Party speaker
T9 PRO
OWNER’S MANUAL
INTRODUCTION PRODUCT OVERVIEW
Thank you and congratulations on your choice of W-KING T9 PRO Bluetooth Party Speaker.
Before using this speaker, please take a few minutes to read this manual, which includes
detailed messages concerning the Proper operation of the unit.
1
2
3
4
5
6
1
2
3
4
5
6
7
7
8
9
10
11
WHAT’S IN THE BOX
USING THE MICROPHONES
1. Main unit ×1
2. Wireless microphones ×2
3. Remote control ×1
4. Speaker charging adapter (15V/1.6A) ×1
5. Android live cable ×1
6. Microphone charging cable ×1
(1) Press to switch volume knob to musical instrument volume adjustment (plug in musical
instrument to active this function).
(2) The knob back to music volume control when no operation after 10 seconds.
(3) When using the headphone monitoring function, press and hold this button, the speaker and
earphone can have sound at the same time, press and hold again to turn off the speaker sound.
1. Musical Instrument Volume
(1)Press to toggle between different light patterns.
(2)6 light patterns and state, switch order:
pattern 1 -- pattern 2 -- pattern 3 -- pattern 3 – pattern 4—pattern 5 – turn off
2. Light
Press to turn on/off microphone over music priority.
3. Microphone priority
Press to switch volume knob to bass adjustment.
4. BASS
Press to toggle between Bluetooth, USB and AUX mode.
5. Mode
(1) Record voice: press (only apply when inserting USB storage device)
(2) Play recording: press and hold
(3) Delete record file: press and hold during playing record file
6. Recording
Turn the power on or off.
7. Power
Press to the previous song track.
8. Previous
Press to the next song track.
9. Next
Play, pause or resume.
10. Play/Pause
Clockwise: larger volume;
Counterclockwise: lower volume.
11. Volume knob
Connect to guitar and other musical instruments.
1. Musical instrument
(1) Power on T9, it enters Bluetooth pairing mode automatically;
(2) Choose “W-KING T9 Pro” to connect.
(3) Once successfully connected, music will stream to this speaker.
Empty connect list.
(1) T9 Pro can remember a maximum of 8 paired devices.
(2) In Bluetooth mode, when the speaker is unconnected, press and hold PLAY/PAUSE Button to
empty connect list.
Remarks:
(1) Automatically turn off when there is no connection for 10 minutes.
(2) Bluetooth transmission distance may vary with environment.
(3) When turn on this speaker next time, it will reconnect to the last connected device automatically.
If not, please try manually.
* Transmission distance is tested in open space without interference.
* The above data is based on WEIKING laboratory environment and test results; actual playtime
may vary with environment and user habit, for reference only.
1. Bluetooth Connection
Insert a needle to reset.
2. Reset
Connect to a USB storage device.
3. USB storage device
Connect to an external audio device through a 3.5mm audio cable.
4. AUX
Connect to live device through included live cable;
Connect another music source device with T9, music will switch to live device.
5. Live
Connect to headphone.
6. Headphone monitoring
Connect to charging adapter.
7. DC charging
Top panel
Back panel
www.w-king.com
USING YOUR W-KING T9 Pro
Connect your W-KING T9 Pro with Bluetooth enabled devices.
(1) In Bluetooth mode, double press POWER Button on one speaker, digital tube screen flashes
to enter TWS automatically connection process;
(2) After TWS connection build-up, the secondary speaker screen and Bluetooth icon are
constantly on, the primary speaker screen is constantly on.
(3) To exit TWS mode: double press POWER Button.
Remark:
* Two T9 Pro should in the same software and hardware version.
2. TWS Connection
Connect 2pcs T9 Pro together via TWS function
(1) Low battery notice: when battery capacity less than 20%, voltage lower than 9.9V;
(2) Low battery turn off: when battery capacity less than 10%, voltage lower than 9.3V
(3) Red LED turns on during charging, turn off automatically when fully charged.
(4) To protect battery, please charge the speaker at least once in every six months.
3. Charging the Speaker
Please use included adapter to charge the speaker.
1. Pairing
(1) Power on the microphone
(2) After around 10 seconds, press pairing button to enter pairing mode;
(3) When microphone screen flashes, power on the speaker again, then the microphone will
connect with speaker automatically;
(4) Press pairing button again to exit pairing mode, then this button will use for switch frequency.
(5) Once they are paired, they will reconnect to the speaker automatically.
1. Voice change
When using the microphones, press voice change on remote, your voice can toggle between
man voice, woman voice and original sound;
2. Sound mode
Press this button to choose a suitable sound mode base on your environment
Microphone Core
Mute
Sound mode
Previous
Microphone priority
Recording play
Switch mode
List cycle/Single cycle
Increase volume
Next
Voice change
Song order number (0-9): for number
beyond 9, press the number in combination.
Only workable for USB reader mode and TF
card mode (if have).
Live Show Sound Feedback
Applause, Laugh, Contempt,
kiss, Awkward, Dull Moment,
Cheer
Decrease volume
Recording: only workable when USB device
connected
Show current frequency and microphone state
Turn on/off: Press and hold to turn on/off
Pairing Button:
After turning on the microphone for 10 sec., press this button
to enter pairing mode. When you see the microphone screen
flashes, power on the speaker again to pair with the
microphone. Press button to exit pairing mode, the button is
for switching frequency then.
HD LED display
(1) Use the included live cable to connect your live mobile and speaker live port;
(2) Use another mobile or laptop to connect speaker via Bluetooth/AUX IN, you can use it to
play accompaniment or other music sources, then this music will transfer to live
(3) If you are using included microphones to sing and speaker, your voice will transfer to live
how with the music sources at the same time.
4. Live Function
Use T9 for better live show sound quality.
T9 Pro included 2pcs high-quality wireless microphones
USING THE REMOTE CONTROL
FUNCTION
INDICATOR
DIGITAL TUBE SCREEN
Bluetooth mode
Bluetooth
bL XX (XX stands for volume level)
Musical Instrument
Volume
Volume knob light
flashes
gt XX (XX stands for volume level, 0 to 30)
Microphone Priority N/A Microphone icon
Bass
Volume knob light
flashes
Ab XX (XX stands for volume level, 0 to 30)
Record N/A
“REC” flashes, shows recording time
Play recording
N/A
“REC” light (constant), shows playing time
Delete record file
N/A
“DEL”
Power
N/A
“LOAd”
Music volume
N/A
U XX (XX stands for volume level, 0 to 30)
TWS connection N/A
Flashes during TWS searching.
Shows bL XX (XX stands for volume level, 0 to 30)
Low battery Low battery notice Battery icon flashes
N/A rESt
Microphone voice
change
Factory reset
N/A uC-X (X stands for order)
SPECIFICATIONSSCREEN&INDICATOR
Bluetooth version: 5.0
Product size: 53.55 * 27.4 * 25.65cm
Bluetooth transmission distance: 10 meters
Remote control distance: 5 meters
Speaker drivers: woofer×2pcs, 6.5 inches; tweeter×2pcs, 2.5 inches;
Speaker output: 120W
S/N: ≥75dB
Frequency range: 60Hz-15 KHz
Charging: DC 15V/1.6A
Charging time: around 4 hours
Battery: built-in lithium battery, 9pcs battery cells total capacity 3.6V/18000mAh;
Battery pack 10.8V/6000mAh
SAFETY NOTICE
1. Please read and keep this manual for reference.
2. Do not open (or modify in any way) the unit or its DC adaptor.
3. Do not attempt to repair the unit, or replace parts within it. Refer all servicing to your retailer
or an authorized W-KING distributor.
4. Never use or store the unit in an extreme temperature, humid or dusty environment; please
not expose the unit to rain or chemical materials, and it’s dangerous to put it in vibration places,
please make sure it’s placed stable before using. Please avoid strong impact.
5. When used by children, please make sure an adult provides supervision until they are familiar
with operation methods and safe operation notice.
