DS-K3Y411X Series Flap Barrier
User Manual
Legal Informaon
About this Document
●
This Document includes instrucons for using and managing the Product. Pictures, charts,
images and all other
informaon hereinaer are for descripon and explanaon only.
●
The
informaon contained in the Document is subject to change, without noce, due to
rmware updates or other reasons. Please nd the latest version of the Document at the
Hikvision website ( hps://www.hikvision.com ). Unless otherwise agreed, Hangzhou Hikvision
Digital Technology Co., Ltd. or its aliates (hereinaer referred to as "Hikvision") makes no
warranes, express or implied.
●
Please use the Document with the guidance and assistance of professionals trained in
supporng the Product.
About this Product
●
This product can only enjoy the aer-sales service support in the country or region where the
purchase is made.
●
If the product you choose is a video product, please scan the following QR code to obtain the
"Iniaves on the Use of Video Products", and read it carefully.
Acknowledgment of Intellectual Property Rights
●
Hikvision owns the copyrights and/or patents related to the technology embodied in the
Products described in this Document, which may include licenses obtained from third pares.
●
Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part
of this Document may be excerpted, copied, translated, or modied in whole or in part by any
means without
wrien permission.
●
and other Hikvision's trademarks and logos are the properes of Hikvision in
various
jurisdicons.
●
Other trademarks and logos menoned are the properes of their respecve owners.
LEGAL DISCLAIMER
●
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS DOCUMENT AND THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS
IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR
DS-K3Y411X Series Flap Barrier User Manual
i
IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK.
IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,
INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR
LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING
NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSS.
●
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
●
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY
RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT
RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF
HUMAN RIGHTS ABUSES.
●
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE
LATTER PREVAILS.
Data
Protecon
●
To protect data, the development of Hikvision Products incorporates privacy by design
principles. For example, for Products with facial
recognion features, biometrics data is stored in
your Products with encrypon method; for ngerprint Products, only ngerprint template will be
saved, which is impossible to reconstruct a
ngerprint image.
●
As a data controller/processor, you may process personal data, including collecon, storage, use,
processing, disclosure,
deleon, etc. You are advised to pay aenon to and comply with
applicable laws and regulaons related to the protecon of personal data, including without
limitaon, conducng security controls to safeguard personal data, such as, implemenng
reasonable administrave and physical security controls, conduct periodic reviews and the
assessments of the
eecveness of your security controls.
© Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
DS-K3Y411X Series Flap Barrier User Manual
ii
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable
protecon against harmful interference in a residenal installaon. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the
instrucons, may cause harmful interference to radio communicaons. However, there is
no guarantee that interference will not occur in a parcular installaon. If this equipment does
cause harmful interference to radio or television
recepon, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the
separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
FCC
Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired
operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
DS-K3Y411X Series Flap Barrier User Manual
iii
under the EMC Direcve 2014/30/EU, RE Direcve 2014/53/EU,the RoHS Direcve
2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated
collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include
leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the
baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to
the following two condions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence.
L'exploitaon est autorisée aux deux condions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2)
l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est suscepble d'en compromere le fonconnement.
COMPLIANCE NOTICE
The thermal series products might be subject to export controls in various countries or regions,
including without
limitaon, the United States, European Union, United Kingdom and/or other
member countries of the Wassenaar Arrangement. Please consult your professional legal or
compliance expert or local government
authories for any necessary export license requirements if
you intend to transfer, export, re-export the thermal series products between dierent countries.
DS-K3Y411X Series Flap Barrier User Manual
iv
Safety Instrucon
These instrucons are intended to ensure that user can use the product correctly to avoid danger
or property loss.
The
precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury or death.
Cauons: Neglecng any of the cauons may cause injury or equipment damage.
Dangers: Follow these safeguards to prevent
serious injury or death.
Cauons: Follow these precauons to prevent
potenal injury or material damage.
Danger:
●
In the use of the product, you must be in strict compliance with the electrical safety regulaons
of the naon and region.
●
The equipment must be connected to an earthed mains socket-outlet.
●
Shock hazard! Disconnect all power sources before maintenance.
●
Do not touch the bare metal contacts of the inlets
aer the circuit breaker is turned o.
Electricity sll exists.
●
indicates hazardous live and the external wiring connected to the terminals requires
installaon by an instructed person.
●
Keep body parts away from fan blades. Disconnect the power source during servicing.
●
Keep body parts away from motors. Disconnect the power source during servicing.
●
To prevent possible hearing damage, do not listen at high volume levels for long periods.
●
All the electronic
operaon should be strictly compliance with the electrical safety regulaons,
re
prevenon regulaons and other related regulaons in your local region.
●
Do not connect several devices to one power adapter as adapter overload may cause over-heat
or
re hazard.
●
Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
If the top caps should be open and the device should be powered on for maintenance, make
sure:
1. Power
o the fan to prevent the operator from geng injured accidentally.
2. Do not touch bare high-voltage components.
3. Make sure the switch’s wiring sequence is correct
aer maintenance.
●
Please make sure that the power has been disconnected before you wire, install or dismantle the
device.
●
When the product is installed on wall or ceiling, the device shall be
rmly xed.
●
If smoke, odors or noise rise from the device, turn
o the power at once and unplug the power
cable, and then please contact the service center.
DS-K3Y411X Series Flap Barrier User Manual
v
●
Do not ingest baery, Chemical Burn Hazard.
This product contains a coin/buon cell baery. If the coin/buon cell baery is swallowed, it
can cause severe internal burns in just 2 hours and can lead to death.
Keep new and used
baeries away from children. If the baery compartment does not close
securely, stop using the product and keep it away from children. If you think
baeries might have
been swallowed or placed inside any part of the body, seek immediate medical
aenon.
●
If the product does not work properly, please contact your dealer or the nearest service center.
Never aempt to disassemble the device yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)
●
The device do not support the PoE network switch. Connecng with the PoE network switch may
damage the control board.
Cauons:
●
The equipment shall not be exposed to dripping or splashing and that no objects lled with
liquids, such as vases, shall be placed on the equipment.
●
Ensure correct wiring of the terminals for
connecon to an AC mains supply.
●
The equipment has been designed, when required, modied for connecon to an IT power
distribuon system.
●
+ idenes the posive terminal(s) of equipment which is used with, or generates direct current.
+
idenes the negave terminal(s) of equipment which is used with, or generates direct
current.
●
No naked ame sources, such as lighted candles, should be placed on the equipment.
●
This equipment is suitable for
mounng on concrete or other non-combusble surface only.
●
Install the equipment according to the instrucons in this manual.
●
To prevent injury, this equipment must be securely
aached to the oor/wall in accordance with
the installaon instrucons.
●
Stainless steel may be corroded in some circumstances. You need to clean and care the device by
using the stainless steel cleaner. It is suggested to clean the device every month.
●
Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnesm radiaon. Avoid the equipment installaon on vibraons surface or places
subject to shock (ignorance can cause equipment damage).
●
Do not place the device in extremely hot (refer to the
specicaon of the device for the detailed
operang temperature), cold, dusty or damp locaons, and do not expose it to high
electromagnec radiaon.
●
The device cover for indoor use shall be kept from rain and moisture.
●
Exposing the equipment to direct sun light, low
venlaon or heat source such as heater or
radiator is forbidden (ignorance can cause re danger).
●
Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a
malfuncon however), and aecng the endurance of sensor at the
same me.
●
Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the ngers may erode the surface coang of the device
cover.
DS-K3Y411X Series Flap Barrier User Manual
vi
●
Please use a so and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
●
Please keep all wrappers aer unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper.
Transportaon without the
original wrapper may result in damage on the device and lead to
addional costs.
●
Improper use or replacement of the baery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used baeries according to the instrucons provided by
the baery manufacturer.
●
Biometric recognion products are not completely applicable to an-spoong environments. If
you require a higher security level, use mulple authencaon modes.
●
Do not stay in the lane when the device is reboong.
●
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED
BATTERIES ACCORDING TO THE INSTRUCTIONS.
●
SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-COMBUSTIBLE SURFACE ONLY.
●
The
instrucons shall require connecon of the equipment protecve earthing conductor to the
installaon protecve earthing conductor.
DS-K3Y411X Series Flap Barrier User Manual
vii
Available Models
Product Name Model Descripon Example
Flap Barrier DS-K3Y411X-L1 Le Pedestal 1 DS-K3Y411X-L1/Dp60
DS-K3Y411X-L1/Dp60-
S12
DS-K3Y411X-L2 Le Pedestal 2 DS-K3Y411X-L2/Dp60
DS-K3Y411X-L2/Dp60-
S12
DS-K3Y411X-M1 Middle Pedestal 1 DS-K3Y411X-M1/M-
Dp60
DS-K3Y411X-M1/M-
Dp60-S12
DS-K3Y411X-M2 Middle Pedestal 2 DS-K3Y411X-M2/M-
Dp60
DS-K3Y411X-M2/M-
Dp60-S12
DS-K3Y411X-R Right Pedestal DS-K3Y411X-R/M-Dp60
DS-K3Y411X-R/M-
Dp60-S12
You can follow the picture below to select pedestals:
DS-K3Y411X Series Flap Barrier User Manual
viii
DS-K3Y411X Series Flap Barrier User Manual
ix
Contents
Chapter 1 Overview .................................................................................................................... 1
1.1 Introducon ........................................................................................................................... 1
1.2 Main Features ........................................................................................................................ 1
Chapter 2 System Wiring ............................................................................................................ 3
Chapter 3 Installaon ................................................................................................................. 6
3.1 Disassemble Pedestals ........................................................................................................... 6
3.2 Install Pedestals ..................................................................................................................... 7
Chapter 4 General Wiring ......................................................................................................... 10
4.1 Components
Introducon .................................................................................................... 10
4.2 Wiring Electric Supply .......................................................................................................... 12
4.3 Wire Interconnecng Cable ................................................................................................. 14
4.4 Face
Recognion Terminal Power Supply Wiring (Oponal) ................................................ 16
4.5 Terminal Descripon ............................................................................................................ 17
4.5.1 UART Related Terminal and Posion ........................................................................... 17
4.5.2 Main Control Board Terminal
Descripon ................................................................... 20
4.5.3 Sub Control Board Terminal Descripon ..................................................................... 21
4.5.4 BUS Terminal Descripon ............................................................................................ 22
4.5.5 Access Control Board Terminal
Descripon ................................................................ 24
4.5.6 Access Control Board UART Descripon ..................................................................... 30
4.5.7 RS-485 Wiring ............................................................................................................. 36
4.5.8 RS-232 Wiring ............................................................................................................. 37
4.5.9 Barrier Control Wiring ................................................................................................. 38
4.5.10 Alarm Output Wiring ................................................................................................. 39
4.5.11 Exit
Buon Wiring ..................................................................................................... 39
Chapter 5 Device Sengs ......................................................................................................... 40
5.1 Pair Keyfob (Oponal) .......................................................................................................... 40
DS-K3Y411X Series Flap Barrier User Manual
x
5.2 Inialize Device .................................................................................................................... 41
5.3 Switch Relay Output Mode (NO/NC) .................................................................................... 43
5.3.1 Barrier Control Relay Output Mode ............................................................................ 43
5.3.2 Alarm Relay Output Mode (NO/NC) ............................................................................ 44
Chapter 6
Acvaon ................................................................................................................. 47
6.1 Acvate via SADP ................................................................................................................. 47
6.2 Acvate Device via Client Soware ...................................................................................... 48
Chapter 7 Client Soware Conguraon ................................................................................... 50
7.1 Conguraon Flow of Client Soware ................................................................................. 50
7.2 Device Management ............................................................................................................ 50
7.2.1 Add Device .................................................................................................................. 51
7.2.2 Reset Device Password ................................................................................................ 53
7.2.3 Manage Added Devices .............................................................................................. 54
7.3 Group Management ............................................................................................................. 55
7.3.1 Add Group ................................................................................................................... 55
7.3.2 Import Resources to Group ......................................................................................... 55
7.4 Person Management ............................................................................................................ 56
7.4.1 Add
Organizaon ........................................................................................................ 56
7.4.2 Import and Export Person Idenfy Informaon .......................................................... 56
7.4.3 Get Person
Informaon from Access Control Device .................................................. 59
7.4.4 Issue Cards to Persons in Batch ................................................................................... 59
7.4.5 Report Card Loss ......................................................................................................... 60
7.4.6 Set Card Issuing Parameters ........................................................................................ 60
7.5
Congure Schedule and Template ....................................................................................... 61
7.5.1 Add Holiday ................................................................................................................. 62
7.5.2 Add Template .............................................................................................................. 62
7.6 Set Access Group to Assign Access
Authorizaon to Persons .............................................. 64
7.7
Congure Advanced Funcons ............................................................................................ 66
DS-K3Y411X Series Flap Barrier User Manual
xi
7.7.1 Congure Device Parameters ...................................................................................... 66
7.7.2 Congure Device Parameters ...................................................................................... 72
7.8 Door Control ........................................................................................................................ 73
7.8.1 Control Door Status ..................................................................................................... 74
7.8.2 Check Real-Time Access Records ................................................................................ 75
Appendix A. DIP Switch
Descripon .......................................................................................... 77
Appendix B. Event and Alarm Type ........................................................................................... 78
Appendix C. Table of Audio Index Related Content ................................................................... 79
Appendix D. Error Code Descripon .......................................................................................... 80
Appendix E. Communicaon Matrix and Device Command ....................................................... 82
DS-K3Y411X Series Flap Barrier User Manual
xii
Chapter 1 Overview
1.1 Introducon
The ap barrier with two barriers and 12 IR lights is designed to detect unauthorized entrance or
exit. By adopng the ap barrier integratedly with the access control system, person should
authencate to pass through the lane via swiping IC or ID card, scanning QR code, etc. It is widely
used in aracons, stadiums, construcon sites, residences, etc.
1.2 Main Features
●
32-bit high-speed processor
●
TCP/IP network
communicaon and network speed adapve
The communicaon data is specially encrypted to relieve the concern of privacy leak
●
Permissions validaon and an-tailgang
●
Remaining open/closed mode selectable
●
Bidireconal (Entering/Exing) lane
The barrier opening and closing speed can be
congured according to the visitor ow
●
The barrier will be locked or stop working when people are nipped
●
An-forced-accessing
The barrier will be locked automacally without open-barrier signal.
●
Self-detecon, Self-diagnoscs, and automac alarm
●
Audible and visual alarm will be triggered when
detecng intrusion, tailgang, reverse passing,
and climbing over barrier
●
IP
conict detecon
DS-K3Y411X Series Flap Barrier User Manual
1
●
Remote control and management
●
Online/oine operaon
●
LED indicates the entrance/exit and passing status
●
Barrier is in open status when powered down; If the device is installed with supercapacitor, the
barrier remains open when powered down
●
Fire alarm passing
When the re alarm is triggered, the barrier will be open automacally for emergency
evacuaon
●
Valid passing duraon sengs
System will cancel the passing permission if a person does not pass through the lane within the
valid passing
duraon
●
Opens/Closes barrier according to the schedule template
DS-K3Y411X Series Flap Barrier User Manual
2
Chapter 2 System Wiring
The preparaon before installaon and general wiring.
Steps
1.
Draw a central line on the
installaon surface of the le or right pedestal.
2.
Draw other parallel lines for installing the other pedestals.
Note
The distance between the nearest two line is L+200 mm. L represents the lane width.
3.
Slot on the installaon surface and dig installaon holes according to the hole posion diagram.
Figure 2-1 Hole Posion Diagram
4.
Bury cables. Each lane buries 1 network cable and 1 high voltage cable. For details, see the
system wiring diagram below.
DS-K3Y411X Series Flap Barrier User Manual
3
Figure 2-2 System Wiring Diagram (General Wiring)
Note
●
The supplied interconnecng cable length is 3.75 m. If you need a longer one, you can buy a
new accessory.
●
The suggested inner diameter of the low voltage conduit is larger than 30 mm.
●
If you want to bury both of the AC power cord and the low voltage cable at the entrance, the
two cables should be in separated conduits to avoid interference.
●
If more peripherals are required to connect, you should increase the conduit diameter or bury
another conduit for the external cables.
●
The external AC power cord should be double-insulated.
●
The network cable must be CAT5e or the network cable has
beer performance. And the
suggested network cable length should be less than 100 m.
DS-K3Y411X Series Flap Barrier User Manual
4
Figure 2-3 Wire Face Recognion Terminal
Note
●
The face recognion terminal installed on the le pedestal will gain power from the sub
switch, which should connect to high voltage.
●
The suggested inner diameter of the low voltage conduit is larger than 30 mm.
●
The supplied
interconnecng cable length is 3.75 m. If you need a longer one, you can extend
the cable by yourself.
●
If you want to bury both of the AC power cord and the low voltage cable at the entrance, the
two cables should be in separated conduits to avoid interference.
●
If more peripherals are required to connect, you should increase the conduit diameter or bury
another conduit for the external cables.
●
The external AC power cord should be double-insulated.
●
The network cable must be CAT5e or the network cable has
beer performance. And the
suggested network cable length should be less than 100 m.
DS-K3Y411X Series Flap Barrier User Manual
5
Chapter 3 Installaon
3.1 Disassemble Pedestals
Before installaon, you should use the key to open the pedestals.
View the pictures below to nd the lock holes.
Figure 3-1 Lock Holes
DS-K3Y411X Series Flap Barrier User Manual
6
Note
Please check and avoid metal pieces dropped into the high and low voltage modules, which will
cause short circuit.
3.2 Install Pedestals
Before You Start
Prepare for the installaon tools, check the device and the accessories, and clear the installaon
base.
Steps
Note
●
The device should be installed on the concrete surface or other non-ammable surfaces.
●
For opening the pedestal conveniently, make sure the distance between the pedestal and the
wall should be more than 10 mm.
●
The dimension is as follows.
DS-K3Y411X Series Flap Barrier User Manual
7
Figure 3-2 Dimension
1.
Prepare for the installaon tools, check the components, and prepare for the installaon base.
2.
Drill holes on the ground according to the installaon holes on the pedestals and insert the
expansion sleeves.
3.
According to the entrance and exit marks on the pedestals, move the pedestals to the
corresponded
posions.
Note
Make sure the installaon holes on the pedestals and the base are aligned with each other.
4.
Secure the pedestals with expansion bolts.
Note
●
The suggested expansion bolt's size is M12*150. You can change or transform the expansion
bolt according to your actual needs. But make sure that do not drill through the oor. If the
oor is too so to install, it is suggested to apply the construcon adhesive to strengthen.
●
Do not immerse the pedestal in the water. In special circumstances, the immersed height
should be no more than 150 mm.
●
The installaon footprint is as follows:
DS-K3Y411X Series Flap Barrier User Manual
8
Figure 3-3 Installaon Footprint
5.
Aer installaon, assemble the components and screws back to the pedestal in reverse order
(except for
protecve sheets).
DS-K3Y411X Series Flap Barrier User Manual
9
Chapter 4 General Wiring
Note
●
Aer maintenance, you should close the water-proof cover over the high/low voltage module.
●
When you should maintain or disassemble the high voltage modules, you should remove the
enre high voltage modules and maintain it outside the turnsle. You should unplug the cables
that connected to the peripherals before maintenance to avoid destroy of the device.
4.1 Components Introducon
By default, basic components of the turnsle are connected well. The pedestals can communicate
by wiring the
interconnecng cables. And the turnsle supports wiring the AC electric supply for
the whole system's power supply.
Note
The voltage uctuaon of the electric supply is between 100 VAC and 240 VAC, 50 to 60 Hz.
The picture displayed below describes each component's posion on the turnsle.
Note
The diagram is for reference only.
DS-K3Y411X Series Flap Barrier User Manual
10
Figure 4-1 Components Diagram 1
Note
The reinstalled supercapacitor needs to be powered on for at least 3 minutes before it can work
normally.
The picture displayed below describes the IR adapter and the IR sending/receiving board and their
corresponding number on the pedestal.
DS-K3Y411X Series Flap Barrier User Manual
11
Figure 4-2 Components 2
Note
If the turnsle contains two lanes, standing at the entrance posion, the IR boards on the le
pedestal are the IR sending boards. The IR boards on the right pedestal are the IR receiving boards.
The IR boards on the le side of the middle pedestal are the IR receiving boards, while the IR
boards on the right side of the middle pedestal are the IR sending boards.
4.2 Wiring Electric Supply
Wire electric supply with the switch in the pedestal. Terminal L and terminal N are on the switch,
while terminal PE should connect to a ground wire (yellow and green wire).
DS-K3Y411X Series Flap Barrier User Manual
12
Note
●
The cable bare part should be no more than 8 mm. It is suggested that you can immerse the
bare part into the liquid n. If possible, wear an insulaon cap at the end of the bare cable.
Make sure there’s no bare copper or cable aer the wiring.
●
The Terminal L and the Terminal N cannot be wired reversely. Do not wire the input and output
terminal reversely.
●
To avoid people injury and device damage, when tesng, the ground resistance of the
equipotenal points should not be larger than 2 Ω。
●
Use the device in
conjuncon with an UPS.
DS-K3Y411X Series Flap Barrier User Manual
13
4.3 Wire Interconnecng Cable
You should use interconnecng cables to connect the main lane board and the sub lane board for
components communicaon.
Note
The right/middle pedestal contains an interconnecng cable, including one network cable (5.5 m)
and one 2-core cable.
The picture displayed below describes the cable hole's posion on the pedestals.
Figure 4-3 Cable Hole of Interconnecng Cable
If the slong posion is at the middle of the pedestal, you can wire the cable through the
pedestal, and the side cable hole. For details about the wiring
instrucons, see the picture below:
DS-K3Y411X Series Flap Barrier User Manual
14
Figure 4-4 Wiring Method of Slong in Middle
Follow the instrucons below to connect the interconnecng cable.
DS-K3Y411X Series Flap Barrier User Manual
15
Figure 4-5 Connect Interconnecng Cable
4.4 Face
Recognion Terminal Power Supply Wiring (Oponal)
If connect to face recognion terminals, the face recognion terminals of right pedestal and middle
pedestal (entrance) will power supplied by 12 V terminal on
le side of the pedestal.
The face recognion terminal of le pedestal and middle pedestal (exit) will power supplied by 12
V terminal of the power adaptor of the right pedestal. The sub lane control board will power
supplied by the power adaptor.
For details about the wiring, see the picture below:
DS-K3Y411X Series Flap Barrier User Manual
16
Figure 4-6 Face Recognion Terminal Power Supply Wiring
4.5 Terminal
Descripon
The lane controller contains main lane controller and sub lane controller, which controls the IR
beams, motor, and other components' work.
4.5.1 UART Related Terminal and
Posion
View the UART posion on the lane control board and the access control board. You can also view
the UART related terminals and DIP switch
informaon.
The reserved UART terminal posions in the turnsle and their corresponded UART No. are as
follows:
DS-K3Y411X Series Flap Barrier User Manual
17
Note
The diagram is for reference only.
Figure 4-7 Interface and Corresponded UART No.
The UART related terminals are on the access control board and BUS of the lane control board. You
can switch between the RS-232 and the RS-485 communicaon modes via DIP switch.
The UART and the related DIP switch
informaon is as follows:
DS-K3Y411X Series Flap Barrier User Manual
18
Figure 4-8 UART No. Descripon
Table 4-1 UART Related
Posion/Terminals/DIP Switch Introducon
UART No. Related Terminals Terminal Posion DIP Switch No. Funcon
UART1
Note
External card
reader is
recommended to
access.
485A/232A BUS of Main Lane
Control Board
1 to 3 ON: UART1 is RS-
232A Interface
4 to 6 ON: UART1 is RS-
485A Interface
7 Reserved
8 Reserved
UART3 485C+/232C+ Access Control
Board
1 to 3 ON: UART3 is RS-
232C Interface
DS-K3Y411X Series Flap Barrier User Manual
19
UART No. Related Terminals Terminal Posion DIP Switch No. Funcon
Note
External card
reader is
recommended to
access.
4 to 6 ON: UART3 is RS-
485C Interface
485C-/232C- 7 Reserved
8 Reserved
UART5
Note
External card
reader is
recommended to
access.
485E+/232E+ BUS of Sub Lane
Control Board
1 to 3 ON: UART3 is RS-
232E Interface
4 to 6 ON: UART3 is RS-
485E Interface
485E-/232E- 7 Reserved
8 Reserved
UART6
Note
Face recognion
terminal is
recommended to
access.
485F+/232F+ BUS of Sub Lane
Control Board
1 to 3 ON: UART3 is RS-
232F Interface
4 to 6 ON: UART3 is RS-
485F Interface
485F-/232F- 7 Reserved
8 Reserved
UART7 232G+/232G- Access Control
Board
/ /
UART8 232H+/232H- Access Control
Board
/ /
4.5.2 Main Control Board Terminal Descripon
The main lane control board contains power input, BUS interface, interconnecng interface,
supercapacitor interface, barrier
posion control board interface and motor drive interface.
The picture displayed below is the main control board diagram.
DS-K3Y411X Series Flap Barrier User Manual
20
Figure 4-9 Main Control Board Terminal
4.5.3 Sub Control Board Terminal
Descripon
The sub lane control board contains power input, BUS interface, interconnecng interface,
supercapacitor interface, barrier
posion control board interface and motor drive interface.
The picture displayed below is the sub control board diagram.
DS-K3Y411X Series Flap Barrier User Manual
21
Figure 4-10 Sub Control Board Terminal
4.5.4 BUS Terminal
Descripon
You can connect the lane controller light board, fan, TAMPER, lane control board, card reader, face
recognion terminal, QR code scanner, etc. via the BUS terminal.
Note
Part of the wiring has been completed at the factory, please connect according to actual needs.
Table 4-2 BUS Terminal in Main Lane Controller
Terminal Name Descripon
Lane Controller Light Board 1 Connects lane controller light board 1
Lane Controller Light Board 2 Connects lane controller light board 2
Fan Connects fan
TAMPER1 Connects TAMPER1
TAMPER2 Connects TAMPER2
Lane Controller Board Connects main lane controller board
5 V Reserved
IR Adaptor Connects IR adaptor
DS-K3Y411X Series Flap Barrier User Manual
22
Terminal Name Descripon
UART 1
Note
External card reader or face
recognion terminal is
recommended to access. If
both should be connected, you
should congure the address
code for both of the devices.
Red 12 V: connects 12 VDC power supply terminal
Yellow 485A/232A+: card reader RS-485A+/RS-232A+ access
terminal
Blue 485A/232A-: card reader RS-485A-/RS-232A- access
terminal
Black GND: grounding
Table 4-3 BUS Terminal in Sub Lane Controller (Le Pedestal)
Terminal Name Descripon
Lane Controller Light Board 1 Connects lane controller light board 1
Lane Controller Light Board 2 Connects lane controller light board 2
Fan Connects fan
TAMPER1 Connects TAMPER1
TAMPER2 Connects TAMPER2
Lane Controller Board Connect sub lane controller board
5 V Reserved
IR Adaptor Connects IR adaptor
UART 5
Note
External card reader is
recommended to access.
Red 12 V: connects 12 VDC power supply terminal
Yellow 485E/232E+: card reader RS-485E+/RS-232E+ access
terminal
Blue 485E/232E-: card reader RS-485E-/RS-232E- access terminal
Black GND: grounding
UART 6
Note
External face recognion
terminal is recommended to
access.
Red 12 V: connects 12 VDC power supply terminal
Yellow 485F/232F+: card reader RS-485F+/RS-232F+ access
terminal
Blue 485F/232F-: card reader RS-485F-/RS-232F- access terminal
Black GND: grounding
DS-K3Y411X Series Flap Barrier User Manual
23
Table 4-4 BUS Terminal in Sub Lane Controller (Middle Pedestal)
Terminal Name Descripon
Lane Controller Light Board 1 Connects lane controller light board 1
Lane Controller Light Board 2 Connects lane controller light board 2
Lane Controller Board Connect sub lane controller board
5 V Reserved
IR Adaptor Connects IR adaptor
UART 5
Note
External card reader is
recommended to access.
Red 12 V: connects 12 VDC power supply terminal
Yellow 485E/232E+: card reader RS-485E+/RS-232E+ access
terminal
Blue 485E/232E-: card reader RS-485E-/RS-232E- access terminal
Black GND: grounding
UART 6
Note
External face recognion
terminal is recommended to
access.
Red 12 V: connects 12 VDC power supply terminal
Yellow 485F/232F+: card reader RS-485F+/RS-232F+ access
terminal
Blue 485F/232F-: card reader RS-485F-/RS-232F- access terminal
Black GND: grounding
4.5.5 Access Control Board Terminal Descripon
Access control board is mainly used for authority idencaon in places with high security levels
such as public security or judicial place, external device accessing, and
communicaon with the
upper plaorm and lane controller.
DS-K3Y411X Series Flap Barrier User Manual
24
Figure 4-11 Access Control Board Terminal
Table 4-5 Access Control Board Terminal
Descripon
Access Control Board Terminal Descripon
Power Output 1 +12 V 12 VDC Power Output /
G Grounding
RS-485 Interface RS-485 C+ Connect to Card Reader RS485+
●
RS-485 card
reader ID
factory DIP is
1 and 3. 1
represents
the passage
entrance,
and 3
represents
RS-485 C- Connect to Card Reader RS485-
GND Grounding
DS-K3Y411X Series Flap Barrier User Manual
25
Access Control Board Terminal Descripon
the passage
exit. UART 1
in the main
control board
corresponds
to the
entrance
card reader,
and UART 5
in the main
control board
corresponds
to the exit
card reader.
●
If the user
has
congured a
guest card,
the exit
needs to be
connected to
two card
readers, one
with the DIP
4 and the
other with
the DIP 3.
The card
reader 3 and
the card
receiver are
used
together, the
ordinary user
swipes the
card on the
card reader
4, and the
guest user
swipes the
card on the
DS-K3Y411X Series Flap Barrier User Manual
26
Access Control Board Terminal Descripon
card reader
3.
●
This is the
RS-485
interface,
which cannot
be switched
by dialing.
Power Output 2 5 V 5 VDC Power Output /
G Grounding
RS-232 Interface G Grounding
●
This is the
RS-232
interface,
which cannot
be switched
by dialing.
●
The RS-232
interface's
QR code
transmission
database
should no
more than 64
bit.
●
By default,
there is no
QR code
scanner on
the
le
pedestal of
the device
entrance. If
you need to
connect an
addional QR
code
scanner, you
need to
connect it
RS-232 G-
Connect to RS-232G-
RS-232 G+ Connect to Card Reader RS-232G+
G Grounding
RS-232 H- Connect to RS-232H-
RS-232 H+ Connect to Card Reader RS-232H+
DS-K3Y411X Series Flap Barrier User Manual
27
Access Control Board Terminal Descripon
through the
RS-232
interface
here.
Aer
the cable is
connected to
the RS-232
interface, it
passes
through the
embedded
pipe and
connects
with the QR
code on the
le.
Power Input +24 V 24 VDC Power Input /
GND Grounding
Event Input C1 Event Alarm Input 1 The event
alarm input
hardware
interface is
remaining
open, and only
supports access
to remaining
open signals,
which can be
linked to the
host buzzer
output, card
reader buzzer
output, alarm
relay output,
door open relay
output, etc.
G Grounding
C2 Event Alarm Input 2
Exit Buon B2 Door 2 Signal Input /
G Grounding
DS-K3Y411X Series Flap Barrier User Manual
28
Access Control Board Terminal Descripon
B1 Door 1 Signal Input
Door Lock (Relay) D1- Door 1 Relay Output (Dry Contact) If necessary,
the door lock
relay can be
used to control
the third-party
barrier switch.
D1 controls the
door opening
for ordinary
entrance, and
D2 controls the
door opening
for ordinary
exit.
D1+
D2- Door 2 Relay Output (Dry Contact) If necessary,
the door lock
relay can be
used to control
the third-party
barrier switch.
D1 controls the
door opening
for ordinary
entrance, and
D2 controls the
door opening
for ordinary
exit.
D2+
Alarm Output NO/NC1 Alarm Output Relay 1 (Dry Contact) The alarm
output
supports switch
output.
COM1
NO/NC2 Alarm Output Relay 2 (Dry Contact) The alarm
output
supports switch
output.
COM2
Loudspeaker / Connect to loudspeaker /
DS-K3Y411X Series Flap Barrier User Manual
29
Access Control Board Terminal Descripon
Network Interface LAN Network Accessing /
Fire Input XF Fire input /
G Grounding
Note
●
You can swch between RS-485 and RS-232 via the DIP switch on the access control board. For
details about DIP switch and swiching method, see Access Control Board UART Descripon .
●
For details about DIP switch operaon, see DIP Switch Descripon .
4.5.6 Access Control Board UART Descripon
You can set the device mode, switch the communicaon mode of the corresponding UART, and
inialize the device through the DIP on the access control board.
The DIP switch of the access control board is shown in the gure below:
Note
The diagram is for reference only.
DS-K3Y411X Series Flap Barrier User Manual
30
Figure 4-12 DIP Switch on Access Control Board
DIP A can set the device mode, DIP 2 to 5 can set the RS-485/RS-232 interface, and DIP B can also
be used to inialize the device.
The UART corresponding to the DIP Switch is shown in the
gure below:
DS-K3Y411X Series Flap Barrier User Manual
31
Figure 4-13 UART No. Descripon
The corresponding funcons of dierent DIP Switch are described as follows:
No.
Device Mode UART No. Funcon Binary Value
DIP A 1 to 2: Work
Mode
/ Normal Mode
Test Mode
DS-K3Y411X Series Flap Barrier User Manual
32
No. Device Mode UART No. Funcon Binary Value
3: Memory Mode Enable Memory
Mode
Disable Memory
Mode
4: Keyfob Paring
Mode
Enable Keyfob
Paring Mode
Disable Keyfob
Paring Mode
5 to 8: Passing
Mode
Controlled Bi-
direcon
Controlled
Entrance and
Prohibit Exit
Controlled
Entrance and Free
Exit
Free Bi-direcon
Free Entrance and
Controlled Exit
Free Entrance and
Prohibit Exit
Prohibited Bi-
direcon
DS-K3Y411X Series Flap Barrier User Manual
33
No. Device Mode UART No. Funcon Binary Value
Prohibit Entrance
and Controlled
Exit
Prohibit Entrance
and Free Exit
DIP B 1 to 3 UART 5 ON: UART 5 is RS-
232E Interface
/
4 to 6 ON: UART 5 is RS-
485E Interface
/
7 / Reserved /
8 / Default is OFF. You
can dial to ON for
inial operaon
/
DIP C 1 to 3 UART 6 ON: UART 6 is RS-
232F Interface
/
4 to 6 ON: UART 6 is RS-
485F Interface
/
7 / Reserved /
8 / Reserved /
DIP D 1 to 3 UART 1 ON: UART 1 is RS-
232A Interface
/
4 to 6 ON: UART 1 is RS-
485A Interface
/
7 / Reserved /
8 / Reserved /
DIP E 1 to 3 UART 3 ON: UART 3 is RS-
232C Interface
/
4 to 6 ON: UART 3 is RS-
485C Interface
/
7 / Reserved /
8 / Reserved /
DS-K3Y411X Series Flap Barrier User Manual
34
Note
For proper communicaon between turnsle and peripherals, DIP Switch No. 1 to 3, 4 to 6, 7, and
8 of DIP B, DIP C, DIP D, and DIP E cannot be turned ON at the same me.
The reserved UART terminal posions in the turnsle and their corresponded UART No. are as
follows:
Note
The diagram is for reference only.
Figure 4-14 Interface and Corresponded UART No.
DS-K3Y411X Series Flap Barrier User Manual
35
4.5.7 RS-485 Wiring
Note
●
The RS-485 interfaces are for connecng ID card reader, IC card reader, card reader, card recycler,
text screen, and face recognion terminal. Take the wiring of RS-485 card reader as an example.
●
For details about text screen, see Conguring Screen Parameters in User Manual of iVMS-4200
AC Client
Soware.
DS-K3Y411X Series Flap Barrier User Manual
36
4.5.8 RS-232 Wiring
Note
●
Access control board of pedestal can connect QR code scanner, card recycler, text screen and
face recognion terminal via RS-232 interface.
●
For details about text screen, see Conguring Screen Parameters in User Manual of iVMS-4200
AC Client
Soware.
●
Take the wiring of text screen as an example.
DS-K3Y411X Series Flap Barrier User Manual
37
4.5.9 Barrier Control Wiring
By default, the barrier has connected with the access control board. The lane control board can
control the barrier status. If possible, the device can connect with a third party lane control board
to control the third party barriers. Interface D1 controls barrier opening for entrance, while
interface D2 controls barrier opening for exit.
Note
Use the jumper cap to switch the relay status. For details, see Barrier Control Relay Output Mode .
Entering Wiring
Exing Wiring
DS-K3Y411X Series Flap Barrier User Manual
38
Chapter 5 Device Sengs
Aer installaon and wiring completed, the turnsle will learn the open and closed posion
automacally.
Aer
the learning, the turnsle is in the normal mode. You can also set the turnsle to test mode,
passing mode and memory mode, pair the keyfob, inialize the hardware, switching between
RS-485
communicaon mode and RS-232 communicaon mode, and view relay output NO/NC
diagram by seng the DIP switch on the access control board.
●
Normal Mode: The device will work properly.
●
Test Mode: Test mode is the same as the normal mode except that the device cannot report the
alarm, the event, or the people
counng informaon to the center.
●
Passing Mode: There are 9 passing modes, including controlled bi-direcon, controlled entrance
and prohibited exit, controlled entrance and free exit, free bi-direcon, free entrance and
controlled exit, free entrance and prohibited exit, prohibited
bi-direcon, prohibited entrance
and free exit.
●
Memory Mode: By default, the memory mode is enabled. When
mulple cards are presented
and authencated, it allows mulple persons passing through the lane. When it counts the
passing people number is equal to the card presented
mes, or no person passing through the
lane aer the last person passing, the barriers will be closed.
Note
You can also set the DIP switch on the access control board to control the entrance and exit
controlling type, keyfob pairing, etc. For details about the DIP switch value, see Access Control
Board UART Descripon .
5.1 Pair Keyfob (Oponal)
Pair the remote control to the device through DIP switch to open/close the barrier remotely.
Before You Start
Ask our technique supports or sales and purchase the keyfob.
Steps
Note
●
Up to 32 keyfobs can be added to the turnsle.
●
You can set the keyfob to one-to-one mode or one-to-many mode via the DIP switch on the
keyfob. Here takes one-to-one mode as an example to explain. For one-to-many mode, see the
keyfob user manual.
One-to-One Mode
DS-K3Y411X Series Flap Barrier User Manual
40
By default, the keyfob is in one-to-one mode. The keyfob's DIP switch is towards 1 (OFF). The
keyfob can control only one turnsle.
One-to-Many Mode
The keyfob's DIP switch is ON. In this mode, the keyfob can control mulple turnsles.
1.
Power o the turnsle.
2.
Set the No.4 switch of the DIP Switch on the access control board to the ON side.
3.
Power on the turnsle and it will enter the keyfob pairing mode.
4.
Hold the Close buon for more than 10 seconds. Or pair turnsle and keyfob in the client
soware, see Manage Keyfob User for more details.
The keyfob's indicator of the will
ash twice if the pairing is completed.
5.
Set the No.4 switch to OFF, and reboot the turnsle to take eect.
Note
●
Only one turnsle can pair the keyfob. If mulple turnsles are in the pairing mode, the
keyfob will select only one of them to pair.
●
For details about DIP switch value and meaning, see Access Control Board UART Descripon .
6.
Oponal: Go to System → User → Keyfob User on the remote control page of the client
soware to delete the keyfob.
5.2
Inialize Device
Steps
1.
Set the No.8 switch of the DIP 2 Switch on the access control board to the ON side.
DS-K3Y411X Series Flap Barrier User Manual
41
Figure 5-1 Inializaon Jumper Cap
2.
Disconnect the power and reboot the device.
3.
When the beep stopped, set the No.8 switch to the OFF side, and reboot the
turnsle to take
eect.
4.
Disconnect the power and power on the device again.
Cauon
The inializaon of the device will restore all the parameters to the default seng and all the
device events are deleted.
Note
Make sure no persons are in the lane when powering on the device.
DS-K3Y411X Series Flap Barrier User Manual
42
5.3 Switch Relay Output Mode (NO/NC)
5.3.1 Barrier Control Relay Output Mode
The jumper cap of the barrier control relay on the access control board is as below:
Figure 5-2 Jumper Cap Locaon (Barrier Control Relay Output Mode)
The jumper cap posion of barrier opening (NO) is as below:
DS-K3Y411X Series Flap Barrier User Manual
43
Figure 5-3 Barrier Opening (NO)
The jumper cap posion of barrier closing (NC) is as below:
Figure 5-4 Barrier Closing (NC)
Note
The default status is NC.
5.3.2 Alarm Relay Output Mode (NO/NC)
The jumper cap of the alarm relay on the access control board is as below:
DS-K3Y411X Series Flap Barrier User Manual
44
Figure 5-5 Jumper Cap Locaon (Alarm Relay Output Mode)
The jumper cap posion of alarm opening (NO) is as below:
Figure 5-6 Alarm Opening (NO)
The jumper cap posion of alarm closing (NC) is as below:
DS-K3Y411X Series Flap Barrier User Manual
45
Figure 5-7 Alarm Closing (NC)
Note
The default status is NO.
DS-K3Y411X Series Flap Barrier User Manual
46
Chapter 6 Acvaon
You should acvate the device before the rst login. Aer powering on the device, the system will
switch to Device
Acvaon page.
Acvaon via the device, SADP tool and the client soware are supported.
The default values of the device are as follows:
●
The default IP address: 192.0.0.64
●
The default port No.: 8000
●
The default user name: admin
6.1
Acvate via SADP
SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.
Before You Start
●
Get the SADP soware from the supplied disk or the ocial website hp://
www.hikvision.com/en/ , and install the SADP according to the prompts.
●
The device and the PC that runs the SADP tool should be within the same subnet.
The following steps show how to acvate a device and modify its IP address. For batch acvaon
and IP addresses modicaon, refer to User Manual of SADP for details.
Steps
1.
Run the SADP soware and search the online devices.
2.
Find and select your device in online device list.
3.
Input new password (admin password) and
conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
4.
Click Acvate to start acvaon.
DS-K3Y411X Series Flap Barrier User Manual
47
Status of the device becomes Acve aer successful acvaon.
5.
Modify IP address of the device.
1) Select the device.
2) Change the device IP address to the same subnet as your computer by either modifying the IP
address manually or checking Enable DHCP.
3) Input the admin password and click Modify to
acvate your IP address modicaon.
6.2
Acvate Device via Client Soware
For some devices, you are required to create the password to acvate them before they can be
added to the
soware and work properly.
Steps
Note
This funcon should be supported by the device.
1.
Enter the Device Management page.
2.
Click on the right of Device Management and select Device.
3.
Click Online Device to show the online device area.
The searched online devices are displayed in the list.
4.
Check the device status (shown on Security Level column) and select an
inacve device.
5.
Click
Acvate to open the Acvaon dialog.
6.
Create a password in the password eld, and conrm the password.
DS-K3Y411X Series Flap Barrier User Manual
48
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
Note
Characters containing admin and nimda are not supported to be set as acvaon password.
7.
Click OK to acvate the device.
DS-K3Y411X Series Flap Barrier User Manual
49
Chapter 7 Client Soware Conguraon
7.1 Conguraon Flow of Client Soware
Follow the ow diagram below to congure on the client soware.
Figure 7-1 Flow Diagram of Conguraon on Client Soware
7.2 Device Management
The client supports managing access control devices and video intercom devices.
DS-K3Y411X Series Flap Barrier User Manual
50
Example
You can control entrance & exit and manage aendance aer adding access control devices to the
client; you can perform video intercom with the indoor staons and door staons.
7.2.1 Add Device
The client provides three device adding modes including by IP/domain, IP segment, and ISUP
protocol. The client also supports imporng mulple devices in a batch when there are large
amount of devices to be added.
Add Device by IP Address or Domain Name
If you know the IP address or domain name of the device to add, you can add devices to the client
by specifying the IP address (or domain name), user name, password, etc.
Steps
1.
Enter Device Management module.
2.
Click Device tab on the top of the right panel.
The added devices are displayed on the right panel.
3.
Click Add to open the Add window, and then select IP/Domain as the adding mode.
4.
Enter the required
informaon.
Name
Create a descripve name for the device. For example, you can use a nickname that can show
the locaon or feature of the device.
Address
The IP address or domain name of the device.
Port
The devices to add share the same port number. The default value is 8000.
User Name
Enter the device user name. By default, the user name is admin.
Password
Enter the device password.
Cauon
The password strength of the device can be automacally checked. We highly recommend
you change the password of your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers, lower case leers, numbers,
and special characters) in order to increase the security of your product. And we recommend
DS-K3Y411X Series Flap Barrier User Manual
51
you change your password regularly, especially in the high security system, changing the
password monthly or weekly can beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
5.
Oponal: Check Transmission Encrypon (TLS) to enable transmission encrypon using TLS
(Transport Layer Security) protocol for security purpose.
Note
●
This funcon should be supported by the device.
●
If you have enabled Cercate Vericaon, you should click Open Cercate Directory to
open the default folder, and copy the cercate le exported from the device to this default
directory to strengthen the security. See for details about enabling
cercate vericaon.
●
You can log into the device to get the
cercate le by web browser.
6.
Check Synchronize Time to synchronize the device me with the PC running the client aer
adding the device to the client.
7.
Oponal: Check Import to Group to create a group by the device name, and import all the
channels of the device to this group.
Example
For access control device, its access points, alarm inputs/outputs, and encoding channels (if
exist) will be imported to this group.
8.
Finish adding the device.
-
Click Add to add the device and back to the device list page.
-
Click Add and New to save the
sengs and connue to add other device.
Import Devices in a Batch
You can add mulple devices to the client in a batch by entering the device parameters in a pre-
dened CSV le.
Steps
1.
Enter the Device Management module.
2.
Click Device tab on the top of the right panel.
3.
Click Add to open the Add window, and then select Batch Import as the adding mode.
4.
Click Export Template and then save the
pre-dened template (CSV le) on your PC.
5.
Open the exported template le and enter the required informaon of the devices to be added
on the corresponding column.
Note
For detailed descripon of the required elds, refer to the introducons in the template.
Adding Mode
Enter 0 or 1 or 2.
DS-K3Y411X Series Flap Barrier User Manual
52
Address
Edit the address of the device.
Port
Enter the device port number. The default port number is 8000.
User Name
Enter the device user name. By default, the user name is admin.
Password
Enter the device password.
Cauon
The password strength of the device can be automacally checked. We highly recommend
you change the password of your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers, lower case leers, numbers,
and special characters) in order to increase the security of your product. And we recommend
you change your password regularly, especially in the high security system, changing the
password monthly or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
Import to Group
Enter 1 to create a group by the device name. All the channels of the device will be imported
to the corresponding group by default. Enter 0 to disable this
funcon.
6.
Click and select the template le.
7.
Click Add to import the devices.
7.2.2 Reset Device Password
If you forgot the password of the detected online devices, you can reset the device password via
the client.
Steps
1.
Enter Device Management page.
2.
Click Online Device to show the online device area.
All the online devices sharing the same subnet will be displayed in the list.
3.
Select the device from the list and click
on the Operaon column.
4.
Reset the device password.
-
Click Generate to pop up the QR Code window and click Download to save the QR code to
your PC. You can also take a photo of the QR code to save it to your phone. Send the picture
to our technical support.
DS-K3Y411X Series Flap Barrier User Manual
53
Note
For the following operaons for reseng the password, contact our technical support.
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
installer and/or end-user.
7.2.3 Manage Added Devices
Aer adding devices to device list, you can manage the added devices including eding device
parameters, remote conguraon, viewing device status, etc.
Table 7-1 Manage Added Devices
Edit Device Click to edit device informaon including device name, address, user
name, password, etc.
Delete Device Check one or more devices, and click Delete to delete the selected
devices.
Remote Conguraon Click to set remote conguraon of the corresponding device. For
details, refer to the user manual of device.
View Device Status Click to view device status, including door No., door status, etc.
Note
For dierent devices, you will view dierent informaon about device
status.
View Online User Click to view the details of online user who access the device,
including user name, user type, IP address and login me.
Refresh Device
Informaon
Click to refresh and get the latest device informaon.
DS-K3Y411X Series Flap Barrier User Manual
54
7.3 Group Management
The client provides groups to manage the added resources in dierent groups. You can group the
resources into dierent groups according to the resources' locaons.
Example
For example, on the 1st oor, there mounted 16 doors, 64 alarm inputs, and 16 alarm outputs. You
can organize these resources into one group (named 1st Floor) for convenient management. You
can control door status, and do some other
operaons of the devices aer managing the resources
by groups.
7.3.1 Add Group
You can add group to organize the added device for convenient management.
Steps
1.
Enter the Device Management module.
2.
Click Device Management → Group to enter the group management page.
3.
Create a group.
-
Click Add Group and enter a group name as you want.
-
Click Create Group by Device Name and select an added device to create a new group by the
name of the selected device.
Note
The resources (such as alarm inputs/outputs, access points, etc.) of this device will be
imported to the group by default.
7.3.2 Import Resources to Group
You can import the device resources (such as alarm inputs/outputs, access points, etc.) to the
added group in a batch.
Before You Start
Add a group for managing devices. Refer to Add Group .
Steps
1.
Enter the Device Management module.
2.
Click Device Management → Group to enter the group management page.
3.
Select a group from the group list and select the resource type as Access Point, Alarm Input,
Alarm Output, etc.
4.
Click Import.
5.
Select the thumbnails/names of the resources in the thumbnail/list view.
DS-K3Y411X Series Flap Barrier User Manual
55
Note
You can click or to switch the resource display mode to thumbnail view or to list view.
6.
Click Import to import the selected resources to the group.
7.4 Person Management
You can add person informaon to the system for further operaons such as access control, video
intercom,
me and aendance, etc. You can manage the added persons such as issuing cards to
them in a batch, imporng and exporng person informaon in a batch, etc.
7.4.1 Add
Organizaon
You can add an organizaon and import person informaon to the organizaon for eecve
management of the persons. You can also add a surbodinate organizaon for the added one.
Steps
1.
Enter Person module.
2.
Select a parent organizaon in the le column and click Add in the upper-le corner to add an
organizaon.
3.
Create a name for the added organizaon.
Note
Up to 10 levels of organizaons can be added.
4.
Oponal: Perform the following operaon(s).
Edit
Organizaon Hover the mouse on an added organizaon and click to edit its name.
Delete
Organizaon
Hover the mouse on an added organizaon and click to delete it.
Note
●
The lower-level organizaons will be deleted as well if you delete an
organizaon.
●
Make sure there is no person added under the organizaon, or the
organizaon cannot be deleted.
Show Persons in
Sub Organizaon
Check Show Persons in Sub Organizaon and select an organizaon to
show persons in its sub organizaons.
7.4.2 Import and Export Person Idenfy Informaon
You can import the informaon and pictures of mulple persons to the client soware in a batch.
Meanwhile, you can also export the person
informaon and pictures and save them in your PC.
DS-K3Y411X Series Flap Barrier User Manual
56
Import Person Informaon
You can enter the informaon of mulple persons in a predened template (CSV/Excel le) to
import the
informaon to the client in a batch.
Steps
1.
Enter the Person module.
2.
Select an added organizaon in the list, or click Add in the upper-le corner to add an
organizaon and then select it.
3.
Click Import to open the Import panel.
4.
Select Person Informaon as the imporng mode.
5.
Click Download Template for
Imporng Person to download the template.
6.
Enter the person informaon in the downloaded template.
Note
●
If the person has mulple cards, separate the card No. with semicolon.
●
Items with asterisk are required.
●
By default, the Hire Date is the current date.
7.
Click to select the CSV/Excel le with person informaon from local PC.
8.
Click Import to start imporng.
Note
●
If a person No. already exists in the client's database, delete the exisng informaon before
imporng.
●
You can import informaon of no more than 2,000 persons.
Import Person Pictures
Aer imporng face pictures for the added persons to the client, the persons in the pictures can be
idened by an added face recognion terminal. You can either import person pictures one by
one, or import
mulple pictures at a me according to your need.
Before You Start
Be sure to have imported person informaon to the client beforehand.
Steps
1.
Enter the Person module.
2.
Select an added organizaon in the list, or click Add in the upper-le corner to add an
organizaon and then select it.
3.
Click Import to open the Import panel and check Face.
4.
Oponal: Enable Verify by Device to check whether face recognion device managed in the
client can recognize the face in the photo.
5.
Click
to select a face picture le.
DS-K3Y411X Series Flap Barrier User Manual
57
Note
●
The (folder of) face pictures should be in ZIP format.
●
Each picture le should be in JPG format and should be no larger than 200 KB.
●
Each picture le should be named as "Person ID_Name". The Person ID should be the same
with that of the imported person
informaon.
6.
Click Import to start imporng.
The imporng progress and result will be displayed.
Export Person Informaon
You can export the added persons' informaon to local PC as a CSV/Excel le.
Before You Start
Make sure you have added persons to an organizaon.
Steps
1.
Enter the Person module.
2.
Oponal: Select an organizaon in the list.
Note
All persons' informaon will be exported if you do not select any organizaon.
3.
Click Export to open the Export panel.
4.
Check Person Informaon as the content to export.
5.
Check desired items to export.
6.
Click Export to save the exported
le in CSV/Excel le on your PC.
Export Person Pictures
You can export face picture le of the added persons and save in your PC.
Before You Start
Make sure you have added persons and their face pictures to an organizaon.
Steps
1.
Enter the Person module.
2.
Oponal: Select an organizaon in the list.
Note
All persons' face pictures will be exported if you do not select any organizaon.
3.
Click Export to open the Export panel and check Face as the content to export.
4.
Click Export to start exporng.
DS-K3Y411X Series Flap Barrier User Manual
58
Note
●
The exported le is in ZIP format.
●
The exported face picture is named as "Person ID_Name_0" ("0" is for a full-frontal face).
7.4.3 Get Person Informaon from Access Control Device
If the added access control device has been congured with person informaon (including person
details and issued card informaon), you can get the person informaon from the device and
import them to the client for further
operaons.
Steps
Note
●
If the person name stored in the device is empty, the person name will be lled with the issued
card No. aer imporng to the client.
●
If the card number or person ID (employee ID) stored on the device already exists in the client
database, the person with this card number or person ID will not be imported to the client.
1.
Enter Person module.
2.
Select an organizaon to import the persons.
3.
Click Get from Device.
4.
Select an added access control device or the enrollment
staon from the drop-down list.
Note
If you select the enrollment staon, you should click Login, and set IP address, port No., user
name and password of the device.
5.
Click Import to start imporng the person informaon to the client.
Note
Up to 2,000 persons and 5,000 cards can be imported.
The person informaon, including person details, and the linked cards (if congured), will be
imported to the selected organizaon.
7.4.4 Issue Cards to Persons in Batch
The client provides a convenient way to issue cards to mulple persons in a batch.
Steps
1.
Enter Person module.
2.
Click Batch Issue Cards.
All the added persons with no card issued will be displayed in the right panel.
DS-K3Y411X Series Flap Barrier User Manual
59
3.
Oponal: Enter key words (name or person ID) in the input box to lter the person(s) that need
issuing cards.
4.
Oponal: Click Sengs to set the card issuing parameters. For details, refer to Issue a Card by
Local Mode.
5.
Click Inialize to inialize the card enrollment staon or card reader to make it ready for issuing
cards.
6.
Click the Card No. column and enter the card number.
-
Place the card on the card enrollment staon.
-
Swipe the card on the card reader.
-
Manually enter the card number and press the Enter key.
The person(s) in the list will be issued with card(s).
7.4.5 Report Card Loss
If the person lost his/her card, you can report the card loss so that the card's related access
authorizaon will be inacve.
Steps
1.
Enter Person module.
2.
Select the person you want to report card loss for and click Edit to open the Edit Person window.
3.
In the
Credenal → Card panel, click on the added card to set this card as lost card.
Aer reporng card loss, the access authorizaon of this card will be invalid and inacve. Other
person who gets this card cannot access the doors by swiping this lost card.
4.
Oponal: If the lost card is found, you can click to cancel the loss.
Aer cancelling card loss, the access authorizaon of the person will be valid and acve.
5.
If the lost card is added in one access group and the access group is applied to the device
already,
aer reporng card loss or cancelling card loss, a window will pop up to nofy you to
apply the changes to the device. Aer applying to device, these changes can take eect on the
device.
7.4.6 Set Card Issuing Parameters
The client provides two modes for reading a card's number: via card enrollment staon or via the
card reader of the access control device. If a card enrollment
staon is available, connect it to the
PC running the client by USB interface or COM, and place the card on the card enrollment to read
the card number. If not, you can also swipe the card on the card reader of the added access control
device to get the card number. As a result, before issuing a card to one person, you need to set the
card issuing parameters including the issuing mode and related parameters.
When adding a card to one person, click
Sengs to open the Card Issuing Sengs window.
DS-K3Y411X Series Flap Barrier User Manual
60
Local Mode: Issue Card by Card Enrollment Staon
Connect a card enrollment staon to the PC running the client. You can place the card on the card
enrollment staon to get the card number.
Card Enrollment
Staon
Select the model of the connected card enrollment staon
Note
Currently, the supported card enrollment staon models include DS-K1F100-D8, DS-K1F100-M,
DS-K1F100-D8E, and DS-K1F180-D8E.
Card Type
This eld is only available when the model is DS-K1F100-D8E or DS-K1F180-D8E.
Select the card type as EM card or IC card according to the actual card type.
Serial Port
It is only available when the model is DS-K1F100-M.
Select the COM the card enrollment
staon connects to.
Buzzing
Enable or disable the buzzing when the card number is read successfully.
Card No. Type
Select the type of the card number according to actual needs.
M1 Card Encrypon
This eld is only available when the model is DS-K1F100-D8, DS-K1F100-D8E, or DS-K1F180-D8E.
If the card is M1 card, and if you need to enable the M1 Card
Encrypon funcon, you should
enable this funcon and select the sector of the card to encrypt.
Remote Mode: Issue Card by Card Reader
Select an access control device added in the client and swipe the card on its card reader to read
the card number.
7.5
Congure Schedule and Template
You can congure the template including holiday and week schedule. Aer seng the template,
you can adopt the
congured template to access groups when seng the access groups, so that
the access group will take eect in the me duraons of the template.
Note
For access group sengs, refer to Set Access Group to Assign Access Authorizaon to Persons .
DS-K3Y411X Series Flap Barrier User Manual
61
7.5.1 Add Holiday
You can create holidays and set the days in the holidays, including start date, end date, and holiday
duraon in one day.
Steps
Note
You can add up to 64 holidays in the soware system.
1.
Click Access Control → Schedule → Holiday to enter the Holiday page.
2.
Click Add on the
le panel.
3.
Create a name for the holiday.
4.
Oponal: Enter the descripons or some nocaons of this holiday in the Remark box.
5.
Add a holiday period to the holiday list and
congure the holiday duraon.
Note
Up to 16 holiday periods can be added to one holiday.
1) Click Add in the Holiday List eld.
2) Drag the cursor to draw the me duraon, which means in that duraon of me, the
congured access group is acvated.
Note
Up to 8 me duraons can be set to one holiday period.
3) Oponal: Perform the following operaons to edit the me duraons.
●
Move the cursor to the me duraon and drag the me duraon on the meline bar to the
desired posion when the cursor turns to .
●
Click the
me duraon and directly edit the start/end me in the appeared dialog.
●
Move the cursor to the start or the end of me duraon and drag to lengthen or shorten
the
me duraon when the cursor turns to .
4) Oponal: Select the me duraon(s) that need to be deleted, and then click in the
Operaon column to delete the selected me duraon(s).
5) Oponal: Click in the Operaon column to clear all the me duraon(s) in the me bar.
6) Oponal: Click in the Operaon column to delete this added holiday period from the
holiday list.
6.
Click Save.
7.5.2 Add Template
Template includes week schedule and holiday. You can set week schedule and assign the me
duraon of access authorizaon for dierent person or group. You can also select the added
holiday(s) for the template.
DS-K3Y411X Series Flap Barrier User Manual
62
Steps
Note
You can add up to 255 templates in the soware system.
1.
Click Access Control → Schedule → Template to enter the Template page.
Note
There are two default templates: All-Day Authorized and All-Day Denied, and they cannot be
edited or deleted.
All-Day Authorized
The access authorizaon is valid in each day of the week and it has no holiday.
All-Day Denied
The access authorizaon is invalid in each day of the week and it has no holiday.
2.
Click Add on the le panel to create a new template.
3.
Create a name for the template.
4.
Enter the descripons or some nocaon of this template in the Remark box.
5.
Edit the week schedule to apply it to the template.
1) Click Week Schedule tab on the lower panel.
2) Select a day of the week and draw
me duraon(s) on the meline bar.
Note
Up to 8 me duraon(s) can be set for each day in the week schedule.
3) Oponal: Perform the following operaons to edit the me duraons.
●
Move the cursor to the
me duraon and drag the me duraon on the meline bar to the
desired posion when the cursor turns to .
●
Click the me duraon and directly edit the start/end me in the appeared dialog.
●
Move the cursor to the start or the end of
me duraon and drag to lengthen or shorten
the me duraon when the cursor turns to .
4) Repeat the two steps above to draw more
me duraons on the other days of the week.
6.
Add a holiday to apply it to the template.
Note
Up to 4 holidays can be added to one template.
1) Click Holiday tab.
2) Select a holiday in the
le list and it will be added to the selected list on the right panel.
3) Oponal: Click Add to add a new holiday.
Note
For details about adding a holiday, refer to Add Holiday .
DS-K3Y411X Series Flap Barrier User Manual
63
4) Oponal: Select a selected holiday in the right list and click to remove the selected one, or
click Clear to clear all the selected holiday(s) in the right list.
7.
Click Save to save the sengs and nish adding the template.
7.6 Set Access Group to Assign Access Authorizaon to Persons
Aer adding the person and conguring the person's credenals, you can create the access groups
to dene which person(s) can get access to which door(s) and then apply the access group to the
access control device to take
eect.
Steps
When the access group sengs are changed, you need to apply the access groups to the devices
again to take
eect. The access group changes include changes of template, access group sengs,
person's access group sengs, and related person details (including card number, face picture,
linkage between card number and linkage between card number and card password, card eecve
period, etc).
1.
Click Access Control → Authorizaon → Access Group to enter the Access Group interface.
2.
Click Add to open the Add window.
3.
In the Name text
eld, create a name for the access group as you want.
4.
Select a template for the access group.
Note
You should congure the template before access group sengs. Refer to Congure Schedule
and Template for details.
5.
In the le list of the Select Person eld, select person(s) to assign access authority.
6.
In the
le list of the Select Access Point eld, select door(s), door staon(s) or oor(s) for the
selected persons to access.
7.
Click Save.
You can view the selected person(s) and the selected access point(s) on the right side of the
interface.
DS-K3Y411X Series Flap Barrier User Manual
64
Figure 7-2 Display the Selected Person(s) and Access Point(s)
8.
Aer adding the access groups, you need to apply them to the access control device to take
eect.
1) Select the access group(s) to apply to the access control device.
2) Click Apply All to Devices start applying all the selected access group(s) to the access control
device or door
staon.
3) Click Apply All to Devices or Apply Changes to Devices.
Apply All to Devices
This
operaon will clear all the existed access groups of the selected devices and then
apply the new access group to the device.
Apply Changes to Devices
This operaon will not clear the existed access groups of the selected devices and only
apply the changed part of the selected access group(s) to the device(s).
4) View the applying status in the Status column or click Applying Status to view all the applied
access group(s).
Note
You can check Display Failure Only to lter the applying results.
The selected persons in the applied access groups will have the authorizaon to enter/exit the
selected doors/door
staons with their linked card(s).
9.
Oponal: Click to edit the access group if necessary.
DS-K3Y411X Series Flap Barrier User Manual
65
Note
If you change the persons' access informaon or other related informaon, you will view the
prompt Access Group to Be Applied on the right corner of the client.
You can click the prompt to apply the changed data to the device. You can select either Apply
Now or Apply Later.
Figure 7-4 Data Synchronizaon
7.7
Congure Advanced Funcons
You can congure the advanced funcons of access control to meet some special requirements in
dierent scene.
Note
●
For the card related funcons(the type of access control card), only the card(s) with access group
applied will be listed when adding cards.
●
The advanced funcons should be supported by the device.
●
Hover the cursor on the Advanced
Funcon, and then Click to customize the advanced
funcon(s) to be displayed.
7.7.1 Congure Device Parameters
Aer adding the access control device, you can congure the parameters of access control device,
access control points.
Congure
Parameters for Access Control Device
Aer adding the access control device, you can congure its parameters.
DS-K3Y411X Series Flap Barrier User Manual
66
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter .
Note
If you can nd Device Parameter in the Advanced Funcon list, Hover the cursor on the
Advanced Funcon, and then Click to select the Device Parameter to be displayed.
2.
Select an access device to show its parameters on the right page.
3.
Turn the switch to ON to enable the corresponding funcons.
Note
The displayed parameters may vary for dierent access control devices.
RS-485 Communicaon Redundancy
You should enable this funcon if you wire the RS-485 card reader to the access control
device redundantly.
Enable NFC
If enable the funcon, the device can recognize the NFC card. You can present NFC card on
the device.
Enable M1 Card
If enable the
funcon, the device can recognize the M1 card. You can present M1 card on the
device.
Enable EM Card
If enable the funcon, the device can recognize the EM card. You can present EM card on the
device.
Enable CPU Card
Reserved. If enable the
funcon, the device can recognize the CPU card. You can present CPU
card on the device.
Enable ID Card
Reserved. If enable the funcon, the device can recognize the ID card. You can present ID
card on the device.
4.
Click OK.
5.
Oponal: Click Copy to, and then select the access control device(s) to copy the parameters in
the page to the selected device(s).
Congure
Parameters for Door
Aer adding the access control device, you can congure its access point door parameters.
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter .
DS-K3Y411X Series Flap Barrier User Manual
67
2.
Select an access control device on the le panel, and then click to show the doors or oors of
the selected device.
3.
Select a door or oor to show its parameters on the right page.
4.
Edit the door or
oor parameters.
Note
s
The displayed parameters may vary for dierent access control devices.
Name
Edit the card reader name as desired.
Exit Buon Type
You can set the exit buon as remaining closed or remaining open. Usually, it is remaining
open.
Open Duraon
Aer swiping the normal card and relay acon, the me for locking the door starts working.
Door Le Open Timeout Alarm
The alarm can be triggered if the door has not been closed in a congured me period. If it is
set as 0, no alarm will be triggered.
Super Password
The
specic person can open the door by inpung the super password.
5.
Some of the following parameters are not listed in the Basic Informaon page, click Advanced to
edit the parameters.
Duress Code
The door can open by
inpung the duress code when there is duress. At the same me, the
client can report the duress event.
Dismiss Code
Create a dismiss code which can be used to stop the buzzer of the card reader (by entering
the dismiss code on the keypad).
Note
●
The duress code, super code, and dismiss code should be dierent.
●
The duress code, super password, and the dismiss code should be dierent from the
authencaon password.
●
The length of duress code, super password, and the dismiss code is according the device,
usually it should contains 4 to 8 digits.
6.
Click OK.
7.
Oponal: Click Copy to , and then select the door(s) to copy the parameters in the page to the
selected doors(s).
DS-K3Y411X Series Flap Barrier User Manual
68
Note
The door's status duraon sengs will be copied to the selected door(s) as well.
Congure Parameters for Card Reader
Aer adding the access control device, you can congure its card reader parameters.
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter .
2.
In the device list on the
le, click to expand the door, select a card reader and you can edit the
card reader's parameters on the right.
3.
Edit the card reader basic parameters in the Basic
Informaon page.
Note
The displayed parameters may vary for dierent access control devices. There are part of
parameters listed as follows. Refer to the user manual of the device for more details.
Name
Edit the card reader name as desired.
Minimum Card Swiping Interval
If the interval between card swiping of the same card is less than the set value, the card
swiping is invalid. You can set it as 0 to 255.
Alarm of Max. Failed
Aempts
Enable to report alarm when the card reading aempts reach the set value.
Card Reader Type/Card Reader Descripon
Get card reader type and descripon. They are read-only.
4.
Oponal: Some of the following parameters are not listed in the Basic Informaon page, click
Advanced to edit the parameters.
Enable Card Reader
If enabling the
funcon, user can present card on the card reader. If disabling the funcon,
the card reader for entrance cannot be used.
OK LED Polarity/Error LED Polarity/Buzzer Polarity
Set OK LED Polarity/Error LED Polarity/Buzzer LED Polarity of main board according to the
card reader parameters. Generally, adopts the default sengs.
Buzzing Time
Set the card reader buzzing me. The available me ranges from 0 to 5,999s. 0 represents
connuous buzzing.
Max. Interval When Entering PWD
DS-K3Y411X Series Flap Barrier User Manual
69
When you inpung the password on the card reader, if the interval between pressing two
digits is larger than the set value, the digits you pressed before will be cleared automacally.
Tampering Detecon
Enable the an-tamper detecon for the card reader.
Communicate with Controller Every
When the access control device cannot connect with the card reader for longer than the set
me, the card reader will turn oine automacally.
Fingerprint Recognion Level
Select the ngerprint recognion level in the drop-down list.
5.
Click OK.
6.
Oponal: Click Copy to, and then select the card reader(s) to copy the parameters in the page to
the selected card reader(s).
Congure
Parameters for Alarm Output
Aer adding the access control device, if the device links to alarm outputs, you can congure the
parameters.
Before You Start
Add access control device to the client, and make sure the device supports alarm output.
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter to enter access control
parameter
conguraon page.
2.
In the device list on the le, click to expand the door, select an alarm input and you can edit
the alarm input's parameters on the right.
3.
Set the alarm output parameters.
Name
Edit the card reader name as desired.
Alarm Output
Acve Time
How long the alarm output will last aer triggered.
4.
Click OK.
5.
Oponal: Set the switch on the upper right corner to ON to trigger the alarm output.
Congure
Parameters for Lane Controller
Aer adding the lane controller to the client, you can congure its parameters for passing through
the lane.
DS-K3Y411X Series Flap Barrier User Manual
70
Steps
1.
Click Access Control → Advanced Funcon → Device Parameter to enter Parameter Sengs
page.
2.
In the device list on the
le, select a lane controller and you can edit the lane controller's
parameters on the right.
3.
Edit the parameters.
Passing Mode
Select the controller which will control the barrier status of the device.
●
If you select According to DIP
Sengs, the device will follow the lane controller's DIP
sengs to control the barrier. The sengs on the soware will be invalid.
●
If you select According to Door's Schedule Sengs, the device will follow the sengs of
the soware to control the barrier. The DIP sengs of the lane controller will be invalid.
Enable Free Passing Authencaon
If you enable this funcon, when both entrance and exit's barrier mode is Remain Open, the
pedestrians should
authencate each me passing through the lane. Or an alarm will be
triggered.
Alarm Voice Prompt Time Duraon
Set how long the audio will last, which is played when an alarm is triggered .
Note
0 refers to the alarm audio will be played unl the alarm is ended.
Temperature Unit
Select the temperature unit that displayed in the device status.
Motor Rotaon Direcon
Set the motor rotaon as Clockwise or Anclockwise. The motor rotaon direcon is the
barrier's open
direcon.
Note
●
For single pedestal scenario, the motor rotaon direcon should set as Clockwise.
●
For mulple pedestals scenario, standing at the entrance, the motor rotaon direcon
from right to le should set as: Clockwise, Anclockwise, Clockwise, etc. respecvely.
Lightboard Brightness
Set the lightboard brightness.
Barrier Material
Select the material of the barrier gate. You can select the barrier material from the drop-
down list.
DS-K3Y411X Series Flap Barrier User Manual
71
Note
The barrier material may aect the device working. Select a correct barrier material or the
barrier may not open.
Lane Length
The width of the lane. You can set the lane width.
Note
The lane width may aect the device working. Set a correct lane width or the barrier may not
open.
Do Not Open Barrier in Authencates in Lane
If there is someone or something in the lane, the gate will not open even if the credenal is
authencated.
This funcon is designed to avoid more than one person passing through the gate with only
one
authencaon.
Opening/Closing Barrier Speed
Set the barrier's opening and closing speed. You can select from 1 to 10. The greater the
value, the faster the speed.
Note
The recommended value is 6.
4.
Click OK.
7.7.2
Congure Device Parameters
Aer adding the access control device, you can set its parameters such as network parameters.
Set RS-485 Parameters
You can set the access control device's RS-485 parameters including the baud rate, data bit, the
stop bit, parity type, ow control type, communicaon mode, work mode, and connecon mode.
Steps
Note
The RS-485 Sengs should be supported by the device.
1.
Enter the Access Control module.
2.
On the navigaon bar on the le, enter Advanced Funcon → More Parameters .
3.
Select an access control device in the device list and click RS-485 to enter the RS-485
Sengs
page.
DS-K3Y411X Series Flap Barrier User Manual
72
4.
Select the serial port number from the drop-down list to set the RS-485 parameters.
5.
Set the serial number, external device, authencaon center, baud rate, data bit, stop bit, parity
type, ow control type, communicaon mode, and working mode in the drop-down list.
6.
Click Save.
●
The congured parameters will be applied to the device automacally.
●
When you change the working mode or connecon mode, the device will reboot
automacally.
Enable M1 Card Encrypon
M1 card encrypon can improve the security level of authencaon.
Steps
Note
The funcon should be supported by the access control device and the card reader.
1.
Enter the Access Control module.
2.
On the
navigaon bar on the le, enter Advanced Funcon → More Parameters .
3.
Select an access control device in the device list and click M1 Card
Encrypon Vericaon to
enter the M1 Card Encrypon Vericaon page.
4.
Set the switch to on to enable the M1 card
encrypon funcon.
5.
Set the sector ID.
Note
●
The sector ID ranges from 1 to 100.
●
By default, Sector 13 is encrypted. It is recommended to encrypt sector 13.
6.
Click Save to save the sengs.
7.8 Door Control
In Monitoring module, you can view the real-me status of the doors managed by the added
access control device. You can also control the doors such as open/close the door, or remain the
door open/closed via the client remotely. The
real-me access event are displayed in this module.
You can view the access details and person details.
Note
For the user with door control permission, the user can enter the Monitoring module and control
the door. Or the icons used for control will not show. For seng the user permission, refer to
Person Management .
DS-K3Y411X Series Flap Barrier User Manual
73
7.8.1 Control Door Status
You can control the status for the door(s), including unlock door, locking door, remaining the door
unlock, remaining the door locked, remain all unlocked, etc.
Before You Start
●
Add person and assign access authorizaon to designed person, and person will have the access
authorizaon to the access points (doors). For details, refer to Person Management and Set
Access Group to Assign Access Authorizaon to Persons .
●
Make sure the
operaon user has the permission of the access points (doors).
Steps
1.
Click Monitoring to enter the status monitoring page.
2.
Select an access point group on the upper-right corner.
Note
For managing the access point group, refer to Group Management .
The doors in the selected access control group will display.
3.
Click a door icon to select a door, or press Ctrl and select mulple doors.
Note
For Remain All Unlocked and Remain All Locked, ignore this step.
4.
Click the following buons to control the door.
Unlock
When the door is locked, unlock it and it will be open for once.
Aer the open duraon, the
door will be closed and locked again automacally.
Lock
When the door is unlocked, lock it and it will be closed. The person who has the access
authorizaon can access the door with credenals.
Remain Unlocked
The door will be unlocked (no maer closed or open). All the persons can access the door
with no credenals required.
Remain Locked
The door will be closed and locked. No person can access the door even if he/she has the
authorized
credenals, except the super users.
Remain All Unlocked
All doors in the group will be unlocked (no maer closed or open). All the persons can access
the doors with no credenals required.
Remain All Locked
DS-K3Y411X Series Flap Barrier User Manual
74
All doors in the group will be closed and locked. No person can access the doors even if
he/she has the authorized credenals, except the super users.
Capture
Capture a picture manually.
Note
The Capture buon is available when the device supports capture funcon. The picture is
saved in the PC running the client. For seng the saving path, refer to Set File Saving Path in
the user manual of the client soware.
Result
The icon of the doors will change in real-me according to the operaon if the operaon is
succeeded.
7.8.2 Check Real-Time Access Records
The real-me access records can be displayed in the client, including card swiping records, face
recognion records, skin-surface temperature informaon, etc. Also, you can view the person
informaon and view the picture captured during access.
Before You Start
You have added person(s) and access control device(s) to the client. For details, refer to Person
Management and Add Device .
Steps
1.
Click Monitoring to enter monitoring module.
Real-me access records are displayed on the boom of the page. You can view record details,
including card No., person name, event
me, door locaon, temperature, authencaon type
etc.
Figure 7-5
Real-me Access Records
DS-K3Y411X Series Flap Barrier User Manual
75
Note
You can right click the column name of access event table to show or hide the column according
to actual needs.
2.
Oponal: Select an access point group from the drop-down list in the upper-right corner to
show the real
me access records of the selected group.
3.
Oponal: Check the event type and event status.
The detected events of checked type and status will be displayed in the list below.
4.
Oponal: Check Show Latest Event to view the latest access record.
The record list will be listed reverse chronologically.
5.
Oponal: Check Enable Abnormal Temperature Prompt to enable abnormal skin-surface
temperature prompt.
Note
When enabled, if there is abnormal temperature informaon, an Abnormal Temperature
window pops up when you enter Monitoring module, displaying person's picture, skin-surface
temperature, card No., person name, etc.
6.
Oponal: Click an event to view person pictures (including captured picture and prole).
Note
In Linked Capture Picture eld, you can double click the captured picture to view an enlarged
picture.
7.
Oponal: Click to view details (including person's detailed informaon and the captured
picture).
Note
In the pop-up window, you can click to view details in full screen.
DS-K3Y411X Series Flap Barrier User Manual
76
Appendix A. DIP Switch Descripon
The DIP switch is on the main lane control board. The le side to the right side is from the low bit
to the high bit.
When the switch is towards ON, it means the switch is enabled, otherwise, the switch is o. If you
set the DIP switch like the gure displayed below, its binary value is 00001100, and its decimal
value is 12.
DS-K3Y411X Series Flap Barrier User Manual
77
Appendix B. Event and Alarm Type
Event Alarm Type
Tailgang Visual and Audible
Reverse Passing Visual and Audible
Force Accessing None
Climb over Barrier Visual and Audible
Overstay Visual and Audible
Passing Timeout None
Intrusion Visual and Audible
Free Passing
Authencaon Failed
Visual
Barrier Obstructed None
DS-K3Y411X Series Flap Barrier User Manual
78
Appendix C. Table of Audio Index Related Content
Index Content
1 Authencated.
2 Card No. does not exist.
3 Card No. and ngerprint mismatch.
4 Climbing over the barrier.
5 Reverse passing.
6 Passing meout.
7 Intrusion.
8 Force accessing.
9 Tailgang.
10 No permissions.
11 Authencaon me out.
12 Authencaon failed.
13 Expired card.
14 Stay out of me.
DS-K3Y411X Series Flap Barrier User Manual
79
Appendix D. Error Code Descripon
The swing barrier will display the error code on the seven-segment display if error occurred. Refer
to the table below to
nd the descripon of each number.
Error Reason Code Error Reason Code
Normal Working 00 Lower Fih IR Beam Triggered 21
First IR Beam Triggered 01 Lower Sixth IR Beam Triggered 22
Second IR Beam Triggered 02 Lower Seventh IR Beam
Triggered
23
Third IR Beam Triggered 03 Lower Eighth IR Beam
Triggered
24
Fourth IR Beam Triggered 04 Lower Ninth IR Beam Triggered 25
Fih IR Beam Triggered 05 Lower Tenth IR Beam Triggered 26
Sixth IR Beam Triggered 06 Lower Eleventh IR Beam
Triggered
27
Seventh IR Beam Triggered 07 Lower Twelh IR Beam
Triggered
28
Eighth IR Beam Triggered 08 Lower Thirteenth IR Beam
Triggered
29
Ninth IR Beam Triggered 09 Lower Fourteenth IR Beam
Triggered
30
IR Beam Triggered 10 Lower Fieenth IR Beam
Triggered
31
Eleventh IR Beam Triggered 11 Lower Sixteenth IR Beam
Triggered
32
Twelh IR Beam Triggered 12 Light Board Oine (Entrance) 49
Thirteenth IR Beam Triggered 13 Light Board Oine (Exit) 50
Fourteenth IR Beam Triggered 14 IR Adapter Oine (Up) 51
Fieenth IR Beam Triggered 15 IR Adapter Oine (Low) 52
Sixteenth IR Beam Triggered 16 CAN Bus Excepon 53
Lower First IR Beam Triggered 17 Not Studying 54
DS-K3Y411X Series Flap Barrier User Manual
80
Error Reason Code Error Reason Code
Lower Second IR Beam
Triggered
18 Obstrucon 55
Lower Third IR Beam Triggered 19 Exceeding Studying Range 56
Lower Fourth IR Beam
Triggered
20 Motor Excepon 57
DS-K3Y411X Series Flap Barrier User Manual
81
Appendix E. Communicaon Matrix and Device
Command
Communicaon Matrix
Scan the following QR code to get the device communicaon matrix.
Note that the matrix contains all
communicaon ports of Hikvision access control and video
intercom devices.
Figure E-1 QR Code of Communicaon Matrix
Device Command
Scan the following QR code to get the device common serial port commands.
Note that the command list contains all commonly used serial ports commands for all Hikvision
access control and video intercom devices.
Figure E-2 Device Command
DS-K3Y411X Series Flap Barrier User Manual
82
UD23420B-C
