thiswillnotaffectanyofthecurrent

settings.

Note

ArestartclearsallentriesintheServerReport.

ClickRestoretoresetmostsettingstothefactorydefaultvalues.Thefollowingsettingsarenotaffected:

•thebootprotocol(DHCPorstatic)

•thestaticIPaddress

•thedefaultrouter

•thesubnetmask

•thesystemtime

•theIEEE802.1Xsettings

•thefocusposition

•uploadedapplicationsarekeptbutmustberestarted

ClickDefaulttoresetallsettings,includingtheIPaddress,tothefactorydefaultvalues.Thisbuttonshouldbeusedwithcaution.The

Axisproductcanalsoberesettofactorydefaultusingthecontrolbutton,seeResettoFactoryDefaultSettingsonpage57.

Toresettheoptics,clickCalibrateunderSystemOptions>Maintenance>Optics.Thismaybenecessaryinsituationswherethe

opticshaslostitscalibrationduringtransportorhasbeenexposedtoextremevibrations.Ifnecessarycongurefocusandzoom

again(seeBasicSetuponpage17).

ToidentifytheproductortesttheStatusLED,clickFlashLEDunderIdentifyandspecifythedurationinseconds,minutesorhours.

Thiscanbeusefulforidentifyingtheproductamongotherproductsinstalledinthesamelocation.

Forinformationaboutrmwareupgrade,seeUpgradetheFirmwareonpage58.

Support

SupportOverview

TheSystemOptions>Support>SupportOverviewpageprovidesinformationontroubleshootingandcontactinformation,

shouldyourequiretechnicalassistance.

SeealsoTroubleshootingonpage58.

SystemOverview

TogetanoverviewoftheAxisproduct’sstatusandsettings,gotoSystemOptions>Support>SystemOverview.Informationthat

canbefoundhereincludesrmwareversion,IPaddress,networkandsecuritysettings,eventsettings,imagesettingsandrecentlog

items.ManyofthecaptionsarelinkstotheproperSetuppage.

AXISQ3505–VEFixedDomeNetworkCamera

SystemOptions

Logs&Reports

TheSystemOptions>Support>Logs&Reportspagegenerateslogsandreportsusefulforsystemanalysisandtroubleshooting.If

contactingAxisSupport,pleaseprovideavalidServerReportwithyourquery.

SystemLog-Providesinformationaboutsystemevents.

AccessLog-Listsallfailedattemptstoaccesstheproduct.TheAccessLogcanalsobeconguredtolistallconnectionstothe

product(seebelow).

ServerReport-Providesinformationabouttheproductstatusinapop-upwindow.TheAccessLogisautomaticallyincluded

intheServerReport.

Youcanviewordownloadtheserverreport.Downloadingtheserverreportcreatesa.ziplethatcontainsacompleteserverreport

textleinUTF–8format.SelecttheIncludesnapshotwithdefaultimagesettingsoptiontoincludeasnapshotoftheproduct’sLive

View.Theserverreport.zipleshouldalwaysbeincludedwhencontactingsupport.

ParameterList-Showstheproduct'sparametersandtheircurrentsettings.Thismayproveusefulwhentroubleshootingor

whencontactingAxisSupport.

ConnectionList-Listsallclientsthatarecurrentlyaccessingmediastreams.

CrashReport-Generatesanarchivewithdebugginginformation.Thereporttakesseveralminutestogenerate.

TheloglevelsfortheSystemLogandtheAccessLogaresetunderSystemOptions>Support>Logs&Reports>Conguration.

TheAccessLogcanbeconguredtolistallconnectionstotheproduct(selectCritical,Warnings&Info).

Advanced

Scripting

Scriptingallowsexperienceduserstocustomizeandusetheirownscripts.

NO NO

TICE TICE

TICE

ImproperusemaycauseunexpectedbehaviorandlossofcontactwiththeAxisproduct.

Axisstronglyrecommendsthatyoudonotusethisfunctionunlessyouunderstandtheconsequences.AxisSupportdoesnotprovide

assistanceforproblemswithcustomizedscripts.

ToopentheScriptEditor,gotoSystemOptions>Advanced>Scripting.Ifascriptcausesproblems,resettheproducttoits

factorydefaultsettings,seepage57.

Formoreinformation,seewww.axis.com/developer

FileUpload

Files,forexamplewebpagesandimages,canbeuploadedtotheAxisproductandusedascustomsettings.Touploadale,go

toSystemOptions>Advanced>FileUpload.

Uploadedlesareaccessedthroughhttp://<ipaddress>/local/<user>/<filename>where<user>isthe

selectedusergroup(viewer,operatororadministrator)fortheuploadedle.

PlainCong

PlainCongisforadvanceduserswithexperienceofAxisproductconguration.Mostparameterscanbesetandmodiedfrom

thispage.

ToopenPlainCong,gotoSystemOptions>Advanced>PlainCong.AxisSupportdoesnotprovideassistance.

AXISQ3505–VEFixedDomeNetworkCamera

SystemOptions

ResettoFactoryDefaultSettings

Important

Resettofactorydefaultshouldbeusedwithcaution.Aresettofactorydefaultwillresetallsettings,includingtheIP

address,tothefactorydefaultvalues.

Note

TheinstallationandmanagementsoftwaretoolsareavailableontheCDsuppliedwiththeproductandfromthesupport

pagesonwww.axis.com/techsup

Toresettheproducttothefactorydefaultsettings:

1.Disconnectpowerfromtheproduct.

2.Pressandholdthecontrolbuttonandreconnectpower.SeeHardwareOverviewonpage6.

3.Keepthecontrolbuttonpressedforabout15–30secondsuntilthestatusLEDindicatorashesamber.

4.Releasethecontrolbutton.TheprocessiscompletewhenthestatusLEDindicatorturnsgreen.Theproducthasbeenreset

tothefactorydefaultsettings.IfnoDHCPserverisavailableonthenetwork,thedefaultIPaddressis192.168.0.90

5.Usingtheinstallationandmanagementsoftwaretools,assignanIPaddress,setthepassword,andaccessthevideostream.

Itisalsopossibletoresetparameterstofactorydefaultviathewebinterface.GotoSetup>SystemOptions>Maintenance.

AXISQ3505–VEFixedDomeNetworkCamera

Troubleshooting

ChecktheFirmware

Firmwareissoftwarethatdeterminesthefunctionalityofnetworkdevices.Oneofyourrstactionswhentroubleshootingaproblem

shouldbetocheckthecurrentrmwareversion.Thelatestversionmaycontainacorrectionthatxesyourparticularproblem.The

currentrmwareversionintheAxisproductisdisplayedinthepageSetup>BasicSetupandinSetup>About.

UpgradetheFirmware

Important

•Yourdealerreservestherighttochargeforanyrepairattributabletofaultyupgradebytheuser.

•Preconguredandcustomizedsettingsaresavedwhenthermwareisupgraded(providingthefeaturesareavailableinthe

newrmware)althoughthisisnotguaranteedbyAxisCommunicationsAB.

Note

•Aftertheupgradeprocesshascompleted,theproductwillrestartautomatically.Ifrestartingtheproductmanuallyafterthe

upgrade,alwayswait10minutesevenifyoususpecttheupgradehasfailed.

•WhenyouupgradetheAxisproductwiththelatestrmwarefromAxiswebsite,theproductreceivesthelatestfunctionality

available.Alwaysreadtheupgradeinstructionsandreleasenotesavailablewitheachnewreleasebeforeupgrading

thermware.

Toupgradetheproduct’srmware:

1.Savethermwareletoyourcomputer.ThelatestversionofthermwareisavailablefreeofchargefromAxiswebsite

atwww.axis.com/techsup

2.GotoSetup>SystemOptions>Maintenanceintheproduct’swebpages.

3.UnderUpgradeServer,clickBrowseandlocatetheleonyourcomputer.ClickUpgrade.

4.Waitapproximately10minuteswhiletheproductisbeingupgradedandrestarted.Thenaccesstheproduct.

AXISCameraManagementcanbeusedformultipleupgrades.Seewww.axis.comformoreinformation.

AXISQ3505–VEFixedDomeNetworkCamera

Troubleshooting

EmergencyRecoveryProcedure

Ifpowerornetworkconnectionislostduringtheupgrade,theprocessfailsandtheproductbecomesunresponsive.FlashingredStatus

indicatorindicatesafailedupgrade.Torecovertheproduct,followthestepsbelow.Theserialnumberisfoundontheproduct’slabel.

1.InUNIX/Linux,typethefollowingfromthecommandline:

arp-s<IPaddress><serialnumber>temp

ping-l408<IPaddress>

InWindows,typethefollowingfromacommand/DOSprompt(thismayrequirethatyourunthecommandpromptas

anadministrator):

arp-s<IPaddress><serialnumber>

ping-l408-t<IPaddress>

2.Iftheproductdoesnotreplyin30seconds,restartitandwaitforareply.PressCTRL+CtostopPing.

3.Openabrowserandtypeintheproduct’sIPaddress.Inthepagethatopens,usetheBrowsebuttontoselecttheupgrade

letouse.ThenclickLoadtorestarttheupgradeprocess.

4.Aftertheupgradeiscomplete(1–10minutes),theproductautomaticallyrestartsandshowsasteadygreenonthe

Statusindicator.

5.Reinstalltheproduct,referringtotheInstallationGuide.

Iftheemergencyrecoveryproceduredoesnotgettheproductupandrunningagain,contactAxissupportatwww.axis.com/techsup/

Symptoms,PossibleCausesandRemedialActions

ProblemssettingtheIPaddress

WhenusingARP/Ping

Trytheinstallationagain.TheIPaddressmustbesetwithintwominutesafterpowerhasbeen

appliedtotheproduct.EnsurethePinglengthissetto408.Forinstructions,seeAssignIPAddress

UsingARP/Pingonpage48.

Theproductislocatedona

differentsubnet

IftheIPaddressintendedfortheproductandtheIPaddressofthecomputerusedtoaccessthe

productarelocatedondifferentsubnets,youwillnotbeabletosettheIPaddress.Contactyour

networkadministratortoobtainanIPaddress.

TheIPaddressisbeingused

byanotherdevice

DisconnecttheAxisproductfromthenetwork.RunthePingcommand(inaCommand/DOS

window,typepingandtheIPaddressoftheproduct):

•Ifyoureceive:Replyfrom<IPaddress>:bytes=32;time=10...

thismeansthattheIPaddressmayalreadybeinusebyanotherdeviceonthenetwork.

ObtainanewIPaddressfromthenetworkadministratorandreinstalltheproduct.

•Ifyoureceive:Requesttimedout,thismeansthattheIPaddressisavailable

forusewiththeAxisproduct.Checkallcablingandreinstalltheproduct.

PossibleIPaddressconict

withanotherdeviceonthe

samesubnet.

ThestaticIPaddressintheAxisproductisusedbeforetheDHCPserversetsadynamicaddress.

ThismeansthatifthesamedefaultstaticIPaddressisalsousedbyanotherdevice,theremay

beproblemsaccessingtheproduct.

Theproductcannotbeaccessedfromabrowser

Cannotlogin

WhenHTTPSisenabled,ensurethatthecorrectprotocol(HTTPorHTTPS)isusedwhenattempting

tologin.Youmayneedtomanuallytypehttporhttpsinthebrowser’saddresseld.

Ifthepasswordfortheuserrootislost,theproductmustberesettothefactorydefaultsettings.

SeeResettoFactoryDefaultSettingsonpage57.

AXISQ3505–VEFixedDomeNetworkCamera

Troubleshooting

TheIPaddresshasbeen

changedbyDHCP

IPaddressesobtainedfromaDHCPserveraredynamicandmaychange.IftheIPaddresshas

beenchanged,useAXISIPUtilityorAXISCameraManagementtolocatetheproductonthe

network.Identifytheproductusingitsmodelorserialnumber,orbytheDNSname(ifthename

hasbeencongured).

Ifrequired,astaticIPaddresscanbeassignedmanually.Forinstructions,seetheInstallationand

ManagementSoftwareCDorthedocumentAssignanIPAddressandAccesstheVideoStreamon

AxisSupportwebatwww.axis.com/techsup.

Certicateerrorwhenusing

IEEE802.1X

Forauthenticationtoworkproperly,thedateandtimesettingsintheAxisproductshouldbe

synchronizedwithanNTPserver.SeeDate&Timeonpage47.

Theproductisaccessiblelocallybutnotexternally

RoutercongurationTocongureyourroutertoallowincomingdatatrafctotheAxisproduct,enabletheNAT-traversal

featurewhichwillattempttoautomaticallyconguretheroutertoallowaccesstotheAxis

product,seeNATtraversal(portmapping)forIPv4onpage50.TheroutermustsupportUPnP

Firewallprotection

ChecktheInternetrewallwithyournetworkadministrator.

Defaultroutersrequired

CheckifyouneedtoconguretheroutersettingsfromSystemOptions>Network>TCP/IP>

Basic.

ProblemswithstreamingH.264

ProblemswithAXISMedia

Control(InternetExplorer

only)

ToenabletheupdatingofvideoimagesinInternetExplorer,setthebrowsertoallowActiveX

controls.Also,makesurethatAXISMediaControlisinstalledonyourcomputer.

NoH.264displayedinthe

client

CheckthattherelevantH.264connectionmethodsandcorrectinterfaceareenabledintheAMC

ControlPanel(streamingtab).SeeAXISMediaControl(AMC)onpage14.

IntheAMCControlPanel,selecttheH.264tabandclickSettodefaultH.264decoder.

CheckthatRTSPisenabledunderSystemOptions>Network>TCP/IP>Advanced.

MulticastH.264only

accessiblebylocalclients

Checkifyourroutersupportsmulticasting,oriftheroutersettingsbetweentheclientandthe

productneedtobecongured.TheTTL(TimeToLive)valuemayneedtobeincreased.

NomulticastH.264

displayedintheclient

CheckwithyournetworkadministratorthatthemulticastaddressesusedbytheAxisproduct

arevalidforyournetwork.

Checkwithyournetworkadministratortoseeifthereisarewallpreventingviewing.

Installationofadditional

ActiveXcomponent

restrictedorprohibited

ConguretheAxisproducttouseaJavaappletforupdatingvideoimagesinyourbrowser.Goto

Setup>LiveViewCongandselectJavaappletunderDefaultviewer.

PoorrenderingofH.264

images

Ensurethatyourgraphicscardisusingthelatestdriver.Thelatestdriverscanusuallybe

downloadedfromthemanufacturer’swebsite.

Colorsaturationisdifferent

inH.264andMotionJPEG

Modifythesettingsforyourgraphicsadapter.Refertotheadapter’sdocumentationformore

information.

AXISQ3505–VEFixedDomeNetworkCamera

Troubleshooting

Lowerframeratethan

expected

SeePerformanceConsiderationsonpage68.

Reducethenumberofapplicationsrunningontheclientcomputer.

Limitthenumberofsimultaneousviewers.

Checkwiththenetworkadministratorthatthereisenoughbandwidthavailable.

CheckintheAMCControlPanel(H.264tag)thatvideoprocessingisNOTsettoDecodeonly

keyframes.

Lowertheimageresolution.

SetaCaptureModethatprioritizesframerate.Changingthecapturemodetoprioritizeframerate

willlowerthemaximumresolution.SeeCaptureModeonpage20.

Themaximumframespersecondisdependentontheutilityfrequency(60/50Hz)oftheAxis

product.SeeTechnicalSpecicationsonpage63.

Videoandimageproblems,general

Imageunsatisfactory

CheckthevideostreamandcamerasettingsunderSetup>Video&Audio>VideoStreamand

Setup>Video&Audio>CameraSettings.

MotionDetectiontriggersunexpectedly

Changesinluminance

Motiondetectionisbasedonchangesinluminanceintheimage.Thismeansthatifthereare

suddenchangesinthelighting,motiondetectionmaytriggermistakenly.Lowerthesensitivity

settingtoavoidproblemswithluminance.

Noaudio

Incorrectsetup

Checkthesoundcardinthecomputer.Ensurethatmuteisnotselectedandthatthevolume

settingsarecorrect.

CheckthatEnableaudiosupportisselectedunderSetup>SystemOptions>Security>Audio

Support.

CheckthatthecorrectAudioInputsourceisselectedunderSetup>Video&Audio>Audio

Settings.

Pooraudioquality

Stuttering

Reducethenumberoflistenersandviewers.Decreaseimageresolutionandcompression.

Unsynchronizedaudioand

videousingH.264

Synchronizetheproduct’sdateandtimesettingswithanNTPserver.GotoSetup>System

Options>Date&Time.

Distortedaudio

CheckthatthecorrectAudioInputsourceisselectedunderSetup>Video&Audio>Audio

Settings.

FeedbackloopsFeedbackloopsmightappearinfull-duplexmode.Trymovingthemicrophoneorthespeaker,or

usehalf-duplexmodeinstead.

Storageanddiskmanagementproblems

Storagedisruption

Astoragedisruptionalarmissentifastoragedeviceisunavailable,removed,full,lockedorifother

readorwriteproblemsoccur.Toidentifythesourceoftheproblem,checktheSystemLogunder

SystemOptions>Support>Logs&Reports.Dependingontheproblem,itmightbenecessaryto

re-mountthestoragedevice.

Forinformationonhowtosetupastoragedisruptionalarm,seeEventsonpage38.

AXISQ3505–VEFixedDomeNetworkCamera

Troubleshooting

Videocannotberecorded

CheckthattheSDcardisnotwriteprotected(thatis,readonly).

SDcardcannotbemountedReformattheSDcardandthenclickMount.

NO NO

TICE TICE

TICE

Formattingthecardwillremoveallcontent,includingallrecordings,fromtheSDcard.

AXISQ3505–VEFixedDomeNetworkCamera

TechnicalSpeciﬁcations

Function/group

Item

Specications

Models

AXISQ3505-VE9mm(3-9mmlens)

AXISQ3505-VE22mm(9-22mmlens)

Imagesensor

ProgressivescanRGBCMOS1/2.8”(effective)

Lens3-9mmlens:Varifocal,remotefocusandzoom,P-Iriscontrol,IRcorrected,megapixel

resolution,F1.3

Horizontalangleofview:105°-35°

Verticalangleofview:56°-21°

Diagonalangleofview:122°-42°

9-22mmlens:Varifocal,remotefocusandzoom,P-Iriscontrol,IRcorrected,megapixel

resolution,F1.6

Horizontalangleofview:33°-16°

Verticalangleofview:18°-9°

Diagonalangleofview:39°-16°

DayandNightAutomaticallyremovableinfrared-cutlter

Minimum

illumination

9mm:

HDTV1080p25/30fpswithWDR-ForensicCapture:Color:0.18lux,F1.3,B/W:0.04

lux,F1.3

HDTV1080p50/60fps:Color:0.36lux,F1.3,B/W:0.08lux,F1.3

22mm:

HDTV1080p25/30fpswithWDR-ForensicCapture:Color:0.28lux,F1.6,B/W:0.06

lux,F1.6

HDTV1080p50/60fps:Color:0.56lux,F1.6,B/W:0.1 1lux,F1.6

Shuttertime

HDTV1080p25/30/50/60fps:1/142850sto2s

WUXGA(1920x1200)25/30fps:1/45450sto2s

Camera

Cameraangle

adjustment

Pan360°,tilt90°,rotation100°

Video

compression

H.264(MPEG-4Part10/AVC)Baseline,MainandHighproles

MotionJPEG

Resolutions

1920x1200(WUXGA)to160x90

FramerateH.264

HDTV1080p(1920x1080)withWDR:25/30fpswithpowerlinefrequency50/60Hz

HDTV1080p(1920x1080)withoutWDR:50/60fpswithpowerlinefrequency50/60Hz

WUXGA(1920x1200)withoutWDR:25/30fpswithpowerlinefrequency50/60Hz

Framerate

MotionJPEG

HDTV1080p(1920x1080)withWDR:25/30fpswithpowerlinefrequency50/60Hz

HDTV1080p(1920x1080)withoutWDR:50/60fpswithpowerlinefrequency50/60Hz

WUXGA(1920x1200)withoutWDR:25/30fpswithpowerlinefrequency50/60Hz

Videostreaming

Multiple,individuallycongurablestreamsinH.264andMotionJPEG

Controllableframerateandbandwidth

VBR/CBRH.264

Pan/Tilt/Zoom

DigitalPTZ,opticalzoom,presetpositions

9mmlens:3xopticalzoomand2xdigitalzoom

22mmlens:2.4xopticalzoomand2xdigitalzoom

Limitedguardtour,controlqueue,on-screendirectionalindicator

Video

Imagesettings

Compression,color,brightness,sharpness,contrast,whitebalance,exposurecontrol,

exposurezones,backlightcompensation,netuningofbehavioratlowlight

Rotation:0°,90°,180°,270°,Auto,includingAxisCorridorFormat

Textandimageoverlay

Privacymask

ElectronicImageStabilization(EIS)

AXISQ3505–VEFixedDomeNetworkCamera

TechnicalSpeciﬁcations

Function/group

Item

Specications

Barreldistortioncorrection

Mirroringofimages

WDR-dynamiccapture:Upto120dB(y-zlux)dependingonscene

AudiostreamingTwo-way

Audio

compression

AACLC8/16/32kHz,8-128kbit/s

G.711PCM8kHz64kbit/s

G.726ADPCM8kHz32kbit/sor24kbit/s

Congurablebitrate

Audioinput

3.5mmjackfor:mic/linein.Max80mVppformicrophone/Max6.2Vppforlinesignal

Impedance:Min1kΏ,Mic-poweractivated;Min4kΏline

Tip:BalancedMicrophoneHot(+)In/UnbalancedMicrophoneIn/LineIn

Ring:BalancedMicrophoneCold(-)In

Sleeve:Ground

Powertoexternalelectretmicrophone:1.3V-3.0V(DC)

SNR:>40dB

Optional12Vphantompower

Audio

Audioouput3.5mmjackforlineout.Max2.8Vpp

Impedance:Max100Ώ,normal<1Ώ

SNR:>40dB

SecurityPasswordprotection,IPaddressltering,IEEE802.1Xnetworkaccesscontrol*,HTTPS

encryption*,digestauthentication,useraccesslog

*ThisproductincludessoftwaredevelopedbytheOpenSSLProjectforuseintheOpenSSL

Toolkit.(http://www.openssl.org/),andcryptographicsoftwarewrittenbyEricYoung

([email protected]).

Network

Supported

protocols

IPv4/v6,HTTP,HTTPS,SSL/TLS*,QoSLayer3DiffServ,FTP,CIFS/SMB,SMTP,Bonjour,

UPnP™,SNMPv1/v2c/v3(MIB-II),DNS,DynDNS,NTP,RTSP,RTP,TCP,UDP,IGMP,RTCP,

ICMP,DHCP,ARP,SOCKS,SSH.

*ThisproductincludessoftwaredevelopedbytheOpenSSLProjectforuseintheOpen

SSLToolkit(www.openssl.org),andcryptographicsoftwarewrittenbyEricYoung

([email protected]).

Application

Programming

Interface

OpenAPIforsoftwareintegration,includingVAPIX®andAXISCameraApplication

Platform;specicationsatwww.axis.com

AXISVideoHostingSystem(AVHS)withOne-ClickCameraConnection.

ONVIFProleS;specicationatwww.onvif.org

AXISMediaControlSDK(availableatwww.axis.com),eventtriggerdatainvideostream

QualityofService(QoS)layer3,DiffServModelEmbeddedLinuxoperatingsystem

Intelligentvideo

Videomotiondetection,activetamperingalarm,audiodetection,Gatekeeper

AXISCameraApplicationPlatform(ACAP)enablinginstallationofadditionalapplications

EventtriggersVideomotiondetection,activetamperingalarm,audiodetection

ACAP,externalinput,edgestorageevents,shockdetection,network,temperature

PTZ(movingandpresetsreached),time,systemready,detectors-livestreamaccessed,

day/night

EventsactionsFileupload:FTP,HTTP,networkshareandemail

Notication:email,HTTPandTCP

Externaloutputactivation

Pre-andpost-alarmvideobuffering

Videoandaudiorecordingtoedgestorage

PTZpreset,guardtour

Playaudioclip

WDRmode

Day/nightvisionmode

Overlaytext

SendSNMPtrap

SendVideoclip

StatusLED

System

Integration

AXISQ3505–VEFixedDomeNetworkCamera

TechnicalSpeciﬁcations

Function/group

Item

Specications

DatastreamingEventdata

Videoaccessfrom

webbrowser

Cameraliveview

Videorecordingtole(ASF)

CustomizableHTMLpages

WindowsVista,XP,Windows7,andServer2008,Server2012andWindows8

DirectX9corhigher

Forotheroperatingsystemsandbrowsersseewww.axis.com/techsup

Built-in

installationaids

Remotezoom,remotefocus,pixelcounter,levelingassistant

Installation,

managementand

maintenance

AXISCameraManagementtoolonCDandweb-basedconguration

Conguration

FirmwareupgradesoverHTTPorFTP,rmwareavailableonwww.axis.com

Casing

Polycarbonatetransparentcover

Aluminiumimpact-resistantcasingwithintegrateddehumidifyingmembrane

Aluminium/plasticinnercameramodulewithencapsulatedelectronics

CasingColor:whiteNCSS1002-B

ForrepaintinginstructionsandimpactonwarrantycontactyourAxispartner

Memory512MBRAM,256MBFlash.Batterybacked-upreal-timeclock

Power

PoweroverEthernet(PoE)IEEE802.3af/802.3atType1Class3;max11.4W

WhenpoweredbyAXIST8051PowerConverterAC/DCtoDC:

12.4W@12VDC

21.3VA@24VAC

Connectors

Network:RJ4510BASE-T/100BASE-TXPoE

I/O:Terminalblockfortwocongurableinputs/outputs(12VDCoutput,max.load50mA)

Audio:3.5mmmic/linein,3.5mmlineout

Edgestorage

microSDHCUHS-I/microSDXCUHS-Imemorycardslot(cardnotincluded)

Supportforrecordingtodedicatednetwork-attachedstorage(NAS)

Operating

conditions

-40°Cto60°C(-40°Fto140°F)Humidity10-100%RH(condensing)

Approvals

EN55022ClassB,EN55024,IEC/EN61000-6-1,IEC/EN61000-6-2

FCCPart15,SubpartB,ClassB

ICES-003ClassB

VCCIClassB

C-tickAS/NZSCISPR22ClassB

KCCKN22ClassB,KN24

IEC60068-2-1,IEC60068-2-2,IEC60068-2-6,IEC60068-2-14,IEC60068-2-27,IEC

60068-2-60,IEC60068-2-78

IEC/EN/UL60950-22

IEC/EN62262IK10+(50J)

IEC/EN60529IP66/67

ISO20653IP6K9K

NEMA250Type4X

EN50121-4andIEC62236-4

Dimensions(HxD)

120x184(4.7x7.2in)

Weight

1.7kg(3.7lb.)withweathershield

Included

accessories

Drillholetemplate,InstallationGuide,ManagementSoftwareCD,Windowsdecoder

1-userlicense

Extracablegaskets,ResistorxL-key,I/Oconnector,connectorguardtool

Weathershield

AXISConduitAdapterU-Shape30mmA

General

AXISQ3505–VEFixedDomeNetworkCamera

TechnicalSpeciﬁcations

Function/group

Item

Specications

Video

management

software(not

included)

AXISCameraCompanion(incl.),AXISCameraStationandvideomanagement

softwarefromAxis’ApplicationDevelopmentPartners(notincluded.).See

www.axis.com/products/video/software

Optional

accessories

AXISIntrusionSwitchB

AxisT90AIlluminators

AXIST91A/BMountingAccessories

AXISConduitAdapterU-Shape30mmA

AXIST94M01LRecessedMount

AXIST8051PowerConverterAC/DCtoDC

AXISMulticableBI/OAudioPower2.5m

AXIST94M01DPendantKit

AXIST98A-VESurveillanceCabinet

AXISSkinCoverB(5nos.)

SmokedDome

Optional

accessories

Axis3–yearwarrantyandAXISExtendedWarrantyoption,seewww.axis.com/warranty

Connectors

I/OConnector

4–pinterminalblockfor:

•Auxiliarypower(DCoutput)

•DigitalInput

•DigitalOutput

•0VDC(-)

2 3 4

FunctionPinNotes

Specications

0VDC(-)

0VDC

DCoutput

Canbeusedtopowerauxiliaryequipment.

Note:Thispincanonlybeusedaspowerout.

12VDC

Maxload=50mA

Digitalinput–Connecttopin1toactivate,orleaveoating

(unconnected)todeactivate.

0tomax30VDC Congurable

(InputorOutput)

3–4

Digitaloutput–Connectedtopin1whenactivated,oating

(unconnected)whendeactivated.Ifusedwithaninductive

load,e.g.arelay,adiodemustbeconnectedinparallelwith

theload,forprotectionagainstvoltagetransients.

0tomax30VDC,opendrain,

100mA

AXISQ3505–VEFixedDomeNetworkCamera

TechnicalSpeciﬁcations

12 V max 50 mA

I/Oconguredasinput

I/Oconguredasoutput

AudioConnector

3.5mmaudioconnectors

(stereo)

123

1Tip2Ring

3Sleeve

AudioInput

BalancedMicrophoneHot(+)

In/UnbalanceMicrophoneIn/LineIn

BalancedMicrophoneCold(-)In

Ground

Audio

Output

Lineout(mono)

Ground

SDCardSlot

SupportsmicroSDcardswithupto64GBofstorage.Forbestrecordingperformance,useamicroSDHCUHS-IormicroSDXCUHS-I

card.Intemperaturesbelow–25°CuseindustrialgradeSDcard.

Multicable(soldseparately)

ThemulticablecanbepurchasedfromanAxisresellerforconnectingexternalequipmenttotheAxisproduct.Thecableprovidesthe

followingconnectors:

Audioconnector-SeeConnectorsonpage66

I/Oconnector-SeeConnectorsonpage66

Powerconnector-ConnectorforACandDCpowerforconnectiontotheAXIST8051PowerConverterAC/DCtoDC(notincluded)

wires.

AXISQ3505–VEFixedDomeNetworkCamera

TechnicalSpeciﬁcations

Wires

Specications

Red

+DCorAC

Black

–DCorAC

PerformanceConsiderations

Whensettingupyoursystem,itisimportanttoconsiderhowvarioussettingsandsituationswillaffectperformance.Somefactors

affecttheamountofbandwidth(thebitrate)required,otherscanaffecttheframerate,andsomeaffectboth.Iftheloadonthe

CPUreachesitsmaximum,thiswillalsoaffecttheframerate.

Thefollowingfactorsareamongthemostimportanttoconsider:

•Highimageresolutionand/orlowercompressionlevelsresultinimagescontainingmoredata.Bandwidthaffected.

•AccessbylargenumbersofMotionJPEGand/orunicastH.264clients.Bandwidthaffected.

•Simultaneousviewingofdifferentstreams(resolution,compression)bydifferentclients.Effectonframerateand

bandwidth.

•AccessingMotionJPEGandH.264videostreamssimultaneously.Framerateandbandwidthaffected.

•Heavyusageofeventsettingsaffecttheproduct’sCPUload.Framerateaffected.

•Heavynetworkutilizationduetopoorinfrastructure.Bandwidthaffected.

•Viewingonpoorlyperformingclientcomputerslowersperceivedperformance.Framerateaffected.

UserManualVer.M1.30

AXISQ3505–VEFixedDomeNetworkCamera

Date:June2014

PartNo.54770

Axis 0618-001~EOL Q3505-VE 9mm Fixed Dome Network Camera 0618-001

Product's Documents

Axis Q3505-VE User Manual

Specifications

Axis 0618-001~EOL Questions and Answers
