DS-K3Y501SX Series Flap Barrier
UD23011B-C
Legal Informaon
About this Document
●
This Document includes instrucons for using and managing
the Product. Pictures, charts, images and all other informaon
hereinaer are for descripon and explanaon only.
●
The informaon contained in the Document is subject to
change, without noce, due to rmware updates or other
reasons. Please nd the latest version of the Document at the
Hikvision website (
hps://www.hikvision.com ). Unless
otherwise agreed, Hangzhou Hikvision Digital Technology Co.,
Ltd. or its aliates (hereinaer referred to as "Hikvision")
makes no
warranes, express or implied.
●
Please use the Document with the guidance and assistance of
professionals trained in supporng the Product.
About this Product
●
This product can only enjoy the
aer-sales service support in
the country or region where the purchase is made.
●
If the product you choose is a video product, please scan the
following QR code to obtain the
"Iniaves on the Use of Video
Products", and read it carefully.
Acknowledgment of Intellectual Property Rights
●
Hikvision owns the copyrights and/or patents related to the
technology embodied in the Products described in this
Document, which may include licenses obtained from third
pares.
●
Any part of the Document, including text, pictures, graphics,
etc., belongs to Hikvision. No part of this Document may be
excerpted, copied, translated, or
modied in whole or in part
by any means without
wrien permission.
●
and other Hikvision's trademarks and logos are
the properes of Hikvision in various jurisdicons.
●
Other trademarks and logos menoned are the properes of
their
respecve owners.
LEGAL DISCLAIMER
i
●
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
THIS DOCUMENT AND THE PRODUCT DESCRIBED, WITH ITS
HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS
IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES
NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE
PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL
HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL,
CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF
DATA, CORRUPTION OF SYSTEMS, OR LOSS OF
DOCUMENTATION, WHETHER BASED ON BREACH OF
CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT
LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF
THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES OR LOSS.
●
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET
PROVIDES FOR INHERENT SECURITY RISKS, AND HIKVISION
SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL
OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES
RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER,
HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF
REQUIRED.
●
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL
APPLICABLE LAWS, AND YOU ARE SOLELY RESPONSIBLE FOR
ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE
LAW. ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS
PRODUCT IN A MANNER THAT DOES NOT INFRINGE ON THE
RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION,
RIGHTS OF PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR
DATA PROTECTION AND OTHER PRIVACY RIGHTS. YOU SHALL
NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES,
INCLUDING THE DEVELOPMENT OR PRODUCTION OF
WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY
ACTIVITIES IN THE CONTEXT RELATED TO ANY NUCLEAR
EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT
OF HUMAN RIGHTS ABUSES.
●
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT
AND THE APPLICABLE LAW, THE LATTER PREVAILS.
Data
Protecon
●
To protect data, the development of Hikvision Products
incorporates privacy by design principles. For example, for
Products with facial
recognion features, biometrics data is
stored in your Products with
encrypon method; for ngerprint
Products, only ngerprint template will be saved, which is
impossible to reconstruct a
ngerprint image.
●
As a data controller/processor, you may process personal data,
including collecon, storage, use, processing, disclosure,
deleon, etc. You are advised to pay aenon to and comply
with applicable laws and regulaons related to the protecon
of personal data, including without limitaon, conducng
security controls to safeguard personal data, such as,
implemenng reasonable administrave and physical security
ii
controls, conduct periodic reviews and the assessments of the
eecveness of your security controls.
© Hangzhou Hikvision Digital Technology Co., Ltd.
All rights reserved.
iii
Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide
reasonable
protecon against harmful interference in a
residenal installaon. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the
instrucons, may cause harmful interference
to radio
communicaons. However, there is no guarantee that
interference will not occur in a parcular installaon. If this
equipment does cause harmful interference to radio or television
recepon, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for
help
This equipment should be installed and operated with a minimum
distance 20cm between the radiator and your body.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is
subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operaon.
EU Conformity Statement
iv
This product and - if applicable - the supplied
accessories too are marked with "CE" and
comply therefore with the applicable
harmonized European standards listed under
the EMC
Direcve 2014/30/EU, RE Direcve
2014/53/EU,the RoHS Direcve 2011/65/EU
2012/19/EU (WEEE direcve): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European
Union. For proper recycling, return this product
to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at
designated collecon points. For more
informaon see: www.recyclethis.info
2006/66/EC (baery direcve): This product
contains a baery that cannot be disposed of as
unsorted municipal waste in the European
Union. See the product documentaon for
specic baery informaon. The baery is
marked with this symbol, which may include
leering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the
baery to your supplier or to a designated
collecon point. For more informaon
see:www.recyclethis.info
v
Safety Instrucon
These instrucons are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precauon measure is divided into Dangers and Cauons:
Dangers: Neglecng any of the warnings may cause serious injury
or death.
Cauons: Neglecng any of the cauons may cause injury or
equipment damage.
Dangers: Follow these safeguards
to prevent serious injury or death.
Cauons: Follow these precauons
to prevent potenal injury or
material damage.
Danger:
●
In the use of the product, you must be in strict compliance with
the electrical safety
regulaons of the naon and region.
●
The equipment must be connected to an earthed mains socket-
outlet.
●
Shock hazard! Disconnect all power sources before
maintenance.
●
Do not touch the bare metal contacts of the inlets
aer the
circuit breaker is turned o. Electricity sll exists.
●
indicates hazardous live and the external wiring connected
to the terminals requires
installaon by an instructed person.
●
This equipment is not suitable for use in locaons where
children are likely to be present.
●
To prevent possible hearing damage, do not listen at high
volume levels for long periods.
●
All the electronic
operaon should be strictly compliance with
the electrical safety regulaons, re prevenon regulaons and
other related
regulaons in your local region.
●
Please use the power adapter, which is provided by normal
company. The power consumpon cannot be less than the
required value.
●
Do not connect several devices to one power adapter as
adapter overload may cause over-heat or
re hazard.
●
Please make sure that the power has been disconnected before
you wire, install or dismantle the device.
If the top caps should be open and the device should be
powered on for maintenance, make sure:
1.Power
o the fan to prevent the operator from geng injured
accidentally.
2.Do not touch bare high-voltage components.
3.Make sure the switch’s wiring sequence is correct
aer
maintenance.
vi
●
Please make sure that the power has been disconnected before
you wire, install or dismantle the device.
●
When the product is installed on wall or ceiling, the device
shall be rmly xed.
●
If smoke, odors or noise rise from the device, turn o the
power at once and unplug the power cable, and then please
contact the service center.
●
Do not ingest
baery, Chemical Burn Hazard.
This product contains a coin/buon cell baery. If the coin/
buon cell baery is swallowed, it can cause severe internal
burns in just 2 hours and can lead to death.
Keep new and used
baeries away from children. If the baery
compartment does not close securely, stop using the product
and keep it away from children. If you think
baeries might
have been swallowed or placed inside any part of the body,
seek immediate medical aenon.
●
If the product does not work properly, please contact your
dealer or the nearest service center. Never aempt to
disassemble the device yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)
●
The device do not support the PoE network switch.
Connecng
with the PoE network switch may damage the control board.
Cauons:
●
The equipment shall not be exposed to dripping or splashing
and that no objects lled with liquids, such as vases, shall be
placed on the equipment.
●
Ensure correct wiring of the terminals for connecon to an AC
mains supply.
●
The equipment has been designed, when required, modied
for connecon to an IT power distribuon system.
●
+ idenes the posive terminal(s) of equipment which is used
with, or generates direct current. + idenes the negave
terminal(s) of equipment which is used with, or generates
direct current.
●
No naked ame sources, such as lighted candles, should be
placed on the equipment.
●
The
venlaon should not be impeded by covering the
venlaon openings with items, such as newspapers, table-
cloths, curtains, etc. The openings shall never be blocked by
placing the equipment on a bed, sofa, rug or other similar
surface.
●
The serial port of the equipment is used for debugging only.
●
Stainless steel may be corroded in some circumstances. You
need to clean and care the device by using the stainless steel
cleaner. It is suggested to clean the device every month.
●
Do not drop the device or subject it to physical shock, and do
not expose it to high
electromagnesm radiaon. Avoid the
equipment installaon on vibraons surface or places subject
to shock (ignorance can cause equipment damage).
●
Do not place the device in extremely hot (refer to the
specicaon of the device for the detailed operang
vii
temperature), cold, dusty or damp locaons, and do not
expose it to high electromagnec radiaon.
●
The device cover for indoor use shall be kept from rain and
moisture.
●
Exposing the equipment to direct sun light, low venlaon or
heat source such as heater or radiator is forbidden (ignorance
can cause
re danger).
●
Do not aim the device at the sun or extra bright places. A
blooming or smear may occur otherwise (which is not a
malfuncon however), and aecng the endurance of sensor
at the same
me.
●
Please use the provided glove when open up the device cover,
avoid direct contact with the device cover, because the acidic
sweat of the
ngers may erode the surface coang of the
device cover.
●
Please use a so and dry cloth when clean inside and outside
surfaces of the device cover, do not use alkaline detergents.
●
Please keep all wrappers
aer unpack them for future use. In
case of any failure occurred, you need to return the device to
the factory with the original wrapper. Transportaon without
the original wrapper may result in damage on the device and
lead to
addional costs.
●
Improper use or replacement of the baery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used
baeries according to the instrucons
provided by the baery manufacturer.
●
Biometric recognion products are not completely applicable
to
an-spoong environments. If you require a higher security
level, use mulple authencaon modes.
●
Do not stay in the lane when the device is reboong.
●
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
●
SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-
COMBUSTIBLE SURFACE ONLY.
●
The
instrucons shall require connecon of the equipment
protecve earthing conductor to the installaon protecve
earthing conductor.
viii
Available Models
Product Name Model Descripon
Flap Barrier
DS-K3Y501SX-L1 Le Pedestal 1
DS-K3Y501SX-L2 Le Pedestal 2
DS-K3Y501SX-M1 Middle Pedestal 1
DS-K3Y501SX-M2 Middle Pedestal 2
DS-K3Y501SX-R Right Pedestal
You can follow the picture below to select pedestals:
ix
Contents
1 Overview .................................................................. 1
1.1 Introducon .......................................................... 1
1.2 Main Features ....................................................... 1
2 System Wiring .......................................................... 2
3
Installaon ............................................................... 4
3.1 Disassemble Pedestals .......................................... 4
3.2 Install Pedestals .................................................... 4
4 General Wiring ......................................................... 6
4.1 Components
Introducon ..................................... 6
4.2 Wiring Electric Supply ........................................... 9
4.3 Wire Interconnecng Cable .................................. 9
4.4 Face
Recognion Terminal Power Supply Wiring
................................................................................... 10
4.5 Terminal Descripon ........................................... 10
4.5.1 Main Control Board Terminal
Descripon
............................................................................. 10
4.5.2 Sub Control Board Terminal Descripon ... 11
4.5.3 Access Control Board Terminal Descripon
............................................................................. 12
4.5.4 Access Control Board Serial Port ID
Descripon ......................................................... 16
4.5.5 RS-485 Wiring ............................................ 18
4.5.6 RS-232 Wiring ............................................ 19
4.5.7 Wiegand Wiring ......................................... 20
4.5.8 Barrier Control Wiring ............................... 20
4.5.9 Alarm Output Wiring ................................. 21
4.5.10 Exit
Buon Wiring .................................... 22
5 Device Sengs ....................................................... 22
5.1 Pair Keyfob (Oponal) ......................................... 23
5.2
Inialize Device ................................................... 24
x
5.3 Switch to RS-485/RS-232 Mode .......................... 25
5.4 Switch Relay Output Mode (NO/NC) .................. 25
5.4.1 Barrier Control Relay Output Mode ........... 25
5.4.2 Alarm Relay Output Mode (NO/NC) .......... 26
6 Acvaon ............................................................... 26
6.1 Acvate via SADP ................................................ 26
6.2 Acvate Device via Client Soware .................... 27
7 Client
Soware Conguraon ................................. 28
7.1 Conguraon Flow of Client Soware ................ 28
7.2 Device Management ........................................... 28
7.2.1 Add Device ................................................. 29
7.2.2 Reset Device Password .............................. 34
7.3 Group Management ........................................... 35
7.3.1 Add Group ................................................. 35
7.3.2 Import Resources to Group ....................... 35
7.3.3 Edit Resource Parameters .......................... 36
7.3.4 Remove Resources from Group ................. 36
7.4 Person Management ........................................... 36
7.4.1 Add
Organizaon ....................................... 37
7.4.2 Congure Basic Informaon ...................... 37
7.4.3 Issue a Card by Local Mode ....................... 37
7.4.4 Upload a Face Photo from Local PC ........... 39
7.4.5 Take a Photo via Client ............................... 39
7.4.6 Collect Face via Access Control Device ...... 40
7.4.7 Collect Fingerprint via Client ..................... 41
7.4.8 Collect Fingerprint via Access Control Device
............................................................................. 42
7.4.9
Congure Access Control Informaon ....... 42
7.4.10 Customize Person Informaon ................ 44
7.4.11 Congure Resident Informaon .............. 44
xi
7.4.12 Congure Addional Informaon ............ 45
7.4.13 Import and Export Person Idenfy
Informaon ......................................................... 45
7.4.14 Import Person Informaon ...................... 45
7.4.15 Import Person Pictures ............................ 46
7.4.16 Export Person Informaon ...................... 46
7.4.17 Export Person Pictures ............................. 47
7.4.18 Get Person
Informaon from Access Control
Device ................................................................. 47
7.4.19 Move Persons to Another Organizaon
............................................................................. 48
7.4.20 Issue Cards to Persons in Batch ............... 48
7.4.21 Report Card Loss ...................................... 49
7.4.22 Set Card Issuing Parameters .................... 49
7.5
Congure Schedule and Template ...................... 50
7.5.1 Add Holiday ............................................... 50
7.5.2 Add Template ............................................. 51
7.6 Set Access Group to Assign Access Authorizaon to
Persons ..................................................................... 52
7.7
Congure Advanced Funcons ........................... 54
7.7.1 Congure Device Parameters .................... 54
7.7.2 Congure Remaining Open/Closed ........... 59
7.7.3 Congure Mul-Factor Authencaon ...... 61
7.7.4 Congure Custom Wiegand Rule ............... 62
7.7.5
Congure Card Reader Authencaon Mode
and Schedule ...................................................... 64
7.7.6 Congure First Person In ............................ 65
7.7.7
Congure An-Passback ............................ 66
7.7.8 Congure Device Parameters .................... 67
7.8 Congure Linkage Acons for Access Control ..... 68
7.8.1 Congure Client Acons for Access Event
............................................................................. 68
xii
7.8.2 Congure Device Acons for Access Event
............................................................................. 69
7.8.3 Congure Device Acons for Card Swiping
............................................................................. 70
7.9 Door Control ....................................................... 71
7.9.1 Control Door Status ................................... 71
7.9.2 Check Real-Time Access Records ............... 73
7.10 Event Center ..................................................... 73
7.10.1 Enable Receiving Event from Devices ...... 73
7.10.2 View Real-Time Events ............................. 74
7.10.3 Search Historical Events ........................... 75
7.11 Remote
Conguraon via Client Soware ........ 78
7.11.1 Check Device Informaon ........................ 78
7.11.2 Edit Device Name .................................... 78
7.11.3 Edit Time .................................................. 78
7.11.4 Set System Maintenance ......................... 78
7.11.5 Manage Network User ............................. 79
7.11.6 Manage Keyfob User ............................... 79
7.11.7 Set Security .............................................. 80
7.11.8
Congure Lane Parameters ..................... 80
7.11.9 Congure Screen Parameters .................. 81
7.11.10
Congure Screen Parameters ................ 81
7.11.11 Congure Advanced Network ................ 82
7.11.12 Congure Audio File .............................. 82
7.11.13 Congure Passing Record ...................... 83
7.11.14
Congure Parameters for Lane Controller
............................................................................. 83
7.11.15 Congure IR Detectors ........................... 84
7.11.16 View Relay Status ................................... 85
A. Tips for Scanning Fingerprint ................................. 86
B. DIP Switch ............................................................. 87
xiii
B.1 DIP Switch Descripon ........................................ 88
B.2 DIP Switch Corresponded Funcons ................... 89
C. Event and Alarm Type ............................................ 91
D. Table of Audio Index Related Content .................... 92
E. Error Code Descripon ........................................... 93
F. Communicaon Matrix and Device Command ........ 95
xiv
1 Overview
1.1 Introducon
Figure 1-1 Appearance
The ap barrier designed to detect unauthorized entrance or exit.
By adopng the ap barrier integratedly with the access control
system, person should
authencate to pass through the lane via
presenng IC or ID card, scanning QR code, etc. It is widely used
in
aracons, stadiums, construcon sites, residences, etc.
1.2 Main Features
●
32-bit high-speed processor
●
TCP/IP network
communicaon
The communicaon data is specially encrypted to relieve the
concern of privacy leak
●
Identy authencaon before passing through the turnsle
●
Remaining open/closed mode and passing status selectable
●
The barrier will be open when people are nipped
●
An-forced-accessing
The barrier will be locked automacally without open-barrier
signal.
●
Self-detecon, Self-diagnoscs, and automac alarm
●
Audible and visual alarm will be triggered when detecng
intrusion, tailgang, reverse passing, and climbing over barrier
●
IP conicon detecon
●
Remote control and management
●
Online/oine operaon
●
LED indicates the entrance/exit and passing status
●
Barrier remains open when powered down
●
Fire alarm passing
When the
re alarm is triggered, the barrier will be open
automacally for emergency evacuaon
●
Valid passing duraon sengs
1
System will cancel the passing permission if a person does not
pass through the lane within the valid passing duraon
●
Opens/closes barrier according to the schedule template
●
Up to 3000 visitor cards and up to 60,000 non-visitor cards can
be added
●
Up to 180,000 presenng card events can be recorded
●
Adjustable indicator light brightness
2 System Wiring
The
preparaon before installaon and general wiring.
Steps
1. Draw a central line on the installaon surface of the le or
right pedestal.
2. Draw other parallel lines for installing the other pedestals.
Note
The distance between the nearest two line is L+300 mm. L
represents the lane width.
3. Slot on the installaon surface and dig installaon holes
according to the hole posion diagram.
Figure 2-1 Hole
Posion Diagram
4. Bury cables. Each lane buries 1 network cable and 1 high
voltage cable. For details, see the system wiring diagram below.
Figure 2-2 System Wiring Diagram (General Wiring)
2
Note
●
The supplied interconnecng cable length is 5.5 m.
●
The suggested inner diameter of the low voltage conduit is
larger than 30 mm.
●
If you want to bury both of the AC power cord and the low
voltage cable at the entrance, the two cables should be in
separated conduits to avoid interference.
●
If you want to bury both of the AC power cord and the low
voltage cable at the entrance, the two cables should be in
separated conduits to avoid interference.
●
The external AC power cord should be double-insulated.
●
The network cable must be CAT5e or the network cable has
beer performance. And the suggested network cable
length should be less than 100 m.
Figure 2-3 Wire Face Recognion Terminal
Note
●
The le pedestal and the middle pedestal should bury
interconnecng cables for connecng the face recognion
terminal.
●
The face recognion terminal installed on the le pedestal
will gain power from the sub switch, which should connect
to high voltage.
●
The supplied
interconnecng cable length is 5.5 m.
●
The suggested inner diameter of the low voltage conduit is
larger than 30 mm.
●
If you want to bury both of the AC power cord and the low
voltage cable at the entrance, the two cables should be in
separated conduits to avoid interference.
●
If more peripherals are required to connect, you should
increase the conduit diameter or bury another conduit for
the external cables.
3
●
The external AC power cord should be double-insulated.
●
The network cable must be CAT5e or the network cable has
beer performance. And the suggested network cable
length should be less than 100 m.
3 Installaon
3.1 Disassemble Pedestals
Before installaon, you should use the key to open the pedestals.
View the pictures below to nd the lock holes.
Figure 3-1 Lock Holes
3.2 Install Pedestals
Before You Start
Prepare for the installaon tools, check the device and the
accessories, and clear the
installaon base.
Steps
Note
●
The device should be installed on the concrete surface or other
non-ammable surfaces.
●
The dimension is as follows.
4
Figure 3-2 Dimension
1. Prepare for the installaon tools, check the components, and
prepare for the installaon base.
2. Drill holes on the ground according to the installaon holes on
the pedestals and insert the expansion sleeves.
3. Seal the
boom of the turnsle to avoid water from entering.
4. According to the entrance and exit marks on the pedestals,
move the pedestals to the corresponded posions.
Figure 3-3 Entrance Mark on Pedestal
Note
Make sure the installaon holes on the pedestals and the base
are aligned with each other.
5. Secure the pedestals with expansion bolts.
Note
●
Do not immerse the pedestal in the water. In special
circumstances, the immersed height should be no more than
150 mm.
●
The installaon footprint is as follows:
5
Figure 3-4 Installaon Footprint
6. Remove the auxiliary scks at the boom of the device aer
the device is fully installed. And then use the concrete to seal
the holes.
4 General Wiring
4.1 Components Introducon
By default, basic components of the turnsle are connected well.
The pedestals can communicate by wiring the
interconnecng
cables. And the turnsle supports wiring the AC electric supply
for the whole system's power supply.
Note
The voltage uctuaon of the electric supply is between 100 VAC
and 220 VAC, 50 to 60 Hz.
The picture displayed below describes each component's posion
on the turnsle.
Note
The diagram is for reference only.
6
Figure 4-1 Components Diagram 1
Note
For details about wiring arrangement, refers to the actual device.
The picture displayed below describes the IR adapter and the IR
sending/receiving module and their corresponding number on
the pedestal.
7
Figure 4-2 Components 2
Note
●
For details about wiring arrangement, refers to the actual
device.
●
If the turnsle contains two lanes, standing at the entrance
posion, the IR modules on the le pedestal are the IR sending
modules. The IR modules on the right pedestal are the IR
receiving modules. The IR modules on the
le side of the
middle pedestal are the IR receiving modules, while the IR
modules on the right side of the middle pedestal are the IR
sending modules.
8
●
Warning tags can be viewed on the side panel of each pedestal.
●
Safety Instrucons can be viewed on the middle panel inside
the pedestal.
4.2 Wiring Electric Supply
Wire electric supply with the switch in the pedestal. Terminal L
and terminal N are on the switch, while terminal PE should
connect to a ground wire (yellow and green wire).
Note
●
The cable bare part should be no more than 8 mm. It is
suggested that you can immerse the bare part into the liquid
n. If possible, wear an insulaon cap at the end of the bare
cable. Make sure there’s no bare copper or cable aer the
wiring.
●
The Terminal L and the Terminal N cannot be wired reversely.
Do not wire the input and output terminal reversely.
●
To avoid people injury and device damage, when tesng, the
ground resistance of the
equipotenal points should not be
larger than 2 Ω。
●
Use the device in
conjuncon with an UPS.
4.3 Wire Interconnecng Cable
You should use interconnecng cables to connect the main lane
board and the sub lane board for components communicaon.
The picture displayed below describes the cable hole's posion
on the pedestals.
Figure 4-3 Cable Hole of Interconnecng Cable
Follow the instrucons below to connect the interconnecng
cable.
9
Figure 4-4 Connect Interconnecng Cable
4.4 Face Recognion Terminal Power Supply
Wiring
You should wire the power supply terminal on the 12 V power
supply component if you connect the
turnsle to the face
recognion terminal.
The terminal's posion is shown as follows:
Figure 4-5 Face Recognion Terminal Power Supply Wiring
Posion
4.5 Terminal Descripon
The lane controller contains main lane controller and sub lane
controller, which controls the IR beams, motor, and other
components' work.
4.5.1 Main Control Board Terminal
Descripon
The main lane control board contains power supply interface,
supercapacitor interface, brake interface (reserved), motor drive
interface, light board interface (reserved), motor encoder
interface, door open
posion detecon interface (reserved),
debug port, lane communicaon interface, interconnecng
interface, and DIP switch (reserved).
The picture displayed below is the main control board diagram.
10
Figure 4-6 Main Control Board
4.5.2 Sub Control Board Terminal
Descripon
The sub lane control board contains power supply interface,
supercapacitor interface, brake interface (reserved), motor drive
interface, light board interface (reserved), motor encoder
interface, door open
posion detecon interface (reserved),
debug port, lane communicaon interface, and interconnecng
interface.
The picture displayed below is the sub control board diagram.
11
Figure 4-7 Sub Control Board
4.5.3 Access Control Board Terminal
Descripon
12
Figure 4-8 Access Control Board
Table 4-1 Access Control Board Terminal
Descripon
Access Control Board Terminal Descripon
Power
Output 1
+12 V Power Output
GND Grounding
Wiegand
Card
Reader 1
OK
Indicator of Card Reader
Control Output (Invalid Card
Output)
ERR
Indicator of Card Reader
Control Output (Valid Card
Output)
BZ
Card Reader Buzzer Control
Output
W1
Wiegand Head Read Data
Input Data1
W0
Wiegand Head Read Data
Input Data0
13
Access Control Board Terminal Descripon
GND Grounding
Wiegand
Card
Reader 2
OK
Indicator of Card Reader
Control Output (Invalid Card
Output)
ERR
Indicator of Card Reader
Control Output (Valid Card
Output)
BZ
Card Reader Buzzer Control
Output
W1
Wiegand Head Read Data
Input Data1
W0
Wiegand Head Read Data
Input Data0
GND Grounding
RS-485
Interface
GND Grounding
RS-485 B-
Connect to Card Reader
RS485-
RS-485 B+
Connect to Card Reader
RS485+
GND Grounding
RS-485 C-
Connect to Card Reader
RS485-
RS-485 C+
Connect to Card Reader
RS485+
Power
Output 2
5 V 5 VDC Power Output
GND 5 VDC Grounding
RS-232
Interface
GND Grounding
RS-232 G-
Connect to Card Reader
RS232-
RS-232 G+
Connect to Card Reader
RS232+
GND Grounding
RS-232 H-
Connect to Card Reader
RS232-
RS-232 H+
Connect to Card Reader
RS232+
14
Access Control Board Terminal Descripon
Power
Input
+24 V 24 VDC Power Input
GND Grounding
Event
Input
C1 Event Alarm Input 4
GND Grounding
C2 Fire Input
C3 Event Alarm Input 2
GND Grounding
C4 Event Alarm Input 1
Exit
Buon
B2 Door 2 Signal Input
GND Grounding
B1 Door 1 Signal Input
Door Lock
(Relay)
D1-
Door 1 Relay Output (Dry
Contact)
D1+
D2-
Door 2 Relay Output (Dry
Contact)
D2+
Alarm
Output
NO/NC1
Alarm Output Relay 1 (Dry
Contact)
COM1
NO/NC2
Alarm Output Relay 2 (Dry
Contact)
COM2
NO/NC3
Alarm Output Relay 3 (Dry
Contact)
COM3
NO/NC4
Alarm Output Relay 4 (Dry
Contact)
COM4
Network
Interface
LAN Network Accessing
Note
●
The alarm input hardware interface is normally open by
default. So only the normally open signal is allowed. It can be
linked to the buzzer of the card reader and access controller,
and the alarm relay output and open door relay output.
●
The DIP of RS-485 card ID is set as 1 and 4 by default. 1 is for
entering, and 4 is for exing. If the user has congured visitor
card, you should connect two card readers on the exing side.
15
Set the DIP switch of one of the card reader as 4, and set the
other one's as 3.
Card Reader 3 should be used together with the card recycler.
Normal users should present card on Card Reader 4, while
visitors should present card on Card Reader 3.
●
The Wiegand card reader 1 and 2 refer to the entering and
exing card reader respecvely.
●
The alarm output supports relay output.
●
For any requirements, the door lock can control the door
barrier status of the third party. D1 controls the barrier
opening for entrance, while D2 controls the door opening for
exit. For details, see Barrier Control Relay Output Mode.
●
C3 and C4 in the event input can also be people
counng
interface. C3 controls people counng for entrance, while C4
controls people counng for exit. When the access control
board detects signals in C3 and C4, the people number will be
accumulated. For detailed
informaon about people counng
and people number, see Conguring People Counng
Parameters in User Manual of iVMS-4200 AC Client Soware.
●
For detailed informaon about the DIP switch, see DIP Switch.
4.5.4 Access Control Board Serial Port ID
Descripon
You can use the jumper cap on the access control board to switch
the interface
communicaon mode. For details about switching
between RS-232 and RS-485 communicaon type, see Switching
RS-485/RS-232 Mode.
16
Figure 4-9 Access Control Board
According to the picture above, the RS-485 serial port
corresponds to UART2 and UART3. RS-232 serial port is
corresponded to UART7 and UART8. Wiring Interface is
corresponded to UART1, UART4, UART6, UART6, and Lane.
The access control board
descripons are as follows:
UART2/UART3 Jumper Cap
Reserved serial port. Use the jumper cap to switch the serial
port communicaon mode. You can switch between the RS-485
communicaon mode and the RS-232 communicaon mode.
By default, it is in RS-485 communicaon mode.
UART6 Jumper Cap
Use the jumper cap to switch the serial port communicaon
mode with the sub lane controller. You can switch between the
RS-232 communicaon mode and the RS-485 communicaon
mode. By default, it is in RS-232 communicaon mode.
UART5 Jumper Cap
Use the jumper cap to switch the serial port
communicaon
mode with the sub lane controller. You can switch between the
RS-485 communicaon mode and the RS-232 communicaon
mode. By default, it is in RS-485 communicaon mode.
UART1 Jumper Cap
17
Use the jumper cap to switch the serial port communicaon
mode with the main lane controller. You can switch between
the RS-485 communicaon mode and the RS-232
communicaon mode. By default, it is in RS-485
communicaon mode.
Lane
Use the jumper cap to switch the serial port communicaon
mode with the lane controller. By default, the interface is wired
and it is in RS-485
communicaon mode. If wiring other
controllers (compable with Hikvision communicaon
protocol), use the jumper cap to switch between RS-485 and
RS-232
communicaon mode.
UART4
The serial port is in the wiring interface according to the
picture above, which has a
xed RS-232 communicaon mode
to communicate with the main lane controller. It contains no
jumper cap and cannot change the
communicaon mode.
UART7/UART8
Reserved serial port. The serial port has a xed RS-232
communicaon mode. It contains no jumper cap and cannot
change the communicaon mode. The RS-232 interface's QR
code transmission database should no more than 64 bit.
The reserved interface
posions in the turnsle and their
corresponded UART No. are as follows:
Note
The diagram is for reference only.
Figure 4-10 Interface and Corresponded UART No.
4.5.5 RS-485 Wiring
18
Note
●
There are four RS-485 interfaces, which are for connecng ID
card reader, IC card reader, QR code scanner, ngerprint and
card reader, card recycler, ngerprint reader, and face
recognion terminal. Take the wiring of RS-485 card reader as
an example.
●
When connecng the RS-485 interface with a card reader, the
default entrance address is 1 and the exit address is 4.
●
If there are more than 1 RS-485 devices connected, the RS-485
ID cannot be
conicted.
4.5.6 RS-232 Wiring
Note
There are three RS-232 interfaces (UART4, UART7, and UART8).
UART7 and UART8 can connect QR code scanner, and card
recycler, while UART4 can connect QR code scanner, card recycler,
and face recognion terminal.
19
4.5.7 Wiegand Wiring
Note
Connect the OK/ERR/BZ if the access controller should control the
LED and buzzer of the Wiegand card reader.
4.5.8 Barrier Control Wiring
By default, the barrier has connected with the access control
board. The lane control board can control the barrier status. If
possible, the device can connect with a third party lane control
board to control the third party barriers. Interface D1 controls
barrier opening for entrance, while interface D2 controls barrier
opening for exit.
20
Note
For details about changing the relay output status via the jumper
cap, see Alarm Relay Output Mode (NO/NC).
4.5.10 Exit Buon Wiring
You can view the exit buon wiring diagram.
Figure 4-11 Exit Buon Wiring
5 Device Sengs
Aer installaon and wiring completed, the turnsle will learn
the open and closed posion automacally.
Aer the learning, the turnsle is in the normal mode. You can
also set the
turnsle to test mode, passing mode and memory
22
mode, pair the keyfob, inialize the hardware, switching between
RS-485 communicaon mode and RS-232 communicaon mode,
and view relay output NO/NC diagram by seng the DIP switch
on the access control board.
●
Normal Mode: The device will work properly.
●
Test Mode: Test mode is the same as the normal mode except
that the device cannot report the alarm, the event, or the
people
counng informaon to the center.
●
Passing Mode: There are 9 passing modes, including controlled
bi-direcon, controlled entrance and prohibited exit, controlled
entrance and free exit, free
bi-direcon, free entrance and
controlled exit, free entrance and prohibited exit, prohibited bi-
direcon, prohibited entrance and free exit.
●
Memory Mode: By default, the memory mode is enabled.
When mulple cards are presented and authencated, it
allows
mulple persons passing through the lane. When it
counts the passing people number is equal to the card
presented mes, or no person passing through the lane aer
the last person passing, the barriers will be closed.
Note
You can also set the DIP switch on the access control board to
control the entrance and exit controlling type, keyfob pairing, etc.
For details about the DIP switch value, see DIP Switch.
5.1 Pair Keyfob (Oponal)
Pair the remote control to the device through DIP switch to open/
close the barrier remotely.
Before You Start
Ask our technique supports or sales and purchase the keyfob.
Steps
Note
Up to 32 keyfobs can be added to the turnsle.
1. Power o the turnsle.
2. Set the No.4 switch of the DIP Switch on the access control
board to the ON side.
3. Power on the turnsle and it will enter the keyfob pairing
mode.
4. Hold the Close
buon for more than 10 seconds. Or pair
turnsle and keyfob in the client soware, see Manage Keyfob
User of the user manual for more details.
The keyfob's indicator of the will
ash twice if the pairing is
completed.
5. Set the No.4 switch to OFF, and reboot the turnsle to take
eect.
23
Note
●
Only one turnsle can pair the keyfob. If mulple turnsles
are in the pairing mode, the keyfob will select only one of
them to pair.
●
For details about DIP switch value and meaning, see DIP
Switch.
6. Oponal: Go to System → User → Keyfob User on the remote
control page of the client soware to delete the keyfob.
5.2 Inialize Device
Steps
1. Remove the JP11 jumper cap on the access control board.
Figure 5-1 Inializaon Jumper Cap
2. Disconnect the power and reboot the device. The device
buzzer buzzes a long beep.
3. When the beep stopped, plug the jumper cap back.
4. Disconnect the power and power on the device again.
Cauon
The inializaon of the device will restore all the parameters to
the default seng and all the device events are deleted.
24
Note
Make sure no persons are in the lane when powering on the
device.
5.3 Switch to RS-485/RS-232 Mode
Take the Serial Port 4 and on the access control board as an
example. If the Jumper cap's posion is like the picture displayed
below. (The black part is the jumper cap.) The serial port is in
RS-485
communicaon mode.
Figure 5-2 Jumper Cap Status of RS-485 Interface
If the Jumper cap's posion is like the picture displayed below.
(The black part is the jumper cap.) The serial port is in RS-232
communicaon mode.
Figure 5-3 Jumper Cap Status of RS-232 Interface
5.4 Switch Relay Output Mode (NO/NC)
5.4.1 Barrier Control Relay Output Mode
The pins of the barrier control relay on the access control board is
as below:
Figure 5-4 Pin Appearance
The jumper cap's posion of barrier opening for entrance (NO) is
as below:
25
The jumper cap's posion of barrier opening for exit (NO) is as
below:
The jumper cap's posion of barrier closing for entrance (NC) is as
below:
The jumper cap's posion of barrier closing for exit (NC) is as
below:
5.4.2 Alarm Relay Output Mode (NO/NC)
Alarm Relay Output Mode (NO):
Alarm Relay Output Mode (NC):
6
Acvaon
You should acvate the device before the rst login. Aer
powering on the device, the system will switch to Device
Acvaon page.
Acvaon via the device, SADP tool and the client soware are
supported.
The default values of the device are as follows:
●
The default IP address: 192.0.0.64
●
The default port No.: 8000
●
The default user name: admin
6.1 Acvate via SADP
SADP is a tool to detect, acvate and modify the IP address of the
device over the LAN.
26
Before You Start
●
Get the SADP soware from the supplied disk or the ocial
website hp://www.hikvision.com/en/ , and install the SADP
according to the prompts.
●
The device and the PC that runs the SADP tool should be within
the same subnet.
The following steps show how to
acvate a device and modify its
IP address. For batch acvaon and IP addresses modicaon,
refer to User Manual of SADP for details.
Steps
1. Run the SADP
soware and search the online devices.
2. Find and select your device in online device list.
3. Input new password (admin password) and conrm the
password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend
you create a strong password of your own choosing (using a
minimum of 8 characters, including upper case leers, lower
case leers, numbers, and special characters) in order to
increase the security of your product. And we recommend you
reset your password regularly, especially in the high security
system,
reseng the password monthly or weekly can beer
protect your product.
4.
Click
Acvate to start acvaon.
Status of the device becomes Acve aer successful acvaon.
5. Modify IP address of the device.
1) Select the device.
2) Change the device IP address to the same subnet as your
computer by either modifying the IP address manually or
checking Enable DHCP.
3) Input the admin password and click Modify to
acvate your
IP address modicaon.
6.2 Acvate Device via Client Soware
For some devices, you are required to create the password to
acvate them before they can be added to the soware and work
properly.
Steps
Note
This funcon should be supported by the device.
1. Enter the Device Management page.
27
2.
Click on the right of Device Management and select Device.
3. Click Online Device to show the online device area.
The searched online devices are displayed in the list.
4. Check the device status (shown on Security Level column) and
select an
inacve device.
5. Click Acvate to open the Acvaon dialog.
6. Create a password in the password
eld, and conrm the
password.
Cauon
The password strength of the device can be automacally
checked. We highly recommend you change the password of
your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers,
lower case leers, numbers, and special characters) in order to
increase the security of your product. And we recommend you
change your password regularly, especially in the high security
system, changing the password monthly or weekly can
beer
protect your product.
Proper conguraon of all passwords and other security
sengs is the responsibility of the installer and/or end-user.
7. Click OK to acvate the device.
7 Client Soware Conguraon
7.1 Conguraon Flow of Client Soware
Follow the ow diagram below to congure on the client
soware.
Figure 7-1 Flow Diagram of Conguraon on Client Soware
7.2 Device Management
The client supports managing access control devices and video
intercom devices.
28
Example
You can control entrance & exit and manage aendance aer
adding access control devices to the client; you can perform video
intercom with the indoor staons and door staons.
7.2.1 Add Device
The client provides three device adding modes including by IP/
domain, IP segment, and ISUP protocol. The client also supports
imporng mulple devices in a batch when there are large
amount of devices to be added.
Add Online Device
The acve online devices in the same local subnet with the client
soware will be displayed on the Online Device area. You can
click Refresh Every 60s to refresh the informaon of the online
devices.
Add a Detected Online Device
You can select a detected online device displayed in the online
device list and add it to the client.
Steps
1. Enter the Device Management module.
2. Click Device tab on the top of the right panel.
3. Click Online Device to show the online device area.
The searched online devices are displayed in the list.
4. Select an online device in the Online Device area, and click Add
to open the device adding window.
Note
For the inacve device, you need to create the password for it
before you can add the device properly. For detailed steps,
refer to .
5. Enter the required informaon.
Name
Enter a descripve name for the device.
IP Address
Enter the device's IP address. The IP address of the device is
obtained
automacally in this adding mode.
Port
You can customize the port number. The port number of the
device is obtained automacally in this adding mode.
User Name
By default, the user name is admin.
Password
Enter the device password.
Cauon
The password strength of the device can be automacally
checked. We highly recommend you change the password of
your own choosing (using a minimum of 8 characters,
including at least three kinds of following categories: upper
case leers, lower case leers, numbers, and special
29
characters) in order to increase the security of your product.
And we recommend you change your password regularly,
especially in the high security system, changing the
password monthly or weekly can beer protect your
product.
Proper conguraon of all passwords and other security
sengs is the responsibility of the installer and/or end-user.
6. Oponal: Check Transmission Encrypon (TLS) to enable
transmission
encrypon using TLS (Transport Layer Security)
protocol for security purpose.
Note
●
This funcon should be supported by the device.
●
If you have enabled Cercate Vericaon, you should click
Open Cercate Directory to open the default folder, and
copy the cercate le exported from the device to this
default directory to strengthen the security. See for details
about enabling
cercate vericaon.
●
You can log into the device to get the cercate le by web
browser.
7. Check Synchronize Time to synchronize the device me with
the PC running the client aer adding the device to the client.
8. Oponal: Check Import to Group to create a group by the
device name, and import all the channels of the device to this
group.
Example
For access control device, its access points, alarm inputs/
outputs, and encoding channels (if exist) will be imported to
this group.
9. Click Add.
Add Mulple Detected Online Devices
For detected online devices sharing the same user name and
password, you can add them to the client in a batch.
Before You Start
Make sure the to-be-added devices are online.
Steps
1. Enter the Device Management module.
2. Click Device tab on the top of the right panel.
3. Click Online Device to show the online device area at the
boom of the page.
The searched online devices are displayed in the list.
4. Select mulple devices.
Note
For the inacve device, you need to create the password for it
before you can add the device properly. For details, refer to .
5. Click Add to open the device adding window.
6. Enter the required informaon.
User Name
By default, the user name is admin.
Password
30
Enter the device password.
Cauon
The password strength of the device can be automacally
checked. We highly recommend you change the password of
your own choosing (using a minimum of 8 characters,
including at least three kinds of following categories: upper
case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product.
And we recommend you change your password regularly,
especially in the high security system, changing the
password monthly or weekly can
beer protect your
product.
Proper
conguraon of all passwords and other security
sengs is the responsibility of the installer and/or end-user.
7. Oponal: Check Synchronize Time to synchronize the device
me with the PC running the client aer adding the device to
the client.
8. Oponal: Check Import to Group to create a group by the
device name, and import all the channels of the device to this
group.
Example
For access control device, its access points, alarm inputs/
outputs, and encoding channels (if exist) will be imported to
this group.
9. Click Add to add the devices.
Add Device by IP Address or Domain Name
If you know the IP address or domain name of the device to add,
you can add devices to the client by specifying the IP address (or
domain name), user name, password, etc.
Steps
1. Enter Device Management module.
2. Click Device tab on the top of the right panel.
The added devices are displayed on the right panel.
3. Click Add to open the Add window, and then select IP/Domain
as the adding mode.
4. Enter the required
informaon.
Name
Create a
descripve name for the device. For example, you
can use a nickname that can show the locaon or feature of
the device.
Address
The IP address or domain name of the device.
Port
The devices to add share the same port number. The default
value is 8000.
User Name
Enter the device user name. By default, the user name is
admin.
Password
Enter the device password.
31
Cauon
The password strength of the device can be automacally
checked. We highly recommend you change the password of
your own choosing (using a minimum of 8 characters,
including at least three kinds of following categories: upper
case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product.
And we recommend you change your password regularly,
especially in the high security system, changing the
password monthly or weekly can
beer protect your
product.
Proper
conguraon of all passwords and other security
sengs is the responsibility of the installer and/or end-user.
5. Oponal: Check Transmission Encrypon (TLS) to enable
transmission encrypon using TLS (Transport Layer Security)
protocol for security purpose.
Note
●
This funcon should be supported by the device.
●
If you have enabled Cercate Vericaon, you should click
Open Cercate Directory to open the default folder, and
copy the cercate le exported from the device to this
default directory to strengthen the security. See for details
about enabling
cercate vericaon.
●
You can log into the device to get the cercate le by web
browser.
6. Check Synchronize Time to synchronize the device me with
the PC running the client aer adding the device to the client.
7. Oponal: Check Import to Group to create a group by the
device name, and import all the channels of the device to this
group.
Example
For access control device, its access points, alarm inputs/
outputs, and encoding channels (if exist) will be imported to
this group.
8. Finish adding the device.
-
Click Add to add the device and back to the device list page.
-
Click Add and New to save the
sengs and connue to add
other device.
Add Devices by IP Segment
If the devices share the same port No., user name and password,
and their IP addresses ranges in the same IP segment, you can
add them to the client by specifying the start IP address and the
end IP address, port No., user name, password, etc of the devices.
Steps
1. Enter the Device Management module.
2. Click Device tab on the top of the right panel.
The added devices are displayed on the right panel.
3. Click Add to open the Add window.
4. Select IP Segment as the adding mode.
5. Enter the required
informaon.
Start IP
32
Enter a start IP address.
End IP
Enter an end IP address in the same network segment with
the start IP.
Port
Enter the device port No. The default value is 8000.
User Name
By default, the user name is admin.
Password
Enter the device password.
Cauon
The password strength of the device can be automacally
checked. We highly recommend you change the password of
your own choosing (using a minimum of 8 characters,
including at least three kinds of following categories: upper
case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product.
And we recommend you change your password regularly,
especially in the high security system, changing the
password monthly or weekly can
beer protect your
product.
Proper
conguraon of all passwords and other security
sengs is the responsibility of the installer and/or end-user.
6. Oponal: Check Transmission Encrypon (TLS) to enable
transmission encrypon using TLS (Transport Layer Security)
protocol for security purpose .
Note
●
This funcon should be supported by the device.
●
If you have enabled Cercate Vericaon, you should click
Open Cercate Folder to open the default folder, and copy
the cercate le exported from the device to this default
directory to strengthen the security. See for details about
enabling
cercate vericaon.
●
You can log into the device to get the cercate le by web
browser.
7. Check Synchronize Time to synchronize the device me with
the PC running the client aer adding the device to the client.
8. Oponal: Check Import to Group to create a group by the
device name, and import all the channels of the device to the
group.
9. Finish adding the device.
-
Click Add to add the device and back to the device list page.
-
Click Add and New to save the sengs and connue to add
other device.
Import Devices in a Batch
You can add mulple devices to the client in a batch by entering
the device parameters in a
pre-dened CSV le.
Steps
1. Enter the Device Management module.
2. Click Device tab on the top of the right panel.
33
3. Click Add to open the Add window, and then select Batch
Import as the adding mode.
4. Click Export Template and then save the pre-dened template
(CSV le) on your PC.
5. Open the exported template le and enter the required
informaon of the devices to be added on the corresponding
column.
Note
For detailed descripon of the required elds, refer to the
introducons in the template.
Adding Mode
Enter 0 or 1 or 2.
Address
Edit the address of the device.
Port
Enter the device port number. The default port number is
8000.
User Name
Enter the device user name. By default, the user name is
admin.
Password
Enter the device password.
Cauon
The password strength of the device can be automacally
checked. We highly recommend you change the password of
your own choosing (using a minimum of 8 characters,
including at least three kinds of following categories: upper
case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product.
And we recommend you change your password regularly,
especially in the high security system, changing the
password monthly or weekly can
beer protect your
product.
Proper
conguraon of all passwords and other security
sengs is the responsibility of the installer and/or end-user.
Import to Group
Enter 1 to create a group by the device name. All the
channels of the device will be imported to the corresponding
group by default. Enter 0 to disable this
funcon.
6.
Click and select the template le.
7. Click Add to import the devices.
7.2.2 Reset Device Password
If you forgot the password of the detected online devices, you
can reset the device password via the client.
Steps
1. Enter Device Management page.
2. Click Online Device to show the online device area.
All the online devices sharing the same subnet will be displayed
in the list.
34
3.
Select the device from the list and click on the Operaon
column.
4. Reset the device password.
-
Click Generate to pop up the QR Code window and click
Download to save the QR code to your PC. You can also take
a photo of the QR code to save it to your phone. Send the
picture to our technical support.
Note
For the following operaons for reseng the password,
contact our technical support.
Cauon
The password strength of the device can be automacally
checked. We highly recommend you change the password of
your own choosing (using a minimum of 8 characters, including
at least three kinds of following categories: upper case leers,
lower case leers, numbers, and special characters) in order to
increase the security of your product. And we recommend you
change your password regularly, especially in the high security
system, changing the password monthly or weekly can
beer
protect your product.
Proper conguraon of all passwords and other security
sengs is the responsibility of the installer and/or end-user.
7.3 Group Management
The client provides groups to manage the added resources in
dierent groups. You can group the resources into dierent
groups according to the resources' locaons.
Example
For example, on the 1st oor, there mounted 16 doors, 64 alarm
inputs, and 16 alarm outputs. You can organize these resources
into one group (named 1st Floor) for convenient management.
You can control door status, and do some other
operaons of the
devices
aer managing the resources by groups.
7.3.1 Add Group
You can add group to organize the added device for convenient
management.
Steps
1. Enter the Device Management module.
2. Click Device Management → Group to enter the group
management page.
3. Create a group.
-
Click Add Group and enter a group name as you want.
-
Click Create Group by Device Name and select an added
device to create a new group by the name of the selected
device.
Note
The resources (such as alarm inputs/outputs, access points,
etc.) of this device will be imported to the group by default.
7.3.2 Import Resources to Group
You can import the device resources (such as alarm inputs/
outputs, access points, etc.) to the added group in a batch.
35
Before You Start
Add a group for managing devices. Refer to Add Group.
Steps
1. Enter the Device Management module.
2. Click Device Management → Group to enter the group
management page.
3. Select a group from the group list and select the resource type
as Access Point, Alarm Input, Alarm Output, etc.
4. Click Import.
5. Select the thumbnails/names of the resources in the
thumbnail/list view.
Note
You can click or to switch the resource display mode to
thumbnail view or to list view.
6. Click Import to import the selected resources to the group.
7.3.3 Edit Resource Parameters
Aer imporng the resources to the group, you can edit the
resource parameters. For access point, you can edit the access
point name. For alarm input, you can edit the alarm input name.
Here we take access point as an example.
Before You Start
Import the resources to group.
Steps
1. Enter the Device Management module.
2. Click Device Management → Group to enter the group
management page.
All the added groups are displayed on the
le.
3. Select a group on the group list and click Access Point.
The access points imported to the group will display.
4.
Click in the Operaon column to open the Edit Resource
window.
5. Edit the resource name.
6. Click OK to save the new
sengs.
7.3.4 Remove Resources from Group
You can remove the added resources from the group.
Steps
1. Enter the Device Management module.
2. Click Device Management → Group to enter the group
management page.
All the added groups are displayed on the
le.
3. Click a group to show the resources added to this group.
4. Select the resource(s) and click Delete to remove the
resource(s) from the group.
7.4 Person Management
You can add person informaon to the system for further
operaons such as access control, video intercom, me and
aendance, etc. You can manage the added persons such as
36
issuing cards to them in a batch, imporng and exporng person
informaon in a batch, etc.
7.4.1 Add Organizaon
You can add an organizaon and import person informaon to
the organizaon for eecve management of the persons. You
can also add a surbodinate organizaon for the added one.
Steps
1. Enter Person module.
2. Select a parent
organizaon in the le column and click Add in
the
upper-le corner to add an organizaon.
3. Create a name for the added organizaon.
Note
Up to 10 levels of organizaons can be added.
4. Oponal: Perform the following operaon(s).
Edit
Organizaon
Hover the mouse on an added
organizaon and click to edit its name.
Delete
Organizaon
Hover the mouse on an added
organizaon and click to delete it.
Note
●
The lower-level organizaons will be
deleted as well if you delete an
organizaon.
●
Make sure there is no person added
under the
organizaon, or the
organizaon cannot be deleted.
Show Persons
in Sub
Organizaon
Check Show Persons in Sub Organizaon
and select an organizaon to show
persons in its sub organizaons.
7.4.2 Congure Basic Informaon
You can add person to the client one by one and congure the
person's basic informaon such as name, email, phone number,
etc.
Steps
1. Enter Person module.
2. Select an
organizaon in the organizaon list to add the
person.
3. Click Add to open the adding person window.
The Person ID will be generated
automacally.
4. Enter the basic informaon including person name, telephone
number, email address, validity period, etc.
5. Conrm to add the person.
-
Click Add to add the person and close the Add Person
window.
-
Click Add and New to add the person and connue to add
other persons.
7.4.3 Issue a Card by Local Mode
If a card enrollment staon is available, you can issue a card by
local mode. To read the card number, you should connect the
37
card enrollment staon to the PC running the client by USB
interface or COM, and place the card on the card enrollment
staon.
Steps
1. Enter Person module.
2. Select an organizaon in the organizaon list to add the person
and click Add to enter Add Person panel.
Note
Enter the person's basic informaon rst. For details about
conguring person's basic informaon, refer to Congure Basic
Informaon.
3. In the Credenal → Card area, click +.
4. Click Sengs to enter the Sengs page.
5. Select Local as the card issuing mode.
Figure 7-2 Issue a Card by Local Mode
6. Set other related parameters.
Card Enrollment
Staon
Select the model of the connected card enrollment staon.
Note
Currently, the supported card enrollment staon models
include DS-K1F100-D8, DS-K1F100-M, DS-K1F100-D8E, and
DS-K1F180-D8E.
Card Type
This eld is only available when the model is DS-K1F100-D8E
or DS-K1F180-D8E. Select the card type as EM card or M1
card according to the actual card type.
Buzzing
Enable or disable the buzzing when the card number is read
successfully.
Card No. Type
Select the type of the card number according to actual
needs.
M1 Card
Encrypon
38
This eld is only available when the model is DS-K1F100-D8,
DS-K1F100-D8E, or DS-K1F180-D8E. If the card is M1 card,
then you can enable the M1 Card Encrypon funcon and
select the sector of the card to encrypt.
7. Click OK to conrm the operaon.
8. Place the card on the card enrollment staon, and click Read to
get the card number.
The card number will display in the Card No. eld
automacally.
9. Click Add.
The card will be issued to the person.
7.4.4 Upload a Face Photo from Local PC
When adding person, you can upload a face photo stored in local
PC to the client as the person's prole.
Steps
1. Enter Person module.
2. Select an organizaon in the organizaon list to add the person
and click Add.
Note
Enter the person's basic informaon rst. For details about
conguring person's basic informaon, refer to Congure Basic
Informaon.
3. Click Add Face in the Basic Informaon panel.
4. Select Upload.
5. Select a picture from the PC running the client.
Note
The picture should be in JPG or JPEG format and smaller than
200 KB.
6. Oponal: Enable Verify by Device to check whether the facial
recognion device managed in the client can recognize the face
in the photo.
7.
Conrm to add the person.
-
Click Add to add the person and close the Add Person
window.
-
Click Add and New to add the person and
connue to add
other persons .
7.4.5 Take a Photo via Client
When adding a person, you can take a photo of the her/him via
the client and set this photo as the person's prole.
Before You Start
Make sure PC running the client has a camera or you have
connected other USB camera to the PC.
Steps
1. Enter Person module.
2. Select an
organizaon in the organizaon list to add the person
and click Add to enter Add Person window.
39
Note
Enter the person's basic informaon rst. For details, refer to
Congure Basic Informaon.
3. Click Add Face in the Basic Informaon area.
4. Select Take Photo to enter Take Photo window.
5. Oponal: Enable Verify by Device to check whether the
captured face photo can meet the uploading requirements.
6. Take a photo.
1) Face to the camera and make sure your face is in the middle
of the
collecng window.
2)
Click to capture a face photo.
3)
Oponal: Click to capture again.
4) Click OK to save the captured photo.
Figure 7-3 Take a Photo via Client
7. Conrm to add the person.
-
Click Add to add the person and close the Add Person
window.
-
Click Add and New to add the person and
connue to add
other persons.
7.4.6 Collect Face via Access Control Device
When adding person, you can collect the person's face via access
control device added to the client which supports facial
recognion funcon.
Steps
1. Enter Person module.
2. Select an organizaon in the organizaon list to add the person
and click Add.
Note
Enter the person's basic informaon rst. For details about
conguring person's basic informaon, refer to Congure Basic
Informaon.
3. Click Add Face in the Basic Informaon panel.
40
4. Select Remote Collecon.
5. Select an added access control device or the enrollment staon
from the drop-down list.
Note
If you select the enrollment staon, you should click Login to
set related parameters of the device including IP address, port
No., user name, and password. Also, you can check Face An-
Spoong and select the liveness level as Low, Medium, or High.
Face An-Spoong
If you check this funcon, then the device can detect
whether the face to be collected is an authenc one.
6. Collect face.
1) Face to the camera of the selected access control device and
make sure your face is in the middle of the
collecng
window.
2)
Click to capture a photo.
3) Click OK to save the captured photo.
7. Conrm to add the person.
-
Click Add to add the person and close the Add Person
window.
-
Click Add and New to add the person and
connue to add
other persons .
7.4.7 Collect Fingerprint via Client
Collecng ngerprints locally means you can collect the
ngerprint via the ngerprint recorder connected directly to the
PC running the client. The ngerprints recorded can be used as
credenals of the persons to access the authorized doors.
Before You Start
Connect the ngerprint recorder to the PC running the client.
Steps
1. Enter Person module.
2. Select an
organizaon in the organizaon list to add the person
and click Add.
Note
Enter the person's basic informaon rst. For details about
conguring person's basic informaon, refer to Congure Basic
Informaon.
3. In the Credenal → Fingerprint panel, click +.
4. In the pop-up window, select the collecon mode as Local.
5. Select the model of the connected ngerprint recorder.
Note
If the ngerprint recorder is DS-K1F800-F, you can click Sengs
to select the COM the ngerprint recorder connects to.
6. Collect the ngerprint.
1) Click Start.
2) Place and li your ngerprint on the ngerprint recorder to
collect the ngerprint.
3) Click Add to save the recorded ngerprint.
41
7. Conrm to add the person.
-
Click Add to add the person and close the Add Person
window.
-
Click Add and New to add the person and
connue to add
other persons.
Note
Once the ngerprint is added, the ngerprint type cannot be
changed.
7.4.8 Collect Fingerprint via Access Control Device
When adding person, you can collect ngerprint informaon via
the access control device's ngerprint module. The ngerprints
recorded can be used as credenals of the persons to access the
authorized doors.
Before You Start
Make sure
ngerprint collecon is supported by the access
control device.
Steps
1. Enter Person module.
2. Select an
organizaon in the organizaon list to add the person
and click Add.
Note
Enter the person's basic informaon rst. For details about
conguring person's basic informaon, refer to Congure Basic
Informaon.
3. In the Credenal → Fingerprint panel, click +.
4. In the pop-up window, select the collecon mode as Remote.
5. Select an added access control device or the enrollment staon
from the drop-down list.
Note
If you select the enrollment staon, you should click Login, and
set IP address, port No., user name and password of the
device.
6. Collect the ngerprint.
1) Click Start.
2) Place and li your ngerprint on the ngerprint scanner of
the selected access control device to collect the
ngerprint.
3) Click Add to save the recorded ngerprint.
7. Conrm to add the person.
-
Click Add to add the person and close the Add Person
window.
-
Click Add and New to add the person and
connue to add
other persons .
7.4.9
Congure Access Control Informaon
When adding a person, you can set her/his access control
informaon, such as binding an access control group with the
person, conguring PIN code, seng the person as a visitor, a
blocklist person, or a super user, etc.
Steps
1. Enter Person module.
42
2. Select an organizaon in the organizaon list to add the person
and click Add.
3.
In the Access Control area, click to select access group(s) for
the person.
Note
For details, refer to Set Access Group to Assign Access
Authorizaon to Persons.
Figure 7-4 Congure Access Control Informaon
4. Set a unique PIN code for the person which can be used for
access
authencaon.
-
Manually enter a PIN code containing 4 to 8 digits.
Note
Persons' PIN codes cannot be repeated.
-
Click Generate to randomly generate an unrepeated PIN
code of 6 digits.
Note
If there are repeated PIN codes, a prompt will pop up on the
client. The admin can generate a new PIN code to replace
the repeated PIN code and nofy related persons.
5. Check the person's operaon permissions.
Super User
If the person is set as a super user, he/she will have
authorizaon to access all the doors/oors and will be
exempted from remaining closed restricons, all an-
passback
rules, and rst person authorizaon.
Extended Door Open Time
Use this funcon for persons with reduced mobility. When
accessing the door, the person will have more me than
others to pass through doors.
For details about
seng the door's open duraon, refer to
Congure Parameters for Door.
Add to Blocklist
Add the person to the blocklist and when the person tries to
access
doors/oors, an event will be triggered and sent to
the client to nofy the security personnel.
Mark as Visitor
If the person is a visitor, you should set the her/his valid
mes for visit.
Note
The valid mes for visit is between 1 and 100. You can also
check No Limit, then there are no limited mes for the
visitor to access doors/oors.
43
Device Operator
For person with device operator role, he/she is authorized to
operate on the access control devices.
Note
The Super User, Extended Door Open Time, Add to Blocklist,
and Mark as Visitor funcons cannot be enabled concurrently.
For example, if one person is set as super user, you cannot
enable extended door open me for her/him, add her/him to
the blocklist, or set her/him as visitor.
6. Conrm to add the person.
-
Click Add to add the person and close the Add Person
window.
-
Click Add and New to add the person and
connue to add
other persons.
7.4.10 Customize Person
Informaon
You can customize the person properes which are not pre-
dened in the client according to actual needs, e.g., place of
birth.
Aer customizing, when add a person, you can enter the
custom informaon to make the person informaon complete.
Steps
1. Enter Person module.
2. Set the
elds of custom informaon.
1) Click Custom Property.
2) Click Add to add a new property.
3) Enter the property name.
4) Click OK.
3. Set the custom informaon when adding a person.
1) Select an organizaon in the organizaon list to add the
person and click Add.
Note
Enter the person's basic informaon rst. For details about
conguring person's basic informaon, refer to Congure
Basic Informaon.
2) In the Custom Informaon panel, enter the person
informaon.
3) Click Add to add the person and close the Add Person
window, or click Add and New to add the person and
connue to add other persons.
7.4.11
Congure Resident Informaon
If the person is resident, for video intercom purpose, you need to
set the room number for her/him and bind an indoor
staon.
Aer bound, you can call this person by calling the indoor staon
and perform video intercom with her/him.
Steps
1. Enter Person module.
2. Select an
organizaon in the organizaon list to add the person
and click Add.
44
Note
Enter the person's basic informaon rst. For details about
conguring person's basic informaon, refer to Congure Basic
Informaon.
3. In the Resident Informaon panel, select the indoor staon to
bind it to the person.
Note
If you select Analog Indoor Staon, the Door Staon eld will
display and you are required to select the door staon to
communicate with the analog indoor staon.
4. Enter the oor No. and room No. of the person.
5. Conrm to add the person.
-
Click Add to add the person and close the Add Person
window.
-
Click Add and New to add the person and
connue to add
other persons.
7.4.12
Congure Addional Informaon
When adding person, you can congure the addional
informaon
for the person, such as person's identy type,
identy No., country, etc., according to actual needs.
Steps
1. Enter Person module.
2. Select an
organizaon in the organizaon list to add the person
and click Add.
Note
Enter the person's basic informaon rst. For details about
conguring person's basic informaon, refer to Congure Basic
Informaon.
3. In the Addional Informaon panel, enter the addional
informaon
of the person, including person's ID type, ID No.,
job tle, etc., according to actual needs.
4. Conrm to add the person.
-
Click Add to add the person and close the Add Person
window.
-
Click Add and New to add the person and connue to add
other persons .
7.4.13 Import and Export Person
Idenfy
Informaon
You can import the informaon and pictures of mulple persons
to the client
soware in a batch. Meanwhile, you can also export
the person informaon and pictures and save them in your PC.
7.4.14 Import Person
Informaon
You can enter the informaon of mulple persons in a predened
template (CSV/Excel le) to import the informaon to the client in
a batch.
Steps
1. Enter the Person module.
2. Select an added
organizaon in the list, or click Add in the
upper-le corner to add an organizaon and then select it.
45
3. Click Import to open the Import panel.
4. Select Person Informaon as the imporng mode.
5. Click Download Template for Imporng Person to download
the template.
6. Enter the person informaon in the downloaded template.
Note
●
If the person has mulple cards, separate the card No. with
semicolon.
●
Items with asterisk are required.
●
By default, the Hire Date is the current date.
7.
Click
to select the CSV/Excel le with person informaon
from local PC.
8. Click Import to start imporng.
Note
●
If a person No. already exists in the client's database, delete
the exisng informaon before imporng.
●
You can import informaon of no more than 2,000 persons.
7.4.15 Import Person Pictures
Aer imporng face pictures for the added persons to the client,
the persons in the pictures can be idened by an added face
recognion terminal. You can either import person pictures one
by one, or import
mulple pictures at a me according to your
need.
Before You Start
Be sure to have imported person informaon to the client
beforehand.
Steps
1. Enter the Person module.
2. Select an added
organizaon in the list, or click Add in the
upper-le corner to add an organizaon and then select it.
3. Click Import to open the Import panel and check Face.
4. Oponal: Enable Verify by Device to check whether face
recognion device managed in the client can recognize the face
in the photo.
5.
Click to select a face picture le.
Note
●
The (folder of) face pictures should be in ZIP format.
●
Each picture le should be in JPG format and should be no
larger than 200 KB.
●
Each picture le should be named as "Person ID_Name". The
Person ID should be the same with that of the imported
person
informaon.
6. Click Import to start imporng.
The imporng progress and result will be displayed.
7.4.16 Export Person
Informaon
You can export the added persons' informaon to local PC as a
CSV/Excel
le.
46
Before You Start
Make sure you have added persons to an organizaon.
Steps
1. Enter the Person module.
2. Oponal: Select an organizaon in the list.
Note
All persons' informaon will be exported if you do not select
any organizaon.
3. Click Export to open the Export panel.
4. Check Person Informaon as the content to export.
5. Check desired items to export.
6. Click Export to save the exported
le in CSV/Excel le on your
PC.
7.4.17 Export Person Pictures
You can export face picture le of the added persons and save in
your PC.
Before You Start
Make sure you have added persons and their face pictures to an
organizaon.
Steps
1. Enter the Person module.
2.
Oponal: Select an organizaon in the list.
Note
All persons' face pictures will be exported if you do not select
any organizaon.
3. Click Export to open the Export panel and check Face as the
content to export.
4. Click Export to start
exporng.
Note
●
The exported le is in ZIP format.
●
The exported face picture is named as "Person ID_Name_0"
("0" is for a full-frontal face).
7.4.18 Get Person Informaon from Access
Control Device
If the added access control device has been congured with
person informaon (including person details, ngerprint, and
issued card
informaon), you can get the person informaon
from the device and import them to the client for further
operaons.
Steps
Note
●
If the person name stored in the device is empty, the person
name will be lled with the issued card No. aer imporng to
the client.
●
If the card number or person ID (employee ID) stored on the
device already exists in the client database, the person with
47
this card number or person ID will not be imported to the
client.
1. Enter Person module.
2. Select an organizaon to import the persons.
3. Click Get from Device.
4. Select an added access control device or the enrollment staon
from the drop-down list.
Note
If you select the enrollment staon, you should click Login, and
set IP address, port No., user name and password of the
device.
5. Click Import to start imporng the person informaon to the
client.
Note
Up to 2,000 persons and 5,000 cards can be imported.
The person informaon, including person details, person's
ngerprint informaon (if congured), and the linked cards (if
congured), will be imported to the selected organizaon.
7.4.19 Move Persons to Another
Organizaon
You can move the added persons to another organizaon if you
need.
Before You Start
●
Make sure you have added at least two
organizaons.
●
Make sure you have imported person informaon.
Steps
1. Enter Person module.
2. Select an
organizaon in the le panel.
The persons under the organizaon will be displayed in the
right panel.
3. Select the person to move.
4. Click Change Organizaon.
5. Select the organizaon to move persons to.
6. Click OK.
7.4.20 Issue Cards to Persons in Batch
The client provides a convenient way to issue cards to mulple
persons in a batch.
Steps
1. Enter Person module.
2. Click Batch Issue Cards.
All the added persons with no card issued will be displayed in
the right panel.
3.
Oponal: Enter key words (name or person ID) in the input box
to
lter the person(s) that need issuing cards.
4. Oponal: Click Sengs to set the card issuing parameters. For
details, refer to Issue a Card by Local Mode.
48
5. Click Inialize to inialize the card enrollment staon or card
reader to make it ready for issuing cards.
6. Click the Card No. column and enter the card number.
-
Place the card on the card enrollment staon.
-
Swipe the card on the card reader.
-
Manually enter the card number and press the Enter key.
The person(s) in the list will be issued with card(s).
7.4.21 Report Card Loss
If the person lost his/her card, you can report the card loss so
that the card's related access authorizaon will be inacve.
Steps
1. Enter Person module.
2. Select the person you want to report card loss for and click Edit
to open the Edit Person window.
3.
In the Credenal → Card panel, click on the added card to
set this card as lost card.
Aer reporng card loss, the access authorizaon of this card
will be invalid and
inacve. Other person who gets this card
cannot access the doors by swiping this lost card.
4.
Oponal: If the lost card is found, you can click to cancel the
loss.
Aer cancelling card loss, the access authorizaon of the
person will be valid and acve.
5. If the lost card is added in one access group and the access
group is applied to the device already,
aer reporng card loss
or cancelling card loss, a window will pop up to nofy you to
apply the changes to the device. Aer applying to device, these
changes can take
eect on the device.
7.4.22 Set Card Issuing Parameters
The client provides two modes for reading a card's number: via
card enrollment
staon or via the card reader of the access
control device. If a card enrollment staon is available, connect it
to the PC running the client by USB interface or COM, and place
the card on the card enrollment to read the card number. If not,
you can also swipe the card on the card reader of the added
access control device to get the card number. As a result, before
issuing a card to one person, you need to set the card issuing
parameters including the issuing mode and related parameters.
When adding a card to one person, click
Sengs to open the
Card Issuing Sengs window.
Local Mode: Issue Card by Card Enrollment
Staon
Connect a card enrollment staon to the PC running the client.
You can place the card on the card enrollment staon to get the
card number.
Card Enrollment
Staon
Select the model of the connected card enrollment staon
49
Note
Currently, the supported card enrollment staon models
include DS-K1F100-D8, DS-K1F100-M, DS-K1F100-D8E, and DS-
K1F180-D8E.
Card Type
This eld is only available when the model is DS-K1F100-D8E or
DS-K1F180-D8E.
Select the card type as EM card or IC card according to the
actual card type.
Serial Port
It is only available when the model is DS-K1F100-M.
Select the COM the card enrollment
staon connects to.
Buzzing
Enable or disable the buzzing when the card number is read
successfully.
Card No. Type
Select the type of the card number according to actual needs.
M1 Card Encrypon
This eld is only available when the model is DS-K1F100-D8,
DS-K1F100-D8E, or DS-K1F180-D8E.
If the card is M1 card, and if you need to enable the M1 Card
Encrypon funcon, you should enable this funcon and select
the sector of the card to encrypt.
Remote Mode: Issue Card by Card Reader
Select an access control device added in the client and swipe the
card on its card reader to read the card number.
7.5 Congure Schedule and Template
You can congure the template including holiday and week
schedule. Aer seng the template, you can adopt the
congured template to access groups when seng the access
groups, so that the access group will take eect in the me
duraons
of the template.
Note
For access group sengs, refer to Set Access Group to Assign
Access Authorizaon to Persons.
7.5.1 Add Holiday
You can create holidays and set the days in the holidays, including
start date, end date, and holiday duraon in one day.
Steps
Note
You can add up to 64 holidays in the soware system.
1. Click Access Control → Schedule → Holiday to enter the
Holiday page.
2. Click Add on the le panel.
3. Create a name for the holiday.
50
4. Oponal: Enter the descripons or some nocaons of this
holiday in the Remark box.
5. Add a holiday period to the holiday list and congure the
holiday duraon.
Note
Up to 16 holiday periods can be added to one holiday.
1) Click Add in the Holiday List eld.
2) Drag the cursor to draw the me duraon, which means in
that duraon of me, the congured access group is
acvated.
Note
Up to 8 me duraons can be set to one holiday period.
3) Oponal: Perform the following operaons to edit the me
duraons.
●
Move the cursor to the me duraon and drag the me
duraon on the meline bar to the desired posion when
the cursor turns to .
●
Click the me duraon and directly edit the start/end me in
the appeared dialog.
●
Move the cursor to the start or the end of me duraon and
drag to lengthen or shorten the
me duraon when the
cursor turns to .
4) Oponal: Select the me duraon(s) that need to be
deleted, and then click in the Operaon column to delete
the selected me duraon(s).
5)
Oponal: Click in the Operaon column to clear all the
me duraon(s) in the me bar.
6)
Oponal: Click in the Operaon column to delete this
added holiday period from the holiday list.
6. Click Save.
7.5.2 Add Template
Template includes week schedule and holiday. You can set week
schedule and assign the me duraon of access authorizaon for
dierent person or group. You can also select the added
holiday(s) for the template.
Steps
Note
You can add up to 255 templates in the soware system.
1. Click Access Control → Schedule → Template to enter the
Template page.
Note
There are two default templates: All-Day Authorized and All-
Day Denied, and they cannot be edited or deleted.
All-Day Authorized
The access authorizaon is valid in each day of the week and
it has no holiday.
All-Day Denied
51
The access authorizaon is invalid in each day of the week
and it has no holiday.
2. Click Add on the le panel to create a new template.
3. Create a name for the template.
4. Enter the descripons or some nocaon of this template in
the Remark box.
5. Edit the week schedule to apply it to the template.
1) Click Week Schedule tab on the lower panel.
2) Select a day of the week and draw
me duraon(s) on the
meline bar.
Note
Up to 8 me duraon(s) can be set for each day in the week
schedule.
3) Oponal: Perform the following operaons to edit the me
duraons.
●
Move the cursor to the
me duraon and drag the me
duraon
on the meline bar to the desired posion when
the cursor turns to .
●
Click the me duraon and directly edit the start/end me in
the appeared dialog.
●
Move the cursor to the start or the end of me duraon and
drag to lengthen or shorten the
me duraon when the
cursor turns to .
4) Repeat the two steps above to draw more
me duraons on
the other days of the week.
6. Add a holiday to apply it to the template.
Note
Up to 4 holidays can be added to one template.
1) Click Holiday tab.
2) Select a holiday in the le list and it will be added to the
selected list on the right panel.
3)
Oponal: Click Add to add a new holiday.
Note
For details about adding a holiday, refer to Add Holiday.
4) Oponal: Select a selected holiday in the right list and click
to remove the selected one, or click Clear to clear all the
selected holiday(s) in the right list.
7. Click Save to save the sengs and nish adding the template.
7.6 Set Access Group to Assign Access
Authorizaon to Persons
Aer adding the person and conguring the person's credenals,
you can create the access groups to dene which person(s) can
get access to which door(s) and then apply the access group to
the access control device to take
eect.
52
Before You Start
●
Add person to the client.
●
Add access control device to the client and group access points.
For details, refer to Group Management.
●
Add template.
Steps
When the access group sengs are changed, you need to apply
the access groups to the devices again to take
eect. The access
group changes include changes of template, access group
sengs, person's access group sengs, and related person
details (including card number, ngerprint, face picture, linkage
between card number and ngerprint, linkage between card
number and
ngerprint, card password, card eecve period,
etc).
1. Click Access Control → Authorizaon → Access Group to enter
the Access Group interface.
2. Click Add to open the Add window.
3. In the Name text eld, create a name for the access group as
you want.
4. Select a template for the access group.
Note
You should congure the template before access group
sengs. Refer to Congure Schedule and Template for details.
5. In the le list of the Select Person eld, select person(s) to
assign access authority.
6. In the le list of the Select Access Point eld, select door(s),
door staon(s) or oor(s) for the selected persons to access.
7. Click Save.
You can view the selected person(s) and the selected access
point(s) on the right side of the interface.
Figure 7-5 Display the Selected Person(s) and Access Point(s)
8. Aer adding the access groups, you need to apply them to the
access control device to take
eect.
1) Select the access group(s) to apply to the access control
device.
2) Click Apply All to Devices start applying all the selected
access group(s) to the access control device or door
staon.
3) Click Apply All to Devices or Apply Changes to Devices.
Apply All to Devices
53
This operaon will clear all the existed access groups of
the selected devices and then apply the new access group
to the device.
Apply Changes to Devices
This operaon will not clear the existed access groups of
the selected devices and only apply the changed part of
the selected access group(s) to the device(s).
4) View the applying status in the Status column or click
Applying Status to view all the applied access group(s).
Note
You can check Display Failure Only to lter the applying
results.
The selected persons in the applied access groups will have the
authorizaon to enter/exit the selected doors/door staons
with their linked card(s) or ngerprints.
9.
Oponal: Click to edit the access group if necessary.
Note
If you change the persons' access informaon or other related
informaon, you will view the prompt Access Group to Be
Applied on the right corner of the client.
You can click the prompt to apply the changed data to the
device. You can select either Apply Now or Apply Later.
Figure 7-6 Data Synchronizaon
7.7 Congure Advanced Funcons
You can congure the advanced funcons of access control to
meet some special requirements in
dierent scene.
Note
●
For the card related funcons(the type of access control card),
only the card(s) with access group applied will be listed when
adding cards.
●
The advanced funcons should be supported by the device.
●
Hover the cursor on the Advanced
Funcon, and then Click
to customize the advanced funcon(s) to be displayed.
7.7.1 Congure Device Parameters
Aer adding the access control device, you can congure the
parameters of access control device, access control points.
Congure Parameters for Access Control Device
Aer adding the access control device, you can congure its
parameters.
54
Steps
1. Click Access Control → Advanced Funcon → Device
Parameter .
Note
If you can nd Device Parameter in the Advanced Funcon list,
Hover the cursor on the Advanced Funcon, and then Click
to select the Device Parameter to be displayed.
2. Select an access device to show its parameters on the right
page.
3. Turn the switch to ON to enable the corresponding funcons.
Note
The displayed parameters may vary for dierent access control
devices.
RS-485 Communicaon Redundancy
You should enable this funcon if you wire the RS-485 card
reader to the access control device redundantly.
Enable NFC
If enable the funcon, the device can recognize the NFC
card. You can present NFC card on the device.
Enable M1 Card
If enable the
funcon, the device can recognize the M1 card.
You can present M1 card on the device.
Enable EM Card
If enable the funcon, the device can recognize the EM card.
You can present EM card on the device.
Enable CPU Card
Reserved. If enable the funcon, the device can recognize
the CPU card. You can present CPU card on the device.
Enable ID Card
Reserved. If enable the
funcon, the device can recognize
the ID card. You can present ID card on the device.
4. Click OK.
5. Oponal: Click Copy to, and then select the access control
device(s) to copy the parameters in the page to the selected
device(s).
Congure Parameters for Door
Aer adding the access control device, you can congure its
access point door parameters.
Steps
1. Click Access Control → Advanced
Funcon → Device
Parameter .
2. Select an access control device on the
le panel, and then click
to show the doors or oors of the selected device.
3. Select a door or oor to show its parameters on the right page.
4. Edit the door or oor parameters.
55
Note
s
The displayed parameters may vary for dierent access control
devices.
Name
Edit the card reader name as desired.
Exit Buon Type
You can set the exit
buon as remaining closed or remaining
open. Usually, it is remaining open.
Open Duraon
Aer swiping the normal card and relay acon, the me for
locking the door starts working.
Door
Le Open Timeout Alarm
The alarm can be triggered if the door has not been closed in
a congured me period. If it is set as 0, no alarm will be
triggered.
Super Password
The specic person can open the door by inpung the super
password.
5. Some of the following parameters are not listed in the Basic
Informaon page, click Advanced to edit the parameters.
Duress Code
The door can open by inpung the duress code when there
is duress. At the same
me, the client can report the duress
event.
Dismiss Code
Create a dismiss code which can be used to stop the buzzer
of the card reader (by entering the dismiss code on the
keypad).
Note
●
The duress code, super code, and dismiss code should be
dierent.
●
The duress code, super password, and the dismiss code
should be dierent from the authencaon password.
●
The length of duress code, super password, and the dismiss
code is according the device, usually it should contains 4 to 8
digits.
6. Click OK.
7. Oponal: Click Copy to , and then select the door(s) to copy
the parameters in the page to the selected doors(s).
Note
The door's status duraon sengs will be copied to the
selected door(s) as well.
Congure Parameters for Card Reader
Aer adding the access control device, you can congure its card
reader parameters.
56
Steps
1. Click Access Control → Advanced Funcon → Device
Parameter .
2.
In the device list on the
le, click to expand the door, select a
card reader and you can edit the card reader's parameters on
the right.
3. Edit the card reader basic parameters in the Basic Informaon
page.
Note
The displayed parameters may vary for dierent access control
devices. There are part of parameters listed as follows. Refer to
the user manual of the device for more details.
Name
Edit the card reader name as desired.
Minimum Card Swiping Interval
If the interval between card swiping of the same card is less
than the set value, the card swiping is invalid. You can set it
as 0 to 255.
Alarm of Max. Failed
Aempts
Enable to report alarm when the card reading aempts
reach the set value.
Card Reader Type/Card Reader Descripon
Get card reader type and descripon. They are read-only.
4. Oponal: Some of the following parameters are not listed in
the Basic Informaon page, click Advanced to edit the
parameters.
Enable Card Reader
If enabling the
funcon, user can present card on the card
reader. If disabling the funcon, the card reader for entrance
cannot be used.
OK LED Polarity/Error LED Polarity/Buzzer Polarity
Set OK LED Polarity/Error LED Polarity/Buzzer LED Polarity of
main board according to the card reader parameters.
Generally, adopts the default
sengs.
Buzzing Time
Set the card reader buzzing me. The available me ranges
from 0 to 5,999s. 0 represents connuous buzzing.
Max. Interval When Entering PWD
When you inpung the password on the card reader, if the
interval between pressing two digits is larger than the set
value, the digits you pressed before will be cleared
automacally.
Tampering Detecon
Enable the an-tamper detecon for the card reader.
Communicate with Controller Every
When the access control device cannot connect with the
card reader for longer than the set me, the card reader will
turn
oine automacally.
Fingerprint Recognion Level
57
Select the ngerprint recognion level in the drop-down list.
5. Click OK.
6. Oponal: Click Copy to, and then select the card reader(s) to
copy the parameters in the page to the selected card reader(s).
Congure Parameters for Alarm Output
Aer adding the access control device, if the device links to alarm
outputs, you can congure the parameters.
Before You Start
Add access control device to the client, and make sure the device
supports alarm output.
Steps
1. Click Access Control → Advanced
Funcon → Device
Parameter to enter access control parameter conguraon
page.
2.
In the device list on the le, click to expand the door, select
an alarm input and you can edit the alarm input's parameters
on the right.
3. Set the alarm output parameters.
Name
Edit the card reader name as desired.
Alarm Output
Acve Time
How long the alarm output will last aer triggered.
4. Click OK.
5. Oponal: Set the switch on the upper right corner to ON to
trigger the alarm output.
Congure Parameters for Lane Controller
Aer adding the lane controller to the client, you can congure its
parameters for passing through the lane.
Steps
1. Click Access Control → Advanced
Funcon → Device
Parameter to enter Parameter Sengs page.
2. In the device list on the le, select a lane controller and you
can edit the lane controller's parameters on the right.
3. Edit the parameters.
Passing Mode
Select the controller which will control the barrier status of
the device.
●
If you select According to DIP
Sengs, the device will follow
the controller's DIP sengs to control the barrier. The
sengs on the soware will be invalid.
●
If you select According to Door's Schedule
Sengs, the
device will follow the schedule congured in the client
soware to control the barrier. The DIP sengs of the
controller will be invalid.
Enable Free Passing
Authencaon
Aer enabling free passing authencaon, an alarm will be
triggered when the passing personnel has no permission to
pass through.
Opening/Closing Barrier Speed
58
Set the barrier's opening and closing speed. You can select
from 1 to 10. The greater the value, the faster the speed.
Note
The recommended value is 6.
Alarm Voice Prompt Duraon
Set how long the audio will last, which is played when an
alarm is triggered.
Note
0 refers to the alarm audio will be played unl the alarm is
ended.
Temperature Unit
Select the temperature unit that displayed in the device
status.
Lightboard Brightness
Set the lightboard brightness.
Barrier Material
Select the material of the barrier gate. You can select the
barrier material from the drop-down list.
Note
The barrier material will aect the device working. Select a
correct barrier material or the barrier may not open.
Lane Length
The width of the lane. You can set the lane width.
Note
The lane width will aect the device working. Set a correct
lane width or the barrier may not open.
Do Not Open Barrier When Lane is Not Clear
If there is someone or something in the lane, the gate will
not open even if the credenal is authencated.
This funcon is designed to avoid more than one person
passing through the gate with only one authencaon.
4. Click OK.
7.7.2
Congure Remaining Open/Closed
You can set the status of the door as open or closed. For example,
you can set the door remaining closed in the holiday, and set the
door remaining open in the
specied period of the work day.
Before You Start
Add the access control devices to the system.
Steps
1. Click Access Control → Advanced
Funcon → Remain Open/
Closed to enter the Remain Open/Closed page.
2. Select the door that need to be
congured on the le panel.
3. To set the door status during the work day, click the Week
Schedule and perform the following operaons.
1) Click Remain Open or Remain Closed.
59
2) Drag the cursor to draw the me duraon, which means in
that duraon of me, the congured access group is
acvated.
Note
Up to 8 me duraons can be set to each day in the week
schedule.
3) Oponal: Perform the following operaons to edit the me
duraons.
●
Move the cursor to the
me duraon and drag the me
duraon
on the meline bar to the desired posion when
the cursor turns to .
●
Click the
me duraon and directly edit the start/end me in
the appeared dialog.
●
Move the cursor to the start or the end of me duraon and
drag to lengthen or shorten the
me duraon when the
cursor turns to .
4) Click Save.
Related Operaons
Copy to
Whole Week
Select one duraon on the me bar, click
Copy to Whole Week to copy all the duraon
sengs on this me bar to other week days.
Delete
Selected
Select one duraon on the me bar, click
Delete Selected to delete this duraon.
Clear Click Clear to clear all the duraon sengs in
the week schedule.
4. To set the door status during the holiday, click the Holiday and
perform the following operaons.
1) Click Remain Open or Remain Closed.
2) Click Add.
3) Enter the start date and end date.
4) Drag the cursor to draw the me duraon, which means in
that
duraon of me, the congured access group is
acvated.
Note
Up to 8 me duraons can be set to one holiday period.
5) Perform the following operaons to edit the me duraons.
●
Move the cursor to the me duraon and drag the me
duraon on the meline bar to the desired posion when
the cursor turns to .
●
Click the me duraon and directly edit the start/end me in
the appeared dialog.
●
Move the cursor to the start or the end of me duraon and
drag to lengthen or shorten the
me duraon when the
cursor turns to
.
6) Oponal: Select the me duraon(s) that need to be
deleted, and then click in the Operaon column to delete
the selected me duraon(s).
7)
Oponal: Click in the Operaon column to clear all the
me duraon(s) in the me bar.
60
8)
Oponal: Click in the Operaon column to delete this
added holiday period from the holiday list.
9) Click Save.
5. Oponal: Click Copy to to copy the door status sengs of this
door to other door(s).
7.7.3 Congure Mul-Factor Authencaon
You can manage the persons by group and set the authencaon
for mulple persons of one access control point (door).
Before You Start
Set access group and apply the access group to the access control
device. For details, refer to
Set Access Group to Assign Access
Authorizaon to Persons.
Perform this task when you want to set authencaons for
mulple cards of one access control point (door).
Steps
1. Click Access Control → Advanced
Funcon → Mul-Factor
Auth .
2. Select an access control device in device list on the le panel.
3. Add a person/card group for the access control device.
1) Click Add on the right panel.
2) Create a name for the group as desired.
3) Specify the start me and end me of the eecve period
for the person/card group.
4) Select members(s) and card(s) in the Available list, and the
selected member(s) and card(s) will be added to the
Selected list.
Note
Make sure you have issue card to the person.
Make sure you have set access group and apply the access
group to the access control device successfully.
5) Click Save.
6) Oponal: Select the person/card group(s), and then click
Delete to delete it(them).
7)
Oponal: Select the person/card group(s), and then click
Apply to re-apply access group that failed to be applied
previously to the access control device.
4. Select an access control point (door) of selected device on the
le panel.
5. Enter the maximum interval when entering password.
6. Add an authencaon group for the selected access control
point.
1) Click Add on the
Authencaon Groups panel.
2) Select a congured template as the authencaon template
from the drop-down list.
Note
For seng the template, refer to Congure Schedule and
Template.
61
3) Select the authencaon type as Local Authencaon, Local
Authencaon and Remotely Open Door, or Local
Authencaon and Super Password from the drop-down
list.
Local Authencaon
Authencaon by the access control device.
Local Authencaon and Remotely Open Door
Authencaon by the access control device and by the
client. When the person swipes the card on the device, a
window will pop up. You can unlock the door via the
client.
Figure 7-7 Remotely Open Door
Note
You can check Oine Authencaon to enable the super
password authencaon when the access control device
is disconnected with the client.
Local Authencaon and Super Password
Authencaon by the access control device and by the
super password.
4) Select the added person/card group in the le list below and
it will be added to the Selected list on the right as the
authencaon group.
5) Click the added authencaon group in the right list to set
authencaon mes in the Auth Times column.
Note
●
The authencaon mes should be larger than 0 and
smaller than the added personnel quanty in the
personnel group.
●
The maximum value of authencaon mes is 16.
6) Click Save.
Note
●
For each access control point (door), up to four
authencaon groups can be added.
●
For the authencaon group of which authencaon type is
Local Authencaon, up to 8 person/card groups can be
added to the
authencaon group.
●
For the authencaon group of which authencaon type is
Local Authencaon and Super Password or Local
Authencaon and Remotely Open Door, up to 7 person/
card groups can be added to the authencaon group.
7.
Click Save.
7.7.4
Congure Custom Wiegand Rule
62
Based on the knowledge of uploading rule for the third party
Wiegand, you can set mulple customized Wiegand rules to
communicate between the device and the third party card
readers.
Before You Start
Wire the third party card readers to the device.
Steps
Note
●
By default, the device disables the custom wiegand funcon. If
the device enables the custom Wiegand funcon, all wiegand
interfaces in the device will use the customized wiegand
protocol.
●
Up to 5 custom Wiegands can be set.
●
For details about the custom Wiegand, see Custom Wiegand
Rule Descripons.
1. Click Access Control → Advanced Funcon → Custom
Wiegand to enter the Custom Wiegand page.
2. Select a custom Wiegand on the
le.
3. Create a Wiegand name.
Note
Up to 32 characters are allowed in the custom Wiegand name.
4. Click Select Device to select the access control device for
seng the custom wiegand.
5. Set the parity mode according to the property of the third
party card reader.
Note
●
Up to 80 bits are allowed in the total length.
●
The odd parity start bit, the odd parity length, the even
parity start bit and the even parity length range from 1 to 80
bit.
●
The start bit of the card ID, the manufacturer code, the site
code, and the OEM should range from 1 to 80 bit.
6. Set output transformaon rule.
1) Click Set Rule to open the Set Output Transformaon Rules
window.
Figure 7-8 Set Output Transformaon Rule
63
2) Select rules on the le list.
The selected rules will be added to the right list.
3) Oponal: Drag the rules to change the rule order.
4) Click OK.
5) In the Custom Wiegand tab, set the rule's start bit, length,
and the decimal digit.
7. Click Save.
7.7.5 Congure Card Reader Authencaon Mode
and Schedule
You can set the passing rules for the card reader of the access
control device according to your actual needs.
Steps
1. Click Access Control → Advanced
Funcon → Authencaon
to enter the authencaon mode conguraon page.
2. Select a card reader on the le to congure.
3. Set card reader authencaon mode.
1) Click Conguraon.
Figure 7-9 Select Card Reader Authencaon Mode
Note
PIN refers to the PIN code set to open the door. Refer to
Congure Access Control Informaon.
2) Check the modes in the Available Mode list and they will be
added to the selected modes list.
3) Click OK.
Aer selecng the modes, the selected modes will display as
icons with dierent color.
4. Click the icon to select a card reader authencaon mode, and
drag the cursor to draw a color bar on the schedule, which
means in that period of
me, the card reader authencaon is
valid.
5. Repeat the above step to set other me periods.
64
Figure 7-10 Set Authencaon Modes for Card Readers
6. Oponal: Select a congured day and click Copy to Week to
copy the same sengs to the whole week.
7. Oponal: Click Copy to to copy the sengs to other card
readers.
8. Click Save.
7.7.6
Congure First Person In
You can set mulple rst persons for one access control point.
Aer the rst person is authorized, it allows mulple persons
access the door or other
authencaon acons.
Before You Start
●
Add access control device to the client, and make sure the
device supports the rst person in funcon.
●
Add person and assign access authorizaon to designed
person. For details, refer to Person Management and Set
Access Group to Assign Access Authorizaon to Persons.
Steps
1. Click Access Control → Advanced
Funcon → First Person In to
enter the First Person In page.
2. Select an access control device in the list on the le panel.
3. Select the current mode as Enable Remaining Open aer First
Person, Disable Remaining Open
aer First Person, or
Authorizaon by First Person from the drop-down list for each
access control point of the selected device.
Enable Remaining Open
aer First Person
The door remains open for the congured me duraon
aer
the rst person is authorized unl the remain open
duraon ends. If you select this mode, you should set the
remain open duraon.
Note
The remain open duraon should be between 0 and 1440
minutes. By default, the remain open duraon is 10 minutes.
Disable Remaining Open aer First Person
Disable the funcon of rst person in, namely normal
authencaon.
Authorizaon by First Person
All authencaons (except for the authencaons of super
card, super password, duress card, and duress code) are
allowed only
aer the rst person authorizaon.
65
Note
You can authencate by the rst person again to disable the
rst person mode.
4. Click Add on the First Person List panel.
5. Select person(s) in the le list and the person(s) will be add to
the selected persons as the rst person(s) of the doors.
The added rst person(s) will list in the First Person List
6. Oponal: Select a rst person from the list and click Delete to
remove the person from the
rst person list.
7. Click Save.
7.7.7 Congure An-Passback
The an-passback feature is designed to minimizes the misuse or
fraudulent use of access
credenals such as passing back card to
an unauthorized person, or tailed access. The an-passback
funcon establishes a specic sequence in which access
credenals must be used in order to grant access. You can set the
sequence according to the actual path via the client and if the
person uses the
credenal in wrong sequence, you can also reset
the an-password records.
Before You Start
Add access control device to the client, and enable the an-
passing
back funcon of the access control device.
Steps
Note
Either the an-passing back or mul-door interlocking funcon
can be congured for an access control device at the same me.
For the conguraon of mul-door interlocking, refer to .
1. Click Access Control → Advanced Funcon → An-Passback to
enter the An-Passpack Sengs page.
2. Select an access control device on the le panel.
3. Select a card reader as the beginning of the path in the First
Card Reader
eld.
4.
Click of the selected rst card reader in the Card Reader
Aerward column to open the select card reader dialog.
5. Select the aerward card readers for the rst card reader.
Note
Up to four aerward card readers can be added as aerward
card readers for one card reader.
6. Click OK in the dialog to save the selecons.
7. Click Save in the An-Passback Sengs page to save the
sengs and take eect.
Example
Set Card Swiping Path: If you select Reader In_01 as the
beginning, and select Reader In_02, Reader Out_04 as the
linked card readers. Then you can only get through the access
control point by swiping the card in the order as Reader In_01,
Reader In_02 and Reader Out_04.
66
8. Click Reset An-Passback and select the person(s) to delete
the related an-passback records about the person(s) on the
device.
Note
This funcon should be supported by the device.
7.7.8 Congure Device Parameters
Aer adding the access control device, you can set its parameters
such as network parameters.
Set RS-485 Parameters
You can set the access control device's RS-485 parameters
including the baud rate, data bit, the stop bit, parity type, ow
control type, communicaon mode, work mode, and connecon
mode.
Steps
Note
The RS-485 Sengs should be supported by the device.
1. Enter the Access Control module.
2. On the navigaon bar on the le, enter Advanced Funcon →
More Parameters .
3. Select an access control device in the device list and click
RS-485 to enter the RS-485
Sengs page.
4. Select the serial port number from the drop-down list to set
the RS-485 parameters.
5. Set the serial number, external device, authencaon center,
baud rate, data bit, stop bit, parity type,
ow control type,
communicaon mode, and working mode in the drop-down
list.
6. Click Save.
●
The
congured parameters will be applied to the device
automacally.
●
When you change the working mode or connecon mode,
the device will reboot
automacally.
Enable M1 Card Encrypon
M1 card encrypon can improve the security level of
authencaon.
Steps
Note
The funcon should be supported by the access control device
and the card reader.
1. Enter the Access Control module.
2. On the navigaon bar on the le, enter Advanced Funcon →
More Parameters .
3. Select an access control device in the device list and click M1
Card
Encrypon Vericaon to enter the M1 Card Encrypon
Vericaon page.
4. Set the switch to on to enable the M1 card encrypon
funcon.
5. Set the sector ID.
67
Note
●
The sector ID ranges from 1 to 100.
●
By default, Sector 13 is encrypted. It is recommended to
encrypt sector 13.
6. Click Save to save the sengs.
7.8 Congure Linkage Acons for Access
Control
You can congure dierent linkage acons for the event detected
by the access control device. Aer that, linkage acons will be
triggered once the event happens. This mechanism is used for
nofying the security personnel the event, or triggering
automac access control in real me.
Two types of linkage acons are supported:
●
Client Acons: When the event is detected, it will trigger the
acons on the client, such as the client making an audible
warning..
●
Device Acons: When the event is detected, it will trigger the
acons of a specic device, such as buzzing of a card reader
and, opening/closing of a door, ..
7.8.1
Congure Client Acons for Access Event
Even if you are far away from an access point, you can sll know
what happens and how urgent the event is via the client by
conguring client acons for the access event. Client acons here
refer to the acons automacally executed by the client itself,
such as making an audible warning and sending an email. Once
an event is triggered, the client will
nofy the security personnel,
so that he/she can handle the event in
me.
Before You Start
Add access control device to the client.
Steps
1. Click Event
Conguraon → Access Control Event .
The added access control devices will display in the device list.
2. Select a resource (including device, alarm input, door, and card
reader) from the device list.
The event types which the selected resource supports appear.
3. Select the event(s) and click Edit Priority to dene the priority
for the event(s), which can be used to
lter events in the Event
Center.
4. Set the linkage acons of the event.
1) Select the event(s) and click Edit Linkage to set the client
acons when the event(s) are triggered.
Audible Warning
The client soware gives an audible warning when the
event is triggered. You can select alarm sound for the
audible warning.
Note
For details about seng the alarm sound, refer to Set
Alarm Sound in the user manual of the client soware.
Send Email
68
Send an email nocaon about the event to one or more
receivers.
For details about seng email parameters, refer to Set
Email Parameters in the user manual of the client
soware.
2) Click OK.
5. Enable the event so that when the event is detected, event will
be sent to the client and the linkage acons will be triggered.
6. Oponal: Click Copy to to copy the event sengs to other
access control device, alarm input, door, or card reader.
7.8.2 Congure Device Acons for Access Event
You can set the access control device's linkage acons for the
access control device's triggered event. Aer that, when an event
is triggered, it can trigger the alarm output, buzzer on access
controller, and other
acons.
Steps
Note
The linkage acons should be supported by the device.
1. Click Access Control → Linkage Conguraon .
2. Select the access control device from the list on the le.
3. Click Add to add a new linkage.
4. Select Event Linkage as the event source.
5. select the event type and detailed event to set the linkage.
6. In the Linkage Target area, set the property target to enable
this
acon.
Buzzer on Controller
The audible warning of access control device will be
triggered.
Capture
An event-related picture will be captured when the selected
event happens.
Recording
An event-related picture will be captured when the selected
event happens.
Note
The device should support recording.
Buzzer on Reader
The audible warning of card reader will be triggered.
Alarm Output
The alarm output will be triggered for nocaon when the
selected event happens
Alarm Input
Arm or disarm the alarm input.
Note
The device should support alarm input funcon.
Access Point
69
The door status of open, close, remain open, or remain close
will be triggered.
Note
The target door and the source door cannot be the same
one.
Audio Play
The audio prompt will be triggered. And the select audio
index related audio content will be played according to the
congured play mode.
7. Click Save.
8. Oponal: Aer adding the device linkage, you can do one or
more of the followings:
Edit Linkage
Sengs
Select the congured linkage sengs in the
device list and you can edit its event source
parameters, including event source and
linkage target.
Delete
Linkage
Sengs
Select the congured linkage sengs in the
device list and click Delete to delete it.
7.8.3 Congure Device Acons for Card Swiping
You enable access control device's linkage acons (such as
disarming a zone and triggering audio prompt) for the swiping of
a specic card, In this way, you can monitor the card holder's
behaviors and whereabouts.
Steps
Note
It should be supported by the device.
1. Click Access Control → Linkage Conguraon .
2. Select the access control device from the list on the
le.
3. Click Add to add a new linkage.
4. Select Card Linkage as the event source.
5. Enter the card number or select the card from the drop-down
list.
6. Select the card reader where the card swipes.
7. In the Linkage Target area, set the property target to enable
this
acon.
Buzzer on Controller
The audible warning of access control device will be
triggered.
Buzzer on Reader
The audible warning of card reader will be triggered.
Capture
An event-related picture will be captured when the selected
event happens.
Recording
An event-related picture will be captured when the selected
event happens.
70
Note
The device should support recording.
Alarm Output
The alarm output will be triggered for nocaon.
Alarm Input
Arm or disarm the alarm input.
Note
The device should support alarm input funcon.
Access Point
The door status of open, close, remain open, or remain
closed will be triggered.
Audio Play
The audio prompt will be triggered. And the select audio
index related audio content will be played according to the
congured play mode.
8. Click Save.
When the card (congured in Step 5) swipes on the card reader
(congured in Step 6), it can trigger the linked acons
(congured in step 7).
9. Oponal: Aer adding the device linkage, you can do one or
more of the followings:
Delete
Linkage
Sengs
Select the congured linkage sengs in the
device list and click Delete to delete it.
Edit Linkage
Sengs
Select the congured linkage sengs in the
device list and you can edit its event source
parameters, including event source and
linkage target.
7.9 Door Control
In Monitoring module, you can view the real-me status of the
doors managed by the added access control device. You can also
control the doors such as open/close the door, or remain the
door open/closed via the client remotely. The
real-me access
event are displayed in this module. You can view the access
details and person details.
Note
For the user with door control permission, the user can enter the
Monitoring module and control the door. Or the icons used for
control will not show. For seng the user permission, refer to
Person Management.
7.9.1 Control Door Status
You can control the status for the door(s), including unlock door,
locking door, remaining the door unlock, remaining the door
locked, remain all unlocked, etc.
Before You Start
●
Add person and assign access
authorizaon to designed
person, and person will have the access
authorizaon to the
access points (doors). For details, refer to Person Management
71
and Set Access Group to Assign Access Authorizaon to
Persons.
●
Make sure the operaon user has the permission of the access
points (doors).
Steps
1. Click Monitoring to enter the status monitoring page.
2. Select an access point group on the upper-right corner.
Note
For managing the access point group, refer to Group
Management.
The doors in the selected access control group will display.
3. Click a door icon to select a door, or press Ctrl and select
mulple doors.
Note
For Remain All Unlocked and Remain All Locked, ignore this
step.
4. Click the following buons to control the door.
Unlock
When the door is locked, unlock it and it will be open for
once.
Aer the open duraon, the door will be closed and
locked again automacally.
Lock
When the door is unlocked, lock it and it will be closed. The
person who has the access authorizaon can access the door
with
credenals.
Remain Unlocked
The door will be unlocked (no maer closed or open). All the
persons can access the door with no credenals required.
Remain Locked
The door will be closed and locked. No person can access the
door even if he/she has the authorized
credenals, except
the super users.
Remain All Unlocked
All doors in the group will be unlocked (no maer closed or
open). All the persons can access the doors with no
credenals required.
Remain All Locked
All doors in the group will be closed and locked. No person
can access the doors even if he/she has the authorized
credenals, except the super users.
Capture
Capture a picture manually.
Note
The Capture buon is available when the device supports
capture funcon. The picture is saved in the PC running the
client. For seng the saving path, refer to Set File Saving
Path in the user manual of the client soware.
72
Result
The icon of the doors will change in real-me according to the
operaon if the operaon is succeeded.
7.9.2 Check Real-Time Access Records
The access records will display in real
me, including card swiping
records, face recognions records, ngerprint comparison
records, etc. You can view the person informaon and view the
picture captured during access.
Steps
1. Click Monitoring and select a group from the drop-down list on
the upper-right corner.
The access records triggered at the doors in the selected group
will display in real
me. You can view the details of the records,
including card No., person name, organizaon, event me, etc.
2. Oponal: Check the event type and event status so that these
events will show in the list if the events are detected. The
events of unchecked type or status will not be displayed in the
list.
3.
Oponal: Check Show Latest Event and the latest access
record will be selected and displayed at the top of the record
list.
4.
Oponal: Click the event to view the accessed person details,
including person pictures (captured picture and prole), person
No., person name,
organizaon, phone, contact address, etc.
Note
You can double click the captured picture to enlarge it to view
the details.
5. Oponal: Right click on the column name of the access event
table to show or hide the column according to actual needs.
7.10 Event Center
The event informaon (for example, device oine) received by
the client displays. In the Event Center, you can check the detailed
informaon of the real-me and historical events, view the event
linked video, handle the events, and so on.
Before the client can receive the event informaon from the
device, you need to enable the events of the resource and arm
the device
rst. For details, refer to Enable Receiving Event from
Devices.
7.10.1 Enable Receiving Event from Devices
Before the client soware can receive event nocaons from
the device, you need to arm the device
rst.
Steps
1.
Click
→ Tool → Device Arming Control to open Device
Arming Control page.
All the added devices appear on this page.
2. In the Auto-Arming column, turn on the switch to enable auto-
arming.
73
Figure 7-11 Arm Device
Aer turned on, the device(s) will be armed. And nocaons
about the events triggered by the armed device(s) will be
automacally sent to the client soware in real-me.
7.10.2 View Real-Time Events
The real-me event informaon received by the client of the
connected resources are displayed. You can check the real-me
event informaon, including event source, event me, priority,
etc.
Before You Start
Enable receiving events from devices before the client can receive
event from the device, see
Enable Receiving Event from Devices
for details.
Steps
1. Click Event Center →
Real-me Event to enter the real-me
event page and you can view the real-me events received by
the client.
Event Time
For encoding device, event
me is the client me when it
receives the event. For other device types, event me is the
me when the event is triggered.
Priority
Priority represents the emergency degree of the event.
2. Filter the events.
Filter by Device Type
and (or) Priority
Select device type(s) and (or)
priories to lter events.
Filter by Keywords Enter the keywords to lter the
events.
3. Oponal: Right-click the table header of the event list to
customize the event related items to be displayed in the event
list.
4. Select an event in the event list to view the event details.
5.
Oponal: Perform the following operaons if necessary.
Handle Single
Event
Click Handle to enter the processing
suggeson, and then click OK.
Note
Aer an event is handled, the Handle
buon will become Add Remark. Click
Add Remark to add more remarks for
this handled event.
Handle Events in
a Batch
Select events that need to be
processed, and then click Handle in
74
Batch. Enter the processing suggeson,
and then click OK.
Enable/Disable
Alarm Audio
Click Audio On/Mute to enable/disable
the audio of the event.
Select the Latest
Event
Automacally
Check Auto-Select Latest Event to
select the latest event automacally
and the event informaon details is
displayed.
Clear Events Click Clear to clear the all the events in
the event list.
Send Email Select an event and then click Send
Email, and the informaon details of
this event will be sent by email.
Note
You should congure the email
parameters rst, see Set Email
Parameters in the user manual of the
client soware for details.
Auto-Play Video Check Auto-Play Video to automacally
play video when displaying event
details.
Enlarge Video or
●
Double click the video image to view
video in a larger window.
●
Put the cursor on the picture, and
click
to view picture in a larger
window.
Download
Captured Picture
Hover the cursor on the captured
picture, and click the download icon on
the lower right corner of the picture to
download it to the local PC.
Download Event
Triggered Video
Hover the cursor on the recorded video,
click to download the video (30s
before the event happens) triggered by
the event.
7.10.3 Search Historical Events
You can search and view historical events by seng search
condions such as me, device type, and priority in the client. For
the searched events, you can handle and export them.
Before You Start
Enable receiving events from devices before the client can receive
event
informaon from the device,see Enable Receiving Event
from Devices for details.
Steps
1. Click Event Center → Event Search to enter the event search
page.
2. Set the
lter condions to display the required events only.
Time
The
me when the event starts.
Search by
75
Device
Search the events by device or the device's resource
channels. If searched by device, you need to set the
followings:
●
Include Sub-Node: Search the events of the device and all
resource channels.
●
Device Type: Select the device from which you want to
search events.
Group
Search the events by resource channels in the group.
Note
●
For video intercom device, you need to select search
scope: All and Locking Log.
●
For access control device, you can click Show More to
set more condions: status, event type, card reader
type, person name, card No., and
organizaon.
Priority
The priority including low, medium, high and uncategorized
which indicates the emergency degree of the event.
Event Type
Select one or more event types to be searched from the
drop-down list.
Note
You can enter a key word (supports fuzzy search) in the
search box to search the target event type(s).
Status
The handling status of the event.
Search by Keyword
Enter a key word (supports fuzzy search) to quickly search
the target historical event(s). For example, you can enter a
person's name to search the events related with this person.
3. Click Search to search the events according the
condions you
set.
Figure 7-12 Search Historical Events
Note
If you have selected Access Control as device type in Step 2,
you can view extra informaon such as card No., skin-surface
temperature, and abnormal temperature (if device supports) in
the searched events.
76
Figure 7-13 Search Historical Event
4. Oponal: Right click the table header of the event list to
customize the event related items to be displayed in the event
list.
5. Select an event in the event list to view the event details.
6.
Oponal: Perform one of the following operaons.
Handle Single
Event
Handle single event: Select one event that
needs to be handled, and then click Handle
in the event informaon details page, and
enter the handling suggeson.
Note
Aer an event is handled, the Handle
buon will become Add Remark, click Add
Remark to add more remarks for this
handled event.
Batch Handle
Events
Handle events in a batch: Select the events
which need to be handled, and then click
Handle in Batch, and enter the handling
suggeson.
Note
Aer an event is handled, the Handle
buon will become Add Remark, click Add
Remark to add more remarks for this
handled event.
Auto-Play
Video
Check Auto-Play Video to automacally
play video when displaying event details.
Enlarge Video
or Picture
●
Double click the video image to view
video in a larger window.
●
Put the cursor on the picture, and click
to view picture in a larger window.
Send Email Select an event and then click Send Email,
and the informaon details of this event
will be sent by email.
Note
You should congure the email parameters
rst, see Set Email Parameters in the user
manual of the client soware for details.
77
Export Event
Informaon
Click Export to export the event log or
event pictures to the local PC in CSV/Excel
le. You can set the saving path manually.
Download
Captured
Hover the cursor on the captured picture,
and click the download icon on the lower
right corner of the picture to download it
to the local PC.
Download
Event
Triggered
Video
Hover the cursor on the recorded video,
click to download the video (30s before
the event happens) triggered by the event.
7.11 Remote Conguraon via Client
Soware
Congure device parameters remotely.
7.11.1 Check Device
Informaon
Steps
1. Click Maintenance and Management → Device Management
→ Device to enter the device list.
2.
Click to enter the remote conguraon page.
3. Click System → Device Informaon and view the device basic
informaon and the device version informaon.
7.11.2 Edit Device Name
Click Maintenance and Management → Device Management →
Device to enter the device list.
Click to enter the remote conguraon page.
Click System → General to congure the device name and
overwrite record
les parameter.
Click Save.
7.11.3 Edit Time
Steps
1. Click Maintenance and Management → Device Management
→ Device to enter the device list.
2.
Click
to enter the remote conguraon page.
3. Click System → Time to congure the me zone.
4. Oponal: Check Enable NTP and set the NTP server address,
the NTP port, and the synchronizaon interval.
5. Oponal: Check Enable DST and set the DST start me, end
me and the bias.
6. Click Save.
7.11.4 Set System Maintenance
You can reboot the device remotely, restore the device to default
sengs, etc.
Steps
1. Click Maintenance and Management → Device Management
→ Device to enter the device list.
2.
Click
to enter the remote conguraon page.
3. Click System → System Maintenance .
78
4. Maintain the device.
Reboot
The device starts reboong.
Restore Default Sengs
Restore the device sengs to the default ones, excluding the
IP address.
Restore All
Restore the device parameters to the default ones. The
device should be
acvated aer restoring.
5. Remotely upgrade the device.
1) In the Remote Upgrade part, select an upgrade type.
Note
●
You need to set the device ID before upgrading if you
select Controller Upgrade File as the remote upgrade
type.
●
Only the card reader that connected via RS-485 protocol
supports upgrading.
2) Click ... to select an upgrade le.
3) Click Upgrade to start upgrading.
Note
Do not power o during the upgrading.
7.11.5 Manage Network User
Steps
1. Click Maintenance and Management → Device Management
→ Device to enter the device list.
2.
Click
to enter the remote conguraon page.
3. Click System → User → Network User .
4. Click Add to add the user.
5. Oponal: Select a user in the user list and click Edit to edit the
user.
You are able to edit the user password, the IP address, the
MAC address and the user permission.
6. Click OK.
7.11.6 Manage Keyfob User
Steps
1. Click Maintenance and Management → Device Management
→ Device to enter the device list.
2.
Click
to enter the remote conguraon page.
3. Click System → User → Keyfob User .
4. Click Add to add the user.
5. Check Enable in the pop-up window and set the keyfob's serial
No.
6. Oponal: Enable the Remain Open Status of the turnsle.
79
Note
If enabling this funcon, aer the keyfob is matching
completed, you can set the barrier as remaining open by using
the keyfob.
7. Set the door open direcon
8. Click OK.
Note
Up to 32 keyfob users can be added.
7.11.7 Set Security
Steps
1. Click Maintenance and Management → Device Management
→ Device to enter the device list.
2.
Click to enter the remote conguraon page.
3. Click System → Security .
4. Select the density level in the drop-down list.
5. You can select Compable Mode or Security Mode.
Compable Mode
The user informaon vericaon is compable with the old
client soware version when logging in.
Security Mode
High security level during the user informaon vericaon
when logging in.
6. Click Save.
7.11.8
Congure Lane Parameters
You can set the passing parameters for a person to pass through
the turnsle.
Steps
1. Click Maintenance and Management → Device to enter the
device list.
2.
Click
to enter the remote conguraon page.
3. Click System → Lane Sengs .
4. Set the lane parameters.
Door Closing Delay Time
Set the delayed me duraon when barrier is closing. The
barrier will be closed
aer the congured delayed me.
Max. Intrusion Duraon
If a person has entered the lane or passed through the lane
for more than the congured me duraon, an alarm will be
triggered. 0 represents the
funcon is disabled.
Note
The suggested minimum detecon me duraon is 2 s.
Overstaying Duraon
If the device detects persons or things staying in the lane for
more than the
congured me duraon, an alarm will be
triggered.
80
Max IR Obstructed Duraon
Set the maximum me duraon for the obstrucon of the IR
light. If the IR light is obstructed for more than the
congured me duraon, the alarm will be triggered. 0
represents the
funcon is disabled.
5. Click Save.
7.11.9 Congure Screen Parameters
The device can connect to a text screen. You can set the display
parameters on this page.
Steps
1. Click Maintenance and Management → Device Management
→ Device to enter the device list.
2.
Click
to enter the remote conguraon page.
3. Click System → Screen Conguraon .
4. Set the screen parameters.
Note
For beer performance, it is suggested to use the default
parameters.
Screen Posion
Select the screen's posion on the device. If select Exit from
the drop-down list, the screen will be installed at the exit
posion of the device.
Screen Model
Select the screen model from the drop-down list.
Font Size
Select the text font size in the screen.
Screen Orientaon
Select the text orientaon on the screen.
Line Space
Set the space between two lines.
Column Spacing
Set the space between two columns.
Inial Posion
Set the rst character's posion displayed on the screen.
5. Click Save.
7.11.10
Congure Screen Parameters
You can set the people counng's parameters and aer the
conguraon.
Steps
1. Click Maintenance and Management → Device Management
→ Device to enter the device list.
2.
Click
to enter the remote conguraon page.
3. Click System → People Counng .
4. Set the people counng parameters.
Clear Device People Counng
81
Click Reset and the counted people number will be restored
to zero.
Device People Counng
Click Enable or Disable to enable or disable the people
counng funcon.
Client Oine People Counng
Click Enable or Disable to enable or disable funcon of the
oine people counng on the client.
If enabling the funcon and if the device is oine, the
device will
connue counng the people and the number
will be stored in the device. When the device is online, the
client will read the updated number from the device
automacally.
People Counng Type
You can select from Invalid, By Detecon, and By
Authencaon Number.
Invalid
The device will not count people. If the device people
counng funcon is enabled, the people counng
funcon
is sll disabled.
By Detecon
The device will count the people who passing through the
device depending on the detecon result.
By Authencaon Number
The device will count the people who authencang on
the device.
The failed authencaon will also count as once.
5. Click Save.
7.11.11
Congure Advanced Network
Click Maintenance and Management → Device Management →
Device to enter the device list.
Click to enter the remote conguraon page.
Click Network → Advanced Sengs and you can congure the
DNS IP address 1 and the DNS IP address.
Click Save to save the sengs.
7.11.12
Congure Audio File
You can relate the audio le to the corresponding playing scene.
You can also export the audio le from the system and import the
audio
le from the local.
Steps
1. Click Maintenance and Management → Device Management
→ Device to enter the device list.
2.
Click
to enter the remote conguraon page.
3. Click Other → Audio File .
Note
By default, the system contains the audio content. For details
about the index related audio content, see Table of Audio
Index Related Content.
4. Select the index (the playing content) corresponded play scene.
82
5. Oponal: Input the descripons of the play scene.
6. Click Save Parameters to save the relaonship between the
index (the playing content) and the play scene.
7. Oponal: Click Export to export the default audio le to the
local computer.
8. Oponal: Click ... and select audio le from the local computer.
Click Import to import the le to the device.
Note
●
The imported audio le should be in MEM format.
●
For details about converng other format of the audio le to
MEM format, see the audio conversion manual.
●
If you use the third part soware to create or edit an audio
le, the volume of the audio le should be no less than 0 ×
68. If the volume is less than the value, it will exceed the
loudspeaker's power
consumpon, so that damage the
loudspeaker.
7.11.13 Congure Passing Record
You can record and upload passing events.
Click Maintenance and Management → Device Management →
Device to enter the device list.
Click to enter the remote conguraon page.
Click Other → Turnsle Management .
Check Enable Passing Record. Aer enabled, the device will
record and upload passing events.
Click Save.
7.11.14
Congure Parameters for Lane Controller
Aer adding the lane controller to the client, you can congure its
parameters for passing through the lane.
Steps
1. Click Access Control → Advanced
Funcon → Device
Parameter to enter Parameter Sengs page.
2. In the device list on the le, select a lane controller and you
can edit the lane controller's parameters on the right.
3. Edit the parameters.
Passing Mode
Select the controller which will control the barrier status of
the device.
●
If you select According to DIP
Sengs, the device will follow
the controller's DIP sengs to control the barrier. The
sengs on the soware will be invalid.
●
If you select According to Door's Schedule Sengs, the
device will follow the schedule congured in the client
soware to control the barrier. The DIP sengs of the
controller will be invalid.
Enable Free Passing
Authencaon
Aer enabling free passing authencaon, an alarm will be
triggered when the passing personnel has no permission to
pass through.
Opening/Closing Barrier Speed
83
Set the barrier's opening and closing speed. You can select
from 1 to 10. The greater the value, the faster the speed.
Note
The recommended value is 6.
Alarm Voice Prompt Duraon
Set how long the audio will last, which is played when an
alarm is triggered.
Note
0 refers to the alarm audio will be played unl the alarm is
ended.
Temperature Unit
Select the temperature unit that displayed in the device
status.
Lightboard Brightness
Set the lightboard brightness.
Barrier Material
Select the material of the barrier gate. You can select the
barrier material from the drop-down list.
Note
The barrier material will aect the device working. Select a
correct barrier material or the barrier may not open.
Lane Length
The width of the lane. You can set the lane width.
Note
The lane width will aect the device working. Set a correct
lane width or the barrier may not open.
Do Not Open Barrier When Lane is Not Clear
If there is someone or something in the lane, the gate will
not open even if the credenal is authencated.
This funcon is designed to avoid more than one person
passing through the gate with only one authencaon.
4. Click OK.
7.11.15
Congure IR Detectors
You can set an-pinch for barrier closing, inducve mode and IR
mode.
Steps
1. Click Maintenance and Management → Device to enter the
device list.
2.
Click
to enter the remote conguraon page.
3. Click Other → Turnsle Module Management .
4. Check to enable Custom An-Pinch for Barrier Closing. When
the device detects that there are people staying in the lane, the
barrier will not close.
Aer enabled, you can uncheck some IR
beam No., allowing the barrier to close early. However, when
the barrier is opened or closed, it may cause injury to
pedestrians.
84
5. Select Inducve Mode (Entrance), Inducve Mode (Exit).
6. Select IR Mode. When you select Panic Mode, you can uncheck
the damaged IR beam No. and temporarily restore the lane to
normal use. However, when the barrier is opened or closed, it
may cause injury to pedestrians.
7. Click Save.
7.11.16 View Relay Status
Click Maintenance and Management → Device Management →
Device to enter the device list.
Click to enter the remote conguraon page.
Click Status → Relay and you can view the relay status.
85
A. Tips for Scanning Fingerprint
Recommended Finger
Forenger, middle nger or the third nger.
Correct Scanning
The gure displayed below is the correct way to scan your nger:
You should press your nger on the scanner horizontally. The
center of your scanned nger should align with the scanner
center.
Incorrect Scanning
The gures of scanning ngerprint displayed below are incorrect:
Environment
The scanner should avoid direct sun light, high temperature,
humid
condions and rain.
When it is dry, the scanner may not recognize your ngerprint
successfully. You can blow your nger and scan again.
Others
If your ngerprint is shallow, or it is hard to scan your ngerprint,
we recommend you to use other authencaon methods.
If you have injuries on the scanned nger, the scanner may not
recognize. You can change another
nger and try again.
86
B. DIP Switch
87
B.1 DIP Switch Descripon
The DIP switch is on the main lane control board. No.1 to No 8 is
from the low bit to the high bit.
When the switch is towards ON, it means the switch is enabled,
otherwise, the switch is
o. If you set the DIP switch like the
gure displayed below, its binary value is 00001100, and its
decimal value is 12.
88
B.2 DIP Switch Corresponded Funcons
Note
Aer seng the DIP switch, you should reboot the device, or the
funcon cannot take eect.
The 8-bit DIP switch corresponded
funcons on the access
control board are as follows:
Bit
Device
Mode
Funcon
Decimal
Value
Binary
Value
1 to 2 Work Mode
Normal
Mode
0
Test Mode 2
3
Memory
Mode
Enable
Memory
Mode
0
Disable
Memory
Mode
1
4
Keyfob
Paring
Mode
Enable
Keyfob
Paring
Mode
1
Disable
Keyfob
Paring
Mode
0
5 to 8
Passing
Mode
Controlled
Bi-direcon
0
89
Bit
Device
Mode
Funcon
Decimal
Value
Binary
Value
Controlled
Entrance
and Prohibit
Exit
1
Controlled
Entrance
and Free
Exit
2
Free Bi-
direcon
3
Free
Entrance
and
Controlled
Exit
4
Free
Entrance
and Prohibit
Exit
5
Prohibited
Bi-direcon
6
Prohibit
Entrance
and
Controlled
Exit
7
Prohibit
Entrance
and Free
Exit
8
90
C. Event and Alarm Type
Event Alarm Type
Tailgang Visual and Audible
Reverse Passing Visual and Audible
Force Accessing None
Climb over
Barrier
Visual and Audible
Overstay Visual and Audible
Passing Timeout None
Intrusion Visual and Audible
Free Passing
Authencaon
Failed
Visual
Barrier
Obstructed
None
91
D. Table of Audio Index Related
Content
Index Content
1 Authencated.
2 Card No. does not exist.
3 Card No. and ngerprint mismatch.
4 Climbing over the barrier.
5 Reverse passing.
6 Passing meout.
7 Intrusion.
8 Force accessing.
9 Tailgang.
10 No permissions.
11 Authencaon me out.
12 Authencaon failed.
13 Expired card.
14 Staying out of me.
92
E. Error Code Descripon
The swing barrier will display the error code on the seven-
segment display if error occurred. Refer to the table below to nd
the descripon of each number.
Error Reason Code Error Reason Code
Normal Working 00
Lower Fih IR Beam
Triggered
21
First IR Beam
Triggered
01
Lower Sixth IR Beam
Triggered
22
Second IR Beam
Triggered
02
Lower Seventh IR
Beam Triggered
23
Third IR Beam
Triggered
03
Lower Eighth IR Beam
Triggered
24
Fourth IR Beam
Triggered
04
Lower Ninth IR Beam
Triggered
25
Fih IR Beam
Triggered
05
Lower Tenth IR Beam
Triggered
26
Sixth IR Beam
Triggered
06
Lower Eleventh IR
Beam Triggered
27
Seventh IR Beam
Triggered
07
Lower Twelh IR Beam
Triggered
28
Eighth IR Beam
Triggered
08
Lower Thirteenth IR
Beam Triggered
29
Ninth IR Beam
Triggered
09
Lower Fourteenth IR
Beam Triggered
30
IR Beam Triggered 10
Lower Fieenth IR
Beam Triggered
31
Eleventh IR Beam
Triggered
11
Lower Sixteenth IR
Beam Triggered
32
Twelh IR Beam
Triggered
12
Light Board Oine
(Entrance)
49
Thirteenth IR Beam
Triggered
13
Light Board Oine
(Exit)
50
Fourteenth IR Beam
Triggered
14 IR Adapter Oine (Up) 51
Fieenth IR Beam
Triggered
15
IR Adapter Oine
(Low)
52
Sixteenth IR Beam
Triggered
16 CAN Bus Excepon 53
Lower First IR Beam
Triggered
17 Not Studying 54
Lower Second IR Beam
Triggered
18 Obstrucon 55
93
Error Reason Code Error Reason Code
Lower Third IR Beam
Triggered
19
Exceeding Studying
Range
56
Lower Fourth IR Beam
Triggered
20 Motor Excepon 57
94
F. Communicaon Matrix and Device
Command
Communicaon Matrix
Scan the following QR code to get the device communicaon
matrix.
Note that the matrix contains all
communicaon ports of
Hikvision access control and video intercom devices.
Figure F-1 QR Code of Communicaon Matrix
Device Command
Scan the following QR code to get the device common serial port
commands.
Note that the command list contains all commonly used serial
ports commands for all Hikvision access control and video
intercom devices.
Figure F-2 Device Command
95
