1
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Mixer
Model no: SDA2632
User Manual
2
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Mixer
Model no: SDA2632
User Manual
Contents
Page No.
2
3
Contents
Reading and Storing the User Manual
3 Important Safety Instructions for Proper Use
5 Explanation of symbols
6 Description of Parts
6 Preparing for Use
7 Charging Your Hand Mixer
7 Using Your Hand Mixer
7 Automatic overload function
8 Removing the Attachments
8 Indicator lights
8 Battery life During Use
8 Charging Indicators
9 Care and Maintenance
9 Cleaning tips
9 Technical specification
9 Customer support
10 Recycling information
Back page Warranty information
3
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Mixer
Model no: SDA2632
User Manual
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Read and familiarise yourself with all operating
instructions before using this Hand Mixer.
This appliance can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance.
Keep the appliance and its cord out of reach of children
less than 8 years when it is energised or cooling down.
Do not immerse the appliance or its cable in water or any
other liquids.
Do not leave the appliance unattended during use.
Do not leave the appliance unattended whilst connected
to the power supply.
It is imperative to unplug the power supply after the
appliance has been used, before it is cleaned and whilst
being repaired.
Repairs to electrical appliances should only be performed
by a qualified electrician. Improper repairs may place user
at serious risk.
Do not operate this appliance with a damaged power
supply or cable, after a malfunction or after being
dropped or damaged in any way.
4
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Mixer
Model no: SDA2632
User Manual
Regular, periodic checks should be carried out on the
cable to ensure no damage is evident. Should there be any
signs of damage the appliance should not be used.
If the cable is damaged, it should only be replaced by the
manufacturer or a suitable qualified after-sales-service in
order to avoid a hazard
Do not allow the power cable to hang over sharp edges or
come in contact with hot surfaces.
The Hand Mixer is not to be used if it has been dropped, if
there are visible signs of damage.
Allow the unit to cool before storage.
Before cleaning, disconnect the appliance from the mains
supply and allow to cool.
This appliance is intended for household use only and
should not be used for industrial purposes.
Do not use any accessories or attachments with this
appliance other than those supplied or recommended by
supplier.
Do not use this appliance for anything other than its
intended use.
Do not push objects into any openings as damage to the
appliance and/or electric shock may occur.
Unplug after each use. Grasp the power supply, not the
cable.
Do not pull or carry the Hand Mixer by the USB cable.
Do not bend or damage the USB cable.
Never operate with wet hands, or submerge in water or
spill liquids onto the appliance.
Do not cover the appliance while in use.
Only use the attachments supplied.
Do not operate by the means of external timer or any type
of separate remote control system.
Avoid contact with moving parts.
Keep hands and utensils out of the mixing bowl while the
Hand Mixer is in use.
5
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Mixer
Model no: SDA2632
User Manual
Do not attempt to charge the Hand Mixer with any other
charge than the one provided.
WARNING: Keep hands, hair, clothes and utensils away from
moving parts. Use caution when attaching and removing the
attachments.
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste. Please ensure it is
taken to a suitable facility for disposal. Check with your Local
Authority or retailer for recycling advice or visit www.recycle-
more.co.uk to find your nearest recycling point.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
WARNING!
This designates a hazard with moderate risk, which may
result in severe injury if not adhered to.
6
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Mixer
Model no: SDA2632
User Manual
Description of Parts
Preparing for Use
Carefully unpack the motor housing unit and all parts. Remove any tape, labels
or packaging materials.
Wash all product attachments carefully except for the motor housing unit with
warm, soapy water. Rinse and dry thoroughly.
Wipe exterior surfaces of the motor housing with a soft, damp cloth to remove
dust particles collected during packing and handling.
NEVER IMMERSE THE MOTOR HOUSING, USB CHARGING CABLE IN WATER
OR ANY OTHER LIQUID.
Ensure all parts are properly assembled and in place before use.
5
6
3
7
1.
Whisk
x 1
2. Beaters x 2
3. Eject Button
4. Speed Control Switch
5. Hand Mixer Body
6. Power Indicator Lights
7. USB Connection Port
8. USB Charging Cable
1
8
4
2
7
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Mixer
Model no: SDA2632
User Manual
Charging Your Hand Mixer
1. Open the USB Connection Port (7) on the motor housing. Insert the small end of
the USB Charging Cable (8) to the motor housing.
2. Attach the USB connector (larger end) into a suitable USB charger rated to at
least 1 Amp. (NB most USB chargers are rated 1 Amp or above). The internal
battery will begin to charge.
3. The Power Indicator lights (6) will flash while charging. The lights will stop
flashing once the unit is fully charged. See (Indicator Light section for details).
NB: The unit is supplied with approximately 30% battery charge. One or two
lights will be illuminated during use. It is recommended to fully charge before
first use for best performance.
4. It will take approximately 2.5 hours to fully charge the unit.
Using Your Hand Mixer
1. To insert the two beater attachments or the whisk attachment, push into the
two holes on the underside of the motor housing until they lock fully in place
and do not fall out.
2.
To start the Hand Mixer, slide the
Speed Control Switch
(4) forward
to level 1 (low speed). To increase the speed, slide the
Speed Control
Switch
(4) forward to level 2 (medium speed) or level 3 (high speed).
3. Do not use the Hand Mixer for longer than 3 minutes at a time.
Slide the
Speed control Switch
(4) to 0 and allow to rest for 5minutes.
4. The indicator lights will extinguish as the battery life reduces. A fully
charged battery will show all three lights. As the batteries discharge, the
Power Indicator Lights (6) will extinguish indicating the Hand Mixer
needs to be charged.
Automatic overload function
The Hand Mixer has an automatic overload function should any food get stuck in
the beaters or whisk, or the current exceeds the maximum range for the motor.
The unit will turn off automatically when any overload is detected.
When the Hand Mixer detects an overload usage, the three Power Indicator Lights
(6) (low, medium and high) will flash in unison five times and then power off. Slide
the
Speed Control Switch
(4)
to 0 and allow the Hand Mixer to rest for 10
minutes and then resume mixing.
8
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Mixer
Model no: SDA2632
User Manual
Removing the Attachments
WARNING! Ensure that the hand mixer is disconnected from the USB Charging
Cable before removing or inserting the attachments.
1. Press the Eject Button (3) to remove the beaters or whisk attachment from the
Hand Mixer.
2.
The
Eject Button (3)
will only work when the
Speed Control Switch
(4) is in
the (0) position.
CAUTION: Do not operate the Hand Mixer for more than 3 minutes at one
time, allow a few minutes rest before next use. For thicker mixers operate
for 1 minute at a time, allow to rest before next use.
Indicator lights
The Power Indicator Lights (6) provide feedback for different situations:
Battery life During Use
As the motor housing is used and the battery begins to drain during performance,
the indicator lights will extinguish in sequence from the top to the bottom to
indicate how much battery capacity is left.
66% to 100% of capacity: Lights 1, 2 and 3 will all illuminate.
33% to 65% of capacity: Light 1 & 2 will illuminate.
20% to 30% of capacity: Light 1 will illuminate.
If ＜20% of capacity: Light 1 flashes and the unit needs to be charged.
Charging Indicators:
Indicator lights will also provide feedback during the charging process:
If battery capacity is less than 33%, Lights 1, 2 and 3 will flash while
charging.
If battery capacity is within 33%-65%, Light 1 will illuminate and Lights 2 and
3 will flash.
If battery capacity is within 66%-99%, Lights 1 and 2 will illuminate and only
Light 3 will flash.
If battery capacity is greater than 99%, Lights 1, 2 and 3 will illuminate.
9
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Mixer
Model no: SDA2632
User Manual
Care and Maintenance
CAUTION: Make
sure the
Speed Control Switch
(4)
is set to the 0 position and,
unplug the USB Charging Cable (8) from the Hand Mixer before cleaning.
Wash the attachments in warm soapy water and dry thoroughly.
Clean outside of the motor housing with a clean damp cloth. Never clean
with harsh or abrasive cleaners.
Do not submerge the Motor Housing Unit in water or any other liquids.
WARNING! DO NOT CLEAN ANY PART OF YOUR MIXER IN A DISHWASHER
Cleaning Tips
To ease washing it is advised to rinse parts immediately after mixing.
Use a small brush (not supplied) to remove particles lodged in the attachments.
Technical Specification
Model no.
SDA
2632
Battery
2
0
00mAh Li
-
Ion
Rated Power
200W
10
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Mixer
Model no: SDA2632
User Manual
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling facilities.
Dispose of non-recyclable plastics in the appropriate plastics collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for recycling
advice visit www.recycle-more.co.uk enter your postcode to find your
nearest recycling site.
This symbol means batteries and rechargeable batteries may not
be disposed of with household waste!
As the end user you are required by law to bring all batteries and
rechargeable batteries to a collection point run by the Local
Authority or to a retailer, so that they can be disposed of in an
environmentally friendly manner.
11
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cordless Pro Handheld Mixer
Model no: SDA2632
User Manual
WARRANTY
Thank you for purchasing your Cordless Pro Handheld Mixer
As part of our commitment to quality, we are offering you an extra 2 years warranty in addition
to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof of
purchase or receipt. If any defect should occur due to faulty workmanship or material, your faulty
vacuum should be returned to the place of purchase, replacement or refund is at the discretion of the
retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the requirements
contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and covers
the main body and housing). If you do not register your product within 28 days of the original
purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28 days
of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
Eurosonic Group Limited
Brightgate House
1 Brightgate Way
Manchester M32 0TB UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
